Josoo Electric Appliance ZS-A145N User manual
Zhongshan Josoo Electric Appliance Co., Ltd.
No.9, Qiye North Road, Maxin Industrial Zone, Huangpu Town , Zhongshan, GD, CN
Website: www.josoocooler.com Email: leah@josoo.com.cn
ZS-A145N Dry Aged Refrigerators
Instructions for use
Zhongshan Josoo Electric Appliance Co., Ltd.
No.9, Qiye North Road, Maxin Industrial Zone, Huangpu Town , Zhongshan, GD, CN
Website: www.josoocooler.com Email: leah@josoo.com.cn
Zhongshan Josoo Electrical Appliance Co.ltd
Thank you for purchasing the dry aged refrigerators products from Zhongshan City Palm Electric
Co.ltd
Please read this manual carefully so that you can use this product better
Installation and placement of the product
Temperature setting
Product maintenance and care
Troubleshooting
Precautions
Product Parameters
Zhongshan Josoo Electric Appliance Co., Ltd.
No.9, Qiye North Road, Maxin Industrial Zone, Huangpu Town , Zhongshan, GD, CN
1.The main structure of the product
1Box
2Glass door box
3Pull handle
4Stainless steel chrome-plated shelf
Zhongshan Josoo Electric Appliance Co., Ltd.
No.9, Qiye North Road, Maxin Industrial Zone, Huangpu Town , Zhongshan, GD, CN
5Stainless steel square plate
6Decorative frame
7Box feet
8Temperature controller face sticker
9Hook support frame
10 S-type hook
11 water tank
2.Installation and placement of products
1、Placement of dry aged refrigerators: dry aged refrigerators can be smoothly placed to any flat,
away from the ground of the heating appliances, but also can be embedded and installed into the
cabinet. Not be embedded in the installation, when the box is unstable, can be adjusted by adjusting
the box feet (twist the box feet, so that all four feet of the wine cabinet close to the ground) eventually
make the box smooth. When it needs to be embedded in the cabinet installation, the minimum
cabinet opening size is shown in the following figure.
Zhongshan Josoo Electric Appliance Co., Ltd.
No.9, Qiye North Road, Maxin Industrial Zone, Huangpu Town , Zhongshan, GD, CN
2、The function of each button of the control panel.
1 ） The temperature setting range is between 1-25 ℃ and the humidity setting range is between
60%-85%, it is recommended to set the temperature between 1-5 degrees and the humidity between
70-80%.
2）Introduction of each function of the control panel:
①Light on key: normal state, the box lighting is closed when off, open the door automatically lit. After
opening the door, this light key can control the box lighting off and on; open the door if the box
lighting is closed and then reopen the lighting, the lighting will remain on after closing the door will
not go out. Only after opening the door and closing the door again after closing the box lighting will
restore the initial closing the box lighting off, open the door automatically light up the function.
Press and hold the lamp key for 3 seconds to turn on the UVC sterilization lamp, at this time the left
digital screen ④ will show "ON" for about 1 second, representing the opening of the UVC
sterilization lamp, but only when the door is closed the UVC sterilization lamp will light up, and after
the door is opened the UVC lamp will automatically go out; if the UVC sterilization lamp is open, press
and hold the lamp key for 3 seconds to turn off the UVC sterilization lamp. At this time, the left digital
screen ④ will show: "OF" for about 1 second, which means the UVC sterilization lamp is closed. In the
off state, the lamp button is invalid.
Zhongshan Josoo Electric Appliance Co., Ltd.
No.9, Qiye North Road, Maxin Industrial Zone, Huangpu Town , Zhongshan, GD, CN
②Fahrenheit/Celsius temperature switching key: This key is used to switch the temperature display in
Celsius/Fahrenheit, and it is switched once per press.
③Temperature/humidity setting key: Temperature/humidity setting must be set by pressing this key
first. Press the temperature/humidity setting key once, the temperature display digital tube flashes,
indicating that the temperature can be changed by pressing the temperature setting up line or down
line key; press it again, the humidity display digital tube flashes (the temperature display digital tube
stops flashing), indicating that the humidity can be changed by pressing the humidity setting up line
or down line key; press this key again, the temperature/humidity display digital tube stops flashing
and resumes displaying the temperature and humidity respectively. The temperature and humidity
inside the box. When the temperature and humidity inside the box is set, without pressing any key, it
will automatically return to the state of displaying the temperature and humidity inside the box
respectively after 5 seconds.
④Temperature setting/display window in the box.
⑤Humidity setting/humidity display window.
⑥Set temperature / humidity up key: In the unlocked state, when the box temperature setting /
temperature display or the box humidity setting / humidity display is flashing, press this key to
change the set temperature / humidity in the box. Press once, the temperature/humidity rises 1
degree until the highest value of the temperature/humidity setting in the box.
⑦Set temperature/humidity down key: In the unlocked state, when the box temperature
setting/temperature display or the box humidity setting/humidity display is flashing, press this key to
change the set temperature/humidity in the box. Press once, the temperature / humidity down 1
Zhongshan Josoo Electric Appliance Co., Ltd.
No.9, Qiye North Road, Maxin Industrial Zone, Huangpu Town , Zhongshan, GD, CN
degree, until the box temperature / humidity set the minimum value.
⑧Power switch key: shutdown state, the display does not show. Press the power switch key, the
screen normally displays all parameters and the machine starts to work. When it needs to stop
working, long press the power switch key for 3 seconds to turn off the machine.
3） Power failure set temperature memory function: that is, the set temperature in the case of power
failure is still automatically saved, the next time the power is turned on to run the dry aged
refrigerators, its temperature setting value is still set temperature according to the last time the power
is turned off.
(4) automatic frost function: dry aged refrigerators has been designed to automate the frost function.
The purpose of the frost function is to regularly remove the frost remaining in the refrigeration system
(built-in, not visible when not disassembled) evaporator surface, thus ensuring that the refrigeration
system has been operating efficiently to obtain a good state of refrigeration. When the machine runs
for a period of time, the machine automatically into the frost state, at this time the dry aged
refrigerators compressor to stop running, while the box of refrigeration fan is continuously running.
Frosting, the box temperature will rise again, which is not a fault.
(5) open the door alarm function: the machine if the door is open for more than 1 minute will sound a
beep alarm to remind the door is in the open state.
3、The use of the water tank
Zhongshan Josoo Electric Appliance Co., Ltd.
No.9, Qiye North Road, Maxin Industrial Zone, Huangpu Town , Zhongshan, GD, CN
The water level in the tank should be kept above the middle water level line as much as possible, and
if the water level is low, it should be added in time, otherwise it will affect the humidity control in the
tank.
3. Attention..
1, the box outside the style grille is the dry aged refrigerators refrigeration system heat dissipation
channel, special attention should be paid to prevent items blocking heat dissipation, otherwise it will
cause the dry aged refrigerators overheating and cause accidents;.
2, the box refrigeration window and cold air circulation window in use to avoid blockage, otherwise it
will lead to the box temperature does not fall, the box temperature is not uniform and other abnormal
phenomena;.
3, pay attention to close the box door, long time not to close the door, will cause a decline in
refrigeration efficiency, box overflow, the temperature is not normal and other abnormal phenomena.
4, a long time not to use the dry aged refrigerators, should first completely shut down the power
supply, clean and open the box door for a period of time, so that the box as dry as possible.
4. Product maintenance and care
Tips.
1. After the power failure, the compressor's self-protection role need to wait 5 minutes before
restarting the refrigeration; otherwise the dry aged refrigerators can not run.
2. If you use the dry aged refrigerators for the first time or reuse after a long shutdown, you may set
the temperature and the temperature displayed in the dry aged refrigerators is not consistent, the
Zhongshan Josoo Electric Appliance Co., Ltd.
No.9, Qiye North Road, Maxin Industrial Zone, Huangpu Town , Zhongshan, GD, CN
temperature display will return to normal after the dry aged refrigerators runs for a period of time.
Clean the dry aged refrigerators (keep it clean, can prevent odor generation, can be done
according to the following steps.)
1. Cut off the power, use a clean soft cloth to clean the surface of the shelf and dry it immediately.
2. Do not use coarse brushes and rough abrasive cleaning jie to clean the inner lining of the dry aged
refrigerators, which will easily damage the surface of the inner lining.
3. Use a soft cloth with neutral cleaning agent or warm water to wipe the exterior of the dry aged
refrigerators, and then dry it with a clean soft cloth.
4. When cleaning the dry aged refrigerators accessories, you must unplug the power cord. Use a
sponge or soft cloth to wipe away the water vapor to prevent water or other liquids from seeping into
the wine cabinet accessories and causing electric shock.
Power outage
Most power outages are repaired within 1 to 2 hours and have little impact on the dry aged
refrigerators. However, during a power outage, you should try to minimize opening the dry aged
refrigerators door. If the power is out for a long time, beef should be taken out of the dry aged
refrigerators to prevent spoilage, or take other appropriate measures.
Decommissioning of dry aged refrigeratorss
If you decide to take the dry aged refrigerators out of service for a period of time, please follow these
steps.
1. first turn off and unplug the power supply.
2. remove all items from the dry aged refrigerators and clean it.
Zhongshan Josoo Electric Appliance Co., Ltd.
No.9, Qiye North Road, Maxin Industrial Zone, Huangpu Town , Zhongshan, GD, CN
3. Open the door slightly to avoid bad odors.
5.Common Troubleshooting
1. dry aged refrigerators does not run: not connected to the power supply or did not open the power
switch; circuit failure or fuse burned out.
2. dry aged refrigerators cooling effect is poor: check the temperature control settings; ambient
temperature is too high or poor ventilation; cabinet door open too many times; cabinet door is not
closed.
3. LED light is not bright: light switch is not on; circuit failure or fuse burned out.
4. dry aged refrigerators vibration: please ensure that the dry aged refrigerators is placed smoothly.
5. Too much noise: whether there are items behind the dry aged refrigerators resonating with the
cabinet; whether it is placed in an unstable or uneven place.
Note: If the dry aged refrigerators does not operate normally, in either case, to ensure safety, first
unplug the power supply before contacting the supplier.
6、Fault Code.
Troubleshooting
Fault
Code
Cause
Processing
E0
Temperature sensing head open circuit
Report a
repair
E1
Short circuit of temperature sensing head
E5
Communication failure
Zhongshan Josoo Electric Appliance Co., Ltd.
No.9, Qiye North Road, Maxin Industrial Zone, Huangpu Town , Zhongshan, GD, CN
Several non-failure phenomena
dry aged refrigerators surface condensation
Condensation is a natural phenomenon, dry aged refrigerators in the summer high temperature and
high humidity environment work, box shell and glass door body surface because of the low
temperature, the moisture in the air will be condensed in the box shell and glass door surface, touch a
wet feeling. Condensation phenomenon mainly occurs in the door seal, door body surface and other
parts. When the relative temperature of the air exceeds 80%, the glass door surface of the dry aged
refrigerators will appear beaded condensation, which is a normal phenomenon, condensation occurs,
you can use a soft cloth to wipe off the condensation, when the relative reduction in ambient
temperature condensation phenomenon will disappear naturally, will not affect the performance of
the dry aged refrigerators, in addition to reduce the phenomenon of condensation, please pay
attention to the following points when you use.
1. dry aged refrigerators in the summer rainy season, often use a soft cloth to wipe the surface of the
glass door and other condensation department, can reduce the phenomenon of condensation.
2, the dry aged refrigerators will be placed to the location of better ventilation, which can also reduce
the phenomenon of condensation.
dry aged refrigerators has "buzzing" vibration sound or like the sound of running water: 1.
1. dry aged refrigerators work, the compressor will occur a slight "buzzing" sound. If the dry aged
refrigerators is not placed smoothly, will also produce vibration and noise.
2. Refrigeration system refrigerant flow in the pipe like the sound of running water.
Zhongshan Josoo Electric Appliance Co., Ltd.
No.9, Qiye North Road, Maxin Industrial Zone, Huangpu Town , Zhongshan, GD, CN
If the above sound is a normal phenomenon
7. Technical parameters
①Net volume: 104L
②Power supply voltage: 220~240 V /50Hz
③Rated current: 0.7A
④Foaming agent: cyclopentane
⑤Refrigerant: R600a/28g
⑥Temperature range: 1-25℃
⑦Humidity range: 60-85%
⑧Product size (WxDxH): 595mm x 575mm x 820mm
