JVC TH-S320B User manual

TH-S320B
Audio Home Theater System
2.0 CH Soundbar

IC: 26551-51H320420B
FCC Warning
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
Note: The Grantee is not responsible for any changes or modifications not expressly approved
by the party responsible for compliance. such modifications could void the user's authority to
operate the equipment.
The device has been evaluated to meet general RF exposure requirement.
To maintain compliance with FCC's RF exposure guidelines, the distance must be at least 20 cm
between the radiator and your body, and fully supported by the operating and installation
configurations of the transmitter and its antenna(s).
IC Warning
This device complies with Industry Canada license-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause interference, and (2) this
device must accept any interference, including interference that may cause undesired operation
of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne
doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
The device has been evaluated to meet general RF exposure requirement. To maintain
compliance with RSS-102 — Radio Frequency (RF) Exposure guidelines, this equipment should
be installed and operated with a minimum distance of 20cm between the radiator and your body.
le dispositif de a été évalué à répondre général rf exposition exigence.pour maintenir la
conformité avec les directives d'exposition du RSS-102-Radio Fréquence (RF). ce matériel doit
être installé et exploité à une distance minimale de 20 cm entre le radiateur et votre corps.
Supplier’s Declaration of Conformity
Model No. TH-S320B
Trade Name: JVC
Responsible Party: Russell Distribution Company
Address: 7801 Hayvenhurst Avenue, Van Nuys, Ca 91406 USA
Telephone No. 888-582-8870
Contact Information:
https://jvcproducts.com
NOTE: For Spanish and French Manual, please visit www.jvcproducts.com/support
NOTA: Para el Manual de Español y Francés, por favor visite www.jvcproducts.com/support
REMARQUE: Pour l’espagnol et Français manuel, s’il vous plaît visitez
www.jvcproducts.com/support

Warning
Caution:
The lightning flash within an equilateral triangle is intended to alert you to the presence
of uninsulated dangerous voltage within the product’s enclosure that may be of
sufficient magnitude to constitute an electric shock to a person or persons.
Important! This symbol alerts you to read and observe important warnings and
instructions on the unit or in this manual.
Notice:
This appliance is not intended for use by persons (including children) with reduced physical sensory or mental
capabilities, unless they are under supervision or instruction concerning use of the appliance by a person
responsible for their safety. Children should be supervised to ensure that they do not damage the appliance.
Important Safety Instruction
1
Thank you for purchasing the TH-S320B Soundbar. Please read this user manual carefully and keep for future
reference.
To reduce the risk of electric shock, do not dismantle the product and do not expose the apparatus
to rain or moisture. No user-serviceable parts inside. Refer servicing to qualified personnel only.
Plug on the power cord is used as disconnect device, the disconnect device shall be easily accessible.
1. To prevent possible hearing damage, do not listen at high volume
levels for prolonged time periods or a sudden high volume level.
2. Do not leave the device unattended. Switch off the device whenever it is not in use.
3. The appliance is not intended to be operated by means of an external remote control system, other than the
branded remote, or as advised in the user manual.
4. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
5. Before operating this system, check the voltage of this system to see if it is identical to the voltage of your
local power supply.
6.
The unit should not be impeded by covering the ventilation opening with items such as newspaper, table-
cloths, curtains etc. Make sure that there are at least 20 cm of space above and at least 5 cm of space on each
side of the unit.
7. The apparatus must not be exposed to dripping or splashing liquids and that objects filled with liquids, such
as vases, must not be placed on the apparatus.
8. To prevent fire or shock hazard, do not expose this equipment to direct heat, rain, moisture or dust.
9. Do not place this unit near any water sources e.g. taps, bathtubs, washing machines or
swimming pools. Ensure that you place the unit on a dry, stable surface.
10. Do not place this unit close to a strong magnetic field. This may damage the system.
11. Do not place the unit on a amplifier or receiver.
12. Do not place this unit in a damp area as the moisture will affect the life of electric components.
13. Do not attempt to clean the unit with chemical solvents as this might damage the finish. Wipe
with a clean, dry or slightly damp cloth.
14. When removing the power plug from the wall outlet, always pull directly on the plug, never pull
on the cord.
15. Depending on the electromagnetic waves used by a television broadcast, if a TV is turned on
near this unit while it is also on, there may be a disturbance on the TV screen. Neither this unit nor
the TV is malfunctioning. If you see such disturbance, keep this unit some distance away from the TV set.
16. The mains plug is used to disconnect the device, the disconnected device should remain readily
operable.

Important Safety Instructions
Read these instructions carefully and follow accordingly.
Do not place this apparatus under running water. It may adversely affect the electronic components inside
Clean only with dry cloth.
Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
Do not install near any heat sources such as radiators, heaters, stoves, or other apparatus (including
amplifiers) that produce heat.
Do not damage the power cord by walking over it or pinching it, particularly at plugs, convenience
receptacles or at the point where they exit from the apparatus.
Only use attachments/accessories specified by the manufacturer.
Unplug this apparatus during lightning storms or when unused for long periods of time.
Ensure the servicing is done by a qualified service personal. Servicing is required when the apparatus
has been damaged in any way, for example, when the power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture.
Does not operate normally, or has been dropped and is not functioning properly.
The AC plug is used to disconnect the device; the disconnected device should remain readily
operable. In order to disconnect the apparatus from the AC power completely, the AC plug must be
removed from the AC outlet completely.
•Remove the Sound bar from the carton and remove all packing material from the Sound bar. Save the
packing material, if possible, in case the Sound bar needs to be serviced or transported. The original carton
and packing material is the only safe way to pack your Sound bar to protect it from damage in-transit.
Preparation for Use
2
Unpacking and Set Up
Bluetooth SIG, Inc. and any use of such marks by AJS Electronics Limited is under license.
Other trademarks and trade names are those of their respective owners.
by E & S International Enterprises, Inc. “JVC” is the trademark of JVCKENWOOD
Corporation, used by such company under license."

This model is equipped with non-skid rubber 'feet' to prevent the product from moving when you operate
the controls. These 'feet' are made from non-migrating rubber material specially formulated to avoid
leaving any marks or stains on your furniture. However certain types of oil based furniture polishes,
wood preservatives, or cleaning sprays may cause the rubber 'feet' to soften, and leave marks or a
rubber residue on the furniture. To prevent any damage to your furniture we strongly recommend that
you purchase small self-adhesive felt pads, available at hardware stores and home improvement center
everywhere, and apply these pads to the bottom of the rubber 'feet' before you place the unit.
This sound bar is designed to operate on normal AC Power source. For India, it works on a normal
operating voltage of 110V-240V～50hz/60Hz. Do not attempt to operate the Sound bar on any other
power source. You could cause damage to the Sound bar that is not covered by your warranty.
lmportant Notes
• This sound bar was especially developed for LED/LCD/Plasma TV's: It should not be used in
combination with CRTTV's (Cathode Ray Tube TV's) in order to avoid image interference.
• Safety and operating instruction manual should be retained for future reference.
• The apparatus should not be exposed to dripping, splashing or placed in a humid atmosphere
such as a bathroom.
• Do not install the product in the following areas:
• Places exposed to direct sunlight or close to radiators.
• On top of other stereo equipment that radiate too much heat -Blocking ventilation or in a dusty area.
• Areas where there is constant vibration.
• Humid or moist places.
• Do not place near candles or other flames.
• Operate the product only as instructed in this manual.
• Before turning on the power for the first time, make sure the sound bar is plugged to power outlet.
• For safety reasons, do not remove any covers or attempt to gain access to the inside of the
product. Refer any servicing to qualified personnel.
• Do not attempt to remove any screws, or open the casing of the unit; there are no user
serviceable parts inside. Refer all servicing to qualified service personnel.
3
Protect Your Furniture
Power Source
•Place your Sound bar on a level surface such as a table, desk or shelf, conveniently nearby an AC outlet,
out of direct sunlight, and away from sources of excess heat, dirt, dust, moisture, humidity or vibration.
•Unwind the Line cord connecting the AC adapter and extend it to its full length.

Product Diagram
4
DISPLAY
OPTICAL
AUX
POWER/STANDBY
VOL-
VOL+
DC IN
HDMI(ARC)
1
2
3
4
5
6
6
7
8
9
10
INPUT
USB
8
9
7
10
88

5
Please insert the batteries as indicated below
A: Remove the battery cover
B: Insert 2*AAA batteries according to the markings inside battery slot
C: Close the battery cover
A B C
REMOTE CONTROL BATTERY REPLACEMENT
REMOTE CONTROL
2. Pair button: Press pair button more than 2 seconds to conect and disconect last device.
3. VOL+: to increase the volume.
4. Previous button: Skip to the previous track in USB & BT mode.
5. VOL-: to decrease the volume.
7. Treble-up button: to increase the treble volume.
8. Treble-down button: to decrease the treble volume.
10. Source input button: to select an input source for playback:
Hd: sound from connected HDMI ARC device
bt: sound from connected Bluetooth drive.
AU: sound from connected Auxiliary Line-in
OP: Sound from connected Digital Optical device.
US: sound from connected USB driver
11. Next button: Skip to the next track in USB & BT mode.
12. Play/Pause button: Start, pause or resume play in USB & BT mode.
Reset button: Press and hold the button more than 2 seconds to restore factory default settings.
15. Bass+ button: To increase the bass.
16. Bass- button: To decrease the bass.
RM-STHS560

6
• When the unit is mounted on a wall, point the remote control at the remote control sensor on the bellowed panel.
The provided Remote Control allows the unit to be operated from a distance.
• Even if the Remote Control is operated within the effective range 26.2 feet (8m), remote control operation may be
impossible if there are any obstacles between the unit and the remote control.
• If the Remote Control is operated near other products which generate infrared rays, or if other remote control
device using infra-red rays are used near the unit, it may operate incorrectly. Conversely, the other products
may operate incorrectly.
• Improper or incorrect use of batteries may cause corrosion or battery leakage, which could cause fire,
personal injury or damage to property.
• Only use the battery type indicated in this manual.
• Do not install new batteries with used ones and do not mix different types of batteries.
• Do not dispose of used batteries as domestic waste. Dispose of them in accordance with local regulations.
• Do not drop the remote control.
• Do not allow anything to impact the remote control.
• Do not spill water or any liquid on the remote control.
• Do not place the remote control on a wet object.
• Do not place the remote control under direct sunlight or near sources of excessive heat.
• Remove the battery from the remote control when not in use for a long period of time, as corrosion or battery
leakage may occur and result in physical injury. And /or property damage, and /or fire.
• When the battery is exhausted, the remote control will not be functional.
Handling the battery
CAUTION
Risk of explosion if the battery is replaced by an incorrect type
Handling the Remote Control
Operating range of the remote control
Remote control sensor
Within 8 m (26.2 feet )
45 45
88

Follow below steps to mount the sound bar on the wall
Step 1: Paste 2 pieces of EVA foam (with holes) on the two wall brackets aligning at the hole position of
wall brackets.
Step 2: Remove 4 screws from the rear housing of sound bar, then insert the 4 screws over the wall bracket
screw holes aligning (on the side of EVA foam pasted), and then fasten the screws again.
Step 3: According to the two hanging wall positions on the rear of soundbar, calibrate and mark the two
hanging brackets hole position on the wall. Then drill two holes on the wall, firstly insert two
expansion plastic screws on the wall, then fasten the hanging screws into expansion screw holes.
Step 4: Then Paste the 2 pieces of EVA foam (without holes) on the two wall brackets downward. Then
place the hollow cross in the center of the bracket against the screws on the wall and hang the
sound bar on the wall finally.
7
Table Placement
•Place the sound bar horizontally on a solid surface such as a TV
unit or shelves and align it centrally with the TV screen.
•For best sound output and good airflow around the soundbar,
place your soundbar and subwoofer as shown on the right.
Positioning the Sound Bar
Wipe off any dirt such as oil on the adhesive surface of the sound bar before adhering.
Make sure that the adhesive is securely attached.
When peeling off the release paper of the double-sided tape, be careful not to get dirt such as finger oil
on the adhesive surface.
Be careful of deterioration of double-sided tape due to storage conditions.
Please note
Note: Brackets, EVA foam, and screws included in the box

Setting the Soundbar
OPERATE INSTRUCTIONS
1: Plug in the power cord of Subwoofer and sound bar, and the display will light up (Standby mode)
2: Switch on the soundbar by using STANDBY button on soundbar or by using POWER button on remote.
After switching on, the default input mode will appear on display
3: lnput mode can be changed by pressing the STANDBY button again or by using the INPUT button on remote
4:Below are input mode names appearing in the soundbar display:
-Bluetooth Pairing mode, -AUX mode, -Optical mode, -HDMI TV(ARC) mode, -USB mode,
backing paper
EVA foam
(with holes)
included
EVA foam
(without holes)
included
8
When mounting the soundbar on a wall, all installation musted be performed in right way. The customer must
never attempt to install it without authorization. Improper or inadequate installation may cause the sound bar
to fall so as to result in personal injury.
To prevent the sound bar from falling, attach it to a wall constructed of drywall (plasterboard)
Make sure that commercially available screws are used so that can support the weight of the installation.
Fix the cables in place where they will not become loose. If your foot or hand accidentally gets caught on
a loose cable, the sound bar may fall.
Do not lean on the sound bar or apply excessive force to the top of the sound bar, which may cause it to fall.
Mount the unit on a wall
52.55CM / 20.7 IN
Bracket
width
2CM
0.75 IN

9
Playing Audio via BT Connection
1.Turn on the sound bar and then short-press the STANDBY button on sound bar or POWER button on remote
control and switch the sound bar to Bluetooth mode and LED display " " on the sound bar will flicker in the
bluetooth pairing mode with a double deep sound.
2. Turn on Bluetooth of your device, search for "
TH-S320B " on your Bluetooth list, and then select Bluetooth
connection.
3. When successfully paired, you will hear a tone and the " ”on the screen stops flickering. Then the music on
your phone or other compatible device that you selected can be played on the sound bar.
4. Use the volume buttons on the sound bar or on the remote controller to adjust the volume.
5. The remote controller includes Bluetooth mode playback controls. Press and hold PAIR button on the remote
controller more than two seconds to disconnect paired Bluetooth device or connect back last disconnected
Bluetooth device.
6. If you wish, you can change the audio settings by using the relevant buttons on the remote controller.
.
Powering On/Off
5. Put adapter plug of the sound bar into a wall outlet, it will automatically enter standby mode.
6. Short-press the STANDBY button to turn on the sound bar.
7. To turn off, press the STANDBY button on remote control or unplug
adapter from wall outlet.
1. The unit will automatically switch to standby mode when no audio input is received for 20 minutes.
The soundbar will wake up from standby mode when any button is pressed or source input is received.
2. If the TV or the external unit is disconnected, switch it off
• To switch the unit off completely, remove the adapter from the mains socket.
• Please turn the unit off completely to save energy when not in use.
3. The screen will be turned off for around 10 seconds without any operation, when pressing the buttons
on the sound bar or on remote control or the using iphone's volume increase or decrease, the display will
be waken up again.
Auto Standby
Volume value: the volume value is 00-32, and the factory set value is "10". It has last volume memory function.
Mode switching: BT/OP/HD/AU/US connection mode can be switched; meanwhile the selected mode will be
displayed on the display screen.

10
Notes:
1. In Bluetooth mode, the remote can control music play/pause or select previous or next track. PREV/NEXT/
PLAY & PAUSE button only work in Bluetooth and USB mode; they have no function in other modes.
2. The above pairing procedure doesn’t need to be repeated with the same connected device once paired.
3. If the connected device is switched off or manually disconnected, the sound bar will automatically enter
pairing mode.
4. If the connected device is moved away from wireless range (up to 10 meters) of the sound bar, then it will
get disconnected, and it will successfully connect to the device once you re-enter Bluetooth range.
To connect to other devices, repeat the above pairing steps.
5. If a Bluetooth device has been connected before, the sound bar will connect to the last connected device.
Unpair this connection to connect a new device.
6. There is no automatic shutdown in pairing mode. The sound bar will remain in pairing mode even if no device
is paired, so switch it off if not in use.
Audio input(Aux)Connection
Playing Audio via USB Port
- The sound bar automatically switches to USB input mode with the LED display “ ” when a USB flash
drive is inserted.
-When a USB flash drive is inserted and sound bar is power on, then short-press the INPUT key on remote
controller or STANDBY button on sound bar to switch to USB input mode (in case it doesn’t change automatically)
with LED display lighting up “ ”. And music in the USB will be automatically played.
-This mode cannot be used on the sound bar until an USB flash drive is connected.
1. Ensure that your USB flash drive contains MP3 audio file (other file types are not supported.)
2. Connect the USB flash drive to the USB port on the sound bar or by USB adapter (or your own USB extension
cable connected to the USB port) and the music will be played automatically.
3. The remote control includes USB input mode playback controls.
• Use a 3.5mm to 3.5mm audio cable (not included) to connect the PC, tablet, smartphone, TV’s headphone
socket to the AUX socket on the soundbar.
• Use a RCA to 3.5mm audio cable (included) to connect the Blue Ray DVD Player / TV’s audio output
sockets to the AUX socket on the soundbar.
• Then short-press the power button on the sound bar or on the remote controller to switch to audio input
mode with LED display lighting up .
• In this mode, playback can only be controlled on your connected device
Note: For some computer, you may need to access the audio control panel to manually set the soundbar
as above picture.

11
Optical Mode
HDMI(ARC) Mode
-Remove the cap of optical cable (keep the cap for the future use); check the direction of the plug. Connect the sound
bar and TV with the optical cable.
-Use this mode to play music from a TV with optical digital output on the sound bar. In TV sound settings, select the sound
bar optical connection (output for audio). When the optical cable is connected, the TV audio output is set to PCM format.
-The TV must have an optical digital output. Use the supplied optical cable to make the connection as follows:
1. Connect the optical cable to the optical digital output of your TV.
2. Connect the optical cable to the optical digital input of your sound bar.
3. Switch on the TV set and the sound bar. Set the connected TV to “PCM Stereo”. Set the audio output mode
as <automatic> or <decoded output as PCM state>.
4. Start playing on the TV.
5. Press “INPUT” button on the remote control or “STANDBY” button on the sound bar to select - OPTICAL mode.
6. Use the volume buttons to adjust the volume to your requirements.
7. You can also change the audio settings by using the relevant buttons on the remote control.
1. The sound bar supports HDMI(ARC) with audio return channel (ARC). You can hear the TV audio through your
sound bar by using a single HDMI(ARC) cable. But on condition that your TV is ARC compliant.
2. Using a high speed HDMI(ARC) cable, connect the HDMI(ARC) connector on the sound bar to the
HDMI(ARC) connector on the TV. The HDMI(ARC) connector on the TV might be labeled differently. For
details, see the user manual of your TV.
3. When HDMI(ARC) is connected, TV sound setting in “sound output” mode should be set as <external PCM Stereo>,
in addition, digital audio output mode should be set as <automatic> or <decoded output as PCM state>. When the
HDMI(ARC) cable is connected, the TV digital audio output is set as PCM format. Then start playing music on the TV.
4. Press “INPUT” button on the remote control or “STANDBY” button on sound bar to select - HDMI(ARC) mode.
Different TV might be different setting, please refer to your TV User Manual.
5. Use the volume buttons to adjust the volume to your requirements.
6. You can also change the audio settings by using the relevant buttons on the remote control.
1. When connecting a device such as a TV/Set-top box/DVD/ game console with HDMI(ARC) cable, set the audio
output mode of the device to PCM mode <digital HDMI (ARC) output>.
2. The TV is connected to a HDMI(ARC) port with
sound bar. Different TVs might have different
setup menus, but the operation approach is the same.
3. If needs to connect set-up box meanwhile,
please firstly connect the HDMI(ARC) connector
and paired to the sound bar. Then connect the set-top box.
1. When connecting a device such as a TV/Set-top
box/ DVD/ game console with optical cable, set the
audio output mode of the device to PCM mode
(digital optical output).
2. Do not bend the optical cable, otherwise the
cable inside will be damaged.
Optical lnput
Optical Output
HDMI(ARC) lnput
HDMI(ARC) Output

12
Another input source is selected.
The mute function is activated.
The volume of sound bar or TV/other device
is adjusted too low.
The power cable of the unit is not
connected properly.
Input jacks on a playback device are connected.
There is no sound
output from sound
bar.
Signals that the sound bar cannot playback
when being input.
The sound is distorted
or echoed. TV volume is not muted. If you play audio from TV through the sound bar, make sure that the TV is muted.
The volume decreases
when the unit is turned
on.
The automatic volume adjustment function is
activated. To prevent excessive loudness, the
unit automatically controlls its volume within
a certain level when the unit is turned on.
Turn up the volume as required.
A device cannot
connect the sound
bar or the unit cannot
be connected to a
Bluetooth device.
Bluetooth function of the device is not activated,
not paired or connected correctly.
A device emitting electromagnetic waves
(such as a microwave oven, a wireless
device and so on) may be placed nearby.
Do not use this unit near devices that emit
electromagnetic waves.
Restart the sound bar and try pairing again. You have
not enabled the Bluetooth function of the device; see
the user manual of the device on how to enable the
function and correctly connected the device. The sound
bar is already connected with another Bluetooth device.
Disconnect the connected device, and then try again.
The unit is out of the operating range. Use the remote control within the operating range.
The batteries are weak. Replace with new batteries.
The remote control sensor of the sound bar
is exposed to direct sunlight or strong lighting.
Adjust the lighting angle or reposition the sound bar.
Make sure our product cannot be used in sunlight.
The unit cannot be
operated by using
the remote control.
The TV cannot be
operated by using the
TV’s remote control.
The unit is blocking the TV’s remote
control sensor.
Position the unit so that it does not obstruct the TV’s
remote control sensor.
When sound bar and TV or other devices are
connected by an audio cable through TV (ARC)
port output, Select the correct audio input and
output. Make sure the digital audio output setting
on the playback device to PCM format. Since the
output format of our sound bar is PCM, if it is used,
the decoding format of TV or other devices will be
adjusted to PCM state.
Make sure that the power cable of the unit is
connected to an AC wall outlet securely.
Connect the input jack on the sound bar and
the output jack on the playback device.
Select an appropriate input source.
Cancel the mute function.
Increase the volume level on sound bar or
by remote control or on TV.
PROBLE/TROUBLE POSSIBLE CAUSE SOLUTION
Noise is heard. The sound bar is too close to another
digital or high-frequency device. Move those devices away from the sound bar.
Bluetooth is not selected as the input source.
Select Bluetooth as the input source.
The unit is connected to a different Bluetooth
device.
The unit is too far away from the Bluetooth device.
Un-pair the Bluetooth device that is currently connected
and pair with the desired Bluetooth device.
Move the Bluetooth device closer to this unit.
The Bluetooth device that you are using
may not support the protocol. Use a Bluetooth device that supports the protocol.
The connection profile registered in the
Bluetooth device may not be functioning
correctly for some reason.
Delete the connection profile in the Bluetooth
device and then connect the Bluetooth device to
this unit.

13
PROBLE/TROUBLE POSSIBLE CAUSE SOLUTION
Sound quality of audio
play from a connected
Bluetooth device is
poor and connection
is not stable.
The Bluetooth reception is poor.
Move the device closer to the sound bar,
or remove any obstacle between the device and
the sound bar.
The volume on the Bluetooth device may
be too low.
Raise the volume on the Bluetooth device.
Bluetooth is not selected as the input source. Select the Bluetooth as the input source.
Playback on the device has not been performed. Perform playback on the device.
The sound output on the Bluetooth
device may not be set to this unit.
Select this unit as the output device on
the Bluetooth device.
The connection to the Bluetooth device
was cut off. Connect with the Bluetooth device one more time.
Move the Bluetooth device near this unit.
The unit may be too far away from the
Bluetooth device.
Do not use this unit near device that emit
electromagnetic waves.
1. Make sure that the user connected TV and
sound bar by a 19-core HD ARC cable.
2. The sound bar and TV are connected through
TV (ARC) port output; make sure that the TV is
ARC compliant.
3. Set the TV to HDMI ARC (CEC).
Set the audio output mode of TV to PCM format.
(Or refer to your TV user manual)
A device emitting electromagnetic waves
(such as a microwave oven, a wireless
device and so on) may be placed nearby.
No qualified HDMI TV (ARC) cable is used &
No signal is input on sound bar & connection
and operation method is not correct.
No sound can be heard
or sound breaks
(Bluetooth mode)
There is no sound from
sound bar -
HDMI TV (ARC) Mode
1. Try to replace another OPTICAL cable to connect.
2. Set your TV audio output to PCM format.
(Pls refer to your TV user manual)
OPTICAL cable maybe damaged & No signal
is input on sound bar & connection and
operation method is not correct.
There is no sound from
sound bar
(OPTICAL Mode)
Make sure that USB flash drive contains MP3 files
because other file types are not support.
Switch the input mode once again, then
playback again.
USB file type is not support & Sound bar
doesn’t switch to USB input mode
automatically when USB is inserted.
There is no sound from
sound bar (USB mode)

14
Specifications
Drivers
Audio Output Power
Frequency Response
Signal-to-Noise Ratio
lmpedance
Power lnput
Bluetooth Operating Range
Dimensions
Technology
Model
2.5"*2
150W Peak Power
70Hz-20KHz
66dB
8Ω*2
DC 24V 1.75A
Version: 5.0 Range:up to 10m
74H*87D*750L mm
BT/USB/AUX/HDMI(ARC)/OPT
TH-S320B
Package Contents
Soundbar X 1 Remote Control X 1
Line in to RCA Cable X 1 User Manual X 1 Remote control batteryWall Mounting
Bracket Sets X 1

This product is manufactured, distributed, serviced and warranted exclusively by E & S International Enterprises, Inc.
“JVC” is the trademark of JVCKENWOOD Corporation, used by such company under license.
To obtain a warranty service, please call 1 [phone] or send an email to
[e-mail]

Claims and Dispute Resolution
RUSSELL DISTRIBUTION COMPANY, LLC AND YOU AGREE THAT ALL CLAIMS OR DISPUTES ARISING IN
ANY WAY FROM THIS LIMITED WARRANTY OR THE SALE, CONDITION OR PERFORMANCE OF THE
PRODUCT, WHETH- ER BASED IN CONTRACT, TORT, STATUTORY, FRAUD, MISREPRESENTATION OR
ANY OTHER LEGAL THEORY, AND ALL CLAIMS THAT ARE SUBJECT OFA PURPORTED CLASS ACTION
LITIGATION THAT YOU ARE NOT A MEMBER OF THE CERTIFIED CLASS, SHALL BE RESOLVED
THROUGH ARBITRATION AS PROVIDED FOR HEREIN, OR IN SMALL CLAIMS COURT, AND NOT BY A
TRIAL BY JURY. YOU WAIVE THE RIGHT TO A TRIAL BY JURY, AND WAIVE THE RIGHT TO PARTICIPATE
IN CLASS ACTIONS ARISING FROM OR RELATING TO ANY AND ALL CLAIMS AND DISPUTES WITH
RussellDistribution. YOU AGREE THAT YOU MAY ARBITRATE CLAIMS AGAINST Russell Distribution ONLY
IN YOUR INDIVIDUAL CAPACITY AND NOT AS A PLAINTIFF, A CLASS REPRE- SENTATIVE, OR CLASS
MEMBER IN ANY CLASS OR REPRESENTATIVE PROCEEDING. THIS AGREEMENT EVIDENCES A
TRANSACTION IN INTERSTATE COMMERCE, AND THUS THE FEDERAL ARBITRATION ACT GOVERNS
THE INTERPRETATION AND ENFORCEMENT OF THIS PROVISION. THIS PARAGRAPH SHALL SURVIVE
THE TERMINATION OF THIS LIMITED WARRANTY.
RUSSELL DISTRIBUTION REQUIRES THAT YOU ARBITRATE YOUR CLAIMS AGAINST RUSSELL
DISTRIBUTION PURSUANT TO THE ARBITRATION DESCRIBED BELOW PRIOR TO YOUR EXERCISE OF
YOUR RIGHTS PURSUANT TO TITLE I OF THE MAGNUSON-MOSS WARRANTY ACT. TITLE I OF THE
MAGNUSONMOSS WARRANTY ACT DOES NOT REQUIRE YOU TO PURSUE RIGHTS AND REMEDIES
AVAILABLE TO YOU THAT ARE NOT PROVIDED BY TITLE I OF THE MAGNUSON- MOSS WARRANTY ACT.
Any such arbitration shall not be combined or consolidated with a claim or dispute involving any other person's or
entity's product or claim or dispute, and specifically, without limitation of the foregoing, shall not under any
circumstances proceed as part of a class action or class arbitration. If you intend to seek arbitration you must first
email Russell Distribution at [e-mail] a notice of dispute, at least thirty (30) days in advance of
initiating the arbitration. The notice must include: (i) a description of your claim and the basis of the dispute; and
(ii) a description of the relief you are seeking. If Russell Distribution and you do not reach an agreement to
resolve the claim within thirty (30) days after Russell Distribution receives your notice, you or Russell Distribution
may commence an arbitration proceeding.
The arbitration will take place in Los Angeles, California or a mutually agreed upon location. Arbitration shall be
administered by JAMS, or alternatively a mutually agreed upon arbitrator or arbitration service, under the
applicable commercial arbitration rules for JAMS or the mutually agreed upon arbitration service, excluding any
rules or procedures governing or permitting class actions. The arbitrator, and not any federal, state or local court
or agency, shall have exclusive authority to resolve all disputes arising out of or relating to the interpretation,
applicability, enforceability or formation of this Limited Warranty, including, but not limited to any claim that all or
any part of this Limited Warranty is void or voidable, or whether a claim is subject to arbitration. The arbitrator
shall be empowered to grant whatever relief would be available in a court under law or in equity. The arbitrator's
award shall be written. and binding on the parties and may be entered as a judgment in any court of competent
jurisdiction. To the extent the filing fee for the arbitration exceeds the cost of filing a lawsuit; Russell Distribution
will pay the additional cost. The arbitration rules also permit you to recover attorney's fees in certain cases. The
parties understand that, absent this mandatory provision, they would have the right to sue in court and have a jury
trial. They further understand that, in some instances. the costs of arbitration could exceed the costs of litigation
and the right to discovery may be more limited in arbitration than in court.
This arbitration provision also applies to claims and disputes by you, the purchaser of the Product. and all those
in privity with you, including your family members, beneficiaries and assigns against Russell Distribution
subsidiaries and affiliates and any person or entity that licensed, supplied, sold or distributed the Product and
each of their officers, employee, representatives, licensors/licensees, Agents, beneficiaries, predecessors in
interest, successors, and/or assigns. You may opt out of this dispute resolution procedure by providing notice to
Russell Distribution no later than thirty (30) calendar days after the date of the first consumer purchaser's
purchase of the Product. To opt out you must send notice by e-mail to suppor[email protected]. The opt-out notice
must include (a) your name, email address. mailing address and phone number; (b) the date on which the
product was purchased; (c) the product model name or model number; and (d) the Serial Number. Opting out of
this dispute resolution procedure will not affect the coverage of the Limited Warranty in any way, and you will
continue to enjoy the benefits of the Limited Warranty. If you opt-out of these arbitration provisions, Russell
Distribution also will not be bound by them.

TH-S320B
Use our Customer Service to assist you in setting up your new product.
Visit: or Call:
Notre personnel d'assistance expérimenté est là pour vous aider!
nouveau produit
Visitez: or Appelez:
Audio Home Theater System
2.0 CH Soundbar
