JVC EX-A10 User manual

COMPACT COMPONENT SYSTEM
EX-A10
Consists of RX-EXA10, SP-EXA10 and XV-EXA10
LVT1403-002B
[J, C, UJ]
INSTRUCTIONS
For Customer Use:
Enter below the Model No. and Serial No.
which are located either on the rear,
bottom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
English
EXA10[J_C_UJ]-00Cov1.fm Page 1 Wednesday, October 17, 2007 4:19 PM

G-1
(For U.S.A.)
(For U.S.A.)
(For U.S.A.)
(For U.S.A.)
The lightning flash with arrowhead symbol, within
an equilateral triangle is intended to alert the
user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
INFORMATION
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Note to CATV system installer:
This reminder is provided to call the CATV system installer’s attention to Section 820-40 of the NEC which provides
guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry as practical.
Warnings, cautions and others
EXA10[J_C_UJ]-00Cov2.fm Page 1 Tuesday, September 13, 2005 12:51 PM

G-2
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
ATTENTION
Afin d’éviter tout risque d’électrocution, d’incendie, etc.:
1. Ne pas enlever les vis ni les panneaux et ne pas ouvrir le cof-
fret de l’appareil.
2. Ne pas exposer l’appareil à la pluie ni à l’humidité.
CAUTION — Fbutton!
Disconnect the mains plug to shut the power off completely (the
STANDBY lamp goes off).
The Fbutton in any position does not disconnect the mains
line.
• When the system is on standby, the STANDBY lamp lights
red.
• When the system is turned on, the STANDBY lamp goes off.
The power can be remote controlled.
ATTENTION - Touche F!
Déconnectez la fiche d’alimentation secteur pour couper l’ali-
mentation complètement (le témoin STANDBY s’éteint).
La touche F, dans n’importe quelle position, ne déconnecte
pas le système du secteur.
• Quand le système est en attente, le témoin STANDBY est
allumé en rouge.
• Quand le système est sous tension, le témoin STANDBY
s’éteint.
L’alimentation ne peut pas être télécommandée.
CAUTION
• Do not block the ventilation openings or holes.
(If the ventilation openings or holes are blocked by a
newspaper or cloth, etc., the heat may not be able to get out.)
• Do not place any naked flame sources, such as lighted
candles, on the apparatus.
• When discarding batteries, environmental problems must be
considered and local rules or laws governing the disposal of
these batteries must be followed strictly.
• Do not expose this apparatus to rain, moisture, dripping or
splashing and that no objects filled with liquids, such as vases,
shall be placed on the apparatus.
ATTENTION
• Ne bloquez pas les orifices ou les trous de ventilation.
(Si les orifices ou les trous de ventilation sont bloqués par un
journal un tissu, etc., la chaleur peut ne pas être évacuée
correctement de l’appareil.)
• Ne placez aucune source de flamme nue, telle qu’une bougie,
sur l’appareil.
• Lors de la mise au rebut des piles, veuillez prendre en
considération les problèmes de l’environnement et suivre
strictement les règles et les lois locales sur la mise au rebut
des piles.
• N’exposez pas cet appareil à la pluie, à l’humidité, à un
égouttement ou à des éclaboussures et ne placez pas des
objets remplis de liquide, tels qu’un vase, sur l’appareil.
EXA10[J_C_UJ]-00Cov2.fm Page 2 Monday, September 12, 2005 6:16 PM

G-3
(For U.S.A. or Canada models)
IMPORTANT FOR LASER PRODUCTS / IMPORTANT POUR PRODUITS LASER
(For models other than U.S.A. or Canada models)
IMPORTANT FOR LASER PRODUCTS / IMPORTANT POUR PRODUITS LASER
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the
unit; leave all servicing to qualified service personnel.
3. CAUTION: VISIBLE AND / OR INVISIBLE CLASS 1M LASER RADIATION WHEN
OPEN. DO NOT STARE INTO BEAM OR VIEW DIRECTLY WITH OPTICAL
INSTRUMENTS.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED INSIDE THE UNIT.
1. PRODUIT LASER CLASSE 1
2. ATTENTION: N'ouvrez pas le couvercle supérieur. Il n'y a aucune pièce réparable par
l'utilisateur à l'intérieur de l'appareil; confiez toute réparation à un personnel qualifié.
3. ATTENTION: RAYONNEMENT LASER VISIBLE ET / OU INVISIBLE DE CLASSE 1M
UNE FOIS OUVERT. NE PAS FIXER LE FAISCEAU NI REGARDER DIRECTEMENT
AVEC DES INSTRUMENTS OPTIQUES.
4. REPRODUCTION DE L'ÉTIQUETTE: ÉTIQUETTE DE PRÉCAUTION PLACÉE À
L'INTERIEUR DE L'APPAREIL.
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the
unit; leave all servicing to qualified service personnel.
3. CAUTION: Visible and invisible laser radiation when open and interlock failed or
defeated. Avoid direct exposure to beam.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED INSIDE THE UNIT.
1. PRODUIT LASER CLASSE 1
2. ATTENTION: N'ouvrez pas le couvercle supérieur. Il n'y a aucune pièce réparable par
l'utilisateur à l'intérieur de l'appareil; confiez toute réparation à un personnel qualifié.
3. ATTENTION: Risque de radiations laser visible et invisible quand l'appareil est ouvert et
que le système de verrouillage ne fonctionne pas ou a été mis hors service. Évitez toute
exposition directe au rayon.
4. REPRODUCTION DE L'ÉTIQUETTE: ÉTIQUETTE DE PRÉCAUTION PLACÉE À
L'INTERIEUR DE L'APPAREIL.
Warnings, cautions and others (continued)
EXA10[J_C_UJ]-00Cov2.fm Page 3 Wednesday, October 17, 2007 5:23 PM

G-4
For Canada/pour le Canada
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE
DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQUAU FOND.
For Canada/pour le Canada
THIS DIGITAL APPARATUS DOES NOT EXCEED THE CLASS B LIMITS FOR RADIO NOISE EMISSIONS FROM
DIGITAL APPARATUS AS SET OUT IN THE INTERFERENCE-CAUSING EQUIPMENT STANDARD ENTITLED
“DIGITAL APPARATUS”, ICES-003 OF THE DEPARTMENT OF COMMUNICATIONS.
CET APPAREIL NUMERIQUE RESPECTE LES LIMITES DE BRUITS RADIOELECTRIQUES APPLICABLES AUX
APPAREILS NUMIRIQUES DE CLASSE B PRESCRITES DANS LA NORME SUR LE MATERIEL BROUILLEUR:
“APPAREILS NUMERIQUES”, NMB-003 EDICTEE PAR LE MINISTRE DES COMMUNICATIONS.
CAUTION — Proper Ventilation
To avoid risk of electric shock and fire and to protect from damage, locate the apparatus as follows:
Top/Front/Back/Sides: No obstructions should be placed in the areas shown by the dimensions below.
Bottom: Place on the level surface. Maintain adequate air path for ventilation by placing on
a stand with a height of 10 cm (3 ″) more.
In addition, maintain the best possible air circulation.
Attention: Ventilation correcte
Pour éviter tout risque d’électrocution et d’incendie, et pour ne pas endommager les appareils, placez-les
de la façon suivante:
Faces supérieure /avant / arrière / côtés : Aucune obstruction ne doit se trouver dans les zones
indiquées par les dimensions ci-dessous.
Bas : Placez l’appareil sur une surface plane. Maintenez une entrée
d’air adéquate pour la ventilation en plaçant l’appareil sur un
support avec une hauteur d’au moins 10 cm
(3 ″) .
De plus, maintenez la meilleure circulation d’air possible.
1516
15
16
Wall or
obstructions
Mur, ou
obstruction
Front
Avant
Front view Side view
Vue avant Vue de côté
15 cm (5 ″)
15 16
15 cm
(5 ″)
15 16
15 cm
(5 ″)
15 16
15 cm
(5 ″)
15 16
10 cm
(3 ″)
15 16
1 cm
(″)
716
1 cm
(″)
716
[European Union only]
[Union européenne seulement]
EXA10[J_C_UJ]-00Cov2.fm Page 4 Wednesday, October 17, 2007 4:20 PM

1
Introduction
Supplied accessories ......................................2
Part description ...............................................3
DVD player ......................................................... 3
Receiver.............................................................. 4
Using the remote control .................................5
Inserting batteries into the remote control .......... 5
Operating the TV using the remote control......... 6
Preparation
Connections ....................................................7
Standard setup ................................................... 7
Connecting the antennas.................................... 7
Connecting the speakers.................................... 9
Connecting the receiver and the DVD player ... 10
Connecting other equipment............................. 11
Connecting a TV............................................... 12
Connecting the power cords............................. 13
Basic operations
Basic operations............................................14
Turning on/off the system ................................. 14
Setting the clock ............................................... 15
Dimmer ............................................................. 16
Adjusting the volume ........................................ 16
Turning off the sound temporarily (MUTING) ... 16
Adjusting the sound quality............................... 16
Adjusting the bass sound.................................. 17
Enhancing the playback sound
(CC CONVERTER) ........................................ 17
Listening to radio
Listening to radio broadcasts ........................18
Setting the AM tuner spacing (only for
models sold at post exchanges)..................... 18
Selecting a radio station ................................... 18
Tuning in to a preset radio station .................... 19
Playing back DVDs/CDs
Basic operations of the DVD player ..............20
Playing back a DVD/CD ....................................20
Changing the display in the display window......23
Selecting a chapter/track using the number
buttons ............................................................23
Stopping playback .............................................23
Pausing playback ..............................................24
Advancing the picture frame by frame...............24
Fast reverse/fast forward search .......................24
Playing back from a position 10 seconds before
(One touch replay) ..........................................25
Slow motion playback........................................25
Skipping to the beginning of a chapter/
track/file...........................................................25
Skipping at about 5 minute intervals..................26
Resuming playback ...........................................26
Selecting a track from the menu screen ............27
Convenient functions of the DVD player .......28
Locking DVD/CD ejection ..................................28
Playing back a DVD/CD in the desired order
(Program playback).........................................28
Playing back a DVD/CD in a random order
(Random playback) .........................................30
Playing back a DVD/CD repeatedly
(Repeat playback) ...........................................30
Playing back a specified part repeatedly
(A-B repeat playback) .....................................31
Saving the playback settings for next time ........31
Selecting the subtitles........................................32
Selecting the audio language ............................32
Selecting the view angle....................................33
Magnifying the picture (ZOOM) .........................33
Adjusting the picture quality (VFP) ....................34
Playing back the bonus group ...........................34
Browsable still pictures (B.S.P.) ........................35
Creating realistic sound (3D PHONIC)..............35
Using the status bar and the menu bar .............36
Changing the initial settings with the
preference screen .....................................38
Basic operations ................................................38
LANGUAGE.......................................................38
PICTURE...........................................................39
AUDIO ...............................................................39
OTHERS............................................................39
Table of contents
EXA10[J_C_UJ]-TOC.fm Page 1 Thursday, September 8, 2005 2:47 PM

2
Introduction
Listening to the sound of other
audio equipment
Listening to the sound of other audio
equipment ...................................................41
Timer
Timer .............................................................42
Using the sleep timer........................................ 42
Using the playback timer .................................. 43
Reference
Using the AV COMPU LINK function ............45
Connection and setup....................................... 45
Operation.......................................................... 45
Special cautions ............................................46
Notes on handling............................................. 46
About DVDs/CDs...........................................47
Playable DVD/CD types.................................... 47
Disc structure.................................................... 49
Troubleshooting.............................................50
Language codes............................................51
Specifications ................................................52
Check to be sure you have all of the supplied
accessories.
The number in parentheses is the quantity of the
items supplied. If anything is missing, contact your
dealer immediately.
• Remote control (1)
• Batteries (2)
• FM antenna (1)
• AM loop antenna (1)
• Speaker cords (4)
• Audio cord (1)
• Optical digital cord (1)
• Synchronization cord (1)
• Composite video cord (1)
• AC plug adaptor* (2)
NOTE
* The AC plug adaptor is not supplied for U.S.A. and
Canada models.
C
AUTION
• Do not fold the optical digital cord as this may
damage the inner wire.
How to read this manual
• This manual explains the operations assuming
that you will use the remote control. Some buttons
on the receiver or the DVD player are the same as
those on the remote control. You can use either
button in this case.
• Some diagrams in this manual are simplified or
exaggerated for the purpose of explanation.
• You can operate some functions differently from
the explanation given in this manual.
• The following marks refer to the usable discs for
the explained function.
• “DVD VR” means a DVD recorded in DVD Video
Recording (DVD VR) format.
• “VCD” stands for “Video Compact Disc”.
• “SVCD” stands for “Super Video Compact Disc”.
• An “ASF” disc means a disc recorded in
“Advanced Systems Format”.
Introduction
Supplied accessories
EXA10[J_C_UJ]-TOC.fm Page 2 Thursday, September 8, 2005 2:47 PM

3
The numbers refer to the pages in which the parts are explained.
Front panel
Rear panel
Display window
The receiver and the DVD player use the same design for their display windows.
DVD player
S
ee
“
Display window” shown below.
13, 14
14
23–26, 28
5
20, 2420, 2820
10
13
12
10
45
10 47 12 12
21, 22
21, 22
21, 22,
29
21, 27 28
21, 22, 29
30
34, 35 13
30 31 31
Part description
EXA10[J_C_UJ]-01.fm Page 3 Tuesday, September 6, 2005 5:57 PM

4
Introduction
The numbers refer to the pages in which the parts are explained.
Front panel
* This terminal is for connecting a pair of headphones equipped with a stereo plug (not supplied). When the
headphones are connected, the speakers do not produce any sound.
Rear panel
Display window
The receiver and the DVD player use the same design for their display windows.
Receiver
13, 14
14, 18
*
16
518
See “Display window” shown below.
17 18, 20, 41
10
11
12
13
7
8
12 10 10 9, 11
15, 18
18 43 42
EXA10[J_C_UJ]-01.fm Page 4 Tuesday, September 6, 2005 5:57 PM

5
The numbers refer to the pages in which the parts
are explained.
If the effective distance between the remote control
and remote control sensor on the receiver or the
DVD player decreases, replace the batteries. Use
two R6P (SUM-3)/AA(15F) type dry-cell batteries.
CAUTION
• Do not use a used battery and a new battery
together.
• Do not use different types of batteries at the
same time.
• Take out the batteries if the remote control is not
to be used for a long time. Otherwise it may
cause a leakage.
Remote control operation
When operating the remote control, point it at the
front panel of the receiver or the DVD player. If the
remote control is operated from a direction that is
extremely oblique or when there is an obstacle in
the way, signals may not be transmitted.
If the remote control sensor is exposed to a strong
light such as direct sunlight, correct operation may
not be carried out.
14
6, 14
41
14
16
17
20
24
32
35
42
16
16
6
6
16
27
11
13
33
25
16
23 20
18
20
6
6
24, 25
23
27
27, 32
36
32
38
22
34
35
33
28, 30
30
15, 43 18
19
15, 21,
27, 36
21, 25, 34
15, 31, 43
Inserting batteries into
the remote control
Batteries (2)
Using the remote control
24, 25
11, 17
24, 25 24, 25
6, 15, 23
15, 29, 44
EXA10[J_C_UJ]-01.fm Page 5 Tuesday, September 6, 2005 5:57 PM

6
Introduction
You can operate your TV using the remote control
of this system.
Setting the manufacturer code
1Slide the remote control
mode selector to TV.
2Hold down FTV.
• Hold down FTV until you finish step 4.
3Press ENTER and release.
4Press number buttons (1-9, 0).
• Refer to “Using the number buttons”
(Apage 15).
Examples:
For a Hitachi TV: Press 1, then 0.
For a Toshiba TV: Press 0, then 8.
When the manufacturer of your TV has two or
more codes, select the manufacturer codes in turn
and find the one that operates the TV and the
remote control properly.
NOTE
• A manufacturer code is subject to change without
notice. You may not be able to operate the TV
produced by the manufacturer.
5Release FTV.
Using the remote control for the TV operation
Operate the remote control by pointing it at the TV.
*1 Make sure to slide the remote control mode
selector to TV in advance.
NOTE
• After replacing the batteries of the remote control,
set the manufacturer code again.
• When the remote control mode selector is slid to TV,
some buttons may not work.
Operating the TV using
the remote control
FTV
TV/VIDEO
TV
CHANNEL
TV
VOLUME
ENTER
Number
buttons
Remote control
mode selector
Manufacturer Code Manufacturer Code
JVC 01 Samsung 12
Hitachi 10 Sanyo 13
Magnavox 02 Sharp 06
Mitsubishi 03 Sony 07
Panasonic 04, 11 Toshiba 08
Philips 14 Zenith 09
RCA 05
Turns on/off the TV.
Changes the channels.
Adjusts the volume.
Selects the channels.
Switches the
previously selected
channel and the
current channel.
Switches the TV and video input.
/
/
~
*1
EXA10[J_C_UJ]-01.fm Page 6 Tuesday, September 6, 2005 5:57 PM

7
Connecting the AM loop antenna (supplied)
3Turn the AM loop antenna to find the best
position for radio reception.
Place the AM loop antenna as far from the
receiver as possible.
• Do not place the AM loop antenna on a metallic
table or close to a TV, computer, or other electric
appliances. Doing so may affect radio reception.
When positioning the antennas, find the best
position for reception while listening to an actual
radio program (refer to “Listening to radio
broadcasts” (Apage 18)).
Standard setup
Speaker Receiver Speaker
DVD player
Connecting the antennas
1Set up the AM loop antenna.
2Connect the antenna cord.
Receiver
(rear panel)
Connect the ends of the
antenna cord as shown
above.
If insulation covers
the tips of the
antenna cord,
twist and pull off
the insulation.
White
Black
7When radio reception with the supplied AM
loop antenna is poor
Electric wire: 3 - 5 m (9 10″- 16 5″) (not supplied)
′
′
Stretch out the electric
wire horizontally,
preferably in a high
place such as above a
window or outdoors.
Connect the AM loop
antenna cord to the
receiver together with
the electric wire.
Receiver
(rear panel)
AM loop
antenna cord
Electric
wire
Tw i s t
together
electric
wire and
the AM
loop
antenna
cord.
Preparation
Connections Do not turn on the power until you complete the connection.
EXA10[J_C_UJ]-02.fm Page 7 Wednesday, October 5, 2005 11:22 AM

8
Preparation
Connecting the FM antenna (supplied)
7When radio reception with the supplied FM
antenna is poor, or when using a communal
antenna
When using an antenna other than those supplied
with this system, refer to the operation manuals for
the antenna and converter for details of connection.
When positioning the antennas, find the best
position for reception while listening to an actual
radio program (refer to “Listening to radio
broadcasts” (Apage 18)).
Stretch out the FM antenna to the best position for
radio reception, and then fix the FM antenna with
adhesive tape.
Receiver
(rear panel)
FM antenna
Receiver
Antenna cord
(not supplied)
Outdoor FM
antenna
(not supplied)
Converter (not
supplied: compatible
with 300 C/75 C)
Coaxial cord
(not supplied)
Receiver
(rear panel)
Depending on the radio reception
conditions, an FM feeder antenna
(not supplied: compatible with
300 C) can be used. In this case, a
converter (not supplied) is required.
or
Communal
antenna terminal
EXA10[J_C_UJ]-02.fm Page 8 Tuesday, September 6, 2005 5:59 PM

9
There is no difference between the left and right speakers.
CAUTION
• Do not short-circuit the ªand ·speaker
terminals. Doing so may damage the receiver.
• Do not connect other speakers together with the
supplied speakers. The change in impedance
may damage the receiver and the speakers.
• Improper speaker cord connection spoils the
stereo effect and sound quality.
• The supplied speakers are magnetically
shielded, but color irregularity may occur on the
TV depending on some conditions. To prevent
color irregularity, set up the speakers following
the instructions below.
1. Turn off the main power of the TV before
setting up the speakers.
2. Place the speakers enough distance from the
TV so that they do not cause color irregularity
on the TV.
3. Wait for about 30 minutes before turning on
the main power of the TV again.
NOTE
• To allow the receiver and the DVD player to emit
generated heat, leave a space of at least 1 cm
( ″ )between the receiver or the DVD player and
the speakers or other objects.
Connecting the speakers
Before
connecting the
speaker cords,
twist and pull off
the insulation.
TWEETER
WOOFER
TWEETER
WOOFER
WOOFER
RIGHT
TWEETER
RIGHT
WOOFER
RIGHT
TWEETER
RIGHT
WOOFER
LEFT
TWEETER
LEFT
WOOFER
LEFT
TWEETER
LEFT
Speaker terminal Speaker cord
Right speaker
(rear panel)
Speaker cords
(supplied)
Speaker terminal Speaker cord
Left speaker
(rear panel)
Receiver (rear panel)
• An incorrect connection may damage the speakers.
• The supplied speakers are dedicated to the supplied receiver as parts of the EX-A10 system. Do not
connect the supplied speakers to equipment other than the supplied receiver. Doing so may damage the
speakers.
The speakers employ natural wood for the
diaphragm and the cabinet in order to
reproduce the original sound faithfully.
The appearance will therefore be different for
each system.
Speaker
cover
You can detach the speaker cover.
7
1
6
Connections (continued) Do not turn on the power until you complete the connection.
EXA10[J_C_UJ]-02.fm Page 9 Tuesday, October 4, 2005 2:03 PM

10
Preparation
Make sure to connect the three supplied cords.
CAUTION
• Do not fold the optical digital cord as this may
damage the inner wire.
Connecting the receiver and the DVD player
DVD player (rear panel)
Synchronization
cord (supplied)
Optical digital
cord (supplied)
Audio cord
(supplied)
If protection caps cover the tips of the optical
digital cord, pull off the protection caps before
connecting.
Protection cap
EXA10[J_C_UJ]-02.fm Page 10 Wednesday, October 17, 2007 4:20 PM

11
Connecting the subwoofer
When you connect this system with an amplifier-
built-in subwoofer (not supplied), you can enjoy a
more dynamic bass sound. Refer to the manual of
the subwoofer for details.
To produce sound from the subwoofer, press
S.WFR OUT on the remote control to display
“S. WOOFER ON” (Subwoofer on) in the display
window on the receiver. Each time you press
S.WFR OUT, the display toggles between
“S. WOOFER ON” and “S. WOOFER OFF”.
NOTE
• When “S. WOOFER ON” is selected, bass sound
from the left and right speakers will be automatically
turned down and the bass sound will be emitted
mainly from the subwoofer.
Connecting other speakers
To connect speakers other than the ones supplied,
follow the operations shown below.
1Slide the remote control
mode selector to
RECEIVER.
2Connect the speakers to the
SPEAKERS WOOFER LEFT and
RIGHT terminals on the
receiver.
3Hold down BASS ADJUST for 2
or more seconds.
• “Single Amp” is displayed in the display
window on the receiver, and no audio signal
is sent to the SPEAKERS TWEETER LEFT
and RIGHT terminals.
Display on the receiver
NOTE
• The impedance of speakers connected to this
system must be within the range 6
C to 16 C .
• When connecting the supplied speakers to the
receiver, hold down BASS ADJUST on the remote
control for 2 or more seconds once again to select
“Bi-Amp” in the display window on the receiver.
Connecting other equipment
7
2/3(cursor)/
ENTER
SCAN MODE
S. WFR OUT
Remote control
mode selector
BASS
ADJUST
Audio cord (not supplied)
(If an audio cord comes with the amplifier-built-in
subwoofer, you can use the audio cord.)
A
mplifier-built-in subwoofer
(not supplied)
Receiver
(rear panel)
Do not turn on the power until you complete the connection.
Connections (continued)
EXA10[J_C_UJ]-02.fm Page 11 Tuesday, September 6, 2005 5:59 PM

12
Preparation
Connecting other audio equipment
Connecting digital equipment with an
optical output terminal
Connecting a TV with the VIDEO terminal
Connecting a TV with the S-VIDEO
terminal
Connecting a TV with the COMPONENT
VIDEO OUT terminals
Receiver (rear panel)
Output
Input
Other audio
equipment
Audio cord
(not supplied)
MD player or satellite
receiver
Output
Input
To an optical digital output
terminal
Optical digital cord
(not supplied)
Receiver (rear panel)
Connecting a TV
TV
To video terminal
DVD player
(rear panel)
Composite video cord (supplied)
TV
To S-video terminal
DVD player
(rear panel)
S-video cord (not supplied)
TV
To component terminals
DVD player
(rear panel)
Component video cord (not supplied)
EXA10[J_C_UJ]-02.fm Page 12 Tuesday, September 6, 2005 5:59 PM

13
For the locations of the remote
control buttons, refer to page 11.
Do not turn on the power until you
complete the connection.
Connections (continued)
After connecting the DVD player to the TV, select
the video signal type correctly according to the TV.
1Slide the remote control
mode selector to DVD.
2Make sure that playback stops.
(If a disc is being played back,
press 7to stop playback.)
3Press SCAN MODE.
• The current video signal type will flash.
4Press 2, 3(cursor) to select
the video signal type suitable
for the TV.
• You can select “INTERLACE” or
“PROGRESSIVE”. You can obtain better
picture quality in the “PROGRESSIVE”
mode than in the “INTERLACE” mode.
When you select “INTERLACE”, the image
is displayed alternating between half of the
scanned lines in the “PROGRESSIVE”
mode and the other half of the scanned
lines. The way of displaying the image is a
conventional video signal type.
• Select “INTERLACE” when a TV only
compatible with interlaced video signals is
connected to the DVD player.
• Select “PROGRESSIVE” when a TV
equipped with a component terminal and
compatible with progressive video signals is
connected to the DVD player. When you
select “PROGRESSIVE”, the image is
displayed with all scanned lines at the same
time. The image has a higher resolution
than that in the “INTERLACE” mode.
5Press ENTER.
• The selected video signal type is displayed
for a short time.
NOTE
• Although the picture may be distorted when you
press ENTER, this is not a malfunction of the
system.
• There are some progressive TVs and high-definition
TVs that are not fully compatible with this system,
resulting in an unnatural picture when playing back
a DVD VIDEO with progressive scanning. In this
case, change the scan mode to “INTERLACE”.
• To check the compatibility of your TV, contact your
local JVC customer service center.
• All JVC-manufactured progressive TVs and high-
definition TVs are fully compatible with this system.
• Even if the power cord of the DVD player is
disconnected from the AC outlet or the power is
interrupted, the video signal type setting is stored.
CAUTION
• Do not connect an S-video cord and a
component video cord at the same time.
Otherwise pictures may not be played back
properly.
• Connect the DVD player directly to a TV (or a
monitor) without routing through a video
cassette recorder (VCR). Otherwise picture
distortion may occur during playback.
• Connecting the DVD player to a VCR-built-in-TV
may also cause picture distortion during
playback.
• Connect the power cords after you complete the
other connections.
• The STANDBY lamps on the front panels of the
receiver and the DVD player will light up.
Connecting the power cords
DVD player
DVD player
Direct connection
TV (or
monitor)
Receiver
AC outlet
Receiver
(rear panel)
AC outlet
DVD player
(rear panel)
EXA10[J_C_UJ]-02.fm Page 13 Tuesday, October 4, 2005 11:02 AM

14
Preparation/Basic operations
•
1Slide the remote control
mode selector to
RECEIVER.
2Press FAUDIO (or Fon the
receiver).
• The power of the receiver will turn on and
the STANDBY lamp on the receiver will turn
off.
• Press
F AUDIO again to turn off the
power of the receiver.
• With the power off, pressing any of the
following buttons also turns on the receiver.
-DVD, FM/AM or AUX on the remote
control
- 3/8on the DVD player
The function assigned to the button starts
working at the same time.
1Slide the remote control
mode selector to DVD.
2Press F DVD (or F on the DVD
player).
• The power of the DVD player will turn on
and the STANDBY lamp on the DVD player
will turn off.
• Press
F DVD again to turn off the power
of the DVD player.
• With the power off, pressing any of the
following buttons also turns on the DVD
player.
- DVD or 0OPEN/CLOSE on the remote
control
- 0or 3/8on the DVD player
The function assigned to the button starts
working at the same time.
(When you press DVD on the remote
control or 3/8on the DVD player, if a disc
has been loaded, playback starts
automatically.)
DISPLAY
0OPEN/
CLOSE
FM/AM
CC
CONVERTER
CLOCK/
TIMER
BASS
+/ –
F AUDIO
F DVD
AUX
MUTING
AUDIO
VOLUME +/ –
5///2/3
(cursor)/
ENTER
Number
buttons
CANCEL
BASS
ADJUST
TREBLE
+/ –
SET
8
DIMMER
Turning on/off the system
DVD player
Receiver
Basic operations
Basic operations
Remote control
mode selector
EXA10[J_C_UJ]-02.fm Page 14 Tuesday, September 6, 2005 5:59 PM

15
You can set the clock when the receiver is turned
either on or off.
Example:
To set the clock to 10:30 a.m. on Wednesday
1Slide the remote control
mode selector to
RECEIVER.
2Press CLOCK/TIMER.
Example:
Display on the receiver ( for U.S.A. or Canada models)
3Press 2or 3(cursor) to select
the hour.
• Hold down the button to incrementally
increase the hour setting.
• You can also use the number buttons to
specify the hour. Refer to “Using the
number buttons” shown on the right.
4Press SET.
5Press 2or 3(cursor) to select
the minute.
• Hold down the button to incrementally
increase the minute setting.
• You can also use the number buttons to
specify the minute.
6Press SET.
7Press 2or 3(cursor) to select
the day of the week.
• Hold down the button to change the setting
for the day of the week.
• Abbreviations are used for the days of the week.
Sun. →Sunday
Mon.→Monday
Tue. →Tuesday
Wed.→Wednesday
Thu. →Thursday
Fri. →Friday
Sat. →Saturday
8Press SET.
• The clock starts from 0 seconds in the
minute you set.
NOTE
• While setting the clock, you can return to the
previous step by pressing CANCEL.
• For U.S.A. or Canada models, the time display on
the receiver is a 12-hour clock.
• For models sold at post exchanges, the time display
on the receiver is a 24-hour clock.
• The clock will gain or lose about 1 minute per month.
• If the power cord of the receiver is disconnected
from the AC outlet or the power is interrupted, the
clock setting is stored for about 1 minute.
• You cannot set the clock when “DISPLAY OFF” is
selected. (
A page 16)
Adjusting the clock
Press CLOCK/TIMER twice to
display the clock, and then adjust
the clock starting from step 3.
Displaying the clock when using the
receiver
Press DISPLAY.
• Refer to “Changing the display in the display
window”. (Apage 23)
Setting the clock
AM
AM
AM
Examples:
5:
15: → →
150: → → → →
Basic operations (continued)
Using the number buttons
EXA10[J_C_UJ]-02.fm Page 15 Tuesday, September 27, 2005 10:48 AM
