Jacobsen TURFCAT-623D User manual

WARNING: If incorrectly used this machine can cause severe injury. Those who use
and maintain this machine should be trained in its proper use, warned of its dangers
and should read the entire manual before attempting to set up, operate, adjust or
service the machine.
4114895 REV B
SETUP, PARTS & MAINTENANCE
MANUAL TURFCAT 600 SERIES
FOR USE WITH OPERATION & SAFETY MANUAL 4114896
Model:
946718 TURFCAT - 623D 2WD AXLE US
946719 TURFCAT - 628D 2WD AXLE US

CALIFORNIA
Proposition 65 Warning
Diesel engine exhaust and some of
its constituents are known to the State
of California to cause cancer, birth
defects and other reproductive harm.
Californie Proposition 65
Avertissement
Les échappements des moteurs diesel
et certains de leurs composés sont
reconnus par l’Etat de Californie pour
être cancérigènes, provoquer des
défauts congénitaux et d’autres dangers
en matière de reproduction.
ADVERTENCIA
AVERTISSEMENT
WARNING
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects or other reproductive harm.
California Advertencia
de la Proposicion 65
El estado de California hace saber que
los gases de escape de los motores
diesel y algunos de sus componentes
producen cáncer, defectos de
nacimiento y otros daños en el
proceso de reproducción humana.
L’ é mission du moteur de ce mat é riel
contient des produits chimiques que
l’Etat de Californie consid è re ê tre
canc é rig è nes, provoquer des d é fauts
cong é nitaux et d’autres dangers en
mati è re de reproduction.
El estado de California hace saber
que los gases de escape de este
producto contienen productos
quÍmicos que producen cáncer,
defectos de nacimiento y otros daños
en el proceso de reproducción
humana.
© 2002, TEXTRON INC

1
600 Series
Turfcat
Tractors
8-2002-TGTSP
IMPORTANT MESSAGE
ThankyouforpurchasingthisJacobsenproduct. Youhavepurchasedaworldclassmowingproduct,oneofthebest
designedandbuiltanywhere.
ThismachinecomeswithanOperationandSafetyManualandaseparateSetup,PartsandMaintenanceManual.
Theusefullifeandgoodserviceyoureceivefromthismachinedependstoalargeextentonhowwellyoureadand
understandthesemanuals.Treatyourmachineproperly,lubricateandadjustitasinstructed,anditwillgiveyoumany
yearsofreliableservice.
YoursafeuseofthisJacobsenproductisoneofourprimedesignobjectives. Manysafetyfeaturesarebuiltin,but
wealsorelyonyourgoodsenseandcaretoachieveaccident-freeoperation. Forbestprotection,studythemanuals
thoroughly. Learn the proper operation of all controls. Observe all safety precautions. Follow all instructions and
warningscompletely. Donotremoveordefeatanysafetyfeatures. Makesurethosewhooperatethismachineare
as well informed and careful in its use as you are.
SeeaJacobsendealerforanyserviceorpartsneeded. Jacobsenserviceensuresthatyoucontinuetoreceive the
best results possible from Jacobsen products. You can trust Jacobsen replacement parts because they are
manufactured with the same high precision and quality as the original parts.
Jacobsendesignsandbuildsitsequipmenttoservemanyyearsinasafeandproductivemanner. Forlongestlife,
usethismachineonlyasdirectedinthemanuals,keepitingoodrepairandfollowsafetywarningsandinstructions.
You'll always be glad you did. Textron Golf, Turf & Specialty Products
One Bob Cat Lane
Johnson Creek, WI 53038-0469
TABLEOF CONTENTS FIGURES PAGE
SAFETY................................................................................................................................................................... 2
ASSEMBLY & SETUP ......................................................................................................................................... 3-8
MAINTENANCE.................................................................................................................................................. 9-16
PARTS SECTION .................................................................................................................................................. 17
FRAME & FRONT AXLE ASSEMBLY ...................FIGURE 1 .......................................................................18, 19
REAR AXLE ASSEMBLY .......................................FIGURE 2 .......................................................................20, 21
ENGINE MOUNTING 623D & 628D .......................FIGURE 3 .......................................................................22, 23
RADIATOR MOUNTING..........................................FIGURE 4 .......................................................................24, 25
FUEL SEPARATOR/AIR CLEANER ......................FIGURE 5 .......................................................................26, 27
TRANSMISSION/DIFFERENTIAL ..........................FIGURE 6 .......................................................................28, 29
PEDAL CONTROLS ...............................................FIGURE 7 .......................................................................30, 31
LIFT CYLINDER MOUNTING .................................FIGURE 8 .......................................................................32, 33
HOOD ASSEMBLY ................................................FIGURE 9 .......................................................................34, 35
SEAT & PLATFORM ASSEMBLY .........................FIGURE 10 .....................................................................36, 37
STEERING..............................................................FIGURE 11 .....................................................................38, 39
INSTRUMENT PANEL ............................................FIGURE 12 .....................................................................40, 41
HYDRAULIC DIAGRAM .........................................FIGURE 13 .....................................................................42, 43
TRACTION ASSIST BRAKES-970212 ...................FIGURE 14 .....................................................................44, 45
FUEL DIAGRAM.....................................................FIGURE 15 .....................................................................46, 47
ELECTRICAL DIAGRAM 723D & 728D .................FIGURE 16 .....................................................................48, 49
EATON M-11 TRANSMISSION ..............................FIGURE 17 .....................................................................50, 51
DIFFERENTIAL BREAKDOWN .............................FIGURE 18 .....................................................................52, 53
MISCELLANEOUS OPTIONS................................FIGURE 19 .....................................................................54, 55
DECALS .................................................................FIGURE 20 .....................................................................56, 57
ELECTRICAL SCHEMATIC ....................................FIGURE 21 ........................................................................... 58
HYDRAULIC SCHEMATIC .....................................FIGURE 22 ........................................................................... 59

2
600 Series
Turfcat
Tractors
SPECIFICTORQUES:
BLADEBOLT:70FT-LBS(95Nm)
WHEELHUBNUTS:300FT-LBS(407Nm)
REARWHEELS:80FT-LBS(108Nm)
FRONTWHEELS:55FT-LBS(75Nm)
PTOCLUTCHBOLTTO45FT-LBS(61Nm)
NOTICE!!!
Unauthorized modifications may present extreme
safetyhazardstooperatorsandbystandersandcould
alsoresult in product damage.
Textron Golf, Turf & Specialty Products strongly
warns against, rejects and disclaims any
modifications, add-on accessories or product
alterationsthatarenotdesigned,developed,tested
andapprovedbyTextronGolf,Turf&SpecialtyProducts
Engineering Department. Any Textron Golf, Turf &
SpecialtyProductsproductthatisaltered,modifiedor
changed in any manner not specifically authorized
after original manufacture–including the addition of
“after-market” accessories or component parts not
specificallyapprovedbyTextronGolf,Turf&Specialty
Products–willresultintheTextronGolf,Turf&Specialty
ProductsWarrantybeingvoided.
Anyandallliabilityforpersonalinjuryand/orproperty
damagecausedbyanyunauthorizedmodifications,
add-on accessories or products not approved by
Textron Golf, Turf & Specialty Products will be
considered the responsibility of the individual(s) or
company designing and/or making such changes.
TextronGolf,Turf&SpecialtyProductswillvigorously
pursuefullindemnificationandcostsfromanyparty
responsibleforsuchunauthorizedpost-manufacture
modifications and/or accessories should personal
injuryand/orpropertydamageresult.
This symbol means:
ATTENTION!
BECOME ALERT!
Yoursafetyandthesafetyofothers is involved.
Signal word definitions:
Thesignalwordsbelowareusedtoidentifylevelsof
hazard seriousness. These words appear in this
manualandonthesafetylabelsattachedtoTextron
Golf,Turf&Specialty machines.Foryoursafetyand
thesafetyofothers,readand followtheinformation
given with these signal words and/or the symbol
shownabove.
DANGERindicatesanimminentlyhazardoussituation
which,ifnotavoided,WILLresultindeathorserious
injury.
WARNINGindicatesapotentiallyhazardoussituation
which, if not avoided, COULD result in death or
seriousinjury.
CAUTIONindicatesapotentiallyhazardoussituation
which,ifnotavoided,MAYresultinminorormoderate
injury. It may also be used to alert against unsafe
practicesorpropertydamage.
CAUTION used without the safety alert symbol
indicates a potentially hazardous situation which, if
notavoided,MAYresultinpropertydamage
MODELNUMBER: Thisnumberappearson
sales literature, technical manuals and price lists.
SERIALNUMBER: Thisnumberappearsonlyon
yourmower.Itcontainsthemodelnumber
followedconsecutivelybytheserialnumber. Use
thisnumberwhenorderingpartsorseeking
warrantyinformation.
SAFETY

3
600 Series
Turfcat
Tractors
1. STEERINGWHEELATTACHMENT
– Attach the steering wheel to the shaft by lining up
holes Rin each and inserting the roll pin.
TRACTOR ASSEMBLY
2. TRACTORWHEELATTACHMENT
a) Attach the tractor wheels to the hubs.
b) Torque the front wheel bolts to 55ft-lbsand the
rear wheel lug nuts to 80 ft-lbs.
NOTE - Check lug nut torque after the first 10 hours of
use and adjust if not still within the initial range.
All references to "right" or "left" or
"front" or "rear" are with respect to an
operator in the tractor seat.
ASSEMBLY&SETUP

4
600 Series
Turfcat
Tractors
4. Tractor and deck tire pressures should be 14 p.s.i. (1 kg/cm2). Adjust if necessary.
5. Check battery electrolyte level and charge. Use protective equipment such as, but not limited to, goggles,
faceshield,rubbergloves,andapron.
6. Beforestartingthemachine:
– Fill the fuel tank.
– Top up the engine sump if lubricating oil is low.
– Topup the radiator with a 50% antifreezesolution if low.
– Top up the hydraulic system if fluid is low.
– Lubricate at designated points (refer to the lubrication section in this manual).
– ReadandunderstandtheOperation&Safetymanual,payingparticularattentiontosafety,controland
operationinformation.
3. SEATATTACHMENT
a) Springsuspensionseat
– Make sure the seat is bolted securely to the
suspensionspring.
– Bolt the suspension spring securely to the center
oftheseatplateusinghardwareprovidedinthe
tractor loose parts bag.
– Locate the two plastic clips and attachment
hardware in the tractor loose parts bag. Attach the
clips to the bottom of the seat plate and secure,
with the throttle cable passing through the clips as
shown.
b) Deluxesuspensionseat
– Drop the four bolts at the base of the seat
suspensionintothecorrespondingholesinthe
seat plate.
– Locate the two plastic clips in the tractor loose
parts bag. Place these two clips on the front two
seat bolts protruding through the seat plate,
guidingthe throttle cable throughthem as shown.
Secure all four seat bolts with the nuts provided.
c) Seat Switch (either seat) - Route the seat switch
cable up through the hole in the seat plate and
attach to the connector at the base of the seat.
Bottom side of seat plate
Deluxe Suspension Seat
ASSEMBLY&SETUP

5
600 Series
Turfcat
Tractors
ASSEMBLY&SETUP
2. PREPARETRACTOR
a) Start the tractor. Push the lift lever forward to fully
extend the deck chains. Stop the engine.
b) Mount each push arm to a tractor differential
bracket Busing a 5/8-18x3-1/2 hex head bolt, two
spacers S, lockwasher and nut Narranged as
shown.Tightensecurely.
CUTTERDECK ASSEMBLY & SETUP
Left arm mounting shown
1. CASTERWHEELS
a) Uncrate the deck. Remove the casters from deck mounting plates P. Reassemble to the mounting plates
with reference to the height of cut chart on the deck cover or in the cutterdeck section of this manual.
b) Place blocks under the rear of the deck so that the bottom edge is approximately parallel with the ground.
Castermountedin"HIGH" position

6
600 Series
Turfcat
Tractors
4. ATTACHDECKTOTRACTOR
a) Unpack the deck mounting kit.
b) Roll the deck in place under the tractor.
c) Lay push arms from the kit between the deck
hangerbrackets.
d) Move the deck toward the tractor while sliding the
splined sections of the PTO shaft together. Make
sure the blocked off section of the shaft is aligned
with the missing spline in the tube.
e) Once the PTO halves are fully together,lineupthe
hole at the end of each push arm with mating
holes in the brackets. Insert pin Pfor each push
arm. Secure push arm pins at each end with
(2)5/16-18X7/8 bolts and (2) 5/16-18 nuts.
3. PREPAREPTOSHAFT SECTIONS
a) Pull apart the two sections of the PTO drive shaft.
NOTE:The PTO shaft and tube sections fit
together only one way, with a blocked off area
between two external splines fitting into a missing
spline in the tube.
b) Attach flange Fon the shaft section to the tractor
withfour3/8-16x1-1/4screwsandlockwashers.
c) Slide coupling Gof the tube section over deck
gearboxshaft.Tighten on shaft securely.
GF
ASSEMBLY&SETUP

7
600 Series
Turfcat
Tractors
7. VERIFYDECKLEVELING
a) Placethedeckonlevelgroundanddetermine
whetherthedeckappears tobelevel.
b) Twospacersandselftappingscrewsareprovided
to adjust deck height at the push arms.
Disconnect the push arm and attach one spacer
L, as illustrated. Reconnect push arm and verify
leveling.
c) Repeatoperationwithotherspacerifneeded.
Check deck leveling. With the deck on flat ground
verifythedeck is level. If not level, add oneor
more spacers S1 to the top of the push arm on the
low side, and recheck.
6. HEIGHTADJUSTMENTPINS
a) Identify with reference to the height of cut chart on
the deck belt cover or in the cutterdeck section of
thismanualthedesiredhangerpinlocation.
b) With the cutterdeck slightly raised, insert an
adjustment pin in the same location for each
hanger.
5. ATTACHLIFTCHAINSTODECK
a) Verify that the bottom link of the deck chains
reach the deck bracket mounting holes. If not, the
deckcylindermay need to be further loweredwith
the tractor lift lever or the chains checked for
routingproblems.
b) Anchor the bottom link of each chain to the
bracket with 5/16-18 x 1-1/4" bolts and washers,
first making sure the chains drop straight without
twisting. Secure with lock nuts.
ASSEMBLY&SETUP

8
600 Series
Turfcat
Tractors
FRONT
INSIDE
Finished installation
9. LUBRICATE
– Lubricate the fittings at the deck end of the two deck push arms.
8. WEIGHTTRANSFERSPRINGS
Securethe weight transfer springs as follows toallow
themtorotateduring normal deckoperation:
a) Start the engine and fully raise the deck. Support
it by hooking the deck latch to the frame floor
board.Stoptheengine.
b) Spring Top - For each of the two 3/8-16 x 1-1/2"
bolts, run a flanged nut to the end of the threads,
which leaves a shank section exposed. Hook one
endof a spring over the shank of each bolt. Insert
the bolts from the inside of bracket BT toward the
frontof the tractor. Secure each bolt with another
flangednutontheoutside.
c) Spring bottom - Assemble large washer Wand
spacer Ron each of the two 3/8-16 x 1" bolts.
Place the hook on the other end of each spring
over the spacer. Insert the bolts into brackets BB
facinginwardandsecureeachontheinside
surfacewithaflangednut.
d) Slightly lift the deck to release the deck latch.
Rotateit downward out of the way.
ASSEMBLY&SETUP

9
600 Series
Turfcat
Tractors
SERVICENOTES:
– Verify cutterdeck belt tension at the first 5,10 and 15 hours of operation.
– Changeengineoil,hydraulicoilandbothfiltersafterfirst 50 hours of operation.
– Changedifferentialfluidafterfirst100hoursofoperation.
erasruohesehT.bojemit-enoasiecivresoN ECIVRES.ecivresHCAEneewtebslavretni NETFOEROM .SNOITIDNOCYTRIDREDNU
NOITAREPOFOSRUOH
SMETIECIVRES
YLIAD05001004006
metsySkcolretnIkcehCX
)1(leveLliOenignEpu-poT/kcehCX
)5(leveLliOciluardyHkcehCX
)7(leveLtnalooCpu-poT/kcehCX
)6(rotarapeSretaWkcehCX
erusserPeriTkcehCX
rotaidaR,tnemtrapmoCenignEnaelC/kcehC neercS& X
sgnittiFesaerGetacirbuL keewyrevE-X
rotcelloCelcitraPrenaelCriAnaelCX
noisneTtleBkceDrettuCyfireVX
)2(tnemelErenaelCriAecalpeR X
yrettaBpu-poT/kcehC X
ssenthgiTrenetsaFkcehC X
noisneTtleBnaFkcehC X
)3(retliF&liOenignEegnahC X
)4(retliF&liOciluardyHegnahC X
launaMenignErePenignEecivreS X
)8(retliFleuFegnahC X
ni-eoTleehWraeRkcehC X
)01(sdiulFxobraeG&)9(laitnereffiDkcehC X
sgniraeBleehWtnorFkcapeR X
)9(diulFlaitnereffiDegnahC X
)11(knaTleuFnaelC&niarD X
)7(metsySgnilooChsulF&niarD X
)margaidnosmetiecivresetacolsrebmungniliarT(
MAINTENANCE

10
600 Series
Turfcat
Tractors
Arrows show lubrication points.
SDIULFYTITNAUQEPYT
LIOENIGNE
)sretil3.3(snollag88.0DC-FS03W01
LIOCILUARDYH
)sretil9.81(snollag0.5W03ROW02EAS
TNALOOCROTAIDAR
)sretil4.6(snollag7.1EZEERF-ITNA%05
EBULLAITNEREFFID
)sretil4.0(secnuo2109-08PE
XOBRAEGKCED
04EAS
MAINTENANCE

11
600 Series
Turfcat
Tractors
CLEANMACHINE
The cooling system must be checked and cleaned
dailytopreventengineoverheating(moreoftenunder
especially dirty conditions).
Procedure:
1. RemoveradiatorscreenS.
2. Cleantheradiator,oilcoolerand radiatorscreenof
anygrass chaff or debris using compressed air.
3. Replacetheradiatorscreen.
BATTERYMAINTENANCE
– Checkfluid level in battery B periodically. Iflow,
top up with distilled water.
– Whenconnectingordisconnecting battery,follow
theproceduregivenatright.
Whenworkingwithbatteryfluids:
– Always use protective equipment, such as, but
notlimitedto,goggles,faceshield, rubber gloves,
andapron.
– If skin is exposed to battery acid, rinse
immediatelywithverylargeamountsofwater;
then seek medical attention.
– Sparks or flame can
start explosion.
– Disconnectnegative(–)
batteryterminalfirst.
– Reconnectnegative(–)
battery terminal last.
WARNING
MAINTENANCE

12
600 Series
Turfcat
Tractors
HYDRAULICSYSTEM
General procedures:
– Lowerimplementsattachedtoliftarmstorelieve
hydraulicpressurefromsystembeforeservicing.
– When servicing hydraulic pipe fittings, do not use
teflon tape. Use a liquid sealant that will dissolve
into system.
– Make sure all hydraulic connections are tight
beforeapplyingpressuretosystem.
Routineservice:
CheckhydraulicfluidlevelinreservoirsightglassG.
Normallevelisapproximatelyinthecenter.
Replacefluidandfilteratintervalsshownintheservice
chart. The hydraulic filter, a spin-on cannister type, is
located at Hbelow the seat plate.
Draining procedure:
The fluid is drained through a brass fitting at the
bottomofthereservoir.
1. Place a 9/16" wrench on the flats of the drain
fitting.
2. Whileholdingthewrenchtoprevent thefittingfrom
turning,removethedrainplug.
3. Afterdraining,holdthe wrench on the fitting flats
againwhiletighteningthedrainplug.
Leaks:
Fluid in the hydraulic system is under high pressure.
Escaping hydraulic fluid can penetrate skin and cause
serious injury. If injured by escaping hydraulic fluid,
see a doctor at once. Serious infection or reaction
candevelopifpropermedicaltreatment is not
administeredimmediately.
Locating leaks: Do not use your hands to attempt to
feel a spray. Instead, pass an object like cardboard
overhydraulicsystem components to visualize a
spray.
– Leakscanpenetrate
skin.
– Seekimmediate
medicalattentionforoil
penetrationinjury.
WARNING
MAINTENANCE

13
600 Series
Turfcat
Tractors
ENGINEOIL
SeeEngineManual for manfacturer's recommendations. Before using themachinefor the first time, check the
oil level in the engine crankcase with crankcase dipstick D. When checking oil level, make sure the machine is
onlevelground.
To change engine oil:
1. Firstwarmupthe engine. Shut offenginewhen
warm,removeoildrainplugPanddraintheoil
fromthesump.
2. Cleanplugandreplace.
3. Re-fillsumpatSwiththerecommendedengine
oil.
NOTE: Afteroil has been added, waitone minute and
then check level of oil again with the dipstick D.
Engine oil filter:
– The oil filter cartridge O is easily reached at the
right side of the tractor.
– Seethetractor servicechartorrecomendationsof
theenginemanufacturerforproperreplacement
intervals.
– Apply a thin film of oil to the seal when replacing
the cartridge. Check for leaks after starting the
engine.
– Check oil using dipstick Dand top off if
necessary.
MAINTENANCE

14
600 Series
Turfcat
Tractors
AIRCLEANER
Cleanandreplacetheair cleaner elementasspecified
intheservicechart.Unevenrunning,lackofpoweror
black exhaust fumes may indicate a dirty air cleaner.
To replace diesel engine air cleaner element:
1. UnclampendcoverYandremoveelementZ.
2. Insertnewelementandreplaceendcover,
clamped in position as shown on the cover.
COOLANT
The quantity of fluid in the coolant system is indicated
bythefluidlevelinoverflow bottleO.
– Keeptheoverflowbottleapproximately1/4-1/2full.
– Whenfilling, use a 50/50 mixture ofantifreezeand
water.
MAINTENANCE

15
600 Series
Turfcat
Tractors
WATERFUELSEPARATOR
Themachineisequippedwithawaterfuelseparator
that traps water in the fuel. If the water is not removed
from the fuel system, extensive damage can occur in
the fuel injection system.
Water will collect at the bottom of the see-through
bowlAandappearsa differentcolorthanthefuel.
Removethewaterasfollows:
1. Drainwaterbyopeningtheself-ventingdrainvalve
Band allowing all water to escape. Re-tighten
drainvalve.
2. Theentire waterseparatorassemblycanbe
removedbyturningcounterclockwisewhile
grippingblackgrip C
NOTE: Always bleed the fuel system of air after
removingthewaterfromtheseparator.
R
BLEEDINGAIRFROMFUEL
Ifanyservicehasbeenperformedonthefuelmanager
waterseparatororfuelfilter,first purgeairfromthefuel
manager (Steps 1-3) otherwise skip to Step 4.
1. Loosen the air vent Done to two turns.
2. FullydepresshandprimerpumpplungerEuntilall
airhas escaped.
NOTE: Step 2 may take up to 60 pumps.
3. ClosetheairventD.
4. Bleed the air in the fuel lines from the fuel
manager to the injector pump by loosening the air
vent bolt Fon the injector pump.
5. Set the parking brake.
6. Turn the keyswitch, cranking the engine until all
air has escaped. Turn keyswitch to the off
position.
7. TightentheairventboltF.
HANDPRIMERPUMP
Thehandprimerpumpisusedtopurge air from the
fuel system. The entire pump assembly is replaceable
if necessary. See parts section for service parts.
1. RemovethesmallblackretainingringHcarefully
as it is spring loaded.
2. Removehandpumpcomponentsandreplacewith
newcomponents
MAINTENANCE

16
600 Series
Turfcat
Tractors
FUELFILTER
1. Tochangethefuel filter only,firstremovethesee-
throughwaterseparatorbowl. Seewaterfuel
separatorprocedureonthepreviouspage.
2. RemovethelargeblackretainingringG.
3. Pull the filter element straight down. Do not twist
as the filter element is not threaded.
4. Dispose the old filter element according to local
laws.
5. Align key in filter element with the slot in the
headerandpush the new filter element up into the
filterhead.
6. PlaceretainerringG. Handtightenretainerring
until it clicks and the arrows line up in the center
oftheheader.
7. Replacethewaterfuelseparator.
NOTE: Always bleed the fuel system of air after
changingthefuelfilter.
HYDRAULICNOTES
– Lowerimplementsattachedto liftarmstorelievehydraulic pressurefromsystembeforeservicing.
– When servicing hydraulic pipe fittings, do not use teflon tape. Use a liquid sealant that will dissolve into
the system.
– Make sure all hydraulic connections are tight before applying pressure to system.
When checking for leaks, do not use your hands to attempt to feel a spray. Instead, pass an object like
cardboard over hydraulic system components to visualize a spray. Escaping hydraulic fluid can be under
sufficient pressure to penetrate skin and cause serious injury. If injured by escaping hydraulic fluid, see a
doctor at once. Serious infection or reaction can develop if proper medical treatment is not administered
immediately.
MAINTENANCE

17
600 Series
Turfcat
Tractors
PARTS
SECTION
PARTSSECTION

18
600 Series
Turfcat
Tractors
FIGURE 1
FRAME & FRONT AXLE ASSEMBLY
