Jia Teng Talk Server Pro WP1264 Manual
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures: •Reorient or relocate the
receiving antenna. •Increase the separation between the equipment and receiver. •
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected. •Consult the dealer or an experienced radio/TV technician for
help.
FCC Caution: This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Non-modification Statement: Changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate the equipment.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
Limited Channels fixed for use in the US:
IEEE 802.11b or 802.11g or 802.11n(HT20) operation of this product in the U.S. is
firmware-limited to Channel 1 through 11. IEEE 802.11n(HT40) operation of this product in
the U.S. is firmware-limited to Channel 3 through 9.
+DUGZDUH6SHFLILFDWLRQ濣
'LPHQVLRQƝ;;PP
$QWHQQDƝ7ZRGHWDFKDEOHG%LDQWHQQD
)UHTXHQF\%DQGƝ*+]a*+]
,QSXWYROWDJHƝ$&9+]+]$
2XWSXWYROWDJHƝ'&9$
2SHUDWLRQHQYLURQPHQWƝ&a&
6WRUDJH+XPLGLW\Ɲa
,QWHUIDFHƝ5-3RUW;:$1˚5-3RUW[/$1˚5HVHW:36
EXWWRQ˚86%3RUW;˚$&;
:LUHOHVV6SHFLILFDWLRQ濣
:LUHOHVVGDWDWUDQVPLVVLRQUDWHƝ
EJQ0+]0D[LPXP7UDQVIHU5DWH
0ESV
:LUHOHVVVHFXULW\VXSSRUWƝELW:(3˚:3$7.,3ZLWK,(((
[˚:3$$(6ZLWK,((([˚:3$36.:3$36.
5RXWHU6SHFLILFDWLRQ
5RXWHU6SHFLILFDWLRQƝ:$10RGHƝ6WDWLF˚'+&3˚333R(
,QWHUQHW6KDULQJƝ'+&36HUYHU˚1$7˚3RUW0DSSLQJ
)LUHZDOOƝ,33RUWILOWHULQJ˚%ORFN3RUW6FDQ˚%ORFN6<1)ORRG
FORFNV\QFKURQL]DWLRQƝ173&OLHQW
4R6Ɲ9RLFHILUVW
,33%;6SHFLILFDWLRQ
A. PBX Features
a. IVR
¨Call busy voice prompt
¨No answer voice prompt
¨Call transfer voice prompt
¨Voice prompt for voice mail operation
¨Voice prompt for call transfer
¨Voice prompt for system setup
b. Auto Attendant
¨6 sets of Auto Attendant configuration
¨Using first DTMF for AA procedure identification
¨Auto Attendant procedure tree support
¨Voice prompt of different Auto Attendant procedures
could be recorded separately
¨Remote voice mail
¨Call transfer to extension number
¨Configuration of dialing plan for incoming call being
transferred to external number
¨On Duty/Break Duty/Off Duty modes
c. Dialing plan
¨64 sets of configuration of call dialing plan
¨64 sets of configuration of Trunk dialing plan
d. Call Features
¨Support G.711A, G.711μ-law, G.723, G.729 codec
¨D.I.L. ( Direct In Line )
¨Remote station (NAT Transversal)
¨Call transfer to extension or SIP Trunk number
¨Call forward/Busy forward to extension or SIP Trunk
number
¨Direct record AA content through IP Phone
¨Personal answering information function support
¨Voice mail setup through IP Phone
¨Phone command
¨Call holding
¨Call waiting
¨Three ways conference ( Phone support is
necessary )
¨Support blind transfer
¨Support DTMF transfer
¨Broadcast(bundle with CM5000)
¨H.264/MPEG4/H263(passthrough)
B. SIP Server
a. SIP Proxy Server
¨Build in SIP Proxy Registration Server
¨Support SIP v2(RFC3261, 3262, 3263, 3264)
¨Compliant with IETF SIP standards
¨Support up to 64 Subscribers
¨Support up to 20 concurrent calls
¨NAT support
b. SIP Trunk
¨Support up to 12 SIP Trunk registrations
¨Support Trunk dialing plan
¨DTMF support RFC2833/SIP information/inband
C. Management
¨Web configuration
¨HTTP firmware upgrade
¨User/admin two tiers password protection
¨Configuration file backup and recovery
D. Network Features
¨DHCP server and client support
¨NAT Setting
¨PPPoE support
¨Wireless
¨QOS
¨Firewall
¨SNMP-Client
Configuration Start WEB browser to Login Network setting DHCP Server Global Setting SIP Account Auto Attendant Duty/Off duty/Holidays SIP Server Functions of Extension SIP Clients (Extension) Dial Control Function code of Phone set IP Phone, Smart PhoneTable of Content:020303040709111213151617
About Jia Teng
Since its establishment in 2006, JiaTeng has adhered to the generous experience of developing software products and the
ability to integrate manufacturing process vertically. We are devoted to offering customers everything from innovative
designs to systematized manufacturing services. The business scope contains management information and billing systems
for telecommunication operators, mobile phones, wireless communication products, and networking products.
It is JiaTeng’s vision to become the strategic partner of the telecommunication operator. Under its great leadership and staff
efforts, JiaTeng has already become one of the important strategic partners within Asian-Pacific telecommunication
operations. Besides providing management information systems for telecommunication operators, JiaTeng also, in
accordance with the demand, supplies Feature Phone and Smart Phone in creating a great harvest for future networking
business.
USB
WPS /
5/# 5/#
.#0
9#075$
1. Please install WIFI Antenna first, and then connect with the power2. Plug ADSL Modem into WAN3. Connect your RJ 45 cable into LAN
&%2944'5'6 Start your browser to input http://192.168.100.1, then press “ENTER”.Input Account: admin Password: 123456
2UMOT -02-
-03-NETWORK SETTING DHCP SERVER
WAN Mode:There are 3 modes of WAN Mode: STATIC/DHCP/PPPoEPlease select your suitable mode according to ADSL dataWIN DNS:Please input the IP address of DNS according to ADSL data.If user has applied the SIP account of Telecom, please input the assigned IP address of Telecom.Finish all setting items, press SAVE putton.DHCP Server Switch:Enable & disable for DHCP Server Switch. Default is “Enable”. Please so not change to be “Disable”, otherwise user cannot login the system.Lan IP: Default for 192.168.100.1Netmask: Default for 255.255.255.0Please do not change or amend the setting, otherwise user cannot login the system.Finish all setting items, press SAVE putton.
-04-GLOBAL SETTING
Web Login Username: Web login Password: Web login Password (check): Input the Password again Number Length: There are 2 available choices (3 digits/4 digits) for Number Length of Extension. IP PBX password: Set the Password of IP PBXEXT '9' function: EXT '0' function:FUN_NULL: No FunctionSIP TRUNK: register the SIP Account to call outCO_GW: connect the PSTN interface of VoIP Gateway to call outDuty Auto Attend: There are 2 available choices Enable/ Disable for duty setting Default is Disable and adopt the greeting of On Duty AA.Change to be Enable will add the selection of Break Duty AA & Off Duty AA.according to the assigned time of duty time, it will automatically to select Greet of Auto Attend to operate the setting.Build-in: 3 items for greeting400 On Duty / 401 Break Duty / 402 Off DutyThere is another item without playing greeting, code: No IVR, ring directly to operator.To recode or amend the new message must use phone set. Here are the operations: Pick up the phone set and press *50#, then hear the reminding message: Input the password (default:1234)after input 1234, hear the reminding message: input the operator numberUser can add one new Greeting or amend the default one (ex 400)after input, hear the reminding message: record the Greeting when finished press #
E-mail notification: There are 4 items for setting to notice voice mail by E-mailE-Mail:E-Mail User Name:E-mail Password:SMTP Server: The IP address of Mail server.
Back up: Save the file of new settingSelect Make Backup File, then appear as the following picture Make Backup File Press Download to download the latest setting file, then appear as the following picture.
-05-GLOBAL SETTING NTP Setting: Time Server settingFinish all, press Save putton
-06-Select the restore file, then the system will appear as the followingpictureRestore: re-save the setting file of system
Reboot: restart deviceReset: back to the default ※ This setting will clear all current setting and back to default
Finish all and press Upload putton to send the setting file※ After Upload the setting file, please reboot manually to make the setting work.
-07-
SIP ACCOUNT This page can afford checking list of SIP account (Trunk).Uni Talk: 2 SIP account availableUni Talk plus: 4 SIP account available.Talk server Pro: 12 SIP account available.Number column: Register column: appear the SIP account or Telecom NumberMode column: appear the register modeGroup column:Select column:DELETE putton:
-08-
Edit SIP Account Answer Mode: 3 mode (ON / OFF / DID) ON Start up the line OFF Close the line DID Ring directly to the assigned extension. It will add To num: for assigned extension.Duty Auto Attend : 2 selections (Enable / Disable). Default is Disable.※ refer to the Duty Auto Attendant of GLOBAL SETTINGOn Duty AA: default is none.※ refer to the Duty Auto Attendant of GLOBAL SETTINGRegister ID:Register Username:Register Password:Authorise Name:Proxy Address:Server IP:Expire Time:DTMF Type:SIP ACCOUNT ※
Each SIP account can set the Auto Attendant and Greeting indi-vidually. Normal usages do not start any setting, otherwise it will imitate the
Duty Auto Attendant of GLOBAL SETTING
Finish all setting items, press SAVE putton.
-09-
AUTO ATTEND
Select AUTO ATTEND or press ADD to enter web page.
ADD
To add new code
DELETED
delete codeBuild-in: 3 items for greeting 400 On Duty / 401 Break Duty/ 402 Off DutyThere is another item without playing greeting, code: None IVR, ring directly to operator. None IVR: Without playing greeting400: On Duty401: Break Duty402: Off Duty
-10-Edit Auto Attend
Operator(1): point out will show all extensionsOperator(2): point out will show all extensionsOperator(3): point out will show all extensionsOperator(4): point out will show all extensionsOperator(5): point out will show all extensionsCall Waiting Times: default is 30 secondsDial Error Times: default 3 times for dial errorAnother four available selections:None / To Operator/ To Voice Mail/ To Auto AttendantNone CloseTo Operator directly to operatorTo Voice Mail enter into voice mail（※extra buying function）To Auto Attendant Enter greeting of AA to be greeting of layer 2'0' Function:'9' Function:'*' Function:Operator Ring Mode: 2 selections (Sequential / Round Robin)Seguential Each ringing start from Operator(1),jump to the next one if Operator(1) is busyRound Robin The first ringing for Operator(1), the second ringing for Operator(2), the third ringing for Operator(3), the fourth ringing for Operator(1).Jump to the next if Operator (1) is busy.Auto Attend Number: Set or amend greeting of Auto AttendantThere are 4 items for incoming call, the process after press phone set
Finish all setting items, press SAVE putton.
-11-
DUTY TIME The process for Duty Auto AttendWorking hours: On Duty AA The time Before Noon and the time After NoonNoon rest: Break Duty AA The interval of noon restAfter working Hours: Off Duty AA The time after working hours
Finish all setting items, press SAVE putton.
-12-
ႏཕྑ༽яخወ SIP SERVER Local Port: Assigned the port of SIP protocolThe registered number for SIP Client must use the same port.Register Expire: default for 300 secondRTP Port: Real-time Transport Protocol PortRFC2833 Payload type: RTP Payload for DTMF Digits, Telephony Tones and Telephony SignalsReference setting for Telecom SpecificationEx: FETnet use 97, this section must fill in 97.Be careful, the registered units must fill in 97, too.Default DTMF Type: 2 selections RFC2833 / SIP_INFO※ Must be compatible with Telecom specification.※ the registered units must use the same values. Default for RFC2833Codec Support: 3 selections for voice codec G.711 / G.723 / G.729※Must be compatible with Telecom specification.※the registered units must use the same values. Default for G.729.G711 Packets/Frame:default for 20default for 20default for 30G729 Packets/Frame:G723 Packets/Frame:※These values have been tuned, no need for amendment.
Finish all setting items, press SAVE putton.
-13-
EXTENSION NUMBER S_NO column: Point out the S_NO to enter the WEBNumber column: Show the extension numberTransfer mode column: Show the status of transferSelect column: Point out the square and select delete, then user can deleteADD putton:To add new extension, point out the ADD to enter the WEB.DELETE putton:Delete the extension once user points out at the Select column.Point out the number of S_NO column or press ADD to enter WEB page.Talk Server Pro: available for 64 extensionsUni-Talk: available for 8 extensions
-14-Edit Extension Number
S_NO: No need for amendmentNumber: set the extension numberUser Password: Set the password of extension, if phone command(*6#,*12#, *15#..,) is in process.Dial Group: Max for 3 groupsCall Control: the limit of extension4 selections: Unlimit / NoInternation / NoDomestic / NoOutlineUnlimit: without any control NoInternation: limit for internationalNoDomestic: limit for long distanceNoOutline: only for extension callNoInternation / NoDomestic: limit table for calling, must enter CALL CONTROLL page Transfer:Four available selections: no transfer / to v_mail / to user / to outsideNo transfer: default no transferto v_mail: extra buying functionsto user: transfer to other extensions, this selection will appear Transfer Number columnto outside: transfer to CO number, this selection will appear Transfer Number columnBusy Transfer: Transfer to other extensions if busy2 selections (Disable / Enable): default is DisableTransfer Number will appear when enable,fill in the transferred extension number.No Answer Transfer: Transfer to the other extension if no answer.2 selections (Disable / Enable): default is DisableRing Mode: Multi phone set to use the same extension for ringing2 selections (Ring All / Single User)Ring All: Ring all extensionsSingle User: only ring one VM On/Off: To set if the extension has the right to use voice mail.2 selections (Enable / Disable): Default is EnableTalk Time Limit On/Off: allow the limit time of Talking on extension or not.2 selections (Enable / Disable): Default is DisableTalk Time Limit: set the limit time of Talking on extensionFinish all and press SAVE putton to save the setting file.Press the LOG putton to check the talking records of extension.
