KBi KrankingKART Mini HD User manual

KrankingKART®Mini HD
Portable 12V Jump Start Device
Powered By
KrankingKAP™Supercapacitors
REV. A
Protected by one or more of the following U.S. Patents
US 6,819,010 B2 | US 6,871,625,B1 | US 6,988,475 B2
®

The patented KBI KrankingKART Mini HD jump start device is capable of de-
livering large amounts of power to start cars, light trucks, ATV’s, boats, lawn
equipment, and most other 12 Volt powered equipment.
KrankingKART Mini HD Introduction.
Identications:
Digital Voltage Guage
Activation and Voltage
Check Switch
Boost Button
For Emergency Recharge
Reverse Polarity
Indicator
Built In Safety
Device Will Not Activate If
Connect In Reverse Polarity
Or Connected To Incorrect
Voltage Source
All Features
Are Waterproof
Heavy Duty Solid Copper
900 Amp Booster Clamps
Rocker switch position functions:
• Center or Nuetral Postition = Off
• Up = On or Starting Mode
• Press and hold down = Momentary Voltage
Check

KrankingKART Mini HD Unique Features.
• Maintenance Free
• Built heavy duty for harsh environments
• Unique patented design
• Unparalleled Power and Reliability
• Cycle life upwards of 1,000,000 cycles
• Recharge to 100% in as little as 30 seconds
• Performance unaffected by cold temperatures
• Extremely long life regardless of storage voltages
• Weighs up to 60% less than lead acid battery alternatives
• Water proof, built using IP67 components
• Can sit unused for months and still start engines
• Recharges off any running vehicle, never needs to be plugged in
• Made in the U.S.A.
ALWAYS WEAR EYE PROTECTION (WEAR SAFETY GLASSES)
WHEN USING AND WHEN WORKING AROUND BATTERIES.
NONCOMPLIANCE WITH THE REQUIREMENTS SET FORTH IN
THIS MANUAL MAY RESULT IN DEVICE FAILURE OR FAILURE OF
THE SUPERCAPACITOR WITHIN THE DEVICE.

THIS DEVICE IS POWERED BY A SUPERCAPACITOR. THIS CAPACITOR
OR CAPACITORS ARE VERY POWERFUL AND SHOULD BE TREATED
WITH RESPECT. FOR THIS REASON WE ISSUE THE FOLLOWING
“WARNINGS” AND “CAUTIONS”.
• Do not short circuit the cable clamps. Short circuiting of the clamps
may result in burning or igniting of combustible materials adjacent to the
point of short circuit. In case of an accidental short circuit it is necessary
to disconnect the clamps immediately from the electrical circuit taking
relevant safety measures.
• Do not touch the clamps to any conductive material.
• Do not use the device if any cable clamp or cord is damaged.
• Do not use the jump start device on a damaged or broken battery.
• Do not attempt to repair the unit or replace parts. Unauthorized repairs
will void your warranty.
• If your KrankingKART Mini HD requires service, follow the directions in
the warranty section or contact Kold-Ban International, Ltd..
• Check vehicle battery terminals on the battery being jump started before
using the power pack. If needed clean the battery terminals.
• After approximately 10 seconds of continuous cranking, if the disabled
vehicle fails to start, stop and wait for 1 minute. This prevents damage to
your vehicle’s system.
• Avoid storing in direct sunlight, in extreme heat, or very moist areas.
• Never attempt to jump start a battery with frozen electrolyte. A frozen
battery could explode from applying a charge.
• If the battery being jump started is less than 2V check battery prior to
proceeding since the battery may no longer be in working condition.
• When LED is GREEN, unit is active. When LED is Orange, unit is on.
• Do not disassemble unit. Do not open unit up.
• Never operate MINI HD if unit is damaged.
WARNINGS AND CAUTIONS
Use your jump start device safely.

• 12 Volt use ONLY.
• Use in well vented area.
• Read owner’s manual before using.
• Contact with battery acid may cause severe burns and blindness.
• Failure to follow these instructions may result in personal injury, de-
struction of the jump starter, or damage to your vehicle.
• ALWAYS WEAR EYE PROTECTION (WEAR SAFETY GLASSES)
WHEN USING AND WHEN WORKING AROUND BATTERIES.
• WARNING – Risk of Explosion or Fire (ALL BATTERIES can release
hydrogen gas that is explosive and/or ammable).
Before using the jump start device it should be charged. Unlike ordinary
battery powered jump start devices, the Mini can be charged with as little as
10V and still provide enough power to start an engine. Differences in engine
size, engine oils, parasitic loads, and temperature may affect the amount of
charge needed. As a result, until you become familiar with the Mini’s charge
characteristics for your application, it is recommend to charge the device
prior to use. In most cases the charge process will take place between 90
and 180 seconds. If more than 5 minutes pass with the unit active, the unit
will automatically shut off and enter sleep mode. If the unit is left in “ON” po-
sition longer than 10 minutes, the device will enter sleep mode. To wake from
sleep mode press the boost button, or the activation switch down.
KrankingKART Mini HD jump start procedures.
To charge the KrankingKART Mini HD using a running
vehicle:
1. BE SURE the jump starter switch is in the “OFF” position.
2. Open the hood of a running vehicle and locate the battery.
3. Connect the RED POSITIVE (+) clamp to the POSITIVE terminal rst,
then connect the BLACK NEGATIVE (-) clamp to NEGATIVE terminal.
4. If you accidentally connected the clamps backwards a warning LED will
light RED. If the warning LED is lit RED, DISCONNECT THE CLAMPS
IMMEDIATELY. DO NOT TURN THE JUMP STARTER “ON”. The unit
has safety features to prevent activation in this scenario, but care should
be taken to avoid this scenario.
5. Turn the device “ON” using the switch on the jump starter. LED should
illuminate green. If the LED is ORANGE, press and hold boost button to
recharge.

6. Wait 90 to 180 seconds. After 90 to 180 seconds the jump starter should
be charged.
7. The digital voltage display will indicate charge level.
8. Turn the jump starter “OFF”.
9. After turning the jump starter “OFF” disconnect the jump starter clamps.
The BLACK NEGATIVE (-) rst then the RED POSITIVE (+). Be sure
the jump starter is in the “OFF” position before disconnecting the clamps.
Failure to do so could cause damage.
10. The KrankingKART Mini HD is now ready for use.
Notes about charging.
1. If more than 5 minutes pass with the unit active, the unit will automatical-
ly shut off and enter sleep mode. If the unit is left in “ON” position longer
than 10 minutes, the device will enter sleep mode.
2. Different Vehicles may provide different levels of maximum charge. This
is because the unit can only charge up to the system voltage of the ve-
hicle used to recharge it.
3. The device may be charged to a maximum of 16V. Do NOT charge the
device to a voltage greater than 16V. Irreversible damage and safety
issues may occur.
4. Charging methods may vary. As a result, use common sense, use safety
measures, and adhere to warnings & cautions at all times.
ALWAYS WEAR EYE PROTECTION (WEAR SAFETY GLASSES)
WHEN USING AND WHEN WORKING AROUND BATTERIES.
USE COMMON SENSE, USE SAFETY MEASURES, AND ADHERE
TO WARINGS & CAUTIONS AT ALL TIMES.
To charge the KrankingKART Mini using a running
vehicle (continued):

To jump start a vehicle or engine:
1. Turn the ignition key to the “OFF” position and remove the key before
connecting clamps to the vehicle battery.
2. Be sure the jump starter switch is in the “OFF” position before the clamps
are connected to the battery.
3. Connect the RED POSITIVE (+) clamp to the POSITIVE terminal rst,
then connect the BLACK NEGATIVE (-) clamp to NEGATIVE terminal.
4. If you accidentally connected the clamps backwards a warning LED will
light RED and the unit will disable itself. If the warning LED is lit RED,
DISCONNECT THE CLAMPS IMMEDIATELY. DO NOT TURN THE
JUMP STARTER “ON”, this could cause serious damage, or injury.
Reverse the clamp connections and the warning LED light should turn off
and stop.
5. Turn the device “ON” using the switch on the jump starter. LED should
illuminate green. If LED is Orange the “boost” button must be held in
during start attempt. The less time between switching the device on and
engine starting the better.
6. Start the engine. After starting the engine leave the jump starter at-
tached for approximately 3 minutes, or until unit has reached system
voltage. This will insure the jump starter is fully charged for its next use.
7. After 3 minutes turn the jump starter “OFF”. This is done by turning the
switch back to the “OFF” position.
8. After turning the jump starter “OFF” disconnect the jump starter clamps.
The BLACK NEGATIVE (-) rst then the RED POSITIVE (+). Be sure
the jump starter is in the “OFF” position before disconnecting the clamps.
Failure to do so could cause damage.
9. The KrankingKART Mini is now ready to be used again, or to be placed
in storage.
If LED is RED after connecting cables:
1. Unit may be hooked up backwards (reverse polarity scenario). Check to
make sure unit is correctly attached to battery terminals. Follow instruc-
tion number 3 from list above.
2. System voltage could be above 16 volts. In this scenario LED will remain
RED, and the unit will not activate. Designed to work with 12 volt vehicles
only.

Frequently asked questions.
What kind of battery is in this device?
The device does not contain a battery. It contains a Supercapacitor.
How is an Supercapacitor different than a battery?
An Supercapacitor contains NO LEAD. Unlike a battery, a Superca-
pacitor stores and releases energy using a physical process not a
chemical process like a battery. As a result, it does not suffer any of
the drawbacks associated with lead acid batteries.
What are some of the advantages a Supercapacitor has over a battery?
• Maintenance Free
• Unparalleled Power and Reliability
• Cycle life upwards of 1,000,000 cycles
• Recharge to 100% in as little as 30 seconds
• Extremely long life regardless of storage voltages
• Weighs up to 60% less than lead acid battery alternatives
What are some of the disadvantages a Supercapacitor has over a bat-
tery?
Supercapacitors are capable of large amounts of power but not energy.
As a result, Supercapacitors are not a good replacement for batteries
running energy demanding loads.
What is the difference between power and energy?
Power is how much can I give something. I.e.: Starting an engine
requires a lot of power but only for a short duration. Energy is how
long can I run something. I.e.: Running a radio, fan, or refrigerator
overnight. This requires a small amount of power but a large amount
of energy.
How long will the device hold a charge?
On average the device should hold a charge between 3 and 4 weeks.
What happens if the voltage in the device is very low or reaches zero
volts?
Nothing, just simply recharge the device. Storing the device at low
voltages does not effect its performance or life. Unlike battery pow-
ered devices, you do not have to keep the device constantly charged
above a set voltage.
Why does the device shut off on its own?
If more than 5 minutes pass with the unit connected to a vehicle, the
unit will automatically shut off and enter sleep mode. If the unit is left in
“ON” position longer than 10 minutes, the device will enter sleep mode.
To wake from sleep mode press the activation switch down.
What should I do to maintain the device?
Nothing except keep the cables and device in clean working order.
Avoid storing in direct sunlight, in extreme heat, or very moist areas.

How can the device crank and engine with as little as 10V?
The internal resistance inside a Supercapacitor is so much less than
a lead acid battery that it can release its power more efciently than a
lead acid battery. Therefore, an engine starter, in most cases can ef-
fectively use the power with as little as 10V.
I keep recharging the device but the voltage seems to drop off quickly?
This is normal. There is a balancing circuit in the device that causes
the voltage to drop as the Supercapacitor cells charge and balance
between themselves. The voltage drop will be high at rst and then
slow down once the cells get synchronized.
I am trying to use the device but nothing seems to be working. What
am I doing wrong?
In most cases there is insufcient charge in the device. Charge the
device and try again. If still nothing, than call our help line.
I am positive something is wrong, can I open unit up to x it myself?
In most cases there is insufcient charge in the device. Charge the
device and try again. If still nothing, than call our help line.
Where can I obtain help or service?
Call Kold-Ban International, Ltd. For help or service.
1-800-527-8278 or 1-847-658-8561.
Notes:

This capacitor is a manufactured electronic product that contains primarily
non-hazardous materials, including metal and plastic. Supercapacitors are
sealed, metal containers (steel or aluminum) which enclose layers of acti-
vated carbon which is saturated by an electrolyte solution, aluminum and
plastic. The electrolyte solution contains a quaternary salt compound (tetra-
ethyl aluminum tetrauoroborate) dissolved in the solvent acetonitrile. The
assembled layers are inserted into the outer metal container and are satu-
rated with the electrolyte, sealed and stored in an uncharged state. There are
minor hazards that can arise from exposure to the activated carbon. If the
contents of these Supercapacitors remain sealed in the outer shell and they
are kept uncharged, persons handling this product will avoid most of the risks
described herein* for all hazardous components of the electrolyte. As such,
precautions should be taken to avoid rupture or overheating the sealed metal
containers.
* herein describes and refers to the Material Data Safety Sheet (MSDS).
** The MSDS can be downloaded from the information center area of KBI’s website.
www.koldban.com If you are not able to download the MSDS sheet, a MSDS sheet can be
faxed, mailed, or emailed by calling Kold-Ban International, Ltd. directly at 1-800-527-8278 or
1-847-658-8561.
Dispose of properly by recycling.
Supercapacitor contents.
Call KBI
1-800-527-8278 or 1-847-658-8861

THIS PAGE INTENTIONALLY LEFT BLANK

Limited warranty:
The Supercapacitor contained in the device is warranty for a period of three
(3) years. All other components fall under the warranty described below.
KBI products are warranted to the original purchaser against failure due to
defective material and/or workmanship for a period of one (1) year from the
date of purchase except when a variance is expressly stated in the Owners
Manual.
This warranty does not cover any product worn out or altered, used for a
purpose other than for which it is intended, or used in a manner inconsistent
with any instructions regarding its use. The exclusive remedy for any product
found to be defective under this warranty is limited to the repair or replace-
ment of the defective product without charge, and KBI shall not be liable for
any consequential or incidental damages, including labor charges.
In order to qualify for this warranty, the alleged defective product must be
returned directly to the KBI factory (or authorized Service Center), postage
or freight prepaid. Before the product is returned, a Return Material Autho-
rization (RMA) number must be issued. Call KBI for a RMA number. Final
determination of defects will be made by KBI in accordance with procedures
established by KBI. No agent, employee, or representative of KBI has any
authority to bind to any afrmation representation, or warranty concerning
KBI Products, except as stated herein. See comprehensive policy for com-
plete details.
Kold-Ban International, Ltd.
8390 Pingree Rd.
Lake In The Hills, IL 60156
P: 800-527-8278 or 847-658-8561
F: 847-658-9280 www.koldban.com
®
KbI form 131406 © 2016 Kold-Ban International, Ltd.
Protected By One Or More Of The Following Patents:
US 6,819,010,B2 US 6,871,625,B1 US 6,988,475 B2
