REVISION INFORMATION
DVD DIGITAL CINEMA SYSTEM
COPYRIGHT © 2010 Victor Company of Japan, Limited MB713-R003
2010/06
TH-G31A, TH-G31B, TH-G31E, TH-G31EN,
TH-G31UG, TH-G31UH, TH-G31UN, TH-G31UX,
TH-G41A, TH-G41UX, TH-G61A, TH-G61E,
TH-G61EN, TH-G61UH, TH-G61UN, TH-G61UX
 OVERVIEW
Add TH-G31UG.
 DETAILS
COVER SECTION
Title Line No.MB713<Rev.002> No.MB713<Rev.003> Description
Revision Rev.002 Rev.003
Issue Date 2010/01 2010/06
Model No. TH-G31A, TH-G31B, TH-G31E, TH-G31EN,
TH-G31UH, TH-G31UN, TH-G31UX, TH-G41A,
TH-G41UX, TH-G61A, TH-G61E, TH-G61EN,
TH-G61UH, TH-G61UN, TH-G61UX
TH-G31A, TH-G31B, TH-G31E, TH-G31EN,
TH-G31UG, TH-G31UH, TH-G31UN, TH-G31UX,
TH-G41A, TH-G41UX, TH-G61A, TH-G61E,
TH-G61EN, TH-G61UH, TH-G61UN, TH-G61UX
STANDARD SCHEMATIC DIAGRAMS
Schematic Diagram
Diagram Name No.MB713<Rev.002> No.MB713<Rev.003> Description
Menu FRONT JACK CIRCUIT DAIAGRAM FRONT JACK CIRCUIT DIAGRAM
Exploded View
Diagram Name No.MB713<Rev.002> No.MB713<Rev.003> Description
Menu Packing materials and accessories(TH-G41/G31) Packing materials and accessories(TH-G31/G41)

2 (MB713-R003)
PARTS LIST
MODEL No. LIST
Model No. No.MB713<Rev.003>
TH-G31A 01
TH-G31B 02
TH-G31E 03
TH-G31EN 04
TH-G31UG 05
TH-G31UH 06
Model No. No.MB713<Rev.003>
TH-G31UN 07
TH-G31UX 08
TH-G41A 09
TH-G41UX 0A
TH-G61A 0B
TH-G61E 0C
Model No. No.MB713<Rev.003>
TH-G61EN 0D
TH-G61UH 0E
TH-G61UN 0F
TH-G61UX 10
General assembly [M1MM]
Part No.
!Symbol or <Rev.002> <Rev.003> Part Name Description Qty Models
M1MM 9 LG-5900R-D004K LG-5900R-D004G FAN 1 01,02,03,04,05,06,07,08,09,0A,
0B,0C,0D,0E,0F,10
M1MM 9 or LG-5900R-D004G LG-5900R-D004K FAN 1 01,02,03,04,05,06,07,08,09,0A,
0B,0C,0D,0E,0F,10
M1MM 33 ------------ LG-EBR63693207 MAIN BOARD ASSY (Addition) 1 0F
M1MM 33 ------------ LG-EBR63693228 MAIN BOARD ASSY (Addition) 1 10
Electrical parts list Main board [01]
Part No.
!
Symbol or <Rev.002> <Rev.003> Part Name Description Qty Models
01 IC104 ------------ LG-0IPMGKE022B IC (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,
0C,0D,0E,0F,10
01 IC104 LG-0IPMGKE022B ------------ IC (Deletion) 1 0B,10,0F,09,0A,01,08,07,0E,06
01 IC104 LG-EAN60658301 ------------ IC (Deletion) 1 0C,0D,02,03,04
01 IC104 or LG-0IPMGKE022B LG-EAN60658301 IC 1 02,03,04,0C,0D
01 IC106 ------------ LG-0IPMGKE047A IC (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,
0C,0D,0E,0F,10
01 IC106 LG-0IPMGKE047A ------------ IC (Deletion) 1 0B,10,0F,09,0A,01,08,07,0E,06
01 IC106 LG-EAN42369201 ------------ IC (Deletion) 1 0C,0D,02,03,04
01 IC106 or LG-0IPMGKE047A LG-EAN42369201 IC 1 02,03,04,0C,0D
01 Q403 LG-0TRAU80008A KTA1504/G/-X BIPOLAR TR 1 01,02,03,04,05,06,07,08,09,0A,0B,
0C,0D,0E,0F,10
01 Q403 or KTA1504/G/-X LG-0TRAU80008A BIPOLAR TR 1 01,02,03,04,05,06,07,08,09,0A,0B,
0C,0D,0E,0F,10
01 Q405 LG-0TRAU80008A KTA1504/G/-X BIPOLAR TR 1 01,02,03,04,05,06,07,08,09,0A,0B,
0C,0D,0E,0F,10
01 Q405 or KTA1504/G/-X LG-0TRAU80008A BIPOLAR TR 1 01,02,03,04,05,06,07,08,09,0A,0B,
0C,0D,0E,0F,10
PTB board [03]
Part No.
!
Symbol or <Rev.002> <Rev.003> Part Name Description Qty Models
03 C2D6 ------------ LG-0CH1104H946 C CAPACITOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,
0C,0D,0E,0F,10
03 C2D6 LG-0CH1104H946 ------------ C CAPACITOR (Deletion) 1 0C,0D,0B,10,0F,09,0A,02,03,04,01,
08,07
03 C2D6 LG-0RH0000D622 ------------ CHIP RESISTOR (Deletion) 1 0E,06
03 C2D6 or LG-0CH1104H946 LG-0RH0000D622 CHIP RESISTOR 1 05,06,0E
Packing and accessories G61 [M3MM]
Part No.
!Symbol or <Rev.002> <Rev.003> Part Name Description Qty Models
M3MM A19 LG-EAA56672101 LG-5010R-L004C AM ANTENNA 1 0B,0E,0F,10
M3MM A19 or LG-5010R-L004C LG-EAA56672101 AM ANTENNA 1 0B,0E,0F,10
Packing and accessories G31/G41 [M4MM]
Part No.
!Symbol or <Rev.002> <Rev.003> Part Name Description Qty Models
M4MM A1 ------------ LG-AFN73972701 INST ASSY (Addition) 1 05
M4MM A19 LG-EAA56672101 LG-5010R-L004C AM ANTENNA 1 01,05,06,07,08,09,0A
M4MM A19 or LG-5010R-L004C LG-EAA56672101 AM ANTENNA 1 01,05,06,07,08,09,0A

(MB713-R003) 3

Victor Company of Japan, Limited
Home Entertainment Business Division Personal AV Operation 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan
(MB713-R003) Printed in Japan
No.MB713<Rev.002> VSE

REVISION INFORMATION
DVD DIGITAL THEATER SYSTEM
COPYRIGHT © 2010 Victor Company of Japan, Limited MB712-R002
2010/02
TH-G51J, TH-G41J, TH-G41C,
TH-G31J, TH-G31C, TH-G61C
 OVERVIEW
Add TH-G61C.
 DETAILS
COVER SECTION
Title Line No.MB712<Rev.001> No.MB712<Rev.002> Description
Revision Rev.001 Rev.002
Issue Date 2009/09 2010/02
Model No. TH-G31C, TH-G31J, TH-G41C,
TH-G41J, H-G51J
TH-G31C, TH-G31J, TH-G41C,
TH-G41J, TH-G51J, TH-G61C
Cover Illustration ILLUSTRATION(mb712_0001.png) ILLUSTRATION(mb712_0001.png)
Category Audio/Video Systems Division Home Entertainment Business Division Personal
AV Operation
Copyright COPYRIGHT (C) 2009 Victor Company of Japan,
Limited
COPYRIGHT (C) 2010 Victor Company of Japan,
Limited
SPECIFICATION 192 - TH-G61
193 - General
194 - Power supply
120 V ~ 60 Hz
195 - Power consumption
130 W
196 - Net Weight
3.6 kg
197 - External dimensions (W × H × D)
430 × 76 × 317 mm
198 - Operating conditions
Temperature: 5°C to 35°C, Operation status:
Horizontal

2 (MB712-R002)
Title Line No.MB712<Rev.001> No.MB712<Rev.002> Description
199 - Operating humidity
5% to 85%
200 - Laser
Semiconductor laser, wavelength 650 nm
201 - CD/DVD
202 - Video system
NTSC
203 - Frequency response (audio)
140 Hz to 20 kHz *
204 - Signal-to-noise ratio (audio)
More than 75 dB (1 kHz, 20 kHz LPF/A-Filter) *
205 - Dynamic range (audio)
More than 75 dB *
206 - Harmonic distortion (audio)
0.5 % (1 kHz, at 1W position) (20 kHz LPF) *
207 - Video
208 - Video output
1.0 V (p-p), 75 , negative sync., RCA jack ×
1
209 - COMPONENT VIDEO OUT
(Y) 1.0 V (p-p), 75 ohms, negative sync, RCA
jack × 1
210 - (PB)/(PR) 0.7 V (p-p), 75 ohms, RCA jack × 1
211 - HDMI OUT
480i/480p/720p/1080i/1080p
212 - Tuner
213 - FM
Tuning Range
87.5 - 108.0 MHz
214 - Intermediate Frequency
10.7 MHz
215 - Signal-to Noise Ratio
60 dB (Mono) *
216 - Frequency Response
140 - 10,000 Hz *
217 - Amplifier
218 - Stereo mode
155 W + 155 W (4 at 1 kHz, THD 10 %)
219 - Surround mode(* Depending on the sound
mode settings and the source, there may be
no sound output.)
Front
155 W + 155 W (THD 10 %)
220 - center*
155 W
221 - Surround*
155 W + 155 W (4 at 1 kHz, THD 10 %)
222 - Subwoofer*
225 W (3 at 70 Hz, THD 10 %)
223 - Inputs
AUDIO IN, OPTICAL IN, AUX IN, iPod

(MB712-R002) 3
Title Line No.MB712<Rev.001> No.MB712<Rev.002> Description
224 - Outputs
MONITOR OUT, HDMI OUT, COMPONENT
VIDEO OUT
225 - Speakers
226 - Front Speaker
Type
2 Way 3 Speaker
227 - Impedance
4 
228 - Frequency Response
80 - 18000 Hz
229 - Sound Pressure Level
83 dB/W (1m)
230 - Rated Input Power
155 W
231 - Max. Input Power
310 W
232 - Net Dimensions (W × H × D)
280 × 1201 × 280 mm
233 - Net Weight
4.4 kg
234 - Center speaker
Type
1 Way 1 Speaker
235 - Impedance
4 
236 - Frequency Response
120 -18000 Hz
237 - Sound Pressure Level
83 dB/W (1m)
238 - Rated Input Power
155 W
239 - Max. Input Power
310 W
240 - Net Dimensions (W × H × D)
301 × 118 × 83 mm
241 - Net Weight
0.9 kg
242 - Rear Speaker
Type
1 Way 1 Speaker
243 - Impedance
4 
244 - Frequency Response
120 -18000 Hz
245 - Sound Pressure Level
83 dB/W (1m)
246 - Rated Input Power
155 W
247 - Max. Input Power
310 W

4 (MB712-R002)
Title Line No.MB712<Rev.001> No.MB712<Rev.002> Description
248 - Net Dimensions (W × H × D)
311 × 209 × 83 mm
249 - Net Weight
0.78 kg
250 - Passive Subwoofer
Type
1 Way 1 Speaker
251 - Impedance
3 
252 - Frequency Response
40 - 1500 Hz
253 - Sound Pressure Level
82 dB/W (1m)
254 - Rated Input Power
225 W
255 - Max. Input Power
450 W
256 - Net Dimensions (W × H × D)
236 × 435 × 391 mm
257 - Net Weight
5.7 kg
259 - Items with * are measured at Front Speaker
Terminals in STEREO mode
260 - Designs and specifications are subject to change
without notice.
STANDARD SCHEMATIC DIAGRAMS
Exploded View
Diagram Name No.MB712<Rev.001> No.MB712<Rev.002> Description
Menu Packing materials and accessories Packing materials and accessories 1
Menu -Packing materials and accessories 2
mb712_m401.svgz
PARTS LIST
MODEL No. LIST
Model No.No.MB712<Rev.002>
TH-G31C 05
TH-G31J 04
TH-G41C 03
TH-G41J 02
TH-G51J 01
TH-G61C 06
General assembly [M1MM]
Part No.
!Symbol or <Rev.001> <Rev.002> Part Name Description Qty Models
M1MM 1 ------------ LG-AGL72919608 FRONT PANEL ASSY (Addition) 1 06
M1MM 2 ------------ LG-ADV72931908 FRAME ASSY (Addition) 1 06
M1MM 12 ------------ LG-3300RCH001B PLATE (Addition) 1 06
M1MM 12 or ------------ LG-3300R-V127A PLATE (Addition) 2 06
!M1MM 16 ------------ LG-MGC58116629 REAR PANEL (Addition) 1 06

(MB712-R002) 5
Electrical parts list Main board [01]
Part No.
!Symbol or <Rev.001> <Rev.002> Part Name Description Qty Models
01 C3C6 ------------ LG-0CK104CKG6A C CAPACITOR (Addition) 1 06
01 L3D2 ------------ LG-0LCCE00042A BEAD FILTER (Addition) 1 06
01 L3D3 ------------ LG-0LCCE00042A BEAD FILTER (Addition) 1 06
Packing and accessories TH-G61 [M4MM]
Part No.
!Symbol or <Rev.001> <Rev.002> Part Name Description Qty Models
M4MM A1 ------------ LG-AFN73077614 INST ASSY (Addition) 1 06
M4MM A2 ------------ ------------ BATTERY (Addition) 1 06
M4MM A3 ------------ LG-AKB37006111 REMOCON UNIT (Addition) 1 06
M4MM A4 ------------ LG-6850R-PAA5F RCA CABLE (Addition) 1 06
M4MM A5 ------------ LG-EAD60793901 iPod DOC STATION (Addition) 1 06
M4MM A6 ------------ LG-5010R-T001D FM ANTENA (Addition) 1 06
M4MM A7 ------------ LG-EBR61173101 SPK CORD(L) (Addition) 1 06
M4MM A8 ------------ LG-EBR61173102 SPK CORD(R) (Addition) 1 06
M4MM A9 ------------ LG-EBR61173103 SPK CORD (Addition) 1 06
M4MM A10 ------------ LG-EBR61173104 SPK CORD(W) (Addition) 1 06
M4MM A11 ------------ LG-EBR61173105 SPK CORD(RL) (Addition) 1 06
M4MM A12 ------------ LG-EBR61173106 SPK CORD(RR) (Addition) 1 06
M4MM A13 ------------ LG-EAB60819601 CENTER SPK (Addition) 1 06
M4MM A14 ------------ LG-EAB60799901 FRONT SPK (Addition) 2 06
M4MM A15 ------------ LG-EAB60818401 FRONT SPK STAND (Addition) 2 06
M4MM A16 ------------ LG-EAB60799601 FRONT/REAR SPK (Addition) 2 06
M4MM A17 ------------ LG-EAB51655701 SUBWOOFER (Addition) 1 06
M4MM P1 ------------ LG-MAY62017558 CARTON (Addition) 1 06
M4MM P2 ------------ LG-MFZ47047382 CUSHION (Addition) 1 06
M4MM P3 ------------ LG-MFZ61796853 SPK CUSHION A (Addition) 1 06
M4MM P4 ------------ LG-MFZ61796854 SPK CUSHION B (Addition) 1 06
M4MM P7 ------------ LG-MFZ61796850 SPK CUSHION(BTM) (Addition) 1 06
M4MM P8 ------------ LG-MFZ61796851 SPK CUSHION(MDL) (Addition) 1 06
M4MM P9 ------------ LG-MFZ61796852 SPK CUSHION(TOP) (Addition) 1 06

Victor Company of Japan, Limited
Home Entertainment Business Division Personal AV Operation 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan
(MB712-R002) Printed in Japan
No.MB712<Rev.001> VSE

SERVICE MANUAL
COPYRIGHT © 2010 Victor Company of Japan, Limited No.MB713<Rev.002>
2010/1
DVD DIGITAL CINEMA SYSTEM
MB713<Rev.002>20101SERVICE MANUAL
TH-G61E, TH-G61EN, TH-G61A, TH-G61UX,
TH-G61UN, TH-G41A, TH-G41UX, TH-G31B,
TH-G31E, TH-G31EN, TH-G31A, TH-G31UX,
TH-G31UN, TH-G61UH, TH-G31UH
COPYRIGHT © 2010 Victor Company of Japan, LimitedLead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
TABLE OF CONTENTS
1 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14
2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-16
3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-17
4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-20
5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-21
TH-G61
XV-THG61 SP-THG51F
iPod is a trademark of Apple Inc.,
registered in the U.S. and other countries.
iPhone is a trademark of Apple Inc.
TH-G61A, TH-G41
Europe only
SP-THG61C
SP-THG50W
SP-THG61F
SP-THG51F
XV-THG41
TH-G41
SP-THG61C
SP-THG51F
SP-THG51F
SP-THG50W
TH-G31
XV-THG31
SP-THG51F
SP-THG51F
SP-THG61C
SP-THG50W

1-2 (No.MB713<Rev.002>)
SPECIFICATION
EX-A15E/EE TH-G61 Europe and Oceania
General
Power supply 220 - 240 V ~ 50/60 Hz
Power consumption 130 W
Net Weight 3.6 kg
External dimensions (W ×H ×D) 430 ×76 ×317 mm
Operating conditions Temperature: 5°C to 35°C, Operation status: Horizontal
Operating humidity 5% to 85%
Laser Semiconductor laser, wavelength 650 nm
CD/DVD
Video system PAL/NTSC
Frequency response (audio) 140 Hz to 20 kHz*
Signal-to-noise ratio (audio) More than 75 dB (1 kHz, 20 kHz LPF/A-Filter)*
Dynamic range (audio) More than 75 dB*
Harmonic distortion (audio) 0.5 % (1 kHz, at 1W position) (20 kHz LPF)*
Video
Video output 1.0 V (p-p), 75 Ω, negative sync., RCA jack ×1/ SCART (TO TV)
COMPONENT VIDEO OUT (Y) 1.0 V (p-p), 75 ohms, negative sync, RCA jack ×1
(PB)/(PR) 0.7 V (p-p), 75 ohms, RCA jack ×1
HDMI OUT 480i (or 576i)/480p (or 576p)/720p/1080i/1080p
Tuner
FM Tuning Range 87.5 - 108.0 MHz
Intermediate Frequency 128 kHz
Signal-to Noise Ratio 60 dB (Mono) *
Frequency Response 140 - 10,000 Hz *
AM (for Australia and Asia) Tuning Range 522 - 1,710 MHz
Intermediate Frequency 128 kHz
Amplifier
Stereo mode 155 W + 155 W (4Ωat 1 kHz, THD 10 %)
Surround mode
(* Depending on the sound mode
settings and the source, there
may be no sound output.)
Front 155 W
Center* 155 W + 155 W (4Ωat 1 kHz, THD 10 %)
Surround* 225 W (3Ωat 70 Hz, THD 10 %)
Subwoofer*
Inputs AUDIO IN, OPTICAL IN, AUX IN, USB, TV-AUDIO (SCART)
Outputs MONITOR OUT, HDMI OUT, SCART (for Europe), COMPONENT VIDEO OUT
Speakers
Front Speaker Type 2 Way 3 Speaker
Impedance 4 Ω
Frequency Response 80 - 18000 Hz
Sound Pressure Level 83 dB/W (1m)
Rated Input Power 155 W
Max. Input Power 310 W
Net Dimensions (W ×H ×D) 280 ×1201 ×280 mm
Net Weight 4.4 kg

(No.MB713<Rev.002>)1-3
Items with * are measured at Front Speaker Terminals in STEREO mode
Designs and specifications are subject to change without notice.
Center speaker Type 1 Way 1 Speaker
Impedance 4 Ω
Frequency Response 120 - 18000 Hz
Sound Pressure Level 83 dB/W (1m)
Rated Input Power 155 W
Max. Input Power 310 W
Net Dimensions (W ×H ×D) 301 ×118 ×83 mm
Net Weight 0.9 kg
Rear Speaker Type 1 Way 1 Speaker
Impedance 4 Ω
Frequency Response 120 - 18000 Hz
Sound Pressure Level 83 dB/W (1m)
Rated Input Power 155 W
Max. Input Power 310 W
Net Dimensions (W ×H ×D) 113 ×209 ×83 mm
Net Weight 0.78 kg
Passive Subwoofer Type 1 Way 1 Speaker
Impedance 3 Ω
Frequency Response 40 - 1500 Hz
Sound Pressure Level 82 dB/W (1m)
Rated Input Power 255 W
Max. Input Power 450 W
Net Dimensions (W ×H ×D) 236 ×435 ×391 mm
Net Weight 5.7 kg
USB
Output power DC 5V 500mA

1-4 (No.MB713<Rev.002>)
TH-G61 Asia
General
Power supply 110 - 240 V ~ 50/60 Hz
Power consumption 130 W
Net Weight 3.6 kg
External dimensions (W ×H ×D) 430 ×76 ×317 mm
Operating conditions Temperature: 5°C to 35°C, Operation status: Horizontal
Operating humidity 5% to 85%
Laser Semiconductor laser, wavelength 650 nm
CD/DVD
Video system PAL/NTSC
Frequency response (audio) 140 Hz to 20 kHz*
Signal-to-noise ratio (audio) More than 75 dB (1 kHz, 20 kHz LPF/A-Filter)*
Dynamic range (audio) More than 75 dB*
Harmonic distortion (audio) 0.5 % (1 kHz, at 1W position) (20 kHz LPF)*
Video
Video output 1.0 V (p-p), 75 Ω, negative sync., RCA jack ×1
COMPONENT VIDEO OUT (Y) 1.0 V (p-p), 75 ohms, negative sync, RCA jack ×1
(PB)/(PR) 0.7 V (p-p), 75 ohms, RCA jack ×1
HDMI OUT 480i (or 576i)/480p (or 576p)/720p/1080i/1080p
Tuner
FM Tuning Range 87.5 - 108.0 MHz
Intermediate Frequency 128 kHz
Signal-to Noise Ratio 60 dB (Mono) *
Frequency Response 140 - 10,000 Hz *
AM (for Australia and Asia) Tuning Range 522 - 1,710 MHz
Intermediate Frequency 128 kHz
Amplifier
Stereo mode 155 W + 155 W (4Ωat 1 kHz, THD 10 %)
Surround mode
(* Depending on the sound mode
settings and the source, there
may be no sound output.)
Front 155 W
Center* 155 W + 155 W (4Ωat 1 kHz, THD 10 %)
Surround* 225 W (3Ωat 70 Hz, THD 10 %)
Subwoofer*
Inputs AUDIO IN, OPTICAL IN, AUX IN, USB, TV-AUDIO (SCART)
Outputs MONITOR OUT, HDMI OUT, COMPONENT VIDEO OUT
Speakers
Front Speaker Type 2 Way 3 Speaker
Impedance 4 Ω
Frequency Response 80 - 18000 Hz
Sound Pressure Level 83 dB/W (1m)
Rated Input Power 155 W
Max. Input Power 310 W
Net Dimensions (W ×H ×D) 280 ×1201 ×280 mm
Net Weight 4.4 kg

(No.MB713<Rev.002>)1-5
Items with * are measured at Front Speaker Terminals in STEREO mode
Designs and specifications are subject to change without notice.
Center speaker Type 1 Way 1 Speaker
Impedance 4 Ω
Frequency Response 120 - 18000 Hz
Sound Pressure Level 83 dB/W (1m)
Rated Input Power 155 W
Max. Input Power 310 W
Net Dimensions (W ×H ×D) 301 ×118 ×83 mm
Net Weight 0.9 kg
Rear Speaker Type 1 Way 1 Speaker
Impedance 4 Ω
Frequency Response 120 - 18000 Hz
Sound Pressure Level 83 dB/W (1m)
Rated Input Power 155 W
Max. Input Power 310 W
Net Dimensions (W ×H ×D) 113 ×209 ×83 mm
Net Weight 0.78 kg
Passive Subwoofer Type 1 Way 1 Speaker
Impedance 3 Ω
Frequency Response 40 - 1500 Hz
Sound Pressure Level 82 dB/W (1m)
Rated Input Power 255 W
Max. Input Power 450 W
Net Dimensions (W ×H ×D) 236 ×435 ×391 mm
Net Weight 5.7 kg
USB
Output power DC 5V 500mA

1-6 (No.MB713<Rev.002>)
TH-G41 Oceania
General
Power supply 220 - 240 V ~ 50/60 Hz
Power consumption 130 W
Net Weight 3.6 kg
External dimensions (W ×H ×D) 430 ×76 ×317 mm
Operating conditions Temperature: 5°C to 35°C, Operation status: Horizontal
Operating humidity 5% to 85%
Laser Semiconductor laser, wavelength 650 nm
CD/DVD
Video system PAL/NTSC
Frequency response (audio) 140 Hz to 20 kHz*
Signal-to-noise ratio (audio) More than 75 dB (1 kHz, 20 kHz LPF/A-Filter)*
Dynamic range (audio) More than 75 dB*
Harmonic distortion (audio) 0.5 % (1 kHz, at 1W position) (20 kHz LPF)*
Video
Video output 1.0 V (p-p), 75 Ω, negative sync., RCA jack ×1
COMPONENT VIDEO OUT (Y) 1.0 V (p-p), 75 ohms, negative sync, RCA jack ×1
(PB)/(PR) 0.7 V (p-p), 75 ohms, RCA jack ×1
HDMI OUT 480i (or 576i)/480p (or 576p)/720p/1080i/1080p
Tuner
FM Tuning Range 87.50 - 108.00 MHz
Intermediate Frequency 128 kHz
Signal-to Noise Ratio 60 dB (Mono) *
Frequency Response 140 - 10,000 Hz *
AM (for Australia and Asia) Tuning Range 522 - 1,710 MHz
Intermediate Frequency 128 kHz
Amplifier
Stereo mode 155 W + 155 W (4Ωat 1 kHz, THD 10 %)
Surround mode
(* Depending on the sound mode
settings and the source, there
may be no sound output.)
Front 155 W + 155 W (THD 10 %)
Center* 155 W
Surround* 155 W + 155 W (4Ωat 1 kHz, THD 10 %)
Subwoofer* 225 W (3Ωat 70 Hz, THD 10 %)
Inputs AUDIO IN, OPTICAL IN, AUX IN, iPod, HDMI IN, USB
Outputs MONITOR OUT, HDMI OUT, COMPONENT VIDEO OUT
Speakers
Front/Rear Speaker Type 1 Way 1 Speaker
Impedance 4 Ω
Frequency Response 120 - 18000 Hz
Sound Pressure Level 83 dB/W (1m)
Rated Input Power 155 W
Max. Input Power 310 W
Net Dimensions (W ×H ×D) 113 ×209 ×83 mm
Net Weight 0.78 kg

(No.MB713<Rev.002>)1-7
Items with * are measured at Front Speaker Terminals in STEREO mode
Designs and specifications are subject to change without notice.
Center speaker Type 1 Way 1 Speaker
Impedance 4 Ω
Frequency Response 120 - 18000 Hz
Sound Pressure Level 83 dB/W (1m)
Rated Input Power 155 W
Max. Input Power 310 W
Net Dimensions (W ×H ×D) 301 ×118 ×83 mm
Net Weight 0.9 kg
Passive Subwoofer Type 1 Way 1 Speaker
Impedance 3 Ω
Frequency Response 40 - 1500 Hz
Sound Pressure Level 82 dB/W (1m)
Rated Input Power 255 W
Max. Input Power 450 W
Net Dimensions (W ×H ×D) 236 ×435 ×391 mm
Net Weight 5.7 kg
USB
Output power DC 5V 500mA

1-8 (No.MB713<Rev.002>)
TH-G41 Asia
General
Power supply 110 - 240 V ~ 50/60 Hz
Power consumption 130 W
Net Weight 3.6 kg
External dimensions (W ×H ×D) 430 ×76 ×317 mm
Operating conditions Temperature: 5°C to 35°C, Operation status: Horizontal
Operating humidity 5% to 85%
Laser Semiconductor laser, wavelength 650 nm
CD/DVD
Video system PAL/NTSC
Frequency response (audio) 140 Hz to 20 kHz*
Signal-to-noise ratio (audio) More than 75 dB (1 kHz, 20 kHz LPF/A-Filter)*
Dynamic range (audio) More than 75 dB*
Harmonic distortion (audio) 0.5 % (1 kHz, at 1W position) (20 kHz LPF)*
Video
Video output 1.0 V (p-p), 75 Ω, negative sync., RCA jack ×1
COMPONENT VIDEO OUT (Y) 1.0 V (p-p), 75 ohms, negative sync, RCA jack ×1
(PB)/(PR) 0.7 V (p-p), 75 ohms, RCA jack ×1
HDMI OUT 480i (or 576i)/480p (or 576p)/720p/1080i/1080p
Tuner
FM Tuning Range 87.50 - 108.00 MHz (or 87.5 - 108.0 MHz)
Intermediate Frequency 128 kHz
Signal-to Noise Ratio 60 dB (Mono) *
Frequency Response 140 - 10,000 Hz *
AM (for Australia and Asia) Tuning Range 522 - 1,710 MHz
Intermediate Frequency 128 kHz
Amplifier
Stereo mode 155 W + 155 W (4Ωat 1 kHz, THD 10 %)
Surround mode
(* Depending on the sound mode
settings and the source, there
may be no sound output.)
Front 155 W + 155 W (THD 10 %)
Center* 155 W
Surround* 155 W + 155 W (4Ωat 1 kHz, THD 10 %)
Subwoofer* 225 W (3Ωat 70 Hz, THD 10 %)
Inputs AUDIO IN, OPTICAL IN, AUX IN, iPod, HDMI IN, USB
Outputs MONITOR OUT, HDMI OUT, COMPONENT VIDEO OUT
Speakers
Front/Rear Speaker Type 1 Way 1 Speaker
Impedance 4 Ω
Frequency Response 120 - 18000 Hz
Sound Pressure Level 83 dB/W (1m)
Rated Input Power 155 W
Max. Input Power 310 W
Net Dimensions (W ×H ×D) 113 ×209 ×83 mm
Net Weight 0.78 kg

(No.MB713<Rev.002>)1-9
Items with * are measured at Front Speaker Terminals in STEREO mode
Designs and specifications are subject to change without notice.
Center speaker Type 1 Way 1 Speaker
Impedance 4 Ω
Frequency Response 120 - 18000 Hz
Sound Pressure Level 83 dB/W (1m)
Rated Input Power 155 W
Max. Input Power 310 W
Net Dimensions (W ×H ×D) 301 ×118 ×83 mm
Net Weight 0.9 kg
Passive Subwoofer Type 1 Way 1 Speaker
Impedance 3 Ω
Frequency Response 40 - 1500 Hz
Sound Pressure Level 82 dB/W (1m)
Rated Input Power 255 W
Max. Input Power 450 W
Net Dimensions (W ×H ×D) 236 ×435 ×391 mm
Net Weight 5.7 kg
USB
Output power DC 5V 500mA

1-10 (No.MB713<Rev.002>)
TH-G31 Europe and Oceania
General
Power supply 220 - 240 V ~ 50/60 Hz
Power consumption 130 W
Net Weight 3.6 kg
External dimensions (W ×H ×D) 430 ×76 ×317 mm
Operating conditions Temperature: 5°C to 35°C, Operation status: Horizontal
Operating humidity 5% to 85%
Laser Semiconductor laser, wavelength 650 nm
CD/DVD
Video system PAL/NTSC
Frequency response (audio) 140 Hz to 20 kHz*
Signal-to-noise ratio (audio) More than 75 dB (1 kHz, 20 kHz LPF/A-Filter)*
Dynamic range (audio) More than 75 dB*
Harmonic distortion (audio) 0.5 % (1 kHz, at 1W position) (20 kHz LPF)*
Video
Video output 1.0 V (p-p), 75 Ω, negative sync., RCA jack ×1
COMPONENT VIDEO OUT (Y) 1.0 V (p-p), 75 ohms, negative sync, RCA jack ×1
(PB)/(PR) 0.7 V (p-p), 75 ohms, RCA jack ×1
HDMI OUT 480i (or 576i)/480p (or 576p)/720p/1080i/1080p
Tuner
FM Tuning Range 87.50 - 108.00 MHz
Intermediate Frequency 128 kHz
Signal-to Noise Ratio 60 dB (Mono) *
Frequency Response 140 - 10,000 Hz *
AM (for Australia and Asia) Tuning Range 522 - 1,710 MHz
Intermediate Frequency 128 kHz
Amplifier
Stereo mode 155 W + 155 W (4Ωat 1 kHz, THD 10 %)
Surround mode
(* Depending on the sound mode
settings and the source, there
may be no sound output.)
Front 155 W + 155 W (THD 10 %)
Center* 155 W
Surround* 155 W + 155 W (4Ωat 1 kHz, THD 10 %)
Subwoofer* 225 W (3Ωat 70 Hz, THD 10 %)
Inputs AUDIO IN, OPTICAL IN, AUX IN, iPod, HDMI IN, USB
Outputs MONITOR OUT, HDMI OUT, COMPONENT VIDEO OUT, SCART (for Europe)
Speakers
Front/Rear Speaker Type 1 Way 1 Speaker
Impedance 4 Ω
Frequency Response 120 - 18000 Hz
Sound Pressure Level 83 dB/W (1m)
Rated Input Power 155 W
Max. Input Power 310 W
Net Dimensions (W ×H ×D) 113 ×209 ×83 mm
Net Weight 0.78 kg
