JVC GC-PX10EK User manual

MemoryCamera
GCPX10EK
BasicUserGuide
ThankyouforpurchasingthisJVCproduct.
Beforeuse,pleasereadtheSafetyPrecautionsandCautionsonp.2andp.13toensuresafe
useofthisproduct.
DetailedUserGuide
Fordetailedoperatinginstructionsofthisunit,refertothe“DetailedUserGuide”
(PDF)intheCDROM.
AInserttheprovidedCDROMintoyourcomputer.
WindowsVista/Windows7
Click“LoiLoScopeFXInstallandUserGuide”intheautoplaydialogbox.
BClick“DetailedUserGuide”.
MacComputer
Doubleclick“start.pdf”inthe“PX10_guide”folder.
CSelectthedesiredlanguage.
o
ContentintheDetailedUserGuide(PDF)
ContinuousShooting/RecordingwithVaryingBrightness
SlowmotionRecording
CapturingSubjectsClearly
CopyingFilestoanSDCard
DeletingUnwantedFiles
CopyingtoComputer
andmore
LYT2383-001A-M
EN

SafetyPrecautions
When the equipment is installed in a cabinet or on
a shelf, make sure that it has sufficient space on
all sides to allow for ventilation (10 cm or more on
both sides, on top and at the rear).
Do not block the ventilation holes.
(If the ventilation holes are blocked by a newspaper,
or cloth etc. the heat may not be able to get out.)
No naked flame sources, such as lighted candles,
should be placed on the apparatus.
When discarding batteries, environmental
problems must be considered and the local rules
or laws governing the disposal of these batteries
must be followed strictly.
The apparatus shall not be exposed to dripping
or splashing.
Do not use this equipment in a bathroom or
places with water.
Also do not place any containers filled with water
or liquids (such as cosmetics or medicines, flower
vases, potted plants, cups etc.) on top of this unit.
(If water or liquid is allowed to enter this
equipment, fire or electric shock may be caused.)
Do not point the lens directly into the sun. This
can cause eye injuries, as well as lead to the
malfunctioning of internal circuitry. There is also a
risk of fire or electric shock.
CAUTION!
The following notes concern possible physical
damage to the unit and to the user.
Carrying or holding the unit by the LCD monitor
can result in dropping the unit, or in a malfunction.
Do not use a tripod on unsteady or unlevel
surfaces. It could tip over, causing serious damage
to the unit.
CAUTION!
Connecting cables (Audio/Video, etc.)
to the unit and leaving it on top of the TV is not
recommended, as tripping on the cables will cause
the unit to fall, resulting in damage.
CAUTION:
To avoid electric shock
or damage to the unit,
first firmly insert the small
end of the power cord
into the AC Adapter
until it is no longer wobbly,
and then plug the larger
end of the power cord into an AC outlet.
IMPORTANT (for owners in the U.K.)
Connection to the mains supply in the United
Kingdom.
DO NOT cut off the mains plug from this equipment.
If the plug fitted is not suitable for the power points
in your home or the cable is too short to reach
a power point, then obtain an appropriate safety
approved extension lead or consult your dealer.
BE SURE to replace the fuse only with an
identical approved type, as originally fitted,
and to replace the fuse cover.
If nonetheless the mains plug is cut off be sure
to remove the fuse and dispose of the plug
immediately, to avoid possible shock hazard by
inadvertent connection to the mains supply.
If this product is not supplied fitted with a mains
plug then follow the instructions given below:
DO NOT make any connection to the Larger
Terminal coded E or Green.
The wires in the mains lead are coloured in
accordance with the following code:
Blue to N
(Neutral) or Black
Brown to L (Live)
or Red
If these colours do not correspond with the terminal
identifications of your plug, connect as follows:
Blue wire to terminal coded N (Neutral) or coloured
black.
Brown wire to terminal coded L (Live) or coloured Red.
If in doubt — consult a competent electrician.
WARNING: TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN
OR MOISTURE.
CAUTIONS:
•
To prevent shock, do not open the cabinet. No
user serviceable parts inside. Refer servicing to
qualified personnel.
When you are not using the AC adapter for a
long period of time, it is recommended that you
disconnect the power cord from AC outlet.
•
NOTES:
•
The rating plate and safety caution are on the
bottom and/or the back of the main unit.
The serial number plate is on the bottom of the unit.
The rating information and safety caution of the
AC adapter are on its upper and lower sides.
•
•
WARNING:
The battery pack, the camcorder with battery
installed, and the remote control with battery
installed should not be exposed to excessive heat
such as direct sunlight, fire or the Iike.
CAUTION:
The mains plug shall remain readily operable.
•Remove the mains plug immediately if the
camcorder functions abnormally.
Caution on Replaceable lithium battery
The battery used in this device may present a fire
or chemical burn hazard if mistreated.
Do not recharge, disassemble, heat above 100°C
or incinerate.
Replace battery with Panasonic, Sanyo, Sony or
Maxell CR2025.
Danger of explosion or Risk of fire if the battery is
incorrectly replaced.
•Dispose of used battery promptly.
•Keep away from children.
•Do not disassemble and do not dispose of in fire.
2

Information for Users on Disposal of Old
Equipment and Batteries
Products
Battery
Notice:
The sign Pb below the symbol
for batteries indicates that this
battery contains lead.
[European Union]
These symbols indicate that the electrical and
electronic equipment and the battery with this symbol
should not be disposed of as general household
waste at its end-of-life. Instead, the products should
be handed over to the applicable collection points for
the recycling of electrical and electronic equipment as
well as batteries for proper treatment, recovery and
recycling in accordance with your national legislation
and the Directive 2002/96/EC and 2006/66/EC.
By disposing of these products correctly, you will help
to conserve natural resources and will help to prevent
potential negative effects on the environment and
human health which could otherwise be caused by
inappropriate waste handling of these products.
For more information about collection points and
recycling of these products, please contact your
local municipal office, your household waste disposal
service or the shop where you purchased the product.
Penalties may be applicable for incorrect disposal of
this waste, in accordance with national legislation.
[Business users]
If you wish to dispose of this product, please visit
our web page http://www.jvc.eu to obtain
information about the take-back of the product.
[Other Countries outside the European Union]
These symbols are only valid in the European Union.
If you wish to dispose of these items, please do so
in accordance with applicable national legislation or
other rules in your country for the treatment of old
electrical and electronic equipment and batteries.
SOME DO’S AND DON’TS ON THE SAFE
USE OF EQUIPMENT
This equipment has been designed and manufactured
to meet international safety standards but, like any
electrical equipment, care must be taken if you are to
obtain the best results and safety is to be assured.
DO read the operating instructions before you attempt
to use the equipment.
DO ensure that all electrical connections (including the
mains plug, extension leads and interconnections between
pieces of equipment) are properly made and in accordance
with the manufacturer’s instructions. Switch off and withdraw
the mains plug when making or changing connections.
DO consult your dealer if you are ever in doubt about
the installation, operation or safety of your equipment.
DO be careful with glass panels or doors on equipment.
DON’T continue to operate the equipment if you are in
any doubt about it working normally, or if it is damaged
in any way — switch off, withdraw the mains plug and
consult your dealer.
DON’T remove any fixed cover as this may expose
dangerous voltages.
DON’T leave equipment switched on when it is
unattended unless it is specifically stated that it is
designed for unattended operation or has a standby
mode. Switch off using the switch on the equipment
and make sure that your family knows how to do this.
Special arrangements may need to be made for infirm
or handicapped people.
DON’T use equipment such as personal stereos
or radios so that you are distracted from the
requirements of road safety. It is illegal to watch
television whilst driving.
DON’T listen to headphones at high volume, as such
use can permanently damage your hearing.
DON’T obstruct the ventilation of the equipment, for
example with curtains or soft furnishings. Overheating
will cause damage and shorten the life of the equipment.
DON’T use makeshift stands and NEVER fix legs with
wood screws — to ensure complete safety always fit
the manufacturer’s approved stand or legs with the
fixings provided according to the instructions.
DON’T allow electrical equipment to be exposed to
rain or moisture.
ABOVE ALL
•
NEVER let anyone especially children push
anything into holes, slots or any other opening in the
case — this could result in a fatal electrical shock;
•
NEVER guess or take chances with electrical equipment
of any kind — it is better to be safe than sorry!
Make a backup of important recorded data
JVC will not be responsible for any lost data. It is
recommended to copy your important recorded
data to a disc or other recording media for storage.
Do not point the AF assist beam of the flash at the eyes within
close range (several cm).
In addition, do not look at it directly.
Incorrect usage of the flash may cause vision problems.
Keep a distance of at least 1 m when shooting young children.
Using the flash at drivers may cause temporary blindness
and result in accidents.
Do not fire the AF assist beam of the flash at the subjects
within close range (several cm).
In addition, do not touch it with your hands directly.
If there are foreign particles such as dust, do not use it.
Also, do not cover with tape, etc.
Incorrect usage may result in burns.
Heat from the flash may result in emission of smoke.
Do not touch the flash immediately after it is used.
Warning
Caution
3

VerifyingtheAccessories
ACAdapter
APV20M PowerCord BatteryPack BNVF815U
USBCable
(TypeAMiniTypeB)
AVCable ShoulderStrap CDROM CoreFilter
SDcardsaresoldseparately.Fordetailsonthetypesofcardsthatcanbeusedonthis
unit,refertop.7.
WhenusingtheACadapteroverseas,pleaseprepareacommerciallyavailable
converterplugforthecountryorregionofvisit.
AttachingtheShoulderStrap
Caution
Becarefulnottodropthisunitduringtransportation.
Donotplacetheshoulderstrapwithinthereachofyoung
children.
Guardiansshouldpaycloseattentionwhenthisunitis
beingusedbychildren.
AttachingtheCoreFilter
AttachacorefiltertotheendoftheUSBcablethatisconnectedtothisunit.
Thecorefilterreducesinterferencewhenthisunitisconnectedtootherdevices.
Release the stopper
To be connected to this unit
Wind once
3cm
Shoulder Strap
4

ChargingtheBatteryPack
Chargethebatterypackimmediatelyafter
purchaseandwhentheremainingbattery
powerislow.
1SlidetheswitchinthedirectionofA
andslideopenthecoverinthe
directionofB.
.
A
B
(Base)
2Pushandslidethebatteryinuntilit
clicksintoplace.
.
3Alignthemarkonthecoverwiththis
unit.
.
Align here
4Slidethecoverinuntilitclicksinto
place.
.
5ConnecttheACadaptertotheDC
connector.
ChargingstartsandthePOWER/
CHARGEappearsblinking.
DetachingtheBatteryPack
APressandholdthelever.
BSlideoutthebattery.
1
2
Caution
BesuretouseJVCbatterypacks.
Ifyouuseanyotherbatterypacks
besidesJVCbatterypacks,safety
andperformancecannotbe
guaranteed.
Chargingcannotbeperformed
whilethepoweristurnedon.Turn
offthepowerbeforechargingthe
battery.
Chargingtime:Approx.2h40m
(usingsuppliedbatterypack)
Thechargingtimeiswhentheunit
isusedat25°C.Ifthebatterypack
ischargedoutsidetheroom
temperaturerangeof10°Cto
35°C,chargingmaytakealonger
timeoritmaynotstart.The
recordableandplayabletimemay
alsobeshortenedundersome
usageconditionssuchasatlow
temperature.
Preparations
5

ClockSetting
1PresstheMbuttontoturnonthe
power.
.
2Tap“YES”when“SETDATE/TIME!”
isdisplayed.
.
NOYES
SET DATE/TIME!
3Setthedateandtime.
.
201111 10 00
SET
TIMEDATE
CLOCKSETTING
Whentheyear,month,day,hour,or
minuteitemistapped,“∧”and“∨”willbe
displayed.
Tap“∧”or“∨”toadjusttheyear,month,
day,hour,andminute.
4Aftersettingthedateandtime,tap
“SET”.
5Selecttheregionwhereyouliveand
tap“SAVE”.
.
GMT
SAVE
CLOCK/AREA SETTING
Thecitynameandtimedifferenceare
displayed.
Tap“<”or“>”toselectthecityname.
Memo
Whenusingthisunitoverseas,you
cansetittothelocaltimefor
recording.
“SETDATE/TIME!”isdisplayed
whenyouturnonthisunitafterithas
notbeenusedforaprolonged
period.
ConnecttheACadapterformore
than24hourstochargetheinternal
clockbatteryofthisunitbefore
settingtheclock.
ResettingtheClock
APresstheMENUbutton.
BTap“Q”.
CTap“CLOCKADJUST”.
DTap“CLOCKSETTING”.
CLOCK SETTING
CLOCK ADJUST
Thesubsequentsettingoperationsare
thesameassteps35ontheleft.
6

InsertinganSDCard
PrecautionswithSDCards
MakeuseofanSDcardwithoperations
confirmed.
Turnoffthepowerofthisunitbefore
insertingorremovingacard.
1Turnoffthepowerifitisturnedon.
.
2Openthecover.
.
(Base)
3InsertanSDcard.
.
Label
4Closethecover.
RemovingtheCard
PushtheSDcardinwardonce,thenpullit
outstraight.
1
2
SDCardswithOperationsConfirmed
Usingcardsfrommanufacturersotherthan
thosespecifiedbelowmayresultin
recordingfailureordataloss.
Manufacturer Panasonic,
TOSHIBA,
SanDisk,
ATP*1,
EyeFi*2
Video
A
Class4orhighercompatible
SDcard(2GB),
Class4orhighercompatible
SDHCcard(4GBto32GB),
Class4orhighercompatible
SDXCcard(48GBto64GB)
(Whenrecordingwithimage
quality“UHR”,acardofClass6
orhigherisrequired.)
Still
ImageB
SDcard(256MBto2GB),
SDHCcard(4GBto32GB),
SDXCcard(48GBto64GB)
EyeFi EyeFiConnectX2,
EyeFiExploreX2,
EyeFiProX2
*1CardsotherthanSDHCarenot
confirmedforATP.
*2EyeFiisanSDmemorycardwith
wirelessLANfunction.
7

TakingStillImagesinIntelligentAutoMode
Youcanrecordwithoutworryingaboutthe
settingdetailsbyusingtheIntelligentAuto
mode.
Beforerecordinganimportantscene,itis
recommendedtoconductatrialrecording.
1PresstheMbuttontoturnonthe
power.
2PresstheA/Bbuttontoselectthe
stillimagemode.
.
MENU
3Settherecordingdialto“i.AUTO”.
.
4PresstheSNAPSHOTbutton
halfway.
.
Press halfway
5PresstheSNAPSHOTbuttonfully.
PHOTOlightsupwhenastillimageis
beingcaptured.
Tocheckthecapturedstillimage
immediately,pressandholdthe
SNAPSHOTbutton.
Memo
Toreturntotherecordingmodefrom
theplaybackmode,pressthe
SNAPSHOTbuttonduringstillimage
playback.
Thisunitturnsonimmediatelyifthe
powerbuttonispressedwithin5
minutesafterthepoweristurnedoff.
(when“QUICKRESTART”issetto
“HIGHSPEED2”)
When“AUTOPOWEROFF”issetto
“ON”,thisunitturnsitselfoff
automaticallytoconservepower
whenitisnotoperatedfor5minutes.
(onlywhenusingthebatterypack)
Zooming
Theangleofviewcanbeadjustedusing
zoom.
UsetheWend(wideangleend)toshoot
awiderfieldofview.
UsetheTend(telephotoend)tomagnify
thesubjectforshooting.
TelephotoWide Angle
Memo
Thefollowingzoomoptionsare
available:
OpticalZoom(110x)
Onlyopticalzoomisavailableinthe
stillimagerecordingmode.
Recording/Playback
8

TakingVideosinIntelligentAutoMode
Youcanrecordwithoutworryingaboutthe
settingdetailsbyusingtheIntelligentAuto
mode.Settingssuchasexposureandfocus
willbeadjustedautomaticallytosuitthe
shootingconditions.
Incaseofspecificshootingscenessuch
aspersonetc.,itsiconisdisplayedon
thescreen.
Beforerecordinganimportantscene,it
isrecommendedtoconductatrial
recording.
1PresstheMbuttontoturnonthe
power.
2PresstheA/Bbuttontoselectthe
videomode.
.
MENU
3Settherecordingdialto“i.AUTO”.
.
4Startrecording.
.
Pressagaintostop.
Memo
Thisunitturnsonimmediatelyifthe
powerbuttonispressedwithin5
minutesafterthepoweristurned
off.(when“QUICKRESTART”is
setto“HIGHSPEED2”)
When“AUTOPOWEROFF”isset
to“ON”,thisunitturnsitselfoff
automaticallytoconservepower
whenitisnotoperatedfor5
minutes.(onlywhenusingthe
batterypack)
Recordingstopsautomaticallyasit
cannotbeperformedfor12ormore
consecutivehoursaccordingto
specifications.
Longperiodsofcontinuous
shootingareautomaticallysplitinto
filesof30minutesorupto4GB.
Donotremovethebatterypack
whilerecordingisinprogress.
Zooming
Theangleofviewcanbeadjustedusing
zoom.
UsetheWend(wideangleend)toshoot
awiderfieldofview.
UsetheTend(telephotoend)to
magnifythesubjectforshooting.
TelephotoWide Angle
9

PlayingBackStillImages
Youcanselectandplaybacktherecorded
stillimagesfromanindexscreen(thumbnail
display).
1PresstheA/Bbuttontoselectthe
stillimagemode.
.
MENU
2PresstheLbuttontoselectthe
playbackmode.
.
MENU
Thelastcapturedimageappears.
Usethezoomlevertomovetothe
previous/nextimage.
3Tapu.
.
Theindexscreenappears.
4Taponthefiletostartplayback.
.
2011
2011
Usethezoomlevertoswitchpages.
TapI/Jtoselectthemediafor
playback.
Taputoreturntotheindexscreen.
TheWbuttonontheindexscreenis
onlydisplayedduringstillimage
playback.Stillimagesthatarerecorded
continuouslywithin2secondsorwith
thecontinuousshootingmodewillbe
groupedtogetheranddisplayedwitha
greenframeonaseparateindex
screen.
Theindexscreenchangesbetweenthe
normalindexscreenandgroupindex
screenwitheverytapoftheW
button.
MagnifyinganImage(PlaybackZoom)
1Tap2duringstillimageplayback.
.
2Tapontheareatomagnify.
3Tap4tozoomin.
Youcanperformthesameoperation
withthezoomlever(T).
Tozoomout,tap5.
Youcanperformthesameoperation
withthezoomlever(W).
Tapup,down,left,orrighttomovethe
magnifiedimage.
Tocancelthesetting,tap5repeatedly.
Youcanperformthesameoperation
withthezoomlever(W).
10

PlayingBackVideos
1PresstheA/Bbuttontoselectthe
videomode.
.
MENU
2PresstheLbuttontoselectthe
playbackmode.
.
MENU
3Taponthefiletostartplayback.
.
2011
TapI/Jtoselectthemediafor
playback.
Tapetopause.
Taputoreturntotheindexscreen.
CapturingaStillImageintheVideoDuring
Playback
Youcancapturestillimagesofthescenes
youlikeintherecordedvideos.
1Duringvideoplayback,pressthe
START/STOPbuttonatthescene
tocaptureastillimage.
.
Playbackpauses.
(Youcanperformthesameoperation
bytappingeonthescreen.)
Tocontinueplayback,pressthe
START/STOPbuttonagain.
(Youcanperformthesameoperation
bytappingdonthescreen.)
Usethezoomlever(T/W)toplayback
inforward/reverseslowmotion.
(Youcanperformthesameoperation
bytappingl/konthescreen.)
2PresstheSNAPSHOTbutton.
.
Press fully
Stillimagesarecapturedwithasizeof
“1920x1080”.
Capturedstillimagesarestoredinthe
mediawherethevideoisbeingplayed
backfrom.
11

OperatingtheMenu
OperatingtheMenu
1PresstheMENUbutton.
.
Themenudiffersaccordingtothemode
inuse.
2Tapthedesiredmenu.
.
DIS
VIDEO
3Tapthedesiredsetting.
.
ON(A.I.S.)
ON
OFF
DIS
Memo
Toexitthescreen
Tap“L”(quit).
Toreturntothepreviousscreen
Tap“J”(return).
OperatingtheCommonMenu
1PresstheMENUbutton.
2Tap“Q”.
.
3Tapthedesiredmenu.
.
LANGUAGE
COMMON
4Tapthedesiredsetting.
.
ENGLISH
LANGUAGE
Memo
Toreturnallthesettingstotheir
defaultvalues,select“FACTORY
PRESET”inthecommonmenu.
FurtherInformation
12

Cautions
Battery Pack
The supplied battery pack is a
lithium-ion battery. Before using
the supplied battery pack or an
optional battery pack, be sure
to read the following cautions:
•To avoid hazards
... do not burn.
... do not short-circuit the terminals. Keep it away
from metallic objects when not in use. When
transporting, make sure the provided battery
cap is attached to the battery. If the battery cap
is misplaced, carry the battery in a plastic bag.
... do not modify or disassemble.
... do not expose the battery to temperatures
exceeding 60°C, as this may cause the
battery to overheat, explode or catch fire.
... use only specified chargers.
•To prevent damage and prolong service life
... do not subject to unnecessary shock.
... charge within the temperature range of 10°C
to 35°C. Cooler temperatures
require longer charging time, or in some cases
stop charging at all.
Warmer temperatures prevent complete
charging, or in some cases stop charging at all.
... store in a cool, dry place. Extended exposure
to high temperatures will increase natural
discharge and shorten service life.
... keep a 30% battery level (
X ) if the battery pack
is not to be used for a long period of time.
In addition, fully charge and then fully discharge
the battery pack every 6 months, then continue
to store it at a 30% battery level (
X ).
... remove from charger or powered unit when not
in use, as some machines use current even
when switched off.
... do not drop or subject to strong impact.
Recording Medium
•Be sure to follow the guidelines below
to prevent corruption or damage to your
recorded data.
•Do not bend or drop the recording medium,
or subject it to strong pressure, jolts or
vibrations.
•Do not splash the recording medium with water.
•Do not use, replace, or store the recording
medium in locations that are exposed to
strong static electricity or electrical noise.
•Do not turn off the camcorder power or
remove the battery or AC adapter during
shooting, playback, or when otherwise
accessing the recording medium.
•Do not bring the recording medium near
objects that have a strong magnetic field or
that emit strong electromagnetic waves.
•Do not store the recording medium in
locations with high temperature or high humidity.
•Do not touch the metal parts.
•When formatting or erasing data using
the camcorder, only the file administration
information is changed. The data is not
completely erased from the recording medium.
If you want to completely erase all of the data,
we recommend either using commercially
available software that is specially designed for
that purpose, or by physically destroying the
camcorder with a hammer etc.
LCD Monitor
•To prevent damage to the LCD monitor,
DO NOT
... push it strongly or apply any shocks.
... place the camcorder with LCD monitor on the
bottom.
•To prolong service life
... avoid rubbing it with coarse cloth.
Terminals
13

Main Unit •To prevent the unit from dropping,
•Fasten the shoulder strap securely.
•When using the camcorder with a tripod,
attach the camcorder to the tripod securely.
If the camcorder drops, you may be injured
and the camcorder may be damaged.
When a child uses the unit, there must be
parental guidance.
•For safety, DO NOT
... open the camcorder’s chassis.
... disassemble or modify the unit.
...
...
...
...
...
...
...
allow inflammables, water or metallic objects
to enter the unit.
remove the battery pack or disconnect the
power supply while the power is on.
leave the battery pack attached when the
camcorder is not in use.
place naked flame sources, such as lighted
candles, on the apparatus.
expose the apparatus to dripping or splashing.
leave dust or metal objects adhered to the
power plug or an AC wall outlet.
insert any objects in the camcorder.
•Avoid using the unit
... in places subject to excessive humidity or dust.
... in places subject to soot or steam such as near
a cooking stove.
... in places subject to excessive shock or
vibration.
... near a television set.
... near appliances generating strong magnetic
or electric fields (speakers, broadcasting
antennas, etc.).
... in places subject to extremely high (over 40°C)
or extremely low (under 0°C)
temperatures.
•DO NOT leave the unit
... in places of over 50°C .
... in places where humidity is extremely low
(below 35 %) or extremely high (above 80 %).
... in direct sunlight.
... in a closed car in summer.
... near a heater.
... in high places such as on a TV. Leaving the unit
in high places while a cable is connected may
result in a malfunction if the cable is caught and
the unit falls onto the floor.
•To protect the unit, DO NOT
... allow it to become wet.
... drop the unit or strike it against hard objects.
... subject it to shock or excessive vibration during
transportation.
... keep the lens directed at extremely bright
objects for long periods.
... expose the lens to direct sunlight.
... swing it excessively when using the Shoulder Strap.
... swing the soft camera case excessively when
the camera is inside it.
... place the camcorder in dusty or sandy areas,
such as on a beach.
Dear Customer, [European Union]
This apparatus is in conformance with the valid
European directives and standards regarding
electromagnetic compatibility and electrical
safety.
European representative of Victor Company of
Japan, Limited is:
JVC Technical Services Europe GmbH
Postfach 10 05 04
61145 Friedberg
Germany
Remember that this unit is intended for
private consumer use only.
Any commercial use without proper permission
is prohibited. (Even if you record an event such
as a show, performance or exhibition for personal
enjoyment, it is strongly recommended that you
obtain permission beforehand.)
Trademarks
•
HDMI is a trademark of HDMI
Licensing, LLC.
•YouTube™ and the YouTube logo are
trademarks and/or registered trademarks of
YouTube LLC.
•Windows
®
is either registered trademark or
trademark of Microsoft Corporation in the
United States and/or other countries.
•Macintosh is a registered trademark of Apple Inc.
•iMovie and iPhoto are trademarks of Apple Inc.,
registered in the U.S. and other countries.
•
Intel, Intel Core, and Pentium are trademarks or
registered trademarks of Intel Corporation or its
subsidiaries in the United States and other countries.
•
Eye-Fi is a trademark of Eye-Fi, Inc.
•
Other product and company names included in
this instruction manual are trademarks and/or
registered trademarks of their respective holders.
14

Specifications
General
PowerSupply UsingACadapter:DC11V
Usingbatterypack:DC7.2V
PowerConsumption 4.8W(whenMONITORBRIGHTNESSissetto“3”)
Dimensions(mm) 131x67x122(WxHxD)(excludingshoulderstrap)
Mass Camera:Approx.435g
Duringrecording:Approx.520g(includingsuppliedbatterypack)
OperatingEnvironment Allowableoperatingtemperature:0°Cto40°C
Allowablestoragetemperature:20°Cto50°C
Allowablerelativehumidity:35%to80%
ACAdapter(APV20M)
PowerSupply AC110V240V,50Hz/60Hz
Output DC11V,1A
AllowableOperating
Temperature
0°Cto40°C
(10°Cto35°Cduringcharging)
Dimensions(mm) 50x29x100(WxHxD)
(excludingcordandACplug)
Mass Approx.105g
15

If the above do not solve the problem, consult your nearest JVC
dealer or JVC service center.
Remove the AC adapter and battery pack from this unit,
reattach them, and turn on this unit.
Turn off the power.
Reset the unit with the following steps.
This unit is a microcomputer-controlled device. Electrostatic discharge,
external noise and interference (from a TV, a radio, etc.) might prevent it
from functioning properly.
Reset the unit.
Refer to the “Troubleshooting” section in the “Detailed User Guide” (PDF).
If you encounter problems with this unit, check the following before
requesting service.
Troubleshooting
*LYT2383-001A-M*
©2011VictorCompanyofJapan,Limited C1P 0811AJHSWVM
