James MGA1-8 Series User manual

BUILT-IN OVEN
ICQN Better Model
USER MANUAL GB
ES
H10-20-360-020 Rev 004
MANUAL DE INSTRUCCIONES

2
Dear Customer,
Thank you for relying on products.
We aim to allow you to optimally and efciently use this environment-friendly
product produced in our modern facilities under precise conditions with
respect to sense of quality in total.
We advise you to read these operating manual thoroughly before using
your built-in oven and keep it permanently so that the features of the oven
you have purchased shall stay the same as the rst day for a long time.
Note: This operating manual is prepared for multiple models. Your
appliance may not feature some functions specied in the manual.
The product images are schematic.
Products marked with an * are optional.
Our appliances are intended for domestic use. It is not intended for
commercial use.
“PLEASE READ THE INSTRUCTIONS BEFORE INSTALLING OR USING THIS
APPLIANCE.”
This product has been produced in modern environment-friendly facilities
without adversely affecting nature.
“Complies with AEEE Regulation”
GB

3
Contents
Important warnings 4
Electrical connection 12
Introducing the appliance 13
Accessories 14
Technical specications 15
Installation of the appliance 15
Operation of the oven 22
Operating oven control unit 22
Operation of the chicken roast 48
Operation of the grill 49
Cooking recommendations 49
Cooking table 50
Baking with pizza stone 51
Maintenance and cleaning 52
Cleaning and assembly of the oven door 53
Catalytic panel 54
Wire rack positions 54
Replacement of the oven lamp 55
Troubleshooting 56
Handling rules 58
Recommendations for energy saving 58
Environmentally-friendly disposal 59
Packaging information 59

4
IMPORTANT WARNINGS
1. Installation and repair should always be performed
by “AUTHORIZED SERVICE”. Manufacturer shall not be
held responsible for operations performed by unauthorized
persons.
2. Please read this operating instructions carefully.
Only by this way you can use the appliance safely and
in a correct manner.
3. The oven should be used according to operating
instructions.
4. Keep children below the age of 8 and pets away
when operating.
5. The accessible parts may be hot during use. Young
children must be kept away.
6. WARNING: Danger of re: do not store items on the cooking
surfaces.
7. WARNING: During use the appliance becomes hot.
Care should be taken to avoid touching heating elements
inside the oven.
8. Setting conditions of this device are specied on
the label. (Or on the data plate)
9. The accessible parts may be hot when the grill is
used. Small children should be kept away.
10. WARNING: This appliance is intended for cooking. It
should not be used for other purposes like heating a room.
11. To clean the appliance, do not use steam cleaners.
GB

5
12. Ensure that the oven door is completely closed
after putting food inside the oven.
13. NEVER try to put out the re with water. Only shut
down the device circuit and then cover the ame with
a cover or a re blanket.
14. WARNING: Children less than 8 years of age shall be
kept away unless continuously supervised.
15. Touching the heating elements should be avoided.
16. CAUTION: Cooking process shall be supervised.
Cooking process shall always be supervised.
17. This appliance can be used by children aged from
8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
18. This device has been designed for household use
only.
19. Children must not play with the appliance. Cleaning
or user maintenance of the appliance shall not be performed
by children unless they are older than 8 years and
supervised by adults.
20. Keep the appliance and its power cord away from
children less than 8 years old.

6
21. Put curtains, tulles, paper or any flammable
(ignitable) material away from the appliance before
starting to use the appliance. Do not put ignitable or
ammable materials on or in the appliance.
22. Keep the ventilation channels open.
23. The appliance is not suitable for use with an external
timer or a separate remote control system.
24. Do not heat closed cans and glass jars. The pressure
may lead jars to explode.
25. Oven handle is not a towel drier. Do not hang towels,
etc. on the oven handle.
26. Do not place the oven trays, plates or aluminium
foils directly on the oven base. The accumulated heat
may damage the base of the oven.
27. While placing food to or removing food from the
oven, etc., always use heat resistant oven gloves.
28. Do not use the product in states like medicated
and/or under inuence of alcohol which may affect your
ability of judgement.
29. Be careful when using alcohol in your foods. Alcohol
will evaporate at high temperatures and may catch re
to cause a re if it comes in contact with hot surfaces.
30. After each use, check if the unit is turned off.
31. If the appliance is faulty or has a visible damage,
do not operate the appliance.
32. Do not touch the plug with wet hands. Do not pull
the cord to plug off, always hold the plug.
GB

7
33. Do not use the appliance with its front door glass
removed or broken.
34. Place the baking paper together with the food into
a pre-heated oven by putting it inside a cooker or on an
oven accessory. (tray, wire grill etc.)
35. Do not put objects that children may reach on the
appliance.
36. It is important to place the wire grill and tray properly
on the wire racks and/or correctly place the tray on the
rack. Place the grill or tray between two rails and make
sure it is balanced before putting food on it.
37. Against the risk of touching the oven heater elements,
remove excess parts of the baking paper that hang over
from the accessory or container.
38. Never use it at higher oven temperatures than the
maximum usage temperature indicated on your baking
paper. Do not place the baking paper on the base of
the oven. Against the risk of touching the oven heater
elements, remove excess parts of the baking paper that
hang over from the accessory or container.
39. When the door is open, do not place any heavy
object on the door or allow children to sit on it. You
may cause the oven to overturn or the door hinges to be
damaged.
40. The packaging materials are dangerous for children.
Keep packaging materials away from the reach of children.

8
41. Do not use abrasive cleaners or sharp metal scrapers
to clean the glass as the scratches that may occur on
the surface of the door glass may cause the glass to
break.
42. User should not handle the oven by himself.
43. During usage, the internal and external surfaces
of the oven get hot. As you open the oven door, step
back to avoid the hot vapour coming out from the interior.
There is risk of burning.
44. Do not place heavy objects when oven door is
open, risk of toppling.
45. Oven supply can be disconnected during any
construction work at home. After completing the work,
re-connecting the oven shall be done by authorized service.
46. User should not dislocate the resistance during
cleaning. It may cause an electric shock.
47. To prevent overheating, the appliance should not
be installed behind of a decorative cover.
48. Turn off the appliance before removing the
safeguards. After cleaning, install the safeguards
according to instructions.
49. Cable xing point shall be protected.
50. Please don’t cook the food directly on the tray /
grid. Please put the food into or on appropriate tools
before putting them in the oven.
GB

9
Electrical Safety
1. Plug the appliance in a grounded socket protected by
a fuse conforming to the values specied in the technical
specications chart.
2. Have an authorized electrician set grounding equipment.
Our company shall not be responsible for the damages
that shall be incurred due to using the product without
grounding according to local regulations.
3. The circuit breaker switches of the oven shall be
placed so that end user can reach them when the oven
is installed.
4. The power supply cord (the cord with plug) shall
not contact the hot parts of the appliance.
5. If the power supply cord (the cord with plug) is
damaged, this cord shall be replaced by the manufacturer
or its service agent or an equally qualied personnel to
prevent a hazardous situation.
6. Never wash the appliance by spraying or pouring
water on it. There is a risk of electrocution.
7. WARNING: To avoid electric shock, ensure that the
device circuit is open before changing the lamp.
8. WARNING: Cut off all supply circuit connections before
accessing the terminals.
9. Do not use cut or damaged cords or extension cords
other than the original cord.
10. Make sure that there is no liquid or humidity in
the outlet where the product plug is installed.

10
11. The rear surface of the oven also heats up when
the oven is operated. Electrical connections shall not
touch the rear surface, otherwise the connections may
be damaged.
12. Do not tighten the connecting cables to the oven
door and do not run them over hot surfaces. If the cord
melts, this may cause the oven to short circuit and
even a re.
13. Unplug the unit during installation, maintenance,
cleaning and repair.
14. If the power supply cable is damaged, it must be
replaced by its manufacturer or authorized technical
service or any other personnel qualied at the same
level, in order to avoid any dangerous situation.
15. Make sure the plug is inserted rmly into wall
socket to avoid sparks.
16. Do not use steam cleaners for cleaning the appliance,
otherwise electric shock may occur.
17. An omnipolar switch capable to disconnect power
supply is required for installation. Disconnection from
power supply shall be provided with a switch or an
integrated fuse installed on xed power supply according
to building code.
18. Appliance is equipped with a type ‘’Y’’ cord cable.
19. Fixed connections shall be connected to a power
supply enabling omnipolar disconnection. For appliances
with over voltage category below III, disconnection device
shall be connected to xed power supply according to
wiring code.
GB

11
Intended Use
1. This product has been designed for domestic use.
Commercial use is not permitted.
2. This appliance may only be used for cooking
purposes. It shall not be used for other purposes like
heating a room.
3. This appliance shall not be used to heat plates
under the grill, drying clothes or towels by hanging
them on the handle or for heating purposes.
4. The manufacturer assumes no responsibility for any
damage due to misuse or mishandling.
5. Oven part of the unit may be used for thawing,
roasting, frying and grilling food.
6. Operational life of the product you have purchased
is 10 years. This is the period for which the spare parts
required for the operation of this product as dened is
provided by the manufacturer.

12
Electrical Connection
This oven shall be correctly installed and connected by the authorized
service and according to the manufacturer’s instructions.
The appliance shall be installed in an oven housing which provides high
ventilation.
The electrical connections of the appliance shall be made only by using
grounded sockets equipped with a grounding system laid in accordance
with the instructions. If the place where the appliance shall be installed
is not designed for a grounded system, immediately contact an authorized
service. The manufacturer shall never be responsible for damages caused
by non-grounded sockets, to which the appliance has been plugged.
Your oven’s plug is grounded; make sure that the outlet you shall connect
the plug is grounded, too. The plug shall be placed so that it can be
accessed after installation.
Your oven is manufactured as compatible with the 220-240 V 50/60 Hz. AC
power supply and requires a fuse of 16 Amp. If your power network does not
provide these specications, contact an electrician or an authorized service.
When you need to replace the fuse, please make sure that the electrical
connection is as follows:
• Brown wire to the phase (live end)
• Blue wire to neutral
• Yellow-green wire to ground terminal
The circuit breaker switches of the oven shall be placed so that end user
can reach them when the oven is installed.
The power supply cord (the cord with plug) shall not contact the hot
parts of the appliance.
If the power supply cord (the cord with plug) is damaged, this cord shall
be replaced by the manufacturer or its service agent or an equally qualied
personnel to prevent a hazardous situation.
GB

13
INTRODUCING THE APPLIANCE
1. Control panel 4. Wire grill inside tray
2. Deep tray * 5. Standard tray
3. Chicken roast skewer * 6. Oven door
7. Light
8. Wire grill inside tray
9. Standard tray
1
2
3
4
5
6
7
8
9

14
Accessories (optional)
Deep tray *
Used for pastry, big roasts, watery foods. It can also be
used as oil collecting container if you roast directly on
grill with cake, frozen foods and meat dishes.
Tray / Glass tray *
Used for pastry (cookie, biscuit etc.), frozen foods.
Circular tray *
Used for pastry frozen foods.
Wire grill
Used for roasting or placing foods to be baked, roasted
and frozen into desired rack.
Telescopic rail *
Trays and wire racks can be removed and installed easily
thanks to telescopic rails.
Pizza stone and peel *
They are used for baking pastries such as pizza, bread,
pancake and removing baked food from the oven.
Tray handle *
It is used to hold hot trays.
In tray wire grill *
Foods to stick while cooking such as steak are placed on
in tray grill. Thus contact of food with tray and sticking
are prevented.
GB

15
Technical Specications
MGA1-8..... :
Lamp power 15-25 W
Thermostat 40-240 / Max °C
Bottom heater 1200 W
Top heater 1200 W
Turbo heater 1800 W
Grill heater Small grill 1200 W Large grill 2400 W
Supply voltage 220-240 V 50/60 Hz.
MGA1-6..... :
Lamp power 15-25 W
Thermostat 40-240 / Max °C
Bottom heater 1200 W
Top heater 1000 W
Turbo heater 1800 W
Grill heater Small grill 1000 W Large grill 2000 W
Supply voltage 220-240 V 50/60 Hz.
WARNING: In order to increase the product quality, the technical
specications may be changed without prior notice.
WARNING: The values provided with the appliance or its accompanying
documents are laboratory readings in accordance with the respective
standards. These values may differ depending on the usage of the appliance
and ambient conditions.
WARNING: Figures in this manual are schematic and may not exactly
match your product.
INSTALLATION OF APPLIANCE
Check if the electrical installation is proper to bring the appliance in
operating condition. If not, call an electrician and plumber to arrange
the utilities as necessary. Manufacturer shall not be held responsible for
damages caused by operations performed by unauthorized persons.
WARNING: It is customer’s responsibility to prepare the location the
product shall be placed on and also to have the electrical installation
prepared.

16
WARNING: The rules in local standards about electrical installations
shall be followed during product installation.
WARNING: Check for any damage on the appliance before installing it.
Do not have the appliance installed if it is damaged. Damaged products
cause a risk for your safety.
Important Warnings for Installation:
Cooling fan shall take extra steam out and
prevent outer surfaces of appliance from
overheating during operation of oven.
This is a necessary condition for better
appliance operation and better cooking.
Cooling fan shall continue operation after
cooking is nished. Fan shall automatically
stop after cooling is completed.
A clearance must be left behind the
enclosure where you’ll place the appliance
for efcient and good operation.
This clearance shouldn’t be ignored as it’s required for ventilation system
of the appliance to operate.
Right Place For Installation
The appliance is designed so that it shall t commercially available
counters. A safe clearance shall be left between the product and kitchen
walls or furniture. Refer to the drawings on the installation section. for
suitable clearances. (dimensions are given in mm)
• Surfaces, synthetic laminates and adhesives used shall be resistant
to heat. (minimum 100 °C)
• Kitchen cabinets shall be level with the appliance and xed.
• A rack shall be placed between the oven and the shelf if there is a
shelf under the oven.
WARNING: Do not install the appliance beside refrigerators or coolers.
Heat radiated by the appliance increases the energy consumption of cooling
devices.
WARNING: Do not use the door and/or handle to carry or move the appliance.
Figure 1
GB

17
Installation and Assembly Of The Oven
Operating space of the appliance shall be determined before starting
the installation.
Appliance shall not be installed on areas with high ow of air.
Handle the appliance with two persons at least. Do not drag the appliance
to prevent damage to the ground.
Remove all transportation materials inside and outside of the packaging.
Remove all materials and documents inside the product.
Installation Under Counter
Cabinet shall conform with dimensions specied in g. 2.
A clearance with the dimensions specied in the gure shall be ensured
at the rear compartment of the cabinet to provide the required ventilation.
After installation, the clearance that shall be left between the bottom
of the counter and the top of the appliance is indicated by “A” in g. 5.
This is for ventilation and it shall not be closed.
Installation In A High Cabinet
The cabinet shall comply with the dimensions given in g. 4.
In the rear part of the cabin, and at the top and bottom, clearances with
the dimensions specied in the gure shall be ensured to provide the
required ventilation.
Installation Conditions
The dimensions of the appliance are given in gure 3.
The furniture surfaces to be installed and the installation materials to
be used shall resist a temperature of at least 100 °C.
To prevent the appliance from turning over, the cabinet to be installed
shall be fixed and the cabinet floor shall be level.
The floor of the cabinet shall be strong enough to withstand a load of at
least 60 kg.
Placing and Securing Of The Oven
Place the oven to the cabinet with two or more persons.
Make sure that the frame of the oven and the front of the furniture are
properly aligned.
The supply cord shall not be left under the oven or be stuck or bent
between the oven and the furniture.

18
Secure the oven to the furniture using the screws supplied with the
appliance. Screws shall be installed by putting them through the plastics
attached on the frame of the appliance as shown in gure 5. The screws
shall not be tightened too much. Otherwise, the screw holes may wear
out.
Check that the oven does not move after installation. If the oven has not
been installed in accordance with the installation instructions, there is a
risk of overturning during operation.
Electrical Connection
The place where the product shall be installed shall have proper electrical
installation.
The mains voltage shall comply with the rating given on the product
type plate.
Connection of appliance shall be made in accordance with local and
national electrical regulations.
Disconnect the mains power before starting to install the product.
Do not connect the product to the mains until the installation is nished.
Assembly
Figure 2
GB

19
560
600
35
500
30 30
555
545
595
595
565
22
Figure 3

20
590
550
560
35 500
30 30
Figure 4
GB
