JVC Everio GZ-MS150U Operating and maintenance manual

MEMORY CAMERA
GZ-MS150U
Basic User Guide
Dear Customers
Thank you for purchasing this JVC product.
Before use, please read the Safety Precautions and Cautions on p. 2 and p. 24 to ensure safe
use of this product.
.Detailed User Guide
A “Basic User Guide” (this manual) and a “Detailed User Guide” are available for this
product.
For more details on operating this product, please refer to the “Detailed User Guide”
at the following website.
ohttp://manual.jvc.co.jp/index.html/
o
You can also access the website from the supplied CD-ROM. (p. 18)
For Future Reference:
Enter the Model No. (located on the bottom of the camera) and Serial No.
(located on the battery pack mount of the camera) below.
Model No.
Serial No.
LYT2340-001B-M
EN SP
Getting StartedRecordingPlaybackCopying
Further
Information

Safety Precautions
.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated "dangerous voltage" within the
product's enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
WARNING: TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS UNIT TO
RAIN OR MOISTURE.
NOTES:
•The rating plate and safety caution are on the
bottom and/or the back of the main unit.
•The serial number plate is on the battery pack
mount.
•The rating information and safety caution of the
AC adapter are on its upper and lower sides.
Caution on Replaceable lithium battery
The battery used in this device may present a fire
or chemical burn hazard if mistreated.
Do not recharge, disassemble, heat above 100°C
(212°F) or incinerate.
Replace battery with Panasonic, Sanyo, Sony or
Maxell CR2025.
Danger of explosion or Risk of fire if the battery is
incorrectly replaced.
•Dispose of used battery promptly.
•Keep away from children.
•
Do not disassemble and do not dispose of in fire.
For USA-California Only
This product contains a CR Coin Cell Lithium
Battery which contains Perchlorate Material
– special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate
When the equipment is installed in a cabinet or on
a shelf, make sure that it has sufficient space on all
sides to allow for ventilation (10 cm (3-15/16") or
more on both sides, on top and at the rear).
Do not block the ventilation holes.
(If the ventilation holes are blocked by a
newspaper, or cloth etc. the heat may not be able
to get out.)
No naked flame sources, such as lighted candles,
should be placed on the apparatus.
When discarding batteries, environmental
problems must be considered and the local rules or
laws governing the disposal of these batteries must
be followed strictly.
The apparatus shall not be exposed to dripping or
splashing.
Do not use this equipment in a bathroom or places
with water.
Also do not place any containers filled with water
or liquids (such as cosmetics or medicines, flower
vases, potted plants, cups etc.) on top of this unit.
(If water or liquid is allowed to enter this
equipment, fire or electric shock may be caused.)
Do not point the lens directly into the sun. This
can cause eye injuries, as well as lead to the
malfunctioning of internal circuitry. There is also a
risk of fire or electric shock.
CAUTION!
The following notes concern possible physical
damage to this unit and to the user.
Carrying or holding this unit by the LCD monitor
can result in dropping the unit, or in a malfunction.
Do not use a tripod on unsteady or unlevel surfaces.
It could tip over, causing serious damage to the unit.
CAUTION!
Connecting cables (Audio/Video, etc.) to this unit
and leaving it on top of the TV is not recommended,
as tripping on the cables will cause
this unit to fall,
resulting in damage.
CAUTION:
WARNING:
The battery pack, the camcorder with battery
installed, and the remote control with battery
installed should not be exposed to excessive heat
such as direct sunlight, fire or the like.
The mains plug shall remain readily operable.
•Remove the mains plug immediately if the
camcorder functions abnormally.
2For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/

.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9. Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
10.Only use attachments/accessories specified by
the manufacturer.
11.Use only with the cart,
stand, tripod, bracket,
or table specified by
the manufacturer, or
sold with the apparatus.
When a cart is used,
use caution when
moving the cart/
apparatus combination
to avoid injury from tip-over.
12.Unplug this apparatus during lightning storms or
when unused for long periods of time.
13.Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
If this symbol is shown, it is only valid
in the European Union.
Remember that this unit is intended for
private consumer use only.
Any commercial use without proper permission
is prohibited. (Even if you record an event such
as a show, performance or exhibition for personal
enjoyment, it is strongly recommended that you
obtain permission beforehand.)
Trademarks
Make a backup of important recorded data
• Windows®is either registered trademark or
trademark of Microsoft Corporation in the
United States and/or other countries.
• Macintosh is a registered trademark of Apple Inc.
• iMovie and iPhoto are trademarks of Apple Inc.,
registered in the U.S. and other countries.
• YouTube™ and the YouTube logo are
trademarks and/or registered trademarks of
YouTube LLC.
•
Intel, Intel Core, and Pentium are trademarks or
registered trademarks of Intel Corporation or its
subsidiaries in the United States and other countries.
• Eye-Fi is a trademark of Eye-Fi, Inc.
•
Other product and company names included in
this instruction manual are trademarks and/or
registered trademarks of their respective holders.
JVC will not be responsible for any lost data. It is
recommended to copy your important recorded
data to a disc or other recording media for storage.
For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/ 3

Contents
Safety Precautions ............................... 2
Verifying the Accessories .................... 4
Names of Parts and Functions ............. 5
IGetting Started ........................... 6
Charging the Battery Pack ................... 6
Grip Adjustment ................................... 7
Using as a Hand Strap ......................... 7
Inserting an SD Card ........................... 8
Clock Setting ..................................... 10
IRecording ................................. 12
Video Recording ................................ 12
IPlayback ................................... 13
Playing Back/Deleting Files on this Unit
........................................................... 13
Playing Back on TV ............................ 14
ICopying .................................... 15
Copying Files ..................................... 15
Dubbing Files by Connecting to a DVD
Recorder or VCR ............................... 16
Copying to Computer ......................... 17
IFurther Information ................... 20
Operating the Menu ........................... 20
Recordable Time ............................... 21
Troubleshooting ................................. 22
Cautions ............................................ 24
Specifications .................................... 26
.Detailed User Guide
A “Basic User Guide” (this manual) and a “Detailed User Guide” are available for this product.
For more details on operating this product, please refer to the “Detailed User Guide” at the
following website.
ohttp://manual.jvc.co.jp/index.html/
o
You can also access the website from the supplied CD-ROM. (p. 18)
Verifying the Accessories
AC Adapter
AC-V11U*
Battery Pack
BN-VG108U/
BN-VG107U
USB Cable
(Type A - Mini Type B)
QAM1313-001/
QAM1369-001
AV Cable
....
CD-ROM
LY37342-036 Basic User Guide (this manual)
..
0SD cards are sold separately. For details on the types of cards that can be used on this
unit, refer to p. 8.
* When using the AC adapter overseas, please prepare a commercially available converter
plug for the country or region of visit.
4For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/

Names of Parts and Functions
.
2
45
1
j
c
e
d
g
h
f
m
l
k
i
6
7
8
9
0
b
a
3
ALens Cover
BMonaural Microphone
CLCD Monitor
Turns the power on/off by opening and
closing.
DSpeaker
EACCESS (Access) Lamp
Lights up/blinks during recording or
playback.
FPOWER/CHARGE (Power/Charge)
Lamp (p. 6)
GL (Play/Record) Button
Switches between recording and
playback modes.
HUP/< Button
UP :Scrolls/moves cursor on the
icons upward
<:Reverse search
IDOWN/> Button
DOWN :Scrolls/moves cursor on the
icons downward
>:Forward search
JOK/INFO Button
Confirms the selection. / Displays
information as follows.
Recording :Displays the remaining
time and battery power.
Playback :Displays file information
such as recording date.
KAV Connector (p. 14, 16)
LMENU Button (p. 20)
MUSB Connector (p. 19)
NZoom/Volume Lever / Index (u)
(p. 12, 13)
Oi.AUTO (Intelligent Auto) Button
(p. 12)
PDC Connector (p. 6)
QSTART/STOP Button (Video
Recording) (p. 12) /
d/e (Play/Pause) Button (Video
Playback) (p. 13)
RStrap Lock (p. 7)
SLens Cover Switch (p. 12)
TGrip Belt (p. 7)
UTripod Mounting Hole
VSD Card Slot (p. 8)
WBattery Release Lever (p. 6)
For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/ 5

Charging the Battery Pack
.
(Base)
To detach the battery pack
Charging finished:
Goes out
Charging in progress:
Blinks
Charging Lamp
Plug in the power.
To AC Outlet
(110 V to 240 V)
AC Adapter
Cover
Connect the DC
connector.
Mark
Align the top of the battery
with the mark on this unit,
and slide in until the battery
clicks into place.
The battery pack is not
charged at the time of
purchase.
Attach the battery pack.
CAUTION
Be sure to use JVC battery packs.
0If you use any other battery packs besides JVC battery packs, safety and
performance cannot be guaranteed.
0Charging time: Approx. 2 h 10 m (BN-VG108U)/1 h 50 m (BN-VG107U) (using
supplied battery pack)
* The charging time is when the unit is used at 25°C (77°F). If the battery pack is charged
outside the room temperature range of 10°C to 35°C (50°F to 95°F), charging may
take a longer time or it may not start. The recordable and playable time may also be
shortened under some usage conditions such as at low temperature.
0Charging is also possible with a USB cable. (Refer to Detailed User Guide.)
Getting Started
6For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/

Grip Adjustment
.
Close the lever
Adjust the length
of the belt
Open the lever on
the strap lock
Using as a Hand Strap
Adjust the length of the belt and loop it around your wrist.
.
For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/ 7
Getting StartedRecordingPlaybackCopying
Further
Information

Inserting an SD Card
Insert a commercially available SD card before recording.
.
Turn off the power of this unit before
inserting or removing a card.
(Base)
Label
Insert an SD card.
Open the cover.Close the LCD monitor.
When the LCD monitor is closed, the unit turns off.
oTo remove the card
Push the card inward once, then pull it out straight.
.
(Base)
NOTE
Operations are confirmed on the following SD cards.
Manufacturer Panasonic, TOSHIBA, SanDisk, Eye-Fi*
Video A
Class 4 or higher compatible SDHC card (4 GB to 32 GB) /
Class 4 or higher compatible SDXC card (Max. 64 GB)
Eye-Fi Eye-Fi Connect X2 / Eye-Fi Explore X2 / Eye-Fi Pro X2
*Only the specified models may be used. Refer to the Detailed User Guide for
details.
0Using SD cards (including SDHC/SDXC cards) other than those specified above
may result in recording failure or data loss.
0To protect the data, do not touch the terminals of the SD card.
0Eye-Fi manufactures SD memory cards with wireless LAN function.
8For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/

To select/move cursor towards up/left or down/
right, press the button UP/< or DOWN/>.
oTo use SD cards that have been
used on other devices
Format (initialize) the card using
“FORMAT SD CARD” from media
settings.
All data on the card will be deleted
when it is formatted. Copy all files
on the card to a computer before
formatting.
APress MENU.
BSelect “MEDIA SETTINGS” and
press OK.
CSelect “FORMAT SD CARD” and
press OK.
.
FORMAT SD CARD
DSelect “FILE” and press OK.
.
FILE
FORMAT SD CARD
ESelect “YES” and press OK.
FAfter formatting, press OK.
For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/ 9
Getting StartedRecordingPlaybackCopying
Further
Information

Clock Setting
To select/move cursor towards up/left or down/
right, press the button UP/< or DOWN/>.
.
1Open the LCD monitor.
.
0The unit turns on. When the LCD
monitor is closed, the unit turns off.
2Select “YES” and press OK when
“SET DATE/TIME!” is displayed.
.
NOYES
SET DATE/TIME!
3Set the date and time.
.
2011JAN 1 10 00
TIME
CLOCK SETTING
DATE
0Press UP/< or DOWN/> to adjust the
setting value and press OK to confirm
it. The cursor moves to the next item.
0Repeat this step to input the year,
month, day, hour, and minute.
4Press UP/< or DOWN/> to select the
region where you live and press OK.
0The city name and time difference are
displayed.
.
GMT
CLOCK/AREA SETTING
oTo return to the previous screen
Press MENU.
10 For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/

To reset the clock
Set the clock with “CLOCK ADJUST”
from the menu.
APress MENU.
BSelect “CLOCK ADJUST” and
press OK.
.
CLOCK ADJUST
CSelect “CLOCK SETTING” and
press OK.
.
CLOCK SETTING
CLOCK ADJUST
0The subsequent setting operations
are the same as steps 3 - 4 on the
previous page.
To change the display language
The language on the display can be
changed.
APress MENU.
BSelect “DISPLAY SETTINGS”
and press OK.
.
DISPLAY SETTINGS
CSelect “LANGUAGE” and press
OK.
.
LANGUAGE
DSelect the desired language and
press OK.
NOTE
0“SET DATE/TIME!” is displayed when you turn on this unit after it has not been
used for a prolonged period.
Charge this unit for more than 24 hours before setting the clock.
For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/ 11
Getting StartedRecordingPlaybackCopying
Further
Information

Video Recording
You can record without worrying about the setting details by using the Intelligent Auto mode.
Settings such as exposure and focus will be adjusted automatically to suit the shooting
conditions.
*
In case of specific shooting scenes such as backlight (C), night view (B), person (A) etc., its
icon is displayed on the screen.
Before recording an important scene, it is recommended to conduct a trial recording.
.
(Telephoto)(Wide angle)
Zooming
Press again to stop.
Start recording.
The mode changes between Intelligent
Auto and Manual with every press.
If the mode is HManual, press the
Sbutton to switch.
Check if the recording mode is PIntelligent Auto.
Open the
lens cover.
Zoom ratio setting depends on the setting
of “VIDEO QUALITY”. (P.26)
oIndications during video recording
.
0:00:00 [000:22]
Battery Indicator
Recording Media
Recording in Progress
Record-Standby
Remaining Recording Time
Video Quality
Scene Counter
Image Stabilizer
NOTE
0The estimated recording time of the supplied battery pack is approximately 40
minutes. (p. 21)
0Do not remove the battery pack, AC adapter, or SD card when the access lamp
is lighted. The recorded data may become unreadable.
Recording
12 For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/

Playing Back/Deleting Files on this Unit
Select and play back the recorded videos from an index screen (thumbnail display).
.
2011
Turn up the
volume
Turn down the
volume
Volume adjustment
To select/move cursor towards up/left or
down/right, press the button UP/< or DOWN/>.
Select the desired video and press
[d/e].
Select the playback mode.
0Press L again to return to the recording mode.
oTo delete selected files from
the index screen
A
Press MENU, select “DELETE” and
press OK.
B
Select “FILE SELECT” and press OK.
C
Press UP/< or DOWN/> to select files
and press OK.
D
Press MENU, select “EXECUTE” and
press OK to confirm deletion.
E
After deleting is complete, press OK.
oUsable operation buttons/levers during playback
During video playback During video pause
d/ePause Playback
Zoom u- Stop (returns to thumbnail display)
Zoom T / Vol.+ Increases volume level -
Zoom W / Vol.- Decreases volume level -
UP/< Reverse search Frame-by-frame playback in reverse
direction
DOWN/> Forward search Frame-by-frame playback in forward
direction
Playback
For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/ 13
Getting StartedRecordingPlaybackCopying
Further
Information

Playing Back on TV
1Connect to a TV.
* Refer also to the instruction manual of the TV in use.
0Turn off the power.
oPlaying back in standard quality
If you are using a conventional TV, you can play back in standard quality by connecting
to the AV connector.
Connecting to the AV connector
.
Red
White
Yellow
TV
Audio Input (R)
Audio Input (L)
Video Input
Video Input
AV Cable (Provided)
To AV Connector
2Connect the AC adapter.
0This unit powers on automatically when the AC adapter is connected.
3Select the TV input switch.
4Play back a file. (p. 13)
oTo play back with date/time display
Set “DISPLAY ON TV” in the “CONNECTION SETTINGS” menu to “ON”.
Set “ON-SCREEN DISPLAY” in the playback menu to “ON”.
oWhen images look unnatural on the TV
Images do not appear on the TV
properly.
0Disconnect the cable and connect again.
0Turn off and on this unit again.
Images are projected vertically on
the TV.
0Set “VIDEO OUTPUT” in the “CONNECTION
SETTINGS” menu to “4:3”.
Images are projected horizontally
on the TV.
0Adjust the TV’s screen accordingly.
The color of images looks strange. 0Adjust the TV’s screen accordingly.
14 For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/

Copying Files
You can create discs or copy the files on this unit by connecting it to various devices.
X:Recordable and playable
F:Playable only
—:Not applicable
Media Selection
Standard Quality
Page
.
(VHS Tape)
.
(DVD Disc)
Device
DVD Recorder
.
—Xp. 16
VCR
.
X—p. 16
Computer
.
—* p. 17
* For details on how to create a disc using a computer, refer to the Detailed User Guide.
NOTE
0It is not possible to connect and record to a DVD writer, external Blu-ray drive,
or external hard disk.
Copying
For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/ 15
Getting StartedRecordingPlaybackCopying
Further
Information

Dubbing Files by Connecting to a DVD
Recorder or VCR
You can dub videos in standard quality by connecting to a DVD recorder or VCR.
Refer also to the instruction manuals of the TV, DVD recorder, VCR, etc.
1Connect to a VCR/DVD recorder.
0Turn off the power.
.
VCR/DVD Recorder
Audio Input (R)
Audio Input (L)
Video Input
Video Input
Red
White
Yell ow
To DC Connector
To AC Outlet
(110 V to 240 V)
AC Adapter
AV Cable (Provided)
To AV Connector
0This unit powers on automatically when the AC adapter is connected.
2Press L (Play/Record) to select the playback mode.
.
3Prepare to record.
Preparation on TV and VCR/DVD recorder
0Switch to a compatible external input.
0Insert a DVD-R or video tape.
Preparation on this unit
0Set “VIDEO OUTPUT” in the “CONNECTION
SETTINGS” menu to the aspect ratio (“4:3” or “16:9”) of the connecting TV.
0
To include the date during dubbing, set “DISPLAY ON TV” in the “CONNECTION
SETTINGS” menu to “ON”. Set “ON-SCREEN DISPLAY” in the playback menu to “ON”.
4Start recording.
0Start playback on this unit and press the record button on the recorder.
0After playback is complete, stop the recording.
16 For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/

Copying to Computer
Verifying System Requirements (Guideline)
Windows PC
You can copy files to a PC using the provided software.
Right-click on “Computer” (or “My Computer”) in the “Start” menu and select “Properties”
to check the following items.
oWindows 7 / Windows Vista
.
Processor
High definition: Intel Core Duo, CPU 1.66 GHz or higher
(Intel Core 2 Duo, CPU 2.13 GHz or higher recommended)
Service Pack 2 (Windows Vista only)
Home Basic or Home Premium (Pre-installed versions only)
WindowsVista
Home Premium (Pre-installed versions only)
Windows7
System type: 32-bit / 64-bit
Memory: At least 2 GB
oWindows XP
.
Memory: At least 2 GB
Processor
High definition: Intel Core Duo, CPU 1.66 GHz or higher
(Intel Core 2 Duo, CPU 2.13 GHz or higher recommended)
Service Pack 3
Home Edition or Professional (Pre-installed versions only)
Windows XP
oOther requirements
Graphic: Intel G945 or higher recommended
NOTE
0If your PC does not meet the above system requirements, the provided software
cannot be used.
0For more information, contact your PC’s manufacturer.
For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/ 17
Getting StartedRecordingPlaybackCopying
Further
Information

Mac Computer
You can import files from this unit to a computer using Apple’s iMovie ‘08, ‘09 or ‘11.
To verify the system requirements, select “About This Mac” from the Apple menu. You
can determine the operating system version, processor and amount of memory.
0For the latest information on iMovie, refer to the Apple website.
0For details on how to use iMovie, refer to the help file of the software.
0There is no guarantee that the operations will work with all computer environments.
Installing the Provided Software
You can display the recorded images in
calendar format and perform simple editing
using the provided software.
1Load the provided CD-ROM into
your PC.
ASelect “LoiLoScope AX install”.
Follow the on-screen instructions.
0“Windows Installer” appears after a
while.
0If it doesn’t appear, double-click the
CD-ROM icon in “My Computer”.
2Click “Next”.
.
0Follow the on-screen instructions.
3Click “Close” to exit.
.
0Installation ends and icon is created on
the desktop.
18 For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/

Backing Up All Files
Before making backup, make sure that
there is enough free space in the PC’s HDD.
0Close the LCD monitor to turn off the
camcorder. Disconnect the power
supply.
To select/move cursor towards up/left or
down/right, press the button UP/< or DOWN/
>.
.
1Open the LCD monitor.
2Connect the USB cable and the AC
adapter.
0Be sure to use the supplied AC
adapter.
.
To AC Outlet
(110 V to 240 V)
AC Adapter
To USB Connector
USB Cable
(Provided)
To DC Connector
To USB
Connector
0Reconnect the power supply.
0The provided software LoiLoScope
MediaBrowser starts up on the PC.
The subsequent operations are to be
performed on the PC.
3Select the files to back up.
.
4Select backup.
.
Click
5Start backup.
.
Click
If you encounter any problems with
the provided software “LoiLoScope
AX”, refer to following website “http://
loilo.tv/product/15”.
o
To disconnect this unit from the PC
AClick “Safely Remove Hardware”.
.
BClick “Safely Remove USB Mass
Storage Device”.
C(For Windows Vista) Click “OK”.
DDisconnect the USB cable and
close the LCD monitor.
For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/ 19
Getting StartedRecordingPlaybackCopying
Further
Information

Operating the Menu
You can configure various settings using the
menu.
To select/move cursor towards up/left
or down/right, press the button UP/< or
DOWN/>.
.
1Press MENU.
2Select the desired menu and press
OK.
.
GAIN UP
3Select the desired setting and press
OK.
.
AUTO SLOW-SHUTTER
oTo return to the previous screen
Press MENU.
0For more information on the
settings, refer to the Detailed User
Guide.
.
FORMAT SD CARD
MEDIA SETTINGS
VIDEO OUTPUT
DISPLAY ON TV
CONNECTION SETTINGS
FACTORY PRESET
UPDATE
QUICK RESTART
AUTO POWER OFF
OPERATION SOUND
DEMO MODE
BASIC SETTINGS
MONITOR BRIGHTNESS
DATE DISPLAY STYLE
LANGUAGE
DISPLAY SETTINGS
Common Menu
ON-SCREEN DISPLAY
CLOCK ADJUST
PLAYBACK OTHER FILE
PROTECT/CANCEL
DELETE
Playback Menu
CLOCK ADJUST
ZOOM
VIDEO QUALITY
AUTO REC
TIME-LAPSE RECORDING
WIND CUT
GAIN UP
DIS
FACE PRIORITY AE/AF
TELE MACRO
BACKLIGHT COMP.
WHITE BALANCE
BRIGHTNESS ADJUST
FOCUS
SCENE SELECT
MANUAL SETTING
Recording Menu
Menu Map
Further Information
20 For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/
