S E R V I C E
Spare parts
Ersatzteile
Pièces détachées
Reserve onderdelen
Repuestos
Reservdelar
Ersätter 106 xx xx-xx
I0600016
IPL, LM2153 CMD, 2006-01, 544 33 81-01
LM2153CMD
544 33 81-01
11
Replaces
Ersetzt
Remplace
Vervangt
Reemplaza
96141010100

402356 11.02.05 BY
ILLUSTRATED PARTS LIST
MODEL NUMBER LM2153CMD
PRODUCT NUMBER 961 41 01-01
MFG. ID. NUMBER 96141010100

2
ROTARY LAWN MOWER - - MODEL NUMBER LM2153CMD (96141010100) PRODUCT NUMBER 961 41 01-01

3
ROTARY LAWN MOWER - - MODEL NUMBER LM2153CMD (96141010100) PRODUCT NUMBER 961 41 01-01
KEY PART
NO. NO. DESCRIPTION
1 532 16 71-63 Handle, Upper, Deluxe Comfort
2 532 19 60-05 Handle, Lower
3 532 18 60-53 Spring, Rear Door, RH
4 532 19 47-88 Guide, Rope, Side
5 532 13 20-04 Nut, Hex, with Lockwasher Insert 1/4-20
6 532 06 64-26 Wire, Tie
7 532 19 15-74 Bolt, Handle 5/16-18 x 1.75
8 532 08 76-92 Knob, Handle
9 532 19 18-19 Bar, Control, Wire, Deluxe Comfort
10 532 18 88-21 Bolt, Carriage
11 873 93 05-00 Nut, Hex, with Lockwasher Insert 5/16-18 UNC
12 532 05 17-93 Cotter, Hairpin
13 532 18 60-52 Spring, Rear Door, LH
14 532 75 06-34 Screw, Tapping, Hex Washer Head #10-24
15 532 12 51-62 Bracket, Upstop
16 532 19 05-74 Rear Door Assembly
17 532 18 41-93 Bolt, Rear Door
18 532 19 81-70 Plug, Mulcher
19 532 40 07-32 Kit, Lawn Mower Housing Assembly
20 532 19 40-29 Handle Bracket Assembly, LH
21 532 19 40-31 Handle Bracket Assembly, RH
22 532 15 00-78 Screw, Hex Washer Head
23 532 16 31-83 Bolt, Hex Head 5/16-18 x 5/8
24 873 80 05-00 Nut, Hex, with Lockwasher Insert 5/16-18
25 532 16 13-33 Baffle, Side
KEY PART
NO. NO. DESCRIPTION
26 532 16 34-09 Screw #12 x 5/8
29 532 13 31-07 Cable, MZR
30 532 19 37-07 Adapter, Blade
31 532 19 93-77 Blade, 21"
32 532 85 10-74 Washer, Hardened
33 532 85 02-63 Lockwasher, Helical Spring 3/8
34 532 85 10-84 Screw, Hex Head 3/8-24 x 1.38
35 532 18 91-85 Shield, Debris
37 532 15 04-06 Bolt, Engine
38 - - - Engine, Briggs & Stratton, Model Number 128802
(Order parts from engine manufacturer)
39 532 40 20-19 Grassbag
40 532 19 46-44 Frame, Grassbag
41 532 18 21-66 Decal, Danger
42 532 05 45-83 Self-Tapping Screw
43 532 18 49-41 Pulley, Engine
44 532 18 77-23 Key, Hi-Pro
59 532 16 42-65 Grip, Handle, Foam, Smooth
60 532 18 21-54 Throttle Control
61 532 18 33-65 Screw
65 532 11 11-90 Cable Clamp
97 532 08 38-16 Screw
- - 532 18 21-34 Warning Decal
- - 532 40 23-51 Operator’s Manual, European
- - 532 40 23-52 Operator’s Manual, Scandinavian
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts. Failure to do so could be hazardous, damage your lawn mower and void your warranty.

4
ROTARY LAWN MOWER - - MODEL NUMBER LM2153CMD (96141010100) PRODUCT NUMBER 961 41 01-01

5
ROTARY LAWN MOWER - - MODEL NUMBER LM2153CMD (96141010100) PRODUCT NUMBER 961 41 01-01
KEY PART
NO. NO. DESCRIPTION
1 532 18 76-26 Cable, Drive
2 532 16 14-73 Bail, Control, Drive
3 532 16 45-57 Bracket, Downstop
4 532 75 06-34 Screw, Tapping, Hex Washer Head #10-24
5 532 40 28-07 Cover, Drive
6 532 75 06-34 Screw, Threaded, Rolled #10-25 x .50
7 532 16 08-16 V-Belt
8 532 13 20-10 Nut, Hex, Flangelock, Zinc Plated 3/8-16
9 532 16 39-39 Pulley, Driven
10 532 16 45-53 Belt Keeper
11 532 16 34-09 Screw, Hex Washer Head #10-24 x .668
12 532 18 76-27 Spring
13 532 18 82-95 Gearcase Assembly, Complete
14 532 14 53-54 Pin, Spring, Thrust
15 532 05 70-79 Washer, Hardened
16 532 16 15-84 Rod, Connecting
17 532 16 16-02 Spring, Extension
18 532 19 61-62 Spring, Selector
19 532 19 00-69 Knob, Selector Spring
20 812 00 00-22 E-Ring 7/8
21 532 16 33-65 Bearing, Support
22 532 16 99-11 Bearing, Ball
23 532 16 45-55 Retainer, Drive Assembly, Stamped
24 532 05 78-08 Screw, Tapping, Hex Head 1/4-20 x .75
25 532 17 00-11 Drive Pawl
26 532 16 64-50 Pinion, Drive
27 532 05 21-60 Washer, Shim (as required)
28 812 00 00-58 E-Ring 7/16
KEY PART
NO. NO. DESCRIPTION
29 532 18 94-03 Cover, Dust, Wheel
32 532 18 80-42 Wheel & Tire Assembly, Rear, Driven 9 x 2
33 532 08 39-23 Nut, Hex, Flangelock
34 532 18 06-26 Hubcap
35 532 19 60-16 Shaft Assembly, Rear
36 532 19 60-15 Shaft Assembly, Front
37 532 16 14-63 Retainer, Front Shaft
38 532 16 34-09 Screw #12 x 5/8
39 532 70 02-79 Clip, Retainer
40 532 15 03-48 Wheel & Tire Assembly, Front 8 x 2
42 532 18 81-52 O-Ring
43 532 08 83-48 Washer, Flat 3/8
44 532 06 23-35 Belleville Washer 1/2
45 532 06 77-25 Washer 1/2 x 1-1/2 x .134
46 819 57 22-16 Washer
47 532 08 81-18 Felt Washer
51 532 18 75-30 Case, Lower
52 532 19 12-45 Case, Upper
53 532 18 75-32 Gear, 24 Teeth
54 532 18 75-33 Shaft, Worm
55 532 18 35-05 Wireform
56 532 18 35-06 Bearing, Ball
57 532 18 35-08 Seal, Output Shaft
58 532 18 35-09 Washer
59 532 18 35-11 Bushing
60 532 19 12-48 Shaft, Output
61 532 18 35-13 Screw
62 532 18 35-14 Seal, Worm Shaft
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts. Failure to do so could be hazardous, damage your lawn mower and void your warranty.
