JVC LT-50MA877 User manual

4K UHD HDR Smart TV
LT-50MA877
(50" class/ 50 diagonal)"
Before operating the unit, please read this manual thoroughly.
ATTENTION
If you purchase a universal remote control from your local retailer, please contact the remote manufacturer for the
required programming code.
PLEASE HAVE THE MODEL NUMBER READY PRIOR TO CALLING
FOR RECYCLING INFORMATION, PLEASE CONTACT CUSTOMER SERVICE.
CUSTOMER SERVICE - 1-888-582-8870
ENGLISH
0
7 8 9
456
1 2 3
VOL CH
MTS/AUDIO
CC/SUBTITLE
TTS
CH
EXIT
OK
INFO
SOUNDASPECT
USER GUIDE

Contents
Safety and warnings......................................................................................1-3
Introduction................................................................................... ..............4
Installation...................................................................................................5-8
...................................................................................................9
General Description............................................................................ ..........10-13
External Connection......................................................................................14-17
Basic Operations...........................................................................................18-19
Menu System Instruction................................................................................20-37
Digital Media Player.......................................................................................38
Trouble Shooting...........................................................................................39-40
Reference.....................................................................................................41
Wall Mount

SAFETY AND WARNINGS
-1-
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK).NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK!
DO NOT OPEN!
ATTENTION
RISQUE DE CHOC ELECTRIQUE!
NE PAS OUVRIR!
CAUTION
CAUTION:
The lightning flash with arrowhead symbol,within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE
TO RAIN OR MOISTURE.
TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES OR OPEN FLAMES AWAY
FROM THIS PRODUCT AT ALL TIMES.
WARNING:
TO PREVENT ELECTRIC SHOCK. DO NOT USE THIS POLARIZED PLUG WITH
AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE
BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.
CAUTION:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
WARNING:
Changes or modifications not expressly approved by the party responsible for compliance with
the FCC Rules could void the user’s authority to operate this equipment.
CAUTION:
Serial number: Model number:
Location of the required marking
The rating sheet and the safety caution are on the
rear of the unit.
Important Note:
In the spaces below, enter the model and serial
number of your television (located at the rear of the
television cabinet). Staple your sales receipt or
invoice to the inside cover of this guide. Keep this
user’s guide in a convenient place for future
reference. Keep the carton and original packaging for
future use.
BATTERY PRECAUTIONS:
Batteries should not be exposed to excessive heat
such as sunshine,fire or the like.
The remote control unit uses infrared beams to
transmit signals, so sunlight or fluorescent light on
the remote sensor may shorten operating
distance.
Incorrect use of batteries may cause them to leak
or burst. Read the battery warnings and use the
batteries
properly.
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or
rechargeable, (Ni-Cd, Ni-MH, etc.) batteries.
Remove batteries if the remote control will not be
operated for an extended period of time.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING
TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

SAFETY AND WARNINGS
IMPORTANT SAFETY INSTRUCTIONS
The symbol indicates that dangerous
voltages constituting a risk of electric shock
are present within this unit.
The symbol indicates that there are
important operating and maintenance
instructions in the literature
accompanying this unit.
To reduce the risk of fire or electric shock, do
not expose this apparatus to rain or moisture.
WARNING:
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with non abrasive dry cloth.
7) Do not block any ventilation openings, install
in accordance with the instructions.
8) Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9) Do not defeat the safety purpose of the
polarized plug. If the provided plug does not fit
into your outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11) Only use attachments/accessories specified
by the manufacturer.
12) Unplug this apparatus during lighting storms
or when unused for long periods of time.
13) Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as when power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed
to rain or moisture, does not operate normally, or
has been dropped.
14) Mains plug is used as the disconnect device,
the disconnect device shall remain readily
operable.
15) Do not cover the ventilation openings with
items such as newspapers, table-cloth, curtains,
etc.
16) No naked flame sources, such as lighted
candles, should be placed on the apparatus.
17) Attention should be drawn to the
environmental aspects of battery disposal.
18) Use apparatus in moderate climate.
19) The apparatus shall not be exposed to
dripping or splashing and that no objects filled
with liquids, such as vases, shall be placed on
the apparatus.
20) Use only with a cart , stand, tripod, bracket,
or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.
The batteries shall not be exposed to
excessive heat such as, fire or the like.
WARNING:
The excessive sound pressure from earphones
and headphones can cause hearing loss.
WARNING:
This symbol indicates that this product
incorporates double insulation between
hazardous mains voltage and user accessible
parts. When servicing use only
identical replacement parts.
This marking indicates that this product
should not be disposed with other
household wastes. To prevent possible
harm to the environment or human health
from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable
reuse of material resources. To return your
used device, please use the return and
collection systems or contact the retailer
where the product was purchased. They
can take this product for environmental
safe recycling.
-2-

SAFETY AND WARNINGS
High voltages are used in the operation of this television
receiver. Do not remove the cabinet back from your set.
Refer servicing to qualified service personnel.
To prevent fire or electrical shock hazard, do not expose
the television receiver to rain or moisture.
Do not drop or push objects into the television cabinet
slots or openings. Never spill any kind of liquid on the
television receiver.
Do not block the ventilation holes in the back cover.
Adequate ventilation is essential to prevent failure of
electrical components.
Do not trap the power supply cord under the television
receiver.
Never stand on, lean on, or suddenly push the television or
its stand. You should pay special attention to children.
Serious injury may result if it falls.
Do not place your television on an unstable cart, stand, shelf
or table. Serious injury to an individual , and damage to the
television, may result if it falls. Recommended to utilize rear
mount screw holes for anti-tipping (hardware not included).
When the television receiver is not used for an
extended period of time, it is advisable to disconnect
the AC power cord from the AC outlet.
Avoid exposing the television receiver to direct sunlight
and other sources of heat. Do not stand the television
receiver directly on other products which give off heat,
e.g. video cassette players and audio amplifiers. Do not
place naked flame sources, such as lighted candles on
the television.
Dim:515 *320mm(不包 括底座)
If the television is to be built into a compartment or similar
enclosure, the minimum distances must be maintained. Heat
build-up can reduce the service life of your television, and
can also be dangerous.
-3-

INTRODUCTION
Antenna
Main features Accessories
50" wide screen for a complete home theater experience
Super slim LCD TV with LED backlight
3840 x 2160 native resolution for UHD performance
Integrated ATSC TV tuner for HDTV broadcast reception
Beautiful color depth with a contrast ratio of 5000:1
HDMI inputs for true digital connections
®
Specifications
Resolution:
Aspect Ratio:
TV System:
Video Signal System:
Receiving Channel:
Input Power Voltage:
Power Consumption:
YCb(Pb)Cr(Pr) Input
Viewing Picture Size(diagonal)
3840 x 2160
16:9
120W
Audio Output Power(THD 7%): 2 x 10W
NTSC
Cable :1-135/ Air: 2-69(ATV&DTV)
High-Definition Multimedia Interface(HDMI) Input x 3
x 1
50"class (50"diagonal)
Composite Video Input
AC 100-240V 50/60Hz
ATSC Digital system and NTSC Analog system
x 1
1123 x 250 x 710 mm
44.21 x 9.84 x 27.95 inch
Audio Input
Headphone Output
Coaxial
USB 2.0 Input
Dimensions (approx)
with stand fitted(WxDxH)
Net weight 11.51 kg (25.38 lbs) with STAND
x 1
x 1
x 2
x 1
Infrared Remote Control...................
1
User’s M anual ...............................
1
Battery(AAA) .................................. 2
Screws........................................... 4
Base stand......................................2
Component adaptor cable.................2
“This product is manufactured, distributed, serviced and warranted exclusively by SHENZHEN
MTC CO., LTD.. “JVC” is the trademark of JVC KENWOOD Corporation, used by such company
under license.”
-4-
LAN x 1
The Adopted Trademarks HDMI, HDMI High-Definition Multimedia Interface, and the HDMI
Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the
United States and other countries.
Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the
double-D symbol are trademarks of Dolby Laboratories.

INSTALLATION
Front panel
REAR Connections
SIDE Connections
All the terminals are(from left to right): HEADPHONE, COAXIAL, LAN, HDMI3, HDMI2, RF.
VIDEO L ROPTICAL
All the terminals are (from left to right):
HDMI1(ARC), USB2.0, USB2.0, VIDEO/YPbPr, AUDIO.
1: Remote control sensor.
2: Indicator LED: RED STANDBY.
3: Key board
3
2
1
≤8m
Bottom
1. Middle Button: press longtime for “power” function;
2. Up/Down: CH+/-
3. Left/Righ: VOL-/+
press once for “source” function
The keyboard is located at the bottom left near the right side of signal indicator.
KEYBOARD
Rocker
HDMI3 HDMI2
HEADPHONE COAXIAL LAN RF
HDMI1(ARC) USB2.0 USB2.0 V/YPbPr AUDIO
0
7 8 9
456
1 2 3
VOL CH
MTS/AUDIO
CC/SUBTITLE
TTS
CH
EXIT
OK
INFO
SOUNDASPECT
-5-

INSTALLATION
Antenna
PRESET MODE (HDMI)
1
2
3
800*600
1024*768
60
60
37.88
48.36
RESOLUTION V.Freq.(Hz) H.Freq.(KHz)
1366*768 60 47.7
41280*768 60 47.3
5
1920*1080
60 67.5
63840*2160 30 67.5
750 112.5
860 135
3840*2160
3840*2160
CABLE
When shipped from the factory, the Signal Type option is for the RF connector (F-type) set to
the"AIR" (Over-the air antenna) mode.
Power connection
Please note: After unpacking, allow the TV to reach ambient room temperature before
connection the TV to the mains power socket.
Connect the power cord plug to the mains power socket.
-6-
OUTDOOR OR INDOOR ANTENNA
Note:
Aerial connections:F connector.
Input impendance:75 unbalanced.
PLUG
75Ω CABLE
ANTENNA OR CABLE TV
ADAPTER (NOT SUPPLIED)
TWIN-LEADER FEEDER (300Ω)
OUTDOOR OR INDOOR ANTENNA
(NOT SUPPLIED)

Prepare to place the TV with the display side down on a flat surface. Due to the size and
weight of this TV, the use of 2 people is recommended when moving it. Ensure the table or
desk you use provides a flat, totally clean surface, and use a soft cloth between the face of the
TV and the table to protect the TV's screen.
1. Locate the 2PCS of the base stand and insert it into the gap in the bottom of the TV , and
check that it is securely held in place as per a) below.
2.Lock 4 screws in the designated location as per b) below and check each screw is firmly
tightened.
INSTALLATION
Base Stand Assembly Instruction
The base stand
b)
4 x Screws( )4X14MM
-7-
a)

INSTALLATION
AV Equipment
You can use the rear input terminals as follows.
HDMI
VIDEO EQUIPMENT with YPbPr
GBR
G
B
R
G
B
R
HDMI1(ARC) USB2.0 USB2.0 V/YPbPr AUDIO
HDMI3 HDMI2
HEADPHONE COAXI AL LAN RF
HDMI
-8-
1 WAN2
3
4
W
R
W
R
W
R
Video Equipments: VCR, Multi Disc Player, DVD Player, Camcorder, Video Game, etc.
Video format that YPbPr supports: 480i, 576i, 480p, 720p, 1080i, 1080p, 2160p.

Wall Mount
Instruction for Wall Mount
A wall mount kit (purchased separately) would allow you to mount your JVC
TV on the wall. For detailed information on installing the wall mount, refer
to the instructions provided by the wall mount manufacturer. It is strongly
recommended to contact a technician for professional assistance for wall mount
installation. is not responsible for any damagJVC e to the product or injury to
yourself or others resulting from the wall-mounting.
This TV is compatible with a mounting hole pattern.JVC 200mm x 200mm
- Do not mount your TV at more than a 15 degree tilt.JVC
-Always use two people to mount the TV to a wall.
- Do not install your Wall Mount Kit while your TV is turned on. It may result in
personal injury due to electric shock.
- 4 pcs of type M6 screws are required for installing the wall mount bracket to
your TV. Do not use screws that are longer than 12 mm. Screws that JVC
are too long may cause damage to the inside of the TV set.
- Do not fasten the screws too tight for this may damage the TV or cause the
TV to fall, resulting in personal injury. is not liable for these kinds of JVC
incidents.
-9-
专案号
视图:
型号:
图号:
名称:六视图
批准
比例版本
图幅
单位
数量 1
材料
设计
mm
核对
A4
结构六视
图
深圳市兆驰股份有限公司}
QR-RD-014B
R
LD5560配61底座
1238
774
714
11
32
62
250
400
200
Dimensions for Mounting Hole Pattern

0
78 9
456
123
VOL CH
MTS/AUDIO
CC/SUBTITLE
TTS
CH
EXIT
OK
INFO
SOUNDASPECT
Overview of remote control
General Description
Loading batteries:
1) Remove the lid of the battery compartment.
2) Insert 2 size AAA batteries with polarities as indicated inside the compartment.
3) Replace the lid.
Note:
1) A loading of batteries should be last one year under normal use.
2) If you don't intend to use the remote control for a long period of time, remove batteries
to avoid damage due to leakage.
3) Do not mix old and new batteries or different types.
4) Do not throw batteries into fire or water.
5) The batteries (battery pack or batteries installed) should not be exposed to excessive
heat such as sunshine, fire or the like.
-10-

0
78 9
456
123
VOL CH
MTS/AUDIO
CC/SUBTITLE
TTS
CH
EXIT
OK
INFO
SOUNDASPECT
1. POWER: Turn the TV on and off.
2. MUTE: Press this button to cut off the sound of
the TV set temporarily, press again to resume.
3. Digital Buttons(0-9, -): Directly select channel
with digital buttons.
4. CH : Switch to the previous program.
5. YouTube: If network connects, press this key
to view YouTube directly.
6. VUDU: Press it to show channel list and favorite
list on screen.
7. : Press it to go to App home page.
8. NETFLIX: If network connects, press this key
to view NETFLIX directly.
9. INFO: Display the program information
: Display the main menu or exit the
current menu.
11. OK: Validation key.
12. Arrow button : Use to select
on-screen menu items and change menu
values.
13. : Return.
14. EXIT: Exit the menu.
15. COLOR It's used as it's showed
in the EPG or Program Edit menu.
16. : This button is used to switch among
different sources, Select a source and press
OK button to confirm
.
10.
s pqtu
BUTTONS:
General Description
Overview of remote control
-11-

0
78 9
456
123
VOL CH
MTS/AUDIO
CC/SUBTITLE
TTS
CH
EXIT
OK
INFO
SOUNDASPECT
ICTURE icture mode17. P : Select p .
18. VOL -: Press these buttons to adjust the
volume.
19. CH :
20. DIGITAL MEDIA PLAYER CONTROL
BUTTON: Include play/pause, stop,
backward, forward is used in USB mode .
Please refer to relevnat instructions in
the section of multimed player.
21. CC/SUBTITLE:
MTS/AUDIO: In USB mode, press this
button to switch audio track when movie
is playing. In TV mode, press this button
to switch MTS or Audio Language.
23. ASPECT: Press this button to set aspect,
such as 16:9,4:3,native,ect.
24. TTS: Press this button to set TTS on or off.
25. SOUND: Press this button to select sound
mode.
+/
/ Press these buttons to change
channel upward or downward.
In USB mode, press this
button to switch subtitles when movie is
playing.
22.
General Description
Overview of remote control
-12-

Installing Batteries in the Remote Control
General Description
Antenna connection
Antenna input impedance of this unit is 75ohm. VHF/UHF 75ohm coaxial cable can be
connected to the antenna jack directly, if the antenna cable is 300ohm parallel flat feeder
cable, you need to use the 300ohm/75ohm converter to connect the antenna cable to the
antenna jack. For details Please refer to the following drawing.
Use a 75ohm - 300ohm converter
300ohm coaxial cable
Antenna feeder
ANT IN
75ohm coaxial cable
Antenna cable
Antennas with 300 W flat twins Leads Antennas with 75 W Round Leads
External Connection
The batteries (battery pack or batteries installed) shall not be exposed to
excessive heat such as sunshine, fire or the like.
Installing Batteries
1Open the battery compartment
cover on the back side.
2Insert two 1.5V AAA size batteries in
correct polarity. Don´t mix old or used
batteries with new ones.
3Closed the cover.
Point the remote towards the remote
control sensor of the TV and use it
within 8 meters.
Put the used batteries into the recyc-
ling bin since they can negatively
affect the environment.
General Description
-13-

External Connection
Connecting VCR
These instructions assume that you have already connected your TV to an antenna or a cable
TV system. Skip step 1 if you have not yet connected to an antenna or a cable system.
VCR Rear Panel
TV Rear Panel
White
Red
ANT ANT OUT S-VIDEO AUDIO OUT
Red
Blue
Green
VIDEO OUT
23
1
2
1
3Audio Cable (Not supplied)
YPbPr cable( supplied) Not
RF Cable (Not supplied)
Follow the instructions in Viewing a VCR or Camcorder Tape to view your VCR tape.
Each VCR has a different back panel configuration.
When connecting a VCR, match the color of the connection terminal to the cable.
1. Unplug the cable or antenna from the back of the TV.
2. Connect the cable or antenna to the ANT IN terminal on the back of the VCR.
3. Connect an RF Cable between the ANT OUT terminal on the VCR and the ANT IN terminal on the
TV.
4. Connect a Component Cable between the COMPONENT [Y, Pb, Pr] jacks on the DVD player and
YPbPr jack on the TV.
5. Connect Audio Cables between the AUDIO OUT jacks on the VCR and the AUDIO L and
AUDIO R jacks on the TV.
Note:
1. Whenever you connect an external device to your TV, make sure that power on the unit
is turned off.
2. When connecting an external device, match the color of the connection terminal to the
cable.
Pb
Pr
Y/V
L
R
V/YPbPr
AUDIO
Red
Blue
Green
Red
White
2
3
1
-14-
HDMI3 H DMI2
HEADP HONE CO AXIAL LAN RF

External Connection
Connecting a Camcorder
The rear panel jacks on your TV make it easy to connect a camcorder to your TV. They allow you
to view the camcorder tapes without using a VCR.
Each Camcorder has a different back panel configuration.
When connecting a Camcorder or DVD, match the color of the connection terminal to the cable.
Video
Green
1. Connect a Video Cable between the AV VIDEO in jacks on the TV and the VIDEO OUT jack
on the camcorder.
2. Connect Audio Cables between the AUDIO L and AUDIO R jacks on the TV and the AUDIO
OUT jacks on the camcorder.
3. Connect a Video Cable between the AV VIDEO IN jacks on the TV and the VIDEO OUT jack
on the DVD.
4. Connect Audio Cables between the component IN AUDIO L and R jacks on the TV and the
AUDIO OUT jack on the DVD.
Notes:
1. Whenever you connect an external device to your TV, make sure that power on the unit
is turned off.
2. When connecting an external device, match the color of the connection terminal to the
cable.
White
Red
Camcorder
Video Cable (Not supplied)
1
Audio Cable (Not supplied)
2
Pb
Pr
Y/V
L
R
V/YPbPr
AUDIO
Green
Red
White
-15-

External Connection
Connecting Digital Audio System
This connection can only be made if there is a HDMI Output connector on the external device.
HDMI Cable (Not supplied)
What is HDMI?
HDMI, or high-definition multimedia interface, is a next-generation interface that enables the
transmission of digital audio and video signals using a single cable without compression.
Multimedia interface is a more accurate name for it especially because it allows multiple channels
of digital audio (5.1 channels).
The difference between HDMI and DVI is that the HDMI device is smaller in size, has the HDCP
(High Bandwidth Digital Copy Protection) coding feature installed, and supports multi-channel digital
audio.
Each DVD player/STB has a different back panel configuration.
Connect an HDMI Cable between the HDMI1, HDMI2, HDMI3 connector on the TV and the HDMI
connector on the DVD player/Set-Top Box.
Notes:
1.Whenever you connect an external device to your TV, make sure that power on the unit
is turned off.
2.When connecting an external device, match the color of the connection terminal to the
cable.
-16-
HDMI3 HDMI 2
HEADPHON E COA XIA L LAN RF

Connecting PC
External Connection
Supporing Signals
Input Mode
Digital
Analog
ATSC
CVBS PAL/NTSC
PAL-M/PAL-N/NTSC M
The rear panel jacks on your TV make it easy to connect a Digital Audio System to your TV.The rear panel jacks on your TV make it easy to connect a Digital Audio System to your TV.
5.1 CH audio is possible when the TV is connected to an external device supporting 5.1 CH.
Connect an OPTICAL Cable between the OPTICAL jacks on the TV and the Digital Audio Input jacks
on the Digital Audio System. When a Digital Audio System is connected to the OPTICAL terminal:
Decrease the gain (volume) of the TV, and adjust the volume level with the
volume control.
Digital Audio System's
Digital Audio System
(Black)
TV Rear Panel
COAXIAL
Resolution
Input
Component
60Hz
60Hz
50Hz/60Hz
480i
480p
720p
50Hz/60Hz
1080i
HDMI 50Hz/60Hz
50Hz/60Hz
480p
720p
60Hz
1080i
Vertical
Frequency
50Hz/60Hz
1080p
50Hz/60Hz
1080p
3840x2160 24Hz/25Hz/30Hz/60Hz
-17-
HDMI3 HDMI 2
HEADPHON E COA XIA L LAN RF
(Not included)

Basic Operations
Menu Operation
1 Input Setup
Press key on the remote control to enter "INPUT SOURCE" menu. There are
these options for you to select: "TV", "AV","Component", "HDMI1", “HDMI2",
“HDMI3", “USB".
Use t/ukey to select a input source and press OK key to confirm.
2 Channels Selection
There are four ways to select channel:
1) Using number keys, and OK keys on the remote control
to select channel directly.
To select channel 90, press .
When you use the number buttons, you can directly select channels that were either erased
or not memorized.
2) Using CHr/s key on the remote control or on your TV to select channel.
When you press the CHr/s key, the TV changes channels in sequence. You will see all
the channels that the TV has memorized.
You will not see channels that were either erased or not memorized.
3) Press CH key to return to previous channel, press it again to return to
current channel.
To quickly switch between two channels that are far apart, tune to one channel, then use the
number keys to select the second channel. Then use the CH button to quickly
alternate between them.
CH is not activated if no channel has been changed after TV turning on.
4) Select channels from "Channels List" or "Favorite List".
Press OK key to choose from "Channel List" menu.
3 Volume Adjustment and Mute Setup
Volume adjustment
Press VOLr/s key on the remote control or the TV to display "Volume" menu,
adjust the volume of TV between 0 to 100 by using VOLr/skey:
Input Source
90OK
HDMI 2AV Component HDMI 1
Input Source
TV AV Component HDMI 2 HDMI 3
Input Source
HDMI 3 USB
HDMI 1
-18-
Table of contents
Other JVC UHD TV manuals
