KeeNetic GIANT KN-2610 User manual

Quick Start Guide
For technical support or other information, please visit
help.keenetic.com
AC1300 Dual Band Mesh Wi-Fi Gigabit Router with
Dual Core CPU, a 9-Port Gigabit Smart Pro Switch,
SFP Combo Port, USB 2.0 and 3.0 Ports
Model: KN-2610
SFP
0156 78
234
Installing Your
Keenetic Giant
10:00
Welcome to
Your Keenetic
Next
3
Сonnect a mobile device to your Keenetic device via Wi-Fi.
The default Wi-Fi name (SSID) and Wi-Fi password are
printed on your Keenetic device’s back label along with a QR
code that will automatically connect your mobile device
to the Keenetic device’s Wi-Fi when scanned. Alternatively,
сonnect a computer to any gray Ethernet port on your
Keenetic device using the included Ethernet cable.
4Once connected, an Initial Setup Wizard window will appear on
your mobile device / computer. If the Wizard does not appear,
using a browser go to my.keenetic.net.
Note: If the Initial Setup Wizard doesn’t appear, please refer
to the Frequently Asked Questions section below.
5In the Initial Setup Wizard window that appeared, select the
configuration option.
To create a new network and connect it to the Internet, choose
the appropriate connection type and follow the setup instructions.
To extend an existing network and add this Keenetic device
as a Wi-Fi extender, choose the ‘To switch to Wi-Fi Extender Mode’
option and follow the setup instructions.
2
Connect your Keenetic device to a power source.
Check that both the Status LED Cand Wi-Fi LED D
are illuminated and not blinking.
1Position your Keenetic Giant (hereinafter ‘Keenetic device’,
'Keenetic router') within cable lengths of Ethernet and power
outlets. Install the supplied removable Wi-Fi antennas and
position them vertically. Place your Keenetic router in an
open area for better wireless coverage.

SFP
0156 78
234
FN2FN1
FN221FN1
What should I do if I can’t access
the Initial Setup Wizard page or the
Keenetic Web Interface page?
1. Make sure that your mobile device / computer
is connected to your Keenetic device (in Router
Mode) via Wi-Fi or Ethernet cable and set
up to obtain an IP address and DNS servers
automatically.
2. Check that you have correctly entered the
appropriate Keenetic device web address:
either my.keenetic.net (recommended) or
192.168.1.1 or 192.168.2.1.
3. Reboot your mobile device / computer and
your Keenetic device.
4. If the Initial Setup Wizard page is still not
appearing, please follow the instructions below
to reset your Keenetic device.
What should I do if I can’t access the
Internet with my Keenetic device?
1. If the Internet LED Aon the Keenetic device
(in Router Mode) is not illuminated, consult
your ISP to make sure that that service is
available, and that you are using the correct
connection parameters, e.g. account login
and password, authentication protocol, MAC
address, etc. Make the necessary changes.
2. If the Internet LED Aon the Keenetic device
(in Router Mode) is illuminated, please check
the wired or Wi-Fi connections between your
Keenetic Main Router and home devices,
including any Keenetic extenders.
What should I do if I forget my
wireless password?
The default password for connecting to the
Wi-Fi network can be found on a sticker on the
back of your Keenetic device. If the default Wi-Fi
password has been changed and subsequently
lost, the changed password can be retrieved or
reset by logging in to my.keenetic.net or in the
Keenetic Mobile Application.
What should I do if I forget my Web
Interface page password?
To create a new password, please follow the
instructions to restore the factory settings on
your Keenetic device in the question below.
How do I reset/restore the original
factory settings on my Keenetic
device?
Make sure that your Keenetic device is connected
to a power supply. Press and hold the Reset
Button Buntil the Status LED Cbegins to blink
rapidly, release the Reset Button and wait while
your device restarts.
Important: After restoring factory settings, you
will need to reconfigure your Internet connection
and re-add extenders to your Mesh Wi-Fi System.
LED Lights, Antennas, Buttons and Ports Frequently Asked Questions
1. Wi-Fi Antennas
Four removable precision printed dipole Wi-Fi
antennas with 5 dBi gain. We recommend keeping
the antennas in a vertical position.
2. Reset Button B
Restores the original factory settings and resets
the administrator password. For instructions on how
to reset your Keenetic device, see the Frequently
Asked Questions section.
3. Combo Port 0
The port for Internet connection, combining a
RJ-45 connector for Ethernet cable and an SFP slot
for a fiber optic connection via SFP module (sold
separately). It is possible to use only one connection
type at the same time. If an SFP module is plugged in,
the RJ-45 connector will be disabled. The connection
that is currently active can be identified by the LED
light.
4. Network Ports 1–8
By default, these ports are intended for home
devices, but they can be reconfigured and used to
connect to the Internet.
5. DC Power Socket F
For use with the power adapter supplied in the
package. The Keenetic device is designed for
continuous operation and does not need to be
powered off daily.
6. Status LED C
Solid green — Ready for operation.
Blinking green — Rebooting or
updating the operating system.
Rapidly blinking for 2 seconds followed by
continuous illumination — An FN Button
or Wi-Fi Button has been pressed, and the
function assigned to that button has started.
Rapidly blinking for 2 seconds followed by
no illumination — An FN Button or Wi-Fi
Button has been pressed, and the function
assigned to that button was stopped.
Off — Off.
7. Internet LED A
Solid green — Internet connection is established.
Off — No Internet connection.
8. FN1 & FN2 LEDs
By default, they indicate the status of the USB ports.
The purpose of these LEDs can be changed in the
settings.
On — The USB device connected to
the corresponding port is ready.
Off — A compatible USB device was
not found or is not ready.
9. Wi-Fi LED D
Solid green — Wi-Fi network enabled.
Blinking green — Transferring data.
Blinking slowly — Quick connection
session (WPS) in progress.
Off — Wi-Fi network disabled.
10. Wi-Fi Control Button D
By default, this button allows you to easily add
extenders to the Keenetic Mesh Wi-Fi System, or
other WPS-compliant devices to the wireless network.
Pressing it once — Starts a quick connection
session for adding a new device.
Pressing and holding for 3 seconds —
Turns the Wi-Fi on or off.
You can assign other functions to this button if
necessary.
11. FN1 & FN2 Buttons
By default, the buttons are used to safely remove
drives connected to the USB ports of your Keenetic
device. You can assign other functions to these
buttons if necessary.
12. USB 3.0 & USB 2.0 Port
For connecting compatible USB devices, such as
external hard drives, printers, and 3G/4G modems
with a USB 3.0 or USB 2.0 interface. The ports are
located on the side panel; the high-speed USB 3.0
port is the blue one.
The current list of compatible USB devices can be
found on the website help.keenetic.com.
2 3 31 4
6 7 8 9
12 1211 11
10
5
What’s in the Box
■1 Router preloaded with KeeneticOS
■4 Removable Wi-Fi antennas
■1 Level VI energy-efficient 100–240 V power adapter
■1 Ethernet cable
■1 Quick Start Guide (multilingual)
■1 Quick Start Guide (English)
Safety Instructions
■Your Keenetic device is ONLY for indoor use, NEVER use
it outside.
■Keep your Keenetic device away from water, humidity,
excessive heat, and direct sunlight.
■Your Keenetic device and its power adapter contain
no user-serviceable parts. DO NOT OPEN.
■Remove all protective stickers, do not block ventilation
holes, or operate in enclosed spaces.
■ONLY use a Keenetic supplied power adapter,
cease to use any damaged adapter IMMEDIATELY.
■Your Keenetic device can be safely wall-mounted using
two firmly attached screws on any wall strong enough
to support 4x the device weight.
Certification Information
Keenetic Limited hereby declares that this device
is in compliance with all relevant provisions of directives
2014/53/EU, 2009/125/EC, and 2011/65/EU.
Details of the original EU declaration may be found at
keenetic.com within details on specific model pages.
This device complies with EU radiation exposure limits set
forth for an uncontrolled environment.
This equipment should be installed and operated with
a minimum distance of 20 cm between the antennas
and a person’s body.
The frequency and the maximum transmitted power for
your device, per the requirements of the EU are listed below:
2400-2483,5 MHz: 20 dBm; 5150-5350 MHz: 23 dBm; 5470-
5725 MHz: 30 dBm. This device will support DFS and TPC
functionality while operating in the 5 GHz band.
20 mm or longer 128 mm
3.0~4.0 mm
1.5~2.0 mm
6.0~8.0 mm
This device is restricted to indoor use only when
operating in 5150 to 5350 MHz frequency range
(channels 36 - 64).
Per (EC) No 1275/2008, the power consumption
in networked standby if all wired network ports are
connected and all wireless network ports are activated
is 7,2 W.
Device Warranty
For the most up to date Warranty Information, please
visit our website keenetic.com/legal.
Your Keenetic device comes with a non-transferable
3-year warranty from the documented date of purchase
(including your 2-year European Limited Warranty). Valid
claims in case of a defect will be honored subject to local
legal requirements.
Disposal
In accordance with European directives, your
Keenetic device, including the power adapter
and cables may not be disposed of with general
household waste. Consult your local authority
or your supplier for information about disposal.
Notice
When you use your Keenetic device (including when you
connect your Keenetic device the first time), Keenetic
Limited will process certain personal data about you,
e.g., service tag, serial number, model name, software
version, and IP address of your Keenetic device. For more
information, please go to keenetic.com/legal.
If you are in the European Union / European Economic
Area, Keenetic GmbH will process certain personal data
about you, e.g., service tag, serial number, model name,
software version, and IP address of your Keenetic device.
Please read our Device Privacy Notice for the European
Union / European Economic Area at keenetic.com/legal.
