JLA M.2 User manual
1
USER MANUAL
1
ComponentsComponents
Cabinet
with drivers
and electronics
Grill
Cover
Metal
Base
24V Power
Adapter
How does the M.2 Audio system work?How does the M.2 Audio system work?
The M.2 requires an initial installation that allows it to
connect to your WiFi network. Once set up, the M.2 will
remain connected and will be available at any time to
anyone with access to your WiFi network.
The installation process for the M.2 requires that you
download and install the
AudioCast
app onto your
preferred digital device* to set up a WiFi connection
3
with the unit. The AudioCast app can be found on the
appstore, or by following the following QR code:
Once you have installed the Audiocast app, please
return to follow the M.2 set up instructions.
*For more information on AudioCast, please visit their website at:
www.audiocast.io.
Installation InstructionsInstallation Instructions
1. Connect the power adapter to the unit and then
to a power source.
2. Once connected, the Audiocast WiFi module will
make a sound and automatically begin outputing
and searching for a signal.
3. Open the AudioCast app and follow the set up
instructions.
The app will search for devices until it nds an Audiocast
signal and prompt you to pair your personal device. Make
sure that your personal device is connected to the same
WiFi as the M.2.
5
4. Name your M.2 unit in the Audiocast app.
This is important, as it will appear under that name on all of
your streaming services output options.
5. Your M.2 is now ready to stream music!
Anyone on your WiFi will be able to control the music from
their own device without having to do the initial set up.
6. If you have multiple M.2 units, you may send
dierent audio channels to each one from your
device.
To do this, open the AudioCast App, repeat steps 1-5 to
install each unit, then select the specic unit and direct a
specic channel as desired.
Controls & InterfaceControls & Interface
When it comes to buttons and cables, less is more.
Once installed, the M.2 detects when music is being
played from your personal device to automatically
turn on. Simply play a song and select the M.2 from
your devices’ speaker options to begin streaming.
No need to reach for a power button or pair your unit
every time!
Volume can be directly controlled from your phone,
but two touch-sensitive buttons on the unit provide
a simple way to directly control the volume for those
times when your phone is out of reach.
7
+ -
volume
24V Power
Safety Precautions & WarningsSafety Precautions & Warnings
The M.2 can be used as a side table and is designed to
hold small objects on top; however, it is not meant to be
used for personal support. Do not stand, sit, or place loads
heavier than 50lbs on the device. Avoid dropping or placing
the device on an uneven or potentially unstable location.
Do not carry the M.2 just from the legs as unit may come
apart.
Do not place the device in any other orientation from the
one indicated, failure to do so will reduce sound quality
and could damage the system. Do not block airow to the
metal grid. If any liquids are spilled on device, unplug and
clean thoroughly with a dry cloth to prevent permanent
damage to nish.
Do not operate any device with a damaged power cord or
plug. Keep the power cord away from high-trac areas
to avoid a tripping hazard. If the device is demonstrating
unwanted or unexpected behavior, unplug it and contact
JLA customer support.
9
Limited Warranty InformationLimited Warranty Information
JLA warrants that for a period of 1 year from shipment,
the Product will be free from defects in materials and
workmanship under normal use in accordance with
the documentation provided with the Product. In the
event of defect, visit JLA at www.jla.design/contact for
return instructions. The sole obligation of JLA under this
warranty is to at its option repair or replace the product.
The replaced product will be warranted for the remaining
period of the original warranty.
This warranty does not apply to Products damaged by
misuse, accident, electrical disturbance or normal wear
and tear. The product is not designed for or warranted
against damage from outdoor use or use in areas with
extreme temperature, excessive moisture, or other volatile
environments.
FCC StatementFCC Statement
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause hamful interference
2. This device must accept any interference received,
including interference that may cause undesired
operation. NOTE: This equipment has been tested and
found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules.
FCC Radiation Exposure StatementFCC Radiation Exposure Statement
This Equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment. This
equipment shold be installed and operated with minimum
distance 20cm between the radiator and your body.
Changes or modications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate equipment.
11
Help & SupportHelp & Support
We want to hear from you! If you love the system, if you
have any problems, or if you have any questions and would
like to learn more about any JLA products please reach
out to us via the customer support portal online. It can be
found at:
www.jla.design/contact
PLEASE READ AND SAVE THESE INSTRUCTIONS
© 2020 Jofre Lora Audio LLC.
All rights reserved.
