JoinTech JT707A User manual

1
JT707A E-seal Tracker
Shenzhen Joint Technology Co., Ltd

2
1. Application ....................................................................................................................................................................................... 3
2. Standard Introduced ........................................................................................................................................................................3
3. Product introduction ........................................................................................................................................................................ 3
3.1. Product and accessory ..........................................................................................................................................................3
4. Function Introduction....................................................................................................................................................................... 4
4.1. Remote Tracking of Device’s Status...................................................................................................................................... 4
4.2. Smart Working Mode ........................................................................................................................................................... 4
4.3. Status of Lock Rope .............................................................................................................................................................. 4
4.4. RED LED Status...................................................................................................................................................................... 4
4.5. Function &Performance ....................................................................................................................................................... 4
4.6. Working time ........................................................................................................................................................................ 5
5. Operation Device.............................................................................................................................................................................. 6
5.1 Recharge ................................................................................................................................................................................6
5.2 Device Configuration ............................................................................................................................................................. 7
5.2.1 PC tool to config device ............................................................................................................................................. 7
5.2.2 GPRS/SMS(Inserted Micro SIM Card) ........................................................................................................................ 9
5.3 Install Micro SIM Card ......................................................................................................................................................... 12
6. Environment Adaptation ................................................................................................................................................................ 14
7. Core parameters............................................................................................................................................................................. 15

3
1. Application
Guidance for internal techniques and customer support
2. StandardIntroduced
IEC60529/GB4208-2008 Housing Protection Level
3. Product Introduction
JT707A ,an Intelligent E-lock for mobile assets management solutions ,boasts the tiny size,easy installation
and low cost which supports GPS. Real-time tracking information for assets and remote changing of
product’s configuration are available. Coupled with rechargeable or disposable Li-ion battery, JT707 can be
re-used or one-time-used, which is a set of safe, intelligent and convenient solutions for mobile assets
management.
3.1. Product and Accessory
Include JT707A device:
(JT707A-Necessary)

4
4. FunctionIntroduction
4.1. Remote Tracking of Device’sStatus
Device’s status can be captured by means of real-time tracking, such as speed,direction,GPS location and
status of lock rope, which secures the shipping in a more efficient way.
4.2. Smart Working Mode
Device in sleep can be waken up by inserting or cutting rope. It would be convenient for clients to be kept
informed of assets’ location and other status by uploading real-time data, which enables them act
accordingly and secures the reliability in transit. Power-saving mode will be activated by default if the
device is disconnected for a long time.
4.3. Status of LockRope
Real-time Status of lock rope will be uploaded on user platform, following the GPS data as well.It would
be crystal clear for clients to be kept informed of the current assets status; The rope-cut will be counted
which enables a maximum use for clients.
4.4. RED LED Status
ON 500ms, OFF 500ms, means registered network successfully;
ON 100ms, OFF 100ms, means connected to server and sending data;
OFF always, means device in sleep mode.
4.5. Function&Performance
Locating
Ways
GPS,LBS
Data
Coordinates.Speed,Time,Direction
Data-collecting
Live Status
Lock rope, Motion,Location, Battery
Lock Status
Real-time counting of lock/unlock
Data Storage
Size
1000 data can be stored
System
Upload blind area data when available
Data
Communication
Ways
GSM
1. Inbuilt ESIM can support data only, can not support
SMS;
2. When deice work in sleep mode, can not use SMS
function;
Content
Live data, Blind area data,Alarms
Smart Wake-up
Fixed-time wake up or triggered by rope-cutting
Alarm
Alarm
Rope-cutting alarm

5
Low battery alarm
Battery
Battery
management
Recharge Li-ion battery, capacity 1500mAh;
Low battery management
Configuration
Configuration
USB PORT, GPRS
4.6. Continuous Working Period
No.
Upload Interval
GPS, GSM Signal Normal to Work
GPS, GSM Signal Poor to Work
1
30 Minutes/Per Data
16 Days
8 Days
2
4 Hours/Per Data
101 Days
55 Days
3
12 Hours/Per Data
200 Days
128 Days
4
24 Hours/Per Data
264 Days
193 Days
Battery Capacity: 1500mAh

6
5. Operation Device
5.1 Recharge
Put device on the “Config&Recharge BOX”, switch to recharge status, the “Config&Recharge BOX” the other
side connect to adapter, then red LED will be light.
Note: LED turn to green means full charged.
Note: When you are using adapter output 5V/1A, recharge to 90%, will spend 100 minutes, recharge to
100%, will spend 150 minutes.

7
5.2 Device Configuration
5.2.1 PC tool to configure device
Put device on the “Config&Recharge BOX”, switch to config status, the “Config&Recharge BOX” the other
side connect to computer, then green LED will be light.
Then install the config cable driver.

8
Check the cable driver and COM port status.
Running the PC tool to set device parameter

9
5.2.2 GPRS/SMS(Inserted Micro SIM Card)
5.2.2.1 To Query Terminal’s Basic Information
Send
commands
(700160818000,1,001,BASE,1)
Commands
descriptions
Query terminal version
Premise of
commands
no
Parameters
descriptions
no
Relevant
function
descriptions
Returns the following message：
1. Terminal version
2. Alias of terminal ID
3. GSM model version
4. SIM card’s CCID
5. IMEI of GSM model
6. GSM Internet information of community
Expectations
returns
(700160818000,1,001,BASE,1,1,20150418_G300,0,BeiHuan,1137B03SIM90
0M64_ST_MMS,
89860042191130000000,89860042191130272549,012207005620932,460,
00,4243,6877)
No.
example
description
1
20150418_G300
Current terminal version
2
0,BeiHuan
The 0 means English, while 1 means Unicode
of other languages.,”BeiHuan”is expressed by
ASCII code. For example, there are 8 bytes for
alarm(62A58B66). Here is English with the
name of”BeiHuan”.
3
1137B03SIM900M6
4_ST_MMS
GSM model version
4
8986004219113000
0000
ESIM ICCID
5
8986004219113027
2549
Micro SIM cardICCID, empty if no SIM card
6
012207005620932
IMEI of GSM model

1
0
5.2.2.2 To Set Query/Set Master &Slave IP address and port, APN, user-name and password
Send
commands
(700160818000,1,001,BASE,10,1,211.154.112.98,1088,211.154.112.99,108
8,CMNET,abc,123456)
Command
descriptions
Query/Set Master &Slave IP address and port, APN , user-name and
password
Premise of
commands
no
Command-
parameters
descriptions
To Set parameter：
1,211.154.112.98,1088,211.154.112.99,1088,CMNET,abc,123456
1 Function of commands：
0 means query ESIM parameters, the later parameters can be ignored，
eg：(700160818000,1,001,BASE,10,0)
2 means query Micro SIM card parameters, the later parameters can be
ignored，eg：(700160818000,1,001,BASE,10,2)
1 means setting ESIM parameters,
(700160818000,1,001,BASE,10,1,211.154.112.98,1088,211.154.112.99,108
8,CMNET,abc,123456)
Main IP, PORT: 211.154.112.98,1088
Backup IP, PORT: 211.154.112.99,1088
ESIM APN: CMNET
APN user: abc
APN password: 123456
3 means setting micro SIM card parameters,
(700160818000,1,001,BASE,10,3,211.154.112.98,1088,211.154.112.99,108
8,CMNET,abc,123456)
Main IP, PORT: 211.154.112.98,1088
Backup IP, PORT: 211.154.112.99,1088
Micro SIM card APN: CMNET
APN user: abc
APN password: 123456
7
460,00,4243,6877
Internet information：
460means Mobile Country Code (MCC)，it
represents China；
00 telecom operators network NO. （China
Mobile--00，China Unicom--01）；
4243 Base station NO.---cell ID information；
6877 Location Area Code ---LAC
information。
CELL ID and LAC is hexadecimal，which
means 4243 transform into 16963 by
decimal .
Feedback
descriptions
See above

1
1
Items can setbe null
If the backup IP & port no need to set, user-name and password will be the
following：
(700160818000,1,001,BASE,10,1,211.154.112.98,1088,,,CMNET,,)
211.154.112.98IP address: server address for uploading GPRS.
PS: The first IP is master IP and the latter is slave IP.
1088 port: No. Of server port ; PS: The first IP is master IP and the latter is
slave IP.
CMNET APN name: within 32 bytes
abc,123456 user-name and password: both within 20 bytes
Relevant
descriptions
of function
When setting master IP，it will immediately reconnect to newly set master
IP after terminal response
When master IP fails to connect, terminal will query if there is a IP setting
automatically; If detects ,it will connect slave IP.
Expectations
return
(700160818000,1,001,BASE,10,211.154.112.98,1088,211.154.112.98,1088,
CMNET,abc,123456)
Feedback
descriptions
feedback：
211.154.112.98,1088,211.154.112.98,1088,CMNET,abc,123456: .Same as
above
5.2.2.3 To Query/Set upload,Sleep, Periodic wake-up Interval
Send
commands
(700160818000,1,001,BASE,6,1,60,30,30)
Commands
descriptions
Query/Set upload ,sleep,periodic wake-up interval
Premise of
commands
no
Command-
parameters
description
Set parameter：1,60,30,30
1command function：0 means query; If it’s 0，the following can be
ignored，eg(700160818000,1,001,BASE,6,0)
1 means setting.
60--upload interval( Montion), unit by minute. For the upload contents,
please see”2.8positioning data” This value set 30minutes as default. The
minimum value is 30minutes and maximum 1440 minutes(12h).
30--Fixed as 30, reserved.
30--upload interval( Static), unit by minute. For the upload contents,
please see”2.8positioning data” This value set 30minutes as default. The
minimum value is 30minutes and maximum 1440 minutes(12h).
Relevant
descriptions of
function
no
Expectations
return
(700160818000,1,001,BASE,6,60,30)
Feedback
feedback：60,30:same as above setting

1
2
descriptions
5.3 Install Micro SIM Card
Remove the device top side cover.

1
3
Insert Micro SIM Card, then recover the top side cover.
Note: Device within Embedded-SIM, as below picture:

1
4
6. EnvironmentAdaptation
Low temperature type battery
Temperature: -40℃~55℃
High temperature type battery
Temperature: -20℃~75℃
Humidity
It can work for 48 hours under the testing of +50℃and 95% non-condensing humidity.
Impact
The device will be intact under the testing of half sine wave, 5G acceleration,pulse duration of 11ms by
impacting three times from each axis. The device functions well during and after testing.
Vibration
Scanning range:5Hz–300Hz. Scanning speed: 1oct／min
Scanning time: 30 minutes at each direction
Housing Protection grade
Housing of Intelligent device is compatible with the requirements of IP65 in GB/T4208-2008
Electromagnetic Compatibility
Immunity of ESD is compatible with the requirements of GB/T17626.2. With the testing grade of 7kv
accepted contact discharge and 14kv air discharge, grade B is judged. Immunity of radiation can meet the
requirements of GB/T17626.3. With filed strength of 24V/m and frequency of 20MHz–6000MHz, grade B is
judged.
Installation Compatibility
Ways: Locked by bolting and unlocked by rope-cutting

1
5
7. CoreParameters
Basic
parameters
Size
46mm*21mm*52mm
Length of Lock Rope
300mm, with unique ID for each rope
Weight
about 67g
Housing material
Nylon
Protection grade
IP67
Working Temperature
-10°C -- 45°C
Storage Temperature
-40°C -- +85°C
Relative Humidity
5%—95%
Working Current
Av. current<100mA
Standby ：<20uA
Battery Capacity
1500mAh,3.7v rechargeable Li-ion, 500 data upload
supported
GPS Antenna
Built-in
GSM Antenna
Built-in
SIM
Micro SIM Card

1
6
GSM
2G:
GSM 850MHz/900MHz,DSC1800MHz,PCS1900MHz。
Communication Mbps:
GPRS data downstream traffic: Max
85.6kpbs GPRS data upstream traffic: Max
85.6kpbs Coding format:
CS-1、CS-2、CS-3 and CS-4
Embedded protocol
TCP
GPS module
GPS and Beidou are both supported
GPS
Beidou
Sensitivity
Track -167dBm
Capture -
149dBm Re-
capture -161dBm
Cold start -148
dBm Hot start-
155dBm
Frequency
GPS L1
Frequency
(1575.42MHz)
BeiDouB1 (1561.10MHz)
Start
speed
Hot start <1s
Cold start
35s(typical
value)
Accuracy
<10 meters

1
7
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or
transmitter.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be installed and
operated with minimum distance between 20cm the radiator your body: Use only the supplied antenna.
