JDW EQ747 User manual

1
Cordless Hedge Trimmer (EQ747)
Assembly Instructions
Please Read All Instructions Thoroughly Before Starting Assembly

2
Components
1) Blade
2) Protector
3) Locked front handle
4) Front switch-handle
5) Back switch-handle
6) Battery pack

3
Safety Instructions
General Safety Instructions
WARNING! Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool
or battery pack-operated (cordless) power tool.
This product is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
Only use the product in the manner and for the functions described in these instructions.
Work area safety
Keep work area clean and well lit. Cluttered or dark areas invite accidents
Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
Keep children and bystanders away while operating a power tool. Distractions can cause
you to lose control.
Electrical safety
Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching out-
lets will reduce risk of electric shock.

4
Plug Fitting
Note: The product is fitted with a standard UK mains outlet 3 pin plug. If a moulded plug is
fitted and has to be removed take great care in disposing of the plug and severed cable, it must
be destroyed to prevent engaging into a socket. If the supply cord is damaged it must only be
replaced by a qualified person. If you need to fit a new plug follow the instructions below. If in
doubt consult a qualified electrician
IMPORTANT!
The wires in the mains lead are colored in accordance with the following code:
Blue - Neutral Brown - Live
As the colours of the wires in the mains lead of this appliance may not correspond with the
colored markings identifying the terminals in your plug, proceed as follows:
• The wire colored BROWN must be connected to the terminal that is marked with the letter
“L”.
• The wire colored BLUE must be connected to the terminal that is marked with the letter “N”.
• This product is a class II product. No connection is to be made to the earth terminal which is
marked “E” or If a (BS 1363/A) plug is used, a 13 amp fuse must be fitted, or if any other type of
plug is used a 13 Amp fuse must be fitted, either in the plug, or adaptor or on the distribution
board.

5
Personal Saftey
Stay alert, watch what you are doing and use common sense when operating a power tool.
Do not use a power tool while you are tired or under the influence of drugs, alcohol or med-
ication. A moment of inattention while operating power tools may result in serious personal
injury.
Use personal protective equipment. Always wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with
your finger on the switch or energizing power tools that have the switch on invites accidents.
Remove any adjusting key or wrench before turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool may result in personal injury.
Do not overreach. Keep proper footing and balance at all times. This enables better control
of the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewelry or long hair can be caught in moving parts.
Power tool use and care
X Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
X Do not use the power tool if the switch does not turn it on and off. Any power tool
that cannot be controlled with the switch is dangerous and must be repaired
XDisconnect the plug from the power source and/or the battery pack from the
power tool before making any adjustments, changing accessories, or storing power
tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
XStore idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.

6
Personal Saftey
X Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts
and any other condition that may affect the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are caused by poorly maintained power tools.
X Keep cutting parts sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
X Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the power
tool for operations different from those intended could result in a hazardous situation.
Service
Have your power tool serviced by a qualified repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.
CORDLESS HEDGE TRIMMER SAFETY WARNNINGS
1. Keep all parts of the body away from the cutter blade. Do not remove cut material
or hold material to be cut when blades are moving. Make sure the product is
switched off when clearing jammed material. A moment of inattention while operating
the product may result in serious personal injury.
2. Carry the product by the handle with the cutter blade stopped. When transporting
or storing the product always fit the cutting device cover. Proper handling of the
product will reduce possible personal injury form the cutter blades.
3. Hold the product by insulated gripping surfaces only, because the cutter blade may
contact hidden wiring of its own cord. Cutter blades contacting a “live” wire may make
exposed metal parts of the product “live” and could give the operator an electric shock.
4. Check the hedge for foreign objects before operation, e.g. wire fences.
5. Hold the product properly, e.g. with both hands if two handles are provided. Loss of con-
trol can cause personal injury.
ADDITIONAL SAFETY WARNNINGS
IMPORTANT
Read carefully before use
Keep for future reference

7
Personal Saftey
XRead the instructions carefully. Be familiar with the controls and the proper use of the
appliance.
XNever allow children to use the product.
XNever allow people unfamiliar with these instructions to use the appliance. Local regula-
tions may restrict the age of the operator.
XNever operate the appliance while people, especially children, or pets are nearby.
XThe operator or user is responsible for accidents or hazards occurring to other people or
their property.
Preparation
XWear safety goggles and ear muffs while operating.
XAlways wear substantial footwear and long trousers. Do not operate the equipment when
barefoot or wearing open sandals.
XAlways wear suitable working clothes during working, which allow freedom of movement.
XNever operate the appliance which is damaged, incomplete or changed without approval of
the manufacturer.
Operation
X Disconnect the battery from the product:
whenever you leave the product,
before clearing a blockage,
before checking, cleaning or working on the product,
if the product starts to vibrate abnormally.
X Operate the product only in daylight or in good artificial light.
X Do not overreach and keep your balance at all times.
X Always be sure of your footing on slopes.

8
Operation
X Walk, never run.
X Keep all ventilation openings clear of debris.
X Never blow debris in the direction of bystanders.
Maintenance and storage
1). Keep all nuts, bolts and screws tight to be sure the product is in safe working condition.
2). Check the collection bag frequently for wear or deterioration.
3). Replace worn or damaged parts.
4). Store the product only in a dry place.
5). Use only spare parts and accessories approved by the manufacturer.
Residual Risks
Even if you are operating this product in accordance with the provisions, residual risks will
always still remain. The following dangers can arise in connection with the structure and design
of this product:
1). Health defects resulting from vibration emission if the product is being used over longer
period of time or not adequately managed and properly maintained.
2). Injuries and damage to property to due to broken accessories or hidden objects that are
suddenly dashed.
3). Injuries and damage to property to due to thrown and fallen objects.
WARNING! This product produces an electromagnetic field during operation! This field may
under some circumstances interfere with active or passive medical implants! To reduce the
risk of serious or fatal injury, we recommend persons with medical implants to consult their
physician and the medical implant manufacturer before operating this product!

9
Emergency
Vibration and noise reduction
To reduce the impact of noise and vibration emission, limit the time of operation, use low-
vibration and low-noise operating modes as well as wear personal protective equipment.
Emergency
Familiarise yourself with the use of this product by means of this instruction manual.
Memorise the safety directions and follow them to the letter. This will help to prevent risks
and hazards.
1). Always be alert when using this product, so that you can recognize and handle risks early.
Fast intervention can prevent serious injury and damage to property.
2). Stop the motor and disconnect the battery from the product if there is any malfunction.
Have the product checked by a qualified professional and repaired, if necessary, before you
put it into operation again.
Safety Warnings and Instructions: Batteries
XDo not disassemble or open, drop (mechanical abuse), crush, bend or deform, puncture,
or shred.
XDo not modify or remanufacture, attempt to insert foreign objects into the battery,
immerse or expose to water or other liquids, or expose to fire, excessive heat including
soldering irons, or put in microwave oven.
XOnly use the battery/tool with a charging system specified by the manufacturer/supplier.
XDo not short-circuit a battery or allow metallic or conductive objects to contact both
battery terminals simultaneously.
XDispose of used batteries promptly according to the manufacturer/supplier’s instructions.
XImproper battery/tool use may result in a fire, explosion, or other hazard.
XBattery/tool usage by children should be supervised.

10
Saftey Warnings & Instructions
Safety Warnings and Instructions: Charging
1. This manual contains important safety and operating instructions.
2. Before using battery charger, read all instructions and cautionary warnings on battery
charger and product using battery. CAUTION: To reduce the risk of injury, use this charger only
with this product. Batteries in other products may burst causing personal injury or damage.
3. Do not expose charger to rain or snow.
4. Use of an accessory not recommended may result in a risk of fire, electric shock, or injury to
persons.
5. To reduce risk of damage to electric plug and cord, pull by plug rather than cord when
disconnecting charger.
6. Make sure cord is located so that it will not be stepped on, tripped over, or otherwise
subjected to damage or stress.
7. An extension cord should not be used unless absolutely necessary. Use of improper
extension cord could result in a risk of fire, electric shock or electrocution.
a) An extension cord must have adequate wire size (AWG or American Wire Gauge) for safety
to prevent loss of power and overheating. The smaller the gauge number of the wire, the
greater the capacity of the cable; that is, 16 gauge has more capacity than 18 gauge. When using
more than one extension to make up the total length, be sure each extension contains at least
the minimum wire size.
CHART FOR MINIMUM WIRE SIZE (AWG) OF EXTENSION CORDS
NAMEPLATE RATING AMPS 0 – 10.0
Total Extension Cord Length (ft) 0-25 26-50 51-100 101-150
(0-7.6m) (7.6-15.2m) (15.2-30.4m) (30.4-45.7m)
Wire Gauge number 18 16 16 14

11
Saftey Warnings & Instructions
8. Use only the supplied charger when charging your tool. The use of any other charger could
damage the tool or create a hazardous condition.
9. Use only one charger when charging.
10. Do not attempt to open the charger. There are no customer serviceable parts inside.
Return to any authorized Black & Decker service center.
11. DO NOT incinerate the tool or batteries even if they are severely damaged or completely
worn out. The batteries can explode in a fire. Toxic fumes and materials are created when
lithium ion battery packs are burned.
12. Do not charge or use battery in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Inserting or removing the battery from the charger may ignite
the dust or fumes.
13. If battery contents come into contact with the skin, immediately wash area with mild soap
and water. If battery liquid gets into the eye, rinse water over the open eye for three minutes or
until irritation ceases. If medical attention is needed, the battery electrolyte is composed of a
mixture of liquid organic carbonates and lithium salts.
WARNING: Burn hazard. Battery liquid may be flammable if exposed to spark or flame.
Technical Specifications
Voltage DC20V
Battery capacity 1.5Ah
Charging time 4 hours
No load speed 1400min-1
Blade length 510 mm
Cutting capacity 14mm
Symbol explanation:
Read the instruction manual completely and carefully before using
the power tool.
This marking indicates that this product should not be disposed of
with other household wastes. Follow the disposal instructions within
this instruction manual.

12
Charging Procedure
With this symbol the manufacturer confirms that this power tool is in
accordance with applicable European directives.
Do not expose to rain
Be careful!
Wear personal protective equipment. Always wear safety glasses or a
face shield, hearing protection and safety helmet.
Sharp blade can cut limbs
Wear gloves for cutting protection.
Wear safety shoes for preventing slipping.
CHARGING PROCEDURE
IMPORTANT: The battery packs not fully charged at the factory. Before attempting to charge
them, thoroughly read all of the safety instructions.
1) To assure that the charger you use are applicable to the battery pack.
2) Plug the charger plug into the charging hole of the battery pack.
3) Plug the charger into any suitable standard outlet.
4) Let the battery pack charge initially for the green light is twinkled. If the power lights are all
lighting, the battery pack is fully charged.

13
Charging Procedure
Recharge discharged batteries as soon as possible after use or battery life may be
greatly diminished. For longest battery life, do not discharge batteries fully.
It is recommended that the batteries be recharged after each use.
WARNING: Fire Hazard. When unplug the output plug from the charging hole, be sure to
unplug the charger from the outlet first, then disconnect the charger output plug from the
charging hole.
Important Charging Notes
1) Your tool was sent from the factory in an uncharged condition. Before attempting to use it, it
must be charged.
2) CAUTION: To reduce the risk of damage to the batteries, NEVER charge them in an air
temperature below 40°F (4.5°C) or above 105°F (40.5°C). Also, NEVER charge them if the
battery temperature is below 40°F (4.5°C) or above 105°F (40.5°C). Longest life and best
performance occurs when batteries are charged with an air temperature of approximately 75°F
(24°C). NOTE: The tool will not charge if the tool temperature is below approximately 32°F
(0°C) or above 113°F (45°C).
3) While charging, the charger may hum and become warm to touch. This is a normal
phenomenon and does not indicate a problem.

14
Operation Instructions
4) If the batteries do not charge properly—(1) Check current at receptacle by plugging in a
lamp or other appliance. (2) Check to see if receptacle is connected to a light switch which
turns power off when you turn out the lights. (3) Move charger and tool to a surrounding air
temperature of 40°F (4.5°C) to 105°F (+40.5°C). (4) If the receptacle and temperature are OK,
and you do not get proper charging, take or send the tool and charger to your local service
center. See Tools Electric in yellow pages.
5) The tool should be recharged when it fails to produce sufficient power on jobs which
were easily done previously. Battery life may be greatly diminished if batteries are discharged
deeply. DO NOT CONTINUE using product with its batteries in a depleted condition. Recharge
discharged batteries promptly.
6) To maximize battery life:
a. Do not fully discharge batteries.
b. Fully recharge batteries after each use.
c. Store tool in a location where the surrounding air temperature is approximately 40°F-75°F
(4.5°C - 24°C).
d. Disconnect charger from tool after charge is complete. WARNING: Fire Hazard. When
disconnecting the charger from the tool, be sure to unplug the charger from the outlet first,
then disconnect the charger cord from the tool.
Scope of delivery
---Hedge trimmer
---Battery pack
---Charger
---Blade sheath
Operation instructions
Intended use
The hedge trimmer is designed for cutting and trimming of hedges, bushes and shrubs
in domestic gardens.
The maximum cutting capacity must be observed. Do not cut branches exceeding the
stated maximum capacity.
The appliance is suitable for the private use in the garden only, not for continuous
employment in the commercial use.

15
Operation Instructions
The appliance is designed for use by adults. Young people over 16 years old may use the
appliance under supervision only.
This appliance is not intended for use by persons (including children)with reduced physical,
sensory or mental capabilities ,unless they have been given supervision or instruction
concerning the use of the appliance by a person responsible for their safety.
Before using the tool, please insert the battery pack to the machine. Always use the correct
battery pack.
To turn on the machine, you should push down Front switch-handle 4 and Back switch-
handle 5 at the same time. Release any one of the two switch-handles will make the machine
a sudden stop, in that case, you will see sparkle from the ventilation slot, do not worry, this
is normal phenomenon and will not damage the machine. You will probably notice a burning
smell coming from the motor, again do not worry, as this is the electrical brake which always
generates a little smoke.
When you finish the work, you can pull out the battery pack, and charging it, cleaning the
blade, lubricate the blade after each use to prolong the life span of cutting blade and product.
Apply light machine oil along the edge of the cutting blade. Store the machine with the sheath
covering the blade.
Change the blade
Check the blade periodically, if damaged, please change immediately.
It is difficult to change the blade by yourself, so we advise you to change the blade by an
authorized service workshop.

16
General Information
General information
If older hedges need to be cut back a substantial amount, use pruning shears to trim thicker
branches to the desired length before going to work with the hedge trimmer. Ensure that the
blade does not come into contact with anything that could damage it, such as fencing wire or
metal plant supports.
Native hard woods should not be cut with a hedge trimmer, as they will damage the blade.
The hedge trimmer is designed to cut soft new growth and should only be used to cut such
materials.
Maintenance and care
Always remove the battery pack from the machine before carrying out any work on the
machine and before cleaning.
The appliance is maintenance-free. If, despite careful production and rigorous quality
assurance, damage is found, the appliance may only be repaired by an authorized service
workshop for electric tools.
Environmental Protection
Waste electrical products should not be disposed of with household waste. Please recycle
where facilities exist. Check with your Local Authority or retailer for recycling advice.

17
Please Retain Instructions For Future Use
J.D. WILLIAMS & CO. LTD
40 LEVER STREET, MANCHESTER, UK, M60 6ES
