INTRODUCTION
TABLE OF CONTENTS
page page
DESCRIPTION AND OPERATION
VEHICLE IDENTIFICATION NUMBER ..........1
VEHICLE SAFETY CERTIFICATION LABEL ......2
INTERNATIONAL SYMBOLS.................2
FASTENER IDENTIFICATION.................3
FASTENER USAGE ........................3
THREADED HOLE REPAIR ..................3
METRIC SYSTEM .........................6
TORQUE REFERENCES.....................6
DESCRIPTION AND OPERATION
VEHICLE IDENTIFICATION NUMBER
The Vehicle Identification Number (VIN) plate is
located on the lower windshield fence near the left
A-pillar. The VIN contains 17 characters that provide
data concerning the vehicle. Refer to the VIN decod-
ing chart to determine the identification of a vehicle.
The Vehicle Identification Number is also
imprinted on the:
•Body Code Plate.
•Vehicle Safety Certification Label.
•Frame rail.
To protect the consumer from theft and possible
fraud the manufacturer is required to include a
Check Digit at the ninth position of the Vehicle Iden-
tification Number. The check digit is used by the
manufacturer and government agencies to verify the
authenticity of the vehicle and official documenta-
tion. The formula to use the check digit is not
released to the general public.
VEHICLE IDENTIFICATION NUMBER DECODING CHART
POSITION INTERPRETATION CODE = DESCRIPTION
1 Country of Origin 1 = United States
2 Make J = Jeep
3 Vehicle Type 4 = MPV
4 Gross Vehicle Weight Rating F = 4001-5000 lbs.
5 Vehicle Line F= Cherokee 4X4 (LHD)
N = Cherokee 4X4 (RHD)
B = Cherokee 4X2 (RHD)
T = Cherokee 4X2 (LHD)
6 Series 2 = SE
6 = Sport/Classic
7 = Limited
7 Body Style 7 = 2dr Sport Utility
8 = 4dr Sport Utility
8 Engine P = 2.5L Gasoline
S = 4.0L Gasoline
9 Check Digit
10 Model Year Y=2000
11 Assembly Plant L = Toledo #1
12 thru 17 Vehicle Build Sequence
XJ INTRODUCTION 1

VEHICLE SAFETY CERTIFICATION LABEL
A vehicle safety certification label (Fig. 1) is
attached to every DaimlerChrysler Corporation vehi-
cle. The label certifies that the vehicle conforms to all
applicable Federal Motor Vehicle Safety Standards.
The label also lists:
•Month and year of vehicle manufacture.
•Gross Vehicle Weight Rating (GVWR). The gross
front and rear axle weight ratings (GAWR’s) are
based on a minimum rim size and maximum cold tire
inflation pressure.
•Vehicle Identification Number (VIN).
•Type of vehicle.
•Type of rear wheels.
•Bar code.
•Month, Day and Hour (MDH) of final assembly.
•Paint and Trim codes.
•Country of origin.
The label is located on the driver-side door shut-
face.
INTERNATIONAL SYMBOLS
DESCRIPTION
The graphic symbols illustrated in the following
International Control and Display Symbols Chart are
used to identify various instrument controls. The
symbols correspond to the controls and displays that
are located on the instrument panel.
Fig. 1 Vehicle Safety Certification Label—Typical
2 INTRODUCTION XJ
DESCRIPTION AND OPERATION (Continued)

FASTENER IDENTIFICATION
DESCRIPTION
GRADE/CLASS IDENTIFICATION
The SAE bolt strength grades range from grade 2
to grade 8. The higher the grade number, the greater
the bolt strength. Identification is determined by the
line marks on the top of each bolt head. The actual
bolt strength grade corresponds to the number of line
marks plus 2. The most commonly used metric bolt
strength classes are 9.8 and 10.9. The metric
strength class identification number is imprinted on
the head of the bolt. The higher the class number,
the greater the bolt strength. Some metric nuts are
imprinted with a single-digit strength class on the
nut face. Refer to the Fastener Identification and
Fastener Strength Charts.
FASTENER USAGE
WARNING: USE OF AN INCORRECT FASTENER
MAY RESULT IN COMPONENT DAMAGE OR PER-
SONAL INJURY.
Figure art, specifications and torque references in
this Service Manual are identified in metric and SAE
format.
During any maintenance or repair procedures, it is
important to salvage all fasteners (nuts, bolts, etc.)
for reassembly. If the fastener is not salvageable, a
fastener of equivalent specification must be used.
THREADED HOLE REPAIR
Most stripped threaded holes can be repaired using
a Helicoilt. Follow the manufactures recommenda-
tions for application and repair procedures.
1 High Beam 13 Rear Window Washer
2 Fog Lamps 14 Fuel
3 Headlamp, Parking Lamps, Panel Lamps 15 Engine Coolant Temperature
4 Turn Warning 16 Battery Charging Condition
5 Hazard Warning 17 Engine Oil
6 Windshield Washer 18 Seat Belt
7 Windshield Wiper 19 Brake Failure
8 Windshield Wiper and Washer 20 Parking Brake
9 Windscreen Demisting and Defrosting 21 Front Hood
10 Ventilating Fan 22 Rear hood (Decklid)
11 Rear Window Defogger 23 Horn
12 Rear Window Wiper 24 Lighter
XJ INTRODUCTION 3
DESCRIPTION AND OPERATION (Continued)

FASTENER IDENTIFICATION
4 INTRODUCTION XJ
DESCRIPTION AND OPERATION (Continued)

FASTENER STRENGTH
XJ INTRODUCTION 5
DESCRIPTION AND OPERATION (Continued)

METRIC SYSTEM
DESCRIPTION
The metric system is based on quantities of one,
ten, one hundred, one thousand and one million.
The following chart will assist in converting metric
units to equivalent English and SAE units, or vise
versa.
CONVERSION FORMULAS AND EQUIVALENT VALUES
MULTIPLY BY TO GET MULTIPLY BY TO GET
in-lbs x 0.11298 = Newton Meters (N·m) N·m x 8.851 = in-lbs
ft-lbs x 1.3558 = Newton Meters (N·m) N·m x 0.7376 = ft-lbs
Inches Hg
(60° F) x 3.377 = Kilopascals (kPa) kPa x 0.2961 = Inches Hg
psi x 6.895 = Kilopascals (kPa) kPa x 0.145 = psi
Inches x 25.4 = Millimeters (mm) mm x 0.03937 = Inches
Feet x 0.3048 = Meters (M) M x 3.281 = Feet
Yards x 0.9144 = Meters M x 1.0936 = Yards
mph x 1.6093 = Kilometers/Hr. (Km/h) Km/h x 0.6214 = mph
Feet/Sec x 0.3048 = Meters/Sec (M/S) M/S x 3.281 = Feet/Sec
mph x 0.4470 = Meters/Sec (M/S) M/S x 2.237 = mph
Kilometers/
Hr. (Km/h) x 0.27778 = Meters/Sec (M/S) M/S x 3.600 Kilometers/Hr. (Km/h)
COMMON METRIC EQUIVALENTS
1 inch = 25 Millimeters 1 Cubic Inch = 16 Cubic Centimeters
1 Foot = 0.3 Meter 1 Cubic Foot = 0.03 Cubic Meter
1 Yard = 0.9 Meter 1 Cubic Yard = 0.8 Cubic Meter
1 Mile = 1.6 Kilometers
Refer to the Metric Conversion Chart to convert
torque values listed in metric Newton- meters (N·m).
Also, use the chart to convert between millimeters
(mm) and inches (in.)
TORQUE REFERENCES
DESCRIPTION
Individual Torque Charts appear at the end of
many Groups. Refer to the Standard Torque Specifi-
cations Chart for torque references not listed in the
individual torque charts.
6 INTRODUCTION XJ
DESCRIPTION AND OPERATION (Continued)

METRIC CONVERSION CHART
XJ INTRODUCTION 7
DESCRIPTION AND OPERATION (Continued)

TORQUE SPECIFICATIONS
8 INTRODUCTION XJ
DESCRIPTION AND OPERATION (Continued)

INTRODUCTION
TABLE OF CONTENTS
page page
DESCRIPTION AND OPERATION
VEHICLE IDENTIFICATION NUMBER ..........1 E-MARK LABEL ..........................2 MANUFACTURER PLATE ...................2
DESCRIPTION AND OPERATION
VEHICLE IDENTIFICATION NUMBER
DESCRIPTION
The Vehicle Identification Number (VIN) plate is
located on the lower windshield fence near the left
A-pillar. The VIN contains 17 characters that provide
data concerning the vehicle. Refer to the VIN decod-
ing chart to determine the identification of a vehicle.
The Vehicle Identification Number is also
imprinted on the:
•Body Code Plate.
•Vehicle Safety Certification Label.
•Frame rail.
To protect the consumer from theft and possible
fraud the manufacturer is required to include a
Check Digit at the ninth position of the Vehicle Iden-
tification Number. The check digit is used by the
manufacturer and government agencies to verify the
authenticity of the vehicle and official documenta-
tion. The formula to use the check digit is not
released to the general public.
VEHICLE IDENTIFICATION NUMBER DECODING CHART
POSITION INTERPRETATION CODE = DESCRIPTION
1 Country of Origin 1 = United States
2 Make J = Jeep
3 Vehicle Type 4 = MPV
4 Gross Vehicle Weight Rating F = 4001-5000 lbs.
5 Vehicle Line F = Cherokee 4X4 (LHD)
J = Cherokee 4X4 (RHD) EXPORT
N = Cherokee 4X4 (RHD)
B = Cherokee 4X2 (RHD)
T = Cherokee 4X2 (LHD)
6 Series/Transmission N = 5 Speed Manual
A = 3 Speed Auto
B = 4 Speed Auto
4 = Sport
6 = Cherokee Country/Limited
5 = Classic
7 Body Style 7 = 2dr Sport Utility
8 = 4dr Sport Utility
8 Engine M = 2.5L Diesel
P = 2.5L Gasoline
S = 4.0L Gasoline
9 Check Digit
10 Model Year Y = 2000
11 Assembly Plant L = Toledo Assembly#1
12 thru 17 Vehicle Build Sequence
XJ INTRODUCTION 1

E-MARK LABEL
DESCRIPTION
An E-mark Label (Fig. 1) is located on the rear
shut face of the driver’s door. The label contains the
following information:
•Date of Manufacture
•Month-Day-Hour (MDH)
•Vehicle Identification Number (VIN)
•Country Codes
•Regulation Number
•Regulation Amendment Number
•Approval Number
MANUFACTURER PLATE
DESCRIPTION
The Manufacturer Plate (Fig. 2) is located in the
engine compartment on the radiator closure panel
crossmember adjacent to the Body Code Plate. The
plate contains five lines of information:
1. Vehicle Identification Number (VIN)
2. Gross Vehicle Mass (GVM)
3. Gross Train Mass (GTM)
4. Gross Front Axle Rating (GFAR)
5. Gross Rear Axle Rating (GRAR)
Fig. 1 E-Mark Label
1 – Country Code
2 – Regulation Number
3 – Approval Number
4 – Amendment Number
Fig. 2 Manufacturer Plate
2 INTRODUCTION XJ
DESCRIPTION AND OPERATION (Continued)

LUBRICATION AND MAINTENANCE
TABLE OF CONTENTS
page page
LUBRICANTS .............................1
MAINTENANCE SCHEDULES .................4 JUMP STARTING, TOWING AND HOISTING .....9
LUBRICANTS
TABLE OF CONTENTS
page page
SERVICE PROCEDURES
PARTS AND LUBRICANT
RECOMMENDATIONS ....................1
INTERNATIONAL SYMBOLS .................1
CLASSIFICATION OF LUBRICANTS............1
SPECIFICATIONS
FLUID CAPACITIES ........................3
SERVICE PROCEDURES
PARTS AND LUBRICANT RECOMMENDATIONS
RECOMMENDATIONS
When service is required, DaimlerChrysler Corpo-
ration recommends that only Mopartbrand parts,
lubricants and chemicals be used. Mopar provides
the best engineered products for servicing Daimler-
Chrysler Corporation vehicles.
INTERNATIONAL SYMBOLS
DaimlerChrysler Corporation uses international
symbols to identify engine compartment lubricant
and fluid inspection and fill locations (Fig. 1).
CLASSIFICATION OF LUBRICANTS
Only lubricants bearing designations defined by
the following organization should be used to service a
DaimlerChrysler Corporation vehicle.
•Society of Automotive Engineers (SAE)
•American Petroleum Institute (API) (Fig. 2)
•National Lubricating Grease Institute (NLGI)
(Fig. 3)
ENGINE OIL
SAE VISCOSITY RATING INDICATES ENGINE OIL VISCOSITY
An SAE viscosity grade is used to specify the vis-
cosity of engine oil. SAE 30 specifies a single viscos-
ity engine oil. Engine oils also have multiple
viscosities. These are specified with a dual SAE vis-
cosity grade which indicates the cold-to-hot tempera-
ture viscosity range.
•SAE 30 = single grade engine oil.
•SAE 10W-30 = multiple grade engine oil.
DaimlerChrysler Corporation only recommends
multiple grade engine oils.
Fig. 1 International Symbols
XJ LUBRICATION AND MAINTENANCE 0 - 1

API QUALITY CLASSIFICATION
This symbol (Fig. 2) on the front of an oil container
means that the oil has been certified by the Ameri-
can Petroleum Institute (API) to meet all the lubri-
cation requirements specified by DailmlerChrysler
Corporation.
Refer to Group 9, Engine for gasoline engine oil
specification.
GEAR LUBRICANTS
SAE ratings also apply to multiple grade gear
lubricants. In addition, API classification defines the
lubricants usage.
LUBRICANTS AND GREASES
Lubricating grease is rated for quality and usage
by the NLGI. All approved products have the NLGI
symbol (Fig. 3) on the label. At the bottom NLGI
symbol is the usage and quality identification letters.
Wheel bearing lubricant is identified by the letter
“G”. Chassis lubricant is identified by the latter “L”.
The letter following the usage letter indicates the
quality of the lubricant. The following symbols indi-
cate the highest quality.
Fig. 2 API Symbol
Fig. 3 NLGI Symbol
1 – WHEEL BEARINGS
2 – CHASSIS LUBRICATION
3 – CHASSIS AND WHEEL BEARINGS
0 - 2 LUBRICATION AND MAINTENANCE XJ
SERVICE PROCEDURES (Continued)

SPECIFICATIONS
FLUID CAPACITIES
FUEL TANK
All ........................ 76.4 L (20.2 gal.)
ENGINE OIL W/FILTER CHANGE
2.5L ......................... 3.8L(4.0 qts.)
4.0L ......................... 5.7L(6.0 qts.)
COOLING SYSTEM
2.5L ......................... 9.5L(10qts.)*
4.0L ....................... 11.4L(12qts.)**
*Includes 2.2 L (2.3 qts) for coolant recovery reser-
voir.
**Includes 0.9 L (1.0 qt) for coolant recovery reser-
voir.
AUTOMATIC TRANSMISSION
Dry fill capacity*
AW4........................ 7.8L(16.5 pts.)
30RH ....................... 4.67 L (9.86pts.)
*Depending on type and size of internal cooler,
length and inside diameter of cooler lines, or use of an
auxiliary cooler, these figures may vary. Refer to
Group 21, Transmission for proper fluid fill procedure.
MANUAL TRANSMISSION
AX5 (4X2) .................... 3.5L(3.7 qts.)
AX5 (4X4) .................... 3.3L(3.5 qts.)
AX15 (4X2) ................... 3.15 L (3.3 qts.)
AX15 (4X4) ................... 3.15 L (3.3 qts.)
TRANSFER CASE
SELEC-TRAC 242 ............. 1.3L(2.85 pts.)
COMMAND-TRAC 231 .......... 1.0L(2.2 pts.)
FRONT AXLE
181–FBI .................... 1.48 L (3.13 pts.)
186–FBI ...................... 1.18L (2.5pts.)
REAR AXLE
194–RBI .................... 1.66 L (3.5 pts.*)
8-1/4 ...................... 2.08 L (4.4 pts.**)
* When equipped with TRAC-LOK, include 3.5
ounces of Friction Modifier Additive.
** When equipped with TRAC-LOK, include 4
ounces of Friction Modifier Additive.
POWER STEERING
Power steering fluid capacities are dependent on
engine/chassis options as well as steering gear/cooler
options. Depending on type and size of internal
cooler, length and inside diameter of cooler lines, or
use of an auxiliary cooler, these capacities may vary.
Refer to Section 19 of the service manual for proper
fill and bleed procedures.
XJ LUBRICATION AND MAINTENANCE 0 - 3

MAINTENANCE SCHEDULES
TABLE OF CONTENTS
page page
SERVICE PROCEDURES
DESCRIPTION............................4 UNSCHEDULED INSPECTION................4
SERVICE PROCEDURES
DESCRIPTION
Service and maintenance procedures for compo-
nents and systems listed in Schedule “A” or “B” can
be found by using the Group Tab Locator index at
the front of this manual. If it is not clear which
group contains the information needed, refer to the
index at the back of this manual.
There are two maintenance schedules that show
proper service based on the conditions that the vehi-
cle is subjected to.
Schedule “A”, lists scheduled maintenance to be
performed when the vehicle is used for general trans-
portation.
Schedule “B”, lists maintenance intervals for vehi-
cles that are operated under the conditions listed at
the beginning of that schedule section.
Use the schedule that best describes the driving
conditions.
Where time and mileage are listed, follow the
interval that occurs first.
UNSCHEDULED INSPECTION
At Each Stop For Fuel
•Check engine oil level, add as required.
•Check windshield washer solvent and add if
required.
Once A Month
•Check tire pressure and look for unusual wear
or damage.
•Inspect battery and clean and tighten terminals
as required. Check electrolyte level and add water as
needed.
•Check fluid levels of coolant reservoir, power
steering, brake master cylinder, and transmission
and add as needed.
•Check all lights and all other electrical items for
correct operation.
At Each Oil Change
•Inspect exhaust system.
•Inspect brake hoses.
•Rotate the tires at each oil change interval
shown on Schedule “A” (7,500 miles) or every other
interval shown on Schedule “B” (6,000 miles).
•Check coolant level, hoses, and clamps.
•After completion of off-road operation, the
underside of the vehicle should be thoroughly
inspected. Examine threaded fasteners for looseness.
EMISSION CONTROL SYSTEM MAINTENANCE
The scheduled emission maintenance listed in bold
type on the Maintenance Schedules, must be done at
the mileage specified to assure the continued proper
functioning of the emission control system. These,
and all other maintenance services included in this
manual, should be done to provide the best vehicle
performance and reliability. More frequent mainte-
nance may be needed for vehicles in severe operating
conditions such as dusty areas and very short trip
driving.
FLUID FILL LOCATIONS AND LUBRICATION
POINTS
The fluid fill/check locations and lubrication points
are located in each applicable group.
SCHEDULE “A”
7,500 Miles (12 000 km) or at 6 months
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage (4x4 only).
15,000 Miles (24 000 km) or at 12 months
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
•Lubricate steering and suspension ball joints.
22,500 Miles (36 000 km) or at 18 months
•Change engine oil.
•Replace engine oil filter.
•Inspect brake linings.
•Lubricate steering linkage (4x4 only).
0 - 4 LUBRICATION AND MAINTENANCE XJ

30,000 Miles (48 000 km) or at 24 months
•Change engine oil.
•Replace engine oil filter.
•Replace air cleaner element.
•Replace spark plugs.
•Inspect drive belt, adjust tension as necessary.
•Lubricate steering linkage.
•Drain and refill automatic transmission fluid.
•Drain and refill transfer case fluid.
•Lubricate steering and suspension ball joints.
37,500 Miles (60 000 km) or at 30 months
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage (4x4 only).
•Drain and refill manual transmission fluid.
45,000 Miles (72 000 km) or at 36 months
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
•Inspect brake linings.
•Flush and replace engine coolant at 36 months,
regardless of mileage.
•Lubricate steering and suspension ball joints.
52,500 Miles (84 000 km) or at 42 months
•Change engine oil.
•Replace engine oil filter.
•Flush and replace engine coolant if not done at
36 months.
•Lubricate steering linkage (4x4 only).
60,000 Miles (96 000 km) or at 48 months
•Change engine oil.
•Replace engine oil filter.
•Replace engine air cleaner element.
•Replace ignition cables.
•Replace spark plugs.
•Inspect drive belt, adjust tension as necessary.
•Lubricate steering linkage.
•Drain and refill automatic transmission fluid.
•Drain and refill transfer case fluid.
•Lubricate steering and suspension ball joints.
67,500 Miles (108 000 km) or at 54 months
•Change engine oil.
•Replace engine oil filter.
•Inspect brake linings.
•Lubricate steering linkage (4x4 only).
75,000 Miles (120 000 km) or at 60 months
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
•Flush and replace engine coolant if it has been
30,000 miles (48 000 km) or 24 months since last
change.
•Lubricate steering and suspension ball joints.
•Drain and refill manual transmission fluid.
82,500 Miles (133 000 km) or at 66 months
•Change engine oil.
•Replace engine oil filter.
•Flush and replace engine coolant if it has been
30,000 miles (48 000 km) or 24 months since last
change.
•Lubricate steering linkage (4x4 only).
90,000 Miles (144 000 km) or at 72 months
•Change engine oil.
•Replace engine oil filter.
•Replace engine air cleaner element.
•Replace spark plugs.
•Inspect drive belt, adjust tension as necessary.
•Lubricate steering linkage.
•Drain and refill automatic transmission fluid.
•Drain and refill transfer case fluid.
•Inspect brake linings.
•Lubricate steering and suspension ball joints.
97,500 Miles (156 000 km) or at 78 months
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage (4x4 only).
105,000 Miles (168 000 km) or at 84 months
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
•Flush and replace engine coolant if it has been
30,000 miles (48 000 km) or 24 months since last
change.
•Lubricate steering and suspension ball joints.
112,500 Miles (180 000 km) or at 90 months
•Change engine oil.
•Replace engine oil filter.
•Inspect brake linings.
•Flush and replace engine coolant if it has been
30,000 miles (48 000 km) or 24 months since last
change.
•Lubricate steering linkage (4x4 only).
•Drain and refill manual transmission fluid.
120,000 Miles (192 000 km) or at 96 months
•Change engine oil.
•Replace engine oil filter.
•Replace engine air cleaner element.
•Replace ignition cables.
•Replace spark plugs.
•Inspect drive belt, adjust tension as necessary.
XJ LUBRICATION AND MAINTENANCE 0 - 5
SERVICE PROCEDURES (Continued)

•Lubricate steering linkage.
•Drain and refill automatic transmission fluid.
•Drain and refill transfer case fluid.
•Lubricate steering and suspension ball joints.
Important: Inspection and service should also be
performed any time a malfunction is observed or sus-
pected.
SCHEDULE “B”
Follow Schedule “B” if the vehicle is usually oper-
ated under one or more of the following conditions.
•Frequent short trips driving less than 5 miles (8
km).
•Frequent driving in dusty conditions.
•Frequent trailer towing.
•Extensive idling.
•More than 50% of driving is at sustained high
speeds during hot weather, above 90°F (32°C).
•Off-road driving.
•Desert operation.
3,000 Miles (5 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
6,000 Miles (10 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
•Lubricate steering and suspension ball joints.
9,000 Miles (14 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
12,000 Miles (19 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
•Drain and refill automatic transmission fluid.
•Drain and refill front and rear axles.‡
•Inspect brake linings.
•Lubricate steering and suspension ball joints.
15,000 Miles (24 000 km)
•Change engine oil.
•Replace engine oil filter.
•Inspect engine air cleaner element, replace
as necessary.
•Lubricate steering linkage.
18,000 Miles (29 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
•Lubricate steering and suspension ball joints.
•Drain and refill manual transmission fluid.
21,000 Miles (34 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
24,000 Miles (38 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
•Drain and refill automatic transmission fluid.
•Drain and refill front and rear axles.‡
•Inspect brake linings.
•Lubricate steering and suspension ball joints.
27,000 Miles (43 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
30,000 Miles (48 000 km)
•Change engine oil.
•Replace engine oil filter.
•Replace engine air cleaner element.
•Replace spark plugs.
•Inspect drive belt, adjust tension as necessary.
•Lubricate steering linkage.
•Drain and refill transfer case fluid.
•Lubricate steering and suspension ball joints.
33,000 Miles (53 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
36,000 Miles (58 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
•Drain and refill automatic transmission fluid.
•Drain and refill front and rear axles.‡
•Inspect brake linings.
•Lubricate steering and suspension ball joints.
•Drain and refill manual transmission fluid.
39,000 Miles (62 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
42,000 Miles (67 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
•Lubricate steering and suspension ball joints.
0 - 6 LUBRICATION AND MAINTENANCE XJ
SERVICE PROCEDURES (Continued)

45,000 Miles (72 000 km)
•Change engine oil.
•Replace engine oil filter.
•Inspect engine air cleaner element, replace
as necessary.
•Lubricate steering linkage.
48,000 Miles (77 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
•Drain and refill automatic transmission fluid.
•Drain and refill front and rear axles.‡
•Inspect brake linings.
•Lubricate steering and suspension ball joints.
51,000 Miles (82 000 km)
•Change engine oil.
•Replace engine oil filter.
•Flush and replace engine coolant.
•Lubricate steering linkage.
54,000 Miles (86 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
•Lubricate steering and suspension ball joints.
•Drain and refill manual transmission fluid.
57,000 Miles (91 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
60,000 Miles (96 000 km)
•Change engine oil.
•Replace engine oil filter.
•Replace engine air cleaner element.
•Replace ignition cables.
•Replace spark plugs.
•Inspect drive belt, adjust tension as necessary.
•Lubricate steering linkage.
•Drain and refill automatic transmission fluid.
•Drain and refill transfer case fluid.
•Drain and refill front and rear axles.‡
•Inspect brake linings.
•Lubricate steering and suspension ball joints.
63,000 Miles (101 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
66,000 Miles (106 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
•Lubricate steering and suspension ball joints.
69,000 Miles (110 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
72,000 Miles (115 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
•Drain and refill automatic transmission fluid.
•Drain and refill front and rear axles.‡
•Inspect brake linings.
•Lubricate steering and suspension ball joints.
•Drain and refill manual transmission fluid.
75,000 Miles (120 000 km)
•Change engine oil.
•Replace engine oil filter.
•Inspect engine air cleaner element, replace
as necessary.
•Lubricate steering linkage.
78,000 Miles (125 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
•Lubricate steering and suspension ball joints.
81,000 Miles (130 000 km)
•Change engine oil.
•Replace engine oil filter.
•Flush and replace engine coolant if it has been
30,000 miles (48 000 km) since last change.
•Lubricate steering linkage.
84,000 Miles (134 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
•Drain and refill automatic transmission fluid.
•Drain and refill front and rear axles.‡
•Inspect brake linings.
•Lubricate steering and suspension ball joints.
XJ LUBRICATION AND MAINTENANCE 0 - 7
SERVICE PROCEDURES (Continued)

87,000 Miles (139 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
90,000 Miles (144 000 km)
•Change engine oil.
•Replace engine oil filter.
•Replace engine air cleaner element.
•Replace spark plugs.
•Inspect drive belt, adjust tension as necessary.
•Lubricate steering linkage.
•Drain and refill transfer case fluid.
•Lubricate steering and suspension ball joints.
•Drain and refill manual transmission fluid.
93,000 Miles (149 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
96,000 Miles (154 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
•Drain and refill automatic transmission fluid.
•Drain and refill front and rear axles.‡
•Inspect brake linings.
•Lubricate steering and suspension ball joints.
99,000 Miles (158 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
102,000 Miles (163 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
•Lubricate steering and suspension ball joints.
105,000 Miles (168 000 km)
•Change engine oil.
•Replace engine oil filter.
•Inspect engine air cleaner element, replace
as necessary.
•Lubricate steering linkage.
108,000 Miles (173 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
•Drain and refill automatic transmission fluid.
•Drain and refill front and rear axles.‡
•Inspect brake linings.
•Lubricate steering and suspension ball joints.
•Drain and refill manual transmission fluid.
111,000 Miles (178 000 km)
•Change engine oil.
•Replace engine oil filter.
•Flush and replace engine coolant if it has been
30,000 miles (48 000 km) since last change.
•Lubricate steering linkage.
114,000 Miles (182 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
•Lubricate steering and suspension ball joints.
117,000 Miles (187 000 km)
•Change engine oil.
•Replace engine oil filter.
•Lubricate steering linkage.
120,000 Miles (192 000 km)
•Change engine oil.
•Replace engine oil filter.
•Replace engine air cleaner element.
•Replace ignition cables.
•Replace spark plugs.
•Inspect drive belt, adjust tension as necessary.
•Lubricate steering linkage.
•Drain and refill automatic transmission fluid.
•Drain and refill transfer case fluid.
•Drain and refill front and rear axles.‡
•Inspect brake linings.
•Lubricate steering and suspension ball joints.
‡Off-highway operation, trailer towing, taxi, limou-
sine, bus, snow plowing, or other types of commercial
service or prolonged operation with heavy loading,
especially in hot weather, require front and rear axle
service indicated witha‡inSchedule “B”. Perform
these services if the vehicle is usually operated under
these conditions.
Important: Inspection and service should also be
performed any time a malfunction is observed or sus-
pected.
0 - 8 LUBRICATION AND MAINTENANCE XJ
SERVICE PROCEDURES (Continued)

JUMP STARTING, TOWING AND HOISTING
TABLE OF CONTENTS
page page
SERVICE PROCEDURES
JUMP STARTING PROCEDURE...............9
TWO-WHEEL-DRIVE VEHICLE TOWING .......10
FOUR-WHEEL-DRIVE VEHICLE TOWING ......10
EMERGENCY TOW HOOKS.................11
HOISTING RECOMMENDATIONS.............11
SERVICE PROCEDURES
JUMP STARTING PROCEDURE
WARNING: REVIEW ALL SAFETY PRECAUTIONS
AND WARNINGS IN GROUP 8A, BATTERY/START-
ING/CHARGING SYSTEMS DIAGNOSTICS. DO NOT
JUMP START A FROZEN BATTERY, PERSONAL
INJURY CAN RESULT. DO NOT JUMP START WHEN
MAINTENANCE FREE BATTERY INDICATOR DOT IS
YELLOW OR BRIGHT COLOR. DO NOT JUMP
START A VEHICLE WHEN THE BATTERY FLUID IS
BELOW THE TOP OF LEAD PLATES. DO NOT
ALLOW JUMPER CABLE CLAMPS TO TOUCH
EACH OTHER WHEN CONNECTED TO A BOOSTER
SOURCE. DO NOT USE OPEN FLAME NEAR BAT-
TERY. REMOVE METALLIC JEWELRY WORN ON
HANDS OR WRISTS TO AVOID INJURY BY ACCI-
DENTAL ARCING OF BATTERY CURRENT. WHEN
USING A HIGH OUTPUT BOOSTING DEVICE, DO
NOT ALLOW BATTERY VOLTAGE TO EXCEED 16
VOLTS. REFER TO INSTRUCTIONS PROVIDED
WITH DEVICE BEING USED.
CAUTION: When using another vehicle as a
booster, do not allow vehicles to touch. Electrical
systems can be damaged on either vehicle.
TO JUMP START A DISABLED VEHICLE:
(1) Raise hood on disabled vehicle and visually
inspect engine compartment for:
•Battery cable clamp condition, clean if necessary.
•Frozen battery.
•Yellow or bright color test indicator, if equipped.
•Low battery fluid level.
•Generator drive belt condition and tension.
•Fuel fumes or leakage, correct if necessary.
CAUTION: If the cause of starting problem on dis-
abled vehicle is severe, damage to booster vehicle
charging system can result.
(2) When using another vehicle as a booster
source, turn off all accessories, place gear selector in
park or neutral, set park brake and operate engine at
1200 rpm.
(3) On disabled vehicle, place gear selector in park
or neutral and set park brake. Turn off all accesso-
ries.
(4) Connect jumper cables to booster battery. RED
clamp to positive terminal (+). BLACK clamp to neg-
ative terminal (-). DO NOT allow clamps at opposite
end of cables to touch, electrical arc will result.
Review all warnings in this procedure.
(5) On disabled vehicle, connect RED jumper cable
clamp to positive (+) terminal. Connect BLACK
jumper cable clamp to engine ground as close to the
ground cable attaching point as possible (Fig. 1).
Fig. 1 Jumper Cable Connections—Typical
1 – POSITIVE CABLE CONNECTION
2 – BOOSTER BATTERY
3 – NEGATIVE OR GROUND CABLE CONNECTION
XJ LUBRICATION AND MAINTENANCE 0 - 9
