KANDA STK200 Dragon User manual

Getting Started with STK200 Dragon
Introduction This guide is designed to get you up and running with main software and
hardware. As you work through it, there could be lots of details you do not
understand, but these are covered in books and other documentation that you
can read later.
The main software package is AVRStudio, which is Atmel’s Integrated
Development Environment or IDE. There is also a plugin C Compiler module
called WinAVR that compiles C programs within AVRStudio. The Kanda
installer will install these packages and copy documentation to a folder on
your hard drive.
Default install path is C:\Program Files\STK200 Dragon
AVRStudio has its own Atmel-AVR Tools folder in Program Files, and can be
run from there or you can run from desktop icon.
WinAVR never needs to be run directly, only from AVRStudio.
The AVRStudio IDE is designed for writing source code, in C (.c files) or
assembler (.asm files). These are then built or compiled into object code (.hex
files) for programming into the AVR using ISP or debug files (.elf files) to step
through the code.
The AVR Dragon hardware is a programmer and In Circuit Emulator (ICE) in
one tool. Once source code is built, it can be programmed into the AVR using
ISP, which will just run the code or it can be set in Debug mode (using
DebugWire or JTAG )that allows you to examine the code operation to find
bugs.
There are two Debug methods depending on the AVR device you are using
•JTAG Mode for AVR devices with 40-pins or more
•DebugWire for smaller pin-count devices.
In System Programming is common to all AVR devices, using serial
programming (ISP). Devices with JTAG can be programmed through JTAG as
well as ISP.
This guide describes the hardware setup for ISP, DebugWire and JTAG, with
associated AVRStudio software operations. The default AVR supplied is an
Atmega16. As this is a 40-pin device, it uses JTAG for debugging. Although it
can also be programmed through JTAG, we suggest you use ISP first to
familiarise yourself with standard programming.
There is a brief guide to the books and documentation at the end of this guide
as well as links to Atmel site, where more information is available about AVR,
AVRStudio and AVR Dragon.

Getting Started with STK200 Dragon
Creating an AVR
Dragon Project AVR Studio
AVR Studio is Atmel’s development environment. The Kanda installer will
install AVRStudio, service packs for AVRStudio and WinAVR C Compiler,
unless you choose not to because you have them already.
This is a brief guide to using one of the sample files in AVR Studio, but more
information is available in the AVRStudio Getting Started guide and at
www.atmel.com
AVR Studio is project based, so you need to create a project before you can
do anything. Project extension is .aps. Follow this procedure.
1) Run AVRStudio and select New Project from Welcome screen. If
Welcome screen does not appear, select Project Menu > Project
Wizard
2) Choose Atmel AVR Assembler as Project Type or AVR GCC for C
Projects.
3) Give the Project a name
4) Uncheck Create Initial File box
5) Set location of where to save Project files
6) Click Next Button
On the next screen,
1) Set Debug platform to AVR Dragon
2) Set Device to ATmega162, Atmega16 or your own AVR device
3) Click Finish Button

Now the project is created, we need to add a sample file.
1) The Project is displayed at the left of the screen. Right click on the Project
name and choose Add Files to Project
2) Select an assembler file from Assembler Sample Code folder, such as
LedFlash200.asm. See C Code section for using C language.
3) Now go to Build Menu > Build. This will assemble the file and create object
code file (.hex) for programmer and Elf file for debugger in Project folder (or
sub-folder called Default for C Projects).
Once the source file has been built without errors, you can program it into your
target AVR so it runs or use Debug Mode for debugging it. The next step is to
set up the hardware for programming (ISP) and DebugWire or JTAG for
debugging.

Hardware Connections forISP and DebugWire
Using ISP DebugWire is used for debugging smaller pin count devices from AVRStudio.
ISP or In System Programming is used for programming devices from
AVRStudio, or another programmer.
There is a 6-pin pin-header on AVR Dragon board labeled ISP.
Connect the 6-way adapter to this header as shown, with key way facing
prototype area.
There is a jumper on adapter PCB. This should be ON for ISP and OFF for
DebugWire (DW). It is supplied with jumper on.
Side Note: ISP will not work if jumper is off. DebugWire will work with jumper
on, but some of PortB (LEDS) will not be available as ISP lines will be
connected, on PortB, bits 5-7.
ISP : Jumper ON DebugWire : Jumper OFF
Connecting AVR
Dragon

Connect the 10-way ribbon cable to this adapter and into the 10-way box header
on STK target board.
The complete ISP or DebugWire connection looks like this:
Connect the AVR Dragon to a USB port on your computer. The New Hardware
Wizard will appear, just follow instructions to install driver.

Powering STK200 Board
The AVR Dragon is self-powered from USB bus, and in most circumstance it
can also be used to power the STK200 board using the two wires supplied.
Unless you add extra circuitry, the STK200 board will draw less than the
100mA that the USB can supply.
If you have any doubts about your USB, then do not power the board from
AVR Dragon. The alternative is to connect a power supply to the power
connector on the STK200 board.
•2.1mm barrel connector
•Centre positive or negative
•9-15VDC or 6-12VAC
The AVR Dragon has a 6-way connector marked VCC and GND, next to
JTAG connector. It has 3 VCC and 3 GND pins. Connect the green wire
supplied to one of the GND pins, and the red wire to one of the VCC pins.
All the port headers on the STK200 board also have a GND and VCC pin. It
does not matter which header you use but Port A is most convenient. Connect
the green wire to GND pin on Port A header (inside) and red wire to VCC pin
(outside).
Side Note: There are also VCC and GND pins on 14-way LCD header on
STK200 board, if it is easier to use these instead in your setup. GND wire can
be omitted as JTAG or ISP headers have GND line connected already but
board will only be powered if cable is left connected.
This picture shows the completed connections.
STK200
Board Power
Connection
STK200
Board Power
from AVR
Dragon

Programming
from AVRStudio Make sure hardware is connected as shown above for ISP and DebugWire.
Go to Tools Menu > Program AVR > Auto Connect.
This will bring up programmer dialog box. If you get a Connect Failed, then
this Dialog will appear.
Make sure AVR Dragon is set as platform and your connections are all ok and
try Connect button.
Once it has connected, you may get a Firmware Update message, depending
on your version of AVRStudio. If you do, click Yes and continue to main
programmer screen. This is described in AVRStudio Help files. There are a
series of screens – Main, Program, Fuses and Auto tabs are the most
important.
Main

Make sure that Programming Mode is set to ISP mode. It may come up as
JTAG mode on some AVR devices.
Side Note: If you want to program using JTAG, set Programming Mode to
JTAG and use hardware JTAG connections – see JTAG Connections section
Check device type matches and try Read Signature Byte. If the result is
000000 or a signature mismatch, then ISP clock is probably too fast for a new
AVR as default is 1MHz ISP speed. Click Settings button and write slower
ISP speeds until it reads signature correctly.
Program Tab
An AVR device must be erased before it is programmed again, as a separate
operation, so check Erase Device before Programming and Verify boxes. If
Input Hex File is blank, set it to your output Hex file. Remember that C
projects put output in a sub folder called Default, and Create Hex File must be
checked in Project Options. Then click Program button in Flash section.
Fuses Tab
Fuses control the operation of the device. The most important at this stage
are
•SUT_CLKSEL – Default varies with each AVR, but will always be Internal
Resonator (INT RC), running at 1MHz or less. Change this to one of the
External Crystal choices (External Crystal Osc. Or Resonator), 8MHz or
High Frequency, at the bottom of the list. Exact choice does not matter.
•CLKDIV8 – Some AVRs have this fuse to divide clock frequency by 8, so
disable (uncheck) for real clock speed
•JTAGEN – on 40-pin devices, debug is via JTAG and this fuse should be
enabled for Debugging. It will stop PortC acting as normal I/O, so disable
it to use PortC
•DWEN – On AVRs that have DebugWire, this fuse should be disabled for
ISP. The Debugger will set it when required for debugging
•RSTDISBL – On smaller pin count AVRs, this fuse disables Reset for use
as general I/O. DO NOT set this fuse or you will not be able to use ISP
•SPIEN – Do not disable this fuse or ISP will not work
Set up these fuses and use Program and Verify buttons to set and check the
fuses.
Auto
Allows you to do multiple operations by clicking Start button. Easiest way of
reprogramming devices once fuses and other settings have been setup.
Once you are happy that you understand how to program a device, exit the
Programmer screen. Now we will look at debugging. Depending on the AVR
device in your kit, this will either be via DebugWire or JTAG. Read the
appropriate section now, DebugWire for 8, 20 and 28-pin devices or JTAG for
40-pin devices.

DebugWire with
AVR Dragon DebugWire is the onboard debugger for smaller pin count AVR devices, with
less than 40-pins. Hardware connections are same as already set for ISP,
except jumper on adapter PCB should be OFF, see ISP section.
After building your project successfully, Choose Debug > Start Debugging
or use Build and Run, which will launch AVR Dragon after compile. Unless
you have set DWEN fuse before leaving ISP, you will get a Connection
Failed dialog that prompts for setting DWEN.
This will enable DWEN and connect to your AVR. You will need to cycle the
power on STK200 board before DWEN change takes effect.. A yellow arrow
in source code window shows location in the code. You can then run or step
though the code using Debug menu.
Important
Once you have finished debugging your code, you will need to clear DWEN
again or you will not be able to use ISP with the device. Before exiting
debug mode (Stop Debugging), you will need to disable DWEN. Choose
Debug > AVR Dragon Options and click Disable DebugWire button. This
will clear DWEN and exit debug mode.
Newer AVR devices with 40-pins or more have JTAG port for On-chip
Debug. Exceptions are the older Atmega8515 and Atmega8535 devices.
The board does not have a JTAG connection because there are too many
sockets on it, so connections are made to the port pins of the AVR using the
adapters supplied.
The JTAG pins on different AVR devices are in different places, so which
adapter to use depends on which AVR you are using.
AVR Type JTAG Pins Adapter
ATmega32
ATmega323
ATmega16
Atmega164
Atmega324
Atmega644
Atmega1284
TDI - PC5
TDO - PC4
TMS - PC3
TCK - PC2
Adapter B to Port C
header
Atmega162 TDI - PC7
TDO - PC6
TMS - PC5
TCK - PC4
Adapter A to Port C
header
JTAG with AVR
Dragon

Fit the correct adapter to the correct port header, with the back of the adapter
PCB facing out from the board
Fit the 10-way cable to the adapter and connect it to header marked JTAG on
AVR Dragon, with keyway facing prototype area.

AVRStudio
connection
problems
Apart from the hardware interface, the debug process is the same as DebugWire.
Use Build and Run or Debug > Start Debugging to connect to device and then
use Run or Step, or set breakpoints. A yellow arrow shows position in your code.
AVRStudio can be a bit unstable, and if you get connection problems or peculiar
behaviour, try unplugging USB cable, cycling power on STK200 board and
sometimes closing and re-opening AVRStudio software.
Occasionally, you may need to restart PC to reset everything, but usually just
closing AVRStudio works.
The Kanda installer will copy a range of documents to a folder called STK200
Dragon in your Program Files folder.
Folder Description
•AVR Studio folder contains 2 folders, App Builder and Documentation. App
Builder is a Wizard to help create assembler or C file templates.
Documentation has PDF files on getting started with AVR Studio and AVR
instruction set
•C Sample Code folder has example C Projects covering basic topics such as
LED flashing, UART, LCD and Keypad
•Documentation folder has description of STK200 board, LCD details, AVR
datasheets folder and STK200 board schematics
•Embedded C book has a PDF book about writing C code
•Get Going with AVR book is a good place to start if you do not know anything
about AVR microcontrollers
•Assembler Sample Code folder contains Assembler example files on a range
of topics.
AVRStudio Help Menu has AVR Tools User Guide. Select AVR Dragon User
Guide from list for more information on AVR Dragon, and on its prototype area.
Other Documents

C Code
Projects Creating a C Project in AVR Studio is the same as assembler, except you
choose C as Project Type. Create a project without creating an initial file and
then add a C file as source file, just like assembler.
Alternatively, you can open a C project file (*.aps) from C Sample code folder.
Important
The C compiler is a plug-in for AVR Studio and is not directly controlled by it, so
there are some important points to be aware of
1. C projects must have AVR device set correctly, unlike assembler files which
are not so fussy, otherwise code will not run.
2. Changing device in AVR Studio project does NOT change device in C
compiler. You need to go to Project > Configuration Options and change
device there as well. Also on this screen, make sure Create Hex File is
checked.
3. Output files are stored in a sub-folder called Default
There is a document called Pointers.PDF in C Sample Code folder that covers
arrays and pointers if you are not familiar with C programming.
Embedded C Book
There is a PDF book on Embedded C Programming in Embedded C Book folder.
It covers the basics of writing C for AVR microcontrollers but uses IAR C
compiler instead of WinAVR and AVR Studio.
A free 4KB limited version of the IAR compiler, called Kick Start, is available for
download. It is similar to WinAVR but produces smaller code and has lots of
advanced features. AVR Dragon can be run from IAR Embedded Workbench,
using their C Spy debug interface.
To setup AVR Dragon in IAR Embedded Workbench go to Project > Options
and choose Debugging and set it to DRAGONAVR.
Atmel who manufacture the AVR and produce AVRStudio are a very good
source of information. Visit www.atmel.com for new versions of AVRStudio,
application notes, new AVR devices and much more.
Contact Kanda at [e-mail] or visit our website at www.kanda.com
Phone/fax is [phone]
Atmel Website
Contact Kanda
