Kalora FUSION User manual

Contents of manual may be updated without notice.
For the latest version of this manual please refer to our website: www.kalora.com.au
Ka.Fus Version 1.0 07/12/18
FUSION
USER MANUAL
KAF50
Kalora Pty Ltd
Head Oice
58 Access Way
Carrum Downs VIC 3201
Australia
[phone]
[e-mail]
www.kalora.com.au

1
Wood heater safety 2
Before installing your wood heater 3
Installation 4
Operating your wood heater 8
Wood heater maintenance 10
Trouble shooting 12
Hot water generator installation 13
Warranty 14
CONTENTS
INTRODUCTION
Congratulations on purchasing a genuine Kalora Wood heater. When cared for properly, these high quality, nely craed
wood heaters will oer many years of reliable performance. This instruction manual has been developed to ensure optimum
performance from your Kalora wood heater. It’s very important that you thoroughly read and understand all instructions
before using your new wood heater.
COUNCIL REQUIREMENTS
Check Local Council Requirements E.g. permits
When installing, operating and maintaining your wood heater, follow the guidelines presented in these instructions, and make
them available to anyone using or servicing the wood heater.
Your city, town, state or territory may require a building permit to install a solid fuel burning appliance.
Always consult your local building inspector or local council to determine what regulations apply in your area.
Your wood heater must be installed by a qualied person whose work
conforms with local council regulations, Australian standards & manufacturers
recommendations. Failure to do so will void your warranty and could possibly
void any home insurance.
Please note:
KALORA HEATER RANGE
Model Name
Kalora Fusion KAF50

2
1. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
2. Children should be supervised to ensure that they do not play with the appliance.
3. If the electrical supply cord is damaged, it must be replaced by the manufacturer, it’s service agent or similarly
qualied persons in order to avoid hazard.
4. Never place combustible items such as but not limited to furniture, fabric or wood within the specied clearances
to combustibles.
5. The burning of wood gives o gases which can be extremely dangerous. Wood heaters are designed so that under
normal operating circumstances these gases pass up the ue chimney system and cannot escape into your home,
however it is important that your ue system is properly installed and that you check all joints regularly to ensure
that there are no cracks or gaps, check the door sealing rope and replace when damaged/worn. We recommend a
smoke alarm be tted in rooms where wood heaters are installed. Do not use your wood heater in a room where
negative pressure conditions exist. Negative pressure environments can cause products of combustion to be drawn
from the replace into the room. Caution should be taken when using any form of extraction in a room where a
wood heater is installed.
6. This appliance is designed to specically burn dry hardwood. Do not burn rubbish, driwood, ammable liquids
or any substance containing salts or corrosives.
7. Creosote and soot may accumulate in your ue pipe and chimney. This may ignite, causing a chimney re. If you
suspect a chimney re close down the air controls on the wood heater, if the re persists evacuate people from
the building and call the Fire Brigade. To prevent the accumulation of soot or creosote, check ue and chimney
regularly and clean as necessary. Good burning, hot wood heaters will generally cause a lot less build-up than
slow burning wood heaters, likewise dry wood will cause less build-up than wet wood. We recommend a re
extinguisher be available where wood heaters are in operation. In the event of a chimney re do not re-light the
wood heater until the heater and the ue chimney system have been thoroughly checked and repaired/replaced as
necessary.
8. Wood heaters get extremely hot and should not be touched when lit. When young children are in the area, we
recommend the use of a suitable re guard around the wood heater. Always wear protective gloves when reloading
wood heater.
9. Never over-re your wood heater. If external parts of your wood heater are glowing red then the wood heater is
over-ring and your draught settings should be reduced. Never interfere with the draught mechanisms or adjust
your air settings outside those limits set when the wood heater is manufactured. Never use a secondary fan to
supply or extract air to the wood heater.
10. All users of the wood heater should be aware of the contents of this manual. Please leave this manual where it is
accessible to wood heater users and do not allow anyone to use the wood heater that is unfamiliar with its correct
operation.
11. Never use the wood heater if any parts are missing or damaged, only use genuine parts as replacements.
Never modify your wood heater.
WOOD HEATER SAFETY
When properly maintained and operated your wood heater should give you many years of service,
however there are important safety aspects of these products that you need to be aware of when operating a wood heater.

3
BEFORE INSTALLING YOUR WOOD HEATER
You need to consider the following to ensure the safe operation of your wood heater:
- Provision of adequate air to support eicient combustion of the fuel.
- A well sealed ue/chimney system, hereinaer referred to as the “ue system”.
- The protection of combustible materials in proximity of the wood heater.
- A suitable base on which to place your wood heater.
ADEQUATE PROVISION AIR
It is essential for the safe and eicient use of your wood heater that you provide an adequate air supply to your wood heater.
This may mean the provision of an outside air supply to the room, especially if there are extraction units such as cooker hoods
or clothes dryers in the vicinity. Failure to do so will mean that fuel is burned ineiciently causing smoke, blackening the glass
and may also cause smoke to come back into the room. As a simple check for this open a door or window in the room and
check if the wood heater burns more eiciently.
WELL SEALED FLUE SYSTEM
Under no circumstances should you use aluminum or galvanized steel pipes for your wood heater ue. Always t pipes with
the narrow crimped side down, this allows any creosote to run down the inside of the pipe and not to come out and cause an
unsightly mess and possible re hazard.
Pipe bends should be kept to a minimum and we do not recommend using more than 2 bends on any installation. Flues must
not pass through ceilings, oors, attics, roofs, or combustible walls without adequate and approved insulation being provided
to protect combustible materials.
The chimney and ue provide a means of taking combusted fuel from the wood heater, as well as a draught to enable the
wood heater to work. It is essential that the ue system is kept in good condition and there are no breaks or cracks allowing
contact with any other combustible materials of the house. It is also essential that the ue system is kept clean and seals are
maintained to ensure the draught is not lost.
The open end of the ue system must be above the height of the apex of the building and any other obstructions, such as trees,
which are within 3 meters (10) of the ue system. Failure to do this will aect the eiciency of the wood heater and may cause
down draughts which will mean dangerous products of combustion are emitted into the room.
Under no circumstances should the ue pipe be less than 6” (152mm) internal diameter.
When unpacking, please remove the cleaning
brush located in the ue collar.
Hot Plates can be found in Lower Ash Tray
Firebox liners are a consumable item and may
warp during use.
(See maintenance guide P.10 for details)
PLEASE NOTE

4
ASide of heater to side wall 425
BCentre of heater ue to rear wall 295
CRear of heater to rear wall 175
DFront of heater to hearth front 300
EMinimum hearth width 820
FMinimum hearth depth 1060
GRear corner of heater to wall 200
HMinimum Corner Hearth Depth 1265
All measurements are in ‘mm’
When using either Kalora decorative mesh or sleek black ue kit
which are both tted with an additional heat shield.
Manufacturers recommendation: Keep all combustible materials at least 1.22 metres (4 feet) away from the appliance. This
include rugs, fabrics, furnishings, papers, rewood, etc. NEVER dry clothing on or within 1.22 metres of the appliance.
INSTALLATION
CLEARANCES TO COMBUSTIBLES
BEFORE INSTALLING YOUR WOOD HEATER ....continued
CLEARANCES TO COMBUSTIBLES
It is extremely important that you respect required installation distances and that you respect local installation regulations.
This is for your safety! The manufacturer is not responsible for the product, if it is not installed following these
recommendations. These clearances may only be reduced by means approved by the regulatory authority.
A combustible surface is anything that can burn (i.e. plaster, wall paper, wood, fabrics etc.) These surfaces are not limited
to those that are visible and also include materials that are behind non-combustible materials. If you are not sure of the
combustible nature of a material, consult your local re oicials.
HEARTH REQUIREMENTS
The oor protector must consist of 30mm thick cement bre sheet which has a thermal resistance of 0.008m2 K/W, per 4mm
thickness or equivalent. Kalora have a complete range of suitable ready to install hearth pads for straight wall and corner
installations.

5
1. Locate wood re in it’s proposed position according to manufacturers recommendations.
2. Use a plumb bob to mark the ceiling in line with the centre of the ue collar.
3. Check that the outer casing will clear all combustible materials by 25mm. Determine positions of noggins to avoid
cutting, otherwise headers must be installed for strength.
4. Cut a 305mm diameter hole in the ceiling. Directly above cut a hole in the roof to accommodate outer casing.
5. Fix the angle brackets to the joists so that the drop box (rst length of located casing) is located in the centre of the
hole.
ANTI DOWN DRAFT COWL
ROOF
COVER CONE
SECURE COVER CONE TO CASING W/ SCREW
ROOF FLASHING (NOT SUPPLIED IN KIT)
MIDDLE 8” GALVANISED CASING
OUTER 10” GALVANISED CASING
RAFTER
JOIST
CEILING
HEATER
HEATER FLUE COLLAR
DECORATIVE CASING POSITION, SEAM TO REAR
CERAMIC SPACERS
ANGLE BRACKET
CEILING COLLAR FIXED WITH SCREW,
WITH CERAMIC SPACERS BETWEEN
CEILING COLLAR AND THE CEILING
INNER 6” STAINLESS STEEL FLUE
(CRIMPED END DOWN)
180 FIXED HEAT SHIELD
Min 150mm of drop box must
extend from any combustible
surface including ceiling
Min 25mm from outer
casing to any combustible
material
Min 25mm
LOCATION TAG
INSTALLATION ....continued
FOR CONNECTING INTO A STANDARD INSTALLATION
USING KALORA FLUE KITS
The following drawing is meant as a guide only. Your wood heater must be installed by a qualied person whose work
conforms with local council regulations, Australian/New Zealand standards (AS/NZS 2918:2018) & manufacturers
recommendations.
Kalora wood heaters are independently tested to Australian Standards using a Kalora ue kit, we always recommend using
a Kalora ue kit when installing a Kalora wood re.

6
6. Position the drop box between the angle brackets, keeping a 25mm clearance to combustibles. The located end of
the drop box must protrude no less than 150mm down from the ceiling or any combustible material. Fix the drop
box to the angle brackets.
7. Add the remaining casings to the required height. Australian/New Zealand Standards state that “the ue pipe shall
extend not less than 4.6m above the top of the oor protector”. If the ue pipe is within 3 metres of the ridge, the
ue pipe must protrude at least 600mm above the ridge of the roof. If the distance from the ridge is more than 3 me-
tres, the ue pipe must protrude at least 1000mm above roof penetration. Additional lengths of casing and ue may
be required to achieve this. The ue pipe must be more than 6 metres from any nearby structure. Other clearances
may be applicable, it is up to the installer to ensure compliance with all regulations. See Figure 1 and 2 on P7.
8. Install roof ashing (Additional accessory, not supplied in ue kit)
9. Secure the Ceiling Collar in place using ceramic spacers and screws provided.
10. Insert crimped end of the upper decorative ue (without internal stainless steel heat shield) up into the drop box.
Then insert the crimped end of the lower decorative ue (with the internal stainless steel heat shield) up into
bottom of the upper decorative ue. The lower decorative ue features locating tags on the non crimped end which
rest on the heater ue collar. The solid heat shield section of the decorative mesh and stainless steel inner heat
shield is to face the wall.
11. Feed stainless steel ue through decorative ue and drop box through to the required height. Assemble ue pipes
tight together as you go ensuring seams are straight. Secure each joint with three stainless steel rivets or screws
spaced equally. Clean any nger prints or oils o stainless steel ue with methylated spirits.
12. Trim the inner ue to the same height as the outer casing. Place cover cone and cowl over stainless steel ue & push
cover cone over gal casing. Fix cover cone to gal casing with stainless steel pop rivets or screws.
FOR CONNECTING INTO EXISTING MASONRY CHIMNEY
Any chimney should be fully intact with no holes or missing bricks. We recommend a chimney register be installed above any
installation into a masonry replace minimising heat loss up the chimney. The top of the chimney must be sealed using a
chimney plate which should be sealed in place with a mortar mix.
Active ue should be trimmed in line with the top of the chimney if it meets the minimum height requirements under
AS/ NZS 2918. If additional lengths are required to fulll this requirement these lengths must be cased. The ue should always
be nished with a cowl and cone.
INSTALLATION ....continued

7
6m
Increase flue length as
necessary until nothing
within 6m of flue top
ANY NEARBY
STRUCTURE
MINIMUM INSTALLATION CLEARANCES
FIGURE 1
FIGURE 2

8
When operating, this unit will get extremely hot. Do Not Touch, use tools where
necessary. You should begin using your wood heater by lighting small res which
get progressively larger. We recommend lighting approximately 5 small res before
you put the wood heater into full service. Allow the wood heater to fully cool
between each of these res. There may be some smell and a small amount of smoke
from the wood heater during the initial operations. This is perfectly normal and is
merely the curing of the wood heater paint. Opening a window or door to provide
additional ventilation will help alleviate this.
WARNING: FIRST OPERATION OF STOVE
CONTROLS AND THEIR USE
1. Flue Damper Aids in lighting re.
Back = Open.
Forward = Closed.
2. Primary Air
Inlet Control
Provides primary air intake to regu-
late burn rate of re and keep glass
clean.
3. Secondary Air
Inlet Control
Provides secondary air intake direct-
ly to coal base to further regulate
burn rate of re.
4. Oven
Temperature
Control
Provides cool air to oven to further
regulate oven temperature.
(Burn rate of re will be the main
temperature regulation).
2
1
3
4
FUEL
Your wood heater is designed to burn dry hardwood only.
It is NOT designed to burn the following:
• So wood
• Treated or painted wood
• Paper or cardboard, other than small amounts
used to light stove.
• Plastics
• Synthetic fuel or logs that are not approved
for solid fuel stoves
• Household rubbish
• Liquid fuels
Burning these or other products for which the wood heater was not designed may damage the wood heater and cause a re
hazard or release toxic fumes.
Fuel should be stored in a dry place; wood should be dried for at least 1 year and have a moisture content of less than 20%.
Wet wood may cause serious creosote build up, which may damage your ue system and even your wood heater. Therefore the
use of green, sappy or wet wood is strongly discouraged.
OPERATING YOUR WOOD HEATER

9
OPERATING YOUR WOOD HEATER ....continued
AIR CONTROLS
Your wood heater needs air to burn the fuel, on this range this is supplied in two locations. The primary air slide at the right
side of the front of your wood heater above the door and the secondary air slide at the bottom of the rebox door.
Primary air, as the name suggests, is used for the initial burning of the fuel and is also used to keep the stove glass clean.
Secondary air is used for secondary combustion, which makes the stove more eicient, reduces the emissions by introducing
air directly over the re bed.
The settings of the primary and secondary air control very much depends on draught and local conditions and aer a few res,
you should have a good idea of the best settings for your stove. Both air slide controls should be fully opened when lighting
the re. Once the re is established, the primary air can be adjusted to where the glass remains clean and the secondary air
control may be adjusted as required. Reducing the air intake will cause the wood heater to burn slower. This may cause some
blackening of the stove glass, but this should burn o once the wood heater is burning brightly again.
The ue damper must be kept closed except when lighting the re. If oven is too hot for cooking lower temperature quickly by
opening the oven temperature control and the ue damper until required heat is reached and then close. Adjust air controls
so temperature is maintained. Keep the rebox door closed securely at all times except when de-ashing the re or reloading
wood.
Keep all combustible materials at least 1.22 metres (4 feet) away from the appliance. They include rugs, fabrics, furnishings,
papers, rewood, etc. NEVER dry clothing on or within 1.22 metres of the appliance.
LIGHTING THE FIRE
Open the re door, lay a few crumpled sheets of paper on the rebox base then a few small dry pieces of sticks or kindling.
Open the ue damper fully by pushing backwards. Open both the air inlet controls. Now light the paper, close the re door
when the kindling has caught re (allow about 10 minutes for this to happen) add larger pieces of dry wood, until the re box is
half lled. When the larger pieces of wood have caught re, add full sized logs, close the ue damper. Close the air controls to
the point where the required burn rate is obtained.
REFUELING
Before refueling your wood heater, turn the air supply to high for a few moments until there is a good re in the heater. This will
ensure there is no build-up of harmful gases in the wood heater when the door is opened and will also get the new fuel burning
quickly and not allow it to kill the re. Open the door slowly in case any logs or coal have fallen against the glass. Opening the
door quickly may result in smoke being drawn into the room.
To reload the wood heater, open the door and feed the fuel in slowly always using either tongs, a small shovel along with
protective gloves. Do not overll the wood heater. It is always better to put in small loads oen rather than big lls less
frequently. Wood should be loaded in a front to back direction, this helps air ow as well as reducing the risk of logs falling
forward. Close the door gently aer wood heater is reloaded.
OVERNIGHT BURNING
Your wood heater is designed to maximise burn times. Best results are achieved when you establish a good fuel bed in the
wood heater and allow it to burn for about 30 minutes before closing the air slide control fully.
When you return to your wood heater, fully open the air slide control until you have a good re and then set to normal
operating levels. Do not add fuel until the re bed is hot and red. Then add a little for the rst time and allow that to ignite
before adding more. During overnight burning, the wood heater glass may blacken, but when a hot re is established again this
should burn o.

10
1. Check your ue system and the void between the rebox and the outer skin of the unit for build up of soot or
creosote and for signs of damage to joints.
2. To inspect the area between the rebox and the outer skin remove the hotplate and inspection plates located on
the top and front of each unit. Using a ashlight to inspect and the wire brush provided to remove any built-up
residue.
3. On occasion during normal use and immediately aer cleaning remove bottom ash pan, empty, clean
and re-position.
4. During periods of inactivity or infrequent use, regularly alternate the position of the ue damper.
We also recommend placing a silica bag in the rebox to absorb any moisture which may cause rust.
5. The Fusion rebox is lined with steel rebox liners, these are designed to expand and contract which will warp to
some degree during use, this is normal. Replacement of the liners should be undertaken when any section of the
liners is less than 1mm thick or any holes appear.
CLEANING INSTRUCTIONS
WARNING
Before beginning to clean your stove make sure the unit is not in use and is cold.
It is advised that you put some plastic down on the oor in front of the stove whilst cleaning to
prevent any creosote or ash from falling on the oor.
STEP 1. Remove rear cleaning port cover located on the top plate to the le hand side. Push the cleaning tool
down the back of the stove moving it about to loosen any built up creosote or ash. These loose particles
will fall to the bottom into the ash drawer.
STEP 2. Remove hot plate and push cleaning tool down each side of the outside of the re box past the oven, move
cleaning tool about to loosen any built up creosote or ash. These loose particles will fall to the bottom of
the stove.
STEP 3. Open the oven door and remove the ash drawer and dispose of ash carefully. Make sure the ash/creosote is
cold. If the stove was particularly full of creosote once the ash drawer is removed additional creosote may
fall into the compartment. Scrape this out also. Make sure sides and back are clear before putting stove
back into service.
WOOD HEATER MAINTENANCE
CHECK YOUR WOOD HEATER REGULARLY
Initially, we recommend you check your ue system at least once per month. Aer the rst few months you will notice a pattern
of soot and creosote build up and you can then determine an inspection interval for checking soot and creosote build up that is
suitable for your wood heater installation.
Other checks, as listed below, should be carried out at least twice per year. If you notice anything wrong at any time it should
be repaired immediately. Never use a wood heater that is in any way damaged or has a damaged ue.

11
WOOD HEATER MAINTENANCE ....continued
ASH REMOVAL
When the stove is out and completely cold you may remove the ash using an ash vacuum or a steel bucket with a lid and
shovel. Place a cover over the bucket so that when removing the bucket the ash does not blow about your house.
HOT WATER GENERATOR (OPTIONAL)
According to Australian law this appliance must be installed by a registered plumber. Be sure to always have water running
through your system, failure to do so will result in damage to hot water generator. When installing the plumber must use radial
bends and always have the hot water line from the hot water generator to the storage unit inclining. Failure to comply with any
of the above will negate warranty.
WARNING: DO NOT CAP OFF HOT WATER OUTLETS!
CARE OF GLASS
At times, especially when the air controls are turned to low settings or when damp wood is used, the wood heater glass will
blacken. This is caused by fuel that is not completely burnt, but the build-up on the inside of the glass will normally burn o
when a good hot re is established in the wood heater.
There may be times however when you need to clean the glass. To do this, use a so cloth and a non-abrasive glass cleaner.
Only ever clean the glass when the wood heater is cold. For best results select from Kalora’s range of glass cleaning products.
When loading fuel into the wood heater, always make sure it is not protruding out through the door opening, as this may break
the glass when you close the door. This is especially relevant when loading logs. Always close the door gently.
If the glass does crack when the wood heater is lit, let the re die out. Do not open the door until the wood heater has fully
cooled. Replace the glass with the specied replacement part before re-using the wood heater.
DOOR ADJUSTMENTS
Door closing tension adjustment - As door seals age the seal beds into the heater body, this will allow air to be drawn in any gaps
created. Remove the grub screw from the door handle sha on the inside of the door, this will allow the handle to rotate 360O. Rotate
the handle 1 full turn anti-clockwise and shut the door. Repeat this step until the door oers a little resistance to close. Replace the
grub screw. Over tightening may cause the door to distort and break the glass. If the door is at maximum adjustment this generally
means the door seal will need replacing.
SURFACE FINISH
To clean your heater wipe lightly with a damp cloth or dust with a duster. Some cleaning products may leave stains on the
wood heater surface. Never use abrasive cloths as these may scratch the surface; take caution when using microber cloths
as they can leave swirl marks if used in a circular motion. Painted wood heaters can be re-painted by using a good quality,
high temperature wood heater paint. When re-painting, make sure there is plenty of ventilation and follow the manufacturer’s
instructions. Allow the paint to fully dry before lighting the stove and allow extra ventilation for the rst couple of res as some
fumes may emit from the stove as the paint cures.
Forge high temp enamel is available at your local Forge retailer. Visit www.scandiaspares.com.au for details.
REPLACING PARTS
Always use genuine replacement parts. Only ever make replacements when the wood heater is cold.
All replacement parts can be ordered from www.scandiaspares.com.au.

12
TROUBLE SHOOTING
GLASS BLACKENS
Glass usually blackens when:
FIRE BURNING TOO QUICKLY
This is usually caused by too much draught or air.
1. That the air controls are opened.
2. There is no blockage in the ue system.
3. That the open end of the ue is above the height of any nearby obstructions.
4. That there is a suicient air supply into the room and that this supply is not being taken by an extractor fan.
1. Firstly try reducing the air supply to the wood heater by closing down your air controls, if this fails then you may
have to adjust the door or you may have damage to the sealing.
2. Close a thin strip of paper in the door, check to see if the paper stays in place or pulls out. If the paper pulls out
easily you may need to adjust or replace the door seal.
3. Check to see if the glass moves within the door frame. If it does you may need to tighten the glass retainer screws.
4. Check the condition of the door sealing rope and the glass seal tape.
1. The fuel is not being burned eiciently because of starvation of air.
2. Bad quality or damp fuel is being used.
Please note: For optimum eiciency always use a good quality dry hardwood.
See video at: https://www.youtube.com/watch?v=nT-V_zL4jeg
Many people under estimate the importance of using a professional installer with experience in wood heating who adheres to
Australian Standards to install their wood re.
If you are having issues with your wood re not working the way you think it should, we implore you to speak to your installer
rst; they can help you with issues such as burning too much or too little wood, smoke in the room when you open the door,
blackened glass or build-up of creosote during use. A professional installer can also provide guidance on whether the problem
is a manufacturing issue in this instance we will work with them to resolve any issues as soon as possible for you.
It is important to remember that all ue installations must be compliant with Australian Standards. A heater installed with a
non-compliant ue conguration will not perform as advertised or as tested.
FIRE NOT BURNING
A wood heater not burning is generally caused by either a shortage of air and/or incorrect or damp fuel. If fuel is not the problem check:
CHIMNEY FIRE
Chimney res occur when soot and creosote that have built up in the ue system ignite. If the wood heater is operated properly
and the ue checked and cleaned regularly then chimney res should not occur. These res can be very dangerous and must
be avoided. Try to maintain good, hot res in the wood heater whenever possible and at least once in every ring open the air
controls and allow the wood heater to burn on full for a short while until the entire re bed is glowing red.
Check your ue system regularly for build-up of soot and creosote and clean as necessary. Chimney res can be detected by
sparks coming from the top of the chimney, a roaring sound coming from the area of the stove or chimney or vibration in the
stove or chimney. In the event of a chimney re, close the air controls, evacuate the building and call the re department.
Do not relight the stove aer a chimney re until the stove and ue have been checked and any necessary repairs have been
carried out.
SMOKE IN ROOM
If the wood heater is properly installed it should not emit any smoke into your room. Should this happen, check that your room
is not air tight. This can easily be checked by opening a door or window. If the smoking stops you need to provide an additional
air supply into the room. If this is not the problem, check if your chimney is blocked or obstructed and that you are not getting
a down draught caused by the location of the open end of the ue pipe or chimney.
If the problem persists contact your installation company and ask them to get your chimney and stove installation checked.

13
KALORA FUSION HOT WATER GENERATOR
INSTALLATION INSTRUCTIONS
PART NO. SCX520 - KALORA FUSION HOT WATER JACKET
1. Remove re brick retaining bar.
2. Remove rebox side liners.
3. Remove re bricks.
4. Remove rear panel of stove and remove pipe exit hole covers.
5. Remove inner rear panel of stove and remove pipe exit hole covers.
6. Remove insulation.
7. Remove pipe exit hole covers from rear side of rebox.
8. Remove nuts from hot water generator pipes.
9. Install hot water generator in rebox, pipes rst. The pipes should line up with
exit holes in the back of rebox. Push hot water generator pipes all the way
through the exit holes until the rear face of the hot water generator touches the
rear of the rebox.
10. Put one nut on each of the pipes extruding from the rear of the re box. Nuts are
not required to be very tight, just enough pressure is required to hold hot water
generator in place. Do not over tighten as you may damage hot water generator.
11. Replace rebrick retaining bar then side liners.
12. Replace insulation.
13. Replace inner rear panel.
14. Replace outer rear panel.
Now the stove is ready to be connected to the house water system.
Please make sure an experienced plumber connects stove to a low
pressure open vented system only. The hot water line from stove must
always incline and radial bends must be used. Make sure the storage unit
being used is compatible with a combustion stove.
Pipe exit hole covers and re bricks are no longer required.
Firebrick retaining bar
Pipes extruding rear
of rebox
Hot water generator
in position

14
WARRANTY
KALORA LIMITED WARRANTY
This limited warranty is given by Kalora Pty Ltd (ACN 142 881 141) (Kalora or we) to the original retail purchaser (you) of the
wood heater to which this Warranty applies.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
The benets that this Warranty provides are in addition to other rights and remedies available to you under the Australian
Consumer Law. This Warranty does not limit those rights and remedies.
For this Warranty to apply, you must fully complete the Warranty Registration Card and mail
it to our mail address within 30 days aer the original purchase. By completing this form, you
also agree that, to the extent permitted by law, our liability to you on any basis in relation to
the wood heater (other than under the Australian Consumer Law) is limited to our obligations
under this Warranty.
IMPORTANT
SCOPE OF WARRANTY
If a defect in material or workmanship appears in the following parts within the corresponding warranty period aer the date
of the original purchase, such as to make the wood heater unt for normal home use; and you comply with the requirements
below regarding making a claim, then, subject to the exclusions below, we will replace or repair the relevant part or (at our
option) replace the entire wood heater with the same or comparable model.
PART WARRANTY PERIOD
Firebox 10 Years
All other parts (Including dampers, liners and rebrick
retainers) 1 Year
To the extent permitted by law, our liability under this Warranty is limited to this replacement or repair obligation.

15
1. Where the defect is not due to the original design or manufacture of the part (including where the wood heater,
part or accessory has been subject to accident, abuse, alteration, misuse or neglect or has been installed,
inspected, operated or maintained negligently or not in accordance with applicable local laws and regulations and
the manufacturer’s printed instructions, if any)
2. Where the rebricks, top bale or breglass seal have not been replaced aer becoming damaged or worn
3. To any accessories or optional parts
4. To any glass, paint, rebrick, breglass seal sold or used with the wood heater
5. To any surface rust which may occur in transit, storage or use.
This includes installations in close proximity to coastal areas and salt water which may cause rust to the
appliance.
1. The model and serial number of the wood heater
2. The place, price and date of purchase
3. Reasonable details of the defect
To obtain replacement or repair under this Warranty, the wood heater must be returned to the original place of purchase
(and collected from there once the replacement or repair is complete) at your cost. Kalora will not be responsible for any
associated freight, disconnection or re-installation costs (including labour costs). Kalora will only be responsible for transport
of the wood heater from the original place of purchase to Kalora’s premises (and back), and replacement or repair in
accordance with this Warranty.
REGISTER BY MAIL
Please complete the attached warranty card within 30
days of installation and return to:
Kalora Pty Ltd.
58 Access Way, Carrum Downs
Victoria, Australia, 3201.
REGISTER YOUR PRODUCT
WARRANTY ....continued
EXCLUSIONS
This Warranty does not apply:
HOW TO MAKE A CLAIM
Any claim under this Warranty must be in writing to our mail address below. It must be sent within the applicable warranty
period and must state:

16

17

Kalora Pty Ltd
58 Access Way, Carrum Downs
Victoria 3201
Australia
