JUMPBOX BIGRIG PRO 16L User manual

OWNER’S MANUAL
Professional Jumpstarter
Pantone 802C
www.starkpower.com
Customer service at 800-587-9940
[e-mail]
Stark Power, Inc.
P.O. Box 2588, Davidson, NC 28036

Thank You
Thank You for choosing Stark Power.
The JumpBox BIGRIG PRO 16L is a
professional, portable jumpstarting
solution.
Performance and safety are paramount
in this revolutionary product. Our goal
is to provide the ultimate jumpstarting
and charging device that gives freedom
and security to drivers. We understand
that in the transportation industry,
delays are costly. We designed the
BIGRIG PRO 16L to reduce delays and
keep you on the road. Thank you again
for choosing StarkPower.
You will never be stranded again™
“Stark Power is working to enhance current and future lithium-ion battery
technology to reduce the present limitations and in doing so, oer products
to consumers that outperform and are safer than those currently on the
market” ~Martin Koebler
01

BIGRIG PRO 16L Manual
Table of Contents
Page 1. Introduction
Page 2. Important Notes
Page 3. General Information
Page 4. Charging Information
Page 5. What’s inside
Page 6. Technical Specications
and Features
Page 7 Panel & LED Display
Page 8. Jumpstarting Guide
Page 9. Warranty
Page 10 Product Warnings
Page 11. Quickstart Guide
Page 15 Notes

02
•FULLY CHARGE THE UNIT BEFORE FIRST USE
(18V 110-240VAC Wall charger ~6 hours / 12V DC charger ~8 hours)
• Please read the entire instruction manual before operating the JumpBox BIGRIG PRO 16L. Save these instructions.Review all
cautionary markings on this product and in this manual.
• The BIGRIG PRO 16L is designed to start large diesel trucks up to 16L in a variety of conditions. There are variables such
as extreme outdoor temperatures and truck mechanical issues (bad starter, no fuel or engine problems) that may limit the
BIGRIG’s ability to start an engine. The BIGRIG is designed to instantaneously start a truck battery in a low voltage condition
(5V and up). The BIGRIG PRO 16L is equipped with a “Hyperboost” energy transfer feature to assist in starting, but is not
designed to be used primarily as an energy transfer device (i.e. Lead acid jump cart). Please feel free to call us or your local
representative if you have questions about operating the BIGRIG PRO 16L.
• To activate the 12V(16V Peak) DC Aux power ports (Cigarette Charging Ports), hold the output on/off function button until
the unit beeps and the LED display shows “16V”.
• Your BIGRIG PRO 16L is tted with built-in safety protections. These safety protections monitor and control the unit. To
ensure product longevity, activation is limited to 30 second intervals. During this 30 second period the unit is performing
a “Hyperboost” function, transferring large amounts of energy from the BIGRIG PRO 16L to your vehicles batteries. If you
experience the unit timing out during a jumpstart, simply cycle the main On/Off rocker switch to reactivate the jumpstart
“Hyperboost” function.
Important Notes
Need Assistance? Please contact customer service at 800-587-9940
or starkpower.com

BIGRIG PRO 16L Manual
Pantone 802C
Power wherever the road takes you!

03
What can BIGRIG do?
The JumpBox BIGRIG PRO 16L is
engineered to jumpstart the largest 12V
diesel engines on the road, up to 16 liter.
This device can also be used on smaller
12V gasoline or diesel vehicles.
Powering your computer or electronics
is a breeze with the large capacity 236.8
Wh lithium-ion battery. You can charge
all your devices through the USB, 3.5mm
ports or the DC Aux (cigarette) ports. Most
mobile phones, smart phones, laptops,
portable gaming devices, MP3/MP4
players and even CPAP machines can be
charged with the included accessories.
Don’t worry about dead batteries again
when you have a JumpBox BIGRIG PRO
16L.
Charges Most Phones, Tablets and Laptops
Designed Specically for 12V 16 Liter Big Rig Trucks
But Works with Most 12V Gasoline or Diesel Powered Vehicles
Note: BIGRIG can be used with 12V construction equipment as well.

BIGRIG PRO 16L Manual
Vehicle jumpstarting
The BIGRIG PRO 16L jumpstarts diesel
and gasoline powered engines up to 16.0
liters.Whether driving your Big Rig or the
family 4 cylinder car, the BIGRIG PRO
16L has you covered. See the Complete
jumpstarting guide on page 7 for more
details.
“ Never be stranded again™”
Electronics charging
Turn the MAIN ON/OFF switch to the “ON”
position. For charging electronics like smart
phones through the USB port, simply insert
your OEM cord or utilize the 3-in-1 USB
cable provided. For powering CPAP machines,
please utilize the DC auxiliary port by holding
the function button to activate 16V on LCD.
Please check with your CPAP manufacturer to
conrm settings and runtimes.
Laptop charging
Turn the MAIN ON/OFF switch to the
“ON” position. Insert the 40cm adapter
cable into the 5.5 mm round output port
(19V or 12V depending upon your laptop
settings). Then attach the corresponding
8-in-1 tting for your laptop.

04
Pantone 802C
Power for your accessories on the go!
38x
camera
Charges
24x
BT speaker
Charges
312x
smart watch
Charges
21x
Cell phone
charges
5x
Laptop
charges
6x
Tablet
charges
15x
E-Book Reader
charges
121x
Music Player
Charges

BIGRIG PRO 16L Manual
Power when you need it
BIGRIG PRO 16L can charge a:
Smart Watch with a 205 mAh battery 312 times
Music Player with a 525 mAh battery 121 times
Camera with a 1650 mAh battery 38 times
Wireless Bluetooth Speaker with a 2600 mAh battery 24 times
Cell Phone with a 3000 mAh battery 21 times
E-Book Reader with a 4750 mAh battery 15 times
Tablet with a 10307 mAh battery 6 times
Laptop with a 42Wh battery 5 times
Need Assistance? Please contact customer service at 800-587-9940
or starkpower.com

Laptop Adapter Safety Strap 3 in 1 Mobile
Adapter
05
What’s inside
The BIGRIG PRO 16L is equipped with
everything you need to safely operate
and charge your unit at work,home and
on the road. The connectors required
to charge most phones, electronic
accessories and laptops are included.
An 18V 100-240VAC wall charger and
an 18V DC Cigarette port charger are
provided to charge your unit.
A safety strap is also included to help
protect the unit and the operator. The
BIGRIG PRO 16L is a professional piece
of equipment and should always be
secured to your vehicle when in use.
The BIGRIG 16L carrying case helps
keep all your accessories in one place
and protect your investment when not
in use.
18V 100-240 VAC
Wall Charger
12V Car
Charger
Carrying Case

BIGRIG PRO 16L Manual
Safety strap
The BIGRIG PRO 16L is a professional
grade jumpstarter. The unit should be
secured to the vehicle with the supplied
safety strap before use. Also follow the
manufacturers safety precautions when
working with your vehicle’s batteries.
Charging accessories
The BIGRIG PRO 16L is equipped with
an 18V 100-240VAC Power Wall Charger
and a 18V DC Aux power port charger
(Cigarette Port) for optimal charging
convenience at home,work or on the road.
When your BIGRIG PRO 16L is charged,
you will not only be secure in your ability
to jumpstart your vehicle, but you can put
its 236.8 Watt-hours to work charging
many of your electronic accessories.
Powering options
The BIGRIG PRO 16L is equipped with
two USB ports and a high quality braided
3-in-1 USB to lightning, USB-C, or Micro
USB connectors; offering exibility for
most phones or tablets.An 8 tip computer
connection kit is also included to power
most laptops. Additional standard USB
powered accessories can also be used.
(not included)

06
Technical specications
Unit Dimensions: 10.93” (H) X 4.33” (W) X10.78” (L)
277.6mm (H) X 110mm (W) X 274mm (L)
Unit Weight: 11.15 lbs (5060 grams)
Battery type: Lithium Ion Cobalt
Capacity: 236.8 Watt-hours (236,800 mWh)
Peak Current: 3000A (<2ms)
Output voltage: 12V-16V
Output Ports: Jumper cables - integrated
(2) USB - 5V 2.1A
(2) 12V DC Aux port - 10A
(1) 12V 5.5mm port 3.5A
(1) 19V 5.5mm port: 3.5A
Input Charging Ports: 3.5mm - 18V 2A
Operating temp:15F to +110F (-9C to +43C)
Estimated lifetime jumpstarts: up to 5000 starts
A/C Recharging - 18V 100-240 VAC Wall charger ~6 hours
12V DC charger ~8 hours
1. 12V DC Aux power
2. Main ON/Off Switch
3. LED Display
4. 12V DC Aux power
5. Output ports On/off
6. 19V/3.5A output
7. USB ports - 5V/2.1A
8. 12V/3.5A output
9. AC charging port 18V/2A for
18V 100-240 VAC Wall charger
10. LED ON/Off (Cycle for High>Low>
SOS modes)
11. LED work light
JumpBox features

BIGRIG PRO 16L Manual
10
1 2 3 4
5 6 7 8 9 11

07
JumpBox control panel
2X - 12V (16V Max) DC Port
Cigarette lighter port for 12 Volt accessories.
(16V Max) Press and hold the OUTPUT ON/
OFF button until it beeps and the “16V”
indicator lights on the LED display.
18V 100-240VAC AC charging Port
Use the 18V 100-240VAC Wall charger
to charge your BIGRIG PRO 16L.
Main On/Off Switch
Illuminates when the unit is on
Note: The LED display and ON/OFF switch
will timeout after 5 minutes. To reactivate,
toggle the MAIN ON/OFF switch and
depress the OUTPUT ON/OFF switch.
2x - USB ports
Use these ports to operate or charge 5V
USB Accessories, 2.1A Maximum.
19V Output
Use the included 8 tip adapter set
to power 19V computers.
12V Output
Use this port to operate or
charge 12V accessories.

BIGRIG PRO 16L Manual
JumpBox LED display
100 12V
%
16V
5V
IN
19V
2.1A
OUT
Percentage
Charged
AC Aux Out
Activated
Power
output
Charging
Flashes
2.1 12V 16V
5V
IN
19V
2.1A
OUT
USB amperes
drawn
2.1A maximum
A
USB Power
output
blue when off
Green when active
Note: USB amperes only shows for 2 seconds before the LED display returns
to displaying the percentage of charge.
Press and hold the OUTPUT
ON/OFF button until it beeps and
the “16V” indicator lights on the
LED display to activate the 12V
(16V Max) cigarette lighter ports.
Displays the BIGRIG PRO 16L’s
percentage charge except when
a USB port is rst used and the
USB amperes draw is displayed.
The USB amperes drawn displays
for 2 seconds whenever an
accessory is attached to either
of the USB ports. The USB ports
combined maximum load is 2.1
Amperes.
The “5V 2.1A” goes from blue to
green whenever a USB port is
used to charge or power a USB
accessory using one or both of
the USB ports.
The “IN” indicator ashes
whenever the unit is being
charged by the 18V 100-240VAC
wall charger or the 12V cigarette
port charger.
Displays “OUT” when you are
using the unit to power an
accessory via the cigarette lighter
ports, 12V or 19V ports.

08
1. Personal safety & Battery preparation
A. Please use safety glasses when jumpstarting any vehicle. Remove
personal metal items such as watches, rings and bracelets when working
with a lead-acid battery. It may cause personal injury.
B. Please refer to your vehicle’s owners manual for proper jumpstart
connection location.
C. Identify the positive (RED) and negative (BLACK) terminals before
connecting the clamps. Make sure battery terminals are clean and free of
debris for safe connection.
2 .BIGRIG PRO 16L preparation
A. Secure the BIGRIG PRO 16L by inserting the safety strap through
the handle and securely attaching it to the vehicle using the included
carabinier clip.
B. Place the BIGRIG PRO 16L on a at surface and turn the MAIN ON/OFF
to the ON position, ensuring that the BIGRIG PRO 16L has at least a 50%
charge.
Complete jumpstarting guide

BIGRIG PRO 16L Manual
3. Make the Connection
A. Disconnect the Red clamp and the Black clamp from the BIGRIG PRO 16L
docking station. Note: LCD should be ashing red and green “8”s (search for
battery mode)
B. Use the jump port if you vehicle is so equipped,otherwise connections will
be made on the battery.
C Connect the positive red clamps to the positive(+) red terminal on the
battery and connect the negative(-) black clamps to the black terminal. Once
the battery is detected and is connected correctly, then the LED indicator will
show a green “8”.
4. Start the Vehicle
A. Ensure a proper connection. If properly connected, the unit will display a
green “8” on the LED. If the LED displays a red “8” then there is an error that
needs to be addressed. Please see the “Troubleshooting Guide” and the “LED
Indicators guide” in the QUICK START Manual.
B. Turn the ignition key to the on position and start the engine.
C. Once started, turn off the unit and disconnect the clamps from the battery
and reattach the clamps to the docking station and turn off the unit.

One year warranty
Period of Coverage: This product is warranted to the original purchaser from the original purchase date for one (1) year and is subject
to the Warranty Coverage described herein. Registration is required for warranty coverage. Registration can be found on our website
at: www.starkpower.com.
Warranty Coverage: This product is warranted by StarkPower, Inc. to be free from defects in material and workmanship.
This Limited Warranty does not cover defects or damage due to: accidents, acts of God, misuse, abuse, abnormal use, abnormal
conditions, alternation of to the product, attachment to any unauthorized accessory; improper use of an electrical power supply that
causes malfunction; loss of power; dropped or crushed product; tampering with or attempt to modify the product; unauthorized
opening of the product; transportation damage; theft, vandalism, loss of use during the period the product is at a repair facility
or otherwise awaiting parts or repair; Failure to operate this product in accordance with the instructions provided in this Owners’
Manual supplied with this product.
DISCLAIMER: No warranty, written or oral, other than the above warranty is valid with regard to this product. Manufacturer shall not
in any way be liable to the purchaser or any third party for any damages the purchaser or any third party may suffer as a result of use,
intended or unintended or misuse of this product in conjunction with any device, equipment or accessory other than the appropriate
device or equipment for which the product is designed.
09
Limited Warranty

BIGRIG PRO 16L Manual
Customer Commitment
At StarkPower, we are committed to offering you the best value in the marketplace. If you have any questions or concerns, do not
hesitate to contact us.
If you need repair service please contact us via phone or our website to make arrangements.
Once you have a return authorization, please return product for warranty service to Stark Power Inc.
Contact us at www.starkpower.com, [e-mail] or 800-587-9940 for return authorization number (RMA #) and further
instructions.
www.starkpower.com
Customer service at 800-587-9940
[e-mail]
Stark Power, Inc.
P.O. Box 2588
Davidson, NC 28036

Read the entire manual before attempting to use this product.
1. Keep out of reach of children.
2. Do not damage, drop or crush this product. Do not attempt to use this product if it has been dropped, punctured, run over or
damaged in any way including damage to the clamp or cables.
3. Do not insert foreign objects (including ngers and metal objects) into any input or output ports on the BIGRIG. This item may
short circuit causing personal injury or re.
4. Do not expose unit to rain or snow. Do not charge this item in wet conditions.
5. Do not use this product in explosive environments (dust, bilge, gaseous fumes or ammable materials) or in the presence of
ammable materials such as carpeting, paper, cardboard or upholstery etc.
6. Do not burn or incinerate this product.
7. Use only recommended attachments. Use of attachments NOT sold by Stark Power or included with the BIGRIG may result in a risk
of re, electric shock or injury to persons or damage property.
8 Do not disassemble this product. Refer servicing to qualied service professional when service or repair is required. Failing to
adhere to this may result in risk of re or electric shock.
9. Never charge a frozen battery.
10. Store BIGRIG in a cool dry location and do not expose the unit to temperatures over +140F or below -4F.
11. The BIGRIG is not designed to be used in place of a vehicle battery.
12. If the unit needs to be disposed of for any reason. Please dispose properly by calling your nearest lithium battery recycle facility
at 1-800-8-BATTERY.
13. If the product malfunctions or is having problems, discontinue use and contact stark power at
800-587-9940, our website www.starkpower.com or via email at [e-mail]
10
WARNINGS
