GENERAL
Please read the instructions carefully as it contains important information
regarding the safety, the installation of the appliance, it’s use and
maintenance.
A qualified person in accordance with the manufacturer’s instructions
should carry out installation of this appliance.
Disconnect the appliance from the main supply outlet before attempting to
do any maintenance and service or before removing the bottom grille of
the appliance.
In case of any failure of the appliance, switch off and have it attended to
by a qualified technician using original spare parts.
INSTALLATION AND POSITIONING
The appliance is supplied with shelves and hooks which the owner can
install at different levels of his choice. It is also equipped with an
advertising panel, which is hooked onto the top of the appliance.
The appliance should be placed in an adequately ventilated room far from
other sources of heat and in such a way that good air circulation –
especially in front of the grille at the bottom of the appliance –is
maintained. The appliance must also be placed approximately 100mm
away from the wall.
The room temperature should not exceed 35ºC.
Level the appliance by rotating the two front feet, situated at the corners
of the base of the appliance. It is possible to level the appliance in all
directions using the two feet only, and this will ensure proper functioning
of the doors.
ELECTRICAL CONNECTIONS
Any electrical alterations to the appliance should be carried out in
conformity with local standards and regulations.
The appliance operates off a single-phase 220/240 volt, 50 Hz power
supply.
To connect the appliance, insert the plug into the mains supply socket,
making sure that:
a) The mains socket has an adequate current carrying capacity, and is
effectively connected to earth.
b) The mains socket has adequate overload protection according to
standard regulations.
The electrical safety of this appliance is guaranteed only when it is
correctly connected to an efficiently grounded installation as specified in
the standard electrical safety regulations.
If in doubt about the efficiency of the earth connection and electrical
installation, have it tested by a qualified electrician.
The manufacturer accepts no responsibility for situations arising from the
failure to comply with these measures.
INSTRUCTIONS TO THE USER
REMARKS
In order for the appliance to work properly, it is necessary to leave enough
space between packed products, to allow free airflow. This will ensure
efficient and economical functioning.
Isolate the appliance from the electrical supply. Remove the bottom grille and
clean the condenser fins of the refrigeration unit at least once every quarter.
Using a soft brush or vacuum cleaner. Do not use a sharp instrument.
Periodically, the condenser should be cleaned thoroughly by blowing through
the fins using CO2 gas. Always blow from the inside out, thus avoiding the
dirt being blown onto the fan motor.
SWITCHING ON
Turn on the power at the mains.
The appliance is equipped with fluorescent lighting on the inside, and to light
up the advertising panel at the top of the cabinet.
The temperature on the inside of the cabinet is regulated by use of a
mechanical thermostat, which is preset at the factory. Should there be need
to alter the settings of the thermostat, contact the supplier or the service
agent.
When merchandising the cabinet, a latch has been fitted onto the edge of the
outer door. By pulling both doors to the centre, the latch can be locked
across the opposing door handle, thus keeping the doors from automatically
closing.
CHANGING FLUORESCENT TUBES
INSIDE LIGHT
Switch the cooler off at the plug point.
Twist the tube to disengage from the fittings on both ends.
Remove the top cap from the light protector tube and slip the fluorescent
tube out.
Slip the new fluorescent tube into the protector tube and replace the top
cap.
Replace the new tube by inserting the points at the end of the tube into
the fitting and twist the tube until engaged.
Switch the cooler on again.
TOP LIGHT
Switch the cooler off at the plug point.
Remove the cover by pushing upwards.
Twist the tube to disengage from the fittings on both ends.
Replace the new tube by inserting the points at the end of the tube into
the fitting and twist the tube until engaged.
Replace the cover by placing the guide at the rear of the panel over the
guide on the cabinet and push downward until tight.
Switch the cooler on again.
