KEM ECO User manual

Certified according to DIN EN ISO 9001
Manual
ECO and ECO-COM.B.USB

2
Version
Version: ECO_M_ENG_220303_E001
Manual-Version
ECO_M_ENG_220303_E001

3
Version: ECO_M_ENG_220303_E001
Index
Index
1. WARNINGS AND NOTES IN THIS MANUAL ...........................................................................................4
2. GENERAL INFORMATION........................................................................................................................5
2.1. Features......................................................................................................................................................5
2.1.1. General Safety ............................................................................................................................................5
2.1.2. Special Requirements for Ex Installations ..................................................................................................5
2.1.3. Ordering Code ............................................................................................................................................6
2.1.4. Accessories.................................................................................................................................................7
3. GETTING STARTED ..................................................................................................................................7
3.1. Unpacking ...................................................................................................................................................7
3.2. Ordering Elements ......................................................................................................................................7
3.2.1. ECO ............................................................................................................................................................7
3.2.2. ECO-COM.B.USB.......................................................................................................................................8
3.3. PIN Assignments ........................................................................................................................................8
3.3.1. ECO ............................................................................................................................................................8
4. INSTALLATION..........................................................................................................................................9
4.1. Mechanical Installation................................................................................................................................9
4.1.1. Plug tap.......................................................................................................................................................9
4.2. Electrical Installation ...................................................................................................................................9
4.3. Ex Installation............................................................................................................................................10
5. OPERATION.............................................................................................................................................11
5.1. Normal Operation......................................................................................................................................11
5.2. Possible output configurations..................................................................................................................11
5.2.1. Digital configurations.................................................................................................................................11
5.2.2. Analog configurations ...............................................................................................................................12
5.2.3. 0-10V active + Frequency/Pulse (PP, NPN, PNP) – ECO XX-FW-XX-X .................................................14
5.3. Parameterization.......................................................................................................................................15
5.3.1. Installation of KEM EcoControl .................................................................................................................15
5.3.2. Connect ECO with PC/laptop ...................................................................................................................15
5.3.3. Adjustment notes ......................................................................................................................................17
6. SERVICE AND MAINTENANCE..............................................................................................................17
6.1. Maintenance .............................................................................................................................................17
6.2. Trouble Shooting.......................................................................................................................................17
6.3. Service ......................................................................................................................................................18
7. IMPORTANT INFORMATIONEN .............................................................................................................18
7.1. Warranty ...................................................................................................................................................18
7.2. Technical Data ..........................................................................................................................................19
7.3. Dimensional Drawings ..............................................................................................................................22
7.4. WEEE und RoHS......................................................................................................................................23
7.5. List of Figures ...........................................................................................................................................23

4
Warnings and notes in this manual
Version: ECO_M_ENG_220303_E001
1. Warnings and notes in this manual
NOTE:
Notes provide important information for the correct usage of the equipment. If the notes are not observed, a
malfunction of the equipment is possible.
WARNING!
Warnings provide very important information for the correct usage of the equipment. Not observing the warnings
may lead to danger for the equipment and to danger for health and life of the user.

5
General Information
Version: ECO_M_ENG_220303_E001
2. General Information
2.1. Features
ECO type pulse amplifiers are available with different taps and output configurations.
ECO is the generation of amplifiers from KEM that replaces all previous versions and variants. The possible
configurations include one or two channels as well as digital and analog outputs. An integrated medium
temperature measurement is included as standard.
The ECO family is compatible with all of KEM's positive displacement meters.
ECO has a proprietary communication interface integrated into the M12 connector. By using the interface adapter
ECO-COM.B.USB and the parameterization software KEM EcoControl the ECO can be parameterized.
ECO pulse amplifiers can be linearized with up to 20 points.Sicherheit
2.1.1. General Safety
All statements regarding safety of operation and technical data in this manual will only apply when the unit is
operated correctly in accordance with this manual.
The data for Ingress Protection (adequate IP rating) will only apply when all connectors are caped properly with
the corresponding counterpart with the same or better IP rating. Cable glands must be populated with cables with
the specified diameter and closed properly.
During operation all openings of the housing must be closed unless otherwise noted in this manual.
All connections to the load and to the supply must be made with shielded cables unless otherwise noted in this
manual. This unit must be grounded.
This unit must be supplied by a safety approved power supply with outputs which comply with Safety Extra Low
Voltage (SELV).
As a protection against fire in the positive supply a fuse with a current rating not higher than the current carrying
capacity of the cable used is required.
National and international standards regarding electrical installation have to be adhered to.
The devices described in this manual may only be connected and operated by authorized and qualified personnel.
2.1.2. Special Requirements for Ex Installations
When used in hazardous area a suitable separation amplifier or zener barriers must be used.
When using long cables make sure that the maximum inductances and capacitances for the respective voltage
or gas group are not exceeded.

6
General Information
Version: ECO_M_ENG_220303_E001
Order designations and accessories
2.1.3. Ordering Code

7
Getting started
Version: ECO_M_ENG_220303_E001
2.1.4. Accessories
Ordering Code Description
ECO-COM.B.USB: Interface adapter: KEM interface to USB. When communicating via ECO-COM.USB.B,
the ECO is supplied with voltage via the USB interface. The output functionalities are
not available during configuration.
KEM EcoControl: P Parameterization software for WINDOWS®. The minimum installation requirements:
Windows 10.
3. Getting started
3.1. Unpacking
Verify that you have received the following items:
When you ordered ECO:
•ECO
•User’s manual
•Conformation declaration (EU)
When you ordered ECO-COM.B.USB:
•ECO-COM.B.USB
•USB 2.0 cable A/B 1,5m
•CD with KEM EcoControl Software an USB drivers
3.2. Ordering Elements
3.2.1. ECO
Fig. 1: ECO controls
1 = Connector plug
2 = Sensor tip
3 = Screw tap M14 thread
4 = Pickup tip
2
4
1
3

8
Getting started
Version: ECO_M_ENG_220303_E001
3.2.2. ECO-COM.B.USB
Abb. 2: Bedienelemente von ECO-COM.B.USB
1 = Cable screw connection, M12 socket for connection to ECO
2 = Control LED
3.3. PIN Assignments
3.3.1. ECO
1 Vcc / Loop+ (24 V)
2 Digital Output 2 / NAMUR
3 GND / Loop-
4 Digital Output 2 / NAMUR
5 Active Analog Output
14
5
23
1
2

9
Installation
Version: ECO_M_ENG_220303_E001
4. Installation
4.1. Mechanical Installation
Depending on the version of the tap, the installation is performed differently.
WARNING!
Too much force will damage the sensor tip!
4.1.1. Plug tap
Place the ECO in such a way that the tapping holes in the sensor and the insertion tips match. Screw the ECO
onto the sensor hand-tight using the hexagon socket screws (wrench size 3 mm) already inserted in the
housing.Schraubabgriff M14x1.5
Carefully screw the ECO with the sensor tip by hand (without using tools) into the M14x1.5 mounting thread of
the measuring cell until it stops.
WARNUNG!
Too much force will damage the sensor tip!
Turn the ECO back by 15°.
Fix the ECO with the lock nut on the sensor tip.
4.2. Electrical Installation
HINWEIS:
For connecting, shielded cables must be used. The ECO housing is connected to the cable shield.
WARNING!
Improper grounding and shielding may lead to bad EMC behavior or danger to your health!
Connect the ECO via a shielded cable to the control unit. The ECO requires a regulated DC power supply of
24 V nominal and works properly over a supply range of 12 V to 28 V.
HINWEIS:
Make sure that all cable and wires are connected and fixed properly before applying power to the ECO.
For the electrical connections refer to the drawings in chapter 5.1.

10
Installation
Version: ECO_M_ENG_220303_E001
4.3. Ex Installation
The ECO … -Ex is intrinsically save when operated with zener barriers.
Follow the installation instructions from the chapter 4.1.
Connect the ECO to isolation amplifiers via a shielded cable..
WARNING!
When used in hazardous areas the ECO must not be connected to any circuitry except suitable zener barriers.

11
Operation
Version: ECO_M_ENG_220303_E001
5. Operation
5.1. Normal Operation
If the ECO is ordered together with a mechanical sensor, the ECO is already set to this and no further settings
are required for operation.
5.2. Possible output configurations
ECO offers a large number of possible output configurations, which are defined as follows. A distinction is only
made on the basis of the hardware configurations. If the ECO is purchased independently of a KEM
displacement meter, the frequency range must still be set. (EcoControl)
5.2.1. Digital configurations
The frequency/pulse and NAMUR configurations are called digital configurations. With dual channel versions
(ECO X2) you have the possibility to output the measured sensor signals directly, scaled (up to approx. 5 kHz)
or the direction information. For single channel versions (ECO X1) only the flow information is available.
5.2.1.1. Frequency/Pulse (PP, NPN, PNP) – ECO XX-PN-XX-X
Es A frequency/pulse output is provided, whose driver circuit is set by software (default: Push-Pull, PP). The
frequency range is set to the measuring range of the sensor. Upper limit is approx. 5 kHz).).
Fig 1: EcoControl configuration interface

12
Operation
Version: ECO_M_ENG_220303_E001
5.2.1.2. NAMUR Output – ECO XX-NN-XX-X
In dieser Konfiguration steht die Frequenz/Puls Information im „NAMUR-Format“ an. So können weitere
Informationen wie Kurzschluss bzw. Kabelbruch festgestellt werden. Es handelt sich bei dieser Konfiguration
nicht um einen NAMUR Sensor, er benötigt zum Betrieb eine 24 V DC Spannungsquelle.
Fig 2: EcoControl configuration interface
5.2.2. Analog configurations
In addition to the frequency/pulse information, analog configurations offer the possibility of outputting a further
analog output variable. The flow rate or the medium temperature is available as the reference variable for this
analog information. The analog outputs also have the option of signaling an error.
5.2.2.1. 4-20 mA Passive + Frequency/Pulse (NPN) – ECO XX-AN-XX-X
In addition to the ECO XX-PN-XX-X configuration, a passive 4-20 mA current loop is available here, which also
supplies the device with power (two-wire operation).
Fig 3: EcoControl configuration interface

13
Operation
Version: ECO_M_ENG_220303_E001
5.2.2.2. 0-20 mA Active + Frequency/Pulse (PP, NPN, PNP) – ECO XX-FV-XX-X
This configuration offers an active current loop in addition to the frequency/pulse functionality.
Fig 4: EcoControl configuration interface

14
Operation
Version: ECO_M_ENG_220303_E001
5.2.3. 0-10V Active + Frequency/Pulse (PP, NPN, PNP) – ECO XX-FW-XX-X
Here, in addition to the frequency/pulse functionality, an active voltage output (0-10 V) is available.
Fig 5: EcoControl configuration interface

15
Operation
Version: ECO_M_ENG_220303_E001
5.3. Parameterization
A communication interface is implemented in the ECO which uses a digital output for data transmission.
The communication to the PC/laptop is enabled by means of the communication adapter ECO-COM.B.USB and
the parameterization software KEM EcoControl.
WARNING!
During parameterization the outputs cannot be used, the ECO is supplied via the communication adapter.
5.3.1. Installation of KEM EcoControl
You can find the EcoControl software in the download area of the KEM website. There is an installer that installs
all the necessary components on your PC/laptop.
5.3.2. Connect ECO with PC/laptop
Plug the ECO-COM.B.USB into a free USB (USB-A) port.
Start the program.
In the upper part of the screen there is an area "Connection".
Fig 6: Connection on the EcoControl configuration interface
There, next to the Connect button, some status information is displayed:
Rx:number of received telegrams
Err: number of communication errors (serial communications can sometimes have errors)
Circle, which can be red, orange or green.

16
Operation
Version: ECO_M_ENG_220303_E001
After pressing the Connect button you should see the following picture
Fig 7: directly after connection establishment
Model code is displayed, if the ECO was purchased together with a sensor, rudimentary sensor information is
also available (here only ECO without sensor - marked by "??").
All input fields are outlined in orange and can be changed. "Sensor Serial Number" and "Sensor Model Code"
should be taken from the calibration protocol or the type plate of the sensor.
Fig 8: Selection of the sensor, or entry of the K-factor
When you select a sensor, the standard measuring range and, via the K-factor, also the measured frequency
are displayed. These fields can be overwritten manually.

17
Service and Maintenance
Version: ECO_M_ENG_220303_E001
5.3.3. Adjustment notes
K-factor and calculation of flow rate
The flow rate Q is proportional to the input frequency f_(in ), as shown in the fromel below:
[/] = 
 []60
[/]
For. 1: Flow rate calculation
K-factor KF is unique for each displacement meter. The value of K-factor is determined by means of the mandatory
flow calibration. Only authorized persons may change the K-factor of a KEM displacer meter!
6. Service and Maintenance
6.1. Maintenance
The ECO does not require regular maintenance.
If for the specific application an obligatory calibration is required, refer to the corresponding national regulations
for the necessary calibration intervals. For the best performance we recommend a calibration of current output in
the interval of 5 years.
The calibration can be carried out by ECO-COM.B.USB and the software KEM EcoControl directly from the
customer or in our production.
6.2. Trouble Shooting
In case the ECO does not work properly, first check the following items:
No output signal?
All cables properly connected, as described in chapter 4.1?
Connect the missing cables..
ECO properly mounted , as described in chapter 3.1?
Verify that the installation was performed properly.
Output frequency too low?
Alle No output signal?
All cables properly connected, as described in chapter 4.1?
Check the wiring.
The flow meter ist running?
Check the flow meter! Replace the counter if necessary.
Output frequency too high or unstable?
Most probably EMC problems
Shield and ground properly connected?
Connect shield properly.
If necessary, try additional means of grounding and shielding

18
Important Informationen
Version: ECO_M_ENG_220303_E001
6.3. Service
The ECO does not contain any user serviceable parts.
In case of malfunction, please contact your nearest dealer or directly KEM.
For the addresses see the last page of this document.
7. Important Informationen
7.1. Warranty
For warranty refer to the general terms and conditions of KEM Küppers Elektromechanik GmbH, which can be
found on the corresponding website (www.kem-kueppers.com).

19
Important Informationen
Version: ECO_M_ENG_220303_E001
7.2. Technical Data
General technical data
Mounting
Flush-Mount (1- or 2-Channel)
Screw-in M14x1.5 (1- Channel)
Power Supply
12 ... 28 VDC, regulated
Current Consumption
< 25 mA
Frequency Range
1 ... 5000 Hz; suitable for all KEM volumetric counters
Output Stages
Push-Pull active, PNP, NPN
NAMUR
4-20 mA passive + Freq/Puls (NPN)
0- 20 mA active + Freq/Puls (PP, NPN, PNP)
0- 10 V active + Freq/Puls (PP, NPN, PNP)
Output Signal
1:1 Frequency or Direction signal & doubled Frequency scaled
output values
Temperature Measurement
±1 °C ±0.5 %
Ambient Temperature
40 °C ... +60 °C [40 °F ... +140 °F]
Medium Temperature
Flush-Mount (1- or 2-Channel)
-40 °C ... +80 °C [- 40 °F ... +176 °F]
Screw-in M14x1.5 (1-Channel)
-40 °C ... +120 °C [- 40 °F ... +248 °F]
- 40 °C ... +150 °C [- 40 °F ... +302 °F]
Housing Material
Aluminium die casting alloy 231 or Stailness Steel
Sensor Probe Material
1.4404 [AISI 316L] all Variants
Protection Class
Aluminium IP65
Stailness Steel IP68
Weight
approx. 200 g
Electrical Connection
Short circuit proof, Reverse polarity protected)
M12 Connector (5-pole, male, A-coded)
Connector
1 - Vcc / Loop+ (24 V)
2 - Digital Output 2 / NAMUR
3 - GND / Loop-
4 - Digital Output 1 / NAMUR
5 - Active Analog Output
Operating values output stages
NPN
 =  . (  )
min
max
RL
2500 Ω
IL
30 mA
UL
28 V
Vcc
12 V
28 V
ECO
Pin 1 (Vcc)
Pin 2, 4
Pin 3 (GND)
RL

20
Important Informationen
Version: ECO_M_ENG_220303_E001
PNP

=  0.5  (940   )
min
max
RL
2500 Ω
IL
27 mA
UL
28 V
Vcc
12 V
28 V
Push-Pull (PP)

=  0.5  (940   )
min
max
RL
2500 Ω
IL
30 mA
UL
28 V
Vcc
12 V
28 V
NAMUR
4-20 mA passive + Frequency/Pulse (NPN)
 =
 
.
min
max
RL
300 Ω
IL
21 mA
Vcc
21.6 V
28 V
4-20 mA active + Frequency/Pulse (PP,NPN,PNP)
 =
 
.
min
max
RL
600 Ω
IL
21 mA
UL
25 V
Vcc
16.8 V
28 V
ECO
Pin 1 (Vcc)
Pin 2, 4
Pin 3 (GND)
RL
ECO
Pin 1 (Vcc)
Pin 2, 4
Pin 3 (GND)
ECO
Pin 1 (Vcc)
Pin 2,
4
Pin 3 (GND)
ECO
Pin 1 (Loop+)
Pin 2,
4
Pin 3 (GND / Loop-)
RL
ECO
Pin 1(Vcc)
Pin 2, 4 (PP, PNP, NPN)
Pin 3 (GND / Loop-)
Pin 5 (Loop+)
IO
