KanDao Obsidian GO User manual

Go
3D VR Digital Camera
KanDao Obsidian
3D VR 全景相机（GO)
Product description
使用说明书

KanDao Obsidian Go
3D VR Digital Camera

目录
一、部件介绍
1.1 3D VR 全景相机
1.2 相机规格参数
1.3 标准配件
二 、入 门指南
2.1 插入相机电池
2.2 插入存储卡
2.3 开启或关闭相机
2.4 使用相机拍照或录影
中文产品说明
使用设备前，请仔细阅读本说明书

1.1 3D VR 全景相机
一、部件介绍
closed
open
2 3 5
8 9
61 74

1. 电源指示灯
2. 电源键
3. 拍照键
4. 录像键
5. 工作状态指示灯
6. TF卡插座
7. 麦克风
8. 镜头
9. 电池室盖
10. Zoom收音接口
11. Micro USB接口
12. 三脚架快装板接口
13. 12V外接电源接口
11
10
12 13

进口商
公司名称: Vrperception
地址: VR Perception Rebenstrasse 33
8307 Effretikon Switzerland
1.2 相机规格参数
商品名称 参数或描述
视频格式 MOV
重量
（相机+电池) 1015 g
存储介质 TF卡, 最大支持128G
视频编码格式 H.264
输入电压 电池 7.4V, 外接电压12V
功率 10.5 W
视频分辨率 单镜头 1728 * 1728
图片分辨率 单镜头 4608 * 3456
帧率 30 fps
工作温度 -10 ~ 40 °C
工作湿度 10~90% RH
储存温度 -40 ~ 80 °C
储存湿度 5~90% RH
频率范围 2404MHz-2476MHz
最大辐射功率
软件版本
遥控器2.5dBm
摄像头：2.5dBm
MP_VER.01.00.13_20170830
硬件版本 主板:KSA_6_S206_V1.2
电源板:KSA_6_S206_POWER_V1.3

1.3 标准配件
名称 数量
手提箱
遥控器
珍珠棉
电源适配器赠品盒（赠品）
电源适配器 12V 2A（赠品）
音频线 0.7米
遥控器电池
说明书
1个
1个
2节
2个
1条
1个
1个
1个

相机
适配器
手提箱
遥控器
遥控器电池链
音频线

温馨提示：
TF卡请务必选择正规品牌商8G-128G，卡速class10及以
上进行使用。
二、入门指南
2.1 插入相机电池
2.2 插入存储卡
充电：相机电池电量耗尽后需将电池取出，用购买相
机时所标配的电池充电器进行充电。
低电：
相机使用过程中电池电量低
于10%时[电源指示灯]呈慢
闪提示，当电量低于5%的时
候，[电源指示灯]呈快闪提
示。
向左拧[电池盖]即
可打开盖子插入电
池，向右拧紧关闭
盖子。
拍摄前请分别插入六张[TF存储卡]，插入时请确保存
储卡方向正确，存储卡用于存储照片或视频。
电池
电池低电时电源
指示灯闪烁提示
TF存储卡

温馨提示:
相机无卡/卡满/录像同步时/不正常工作时蓝色的[工作指
示灯]闪烁方式为快闪的方式。
2.4 使用相机拍照或录影
拍照：
短按[拍照键]即可拍照，拍照
模式Timelapse10秒，拍照时
[工作指示灯]会灭一下。
再次短按[拍照键 ]停止拍照。
录影：
短按[录影键]即进行录影，再
次短按[录影键]停止录影，开
始录像时[工作指示灯]呈快
闪提示约4秒同步信息后进行
录影，录影过程中[工作指示
灯]呈慢闪提示。
2.3 开启或关闭相机
开机：短按[电源键] 相机正常开启后，[电源指示灯]常
亮红色，其它[工作指示灯]常亮蓝色。
关机：长按[电源键 ]，相机关机后所有
[指示灯]快闪后全灭。
短按电源键开机
短按拍照键拍照
短按录影键录影

Table of Contents
Product Description
1, Nomenclature
1.1 3D VR panorama camera
1.2 Camera specification parameters
1.3 Standard accessories
2.1 Battery charging
2.2 Insert the memory card
2.3 Switch on/off
2.4 Photograph& Video-record
2, Using the camera
Please read the product descripiton
carefully before using the device.

1.1 3D VR panorama camera
1, Nomenclature
closed
open
2 3 5
8 9
61 74

11
10
12 13
1. Power indicator lamp
2. Power button
3. Timelapse button
4. Camcorder button
5. Working mode lamp
6. TF card slot
7. Mic
8. Lens
9. Battery cover
10. Zoom audio port
11. Micro USB port
12. Tripodquick shoe
13. 12V external powersupply port 

Importers
1.2 Camera specification parameters
Video format MOV
Name Description
Weight（camera+battery）1015 g
Memory medium TF card
Video coding format H.264
Power 10.5 W
Working voltage battery 7.4V, adapter 12V
Video resolution single lens 1728 * 1728
Photograph resolution single lens 4608 * 3456
Frame rate 30 fps
Working temperature -10 ~ 40 °C
Working humidity 10~90% RH
Storage temperature -40 ~ 80 °C
Storage humidity 5~90% RH
Frequency range 2404MHz-2476MHz
2.5dBm for remote control
2.5dBm for Camera
MP_VER.01.00.13_20170830
Mainboard：KSA_6_S206_V1.2
Power strip：KSA_6_S206_POWER_V1.3
E.I.R.P:
Software version
Hardware version
Company Name: Vrperception
Address: VR Perception Rebenstrasse 33
8307 Effretikon Switzerland

Working voltage battery 7.4V, adapter 12V
1.3 Standard accessories
Instructions
Adapter 12V 2A (gift)
Pearl cotton
Adapter gift box(gift)
Carrying case
Name Quantity
Remote control
Remote control battery
Donble-ended audio cable 0.7m
1
1
2
2
1
1
1
1

Camera
Adapter
Carrying case
Remote control
Remote control
batteries
Audio cable

Reminder:
Please choose 8G-128G TF card of formal manufacture
with an access speed class of above class10.
2, Using the camera
2.1 Charging
2.2 Insert the memory card
Low power：The [power
indicator lamp] will flash
slowly when power is below
10% and will flash quickly
when power is below 5%.
Please insert all six TF cards before shooting, make sure
you insert from the right direction. The TF cards are
used for data storage.
batteries
Power indicator lamp
will flash when power is low
TF card
Rotate the battery
cover clockwiseto
unload the batteries.
Rotate anti-clockwise
to seal the cover.
Power charge: When battery power is exhausted, charge
the battery with the accessorized battery charger.

Notice: If camerahasno TF-card /memory full /
abnormalworking status,the [working mode lamps]
will flashquickly. During recording,the flash isslower.
2.4 Photograph& Video-record
Photograph: Shortlypress the
[Time-lapse button]to
capturea photo. And the
capture mode is 10-second
time-lapse, shortlypress [the
time-lapse]againto end the
capture. During the capture,
the blue [working mode
lamps]will twinkle once.
Video-record: Shortlypress the
[camcorder button] to record
video.Shortly pressthe button
again to stoprecording.All
[working mode lamps] will be in
quick flashesfor about 4
seconds,before the recording
starts. During the recording
process, [working mode lamps]
will flash slowly.
2.3 Switch on/off
Power on: Shortly press the [power button], if the camera
is turned on normally, the power lamp will keep red, and
the six [working mode lamps] will keep blue.
Power off: Long press [power button]all indictor lamps
will be off when the camera is powered off.
Shortlypress the [time-lapse
button] to capture photo
Shortlypress the [camcorder
button] for record video
Shortlypress [power button]
to switch on camera

FCC Special Statement
FCC Regulatory Information

Warning: changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s authority to
operate the equipment.

Note: This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may
cause harmful interference to radio communica-
tions. However, there is no guarantee that
interference will not occur in a particular
installation.
If this equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the
equipment and receiver.
-- Connect the equipment into an outlet on a
circuit different from that
to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV
technician for help.


RF Exposure

This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. This equipment should be installed
and operated with minimum distance 20cm
between the radiator and your body.
This transmitter must not be co-located or
operating in conjunction with any other antenna
or transmitter.

FCC法规信息
警告：未遵守责任方明确批准的变更或修改可取
消用户操作设备的权限。
注：本设备经检验符合《FCC规则》第15部分的规
定，符合B级数字设备的限制。这些限制旨在为住
宅安装中的有害干扰提供合理的保护。
该设备产生、使用会产生无线电射频，如果没有按
照说明书安装和使用，可能会对无线电通信造成
有害干扰。相反，也无法保证在特定的安装中一定
不会产生干扰。
如果通过打开和关闭设备确认该设备确实对无线
电或电视接收造成有害干扰，则鼓励用户通过以
下一种或多种措施纠正干扰：
-调整接收天线的方向或位置。
-增加设备和接收器之间的分离。
-将设备连接到与接收器不同的电路插座上。
-咨询经销商或有经验的电台/电视技术人员寻求
帮助。
辐射曝光
该设备符合FCC针对无控制环境的辐射曝光限值。
该设备应在散热器和人体之间距离大于20cm的
条件下安装及操作。
此发射机不可与其他天线或发射机结合操作。
FCC特别声明
