James WEDGE Series User manual

INSTALLATION GUIDE
®
Installation guide for James Wedge Series Speaker
Take the bracket off of the back of the speaker
by using your hand, and pulling one side of the
bracket out.
1
3If the wires are in the wall, then run it through
the bottom slots on the bracket (top photo).
If the wire is in the ceiling, then run the wire
through the top slots of the bracket (bottom
photo).
Next, determine if your wires are located in the
ceiling or the wall.
2
If the speaker is being installed flush with the wall
and ceiling, then install all nine screws to secure
the bracket.
4
Now connect your wires to the speaker. (Red to
red, and black to black)
6
5The bracket can also be secured to a wall
using just six wall screws.
WEDGE SERIES INSTALLATION GUIDE

James Loudspeaker | 535 Airpark Road, Napa, CA 94558 | 707.265.6343 | www.JamesLoudspeaker.com
®
20170811
WEDGE SERIES INSTALLATION GUIDE
8Finally, tighten down the three set screws, with
the hex key we have provided, located on the
bottom of the speaker.
The speaker should sit flush with the wall and/or
ceiling before proceeding to the next step.
7
8Once you have the speaker mounted into place,
then lift the speaker from the bottom and use a
fist to pound the speaker back into the wall in
order to make the speaker flush.
Now, mount the speaker onto the bracket by
guiding the upper channel of the speaker into
the top portion of the bracket.
7
10
9
Installation
Video
