1. General
The CV-S3500E is a high resolution camera employing 1/3 inch, 1.25-megapixel progressive scan
CCD.
The CV-S3500E has conventional analog video output, such as composite video and Y/C (luminance
and chrominance) signal. It also provides digital compressed video for both moving and still images.
JPEG still image, Motion JEPG, MPEG4 or H.264 is selectable for digital output. The digital data is
transferred through Ethernet, 100BASE-T or 10BASE-T networking. The power is also provided over
Ethernet (PoE).
The CV-S3500E utilizes a CS mount and includes a C-mount adaptor as an accessory for various C
mount lenses.
The CV-S3500E has an on-screen display for setup, as well as RS-232C control and controls
accessible through Ethernet.
The CV-S3500E is suitable for various applications using NTSC or PAL analog output or as an IP
network camera providing high quality images.
2. Main Features
•1/3 inch progressive scan Bayer mosaic color CCD with 1.25 million effective pixels
•1280 x960 ( 15 fps ) and 960 x 720 ( 30 fps ) sensor scanning modes
•Dual encoding for JPEG and MPEG4/H.264
•Motion JPEG, MPEG4 or H.264 with 640 x 480 resolution image through Ethernet
•NTSC or PAL output converted from 1280 x 960 resolution or 960 x 720 resolution
•Analog Composite and YC outputs for NTSC or PAL signal
•On-screen menu set up
•Auto iris connector built in (DC or video)
•Auto shutter function
•Gamma selection of 1.0, 0.6 or 0.45
•2x digital zoom function
•Power over Ethernet or DC 10.8V to DC 26.4 through D-sub 9-pin connector
•RS-232C interface or Ethernet for camera settings
3. Composition
Camera main unit x 1
C Mount adapter x 1
Auto Iris Lens Plug (4pin) x 1
Hexagonal wrench x 1

CV-S3500E
- 6 -
4. Locations
4.1. Locations and functions
①
Lens mount
CS Mount (note1)
②
Flange back adjustment
Screws for flange back adjustment
③
1/4-20 UNC
Camera mount hole
④
Lens connector
For auto iris (DC or Video)
⑤
D-SUB 9 pin connector
For DC+12V,Video out & RS-232C
⑥LED Power indication
⑦BNC Composite video output(NTSC or PAL)
⑧
Function keys
For camera configuration
⑨
RJ-45
Ethernet connection (100BASE-T,10BASE-T)
Power over Ethernet
⑩
Holes for RJ-45
Holes for fixing screws of RJ-45 (note 2)
⑪
LED (ACT.)
Network connection (ACT.)
⑫
LED (LINK)
Network connection (LINK)
Fig.1 Locations
Note 1) Use the provided C-mount adapter for C–mount lenses
Note 2) When an RJ-45 cable with thumbscrews is connected to the camera, please do not
excessively tighten screws by using a screwdriver. The RJ-45 receptacle on the
camera might be damaged. For security, the strength to tighten screws is less than
0.147 Newton meter (Nm). Tightening by hand is sufficient in order to achieve this.
①
②
③
④
⑤
⑥⑦
⑧
②
⑨
⑩
⑪
⑫
③
①
②
②

CV-S3500E
- 7 -
4.2. LED indication
4.2.1 Power indication
●Green light: Power ON and it is ready to use.
4.2.2 LED (LINK)
●Green light: Connecting with 100BASE-T or 10BASE-T
4.2.3 LED (ACT)
●Orange light: Standby for 100BASE-T connection
Orange flashing: Communicating in 100BASE-T
Note: In case of 10BASE-T connection, LED does not light.

CV-S3500E
- 8 -
5. Pin Assignment
5.1. D-SUB 9-pin multi-connector (DC-in/Video/RS-232C)
1
9
6
5
Fig. 2. D-SUB 9-pin connector.
5.2. RJ-45 Ethernet Connector
12345678
Fig. 3. Ethernet connector
Note: When PoE is used, Cat5 or better cable should be used.
5.3. Auto iris lens connector
Type: EIAJ RC-5204
1
3
2
4
Fig.4 Auto iris connector
Pin no.
Signal
Remarks
1
GND
For DC input
2
+12 V DC input
3
GND
4
Video out (VBS)
*1
5
NC
6
Y output
7
C output
8
RS-232C TXD output
9
RS-232C RXD input
*1 : This video output is the same as BNC. Both outputs
cannot be used simultaneously.
Pin No
10BASE-T/100BASE-T
POE
In/out
1 TX+ Alternative A+
2
TX-
Alternative A+
3
RX+
Alternative A-
4
Not used
Alternative B+
5
Not used
Alternative B+
6
RX-
Alternative A-
7
Not used
Alternative B-
8 Not used Alternative B-
Pin No
DC Control ( Passive )
1 D amp -
2
D amp +
3
Drive +
4 Drive -

CV-S3500E
- 9 -
6. Connections
6.1. Power
Power to the CV-S3500E is supplied through the D-SUB 9 pin or the RJ-45 Ethernet interface. The
power consumption of the CV-S3500E is less than 4.2W.
Fig.5Power supply
The PoE system in the CV-S3500E is Alternative A, which uses data communication lines as power
supply. For connection details, refer to section 5.2.
6.2. Video output (NTSC or PAL)
The CV-S3500E provides composite video and YC video for NTSC or PAL.
BNC output and D-SUB 9-pin output for composite video cannot be used at the same time.
Fig.6video output
NTSC or PAL output can be selected from the on-screen menu which can be activated by the
function keys on the back of the camera.
6.3. Ethernet connection
The CV-S3500E works as an IP network camera, providing JEPG, MPEG4 or H.264 motion video or
JPEG still pictures. Using a web browser, the camera can be configured for different applications.
Fig.7Ethernet connection
6.3.1 MAC address and IP address
When connecting to a net work, please check MAC address and IP address.
MAC address Indicated on the bottom of CV-S3500E
IP address Set in accordance with the connected Network
DHCP can acquire appropriate IP address if DHCP function is set to ON.
The following table shows IP address default settings.
Item
Default
IP Address
192.168.30.30
Subnet Mask
255.255.255.0
Default Gateway
0.0.0.0 (not used)
DHCP
OFF
L INK ACT .
POW E R / T R IG
V ID EO OU T
RS -2 32C/DC IN SYNC /
U P
OD WN
FUNC
100 BASE -TX10 BASE -T /
Pin3 Gnd
Pin4 NTSC or
PAL out
Pin6 Y out
Pin7 C out
D-SUB 9 pin
NTSC or PAL
putput
L INK ACT .
POW E R / T R IG
V ID EO OU T
RS -2 32C/DC IN SYNC /
U P
OD WN
FUNC
100 BASE -TX10 BASE -T /
Pin1 Gnd
Pin2 +12V
D-SUB 9 pin
POE
(Power over Ethernet)
L INK ACT .
POW E R / T R IG
V ID EO OU T
RS - 232C/DC IN SYNC /
U P
OD WN
FUN C
100 BASE -TX10 BASE -T /
100BASE-T/10BASE-T
