JHCTech ALAD-151T User manual

User’s Manual
1
ALAD-151T
User’s Manual

User’s Manual
2
Version Note
No.
Ver.
Note
Date
Writer
1
A1.0
First publish
20170425
Eileen Lee

I
Copyright
The documentation and the software included with this product are copy- righted 2016 by Shenzhen JHC
Technology Co., Ltd. All rights are reserved. Shenzhen JHC Technology Co., Ltd. reserves the right to make
improvements in the products described in this manual at any time without notice. No part of this manual
may be reproduced, copied, translated or transmitted in any form or by any means without the prior written
permission of Shenzhen JHC Technology Co., Ltd. Information provided in this manual is intended to be
accurate and reliable. However, Shenzhen JHC Technology Co., Ltd. assumes no responsibility for its use,
nor for any infringements of the rights of third parties, which may result from its use.
Acknowledgements
Award is a trademark of Award Software International, Inc.
IBM, PC/AT, PS/2 and VGA are trademarks of International Business Machines Corporation.
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
RTL is a trademark of Realtek Semi-Conductor Co., Ltd.
All other product names or trademarks are properties of their respective owners.
For more information on this and other JHC products, please visit our websites at:
http://www.jhctech.com.cn

User’s Manual
II
Product Warranty (2 years)
JHC warrants to you, the original purchaser, that each of its products will be free from defects in materials
and workmanship for two years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by persons other than
repair personnel authorized by JHC, or which have been subject to misuse, abuse, accident or improper
installation.
JHC assumes no liability under the terms of this warranty as a consequence of such events.
Because of JHC.s high quality-control standards and rigorous testing, most of our customers never need to
use our repair service. If a JHC product is defective, it will be repaired or replaced at no charge during the
warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement
materials, service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU speed, JHC products used,
other hardware and software used, etc.) Note anything abnormal and list any onscreen messages you get
when the problem occurs.
2. Call your dealer and describe the problem. Please have your manual, product, and any helpful
information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandise authorization) number
from your dealer. This allows us to process your return more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement Order Card and a
photocopy proof of purchase date (such as your sales receipt) in a shippable container. A product
returned without proof of the purchase date is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer.

User’s Manual
A
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications when shielded cables are used for
external wiring. We recommend the use of shielded cables. This kind of cable is available from JHC. Please
contact your local supplier for ordering information. Test conditions for passing included the equipment
being operated within an industrial enclosure.
In order to protect the product from being damaged by ESD (Electrostatic Discharge) and EMI leakage, we
strongly recommend the use of CE-compliant industrial enclosure products.
FCC Class A
Note: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Technical Support and Assistance
Step 1. Visit the JHC web site at www.jhctech.com.cn where you can find the latest information about the
product.
Step 2. Contact your distributor, sales representative, or JHC’s customer service center for technical support
if you need additional assistance. Please have the following information ready before you call:
- Product name and serial number
- Description of your peripheral attachments
- Description of your software (operating system, version, application software, etc.)
- A complete description of the problem
- The exact wording of any error messages

User’s Manual
B
Contents
General Information............................................................................................................................................ 1
1.1 Introduction........................................................................................................................................... 2
1.2 Features.................................................................................................................................................2
1.3 Specifications........................................................................................................................................ 2
1.3.1 I/O Signal...................................................................................................................................2
1.3.2 LCD and Touch.......................................................................................................................... 3
1.3.4 Audio (Optional)........................................................................................................................ 3
1.3.5 Power Consumption................................................................................................................... 3
1.4 Environmental Specifications...............................................................................................................4
1.3 Dimensions...........................................................................................................................................4
System Setup ...................................................................................................................................................... 6
2.1 I/O indication........................................................................................................................................7
2.1.1 Power Input Connector (DC-IN)...............................................................................................8
2.1.2 USB Connector..........................................................................................................................9
2.1.3 COM Connector......................................................................................................................... 9
2.1.4 OSD Functions (ALAD-1 1 Lines).......................................................................................... 10
2.1.5 OSD Setting............................................................................................................................. 11
◆Signal source input ............................................................................................................................... 11
◆Picture................................................................................................................................................... 11
◆Sound mode..........................................................................................................................................12
◆Treble:................................................................................................................................................... 12
◆Bass:...................................................................................................................................................... 12
◆Sleep time:............................................................................................................................................12
◆Auto sleep:............................................................................................................................................12
◆OSD time:.............................................................................................................................................13
◆OSD language:......................................................................................................................................13
◆Scale mode:........................................................................................................................................... 13
◆Blue screen: .......................................................................................................................................... 13
◆Key lock:............................................................................................................................................... 13
◆Reset: ....................................................................................................................................................13
2.2 Touch Drivers .....................................................................................................................................14
2.3 Installation ..........................................................................................................................................14
2.3.1 Panel Mount............................................................................................................................. 14
2.4 Packing List ........................................................................................................................................16

User’s Manual
1
General Information
CHAPTER
1

User’s Manual
2
1.1 Introduction
ALAD-151T is a brand new industrial display, designed to meet the needs of customers who want quick and
easy integration with JHCTECH Embedded Box Computers, such as KMDA and FEBC lines. JHCTECH
offers two different touch screen of ALAD-151T to meet different demands.
ALAD-151T supports 15 inch 1024*768 TFT LCD, with 5 wire heat-resistant resistive touch screen，optional
projected capacitive touch, DC 9~36V power input.
1.2 Features
1、Aluminum die-casting chassis, flat bezel design
2、15'' LED backlight panel provides 20~30% power saving
3、Resistive touch screen or projected capacitive touch screen
4、DC 9~36V wide power input
5、Versatile mounting methods for rear mount and VESAmount
6、HDMI and VGA video input, audio in and 2x3W speaker
1.3 Specifications
1.3.1 I/O Signal
1* HDMI
1* VGA
1* RS232
1* USB2.0 Type A Ports
1* 3-Pin DC-IN

User’s Manual
3
1.3.2 LCD and Touch
LCD：
Type
15 inch TFT LED
Resolution
1024*768
Color
16.2M colors
Pixel Pitch(mm)
0.297*0.297
Brightness(cd/㎡)
350
Viewing Angle
80 degree(left), 80 degree(right), 80 degree(up), 80 degree(down)
Operating Temperature
-20℃~70℃
Back light lifetime
50,000 hours
TOUCH：
Type
5-wire resistive touch
Projected capacitive touch
Resolution
Gap less
Gap less
Light transmittance
83%
90%
Interface
USB/RS232
USB/RS232
Power Consumption
+5 V @200 mA
+5 V @300 mA
OS
Windows and Linux
Windows and Linux
Click Lifetime
35 million times
3000 million times
1.3.4 Audio (Optional)
Speaker: 2*3W speaker out
1.3.5 Power Consumption
Input Voltage: DC 9~36V
Power Consumption:
TDP 12V/0.94A(No consumption output)
PowerAdapter: AC to DC 12V/5A, 60 W
Power Requirement: Minimum power input: DC 12V/1.5A

User’s Manual
4
1.4 Environmental Specifications
Operating temperature: -20 ~ 70°C (With airflow )
Relative humidity: 10~95% @ 40°C (non-condensing)
Storage temperature: -40 ~ 80°C
Vibration loading during operation:1g 5~500Hz
Shock during operation:10g peak acceleration(duration 11ms)
EMC: CE, FCC Class A
1.3 Dimensions
Figure 1.1
