Jensen AirLink 3G User manual

Manual for how to upgrade, setup etc. your AirLink 3G
AirLink 3G
Introduction
Supported modem list
How to upgrade firmware
How to setup AirLink 3G
APN list
Change IP address on AirLink 3G
FAQ
Page 2
Page 3-5
Page 6-9
Page 10 -11
Page 12
Page 13
Page 14
Version 1.7 - July 2015 - JensenScandinavia AS

Introduction
AirLink 3G is a wireless mobile router that support most of the 3G/4G USB modem on the marked.
With AirLink 3G you can share the internet connection from an USB modem (3G/4G) on several devices
via wireless or cable (port 1,2,3 or 4)
In order for the AirLink 3G to connect to mobile broadband (3G/4G) you have to follow this steps:
LED and ports on your AirLink 3G
Information about your AirLink 3G
Default network name and encryption password are printed on the top and under the router.
- 2 -
Power
LED
Internet and
3G/4G LED
LED for LAN
port 1,2,3 and 4
WLAN
LED
USB port for
3G/4G modem WiFi
on/off
Reset/
WPS
WAN
port
LAN port 4,3,2 and 1 12V DC
input
Front back
Network name
Encryption password
How do I see the version number of my AirLink 3G?
AirLink 3G are made in 3 different versions.
Version 1 and 2 - serial number begins with AL3G....
Version 3 - serial number begins with AL3Gv3....
1
Your USB modem
(3G or 4G) must
be on the list of
supported
modems. 2
Firmware version
must be upgraded
to latest version. 3
AirLink 3G must be
setup with correct
APN and PIN code.
Page 3-5 Page 6-9 Page 10-11

- 3 -
Supported modem list (page 1 of 3)
The following 3G/4G modems are supported by firmware 2.23i
4G-systems XSStick®W12
4G-systems XSStick®W14
Alcatel X200
Alltel (Pantech) UM150AL
Alltel (Pantech) UM175AL
AMOI H01
Ando MH505UP
Any Data Z020
AnyDATA A2502
AnyDATA ADU-310A
AnyData ADU-520C
AnyDATA ADU-635WA
ASUS T500
BandLuxe C100S
BandLuxe C120
BandLuxe C170
BandLuxe C270
BandLuxe MBD-100HU
BC2703 CDMA 800 EVDO
CMotech CDU-550
CMotech D-50
Cooxoo ZX200
Dhiraagu Touch Maldives
D-Link DWM-156
D-Link DWM-652
Emobilre D12LC
EU930
FW2011-R-H3G
FW2011-T (Mywave 29)
GAORAN CC130
Gold Space E800
Huawei 827F
Huawei E1550
Huawei E1552
Huawei E156B
Huawei E156G
Huawei E160 (O2)
Huawei E160E
Huawei E160G
Huawei E169 Vodafone
Huawei E1692
Huawei E169G
Huawei E170
Huawei E173S
Huawei E1750
Huawei E176
Huawei E180
Huawei E180G
Huawei E182E
Huawei E219
Huawei E220
Huawei E226
Huawei E270
Huawei E272
Huawei E303
Huawei E3131
Huawei E3276 (4G)
Huawei E3372 (4G)
Huawei E3256
Huawei E353
Huawei E367
Huawei E372
Huawei E392 (4G)
Huawei E398 (4G)
Huawei E618
Huawei E620
Huawei E626
Huawei E630
Huawei E800
Huawei EC-1260
Huawei EC-1261
Huawei EC-169
Huawei EC-228
Huawei ET128
Huawei K3770
Huawei K4505
Huawei K5005
Kyocera KPC680 Express Card
LG L-02A
LG L-05A
Lightwave LW HSUPA
Maxon BP3
Maxon BP3-Ext
Micromax MMX 300G
Nokia CS-10
Nokia CS-15

- 4 -
Supported modem list (page 2 of 3)
The following 3G/4G modems are supported by firmware 2.23i
Nokia CS-17
Nokia CS-18
Nokia CS-19
Nokia N82
Nokia 21 M-02
Nokia 5800
Nokia 6110
Nokia N95
Nokia N97
Novatel MC760
Novatel MC950D
Novatel Merlin XU 870
Novatel Ovation 930D
Novatel U727
Onda MT503HSA
Option GI1515
Option Icon 210
Option icon 225
Option icon 401
Option icon 505
Option icon XY
Panda PT20
Prolink PHS100
Promate EGO5
Qisda H21 (Flying Beetle)
Quanta 3G MU-Q101
Quanta 3G Q110
Rilan EV8900U
Rilan EV8900UL
Shenzhen Crius 209
Sierra 875U
Sierra 880U
Sierra Aircard 875
Sierra Aircard 880E
Sierra Compass 597
Sierra Compass 885U
Sierra USB 306
Sierra USB 307
Sierra USB 598
Sierra Wireless 301
Sierra Wireless 308
Sierra Wireless 598U
Sierra Wireless 888
Sierra Wireless 960E
Sierra Wireless C885
Sierra Wireless C889
Sierra Wireless Compass 597
Sierra Wireless MC8790
SoftBank C01LC
SOFTBANK C02LC
SONY MD300
SONY MD400
Sprint 4G
Telewell LTE 3G/4G modem
T-mobile 110
T-mobile 530
TP-LINK 3G - MA260
Touchcom TW600U
UC126
UC928
UC988
V605U
Vodafone K3520
Vodafone K3565
Vodafone K3565-Z
Vodafone K3715
Vodafone K3765
Vtion E1916
Willcom HX004IN
Willcom WS002IN
ZTE AC2726
ZTE AC2736
ZTE AC 560
ZTE AC 580
ZTE AC 581
ZTE AC 8710
ZTE MF 100
ZTE MF 110
ZTE MF 190
ZTE MF 195E (#1)
ZTE MF 622
ZTE MF 626
ZTE MF 627
ZTE MF 628
ZTE MF 632
ZTE MF 636

- 5 -
Supported modem list (page 3 of 3)
The following 3G/4G modems are supported by firmware 2.23i
ZTE MF 636DBZTE MF 637
ZTE MF 638
ZTE MF 651
ZTE MF 652
ZTE MF 656
ZTE MF 668
ZTE MF 680
ZTE MF820 LTE (4G)
ZTE MF820D LTE (4G)
ZTE MF821D LTE (4G) (#1)
ZTE MF823 LTE (4G) (#1)
ZTE MF831 LTE (4G) (#1)
ZTE MF880 LTE (4G)
The following USB modems are NOT supported by AirLink 3G:
Huawei E3531
Huawei E5372
Huawei E5372T
Huawei E5832
ZTE MF60
ZTE MF91D
#1
Some USB modems have a built-in
WEB page which have the same
IP addresss (192.168.0.1) as AirLink 3G.
In order for this combination to work
you need to change the IP address of
your AirLink 3G to 192.168.2.1
Please see page 13 for how to do that.
If your USB modem are not in the list please make a debug report and send to us.
Based on this file we may be able (*) to add support for it.
* Not all types of USB modem can be added to AirLink 3G.
This is how you make a debug report:
1. Log into AirLink 3G WEB menu by enter http://192.168.0.1/debug.asp in your
WEB browser.
2. Username = admin and password = 1234 (or your own password if you changed it)
3. Enter report.txt and click Apply.
4. Save this file to your computer and send it to us at [email protected]
with a short description.

How to upgrade firmware (page 1 of 4)
Firmware is the software program inside AirLink 3G that instructs how it should operate.
Since new USB modems are added to the market all the time we need to make new firmware to make
AirLink 3G able to comunicate with them.
Step 1 - Download latest firmware file for your AirLink 3G version from JensenScandinavia.com
Step 2 - Login to AirLink 3G and upgrade the firmware.
Step 1 - Download firmware file
1. Open your WEB browser and go to http://jesenscandinavia.com/downloads
2. Select Jensen AirLink 3G from the list and click Show
3. Download the firmware file to your AirLink 3G version by click the DOWNLOAD icon.
4. Unzip the downloaded file by double-click it and then select «unzip all files»
* If you have installed WinZip/WinRar or similar software the unzip process will be different.
- 6 -
2
3
Which version do I have?
You can find the version of your
AirLink 3G based on the
beginning of the serial number.
Versjon 1 = AL3G.......
Versjon 2 = AL3G.......
Versjon 3 = AL3Gv3...
4

23
How to upgrade firmware (page 2 of 4)
5. Select the folder where you want to unzip the file to and click Unzip.
6. The file are now unzipped.
Step 2 - Login to AirLink 3G and upgrade firmware
1. Connect your computer to AirLink 3G with a network cable to port 1,2,3 or 4.
Important! Firmware upgrade DOES NOT work via wireless connection.
2. Log in to your AirLink 3G by entering http://192.168.0.1 in your WEB browser (e.g. Chrome/Firefox)
3. Enter username and password.
Username = admin and Password = 1234
- 7 -
5
6
2 1 Internet34
12V DC
ON / OFF
Reset/WPS
WiFi

How to upgrade firmware (page 3 of 4)
4. Click Tools -> Firmware Upgrade
5. Click Select file/Browse
6. Select the firmware file you unzipped earlier and click Open/OK.
The firmware file is a *.bin file (e.g. AL3G_v3_fw_2.22j.bin)
7. The file you selected are shown.
Click Apply to start the upgrade process.
- 8 -
Invalid file format?
If you get the message «Invalid file format»
when try to upgrade you have most likely
picked the wrong firmware file.
Please check that you have downloaded
the firmware file for the correct version of
AirLink 3G.

How to upgrade firmware (page 4 of 4)
8. Click OK and then OK
9. Please wait until the upgrade process is finished before proceding with the next step.
10. When the upgrade is completed you will see this screen.
11. To check the installed firmware version you can click the Status button.
Your AirLink 3G are now upgraded and you can follow the setup on the next page.
- 9 -

- 10 -
12
How to setup AirLink 3G (page 1 of 2)
In order for the AirLink 3G to be able to connect to internett you need to set it up with APN and PIN code.
1. Connect the USB modem (3G/4G) to
to the USB port on AirLink 3G
2. Make sure that your computer/device are connected to AirLink 3G by wireless or cable (port 1,2,3 or 4)
3. Log into the AirLink 3G ny entering http://192.168.0.1 in your WEB browser (e.g. Chrome/Firefox)
4. Username = admin
Password = 1234
2 1 Internet34
12V DC
ON / OFF
Reset/WPS
WiFi

- 11 -
How to setup AirLink 3G (page 2 of 2)
5. Click Advanced Settings -> WAN -> 3G/4G
6. Enter the PIN code for the SIM card.
If the PIN code are deactivted/disabled you can leave this empty.
7. Enter the APN for your prodvider (Please see next page to find the correct APN)
Important! Do NOT enter any information in the Username and Password area.
8. Click Apply and then Apply one more time and wait for the router to reboot (about 60 seconds)
9. Click Status -> Modem info to see if AirLink 3G have detected the modem.
It can take up to one minute before the modem is shown, so please try click Modem info several times
to update the screen.
10. Click Status -> Internet connection
This will show you the connection status for the USB modem (3G/4G)
Normaly it will take about 1-2 minutes before the modem is connected to the internet.
11. When the status is saying Connected then your AirLink 3G is connected to internet and ready for use.
6
7
8
This screen shows you information about
the type of USB modem connected, IMEI
and the signal strength.
1-2 min.

APN list
Select your Internet provider from the list below.
If you cannot find your provider in this list, then please contact your provider to get the correct APN to use.
APN
telenor
internet.public
internet.netcom.no
netcom
vpn.netcom.no
mobileinternet.tele2.no
internet.ventelo.no
internet.netcom.no
internet
Provider
Telenor
Telenor - public (*)
Netcom
Netcom (kun 4G)
Netcom - public (*)
Tele 2
Ventelo
Chess
Onecall
(*) Gives the AirLink 3G a public IP address (without NAT)
Provider
Telenor - Privat
Telenor - Public (*)
Telia
Djuice
Glocalnet
Tele 2 (För 3G)
Tele 2 (För 4G)
3 bredband - Privat
3 bredband - Public (*)
(*) Gives the AirLink 3G a public IP address (without NAT)
APN
internet.telenor.se
Public.telenor.se
online.telia.se
internet.djuice.se
internet.glocalnet.se
mobileinternet.tele2.se
4g.tele2.se
bredband.tre.se
data.tre.se
Provider
TDC
TDC (4G/LTE)
3 Denmark
Oister
Telia
Telenor
M1
M1 (for 4G)
APN
internet
internet-lte
bredband.tre.dk
bredband.oister.dk
www.internet.mtelia.dk
internet
internet
internet-lt
Provider
Elisa
DNA
Saunalahti
Sonera
APN
internet
internet
internet.saunalahti
internet
- 12 -

- 13 -
34
2 1 Internet34
12V DC
ON / OFF
Reset/WPS
WiFi
Change IP address on the AirLink 3G
Some USB modems have a built-in WEB server whci use the same IP address as AirLink 3G (192.168.0.1)
and this makes the modem not working.
The solution to this is to change the IP address of the AirLink 3G to 192.168.2.1
1. Disconnect the USB modem from the USB port on the AirLink 3G
2. Connect your computer to the AirLink 3G by a network cable i port 1,2,3 or 4.
3. Log into the router menu by entering http://192.168.0.1 in your WEB browser (e. g. Chrome)
4. Enter username and password.
Default username = admin
Default password = 1234
5. Click Advanced Settings -> LAN
Change the IP address to 192.168.2.1 (This will be the new IP address of your AirLink 3G from now on.)
Start IP = 192.168.2.100
End IP = 192.168.2.200
* Click Apply -> OK
* Then click Apply one more time.
* Wait one minute
6. The IP address of your AirLink 3G has now been changed. Please goto page 10 to setup your AirLink 3G.
Important!
The IP address of your AirLink 3G
has now been changed to
http://192.168.2.1 and this is the only
IP address you can use in future when
you need to logon to it.
IMPORTANT!
The procedure on this page in only necessary to do
IF you have a modem that are marked with * on page 3-5
!

- 14 -
Frequently Asked Questions
1. I can’t get my new 3G/4G modem to work with my AirLink 3G!!
AirLink 3G do support most of the 3G/4G modems on the market (see complete list on page side 3-5).
For the AirLink 3G to be able to connect to internet it’s important that the firmware are upgraded to the
latest version (page 6-9) and that it’s been setup with the correct APN and PIN code.
2. My USB modem (3G/4G) is not in the list of supported modems!!
In most cases we are able to add support for new modem models by making new firmware version.
To that we need the debug report sent to us. Please see page 13 about how you make the debug file.
3. I am not able to access AirLink 3G menu when using http://192.168.0.1 !!
The computer you are using must be connected to AirLink 3G by either wireless or cable (port 1,2,3 or 4)
in order for you to be able to login to the menu with http://192.168.0.1
If your comuter are properly connected and you still cannot access http://192.168.0.1 we recommend
you to factory reset the AirLink 3G by pressing RESET/WPS button for 10 seconds.
Then wait one minute and try accessing the menu again with http://192.168.0.1
4. I cannot see or connect to the AirLink 3G wireless network!
Please check that the backside switch on AirLink 3G marked RADIO ON/OFF is set to ON.
If the WiFi LED on AirLink 3G front are flashing it means it is transmitting a wireless signal and you
should be able to detect and connect to it.
5. How do I see which firmware version that are installed on my AirLink 3G?
- Connect your computer to AirLink 3G by wireless or cable (port 1,2,3 or 4)
- Login to the menu by entering http://192.168.0.1 in a WEB browser (e.g. Chrome, Firefox etc.)
- Username = admin and Password = 1234
- Click Status
- The firmware version are shown here:
2 1 Internet34
12V DC
ON / OFF
Reset/WPS
WiFi
10 sekunder
34
ON / OFF
Reset/WPS
WiFi
