MONITOR WITH DVD RECEIVER
DDX6027/6027Y
DDX7017/7037
DDX7047/7067
SERVICE MANUAL
This product uses Lead Free solder.
EJECT
FNC
AVOUT
PWR
LOUD
OFF
SEL
MODE
SCRN
DIM
AUTO
SRC
VOL SEEK
S
MONITOR WITH
DVD
RECEIVER
DC cord
(E30-6477-15) DC cord (E30-6475-15) Screw set (N99-1776-05) Lever (D10-4674-04) x2
Antena adaptor
(T90-0552-05)
Remote controller
(A70-2072-05 : RC-DV601)
Mounting hardware assy
(J22-0171-03)
Escutcheon
(B07-3046-04)
Size AAA battery
Not supplied
DC cord
(E30-6478-05)
Escutcheon
(B07-3105-02)
Panel assy
(A64-3581-01): DDX7017, (A64-3582-01): DDX7047
(A64-3583-01): DDX6027/6027Y
(A64-3584-01): DDX7037, (A64-3586-01): DDX7067
DDX6027/6027Y only DDX7017/7037/7047/7067 only
Illustrations is DDX7017
