Jr. Pro DSX12 Manual


RADIO SETTING MANUAL

☆ Transmitter Setup For The JR DSX12
JR-CCPM plays a critical role in coordinating the simultaneous activating of multiple servos to contorl
the swashplate. Activation of just a single servo would not lead to control of the swashplate - the three
swashplate servos must be controlled in a coordinated fashion. The setup of these servos diers from that for
other control functions which control just one servo (for example, the throttle).
The initial settings given here must be conrmed on the bench, and then ne tuned after test ying the
helicopter. Prior to commencing this process, conrm all the trim levers and trim knowbs on the transmitter
are in their neutral (zero) positions. Also shift all switches to position”0” (switches moved away from the
operator).
Please also be familiar with the instructions for the transmitter. The initial settings can be entered into the
transmitter without turning power on to the receiver. Please note that ne adjustment will be needed after test
ying the helicopter.
1、Initializing the Radio
① Press (and hold) the 【ENT】key located on the
lower left of the Transmitter,then turn on the power
switch.
([System Mode List], List screen displayed)
② Turn the dial on the right side of the Transmitter to
select [84.Model SEL] and press.
③ Turn the dial to select [Model]and press.
④ Turn the dial to select the model number you want
to reset and press the dial again to settle it.
⑤ Use the 【LIST】key to return to”System Mode List”
⑥ Turn the dial to select[28.MDL Reset]and press.
⑦ Press the【CLR】key and press “YES” in the YES/
NO conrmation screen.
⑧ Press the【LIST】key to return to [Syetem Mode
List]
To switch[Select]and[Copy]press the dial alternately
Select[Model SEL]
①【ENT】+【ON】
Turn the dial to select
Select the model to be reset.
Press the function key to reset
⑦
⑦
⑤・⑧
②・③
④・⑥
P.2

2、Selecting the Swash Type
① Turn the dial to select [34.Swash TYPE] and press.
② Turn the dial to select [ 1 s e r v o N O R M ]
a n d p r e s s .
③ Turn the dial to select [3servos 120。]and press.
④ Press the【LIST】key to return to[SYSTEM Mode
List]
⑤ Press the【ENT】key twice to return to the regular
screen.
3、Setting the Swash Mix
① Press the【LIST】key on the regular screen.
(”Function List”is displayed)
② Turn the dial to select[65.Swash MIX]and press.
③ Conrm that「3servos 120。」is displayed. Now use
the dial to move to the item you want to alter.
④ Use the “+” and “-” keys to input the values shown
in the table below for AILE, ELEV and PIT.
(for the GSR260Z , select [+] in [PIT.] and press to
swith to [-]
⑤ After completing these settings press the【LIST】
key to return to[Function List]
CH-2(AILE) CH-3(ELEV) CH-6(PIT.)
+60
GSR260Z +60 -60
Select by using dial and pressing it
Turn the dial to select
Move to the item you want
to alter.
Select the model to be reset.
④
①・⑤
⑤
①・②・③
②・③・④
Change the value
by using the dial.
Press the dial to
switch between
「+」 and「-」
P.3

4、Setting the Servo Directions (Reverse Switches)
① Turn the dial to selct[11.REV. SW]and press.
② Select the reverse switch for each channel and
press the dial to set NORM or REV.
( Each time the dial is pressed, NORM and REV. are
alternately selected.)
③ After setting is completed for each channel, ues
the【LIST】 key to return to the [Function List].
※ Note the servo directions given are for JR servos.
Please confirm the directions carefully for your
chosen servos.
5、Setting the Travel Adjust Values
① Turn the dial to select[12.TRVL ADJ.]and
press.
② Turn the dial to select each item and press.
(Select L/R or U/D position by moving the
appropriate control in that direction)
③ Turn the dial and enter the values shown in the
table below and press.
④ Press the【LIST】key twice to return to regular
screen.
Setting for other kind of Radio set
※1 If you use a transmitter other than the JR DSX12 or PCM9X II, please refer to the manufactures
instruction manual.
※2 If using a Futaba transmitter, set the pitch value for Swash Mix about 10% lower than the
value in the table.
※3 Please refer to your tail gyro instruction manual for advise on tail rotor setup and initial transmitter
settings.
L・R
U・D はスティックで切換える
③
④
①・②
①・②・③
Diers depending on the gyro used
THRO CH-2(AILE)
H80%
L80%
GSR260Z
L100%
R100%
RUDD
L100%
R100%
GEAR
+100%
-100%
CH-6(PIT.)
H100%
L100%
CH-3(ELEV)
D100%
U100%
※「L( レフト )」側「R( ライト )」側等の切り替えは、各スティックで行います。
「RUDD」は使用するジャイロにより数値が異なります。サーボが最適なストロークになるよう、
数値を設定してください。
THRO CH-2(AILE)
ノーマル
GSR260Z リバース
RUDD
ノーマル
GEAR
ノーマル
CH-6(PIT.)
ノーマル
CH-3(ELEV)
リバース
※「RUDD」は使用するジャイロによってノーマル / リバースを切り替えます。

☆ Trasmitter Setup For The JR PCM9X Ⅱ
JR-CCPM plays a critical role in coordinating the simultaneous activating of multiple servos to control
the swashplate. Activation of just a single servo would not lead to control of the swashplate - the three
swashplate servos must be controlled in a coordinated fashion. The setup of these servos diers from that for
other control functions which control just one servo (for example, the throttle). The initial settings given here
must be conrmed on the bench, and then ne tuned after test ying the helicopter. Prior to commencing this
process, conrm all the trim levers and trim knobs on the transmitter are in their neutral (zero) positions. Also
shift all switches to position “0” (switches moved away from the operator). Please also be familiar with the
instructions for the trasmitter. The initial settings can be entered into the transmitter without turning power on
to the receiver.
Please note that ne adjustment will be needed after test ying the helicopter.
1、Initializing the Radio
① While pressing the【ENT】key (located at the lower
left of the transmitter), turn on the power switch.
(System setting mode,List screen displayed)
② Turn the dial on the right side of the transmitter
to select [Model SEL] and press the dial twice.
③ Turn the dial to select the model number you want
to reset, and press the dial again.
④【Press the【LIST】key to return to [SYSTEM M.].
⑤ Turn the dial to select [MDL Reset] and press.
⑥ Press the【CLR】key and press “YES” in the YES
/ NO conrmation screen.
2、Selecting the Swash Type
① Press the【LIST】key to return to「SYSTEM M.」
again.
② Turn the dial to select「SWASH TYP」and press.
③ Turn the dial again to select [3s120° ] and press.
④ Press the【LIST】key to return to「SYSTEM M.」
⑤ Press the【ENT】key twice to return to the regular
screen.
①「ENTER」+「ON」
②
・③・⑤
⑥
④
⑤
①・④
②・③
選択
P.5
Select the model to be reset

3、Setting the Swash Mix
① Press the【LIST】key to display “Function mode”.
② Turn the dial to select「Swash Mix」and press.
③ Conrm that「3servos 120。」is displayed. Use the
dial to move to the item you want to alter.
④ Use the「+」 or「-」key to input the values shown
in the
table below for AILE、ELEV、and PIT.
⑤ After setting press the【LIST】key to return to
“Function mode”.
4、Setting Servo Direction
① Turn the dial to select「REV.SW」and press.
② Select the reverse switch of each channel and
press the dial to set NORM/REV.
( Every time the dial is pressed,NORM and REV are
alternately selected.)
③ After setting is completed for each channel,press
the【LIST】key to return to the function mode.
①・⑤
②〜④
CH-2(AILE) CH-3(ELEV) CH-6(PIT.)
+60
GSR260Z +60 -60
①・②
③
THRO CH-2(AILE)
ノーマル
GSR260Z リバース
RUDD
ノーマル
GEAR
ノーマル
CH-6(PIT.)
ノーマル
CH-3(ELEV)
リバース
※「RUDD」は使用するジャイロによってノーマル / リバースを切り替えます。
P.6

5、Setting Travel Adjust Values
① Turn the dial to select「TRVL ADJ.」and press.
② Use the dial to select each item and press. Set each
to the value in the table below and press.
③ Press the【ENT】key to return to the regular
screen.
Setting for other kind of Radio set
※1 If you use a transmitter other than the JR X2610 or PCM9X II, please refer to the manufactures
instruction manual.
※2 If using a Futaba transmitter, set the pitch value for Swash Mix about 10% lower than the value
in the table.
※3 Please refer to your tail gyro instruction manual for advise on tail rotor setup and initial trasmitter
settings.
①・②
③
L・R
U・Dはスティック操作で切換える
CH-2 CH-6
CH-3
THRO CH-2(AILE)
H80%
L80%
GSR260Z
L100%
R100%
RUDD
L100%
R100%
GEAR
+100%
-100%
CH-6(PIT.)
H100%
L100%
CH-3(ELEV)
D100%
U100%
※「L( レフト )」側「R( ライト )」側等の切り替えは、各スティックで行います。
「RUDD」は使用するジャイロにより数値が異なります。サーボが最適なストロークになるよう、
数値を設定してください。
P.7

☆ FOR FUTABA Manufactured Transmitters
CCPM plays a critical role in coordinating the simultaneous activating of multiple servos to control the
swashplate. Activation of just a single servo would not lead to control of the swashplate - the three
swashplate servos must be contorolled in a coordinated fashion. The setup of these servos diers from
that for other control functions which control just one servo (for example, the throttle). The initial settings
given here must be confirmed on the bench, and then fine tuned after test flying the helicopter. Prior to
commencing this process, conrm all the trim levers and trim knobs on the transmitter are in their neutral (zero)
positions. Also shift all switches to position “0”(Switches moved away from the operator). Please also be
familiar with the instructions for the transmitter. The initial settings can be entered into the transmitter without
turning power on to the receiver. Also read the instruction manual for your transmitter. Please note that ne
adjustment will be needed after test ying the helicopter.
1、Selecting the Swash Type
See the instruction manual for your transmitter to select the swash type. Go to the TYPE setting screen in the
PARA setting screen to select “HELI SR-3” Note that is not HELI SN-3”.
2、Setting the Swash Plate Mix
Input the values in the table below for each item.
3、Setting Servo Reverse
Initilally, set the same values as for a JR made Radio set, then conrm.
4、Setting the Travel Adjust Values
Initially set the same values as for a JR made Radio set.
For the throttle and the rudder, values will depend on the engine and the gyro used.
Set values so that each servo will have the optimum travel.
5、Wiring
Make connections between the servos and the receiver as shown in the gure below.
7
4
3
2
1
C
9/B 9/B
8
6
5
・・・
・・・
・・・
・・・
・・・
・・・
・・・
・・・
・・・
・・・
Futaba
ch6へ
ch2へ
ch1へ
スワッシュサーボL
スワッシュサーボF
スワッシュサーボR
1Ch( エルロン ) 2Ch( エレベーター ) 6Ch( ピッチ )
+60
GSR260Z +60 -50
P.8
Swash Servo L
Swash Servo F
Swash Servo R

SRVSGYRO
TAILLOCKSYSTEM
HIGHSPEEDSERVOOUTPUT
SERVO
RUDD
SELECT
GAIN
SENSE
☆ Wiring Diagram for JR Radios
Conrm connections between the servos and the receiver as per the gure below.
The lead harnesses of the servos shown in the diagram are color coded simply for easy distinction.
When using other makes of Radio set refer to the instruction manual to conrm correct wiring.
ラダーサーボ
スワッシュサーボ F
スロットルサーボ
スワッシュサーボ Rスワッシュサーボ L
P.9
スワッシュサーボF
各サーボの受信機への接続
スワッシュサーボR
スワッシュサーボL
ELEV
AUX1
A
I
LE
ラダーサーボ
ジャイロ・その他のサーボの接続
ジャイロセンサー
RUDD(ジャイロアンプ )
SERVO(ジャイロアンプ)
SENSE(ジャイロアンプ)
RUDD
GAIN(ジャイロアンプ ) AUX2
SELECT(ジャイロアンプ ) GEAR
スロットルサーボ THRO
Gyro and Other Servo Connections
Rudder Servo output on Gyro)
Gyro sensor input on Gyro)
Throttle servo THRO
(out put on Receiver)
RUDD(input on Gyro) RUDD
(output on Receiver)
SELECT(input on Gyro) GEAR
(output on Receiver)
GAIN(input on Gyro) AUX2
(out put on Receiver)
Throttle Servo
Receiver
Gyro Sensor
Gyro
Rudder Servo
Swash Servo F
S w a s h S e r v o L S w a s h S e r v o R
Swash Servo F ELEV output on Receiver
Swash Servo R AUX1 output on Receiver
Swash Servo L AILE output on Receiver

MODELNO.
MODELNAME
260Z
CCPM
D/R
・
EXP
Pos0
D/R 80 80 80
80 80 80
EXP INH INH +40
INH INH +40
AILE ELEV RUDD
Pos1
D/R 80 80 80
80 80 80
EXP INH INH +40
INH INH +40
GYROSENS
(AUX2)
RUDDD/R
AUTO
INH
ST-1 Pos-0・Pos-1/Pos-2
ST-2 Pos-0・Pos-1/Pos-2
ST-3 Pos-0・Pos-1/Pos-2
ST-4 Pos-0・Pos-1/Pos-2
NORM Pos-0・Pos-1/Pos-2
Pos.0
Pos.1
84%
HOLD Pos-0・Pos-1/Pos-2
80%
Pos.2 %
AUTO
D/R ST-1 INH・POS-0・POS-1・POS-2
NORM INH・POS-0・POS-1・POS-2
REVERSESW NORM REV NORM
0 0 0
SUBTRIM
H80% L100% L100%
L80% R100% R100%
THRO AILE RUDD
TRAVELADJUST
F.S. HOLD HOLD
FAILSAFE(SPCM)
REV
0
D100%
U100%
ELEV
HOLD
NORM
0
+0%
-100%
GEAR
HOLD
NORM
0
H100%
L100%
PIT.
HOLD
NORM
0
+100%
-100%
AUX2
HOLD
NORM
0
+100%
-100%
AUX3
HOLD
NORM
0
+100%
-100%
AUX4
HOLD
SWASHMIX
TYPE
ELEV 60%
PIT. -60%
EXP INH・ACT
AILE 60%
1S・2s180
3s120°・3s140
3s90°・4s90
THRO
CURVE
OFF
NORM
OFF
EXP
0%
L
31.5%
1
INH
2
45%
3
INH
4
58.5%
5
100%
11% 34.5% INH 65% INH 88.5% 100%
H
ST1
PITCH
CURVE OFF
ST1
NORM OFF
20%
20%
51.5%
40%
INH
INH
67%
60%
INH
INH
80
INH
85%
85%
サーボ:DS8355 ジャイロ
ラダーサーボ
:G7000T
:8900G
共通項目
※スロットルのトラベルア
ジャストは実際のエンジンに
合わせて調整してください。
※A.D.T.( トリム ) は、実際
のフライトで調整してくださ
い。
※上記の数値はあくまでも目
安ですので、実際の組み立て、
フライトで微調整してくださ
い。
NORM
・
REV
NORM
・
REV
NORM
・
REV
NORM
・
REV
NORM
・
REV
NORM
・
REV
NORM
・
REV
NORM
・
REV
NORM
・
REV
NORM
・
REV
NORM
・
REV
NORM
・
REV
H
L
スロー
%
%
H
L
%
%
H
L
%
%
H
L
%
%
H
L
%
%
H
L
100
100
100
100
100
100
100
100
%
%
H
L
%
%
H
L
%
%
H
L
%
%
H
L
%
%
H
L
%
%
H
L
80
80
100
100
100
100
100
100
100
100
100
100
100
100
100
100
%
%
THRO
REVERSESW
SUBTRIM
TRAVELADJUST
FAILSAFE
CH-2 CH-3 RUDD GEAR CH-6
AILE ELEV RUDD
80 80 80
80 80 80
0 0 +40
0 0 +40
80 80 80
80 80 80
0 0 +40
0 0 +40
AUTO
NORM
SW
Pos0
Pos1
Pos2
Pos3
Pos4
AUX2 AUX3 AUX4 AUX5 AUX6 AUX7
D/R
POS0
Dual-Rate
・
EXP
EXP
D/R
POS1
EXP
NORM
ST-1
OFF・ON
IN
OUT
HOV.THRO
0
0
ー
OFF・ON
IN
OUT
HOV.THRO
0
11
ー
NORM
ST-1
OFF・ON
IN
OUT
HOV.THRO
0
20
ー
OFF・ON
IN
OUT
HOV.THRO
0
20
ー
100
100
ー
100
100
ー
100
85
ー
100
85
ー
15
33
ON・OFF
15
43
ON・OFF
15
43
ON・OFF
15
56
ON・OFF
85
58
ON・OFF
85
87
ON・OFF
85
77
ON・OFF
ON・OFF
ON・OFF ON・OFF
ON・OFF
85
80
ON・OFF ON・OFF
ON・OFF
ON・OFF
ON・OFF
ON・OFF
ON・OFF
ON・OFF
ON・OFF
ON・OFF
ON・OFF
ON・OFF
ON・OFF
EXP L123456H
THRO
Curve
PITCH
Curve
ST-1
SW
Pos0
Pos1
Pos2
Pos3
Pos4
TYPE
AILE
ELEV
PITCH
%
%
%
+60
+60
-60
ON・OFFEXP
ELEV→PIT.CACELLER INH・( )
AILE→ELEV
ELEV→AILE
L:
R:
%
%
R:
U:
%
%
SWSELECT NORM・ST-1・ST-2・ST-3・ST-4・HOLD
1S・2S180°・3S120°・3S140°・3S90°・4S90°
SWASH
MIX
GAIN
Pos2/ST-2
AILED/R
・
ELEVD/R
・
RUDDD/R
・
FMODSW
・
AUTO
TYPE
Pos0/NORM
Pos1/ST-1
NORMAL・T.LOCK NORMAL・T.LOCK
%
N・T N・T
%
%
84
80
100
100
N・T N・T
%
%
N・T N・T
%
Channel
GEAR AUX2
Gyro
SENS
DATA SHEET N o r m a l :Payload 0 kg
S t u n t 1:Payload 4 Kg
http://www.jrpropo.co.jp/
NOTE
※Alter the travel adjust for
the throttle servo to suit the
engine actually used.
※Adjust the A.D.T.( t r i m )
during ight.
※The values in the table are
standard settings. Confirm
them on the bench and make
fine adjustments after test
ying the helicopter.
Servo
MODEL NO.1
MODEL NAME JR GSR260Z CCPM
Slow
Gyro
RUDD Servo
This manual suits for next models
1
Table of contents
Popular Remote Control manuals by other brands

Carrera
Carrera EVOLUTION 2.4 GHz WIRELESS+ Assembly and operating instructions

MZ electronic
MZ electronic HC300 Instructions for use

Rotel
Rotel RHB-200 Connecting and operating instructions

LEGRAND
LEGRAND MKFOB v2 installation instructions

Remote Control Systems
Remote Control Systems EVO-BATT instruction manual

Arlight
Arlight SR-2833K8 Product data

E-fly
E-fly 100C operating manual

Rockford Fosgate
Rockford Fosgate PUNCH Level Control Remote Install

Tascam
Tascam RC-898 owner's manual

Vetus
Vetus REMCO1 Operation manual and installation instructions

Power-Pole
Power-Pole CM-KF-adv-PP Programming instructions

Strand Lighting
Strand Lighting 63022VN Installation & operation guide
