Jenn-Air JMC2430WS Parts list manual

27" (68.6 cm) and 30" (76.2 cm) Microwave Ovens
27" (68.6 cm) models
A. 27" (68.6 cm) min. cabinet
width
cutout to bottom of upper
cabinet door
C. (101.6 cm) bottom of
cutout to floor (recommended)
D. 25
¹⁄₂ " (64.8 cm) cutout width
E. 1
¹⁄₂ " (3.8 cm) min. bottom of
cutout to top of cabinet door
cutout height (will fit cutout
height from 17" [43.2 cm] to
G. 21
⁷⁄₈ " (55.5 cm) min. cutout
depth
30" (76.2 cm) models
A. (76.2 cm) min. cabinet
width
cutout to bottom of upper
cabinet door
C. (101.6 cm) bottom of
cutout to floor (recommended)
D. 28
¹⁄₂ " (72.4 cm) cutout width
E. 1
¹⁄₂ " (3.8 cm) min. bottom of
cutout to top of cabinet door
cutout height (will fit cutout
height from 17" [43.2 cm] to
G. 21
⁷⁄₈ " (55.5 cm) min. cutout
depth
A
B
C
D
E
FG
¹⁄₄
¹⁄₄
¹⁄₄
¹⁄₄ ¹⁄₄
¹⁄₄
40" 40"
30"
PRODUCT MODEL SERIES PRODUCT DIMENSIONS
CABINET OPENING DIMENSIONS
JMC2430W
To properly install your microwave oven, you must
determine the type of electrical connection you will
be using and follow the instructions provided for it
here.
● Microwave oven must be connected to the
proper electrical voltage and frequency as
specified on the model/serial number rating plate.
The model/serial number rating plate is located
on the left-hand side trim.
● The microwave oven rated 120/240 volt, 20-amp,
has 4 wires (L1, L2, N and G) in the flex conduit
and should be connected to a 20-amp maximum
rated circuit, overcurrent protected on both the
L1 and L2 circuits.
● A time-delay fuse or circuit breaker is
recommended.
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice. Dimensions are for planning purposes only. For complete details, see Installation Instructions packed with product. Specifications subject to change without notice. Ref. W10221385A
08/12/2009
27" (68.6 CM) AND 30" (76.2 CM) ELECTRIC BUILT-IN
CONVECTION MICROWAVE OVEN
27" (68.6 cm) and 30" (76.2 cm) Microwave Ovens
27" (68.6 cm) models
B. 19 " (48.6 cm) overall height
C. 26 " (67.9 cm) overall width
D. 22 " (57.0 cm) overall depth
height
30" (76.2 cm) models
B. 19 " (48.6 cm) overall height
C. 29 " (75.6 cm) overall width
D. 22 " (57.0 cm) overall depth
heigh
t
A
E
C
B
D
ELECTRICAL CONNECTION
A. Model/serial number plate
A
