HomePlug Ethernet Adapter
Home:Link 314
Introduction
Home:Link 314 makes Ethernet connection of your
existing electrical grids! So simple as that! Just plug it
in - and it works! And all this without any driver to
install. Home:Link 314 also takes care of your security
with 56 bit DES Encryption.
Where to use:
•Shared Broadband Internet Access
•DSL/Cable Modem Installation Extender
•AV Streaming and transfer
•Voice over IP Calls
•PC File and application sharing
•Printer and peripheral sharing
•Network and Online Gaming
•Network Cameras LAN extension
•Wireless LAN Extension
Safety
Home:Link 314 also takes care of your security with
56 bit DES Encryption with own software
Support
As a costumer of Jensen you have 3 month FREE
installation help. Our Online Manual guides you to
set-up your product / PC before you contact
costumer-service.
E-mail: [e-mail]
Warranty
All Jensen products are being delivered with 3 years
warranty.

www.jensenscandinavia.com Specifications subject to change without prior notice
HomePlug Ethernet Adapter
Home:Link 314
Technical information
Product name
•Jensen Home:Link 314
Specifications:
•Standards: 10Base-T Ethernet, IEEE 802.3, 10 Mbps
Auto MDI / MDIx Support, 14 Mbps HomePlug 1.0
compatible
•Protocols: CSMA/CA MAC control Transfer rate: 14
Mbps
•Range: Up to 5000 square feet
•Quality of Service: Forward Error Correction (FEC)
support. Channel Adaption ensures that signal
integrity is maintained even under harsh noise
environment. CSMA/CA with prioritisation and ARQ
for reliable delivery of Ethernet packets via Packet
Encapsulation. Four Level prioritised random
access method. Segment bursting and contention -
free access ensures high throughput while
maintaining low latency response and jitter
performance
•Security: 56 bit DES
•LED Indicators: 1 x Power LED, 1 x Powerline Link
Status LED, 1 x Ethernet Link / Activity Status LED
•Computer Interface: RJ45
•External Connectors: 1 x Electrical Power Socket, 1 x
RJ45 for 10Base-T Ethernet(AutoMDI / MDI-X)
•Dimension (plastic housing): 92 x 66 x 45 mm
(height x width x depth)
•Weight: Approx. 180 g
System requirements:
HomePlug Ethernet Adapter - Home:Link 314 is
applicable with all TCP/IP operating systems with
Ethernet port.
Drivers are not required for this adapter. But the
supplied Configuration Utility software to assign the
network password operates only with Windows
operating systems.
Your computer must meet the following
requirements in order to use the Home:Link
Configuration Utility:
•Windows 98SE, Windows Me, Windows 2000 or
Windows XP with Ethernet connection
•Pentium II 300 MHz MMX-Compatible PC or greater
•At least 64 MB hard disk space and memory
•CD-ROM drive
Package content:
•2 pcs Home:Link 314
•2 pcs Ethernet Cable - RJ-45
•Quick Start Guide
•CD with Online Manual and Software
