jcb JCB-20USB Planning guide

POWER TOOL
INSTRUCTION & USER MANUAL
EN
IM-20USB-EN
Original Instructions
JCB-20USB

2JCB-20USB
Instruction & User Manual
GENERAL WARNINGS & DISPOSAL
To reduce the risk of injury, the user must read the instruction manual.
This product has been marked with a symbol relating to removing electric and
electronic waste. The product should not be discarded with household waste
but must be returned to a collection system which conforms to the European
Directive 2012/19/EU. It will then be recycled or dismantled in order to
reduce the impact on the environment. Electric and electronic equipment can
be hazardous for the environment and for human health since they contain
hazardous substances.
This symbol is used throughout this manual to warn the user about potential
risks. Please read & understand these sections before using the device.
WARNING: Lithium-ion batteries and products that contain lithium-ion batteries can expose you
to chemicals including cobalt lithium nickel oxide, and nickel, which are known to the State of
California to cause cancer and birth defects or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
The month and year of manufacture can be found within the product serial number e.g.
MMYYPPPAXXXXX. Where production month (MM) and production year (YY) are included.
Positive terminal
Negative terminal
The device must not be exposed to rain or immersed in water.
Do not allow any part of the device to come into contact with flames, or to
catch fire.
Do not dispose of batteries in household waste. Return exhausted batteries
to a local collection or recycling point.
Do not expose battery pack or tool to fire or excessive temperatures
USB connection port

3
JCB-20USB
Instruction & User Manual
Contents
USB POWER ADAPTOR SAFETY 4
COMPONENT LIST 5
USB POWER ADAPTOR TECHNICAL DATA 5
OPERATING INSTRUCTIONS 6
Intended Use 6
Maintenance 7
Transport and Storage 7
GENERAL CERTIFICATE OF CONFORMITY 8

4JCB-20USB
Instruction & User Manual
m To reduce risk of injury, only charge
JCB rechargable batteries. The USB
power adaptor and battery packs are
specifically designed to work together.
Other types of batteries may burst causing
fire and personal injury.
m Do not allow any liquid to get inside
the USB power adaptor. Electric shock
may result.
m Do not expose the USB power
adaptor to rain or snow.
m Under certain conditions with
the USB power adaptor plugged
into a USB device, the exposed
battery contacts inside the USB
power adaptor can be shorted by
foreign materials. Foreign materials of a
conductive nature such as, but not limited
to, steel, wool, aluminium foil or any buildup
of metallic particles should be kept away
from charger cavities.
m Always unplug the USB power
adaptor from the USB device when
there is no battery fitted to the USB
power adaptor.
m Unplug the USB power adaptor from
the USB device before attempting to
clean.
m Do not operate the USB power
adaptor with a damaged USB cable.
m This appliance can be used by
children aged from 8 years and above
and persons with reduced physical,
sensory or mental capabilities or
lack of experience and knowledge
if they have been given supervision
or instruction concerning use of
the appliance in a safe way and
understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be
made by children without supervision.
USB ADAPTOR SAFETY
Read all safety warnings, instructions
and specifications provided with this
USB power adaptor. Failure to follow all
instructions listed below may result in electric
shock, fire and/or serious injury. Save all
warnings and instructions for future
reference.
WARNING!
The USB power adaptor has an
integral torch which is a high-intensity
lighting device. Avoid shining the
torch directly into anyone’s eyes to
prevent possible eye injury.
WARNING!

5
JCB-20USB
Instruction & User Manual
COMPONENT LIST
1. USB PORTS (LOCATED AT REAR
OF PRODUCT)
2. LED TORCH
3.
4.
POWER BUTTON
POWER OUTPUT INDICATOR
4
2
1
Product Code Input Voltage Output Power Torch Output Power
JCB-20USB 20V d.c. 5V d.c. / 2.0A max 60 Lumens
Torch maximum continuous run time: 10hrs (full charged 2.0Ah battery)
Compatible JCB 20V batteries:
JCB-20-15LI (1.5Ah), JCB-20-20LI (2.0Ah), JCB-20-30LI (3.0Ah), JCB-20-40LI (4.0Ah),
JCB-20-50LI (5.0Ah)
USB POWER ADAPTOR TECHNICAL DATA
3

6JCB-20USB
Instruction & User Manual
OPERATING INSTRUCTIONS
Intended Use
This USB power adaptor is intended for use
only with a compatible JCB 20V lithium-ion
battery pack.
The component must not be modified or used
for any other purposes than the ones described
in these instructions.
Battery
Make sure the power button (3) on the top
of the USB power adaptor is not pressed in
when inserting or removing the battery.
NOTE
m Do not use excessive force when
inserting the JCB battery in the USB
power adaptor. An incorrectly connected
battery can damage the battery terminals
or the battery socket on the USB power
adaptor.
m Connect the battery to the battery socket of
the USB power adaptor so that it clicks into
place.
m Use the button on the battery to check the
charging status; 4 red LEDs indicates fully
charged, where 1 indicates low battery
status.
m Place the USB power adaptor on a level
and stable surface. Connect your USB
device with a suitable cable to one of the
USB ports on the back of the USB power
adaptor.
m Press the power button (3) on the top of
the USB power adaptor once to commence
power output to the USB ports.
m To stop the power output to the USB ports
simply remove the USB supply cable from
the USB port.
LED Torch Operation
m Press the power button (3) on the top
of the USB power adaptor until the red
indicator starts flashing.
m When the red indicator is constantly
illuminated, press the power button (3)
again and the LED torch will power on.
m Press the powe button (3) again to power
down the LED torch.
The red indicator (4) will initially flash during
the power up stage. Upon supplying power
to the two USB ports the red indicator will
illuminate constantly.
NOTE
The USB power adaptor will detect the
cable disconnection and automatically power
down. The red indicator will also extinguish
to confirm the power has been disconnect-
ed.
NOTE
If you press the power button (3) again
while the red indicator remains illuminated,
the LED Torch will power on, but if the red
indicator is not illuminated the LED torch
will not power on until the red indicator
is illuminated and the power button (3) is
pressed again.
NOTE

7
JCB-20USB
Instruction & User Manual
Maintenance
Remove the battery pack from the USB
power adaptor before cleaning and main-
tenance. This helps avoid the risk of electric
shocks and accidental injury.
WARNING!
m Wipe the USB powder adaptor with a dry
or damp cloth. Do not use a wet cloth.
Do not use detergent that contains
solvent or corrosive, abrasive
additives. This risks damaging the surfaces
of the charger.
m Clear the battery connection terminals and
the release button of dust and dirt after
each use. Do not clean terminals by
inserting sharp objects in them, such
as screwdrivers and other similar
objects.
m Stubborn contamination in areas hard to
access can be removed with compressed air
(max 3. bar).
m Regularly check all fasteners, screws and
bolts to make sure that they are tight.
Tighten any loose screws immediately or
serious injury could occur.
Never open the USB power adaptor. The
USB power adaptor has no internal parts that
the user can service or repair. Never try to
repair the USB power adaptor yourself. Take
to an authorised service centre.
WARNING!
Transport and Storage
m If the USB power adaptor will remain
unused for any length of time, it should be
stored in the original packaging.
m Store the USB power adaptor in a dry,
frost-free, well ventilated place with a
temperature of now more than 40 °C
m Keep all USB power adaptors out of the
reach of children.
m Always remove the battery from the USB
power adaptor before transport.
m Ensure that the USB power adaptor is not at
risk of being exposed to excessive vibration
and shocks during transport, especially if the
USB power adaptor will be transported by
car or other vehicle.

8JCB-20USB
Instruction & User Manual
