KALE Hello light HL-ML6P60D User manual

660B
6*60w double face Led pixel zoom and strobe
bar moving head
User manual
P le a se rea d t he ins t r u ction s ca refu ll y before use

2
TABLE OF CONTENTS
1. S af ety I nst r uctions ......................................................................................1 - 4
2. Technical Specifications ......................................................................................... 5
3. How To Control The Unit ........................................................................................ 7
4. DMX Channel List....................................................................................10-23
5. Shape.........................................................................................................................24
6.
Trouble shooting..............................................................................................2 5
statement
The product has well capability and intact packing when leave
factory. All of the user should comply with warning item and manual, any
misuse cause of the damages are not included in our guarantee, and
also can not be responsible for any malfunction & problem owing to
ignore the manual.
1. S af ety I nst r uctions
Please keep this User Guide for future consultation. If you sell the unit to another

3
user, be sure that they also receive this instruction booklet.
 Unpack and check carefully there is no transportation damage before using
the unit.
 Before operating, ensure that the voltage and frequency of power
supply match the power requirements of the unit.
 It’s important to ground the yellow/green conductor to earth in order
to avoid electric shock.
 The unit is for indoor use only. Use only in a dry location.
 The unit must be installed in a location with adequate ventilation, at
least 50cm from adjacent surfaces. Be sure that no ventilation slots are
blocked.
 Disconnect main power before replacement or servicing.
 Make sure there are no flammable materials close to the unit while operating as
it is fire hazard.
 Use safety cable when fixes this unit. DO NOT handle the unit by taking its head
only, but always by taking its base.
 Maximum ambient temperature is Ta: 40℃.DO NOT operate it where the
temperature is higher than this Unit surface temperature may reach up to 85℃.
DO NOT touch the housing bare-hand during its operation. Turn off the power
and allow about 15 minutes for the unit to cool down before replacing or serving.
 the event of serious operating problem, stop using the unit immediately.Never
try to repair the unit by yourself. Repairs carried out by unskilled people can
lead to damage or malfunction. Please contact the nearest authorized
technical assistance center. Always use the same type spare parts.
 DO NOT touch any wire during operation as high voltage might be causing
electric shock.
Warning:

4
 To prevent or reduce the risk of electrical shock or fire, do not expose the unit to
rain or moisture.
 DO NOT open the unit within five minutes after switching off.
 The housing, the lenses, or the ultraviolet filter must be replaced
if they are visibly damaged.
Caution:
There are no user serviceable parts inside the unit. DO NOT open the housing
or attempt any repairs yourself. In the unlikely event your unit may require
service, please contact your nearest dealer.
Installation:
The unit should be mounted via its screw holes on the bracket. Always ensure that
the unit is firmly fixed to avoid vibration and slipping while operating.
And make sure that the structure to which you are attaching the unit is secure
and is able to support a weight of 10 times of the unit’s weight. Also always use a
safety cable that can hold 12 times of the weight of the unit when installing the
fixture.
The equipment must be fixed by professionals. And it must be fixed at a place
where is out of the touch of people.
2. Technical Specifications
Light Sources:
Zoom wash face: 6*60W 4IN1 RGBW LED;
Strobe face: 20*10W white led+384*0.5W 3in1 RGB Led
Beam Angle:4.5°- 55°
PMMA high quality and high output optic
Power Consumption: 700w

5
Power Voltage: AC 100-260V, 50/60Hz
Control
DMX Channel:34/54 Channels
Control Protocol: DMX512/RDM
Pan/Tilt
Pan / Tilt : Infinite Rotation
Pan/Tilt Resolution: 8/16 bit
Magnetic coded reset system is adopted
Construction
Display:2.4 inch 180° reversible colorful LCD Display
Data In/Out socket: 3-pin & 5-pin XLR sockets
Power Socket: Power-Con in
Protection Rating: IP20
Reset the light fixture by menu or console
Equipped with Small and easy to operate Pan & Tilt fix lock
Dimension:640*210*400 mm
Net Weight:18 kg
Features
Double face moving head with beam, wash, strobe effect
Good to use for stage effect, background or stage shape
Dimmer:0~100% smooth dimming
Four dimmer model in optional( delay or without delay)
Led single controlled
Strong beam effects with high brightness
Led temperature protection & auto adjust led brightness
Fan run speed automatic based on the head temperature.

6
3.LUX Data ( 6x60W wash face data)
4. Display & Menu

7
Display:
MENU To select the programming functions
DOWN To go backward in the selected functions
UP To go forward in the selected functions
ENTER To confirm the selected functions
Set DMX Address Code
1 Press "Menu" to "Set DMX Address",and press"ENTER" keys to enter
into
2 Show "Set DMX Address DMX Address:001",Press the "UP and DOWN"
keys to amended
3Press "ENTER"keys to save and Exit,Press the"MENU"Keys does not
save and Exit
Menu
Pan Degree
540 degree
360 degree
Mic Sense
001
- 100,Sound sensitivity adjustment
Language
English
Chinese
Reset
Yes
No
Default
Yes
No
Adjust
Pass Word:up+down+up+down
Pan
0 - 255
Tilt
0 - 255
Focus
0 - 255
Red
0 - 255
Green
0 - 255
Blue
0 - 255
White
0 - 255
Address
Setting from 001 - 512
Pan
1.Yes
2.No

8
Reverse
Forward or
reversed
setting
Tilt
1.Yes
2.No
Display
1.Yes
2.No
Inform
1.CH Value
Each channel value
2.Temp ____℃Temperature of led board
3.Soft V1.0 Show the version number
Mode
DMX 512
Control by DMX console
AUTO
Master
Alone
SOUND
Master
Alone
Manual
Master
Pan:0--255
Manual control
(“1”
mean wash
zoom face;
“2”
means strobe
face)
Tilt:0--255
Focus:0--255
Red1：0--255
Green1: 0--255
Blue1: 0--255
White1: 0--255
Alone
Strobe1：0--255
Red2：0--255
Greed2：0--255
Blue2：0-255
White2:0--255

9
Strobe2:0-255
Channel
45 channels
45 channel mode
Channel
25
channels 25 channel mode
5.DMX Channel List
Model 1 - CH54
Channel Function Description Value
CH-1 Pan Pan adjustment 0 --- 255
CH-2 Pan fine Pan fine adjustment 0 --- 255
CH-3 Tilt Tilt adjustment 0 --- 255
CH-4 Tilt fine Tilt fine adjustment 0 --- 255
CH-5 Pan/Tilt speed from fast to slow 0 --- 255
CH-6
Pan infinite rotation
No function 0 --- 55
Rotating from slow to fast 56 --- 155
Rotating from slow to fast 156---255
No function 0 --- 55

10
CH-7 Tilt infinite rotation
Clockwise rotating from
slow to fast
56 --- 155
Anticlockwise rotating from
slow to fast
156---255
CH-8
6x60W
wash
face
strobe
No function 0-15
Strobe from fast to slow 16--214
Random strobe 215--225
CH-9 Dimmer From dark to bright 0-255
CH-10
Dimmer mode
Model - 1 0 --- 49
Model - 2 50 --- 99
Model - 3 100--- 149
Model - 4 150--- 255
CH-11 zoom Angle from big to small 0 --- 255
CH-12 Red - 1
From dark to bright
0 --- 255
CH-13 Green - 1
CH-14 Blue - 1
CH-15 White - 1
CH-16 Red - 2
0 --- 255
CH-17 Green - 2
CH-18 Blue - 2

11
CH-19
6x60W
wash
face
White - 2
CH-20 Red - 3
0 --- 255
0 --- 255
CH-21 Green - 3
CH-22 Blue - 3
CH-23 White - 3
CH-24 Red - 4
From dark to bright
0 --- 255
CH-25 Green - 4
CH-26 Blue - 4
CH-27 White - 4
CH-28 Red - 5
0 --- 255
CH-29 Green - 5
CH-30 Blue - 5
CH-31 White - 5
CH-32 Red - 6
0 --- 255
CH-33 Green - 6
CH-34 Blue - 6
CH-35 White - 6
No function 0----15
R 100%,G up,B0% 16----35
R down,G 100%,B0% 36----55

12
CH-36
CH-36
6x60W
wash
face
Static color
Static color
R 0%,G 100%,B up 56----75
R 0%,G100%,B up 76----95
R up,G0%,B100% 96----115
R 100%,G0%,B down 116----135
R 100%,G up,B up 136----155
R100%,G down,B100% 156----175
R100%,G
100%,B100%,W100%
176----195
2800K 196----200
3200K 201----205
3500K 206----210
4000K 211----215
4500K 216----220
5000K 221----225
5500K 226----230
6000K 231----235
6500K 236----240
7000K 241----245
7500K 246----250
8000K 251----255

13
CH-37
CH-38
6x60W
wash
face
Effect
No function 0 ----9
3 DMX value per effect 10 --- 99
Jump change 100--- 149
gradual change 150--- 255
Patterns
Static Pattern -1 0 --- 9
Static Pattern -2 10 --- 19
Static Pattern -3 20 --- 29
Static Pattern -4 30 --- 39
Static Pattern -5 40 --- 49
Static Pattern -6 50 --- 59
Static Pattern -7 60 --- 69
Static Pattern -8 70 --- 79
Static Pattern -9 80 --- 89
Static Pattern -10 90 --- 99
Static Pattern -11 100--- 109
Static Pattern -12 110--- 119
Static Pattern -13 120--- 129
Static Pattern -14 130--- 139
Static Pattern -15 140--- 149

14
CH-38
6x60w
wash
face
Static Pattern -16 150--- 159
Dynamic Pattern -1 160--- 169
Dynamic Pattern -2 170--- 179
Dynamic Pattern -3 180--- 189
Patterns
Dynamic Pattern -4 190--- 199
Dynamic Pattern -5 200--- 209
Dynamic Pattern -6 210--- 219
Dynamic Pattern-7 220--- 229
Dynamic Pattern -8 230--- 255
CH-39 Pattern change speed 0 --- 255
CH-40 Pattern change fade 0 --- 255
CH-41 Pattern with Red color from dark to bright
0 --- 255
CH-42 Pattern with green color from dark to bright
CH-43 Pattern with blue color from dark to bright
CH-44 Pattern with white color from dark to bright
CH-45
Strobe
face
Dimmer From dark to bright 0--255
CH-46 Strobe
Led on 0---3
Synchronously strobe
speed from slow to fast
4--203
Random strobe 201--255
CH-47 Dimming of middle area white led from dark 0--255

15
to bright
CH-48 Dimming of two side red led from dark to
bright
0--255
CH-49
Strobe
face
Dimming of two side green led from dark to
bright
0--255
CH-50 Dimming of two side blue led from dark to
bright
0--255
CH-51
Dynamic
patterns
No function 0--9
Dynamic pattern 1 10--19
Dynamic pattern 2 20-29
10 DMX value per pattern .......
Dynamic pattern 16 160--255
CH-52 Patterns
translation
(work with CH
51)
Select pattern scene 0--255
CH-53
Pattern auto
run speed
(work with CH
51)
No function 0--9
forward run fast to slow 10--132
Reverse run slow to fast 133--255
CH-54 Reset
No function 0--9
Reset 10--132
No function 133-255

16
Model 2 - CH34
Channel Function Description Value
CH-1 Pan Pan adjustment 0 --- 255
CH-2 Pan fine Pan adjustment 0 --- 255
CH-3 Tilt Tilt adjustment 0 --- 255
CH-4 Tilt fine Tilt adjustment 0 --- 255
CH-5 Pan/Tilt speed from fast to slow 0 --- 255
CH-6
Pan infinite rotation
No function 0 --- 55
Clockwise rotating from
slow to fast
56 --- 155
Anticlockwise rotating
from slow to fast
156---255
CH-7 Tilt infinite rotation
No function 0 --- 55
Clockwise rotating from
slow to fast
56 --- 155
Anticlockwise rotating 156---255

17
from slow to fast
CH-8 6*60w
wash
face
Strobe
No function 0 --- 15
from slow to fast 16 --- 214
Random strobe 215---255
CH-9 Dimmer From dark to bright 0 --- 255
CH-10 Dimmer Model
Model - 1 0 --- 49
Model - 2 50 --- 99
Model - 3 100--- 149
Model - 4 150--- 255
CH-11
6*60w
wash
face
Zoom Angle from big to small 0 --- 255
CH-12 Red
From dark to bright 0 --- 255
CH-13 Green
CH-14 Blue
CH-15 White
No function 0----15

18
CH-16
6*60w
wash
face
Static
color
R 100%,G up,B0% 16----35
R down,G 100%,B0% 36----55
R 0%,G 100%,B up 56----75
R 0%,G100%,B up 76----95
R up,G0%,B100% 96----115
R 100%,G0%,B down 116----135
R 100%,G up,B up 136----155
R100%,G down,B100% 156----175
R100%,G
100%,B100%,W100%
176----195
2800K 196----200
3200K 201----205
3500K 206----210
4000K 211----215
4500K 216----220
5000K 221----225

19
CH-16
6*60w
wash
face
Static
color
5500K 226----230
6000K 231----235
6500K 236----240
7000K 241----245
7500K 246----250
8000K 251----255
CH-17
Effects
No function 0 ---- 9
3 DMX value per effect 10 --- 99
Jump change 100 --- 149
gradual change 150 --- 255
Pattern
Pattern -1 0 --- 19
Pattern -2 20 --- 29
Pattern -3 30 --- 39
Pattern -4 40 --- 49
Pattern -5 50 --- 59

20
CH-18 6*60w
wash
face
6*60w
face
Pattern
Pattern -6 60 --- 69
Pattern -7 70 --- 79
Pattern-8 80 --- 89
Pattern -9 90 --- 99
Pattern -10 100 --- 109
Pattern -11 110 --- 119
Pattern -12 200 --- 255
CH-19 Pattern change speed 0 --- 255
CH-20 Pattern change fade 0 --- 255
CH-21 Pattern with Red from dark to bright 0 --- 255
CH-22 Pattern with Green from dark to bright 0 --- 255
CH-23 Pattern with Blue from dark to bright 0 --- 255
CH-24 Pattern with White from dark to bright 0 --- 255
CH-25 Dimmer 0-100% linear dimmer 0--255
CH-26 Strobe Led on 0--3
