EN USER GUIDE
3
index
INTRODUCTION
1 LIMITATION OF LIABILITY
2 SAFETY INFORMATION
2.1 AC Adapter Requirement
2.2 Warning Volume Level Headphones and Earphones
2.3 Radio Equipment Directive (RED)
3 PACKAGE CONTENTS
4 DEVICE OVERVIEW
5 CHARGING YOUR DEVICE
5.1 Battery charge status
5.2 Saving battery power
6 TURN ON/OFF YOUR DEVICE
6.1 TurnONforthersttime
6.2 Turn OFF your device
6.3 Sleep mode
6.4 Waking up
7 OPERATIONS
7.1 Basic touchscreen operations
7.2 Stylus operations
7.3 Onscreen keyboard
7.4 Dictionary
8 HOME AND SETTINGS
8.1 Home screens
8.2 Status bar
8.3 Screen settings
9 WIRELESS NETWORKS AND DEVICES
9.1 WI-FI networks
9.2 Bluetooth devices
10 USB, HDMI AND MICRO SD CARD
10.1 Using the USB connector
10.2 USB OTG (On-The-Go) connection
10.3 Using HDMI devices
10.4 Connecting a Memory Card
11 LOCKING AND SECURITY
12 HELP AND TROUBLESHOOTING
12.1 Troubleshooting
12.2 Restoring your device
13 AGENCY REGULATORY NOTICES
13.1SpecicAbsorptionRate(SAR)CerticationInformation
13.2 Elimination of Private Equipment by Users in the European Union
EN USER GUIDE
4
BACK TO INDEX
INTRODUCTION
This User Manual applies to the MOVE S102 product.
Any information must be requested to:
JP Sá Couto, S.A.
Rua da Guarda, 675
4455-466Perata-Portugal
E-mail: [email protected]
Note:
Screen displays and illustrations may dier from those you see on the actual
product.jp.ikoersprofessionaleducationalproducts,eligibletobepurchased
byEducationalinstitutions,AdministrativeocesandBoardsofeducation,Public
libraries and Museums, to be used by administrators, teachers, or students in
school context.
1. LIMITATION OF LIABILITY
Despitereasonableeortsmadetoensuretheaccuracyofthismanual,the
manufacturer and distributor assume no liability resulting from errors or
omissions in this manual or the use of the information contained herein.
2. SAFETY INFORMATION
The battery[ies] in this product cannot be easily replaced by users themselves.
Caution:
• Failure to comply with safety warnings and regulations can cause property
damage, serious injury or death;
• Follow the warning and caution information to prevent injury to yourself or
others and to prevent damage to your device.
Make sure you comply with the following safety instructions:
• Care and use your device properly;
• Neverplacethedevicenearreorothersourcesofheat;
• Never place the device on or in heating appliances, such as microwave ovens,
stoves, or radiators. The device may explode when overheated. Follow all local
regulations when disposing of used devices;
• Do not leave the device plugged in or “on” when enclosed in a non-vented
container, such as school backpack, as overheating may occur;
• Do not place heavy objects that add heavy pressure on the device;
• Avoid exposing your device to very cold or very hot temperatures. Extreme
temperatures can damage the device and reduce the charging capacity and
the lifespan of your device;
• Do not store your device in very hot or very cold areas. It is recommended to
use your device at temperatures from 5 °C to 35 °C;
• Do not use your device or applications momentarily if the device is overheated;
• Do not use your device in a hospital, in an aircraft or in an automotive equipment
as it can be interfered with by radio frequency;
• Avoid using your device within a 15 cm range of a pacemaker, if possible,
as your device can interfere with the pacemaker. To minimize possible
interference with a pacemaker, use your device only on the side of your body
that is opposite the pacemaker;
• Turnothedeviceinpotentiallyexplosiveenvironments;
• Always comply with regulations, instructions and signs in potentially explosive
environments;
• To prevent eye strain, take frequent breaks while using the device;
• Do not use the device if it is cracked or broken;
• Broken glass or acrylic could cause injury to your hands;
• If bent or deformed, your device may be damaged or parts may malfunction;
• Donotdisassemble,modify,orrepairyourdevice.Anychangesormodications
to your device can void your warranty. If your device needs maintenance, take
it to an approved Service Center;
• Allowonlyqualiedpersonneltoserviceyourdevice;
• When cleaning your device, do not use chemicals or detergents. Doing so may
discolor or corrode the outside of the device or may result in electric shock or
re;
• Do not use the device for anything other than its intended use;
• Ifyourdevicehasacameraashorlight,donotuseitclosetotheeyesofpeople
orpets.Usingaashclosetotheeyesmaycausetemporarylossofvisionor
damagetotheeyes.Usecautionwhenexposedtoashinglights;
• Protect your personal data and prevent leakage or misuse of sensitive information;
• While using your device, be sure to back up important data. Our devices are
not responsible for the loss of any data;
• When disposing of your device, back up all data and then reset your device to
prevent misuse of your personal information;
• Carefully read the permissions screen when downloading applications. Be
particularly cautious with applications that have access to many functions or
to a signicant amount of your personal information;
• Checkyouraccountsregularlyforunapprovedorsuspicioususe.Ifyound
any sign of misuse of your personal information, contact your service provider
to delete or change your account information;
EN USER GUIDE
5
BACK TO INDEX
• In the event your device is lost or stolen, change the passwords on your accounts
to protect your personal information;
• Avoid using applications from unknown sources and lock your device with a
pattern, password, or PIN.
Do not distribute copyright-protected material without the permission of the
content owners. Doing this may violate copyright laws. The manufacturer is not
liable for any legal issues caused by the user’s illegal use of copyrighted material.
2.1 AC Adapter Requirement
The AC adapter should match the plug and voltage requirements for your local area.
Regulatory approval has been obtained using the AC adapter for the local area.
Never use a damaged charger, damaged power cords or loose electrical sockets.
Unsecuredconnectionscancauseelectricshockorre.
Do not touch the power cord with wet hands or disconnect the charger by pulling
the cord. Doing so may result in electrocution.
Connecting the charger improperly may cause serious damage to the device.
Any damage caused by misuse is not covered by the warranty.
Whilecharging,thedevicemayheatup.Thisisnormalandshouldnotaect
the device’s lifespan or performance. If the battery gets hotter than usual, the
charger may stop charging.
Use only approved chargers, batteries, and cables. Generic unapproved chargers
may shorten the life of your device or cause it to malfunction. They may also
resultinareorcausethebatterytoexplode.
When using unapproved accessories, batteries, or supplies, user's safety is not
guaranteed and is of his solely responsibility.
2.2 Warning Volume Level Headphones and Earphones
Listening to music at high volume levels and for extended periods of time can
damage hearing. To reduce the risk of hearing damage, lower the volume to a
safe and comfortable level as well as the amount of time listening at high levels.
For your own safety, before using headsets or earphones, always reset the
volume. The sound volume is louder on some headphones, although the volume
control settings are the same. Changing the default audio or equalizer settings
might lead to higher volume and should be done carefully. Exposure to loud
sounds while walking may distract your attention and cause an accident.
Do not use a headset while driving or riding. Doing so may distract your attention
and cause an accident or can be illegal depending on your region.
2.3 Radio Equipment Directive (RED)
EN Restricted to indoor use ES Limitado al uso en espacios interiores PT Limitado
a uso em espaços interiores
Caution:
• Frequency band(s) in which the radio equipment operates: 2.4GHz and 5GHz;
• Maximum radio-frequency power transmitted in the frequency band(s) in which
the radio equipment operates: 9.5dBm (at 2.4GHz) and 10.1dBm (at 5GHz).
3. PACKAGE CONTENTS
Carefully unpack your box and take out the items listed as below.
One tablet with a stylus
One USB cable
One universal USB adapter
Quick Guide
EN USER GUIDE
7
BACK TO INDEX
5. CHARGING YOUR DEVICE
Ifyouarechargingthedeviceforthersttime,itwilltakearound4to5hours
to be fully charged.
To charge your device:
1. Plug the adapter into the USB Type-C, which you
canndintheI/Ocabinetasshowninthegure;
2. Plug the adapter into a wall-socket.
Note:
Plugging the adapter with a remaining battery capacity above 90%, might prevent
the equipment from reaching its full charge.
• Connecting the charger improperly may cause damage to the device. Damages
caused by misuse are not covered by the warranty.
• The device can be used while it is charging, but the charging process may take longer.
• It is normal for the device to become warm during charging for long periods of use.
• Do not leave your device connected to the power supply once it is fully charged.
• Once it is fully charged, unplug the charger from the device, and then unplug it
from the electric supply. Use only accessories approved by jp.ik, like chargers,
batteries, and cables. Unapproved chargers or cables can damage the device
or the battery.
Only use the bundled power adapter. Unplug your device from the power supply
once it is fully charged. These devices are not designed to be left connected to the
power supply for long periods of time. Do not use the charger on other devices.
5.1 Battery charge status
To check the battery status, go to the battery status icon on the status bar. The
following icons represent the battery status of our devices:
Battery is fully charged.
Battery is starting to drain.
Battery is about to completely drain, and you should stop using your
device and charge it at once.
Battery is being charged.
5.2 Saving battery power
Our devices provide options that help you save battery power.
A battery is an expendable supply. Thus, when used over a long period, its capacity
is shortened. If the battery of your device is reduced to under a half of its initial
time, we recommend the purchase of a new battery.
When you don’t use the battery for a long time, you must store it after charging
(we recommend you to charge it at least until 30% or 40% of its capacity). This will
extend the battery life time of your device.
By customizing some options, you can use the device during longer periods of
time between charges:
• Close unnecessary applications;
• DeactivatetheBluetoothandtheWi-Ficonnectionifnotneeded-Toturno
the Bluetooth, open the "Quick Settings" panel. Here either switch on Airplane
modetodisableallwirelessconnections,orswitchoBluetoothandWi-Fito
disable the features;
• Deactivate auto-synchronization of applications like Gmail, Calendar, Contacts
andotherapplicationsifnotneeded-Toturnothesynchronization,openthe
Settings screen and click on the app you want to stop, for example, touch Google
or the Email app, under Accounts category. Then, in the right corner, touch the
menu button and select "Cancel sync" to suspend the auto-sync function;
• Decrease the brightness of your display - To do so, open the Quick Settings
Panel, locate the screen brightness icon and then drag the slider to the left to
reduce screen brightness, or open "Android settings" and touch on "Display-
Brightness level". Drag the slider to the left to reduce the screen brightness;
• Turnothescreenwhenthedeviceistemporarilynotinuse-Pressthepower
buttononcetoturnothescreen;
• Poweroyourdevicewhenisnotusedforawhile-Todothat,pressthepower
buttonuntilthePoweromenuisdisplayed,thentouchPowero;
• Use of the GPS feature - Many apps work to pinpoint your location, thus
consuming battery life. You can reduce the power consumption using the
Battery Saving GPS mode, minimizing the number of reference points used
tondyourlocation.Toenablethismode,headto"Settings">"Location">
"Mode", and enable "Battery Saving".
EN USER GUIDE
8
BACK TO INDEX
6. TURN ON/OFF YOUR DEVICE
If this is the rst time you turn on your device, connect the
charger and fully charge the battery.
To turn on your equipment, press the power button (normally
1 to 2 seconds) until the display is turned on.
6.1 Turn ON for the rst time
The tablet will require you to do the initial setup, which includes:
• Set up the system language and time;
• Signinto/orcreateyourGoogleaccount;
• Setup a wireless connection and more.
Please follow the above instruction to complete the initial setup.
6.2 Turn OFF your device
Beforeturningoyourdevicesaveallyourdata.Toturnoyourdevice,followthe
below steps:
• Press and hold the "Power lock" button;
• The"powero"conrmationmenuappears.Touchthemenutoturnothe
power (by touching anywhere else on the screen, you will continue using the
device);
• Yourdevicewillstartturningoitself.
6.3 Sleep mode
While away from your device it is recommended to put it into sleep mode. To
putyourdevicetosleep,pressthepowerbuttonbrieyonetime.
It is recommended to put your device in sleep mode when you want to move it.
6.4 Waking up
Towakeupyourdevice,pressthepowerbuttonbrieyonetime.
7. OPERATIONS
7.1 Basic touchscreen operations
• Your device is ideal for gestures use, or stylus pen use;
• Don’t use sharp objects to touch the screen, or the screen may be damaged or
scratched;
• Don’t touch the touchscreen with a conductive material. It may cause it to
malfunction;
• The supporting functions are application dependent.
Double-tap Slightlypresstwicewithyourngertoselectanitem.
Press and hold
Pressandleaveyourngeronanitem.Thisbringsup
detailed information or opens a menu with more options
for the item. This is similar to a right-click with the mouse.
Pinch
Movetwongerstogetherorapartwhiletouchingthe
screen. This is to zoom in and out on visual apps, such as
pictures and maps.
Rotate
Placetwoormorengersonanitemandthenturnyour
hand. This enables you to turn an object. (Note: Not all
items can be rotated, depending upon the app.)
Slide
Dragyourngeracrossthescreen.Thiscanscrollthrough
lists and pages, and can also move an object or be used
to draw or write, depending upon your apps.
EN USER GUIDE
9
BACK TO INDEX
7.2 Stylus operations
Your tablet comes with a stylus. Using it, you can perform all the
one-ngergestures–whicharetouching,double-touching,
and swiping described in the previous section.
7.3 Onscreen keyboard
The onscreen keyboard is a software keyboard displayed automatically anytime
you are required to type in some information. The software keyboard preinstalled
in your tablet is the Android keyboard.
Typing text, numbers, symbols, and other characters
Whenyouneedtotypetext,touchthetexteldtobringuptheonscreen
keyboard, then touch keys on the keyboard to type.
To close the onscreen keyboard, touch the down arrow icon from the
black bar under the keyboard.
To type numbers and symbols, touch the ?123 key to switch to
the numbers and symbols keyboard.
Touch the shift key to capitalize a letter. Double-tap the shift key
to capitalize all letters. By default, the auto-capitalization function
is enabled when you are typing English.
Using the onscreen keyboard in other languages
Toconguretheinputlanguage,dothefollowing:
• Open Settings screen and touch Language & input. All the input methods are
listed;
• Locate the input method you are using and touch the settings icon;
• Congurethelanguagesettings;
• Touch the back icon when you are done.
IfyouhaveconguredmultiplelanguagesfortheAndroidkeyboardinputmethod,
and want to switch to another language when you are typing text, do the following:
Touch the keyboard icon from the black bar under the keyboard to
bring up the input method selection dialog box. Then touch the desired
language from the box.
Editing text
For editing the text on the screen, you need to bring up an edit menu bar.
To bring up the menu bar, all only need to do is long-touch the text you want to
edit. Then the menu bar shows up at the top side of the screen, as shown below.
To cut or copy text, do the following:
Long-touch the word you want to use until the edit menu is displayed at the
top of the screen. The selected word is highlighted and two selection tabs are
displayed under the text.
Drag either selection tab to expand or reduce the range of the selected text. (If
you want to select all of the text, touch SELECT ALL from the edit menu.) Touch
CUT or COPY from the edit menu. The text is saved to the clipboard.
EN USER GUIDE
10
BACK TO INDEX
To paste text, do the following:
There are two ways to bring up the paste option.
• A quick touch at the position that you want to insert the text you have copied.
This brings up a tab pointing at the position - You can rearrange the position by
dragging the tab. Touch the tab again to bring out the paste menu, and touch
the menu to paste your copied text.
• Long touch the text you want to replace entirely or partially. This brings up both
the pop-up menu and the menu bar. Arrange the tabs to highlight the section
that you want to replace. Touch PASTE from the pop-up menu or menu bar to
paste the text.
7.4 Dictionary
Your device has dictionaries in many languages which are helpful when composing
messages and documents. The appropriate dictionary is activated automatically
when you touch a supported keyboard.
The active dictionary suggests corrections or completes the word while you
type. You do not need to interrupt your typing to accept the suggested word.
Accepting or rejecting dictionary suggestions
To accept a dictionary suggestion, touch the correct word when the dictionary
suggestionisdisplayed.Torejectadictionarysuggestion,nishtypingtheword
that you want, and then touch the space key.
Correcting a word using the dictionary suggested corrections
If you misspell a word, the word is underlined with a red line. Touch the misspelled
word and a list of suggested corrections is displayed. Touch the one that best
matches your word. The misspelled word is replaced.
You also can create your own dictionary by using the" Personal dictionary
function". To add a word to your dictionary, open "Android Settings" and touch
"Language & input" "Personal dictionary".
8. HOME AND SETTINGS
8.1 Home screens
Whenever you turn on and unlock your device, it displays the main Home screen
which looks like the one shown below.
1. Status bar:Displaysyourdevice’sstatusandnotications.
2. GoogleTM search: Search for information on the Internet.
3. All Apps: A navigation button. Tap on it when you want to open the All Apps
screen,inwhichyoucanndalltheappsinstalledinyourdevice.
4. Back: A navigation button. Tap on it when you want to go back to the previous screen.
5. Home: A navigation button. Tap on it when you want to go back to the Home screen.
6. Recent: Open a list of thumbnail images of applications you have launched recently.
To switch to an application, touch the thumbnail. To close an application, long-touch
the thumbnail to bring up the pop-up menu, and then touch Remove from list.
ThemainHomescreenisactuallythecentraloneoftheveHomescreens.
Touchablankareaonthescreenandslideyourngerleftorrighthorizontally
toscrolltotheotherHomescreens.YoucancustomizetheveHomescreens
to meet your personal preferences. For more information, see next sections.
EN USER GUIDE
11
BACK TO INDEX
8.2 Status bar
The status bar has two areas. The one on the
rightsideiscalledStatusarea,andontheleftsideisNoticationarea.Both
areas give a quick view and head up of your device status.
The status area gives you a quick view of the device status (including the wireless
connection and battery status) and system time.
Thenoticationareagivesyouaheadupofanynoticationsthatarepresent
byshowingtheiconsoftheapplicationsthatgeneratesuchnotications.
Expanding the status bar
Whenyoutouchanddragthestatusbardownwardarsttime,asummaryof
theexistingnoticationsisexpanded,asshownbelow:
Touchanoticationtoviewthedetailedinformation.
To clear the list, just touch on the icon on
the bottom right edge.
A second drag downward from the status
bar opens up the Quick Settings panel, which
displays several icons on it as shown below.
Here you can view and perform basic settings. If
you want to perform more detailed settings, just
touch the settings icon on the right side of the
battery icon on the upper right corner.
To close the Quick Settings panel, touch anywhere
else on the screen.
8.3 Screen settings
In Android, the system setup is done using an
application named “Settings”. This is the app to
open the Settings screen.
ThisistheiconoftheSettingsapp,andyoucannditintheAllApps
screen. To open the All Apps screen, touch the All Apps icon which you
canndintheHomescreen.
9. WIRELESS NETWORKS AND DEVICES
Your device can connect to a variety of networks and devices, including Wi-Fi
data networks and Bluetooth devices.
9.1 WI-FI networks
A Wi-Fi connection requires access to a functioning Wireless Access Point (WAP),
also called a hotspot. Some hotspots are open to the public, but some others
implementsecurityfeaturestolimitaccesstospecicgroupsorindividuals.
Connecting to a Wi-Fi network
To establish a Wi-Fi network connection, do the following:
• Open the Settings screen and set the Wi-Fi button
to ON. A list of available networks will be displayed;
• Touch a Wi-Fi network to connect to it. If
the network is secured, type the required
password or other credentials;
•Ifyouarerequiredtocongureproxysettings
when you are connecting to a Wi-Fi network,
do the following:
• Touch a network in the list of Wi-Fi networks
you've added. A dialog box appears;
• Touch to add a check mark on the option
“Advanced options”. If you don’t see this option,
the network does not request proxy settings;
• Enter the proxy settings required for your
network (you may need to refer to your
network administrator for details about
these settings.);
• Touch “Connect” (located on the low right corner).
Adding a WI-FI network
If you want to access a Wi-Fi network that does not broadcast its network name
(alsocalledaservicesetidentierorSSID),youmustaddthatWi-Finetwork
before you can connect to it.
EN USER GUIDE
12
BACK TO INDEX
To add a Wi-Fi network, touch this icon which you can be found in the
upper right corner of the screen.
This will open an options menu, and select “Add network” to open the dialog
box as shown below.
Type the required information for the network
and touch Save. By doing so, the information
about the network is saved. The Wi-Fi
connection will be established automatically
the next time you come within the range of
this network.
Disabling an automatic Wi-Fi connection
IfyoudonotwantthedevicetoautomaticallyconnecttoaspecicWi-Finetwork
thatyouhavepreviouslycongured,dothefollowingwiththeWi-Fiscreen:
• Switch the Wi-Fi button to ON if it is set
to OFF.
• Touch the name of the Wi-Fi network. The
Wi-Fi status panel appears.
• Touch Forget on the low left corner. The
details of the Wi-Fi network are erased.
9.2 Bluetooth devices
Bluetooth is a short-range wireless communication technology standard. It is
used to connect to a peripheral device, such as a keyboard, a mouse, a printer,
a headphone, a set of speakers, and so on.
Enabling and disabling the Bluetooth
To enable or disable the Bluetooth function, do either of the following:
• Open the Quick Settings panel and switch Bluetooth button to ON;
• Open the Settings screen and switch Bluetooth button to ON;
When enabled, the Bluetooth icon is displayed on the system bar.
WhenyouarenotusingBluetooth,turnitotoextendthebatterylife.
Opening Bluetooth screen
In the Settings screen, touch Bluetooth to open Bluetooth screen. The Bluetooth
screen shows your Bluetooth name and a list of available devices. In addition,
an icon appears in the upper right corner.
This is the menu icon. Touch it to show more setting options.
Changing your Bluetooth name
• Run the Settings app and turn on the Bluetooth button if it is disabled;
• Touch "Bluetooth";
• Touch the menu icon and touch "Rename the device";
• Type a new name, and then touch Rename.
Pairing with a Bluetooth device
To exchange data with another Bluetooth device, pair your device with the
Bluetooth device by doing the following:
• Open Android Settings and turn on Bluetooth
if it is disabled;
• A list of device IDs is displayed in the
column named “Available devices”;
• Touch the ID of the Bluetooth device you
want to pair with and follow the instructions
on both devices to pair them.
When the pairing is successful, the device
is listed under PAIRED DEVICES.
Unpairing a Bluetooth device
To unpair a Bluetooth device, do the following:
• Open the Settings screen and touch Bluetooth;
• Locate the paired Bluetooth device and touch the settings icon;
• Touch Unpair to erase all pairing information for that device.
EN USER GUIDE
13
BACK TO INDEX
10. USB, HDMI AND MICRO SD CARD
10.1 Using the USB connector
Using the attached USB cable, you can connect USB compatible devices to your
device.Readthissectiontolearnhowtousetheconnectortoconnectdierent
devices.
Share les with your Computer
Use the micro USB connector together with a USB cable to connect your device to
yourpersonalcomputertotransferles,orshareyourmobiledataconnection.
• Open the Setting screen, and touch Storage;
• Touch the menu icon on the upper right corner and select “USB computer
Connection”;
• Select either “Media device MTP” or “Camera (PTP)”;
• Connect your tablet to your device using a USB cable;
• Followtheinstructionsonyourcomputerscreentoshareles.
Yourdevicehandleslesbyputtingthemintotheirrespectivelyspeciedfolders.
Mostfrequentlyusedlesareasfollows:
Download - Storesthelesyouhavedownloaded;
DCIM - Stores the photos you have taken and videos you have recorded;
Music - Storesthemusiclesorganizedbyartistandthenbyalbumname.
10.2 USB OTG (On-The-Go) connection
The USB port on your device is a USB OTG port that allows your device to
become a host. In short, you can connect USB peripheral devices and those
devices serve your device.
To achieve this, you need to get a USB OTG (On-The-GO)
adapter, which may look like the item shown on the left. Such
adaptersareavailablefromthemarketinmanydierent
forms.
A USB OTG adapter is basically a female USB port that plugs
into the Micro-USB port on your device, and lets you connect devices to it that
use standard USB connections.
ThefollowingUSBdevicesaremostlikelysupportedbutarenotocial:
• Mouse and keyboards (some keys may not be supported);
• Cardreaders:SupportFAT16/FAT32formatted;
• USBdrivers:MustbeFAT16/FAT32formattedandself-powered.
10.3 Using HDMI devices
Your device has a micro HDMI connector that you can use to connect an external
display to provide video output.
First, connect a micro HDMI cable to your device then plug the other end of the
HDMI cable into a HDMI port on your TV or monitor. Usually, your device works
well with most of the HDMI monitors, and the HDMI device shows exactly the
same as you see on your device’s screen.
However, there is a possibility that there may still be issues as per the following:
Unmatched in resolution or aspect ratio
• Tap the option Modes;
• Scroll down to select a proper resolution setting.
Unmatched in scale
• Tap the option Scale Modes;
• Select your desired mode from the list.
Overscan (Edges of your image are o the HDMI screen)
• Tap the option Overscan Compensation;
• TaptoselectHorizontal/Vertical;
• Pressthezoomin/zoomoutbuttonstoscaleup/downyourimageinHorizontal/
Vertical direction.
10.4 Connecting a Memory Card
Your device supports microSD cards and you can insert your microSD card and
pull it out without powering down the device. To do so, follow the steps:
Install your MicroSD Card:
• Hold your device with front side up;
• Insert your microSD card in the direction as shown
in the image.
Remove your MicroSD Card:
• Push and release the microSD card. This will unlock
the card;
• Pull out the micro SD card.
EN USER GUIDE
14
BACK TO INDEX
11. LOCKING AND SECURITY
This chapter provides information about how to protect the information stored
on your device.
Screen lock mode
To protect your device data against unauthorized access, lock the screen and set
an unlock mode for unlocking the screen. To enable the screen unlock function
and set up a password, PIN, or a pattern to unlock the screen, do the following:
• Open the Settings screen;
• Touch and choose "Security" and, then, "Screen Lock". A screen called “Choose
screen Lock” appears, and you will see several options described as below:
None - The screen doesn’t lock. The main Home screen appears directly
whenever you turn on your device;
Swipe - This activates the sliding lock screen;
Pattern - This activates a pattern-tracing screen. You are required to trace
thepatterninaspecicordertounlockyourdevice;
PIN -Youarerequiredtotypeapersonalidenticationnumber(PIN)to
unlock your device;
Password - You are required to type a password to unlock your device.
• Follow the instructions to set your lock;
• Touch OK to save your setting;
• Make a note of your password, PIN, or pattern in case you forget it.
12. HELP AND TROUBLESHOOTING
12.1 Troubleshooting
This chapter describes some common problems and suggested solutions, and ways
to recover your device from a crash. Be aware that the problems and solutions
describedinthischapteraremeantonlyasaguide.Theyarenotdenitiveproblem
solving techniques. For certain problems, you might need help from your technical
service provider.
When you observe a problem, stop operation immediately, because taking further
action might result in data loss or damage. Take a note of what the system is
doing and what actions you performed before the problem occurred. Provide
detailed information to your service provider for quicker problem resolution.
For most problems, follow these steps:
• Restart your device;
• Check your Wi-Fi connection;
• Reset your Wi-Fi connection;
• Plug your device to a wall outlet to charge it for at least one hour.
My device won’t turn on or o.
Press and hold the Power button for about 4 seconds, the device will either turn
ooron.Ifitfails,waitforabout5minutesandrepeatstep1.
The battery won’t charge.
Check if the wall outlet is providing power.
Checkifyouradapterispluggedintoyourdevicermly.
The screen doesn’t rotate.
Not every app supports this feature. Go back to the Home screen to check if the
device responds and rotates the screen.
If it refuses to rotate, make sure the “Auto-rotate screen” item is not locked.
No sound coming from my device.
Iftheheadsetispluggedintothedevice,thespeakerisautomaticallyshuto.
Disconnect the headset. Check that the device volume setting is not muted.
Check that the volume control is not at its lowest setting.
I cannot view my picture les.
Ifthelesarephotostakenusingyourdevice,restartyourdevice.
Ifthelesarefromothersources,checkiftheyaredamaged.
If they are not damaged, try to convert them to a more widely supported format
such as JPEG.
I cannot play my video les.
Ifthelesarevideos,recordedusingyourdevice,restartyourdevice.
Ifthelesarefromothersources,checkiftheyaredamaged.
If they are not damaged, try to convert them to a more widely supported format
such as MP4.
I cannot play my audio (or music) les.
Ifthelesarerecordedusingyourdevice,restartyourdevice.
Ifthelesarefromothersources,checkiftheyaredamaged.
If they are not damaged, try to convert them to a more widely supported format
such as MP3.
EN USER GUIDE
15
BACK TO INDEX
I forgot my unlock pattern (or password).
If you have an active Google account on your device, the screen will prompt you
toconrmyourGoogleaccountafteryoufailtoenterthecorrectpatternor
password several times. Follow the instructions to reset the pattern or password.
If this is not the case, you can clean boot the device, which can restore your
device to default setting.
The device heats up when charging or operating for a long period.
It is normal for the device to heat up when charging. When charging is complete,
it will return to its normal temperature.
It is also normal for the device to heat up during long periods of use, such as
watching a video or playing a game.
Unable to connect to the wireless network.
Ensure that:
• You are within the network’s service range and the signal strength is good.
• Your device is not in Airplane mode.
If the problem still persists, contact technical support.
12.2 Restoring your device
When all else fails, you can reset all device software returning it to the factory
stateitwasin.Beforeyoustartthisoperation,considerndingatechnical
support from your resellers or suppliers:
• Start the Settings app;
• Choose “Backup & Reset”;
• Choose “Factory Data Reset”;
• Touch the “Reset device” button;
• Youmayneedtoenteryourunlockpatternorpasswordtoconrmyouroperation;
• All the information you’ve set or stored is deleted and removed. It includes
apps you’ve downloaded, music, synchronized accounts, etc.
13. AGENCY REGULATORY NOTICES
13.1 Specic Absorption Rate (SAR) Certication Information
THIS DEVICE MEETS INTERNATIONAL GUIDELINES FOR EXPOSURE TO RADIO WAVES
Your device is a radio transmitter and receiver. It is designed not to exceed
thelimitsforexposuretoradiowaves(radiofrequencyelectromagneticelds)
recommended by international guidelines.
Theguidelinesweredevelopedbyanindependentscienticorganization(ICNIRP)
and include a substantial safety margin designed to assure the safety of all
persons, regardless of age and health.
The radio wave exposure guidelines use a unit of measurement known as the
SpecicAbsorptionRate,orSAR.TheSARlimitsetbyFCCis1.6W/kg.TestsforSAR
are conducted using standard operating positions with the device transmitting
atitshighestcertiedpowerlevelinalltestedfrequencybands.
During use, the actual SAR values for this device are usually well below the
valuesstatedabove.Thisisbecause,forpurposesofsystemeciencyandto
minimize interference on the network, the operating power of your device is
automatically decreased when full power is not needed for the call. The lower
the power output of the device, the lower its SAR value.
Organizations such as the World Health Organization and the US Food and
Drug Administration have suggested that if people are concerned and want
to reduce their exposure, they could use a hands-free accessory to keep the
wireless device away from the head and body during use, or reduce the amount
of time spent using the device.
13.2 Elimination of Private Equipment by Users in the
European Union
This symbol on the product or on its packaging indicates that this product
must not be disposed of with other household waste. It is your responsibility
to dispose your used equipment at a collection point for recycling of electrical
and electronic equipment.The separate collection and recycling of disposed
equipment will help to conserve natural resources and ensure that the equipment
will be recycled adequately to protect human health and the environment.
Formoreinformationaboutthelocationswhereyoucandropoyourequipment
for recycling, please contact your local municipality, the local garbage collection
service or the point where you purchased the product.
ES MANUAL DEL USUARIO
17
VOLVER AL ÍNDICE
índice
INTRODUCCIÓN
1 LIMITACIÓN DE RESPONSABILIDAD
2 INFORMACION DE SEGURIDAD
2.1 Requisito de adaptador de CA
2.2 Nivel de volumen del auricular de advertencia
2.3 Directiva de equipos de radio (RED)
3 CONTENIDOS DEL PAQUETE
4 DESCRIPCIÓN GENERAL DEL DISPOSITIVO
5 CARGAR EL DISPOSITIVO
5.1 Estado de carga de la batería
5.2 Ahorro de energía de la batería
6 ENCIENDE / APAGA TU DISPOSITIVO
6.1 Encender por primera vez
6.2 Apagar su dispositivo
6.3 Modo de suspensión
6.4 Reactivar el dispositivo
7 OPERACIONES
7.1 Operaciones básicas de la pantalla táctil
7.2 Operaciones con lápiz
7.3 Teclado en pantalla
7.4 Diccionario
8 PANTALLA DE INICIO Y CONFIGURACIONES
8.1 Pantallas de Inicio
8.2 Barra de estado
8.3 Ajustes de pantalla
9 DISPOSITIVOS Y REDES INALÁMBRICAS
9.1 Redes WI-FI
9.2 Dispositivos bluetooth
10 TARJETA USB, HDMI Y MICRO SD
10.1 Usando el conector USB
10.2 Conexión USB OTG (On-The-Go)
10.3 Usando dispositivos HDMI
10.4 Conexión de una tarjeta de memoria
11 BLOQUEO Y SEGURIDAD
12 AYUDA Y SOLUCIÓN DE PROBLEMAS
12.1 Solución de problemas
12.2 Restaurar su dispositivo
13 AVISOS REGLAMENTARIOS DE LA AGENCIA
13.1InformacióndeCerticacióndelaTasadeAbsorciónEspecíca(SAR)
13.2Eliminación de Equipos Privados por parte de usuarios en la Unión Euro-
pea
18
18
18
19
19
19
19
20
21
21
21
22
22
22
22
22
22
22
23
23
24
24
24
25
25
25
25
26
27
27
27
27
27
28
28
28
29
30
30
30
ES MANUAL DEL USUARIO
18
VOLVER AL ÍNDICE
INTRODUCCIÓN
Este manual de usuario se aplica al equipo MOVE S102.
Cualquier información debe ser solicitada a:
JP Sá Couto, S.A.
Rua da Guarda, 675
4455-466Perata-Portugal
E-mail: [email protected]
Nota:
Las imágenes e ilustraciones de la pantalla pueden diferir de las que ve en el
producto.
jp.ik ofrece productos educativos para profesionales, elegibles para su compra
porinstitucioneseducativas,ocinasyayuntamientosescolares,bibliotecaspú-
blicas y museos. Estos productos son utilizados por administradores escolares,
profesores o estudiantes en el contexto educativo.
1. LIMITACIÓN DE RESPONSABILIDAD
Apesarde losesfuerzosrealizados paragarantizarla precisióndela información
contenida en este manual, el fabricante y el distribuidor no asumen ninguna
responsabilidad derivada de errores u omisiones en este manual o del uso de
la información contenida en él.
2. INFORMACION DE SEGURIDAD
Las baterías no pueden ser reemplazadas fácilmente por los propios usuarios.
Precaución:
• El incumplimiento de las advertencias y regulaciones de seguridad puede causar
daños a la propiedad, lesiones graves o la muerte;
• Siga la información de advertencia y precaución para evitar lesiones a usted
mismo o a otras personas y para evitar daños a su dispositivo.
Asegúrese de seguir las siguientes instrucciones de seguridad:
• Cuide su equipo y utilícelo correctamente;
• Nunca coloque el equipo cerca del fuego u otras fuentes de calor;
• Nunca coloque el equipo sobre o dentro de dispositivos de calefacción, como
hornos, microondas, estufas o radiadores. El dispositivo puede explotar si
se sobrecalienta. Siga todas las regulaciones locales para la eliminación de
dispositivos usados;
• No deje el dispositivo conectado o "encendido" cuando esté cerrado en un
entorno sin ventilación, como una mochila escolar, ya que puede producirse
un sobrecalentamiento;
• No coloque objetos pesados que ejercen una fuerte presión sobre el dispositivo;
• Evite exponer su dispositivo a temperaturas muy frías o muy calientes. Las
temperaturas extremas pueden dañar el equipo y reducir la capacidad de carga
y la vida útil de su dispositivo;
• No guarde el dispositivo en lugares muy calientes o fríos. Se recomienda utilizar
su equipo a temperaturas medias entre 5 ° C y 35 ° C;
• No use su dispositivo si está sobrecalentado;
• No utilice su dispositivo en un hospital, avión o equipo automotriz, ya que
puede haber interferencia de radiofrecuencia;
• Evite utilizar su dispositivo a menos de 15 cm de un marcapasos, ya que puede
interferir con su funcionamiento. Para minimizar la posible interferencia con
un marcapasos, use su dispositivo solo en el lado opuesto del cuerpo donde
se encuentra el marcapasos;
• Apague el dispositivo en entornos potencialmente explosivos;
• Siga siempre las reglamentaciones, instrucciones y señales en entornos
potencialmente explosivos;
• Para evitar la fatiga visual, tome descansos frecuentes mientras usa el dispositivo;
• No utilice el dispositivo si está rajado o roto;
• El vidrio o el acrílico roto pueden causar lesiones en las manos;
• Si se dobla o se coloca mal, el dispositivo puede dañarse y las piezas pueden
funcionar mal;
• No desmonte, modifique ni repare su dispositivo. Cualquier cambio o
modicaciónensudispositivopuedeanularlagarantía.Sisudispositivo
necesita mantenimiento, llévelo a un centro de servicio aprobado;
• Permitaquesolopersonalcalicadorealiceelmantenimientodesudispositivo;
• Cuando limpie su dispositivo, tenga en cuenta lo siguiente: no utilice productos
químicos ni detergentes. Si lo hace, puede decolorar o corroer el exterior del
dispositivo o puede provocar una descarga eléctrica o un incendio;
• Noutiliceeldispositivoparaningúnotronquenoseaelprevisto;
• Sisudispositivotieneunashounaluzparalacámara,nolousecercade
losojosdepersonasomascotas.Elusodeunashcercadelosojospuede
provocar una pérdida temporal de la visión o daños en los ojos. Tenga cuidado
cuando se exponga a luces intermitentes;
• Protejasusdatospersonalesyevitelaltraciónoelusoindebidodeinformación
condencial;
• Cuando utilice su dispositivo, asegúrese de hacer una copia de seguridad de
los datos importantes. Nuestros dispositivos no son responsables de la pérdida
de datos;
• Al deshacerse de su dispositivo, haga una copia de seguridad de todos los
datos y luego reinicie su dispositivo para evitar el uso indebido de su información
personal;
ES MANUAL DEL USUARIO
19
VOLVER AL ÍNDICE
• Lea atentamente la pantalla de permisos al descargar aplicaciones. Tenga
especial cuidado con las aplicaciones que tienen acceso a muchas funciones o
aunacantidadsignicativadesuinformaciónpersonal;
• Revise sus cuentas con regularidad para detectar usos sospechosos o no
aprobados. Si encuentra algún signo de uso indebido de su información
personal, comuníquese con su proveedor de servicios para eliminar o cambiar
la información de su cuenta;
• En caso de pérdida o robo de su dispositivo, cambie las contraseñas de sus
cuentas para proteger su información personal;
• Evite el uso de aplicaciones de fuentes desconocidas y bloquee su dispositivo
con un patrón, contraseña o PIN.
No distribuya material protegido por derechos de autor sin el permiso de los
propietarios del contenido. Esto puede violar las leyes de derechos de autor.
El fabricante no se hace responsable de los problemas legales causados por el
usuario por el uso ilegal de material protegido por derechos de autor.
2.1 Requisito de adaptador de CA
El adaptador de CA debe coincidir con los requisitos del enchufe y el voltaje de
alimentación de su región. Se obtuvo la aprobación reglamentaria utilizando el
adaptador de CA para el área local. Nunca use un cargador dañado, cables de
alimentación dañados o enchufes eléctricos sueltos. Las conexiones inseguras
pueden provocar descargas eléctricas o incendios.
No toque el cable de alimentación con las manos mojadas ni desconecte el cargador
tirando del cable. Esto puede resultar en electrocución.
La conexión incorrecta del cargador puede causar daños graves al dispositivo.
Cualquier daño causado por un uso inadecuado no está cubierto por la garantía.
Durante la carga, el dispositivo puede calentarse. Esto es normal y no debería
afectar la vida útil ni el rendimiento del dispositivo. Si la batería se calienta más
de lo normal, es posible que el cargador deje de cargarse.
Utilice únicamente cargadores, baterías y cables aprobados. Los cargadores
genéricos no aprobados pueden acortar la vida útil de su dispositivo o provocar
un mal funcionamiento. También pueden provocar un incendio o hacer que la
batería explote.
Al utilizar accesorios, baterías o suministros no aprobados, la seguridad del usuario
no está garantizada y es su exclusiva responsabilidad.
2.2 Advertencia del nivel de volumen del auricular
Escuchar música a altos niveles de volumen y durante largos períodos de tiempo
puede dañar su audición. Para reducir el riesgo de daño auditivo, baje el volumen
a un nivel seguro y cómodo, así como la cantidad de tiempo que escucha a niveles
altos. Por su seguridad, antes de usar auriculares o audífonos, siempre reajuste
el volumen. El volumen del sonido es más alto en algunos auriculares, aunque
laconguracióndelcontroldevolumeneslamisma.Cambiarlaconguración
predeterminada de audio o ecualizador puede aumentar el volumen y debe
hacerse con cuidado. La exposición a sonidos fuertes mientras camina puede
desviar su atención y provocar un accidente.
No utilice auriculares al conducir o montar en bicicleta. Esto puede desviar su
atención y provocar un accidente, o puede ser ilegal, según su región.
2.3 Directiva de equipos de radio (RED)
EN Restricted to indoor use ES Limitado al uso en espacios interiores PT Limitado
a uso em espaços interiores
Precaución:
• La (s) banda (s) de frecuencia en las que opera el equipo de radio: 2,4 GHz y 5 GHz;
• La potencia máxima de radiofrecuencia transmitida en la (s) banda (s) de
frecuencia en la que opera el equipo de radio: 9.5dBm (a 2,4 GHz) y 10.1dBm
(a 5 GHz).
3. CONTENIDOS DEL PAQUETE
Desembale con cuidado su caja y retire los elementos que se enumeran a
continuación.
ES MANUAL DEL USUARIO
20
VOLVER AL ÍNDICE
4. DESCRIPCIÓN GENERAL DEL DISPOSITIVO
Cámara frontal
Bloqueo de energía
Micrófono
Subir / bajar volumen
Sección de puertos I/O
Pantalla táctil
Soporte del lápiz
Lápiz
Altavoces
Puerto de acoplamiento
Puerto micro HDMI
Puerto de auriculares
Ranura para tarjeta micro SD
USB Type-C
Cámara trasera
Table of contents
Languages:
Other jp.ik Tablet manuals
