2007 JEEP®COMPASS
Welcome to an entirely new direction of
Jeep-enabled self-expression.

Jeep® Compass is designed for ultimate utility. That includes getting yourself and
your stu in and out of Compass. Its ve-door design provides access to the vehicle’s
more than 60 cu ft of passenger space.
Both Compass models feature standard advanced multistage
driver and front-passenger air bags* with a driver’s side knee
bolster.
*Always sit properly in the seat with the seat belt fastened.
COMPASS FEATURES
FIVE-DOOR VERSATILITY
ADVANCED MULTISTAGE AIR BAGS
YES Essentials® stain/odor resistant seat fabric is the solution to nearly every kind of
problem, from muddy pets and soccer players, to spilled coee and greasy French fries.
It’s exactly what today’s non-stop professionals with families and full lives want and
need to help protect their vehicle’s cloth interior.
YES Essentials is a trademark of Milliken & Co.
YES ESSENTIALS? FABRIC
Page 2 of 7
ESP & TRACTION CONTROL
The Compass’ standard Electronic Stability Program (ESP)* helps the driver maintain
vehicle directional stability by applying selective braking and engine control. The
traction control helps maintain vehicle mobility by applying the brakes, and in some
cases closing the throttle.
Always drive carefully, consistent with conditions. Always wear your seat belt and obey trac laws.
For more information, please visit www.jeep.com/compass
Jeep is a registered trademark of DaimlerChrysler Corporation
©1995-2006 DaimlerChrysler. All Rights Reserved. For important information, go to jeep.com/privacy
Brilliant! Compass features an available bright, dual-purpose
removable and rechargeable cargo lamp/ashlight. When
mounted in the headliner, the ashlight battery is recharged
while the light is used as the cargo lamp. When unsnapped
from the headliner, the lamp becomes a convenient portable
ashlight.
CRUSH ZONES
Engineered crush zones divert and dissipate impact energy away
from the passenger compartment and help minimize injuries in
the event of an accident, while side-guard door beams provide
additional impact protection.
REMOVABLE FLASHLIGHT

Jeep® Compass delivers
impressive power. Available
on Jeep Compass Sport and
standard on Limited models
is a mighty 2.4-Liter dual
overhead cam (DOHC) I-4
engine that produces 172
horsepower and 165 lb-ft. of
torque.
Compass’s state-of-the-art electronic
four-wheel-drive system anticipates the need for
added traction and responds to wheel-slippage by
transferring pwer between the front and rear wheels.
This system also improves vehicle stability in
cornering situations by modulation power to the
rear wheels.
COMPASS CAPABILITY
HANDLING
WORLD ENGINE
Enjoy great handling with a four-wheel
independent MacPherson strut front suspension
and a multilink rear suspension tuned for superior
ride, handling, and noise reduction.
Page 3 of 7
TRANSMISSION
When it comes to transmission of power,
Compass gives you choices. Choose a
ve-speed manual, a second-generation
continuously variable transaxle (CVT2), or
the available CVT2 with AutoStick®
(Limited only). The CVT2 uses a steel-push
belt and pulleys instead of gears for
smooth, ecient driving performance.
For more information, please visit www.jeep.com/compass
Jeep is a registered trademark of DaimlerChrysler Corporation
©1995-2006 DaimlerChrysler. All Rights Reserved. For important information, go to jeep.com/privacy
FREEDOM-DRIVE ITM SYSTEM
Take advantage of an impressive 26/30 MPG*
(city/highway), available on the Jeep® Compass 4x2
models with manual transmission. Do more. Drive
further. Save on fuel.
*When properly equipped . 2007 EPA estimated miles per
gallon.
GO THE DISTANCE

Page 4 of 7
For more information, please visit www.jeep.com/compass
Jeep is a registered trademark of DaimlerChrysler Corporation
©1995-2006 DaimlerChrysler. All Rights Reserved. For important information, go to jeep.com/privacy
COMPASS COLOR OPTIONS
NOTE: Due to occasional printing irregularities, the colors shown may vary slightly from actual vehicle colors.
