JUNO JBD167D2 User manual

JBD167D2
User Manual
EN
Steam oven

CONTENTS
Safety information 2
Safety instructions 4
Product description 7
Control panel 8
Before first use 10
Daily use 11
Clock functions 14
Automatic programmes 16
Using the accessories 17
Additional functions 20
Hints and tips 22
Care and cleaning 44
Troubleshooting 50
Energy efficiency 53
Environmental concerns 54
Subject to change without notice.
VISIT OUR WEBSITE TO:
Get usage advice, brochures, trouble shooter, service and repair
information:
www.juno.de/support
SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damage that are the result of
incorrect installation or usage. Always keep the instructions
in a safe and accessible location for future reference.
Children and vulnerable people safety
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved. Children of less than 8 years of age and
persons with very extensive and complex disabilities shall
be kept away from the appliance unless continuously
supervised.
•Children should be supervised to ensure that they do not
play with the appliance.
•Keep all packaging away from children and dispose of it
appropriately.
2

•WARNING: The appliance and its accessible parts
become hot during use. Keep children and pets away from
the appliance when in use and when cooling down.
•If the appliance has a child safety device, it should be
activated.
•Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
General Safety
•This appliance is for cooking purposes only.
•This appliance is designed for single household domestic
use in an indoor environment.
•This appliance may be used in, offices, hotel guest rooms,
bed & breakfast guest rooms, farm guest houses and other
similar accommodation where such use does not exceed
(average) domestic usage levels.
•Only a qualified person must install this appliance and
replace the cable.
•Do not use the appliance before installing it in the built-in
structure.
•Disconnect the appliance from the power supply before
carrying out any maintenance.
•If the supply cord is damaged, it must be replaced by the
manufacturer, its Authorised Service Centre or similarly
qualified persons to avoid an electrical hazard.
•WARNING: Ensure that the appliance is switched off
before replacing the lamp to avoid the possibility of electric
shock.
•WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements or the surface of the appliance
cavity.
•Always use oven gloves to remove or insert accessories or
ovenware.
•Use only the food sensor (core temperature sensor)
recommended for this appliance.
3

•To remove the shelf supports first pull the front of the shelf
support and then the rear end away from the side walls.
Install the shelf supports in the opposite sequence.
•Do not use a steam cleaner to clean the appliance.
•Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door since they can scratch the
surface, which may result in shattering of the glass.
SAFETY INSTRUCTIONS
Installation
WARNING! Only a qualified
person must install this
appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not pull the appliance by the handle.
• Install the appliance in a safe and
suitable place that meets installation
requirements.
• Keep the minimum distance from other
appliances and units.
• Before mounting the appliance, check if
the appliance door opens without
restraint. If not the appliance has to be
lifted.
• The appliance is equipped with an
electric cooling system. It must be
operated with the electric power supply.
• The built-in unit must meet the stability
requirements of DIN 68930.
Cabinet minimum
height (Cabinet un‐
der the worktop mini‐
mum height)
600 (600) mm
Cabinet width 550 mm
Cabinet depth 605 (580) mm
Height of the front of
the appliance
594 mm
Height of the back of
the appliance
576 mm
Width of the front of
the appliance
549 mm
Width of the back of
the appliance
548 mm
Depth of the appli‐
ance
567 mm
Built in depth of the
appliance
546 mm
Depth with open
door
1017 mm
Ventilation opening
minimum size. Open‐
ing placed on the
bottom rear side
550 x 20 mm
Mains supply cable
length. Cable is
placed in the right
corner of the back
side
1500 mm
Mounting screws 4 x 12 mm
Electrical connection
WARNING! Risk of fire and
electric shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
4

• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable.
Should the mains cable need to be
replaced, this must be carried out by
our Authorised Service Centre.
• Do not let mains cables touch or come
near the appliance door or the niche
below the appliance, especially when it
operates or the door is hot.
• The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have an
isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation device
must have a contact opening width of
minimum 3 mm.
• This appliance is supplied with a main
plug and a main cable.
Use
WARNING! Risk of injury,
burns and electric shock or
explosion.
• Do not change the specification of this
appliance.
• Make sure that the ventilation openings
are not blocked.
• Do not let the appliance stay
unattended during operation.
• Deactivate the appliance after each
use.
• Be careful when you open the
appliance door while the appliance is in
operation. Hot air can release.
• Do not operate the appliance with wet
hands or when it has contact with
water.
• Do not apply pressure on the open
door.
• Do not use the appliance as a work
surface or as a storage surface.
• Open the appliance door carefully. The
use of ingredients with alcohol can
cause a mixture of alcohol and air.
• Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
• Do not put flammable products or items
that are wet with flammable products
in, near or on the appliance.
WARNING! Risk of damage to
the appliance.
• To prevent damage or discoloration to
the enamel:
– do not put ovenware or other
objects in the appliance directly on
the bottom.
– do not put aluminium foil directly on
the bottom of cavity of the
appliance.
– do not put water directly into the hot
appliance.
– do not keep moist dishes and food
in the appliance after you finish the
cooking.
– be careful when you remove or
install the accessories.
• Discoloration of the enamel or stainless
steel has no effect on the performance
of the appliance.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
• Always cook with the appliance door
closed.
5

• If the appliance is installed behind a
furniture panel (e.g. a door) make sure
the door is never closed when the
appliance operates. Heat and moisture
can build up behind a closed furniture
panel and cause subsequent damage
to the appliance, the housing unit or the
floor. Do not close the furniture panel
until the appliance has cooled down
completely after use.
Care and cleaning
WARNING! Risk of injury, fire,
or damage to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• Make sure the appliance is cold. There
is the risk that the glass panels can
break.
• Replace immediately the door glass
panels when they are damaged.
Contact the Authorised Service Centre.
• Be careful when you remove the door
from the appliance. The door is heavy!
• Clean regularly the appliance to
prevent the deterioration of the surface
material.
• Clean the appliance with a moist soft
cloth. Use only neutral detergents. Do
not use abrasive products, abrasive
cleaning pads, solvents or metal
objects.
• If you use an oven spray, follow the
safety instructions on its packaging.
Steam Cooking
WARNING! Risk of burns and
damage to the appliance.
• Released Steam can cause burns:
– Be careful when you open the
appliance door when the function is
activated. Steam can release.
– Open the appliance door with care
after the steam cooking operation.
Internal lighting
WARNING! Risk of electric
shock.
• Concerning the lamp(s) inside this
product and spare part lamps sold
separately: These lamps are intended
to withstand extreme physical
conditions in household appliances,
such as temperature, vibration,
humidity, or are intended to signal
information about the operational status
of the appliance. They are not intended
to be used in other applications and are
not suitable for household room
illumination.
• This product contains a light source of
energy efficiency class G.
• Use only lamps with the same
specifications.
Service
• To repair the appliance contact the
Authorised Service Centre.
• Use original spare parts only.
Disposal
WARNING! Risk of injury or
suffocation.
• Contact your municipal authority for
information on how to dispose of the
appliance.
• Disconnect the appliance from the
mains supply.
• Cut off the mains electrical cable close
to the appliance and dispose of it.
• Remove the door catch to prevent
children or pets from becoming trapped
in the appliance.
6

PRODUCT DESCRIPTION
General overview
21
10
9
5
4
3
2
1
5
4
6
7
8
3
1Control panel
2Electronic programmer
3Water drawer
4Socket for the food sensor
5Heating element
6Lamp
7Fan
8Descaling pipe outlet
9Shelf support, removable
10 Shelf positions
Accessories
Wire shelf
For cookware, cake tins, roasts.
Baking tray
For cakes and biscuits.
Grill- / Roasting pan
To bake and roast or as a pan to collect
fat.
Food Sensor
To measure the temperature inside food.
7

CONTROL PANEL
Electronic programmer
21 3 4 5 6 7 8 9 10
Use the sensor fields to operate the oven.
Sensor
Field
Function Description
1- Display Shows the current settings of the oven.
2ON / OFF To turn the oven on and off.
3Options To set a heating function or an automatic pro‐
gramme.
4
My Favourite Pro‐
gramme
To store your favourite programme. Use it to
have access to your favourite programme directly
or when the oven is off.
5
Temperature /
Fast Heat Up
To set or check the temperature.
Also to set or check the temperature of Food
Sensor.
Press and hold it for three seconds to turn on and
off the function: Fast Heat Up.
6
Up, Down To move up or down in the menu.
7OK To confirm a selection or setting.
8Oven Light To turn the oven lamp on and off.
9Clock To set the clock functions.
10 Minute Minder To set the Minute Minder.
8

Display
A B C
DEFG
A. Oven function symbol
B. Temperature / time of day display
C. Clock / Residual heat display / Minute
Minder
D. Residual heat indicator (selected
models only)/ Water level indicator
E. Indicators for the clock functions
F. Heat-up indicator / Fast Heat Up
indicator / Residual heat indicator
(selected models only)
G. Number of an oven function /
programme
Other indicators of the display:
Symbol Name Description
Functions You can choose an oven function.
Automatic programme You can choose an automatic programme.
My favourite programme The favourite programme operates.
/ kg / g An automatic programme with a weight in‐
put operates.
/ h / min A clock function operates.
Temperature / Fast heat up The function operates.
Temperature The current temperature is indicated.
Temperature You can change the temperature.
Core temperature sensor The core temperature sensor is in the core
temperature sensor socket.
Light You deactivated the light.
Minute minder The minute minder function operates.
Water drawer indicator Shows the water level
Heat up indicator
If you turn on the heating function,
appears. The bars show that the
temperature in the oven increases or
decreases.
When the oven is at the set temperature,
the bars go off the display.
9

BEFORE FIRST USE
WARNING! Refer to Safety
chapters.
Initial Cleaning
Step 1 Step 2 Step 3
Remove all accessories and
removable shelf supports
from the appliance.
Clean the appliance and the
accessories only with a mi‐
crofibre cloth, warm water
and a mild detergent.
Place the accessories and
the removable shelf sup‐
ports in the appliance.
Initial preheating
Preheat the empty oven before the first
use.
Step 1 Remove all accessories and removable shelf supports from the oven.
Step 2 Set the maximum temperature for the function: .
Let the oven operate for 1 h.
Step 3 Set the maximum temperature for the function: .
Let the oven operate for 15 min.
Step 4 Set the maximum temperature for the function: .
Let the oven operate for 15 min.
The oven can emit an odour and smoke during preheating. Make sure that the room is ven‐
tilated.
Setting the water hardness
When you connect the oven to the mains
you have to set the water hardness level.
The table below shows the water
hardness range (dH) with the
corresponding Calcium deposit and the
quality of the water.
10

Water hardness Calcium deposit
(mmol/l)
Calcium deposit
(mg/l)
Water clas‐
sification
Class dH
1 0 - 7 0 - 1.3 0 - 50 Soft
2 7 - 14 1.3 - 2.5 50 - 100 Moderately
hard
3 14 - 21 2.5 - 3.8 100 - 150 Hard
4 over 21 over 3.8 over 150 Very hard
When the water hardness exceeds the
values in the table, fill the water drawer
with bottled water.
1. Take the 4 colour change strip
supplied with the steam set in the
oven.
2. Put all the reaction zones of the strip
into the water for approximately 1
second.
Do not put the strip into the running
water.
3. Shake the strip to remove the excess
of the water.
4. Wait 1 minute and check the water
hardness with the table below.
The colours of the reaction zones
continue to change. Do not check the
water hardness later than 1 minute
after test.
5. Set the water hardness: settings
menu.
Refer to the "Additional functions" chapter,
Using the settings menu.
Test strip Water Hardness
1
2
3
4
You can change the water hardness in the
settings menu.
DAILY USE
WARNING! Refer to Safety
chapters.
Heating Functions
Oven func‐
tion
Application
True Fan
Cooking
To bake on up to three
shelf positions at the
same time and to dry
food.
Set the temperature 20 -
40 °C lower than for Con‐
ventional Cooking.
Oven func‐
tion
Application
Pizza Func‐
tion
To bake pizza. To make
intensive browning and a
crispy bottom.
Slow Cooking
To prepare tender, suc‐
culent roasts.
11

Oven func‐
tion
Application
Conventional
Cooking
To bake and roast food
on one shelf position.
Frozen Foods
To make convenience
food crispy, e.g. french
fries, potato wedges or
spring rolls.
Grill
To grill thin pieces of
food and to toast bread.
Turbo Grilling
To roast large meat joints
or poultry with bones on
one shelf position. To
make gratins and to
brown.
Bottom Heat
To bake cakes with
crispy bottom and to pre‐
serve food.
Defrost
To defrost food (vegeta‐
bles and fruit). The de‐
frosting time depends on
the amount and size of
the frozen food.
Moist Fan
Baking
This function is designed
to save energy during
cooking. When you use
this function, the temper‐
ature inside the appli‐
ance may differ from the
set temperature. The re‐
sidual heat is used. The
heating power may be re‐
duced. For more informa‐
tion refer to "Daily Use"
chapter, Notes on: Moist
Fan Baking.
Oven func‐
tion
Application
Bread Baking
Use this function to pre‐
pare bread and bread
rolls with professional-
like result in terms of
crispiness, colour and
crust gloss.
Keep Warm
To keep food warm.
Please note that some
dishes may continue to
cook and dry out while
being kept warm. Cover
the dishes if necessary
Steam Re‐
generating
Food reheating with
steam prevents surface
drying. Heat is distributed
in a gentle and even way,
which allows to recover
taste and aroma of food
as just prepared. This
function can be used to
reheat food directly on a
plate. You can reheat
more than one plate at
the same time, using dif‐
ferent shelf positions.
Humidity Low
To bake bread, roast
large pieces of meat or to
warm up chilled and fro‐
zen meals.
Humidity
High
For dishes with a high
moisture content, custard
royale and terrines, and
for poaching fish.
Full Steam
For vegetables, fish, po‐
tatoes, rice, pasta or spe‐
cial side-dishes.
The lamp may turn off
automatically at a temperature
below 60 °C during some oven
functions.
12

Notes on: Moist Fan Baking
This function was used to comply with the
energy efficiency class and ecodesign
requirements (according to EU 65/2014
and EU 66/2014). Tests according to:
IEC/EN 60350-1.
The oven door should be closed during
cooking so that the function is not
interrupted and the oven operates with the
highest energy efficiency possible.
When you use this function the lamp
automatically turns off after 30 sec.
For the cooking instructions refer to "Hints
and tips" chapter, Moist Fan Baking. For
general energy saving recommendations
refer to "Energy Efficiency" chapter,
Energy Saving.
How to set: Heating Functions
1. Turn on the oven with .
The display shows the set temperature,
the symbol and the number of the heating
function.
2. Press or to set a heating
function.
3. Press or the oven starts
automatically after 5 seconds.
If you turn on the oven and do not set any
heating function or programme, the oven
turns off automatically after 20 seconds.
How to set: Temperature
Press or to change the
temperature in steps: 5 °C.
When the oven is at the set temperature a
signal sounds and the Heat up indicator
disappears.
How to check: Temperature
You can check the current temperature in
the oven when the function or programme
works.
1. Press .
The display shows the temperature in the
oven.
2. Press or the display shows again
the set temperature automatically after
5 seconds.
How to set: Fast Heat Up
Do not put food in the oven when the Fast
heat up works.
The Fast Heat Up is available only for
some heating functions. If Faulty Tone is
turned on in the settings menu, the signal
sounds if the Fast Heat Up is not available
for the set function. Refer to "Additional
functions" chapter, Using the settings
menu.
The Fast Heat Up decreases the heat up
time.
To turn on the Fast Heat Up press and
hold for more than 3 seconds.
If the Fast Heat Up is turned on the
display shows flashing bars.
How to set: Steam Cooking
The water drawer cover is in the control
panel.
WARNING! Use only cold tap
water. Do not use filtered
(demineralised) or distilled
water. Do not use other liquids.
Do not put flammable or
alcoholic liquids into the water
drawer.
1. Press the cover of the water drawer to
open it.
2. Fill the water drawer with cold water to
the maximum level (around 950 ml)
until the signal sounds or the display
shows the message.
The water supply is sufficient for
approximately 50 minutes.
Do not fill the water drawer over its
maximum capacity. There is a risk of
water leakage, overflow and furniture
damages.
3. Push the water drawer to its initial
position.
4. Turn on the oven.
13

5. Set a steam heating function and the
temperature.
6. If necessary, set the function: Duration
or: End Time .
The steam appears after approximately 2
minutes. When the oven reaches the set
temperature, the signal sounds.
When the water drawer is running out of
water, the signal sounds and the water
drawer needs to be refilled to continue the
steam cooking as described above.
The signal sounds at the end of the
cooking time.
7. Turn off the oven.
8. Empty the water drawer after the
steam cooking is completed.
Refer to the cleaning function: Tank
Emptying.
CAUTION! The oven is hot.
There is a risk of burns. Be
careful when you empty the
water drawer.
9. After Steam Cooking steam can
condensate on the bottom of the
cavity. Always dry the bottom of the
cavity when the oven is cool.
Let the oven dry fully with the door open.
To speed up the drying you can close the
door and heat up the oven with the
function: True Fan Cooking at temperature
150°C for approximately 15 minutes.
CLOCK FUNCTIONS
Clock functions table
Clock function Application
Time of Day To show or change the time of day. You can change the
time of day only when the oven is on.
Duration To set how long the oven works.
End Time To set when the oven turns off.
Time Delay To combine Duration and End Time function.
Set + Go To turn on the oven with necessary settings with only one
press of the sensor field any time later.
Minute Minder To set a countdown time. This function has no effect on
the operation of the oven. You can set the Minute Minder
at any time and also when the oven is off.
00:00 Count Up Timer To set the count up, which shows how long the oven
works. It is on immediately when the oven starts to heat.
The Count Up Timer is not turned on if Duration and End
Time are set. This function has no effect on the operation
of the oven.
How to set: Time of Day
After the first connection to the mains, wait
until the display shows and 12:00. "12"
flashes.
1. Press or to set the hours.
2. Press .
3. Press or to set the minutes.
4. Press .
14

The display shows the new time.
To change the time of day press again
and again until starts to flash.
How to set: Duration
1. Set a heating function and
temperature.
2. Press again and again until
starts to flash.
3. Press or to set the minutes for
Duration.
4. Press or the Duration starts
automatically after 5 seconds.
5. Press or to set the hours for
Duration.
6. Press or the Duration starts
automatically after 5 seconds.
When the set time ends, the signal sounds
for 2 minutes. The display shows flashing
and time setting. The oven turns off.
7. Press a sensor field to stop the signal.
8. Turn off the oven.
How to set: End Time
1. Set a heating function and
temperature.
2. Press again and again until
starts to flash.
3. Press or to set the End Time
and press . First you set the
minutes and then the hours.
When the set time ends, the signal sounds
for 2 minutes. The display shows flashing
and the time setting . The oven turns
off automatically.
4. Press a sensor field to stop the signal.
5. Turn off the oven.
How to set: Time Delay
1. Set a heating function and
temperature.
2. Press again and again until
starts to flash.
3. Press or to setthe minutes for
Duration.
4. Press .
5. Press or to set the hours for
Duration.
6. Press .
The display shows flashing .
7. Press or to set the End Time
and press . First you set the
minutes and then the hours.
The oven turns on automatically later on,
works for the set Durationand stops at the
set End Time. When the set time ends, the
signal sounds for 2 minutes. The display
shows flashing and the time setting .
The oven turns off automatically.
8. Press a sensor field to stop the signal.
9. Turn off the oven.
When the Time Delay function
is turned on, the display shows
a symbol of the heating
function, with a dot and .
The dot shows which clock
function is on in the Clock /
residual heat display.
How to set: Set + Go
You can use the Set + Go function only
when the Duration is set.
1. Set a heating function and
temperature.
2. Set the Duration.
3. Press again and again until the
display shows flashing .
4. Press to set the Set + Go function.
The display shows and with an
indicator. This indicator shows which clock
function is activated.
5. Press a sensor field (apart from ON /
OFF) to start the Set + Go function.
How to set: Minute Minder
1. Press .
The display shows flashing and "00".
2. Press to switch between options.
First you set the seconds, then the
minutes and the hours.
15

3. Press or to set the Minute
Minder and to confirm.
4. Press or the Minute Minder starts
automatically after 5 seconds.
When the set time ends, the signal sounds
for 2 minutes and the display shows
flashing 00:00 and .
5. Press a sensor field to stop the signal.
How to set: Count Up Timer
1. To reset the Count Up Timer press:
again and again until display shows
flashing .
2. Press and hold: . When the display
shows "00:00" the Count Up Timer
starts to count up again.
AUTOMATIC PROGRAMMES
WARNING! Refer to Safety
chapters.
There are 25 automatic programmes. Use
an automatic programme or recipe when
you do not have the knowledge or
experience on how to prepare a dish. The
display shows the default cooking times
for all automatic programmes.
List of automatic programmes
Programme
1 VEGETABLES, TRADITIONAL
2 POTATO GRATIN
3 FARMER BREAD
4 ROLLS
5 FISH
6 POACHED FISH (TROUT)
7 PLUM DUMPLING
8 VEAL KNUCKLE
9 RICE
10 LASAGNE
11 DOUGH PROVING
12 ROAST BEEF
13 ROAST PORK
14 ROAST VEAL
15 ROAST LAMB
16 ROAST GAME
Programme
17 WHOLE CHICKEN
18 PIZZA
19 QUICHE LORRAINE
20 LEMON SPONGE CAKE
21 CHEESE CAKE
22 CANNELLONI
23 CONVENIENCE CAKE
24 CONVENIENCE PIZZA
25 CONVENIENCE POTATO
TYPES
How to use: automatic
programmes
1. Activate the appliance.
2. Touch .
The display shows , a symbol and the
number of the automatic programme.
3. Touch or to choose the
automatic programme.
4. Touch or wait five seconds until
the appliance automatically starts to
work.
5. When the set time ends, an acoustic
signal sounds for two minutes. The
symbol flashes.
6. Touch a sensor field or open the oven
door to stop the acoustic signal.
7. Deactivate the appliance.
16

How to use: automatic
programmes with weight input
If you set the weight of the meat, the
appliance calculates the roasting time.
1. Activate the appliance.
2. Touch .
3. Touch or to set the weight
programme.
The display shows: the cooking time, the
duration symbol , a default weight, a
unit of measurement (kg, g).
4. Touch or the settings save
automatically after five seconds.
The appliance activates.
5. You can change the default weight
value with or . Touch .
6. When the set time ends, an acoustic
signal sounds for two minutes.
flashes.
7. Touch a sensor field or open the oven
door to stop the acoustic signal.
8. Deactivate the appliance.
How to set: automatic
programmes with Food Sensor
The core temperature of the food is
default and fixed in programmes with the
core temperature sensor. The programme
ends when the appliance is at the set core
temperature.
1. Activate the appliance.
2. Touch again and again until the
display shows .
3. Install the core temperature sensor.
Refer to "Core temperature sensor".
4. Touch or to set the programme
for the core temperature sensor.
The display shows the cooking time,
and .
5. Touch or the settings save
automatically after five seconds.
When the set time ends, an acoustic
signal sounds for two minutes. flashes.
6. Touch a sensor field or open the door
to stop the acoustic signal.
7. Deactivate the appliance.
USING THE ACCESSORIES
WARNING! Refer to Safety
chapters.
Food Sensor
Food Sensor - measures the temperature
inside the food. When the food is at the
set temperature, the oven turns off.
Set 2 temperatures:
• the oven temperature: minimum 120
°C,
• the food core temperature.
For the best cooking results:
• Ingredients should be at the room
temperature.
• Food Sensor - do not use it with liquid
dishes.
• Food Sensor - during cooking it must
remain in the dish.
The oven calculates the approximate
cooking time, it may change during
cooking.
When you put the accessory into the
socket, you cancel the settings for the
clock functions.
Food categories: meat, poultry
and fish
1. Activate the appliance.
2. Insert the tip of the core temperature
sensor (with on the handle) into the
17

centre of the meat or fish, in the
thickest part as possible. Make sure
that at least 3/4 of the core
temperature sensor is inside of the
dish.
3. Put the plug of the core temperature
sensor into the socket located in the
front frame of the appliance.
The display shows flashing and the
default set core temperature. The
temperature is 60 °C for the first
operation, and the last set value for each
subsequent operation.
4. Touch or to set the core
temperature.
5. Touch or the settings save
automatically after 5 seconds.
You can set the core
temperature only when
flashes. If is in the
display but does not flash
before you set the core
temperature, touch and
or to set a new
value.
6. Set the oven function and the oven
temperature.
The display shows the current core
temperature and the heat up symbol .
When you cook with the core
temperature sensor, you can
change the temperature shown
in the display. After you put the
core temperature sensor in the
socket and set an oven
function and temperature, the
display shows the current core
temperature.
Touch again and again to
see three other temperatures:
• the set core temperature
• the current oven
temperature
• the current core
temperature.
When the dish is at the set core
temperature, an acoustic signal sounds for
2 minutes and the value of the core
temperature and flash. The appliance
deactivates.
7. Touch a sensor field to deactivate the
acoustic signal.
8. Remove the core temperature sensor
from the socket and remove the dish
from the appliance.
WARNING! There is a risk of
burns as the core temperature
sensor becomes hot. Be
careful when you unplug it and
remove it from the dish.
Food category: casserole
1. Activate the appliance.
2. Place half of the ingredients in a
baking dish.
3. Insert the tip of the core temperature
sensor exactly in the centre of the
casserole. The core temperature
sensor should be stabilized in one
place during baking. Use a solid
ingredient to achieve that. Use the rim
of the baking dish to support the
silicone handle of the core temperature
sensor. The tip of the core temperature
sensor should not touch the bottom of
18

a baking dish.
4. Cover the core temperature sensor
with the remaining ingredients.
5. Put the plug of the core temperature
sensor into the socket located in the
front frame of the appliance.
The display shows flashing and the
default set core temperature. The
temperature is 60 °C for the first
operation, and the last set value for each
subsequent operation.
6. Touch or to set the core
temperature.
7. Touch or the settings save
automatically after 5 seconds.
You can set the core
temperature only when
flashes. If is in the
display but does not flash
before you set the core
temperature, touch and
or to set a new
value.
8. Set the oven function and the oven
temperature.
The display shows the current core
temperature and the heat up symbol .
When the dish is at the set core
temperature, an acoustic signal sounds for
2 minutes and the value of the core
temperature and flash. The appliance
deactivates.
9. Touch a sensor field to deactivate the
acoustic signal.
10. Remove the core temperature sensor
from the socket and remove the dish
from the appliance.
WARNING! There is a risk of
burns as the core temperature
sensor becomes hot. Be
careful when you unplug it and
remove it from the dish.
Inserting accessories
A small indentation at the top increases
safety. The indentations are also anti-tip
devices. The high rim around the shelf
prevents cookware from slipping of the
shelf.
19

Wire shelf:
Push the shelf between the guide bars of
the shelf support.
Baking tray / Deep pan:
Push the tray between the guide bars of
the shelf support.
ADDITIONAL FUNCTIONS
Using My Favourite Programme
function
Use this function to save your favourite
temperature and time settings for an oven
function or programme.
1. Set the temperature and time for an
oven function or programme.
2. Touch and hold for more than three
seconds. An acoustic signal sounds.
3. Deactivate the appliance.
•To activate the function touch .
The appliance activates your favourite
programme.
When the function operates,
you can change the time
and temperature.
•To deactivate the function touch .
The appliance deactivates your
favourite programme.
Using Child Lock
The Child Lock prevents an accidental
operation of the oven.
1. Press and hold for 3 sec to turn off
the oven.
2. Press and hold and at the same
time for 2 sec.
The signal sounds.
The display shows SAFE.
To turn off the Child Lock function repeat
step 2.
Using the Function Lock
You can turn on the function only when
the oven works.
The Function Lock prevents an accidental
change of the oven function.
1. To turn on the function turn on the
oven.
2. Turn on an oven function or setting.
3. Touch and hold and at the
same time for 2 seconds.
20
