MONITOR WITH DVD RECEIVER
DDX7015/7025/7035
SERVICE MANUAL
/7045/7065
F2
DC cord
(E30-6342-05)
Screw set
(N99-1754-05)
Remote controller assy
(A70-2064-05)
Panel assy
(A64-3302-12): DDX7025, (A64-3341-12): DDX7015, (A64-3342-12): DDX7045 (R)
(A64-3343-12): DDX7035, (A64-3344-12): DDX7065, (A64-3345-12): DDX7045 (X)
Antenna adaptor
(T90-0512-05)
Mounting hardware assy
(J22-0171-03)
Lever
(D10-4589-04)
Escutcheon assy
(B07-3046-04)
F2
DC cord
(E30-6343-05) DC cord
(E30-6341-15)
(RC-DV420)
Escutcheon
(B07-3105-02)
Depends on the model. Refer to the parts list.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

2
DDX7015/7025/7035 DDX7045/7065
BLOCK DIAGRAM
POWER SUPPLY
(X14-939)
VIDEO CONTROL UNIT
from X14 MCU MOTOR
DRIVER
from X14 MCU
OR
to X14 MCU from X14 MCU
to ROM WRITER
RGB SW
CLAMP
(E) TYPE ONLY
+DRIVER+MUTE
LPF+6dB amp
ENCODER
VIDEO
DECODER
MPEG
OSC
27MHz
SYS
COM
EEPROM
2ch AUDIO
DAC MUTE
OPT DRIVER
to BOX MCU
to X34
(ELECTRIC UNIT)
to X14 MCU
DC CONNECTOR
TRANCE
DC/DC
DC/DC
REG
REG
REG SRAM
MPU
to X16 (SUB CIRCUIT UNIT) to X35 (VIDEO UNIT)
LB1836
OSD IC
LC74735NW9817EMB29LV8T9TN6R
FROM
DC/DC
CHROMA &
AN2546FH-AV IC
NJW1303V
SYNC SEP
MM1234XFBE
RGB SW
E2PROM
MM1389XFBE
70F3089YGJ-7R5
SYS COM
ADV7170KSU
ES6218SF
MT48LC4M16T75I
SDRAM
29LV160AT17R2
FLASH SRAM
K6F1008V2CYF55
MM1567AJBE
AK4382AVT
FPGA
M4A3212V18TV1
NJM4580V
LPF
to MECHA
IC200
IC303IC400IC401
IC102
IC100 IC104
IC108
IC101
IC103
IC701
IC703
IC521
IC770
IC520
IC200
IC204
IC541
IC560 IC601 IC652
IC650
IC304
IC362
IC204
IC202
I/F CONNECTOR
CN501
to DVD MECHANISM ASSY
IC750
LCD CONTROL
LCD CS
LCD DATA
LCD CLK
EJECT
KEY CONTROL
SRC
RESET
KEY2
REMO
LED R,G,B
LED SW
SRM MO12
SRM MO11
2
OSD DATA
OSD CLK
OSD CS
OSD RST
OSD RG
HD,VD
HSY,VSY
RGB
VCO
CLAM
POLC
POLS
3
BLK (MASK)
VMUTE
CSYNC
BU5V
KEY3
KEY4
SRC
LCD PON
MIRROR
REMO
MEC SW D
XDATA,YDATA
POS D
NTSC PAL
HPOSI1,2,3,4
MODE1,2,3
X0,Y0,Y1
PWM
SCL
SDA
(12C BAS)
M CLK
FROM VPP
S DATA
M DATA
RESET
SYNC SW
TV,NAVI RG
COMPOSIT
DVDRGB
DVDCOMP V
DVDRGB
DVDCOMP V
CCIR601 [7:0]
VCLOCK
VSYNC
HSYNC
DATABUS [15:0]
SDRAM CLK
RGB SW VIDEO
ATAPI I/F
LOCAL I/F
BCLK
DATAI
LRCLK
MCLK
SPDIF
R REQ
M CLK
S DATA
S REQ
M DATA
SYS ON
ADACML
ADACMC
ADACMD
ADACRST
27MHz
CS
CPUA [1:0]
CPUA17
CPUD [3:0]
SYSTEM DATABUS
[15:00] REMO
ACC DET
REV DET
PRK DET
ACC
REVERSE
ILLUMI
BU14.4
GND
PRK SW
+14.4
PON
8.5V
PON
+14.4 SW5V
MECHA7V
+14.4
PON SW3
+7.5V
SW2V
+7V -7V
BU5V
BU3.3V
+14.4
NTSC/PAL
AUDIO
DOWN MIX
SI
GND
ACC
BU14.4
●VIDEO CONTROL UNIT
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

3
DDX7015/7025/7035 DDX7045/7065
ELECTRIC UNIT (X34-316)
LX I/F
NAVI I/F
u-COM
u-COM
u-COM
to X14
to TV
u-COM
AUDIO
SELECTOR
u-COM
SELECTOR
AUDIO
AUDIO SW2
AUDIO SW1
VISUAL SW1 VIDEO SW
SYSTEM
u-COM
VISUAL SW2 VIDEO SW
SYSTEM
u-COM
RGB SW
u-COM
V
R
L
AV IN
VIDEO SW
u-COM
SYNC SEP.
MM1108XFFE
INPUT
SELECTOR
SELECTOR
OUTPUT
SOFT MUTE
u-COM
BUFF
u-COM
PROCESSOR
AUDIO
HPFILTER
LPFILTER
u-COM
MUTE
MUTE
MUTE
MUTE PRE L
RFRONT
R
LREAR
R
LNF
PRE OUT
R
L
V
AV OUT
MUTE
MUTE SUB OUT
75
BUFF
DRIVER
u-COM
u-COM
u-COM u-COM
SYSTEM
BUFF
RDS
DECODER
u-COM
(F/R)
POWER IC
SP OUT
(F/E)
SW5V
u-COM
u-COM
ANT IN
u-COM
4ch OUT
6dB AMP
75
NJM2267Vx2
IC300
(E)TYPE ONLY
BA3121F
ISO AMP
TC4052BFT
TC4052BFT
BA7652F
BA7612F
MM1234XFBE
MM1503
DRIVER
BA3121F
ISO AMP
BA3121F
ISO AMP
TC7SH08F
BUFF
E-TDA7414
TDA7401
TB2903H
TDA7479D
BA3129Fx2
NJM4565V
1/2 VCC u-COM
IC501
IC555
IC553
IC200
IC103
IC552
IC551
IC450,451
IC301
IC554
IC550 IC250
NJM4565x2
BUFFER
u-COM
HA12187FP
u-COM
PORT VOLTAGE
INSTANTANEOUS
INSTANTANEOUS
PORT VOLTAGE
MUTEu-COM
MZ BUS
L,R ONLY
GSM
DSP BOX ON
IC703,704
IC705
IC700,701
3
8RESET
MUTE
REQC
REQH
DATAC
DATAH
CLK
CHCON
3
3
2 TX RX
RESET
REMO
MUTE
M CON
M CLK
M DATAH
M DATAC
M REQH
M REQC
OOMP GND
COMP V
COMP GND
COMP V
RGB GND
B
G
R
DVD R
DVD L 3
3
7
TV L
TV R
TV COMP V
R
G
B
SC DATA
SC REQ
MC DATA
MC REQ
BP CLK
SC CON
(REMO)
RESET
6
3
3
0
1
2
3
2
3
0
2
1
2
3S2
1
S1 2
2
3S1
S2
1
2
SW
3
CTL
1
2
CD-
AUX
CD
MD
MPX/A
MAIN
SELECTO
SELECTO
SUB
2
2
ACIN 0
ACIN 1
ACIN 2
ACIN 3
MID
REAR
FRONT
FREE
SMETER
QUAL
DCERR
AFS
SMUTE
SDA
SCL
WIN IN
6
22
2
AB
2
BA
HP-FL
HP-FR
HP-RL
HP-RR
AUX-L
AUX-R NF
FRONT
REAR
SDA
SCL
2
2
2
2
IN (FRONT)
IN (REAR)
DC OFFSET
STBY
SVR
PMUTE
BEEP
4
3
MPX
RDCL
RDDA
QUAL
OUT 16
SMETER
A OUT
IF COUNT
SDA
SCL
AM IN
FM IN
VDD 5V
4
ILL
GND
B.U
LINE MUTE
EXT AMP CONT
P.CON
ANT.CON
FL,FR,RL,RR
6
4
AC
SUB
2
2
BUS ON
BUS OFF
RESET
MUTE
L,R
FRONT L,R
REAR L,R
LINE 1 2
2
2
4
2TX
STBY
RX
3
2
INSTANTANEOUS PORT VOLTAGE
MUTE LEFT
MUTE RIGHT
●ELECTRIC UNIT
BLOCK DIAGRAM
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

4
DDX7015/7025/7035
DDX7045/7065
VIDEO UNIT (X35-4332-70)
TC7W14FU
TC7SET08FU
IC101
IC203
IC302
DC-DC IC
LT1947
COM AMP
TA75W558FU
IC304
TIMMING
CONTROLLER
TC200G02AF-0104
IC301
NJM2107F
PLL & LPF
IC303
TOUCH PANEL
SWITCH TOUCH PANEL
S79-0827-05
BACK LIGHT
INVERTER
SW PCB
(C/3)
6.5 INCH
LCD
CFL
CIRCUIT
CN303
PON+5.0V
VGND
V.SYNC
VGND
PON+3.3V
VR/VG/VB
PON-12.0V
PON+18.5V
PON+12.5V
V.COM
POLS/POLC/HSY/VSY/BLK
/NTSC PAL/MIRROR
PDOS/OSCI
VGH+18.5V16
NC1STH2
VR
2
3VG
VB
4
5
L/R(HDIR)8
VSS
STH1
6
7
CX
VSS
9
10
VCOM
VSS13
CPH(CPH1)
VSS
11
12
NC
14
15
VDD2+5.0V
VDD1+3.3V
NC17
18
19 STV2
OE2(NGOE2)22 OE1(NGOE1)
20
21
OE3(NGOE3)
CPV
23
24
VSS27
U/D(UPSD)
STV1
25
26
NC
VGL-12.0V
28
29 NC30
VB
VG
VR
STV1
USPD
CPV
NGOE3
NGOE2
NGOE1
STV2
V.COM
CPH1
CX
HDIR
STH1
STH2
NGOE3/CPH1
NGOE1/NGOE2/
STV1/STV2/STH1/STH2/
USPD/CPV/HDIR/CX/
PON+18.5V
PON+5.0V
PON+3.3V
PON+5.0V
XDATA/YDATA
X0/X1/Y0 X0/X1/
Y0/Y1
D.GND
PWM/ENABLE
BL+8.5V
BL GND
PON+5.0
LED+8.5V(R)/LED+8.5V(G)
ESD GND
EJECT/KEY3/KEY4/SI/RESET/REMO
H.SYNC
PON+3.3V
VGND
PON-12.0V
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
P ON+5.0V
P ON+5.0V
NC
V GND
V GND
LCD PON
D GND
EJECT
KEY3
KEY4
LED GND
SI
NC
LED+8.5V(B)
LED+8.5V(G)
LED+8..5V(R)
NC
P ON+3.3V
NC
V GND
VB
VG
VR
V GND
C.SYNC
V GND
NTSC PAL
POLC
POLS
MIRROR
VSY
HSY
BLK
MODE3
MODE2
MODE1
HPOS4
HPOS3
HPOS2
HPOS1
NC
VCOM
NC
P ON+5.0V
BU +5.0V
KEY1
XDATA
YDATA
X0
X1
Y0
SRC
PWM
ENABLE
NC
NC
BLGND
BLGND
NC
BL+8.5V
BL+8.5V
NC
NC
ESD GND
ESD GND
NC
RESET
REMO
MODE1/2/3/HPOS1/2/3/4
BU+5.0V
D.GND
●VIDEO UNIT
BLOCK DIAGRAM
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

5
DDX7015/7025/7035
DDX7045/7065
●DVD X35 POWER SUPPLY/GND MAP
X14
DVD X35 POWER SUPPLY/GND MAP
+7.5V AVR
IC
DC-DC
COM AMP TIMING
CONTROLLER PLL & LPF
+5.0V AVR OZ960IS
LCD
7 INCH
CFL
SWITCH CIRCUIT
TOUCH PANEL LED RED
x4 LED GREEN x4
SW PCB B
PHOTO REF TILE SENS
INDASH
7 INCH
MECHA
BL+8.5V
PON+3.3V
PON+14.0V
PON+5.0V
PON-12.0V
PON+12.5V
PON+18.5V
V GND
V GND
BL GND
SW+3.3V
D GND
LED GND
BACK-LIGHT INVERTER
PON-12.0V
PON+18.5V
PON+5.0V
PON+3.3V
BL+8.5V
AUTO DIMMER
SW PCB A
LED+8.5V (GREEN)
LED+8.5V (RED)
LED GREEN
LED RED
x3 MINI
SW+5.0V
REF+5
D GND
PON+3.3V
PON+5.0V
PON+7.5V
BLOCK DIAGRAM
COMPONENTS DESCRIPTION
●VIDEO CONTROL UNIT (X14-939x-xx)
Ref.No. Application/Function Operation/Condition/Compatibility
IC100 SW power supply control IC SW5V, mechanism 7V DC/DC
IC101 SW power supply control IC SW3.3V, storage mechanism 7.5V DC/DC
IC102 SW power supply control IC ±7.5V, BL8.5V DC/DC
IC103 3 terminal regulator BU5V output
IC104 Low-loss regulator BU3.3V output
IC105 2ch comparator BU low voltage detection
IC106 Inverter P_ON control
IC107 3 terminal regulator drive Video system 7.5V output
IC108 Low-loss regulator SW2V output
IC200 E2PROM System µ-com memory
IC202 Motor driver Slide mechanism motor control
IC203 Motor driver Tilt mechanism motor control
IC204 Microcomputer System control
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

6
DDX7015/7025/7035
DDX7045/7065
Ref.No. Application/Function Operation/Condition/Compatibility
IC205 AND Remote control output buffer
IC206 Inverter Microcomputer reset control
IC207 Reset System µ-com reset control at low voltage
IC300 3 terminal regulator Video system 5V power supply output
IC301 1H delay PAL color difference signal delay
IC302 RGB switch RGB signal SYNC cutting
IC303 RGB decoder RGB decode
IC304 RGB switch DVD/NAVI,TV switching
IC305 3 terminal regulator Video system 3V power supply output
IC306 Inverter V. MUTE control
IC361 NAND HD, VD mix
IC362 Synchronous separation Synchronous separation
IC363,364 3ch buffer HD, VD buffer
IC365 Mono-multi HD timing for OSD
IC400 OSD OSD graphic signal occurrence
IC401 Flash ROM OSD font data ROM
IC520 Flash ROM MPEG decoder control program ROM
IC521 SRAM Backup ROM for MPEG decoder
IC522 NAND SRAM chip selection
IC540 Inverter 27MHz buffer
IC541 Inverter 27MHz oscillation
IC560 SDRAM RAM for temporary storage of decoded signal
IC580 ANDx4 (4 AND’s included) 3.3V→5V conversion
IC601 MPEG decoder IC for decoding encoded signal
IC650 Driver IC for visual signals Lowpass filter + 6dB_AMP + DRIVER
IC651 Regulator IC Video 5V regulator
IC652 Video encoder Converts digital video signals into analog
IC701 Ope amp Active filter circuit for audio signals
IC702 Regulator IC Audio 5V regulator
IC703 Audio DAC Converts digital audio signals to analog
IC750 Inverter Drive for optical output
IC770 CPLD Audio DAC control, Chip selection control of SRAM
Q100~103 Digital transistor P_ON control
Q104,105 Small signal NPN transistor BU reduced current detection
Q106 High-speed power SW FET SW14V output
Q107 Small signal NPN transistor ACC detection control
Q108 Digital transistor Parking detection control
Q109 High-speed power SW FET SW5V, mechanism 7V DC/DC
Q110 High-speed power SW FET SW3.3V, storage mechanism 7.5V DC/DC
Q111 High-speed power SW FET ±7.5V, mechanism 7V DC/DC
COMPONENTS DESCRIPTION
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

7
DDX7015/7025/7035
DDX7045/7065
Ref.No. Application/Function Operation/Condition/Compatibility
Q112 Low-frequency power Video system 7.5V output
amplifying PNP transistor
Q113 Small signal PNP transistor Fan power supply 12.8V output
Q114 Small signal NPN transistor Fan power supply 12.8V output
Q115 Medium power amplifying Fan power supply 12.8V output
PNP transistor
Q116 Small signal NPN transistor Fan power supply 12.8V output
Q117 NPN digital transistor Storage mechanism power supply switching control
Q118 Small signal PNP transistor BL8.5V over current detection
Q119 NPN digital transistor BL8.5V over current detection
Q120 Small signal PNP transistor BU5V/SW5V switching
Q121 NPN digital transistor BU5V/SW5V switching
Q122 Small signal PNP transistor BU5V/SW5V switching
Q123,124 Small signal NPN transistor BU5V/SW5V switching
Q170,171 Digital transistor SW5V, mechanism 7V DC/DC oscillation frequency switching
Q172,173 Digital transistor SW3.3V, storage mechanism 7.5V DC/DC oscillation frequency switching
Q174,175 Digital transistor ±7.5V, mechanism 7V DC/DC oscillation frequency switching
Q200,201 Digital transistor Blue illumination control
Q202,203 Digital transistor Green illumination control
Q204,205 Digital transistor Red illumination control
Q206 Digital transistor BOX microcomputer
Q207 Digital transistor Microcomputer reset control
Q300 Small signal PNP transistor Chroma LPF fc NT/PAL switching
Q360 Small signal NPN transistor Y signal input buffer
Q361 Small signal PNP transistor C signal input buffer
Q362 Small signal PNP transistor Synchronous separation circuit V signal input buffer
Q400 Small signal PNP transistor OSD R signal output buffer
Q401 Small signal PNP transistor OSD G signal output buffer
Q402 Small signal PNP transistor OSD B signal output buffer
Q403 NPN digital transistor OSD clock NT/PAL switching control
Q650 PNP digital transistor RGB_SW reversal
Q652 NPN digital transistor IC650 6pin input signal muting
Q701 Small signal NPN transistor Audio DMIX_L signal muting
Q702 Small signal NPN transistor Audio DMIX_R signal muting
Q703 Small signal NPN transistor Audio mute control
Q704~707 Digital transistor Audio mute control
Q751 Small signal NPN transistor COAX output driving
Q752 Small signal PNP transistor COAX output driving
Q901 Medium power amplifying TDF panel section power supply ON/OFF control
PNP transistor
Q902 Small signal NPN transistor TDF panel section power supply ON/OFF control
COMPONENTS DESCRIPTION
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

8
DDX7015/7025/7035
DDX7045/7065
●ELECTRIC UNIT (X34-316x-xx)
Ref.No. Application/Function Operation/Condition/Compatibility
IC1 3-terminal regulator IC Generates 8.4V for audio from BU14V.
IC3 3-terminal regulator IC Generates 5.0V for visuals from BU14V.
IC100 Logic IC For audio mute control.
IC101 Logic IC When BU5V goes below 3.7V, reset with output L (When microcomputer is flushed, 4.2V).
IC103 X34 board controller Control of X34 board, Communication with other boards and connected devices.
microcomputer
IC200 RDS demodulator IC Demodulation of RDS signals.
IC250 Power IC Power amplifier for speaker output.
IC300 Digitally audio processor IC 4ch hipass filter, 2ch lowpass filter.
IC301 Electrical volume, Selector,
NC MPX IC
IC350 Isolation amplifier IC For LX BUS
IC400 Logic IC For making navigation and other remote control lines independent.
IC450,451 75Ωdriver, 6dB amplifier IC For video signals from X34 to X14.
IC452 Logic IC For reversing reset signal.
IC500 Isolation amplifier IC ForTV TUNER.
IC501 RGB switch IC For selection of RGB signals for TV or NAVI.
IC550,554 4ch multiplexer For selection of audio signals for LX, NAVI, TV or AVIN.
IC551 Video switch For selection of composite signals for IC553 or AVIN. Used for detecting NTSC, PAL and
detecting rear camera.
IC552 Sync separator IC For determination of NTSC, PAL.
IC553 75Ωdriver + video switch For detection of visual output signal for X14 (TV/AVIN/NAVI).
IC555 75Ωdriver + video switch For selection of visual output signal for AVOUT (DVD/TV/AVIN).
IC600 Isolation amplifier IC For AVIN.
IC700,701 Switching ope amplifier For isolation of audio signal from DSP box and SW for X34 audio signal.
IC702 Operational amplifier For 1/2VCC supply to BA3121F (LX/TV/AVIN).
IC703,704 Operational amplifier For isolation of audio signal from DSP box.
IC900 Operational amplifier For noise canceling circuit.
Q1,2 BU5V switch Turned ON when BU14V is supplied.
Q3 BU5V switch Turned ON when Q9 is turned ON.
Q4 A9V switch Turned ON when SW14V is supplied.
Q5 V5V switch Turned ON when SW14V is supplied.
Q6 A9V power supply Turned ON when Q4 is turned ON.
Q8 SW14V switch Turned ON when P-ON.
Q9 SW5V switch Turned ON when P-ON.
Q10 V5V power supply Turned ON when Q5 is turned ON.
Q19 Illumination switch Turned ON when illumination is turned ON.
Q20 ANT-CONT switch Turned ON whenTUNER is selected.
Q21 P-CONT Turned ON when P-CONT is turned ON.
COMPONENTS DESCRIPTION
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

9
DDX7015/7025/7035
DDX7045/7065
Ref.No. Application/Function Operation/Condition/Compatibility
Q22 P-CONT Turned ON when Q21 is turned ON.
Q23 P-ANT switch Turned ON when Q20 is turned ON.
Q24 P-CONT Turned ON when Q25 is turned ON.
Q25 P-CONT Turned ON when BU14V is supplied.Turned OFF when Q22 is turned ON.
Q26 BU detection switch Turned ON when BU is detected.
Q27 EXT-AMP switch Turned ON when EXT-CONT terminal is L.
Q100 S-MUTE reverse switch Turned ON when momentary power down, when reset, and when S-MUTE is turned ON.
Q200 AM power supply switch Turned ON when TUNER is selected.
Q201 AM power supply switch Turned ON when Q200 is turned ON.
Q300 NOISE switch Turned ON when IC301QUAL terminal is Hi.
Q301 S-MUTE switch Turned ON when Q100 is turned ON.
Q460 TV resetting reverse switch Reverses when reset and outputs Hi.
Q551~554 Voltage conversion audio Outputs by converting 5V→8V.
selector switch
Q600,601 Muting sub-woofer Turned ON when Q607 is turned ON.
Q602,604~606 Muting pre-out Turned ON when Q603 is turned ON.
Q603 Muting pre-out Turned ON when momentary power down, when reset, and when MUTE_PRE is turned ON.
Q607 Muting sub-woofer Turned ON when momentary power down, when reset, and when MUTE_SW is turned ON.
Q608,610 Muting AVOUT Turned ON when Q609 is turned ON.
Q609 Muting AVOUT Turned ON when momentary power down, when reset, and when MUTE_AVOUT is turned ON.
Q700 IC700, 701 switching switch Controlled by ES_DSP_SW.
Q702 Muting GSM left audio Turned ON when momentary power down, when reset, and when MUTE_LEFT is turned ON.
Q703 Muting GSM left audio Q702 is turned ON.
Q704 FAN5V MZ_SYS_ON is turned ON.Turned OFF when MZ_SYS_OFF is turned ON.
Q705 For J701 Turned ON/OFF by 05 signal.
(optical output connector)
Q706 Muting GSM right audio Turned ON when Q707 is turned ON.
Q707 Muting GSM right audio Turned ON when momentary power down, when reset, and when MUTE_RIGHT is turned ON.
Q712 Muting BUS Turned ON when BUS_MUTE is turned ON.
Q713 Muting BUS Turned ON when Q712 is turned ON.
Q904~906 Noise canceller -
●VIDEO UNIT (X35-4332-70)
Ref.No. Application/Function Operation/Condition/Compatibility
IC1 Inverter control IC Controlling and driving inverter circuit for backlight.
IC101 DC/DC converter ±12V power supply for VCOM amplifier, -12.0V/+18.5V LCD power supply.
IC203 VCOM amplifier VCOM signal amplifier.
IC301 Timing controller LCD module control.
IC302 AND V. SYNC delay buffer.
IC303 PLL LPF PLL control LPF (VT voltage control).
COMPONENTS DESCRIPTION
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

10
DDX7015/7025/7035
DDX7045/7065
MICROCOMPUTER’STERMINAL DESCRIPTION
●SYSTEM MICROCOMPUTER : 703068YGJ-108 (X14 : IC204)
Pin No. Pin Name I/O Module Function Processing Operation Description
1AUTO_DIM NC
2KEY4 I KEY Keys (5)
3KEY3 I KEY Keys (6)
4NC I
5PORTGND0 - µCOM
6PM1_SWD NC
7LCD_VOFF_EN O LCD ON/OFF control over backlight power supply H : ON, L : OFF
8NCO L-fixed
9TP_YG O Touch Panel Touch panel control
10 TP_XP O Touch Panel Touch panel control
11 TP_XG O Touch Panel Touch panel control
12~15 LCD_HPOSI1~LCD_HPOSI4 OLCD Setting display start position
16~18 LCD_MODE1~LCD_MODE3 OLCD Setting aspects
19 LCD_MIRROR O LCD Screen display right-left reversal H : Reverse, L : Normal
20 ILL_R O LED (ILLUMI) Illumination (red) control H : Light on
21 ILL_G O LED (ILLUMI) Illumination (green) control H : Light on
Ref.No. Application/Function Operation/Condition/Compatibility
IC304 Schmidt inverter CLAMP/C. SYNC waveform shaping.
IC601 Remote controller sensor Remote controller sensor.
Q1 Dimmer switch Turned ON/OFF by PWM control signal and dimmer is put on the backlight.
Q2,3 Inverter driver Inverter circuit driver.
Q5 5V AVR 5V power supply for inverter control IC.
Q101,102 SW DC/DC converter control switch.
Q201~203 VCOM driver VCOM signal buffer.
Q301 VCO PLL oscillator.
Q302 Touch panel X1 switch Turned ON when a touch to the panel is detected, or when input on X-axis and impresses voltage.
Q303 Touch panelY1 switch Turned ON when there is input onY-axis and impresses voltage.
Q304 Touch panel X0 switch Turned ON when there is input on X-axis and impresses voltage.
Q305 Touch panelY0 switch Turned ON when there is input onY-axis and impresses voltage.
Q306 Touch panelY0/Y1 switch Turned ON when there is input onY-axis and turned OFF when there is input on X-axis.
Q601,602 Switch SI blinking switch.
Q604,605 Switch Hard resetting switch.
Q701 Switch DISC slot illumination switch.
COMPONENTS DESCRIPTION
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

11
DDX7015/7025/7035
DDX7045/7065
MICROCOMPUTER’STERMINAL DESCRIPTION
Pin No. Pin Name I/O Module Function Processing Operation Description
22 PORTVDD0 - µCOM
23 ILL_B O LED (ILLUMI) Sub-panel backlight (blue) control H : Light on
24 NTSC_PAL O VIDEO NTSC/PAL switching H :PAL, L :NTSC
25
PM_LED_SW/PM_LED_SW NC
PM_LED_SW/SI O LED (SI) LED control for SI H : Light on, L : Light off
26 LCD_PON O Power supply DC/DC (X35) power supply ON/OFF control H : ON
27~29 NC O L-fixed
30 V_MUTE O VIDEO Video mute H : Mute ON
31 RGB_SW O VIDEO Switching visual sources H : DVD, L : Except
32 S_MUTE O VIDEO C.SYNC mute H : Except, L : Full OSD screen
33 SYS_SREQ I to X25 Request from Box control microcomputer
34 SYS_MREQ O to X25 Request to Box control microcomputer
35 SYS_ON O to X25 ON/OFF control on Box control microcomputer H : ON, L : OFF
36 CLKOUT
37 GND0 - µCOM
38 CPUREG - µCOM
39 VDD0 - µCOM
40 RESET Reset terminal L : Reset
41 FROM_VPP - µCOM
42 MINI_CS NC
FLASH_SI I V850 Used when writing to flash memory
MINI_DATA/MINI_DATA NC
43 MINI_DATA/LEDSW_SUB NC
MINI_DATA/FLASH_SO O V850 Used when writing to flash memory
44 MINI_CLK/MINI_CLK NC
MINI_CLK/FLASH_CLK I V850 Used when writing to flash memory
45 KEY_OPEN I KEY OPEN/CLOSE key L : Key depressed
46 BE_SDATA I FR30 Data from B/E microcomputer
47 BE_MDATA O FR30 Data to B/E microcomputer
48 BE_CLK O FR30 Clock to B/E microcomputer
49 BE_RST O FR30 Reset to B/E microcomputer L : Reset
50 BE_MREQ O FR30 Request to B/E microcomputer
51 BE_SREQ I FR30 Request from B/E microcomputer
52 PON O Power supply (X14) Power supply ON/OFF control H : ON
53 PM1_MCNT O 1DIN Mecha 7.5V power supply voltage control H : 5V, L : 7.5V
54 POWER_DET I Power supply (X14) Power supply abnormality detection L :Abnormality
55 PAK_DET I DC Cable (X14) Parking detection H : Parking detection
(When car stopped)
56 M_MUTE O Audio mute control L : Mute ON
57 DVD_DISC_DET I DVS-3000 Disc insertion detection L : Disc insertion
58 NC O L-fixed
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

12
DDX7015/7025/7035
DDX7045/7065
MICROCOMPUTER’STERMINAL DESCRIPTION
Pin No. Pin Name I/O Module Function Processing Operation Description
59 D_MUTE NC
60 PORTVDD1 - µCOM
61 LCD_BRIGHT O LCD Backlight adjustment
62~65 NC O L-fixed
66 JIG_EJ I EXTRA 2DIN FC detection terminal H : At FC, L : Except
67 NC O L-fixed
68 SUBLED_OFF O to PANEL Sub panel LED ON/OFF Depends on tilt angle
(H : At eject, L : except)
69 ACC_DET I DC Cable (X14) ACC detection L :ACC ON
70 XT2 - µCOM
71 XT1
72 GND2 - µCOM
73 X1 19.8MHz
74 X2 - µCOM
75~78 NC O L-fixed
79,80 FSEL1, FSEL2 O Power supply DC/DC oscillation frequency switching
81 BU_DET I DC Cable (X14) Backup power down detection H : Momentary power down
82 KEY_SRC I KEY Source selection key L : Key depressed
83 KEY_DVDEJ I KEY DVD eject key L : Key depressed
SDA/CHROMA_SDA I/O CHROMA Chroma IC data AN2546 control
CODE_SDA I/O EEPROM (CODE) EEPROM (Code) data S-24CS02 control
SDA/BE_SDA I/O EEPROM (DVD) EEPROM (Region) data S-24CS02 control
84 SDA/LCD_SDA I/O EEPROM (LCD) EEPROM (Display start position) data S-24CS02 control
SDA/COR_SDA I/O EEPROM (ROM collection) EEPROM (ROM collection) data S-24CS02 control
SDA/TP_SDA I/O EEPROM (TP) EEPROM (Adjustment value) data S-24CS02 control
SDA/CADJ_SDA I/O E2PROM chroma IC adjustment value data S-24CS02 control
85 NC O L-fixed
SCL/CHROMA_SCL I/O CHROMA Chroma IC clock
CODE_SCL I/O EEPROM (CODE) EEPROM (Code) clock S-24CS02 control
SCL/BE_SCL I/O EEPROM (DVD) EEPROM (Region) clock S-24CS02 control
86 SCL/LCD_SCL I/O EEPROM (LCD) EEPROM (Display start position) clock S-24CS02 control
SCL/COR_SCL I/O EEPROM (ROM collection) EEPROM (ROM collection) clock S-24CS02 control
SCL/TP_SCL I/O EEPROM (TP) EEPROM (Adjustment value) clock S-24CS02 control
SCL/CADJ_SCL I/O E2PROM chroma IC adjustment value data AN2546 control
87~91 NC O L-fixed
92 PORTGND1 - µCOM
93 MINI_CLK_IN NC
94 MINI_DATA_IN NC
95 NC O L-fixed
96 PAN_DET NC
97 OSD_CLK O LC74735W Clock to OSDC-IC
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

13
DDX7015/7025/7035
DDX7045/7065
MICROCOMPUTER’STERMINAL DESCRIPTION
Pin No. Pin Name I/O Module Function Processing Operation Description
98 OSD_CS O LC74735W Chip select to OSDC-IC
99 OSD_DATA O LC74735W Data to OSDC-IC
100 NC O L-fixed
101 DSI NC
102 PORTVDD2 - µCOM
103 MINI_PON NC
104 PM1_SET_STATUS0 NC
105 PM1_SET_STATUS1 NC
106 PM1_SET_STATUS2 NC
107 SYS_SDATA I to X25 Data from Box control microcomputer
108 SYS_MDATA O to X25 Data to Box control microcomputer
109 SYS_MCLK O to X25 Clock to Box control microcomputer
110 NC O L-fixed
111 WRT_E2P I EXTRA Write detection at ROM collection H : E2PROM writing
from outside, L :Except
112~115 TYPE0~TYPE3 I Type Destination setting
116~119 NC O L-fixed
120 OSD_RST O LC74735W Reset to OSDC-IC L : Reset
121 OSD_A18 I/O LC74735W External ROM address bus A18 3.3V
122 OSD_A19 I/O LC74735W External ROM address bus A19 3.3V
123 NC O L-fixed
124 PM1_TMOTOR_M NC
PM2_TILT_UP O 2DIN Mecha Panel mechanism motor control
125 VD I VIDEO Old-New NAVI determination VSYNC
126 PM1_TMOTOR_P NC
PM2_TILT_DOWN O 2DIN Mecha Panel mechanism motor control
127 PM1_SMOTOR_M NC
128 VDD1 - µCOM
129 PM1_SMOTOR_P NC
130 PM1_SWC NC
131 GND1 - µCOM
132 PM1_SWB NC
133 PM1_SWA NC
134 NC O L-fixed
135 KEY2 NC
136 VOL- NC
137 VOL+ NC
138 PM_LPS/PM1_LPS1 I 1DIN Mecha TV mechanism tilt sensor voltage detection
PM_LPS/PM2_TILT_SENCE I2DIN Mecha Panel mechanism tilt sensor voltage detection
139 PM1_PHOTO1 I 1DIN Mecha TV mechanism slide photo detection
140 TP_YDATA I Touch Panel Touch panel input (Y-direction)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

14
DDX7015/7025/7035
DDX7045/7065
●TUNER MICROCOMPUTER : 703069YGJ-104 (X34 : IC103)
Pin No. Pin Name Module I/O Application Processing Operation Active Truth
Description (H/L) Value
1NCI Pull down
2RDS_NOISE IC2-5-2 I FM noise detection
3DC_ERR IC2-5-2 I DC offset detection L when detected
4LINE_MUTE DC Cable (X25) ILINE MUTE detection TEL mute : 1V or lower,
NAVI mute : 2.5V or higher
5PORTGND0 µCOM -
6AUDIO_SW1_B Visual O LX/TV/AVIN audio switching r
7MUTE_PRE Mute O PREOUT mute L : Mute ON L
8AUDIO_SW2_A Visual O LX/TV/AVIN audio switching r
9AUDIO_SW2_B Visual O LX/TV/AVIN audio switching r
10 AUD_SCL IC2-5-2 I/O IC2-5-2 clock Based on IIC bus regulation
11 AUD_SDA IC2-5-2 I/O IC2-5-2 data Based on IIC bus regulation
12 S_MUTE IC2-5-2 O S-MUTE control H : Mute ON, L : Mute OFF H
13 AUDIO_SW1_A Visual O LX/TV/AVIN audio switching r
14 RDS_AFS_L IC2-5-2 I/O When detecting noise, constant is switched q
15 RDS_AFS_M IC2-5-2 I/O When detecting noise, constant is switched q
16 MUTE_LEFT Mute O Lch independent muting for handsfree L : Mute ON L
17 MUTE_RIGHT Mute O Rch independent muting for handsfree L : Mute ON L
Destination Setting
Model Destination TYPE3 TYPE2 TYPE1 TYPE0
KVT-715DVD K 0 0 0 1
KVT-725DVD E 0 0 1 0
KVT-735DVD M 0 0 1 1
KVT-765/745DVD C,X 0 1 0 0
KVT-815DVD K2 eXcelon 0 1 1 0
KVT-745DVD R 0 1 1 1
DDX7015 K 1 0 0 1
DDX7025 E 1 0 1 0
DDX7035 M 1 0 1 1
DDX7065/7045 C,X 1 1 0 0
DDX7045 R 1 1 1 1
Pin No. Pin Name I/O Module Function Processing Operation Description
141 TP_XDATA I Touch Panel Touch panel input (X-direction)
142 KEY1 NC
143 ADCVDD - µCOM
144 ADCGND - µCOM
MICROCOMPUTER’STERMINAL DESCRIPTION
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

15
DDX7015/7025/7035
DDX7045/7065
Pin No. Pin Name Module I/O Application Processing Operation Active Truth
Description (H/L) Value
18 VISUAL_SW1_1 Visual O TV/AVIN/NAVI visual switching t
19 VISUAL_SW1_2 Visual O TV/AVIN/NAVI visual switching t
20 VISUAL_SW2_1 Visual O DVD/TV/AVIN visual switching t
21 VISUAL_SW2_2 Visual O DVD/TV/AVIN visual switching t
22 PORTVDD0 µCOM -
23 MUTE_AVOUT Mute O AVOUT mute L : Mute ON L
24 NC O
25 MUTE_SUBOUT Mute O IC2 SUBOUT mute (land compatible) L : Mute ON L
26 NC O
27 SYS_MREQ to X14 I Request from system control microcomputer
28 SYS_SREQ to X14 O Request to system control microcomputer
29~32 NC O
33 P_CON DC Cable (X25) O External amplifier power supply control
H : Power ON except all OFF,
L : All OFF or Power OFF
34 EXT_CONT DC Cable (X25) O External amplifier control
35 ANT_CONT DC Cable (X25) OPower antenna control H : Antenna UP,
L : Antenna DOWN
36 CLKOUT O
37 GND0 µCOM -
38 CPUREG µCOM -
39 VDD0 µCOM -
40 RESET I
41 MODE/VPP µCOM - Flash : Pull down,
Mask : GND direct connection
42
TV_SDATA/TV_SDATA TV (External) I Data from theTV unit
TV_SDATA/FLASH_SI V850 I Used when writing to flash memory
43
TV_MDATA/TV_MDATA TV (External) O Data to TV unit
TV_MDATA/FLASH_SO V850 O Used when writing to flash memory
44 TV_CLK/TV_CLK TV (External) O Clock toTV unit
TV_CLK/FLASH_CLK V850 I Used when writing to flash memory
45 SYS_ON to X14 I ON/OFF control from system control H : Box unit ON,
microcomputer L : Box unit OFF
46 SYS_MDATA to X14 I Data from system control microcomputer
47 SYS_SDATA to X14 O Data to system control microcomputer
48 SYS_MCLK to X14 I Clock from system control microcomputer
49 PWIC_STBY POWER-IC O POWER-IC standby control H : Power ON, L : Power OFF
50 NC O
51 PWIC_SVR POWER-IC O SVR discharge circuit control H : Forced discharge
52 PWIC_MUTE POWER-IC O POWER-IC Mute control L : Mute ON (All OFF or
momentary power down)
MICROCOMPUTER’STERMINAL DESCRIPTION
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

16
DDX7015/7025/7035
DDX7045/7065
Pin No. Pin Name Module I/O Application Processing Operation Active Truth
Description (H/L) Value
53 NC O
54 ILLUMI_DET DC Cable (X25) IIllumination detection L : Illumination ON L
55,56 NC O O
57 BU_DET DC Cable (X25) IBackup power down detection H : Momentary power
down (8.8V or lower)
58,59 NC O
60 PORTVDD1 µCOM -
61 PWIC_BEEP POWER-IC O Beep output
62 P_ON power supply O SW5V power supply control H : ON
SCL/COR_SCL EEPROM I/O EEPROM (ROM collection) clock Based on IIC bus regulation
63 (ROM collection)
SCL/IC5_SCL IC5 I/O IC5 clock Based on IIC bus regulation
SDA/COR_SDA EEPROM I/O EEPROM (ROM collection) data Based on IIC bus regulation
64 (ROM collection)
SDA/IC5_SDA IC5 I/O IC5 data Based on IIC bus regulation
65 ES_DSP_SW Audio O E’s/DSP switching H : DSP, L : E’s
66 BUS_MUTE Mute O BUS_MUTE H : Mute H
67 MZ_ILL_ON MZ-Bus O MZ-Bus ILLUMI control H : ILLUMI ON H
68 MZ_SYSON MZ-Bus O MZ-Bus SYSON control L : Bus ON L
69 MZ_SYSOFF MZ-Bus O MZ-Bus SYSOFF control L : Bus OFF L
70 XT2 µCOM -
71 XT1
72 GND2 µCOM -
73 X1 18.874MHz
74 X2 µCOM -
75~80 NC O
81 SYS_MUTE to X14 I Mute request from main unit L : Mute request
82,83 NC O
84 TUN_SDA S03 F/E I/O F/E I2C data input/output terminal
85 NC O
86 TUN_SCL S03 F/E I/O F/E I2C clock output terminal (MAX 400kHz)
87,88 NC O
89 MZ_BUS_STBY IE-Bus O BUS-IC standby control L : Standby
90 MZ_IERX IE-Bus I Data from IE-Bus
91 MZ_IETX IE-Bus O Data to IE-Bus
92 PORTGND1 µCOM -
93 NC O
94 NC O
95 RGB_SW Visual O TV/NAVI selection (monitor) H : NAVI, L : Other
96 TV_SREQ TV (External) I Request from TV unit
MICROCOMPUTER’STERMINAL DESCRIPTION
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

17
DDX7015/7025/7035
DDX7045/7065
Pin No. Pin Name Module I/O Application Processing Operation Active Truth
Description (H/L) Value
97~99 NC O
100 TV_MREQ TV (External) O Request to TV unit
101 TV_CON TV (External) O Startup request to TV unit H :TV unit ON, L :TV unit OFF
102 PORTVDD2 µCOM -
103,104 NC O
105 MUTE_ACOUT Mute O IC2 SUBOUT mute (land compatible) L : Mute ON L
106 NC O
107 LX_DATA_S LX_M I Data from slave unit
108 LX_DATA_M LX_M O Data to slave unit
109 LX_CLK LX_M I/O LX BUS clock
110 LX_REQ_S LX_M I Communication request from slave unit
111 NAVI_RX NAVI I Data from NAVI
112 NAVI_TX NAVI O Data to NAVI
113 NC O
114 REMO Remote controller IRemote controller input
115 LX_REQ_M LX_M O Communication request from slave unit
116 LX_RST LX_M O Hard reset to slave unit H : Reset, L :Normal H
117 LX_MUTE LX_M I Mute request from slave unit H : Mute ON, L : Mute OFF H
118 LX_CON LX_M O Start up request to slave unit H : Slave unit ON, H
L : Slave unit OFF
119 NC O
120 VSYNC_DET Visual I VSYNC input
121,122 NC O
123 RDS_DATA RDS Decoder I RDS decoder data input
124 RDS_QUAL RDS Decoder I RDS decoder QUAL input
125 RDS_CLK RDS Decoder I RDS decoder CLK input
126 NC O
127 PON_AM Power supply O AM power supply control H : ON (During AM operation)
128 VDD1 µCOM -
129 TUN_TYPE0 IC2-5-2 I Destination setting w
130 TUN_TYPE1 IC2-5-2 I Destination setting w
131 GND1 µCOM -
132 WRT_E2P EXTRA I Write detection at ROM collection H : E2PROM write from
outside, L : Except
133 VSYNC_SW Visual O AVIN NTSC PAL determination /
AVIN2 AUTO detection switching
134 MUTE_SW Mute O SW independent mute L : Mute ON L
135 TUN_SMETER S03 F/E I S-meter input
136 TUN_IFC_OUT S03 F/E I F/E IFC OUT input terminal H :With station, L : No station H
137~140 TYPE0~TYPE3 Type I Destination setting e
MICROCOMPUTER’STERMINAL DESCRIPTION
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

18
DDX7015/7025/7035
DDX7045/7065
qIC2_AFS_L, IC2_AFS_M
Typ value FM input mute Qualty constant Stereo PLL
High 2.4~5V Unmuted Long Not-hold
Mid 1~2.4V Unmuted Short Not-hold/Hold
Low 1V or lower Muted Short Hold
Stereo PLL when set to Mid can be set to either Not-hold/Hold by the
data.
During hold, condition of ST/MONO will be maintained to the state
when hold is started.
High Normal reception
Mid Although sound is output, Qualty (RDS-Noise) is being
checked with short time constant.
Low With mute on (no sound), the condition of RDS AF
stations are being checked.
wTUN_TYPE0,TUN_TYPE1
TYPE0 TYPE1
AFTER L L
OEM1 L H
OEM2 H L
OEM3 H H
eTYPE3,TYPE2,TYPE1,TYPE0
Model Destination TYPE3 TYPE2 TYPE1 TYPE0
KVT-715DVD K 0001
KVT-725DVD E 0010
KVT-735DVD M 0011
KVT-765DVD C 0100
KVT-745DVD X 0101
KVT-815DVD K2 0110
KVT-745DVD R 0111
DDX7015 K 1001
DDX7025 E 1010
DDX7035 M 1011
DDX7065 C 1100
DDX7045 X 1101
DDX7045 R 1111
rAudio selector (TC4052BFT)
AUDIO_SW1_A AUDIO_SW1_B Output
LLIN3 Not used
HLIN2 AVIN
LHIN1 TV
HHIN0 LX
AUDIO_SW2_A AUDIO_SW2_B Output
LLIN3 Not used
HLIN2 AVIN
LHIN1 TV
HHIN0 Not used.
Note : Each output is reversed by a transistor
tVideo selector
BA7652AF
VISUAL_SW1_1 VISUAL_SW1_2 Output
LLIN1 TV
HLIN2 AVIN
LHIN3 NAVI
HHMUTE*
* : MUTE_ON when full OSD is switched, OFF when normal visual
source is switched from OSD.
BA7612F
VISUAL_SW2_1 VISUAL_SW2_2 Output
LLIN1 DVD
LHIN2 TV
HLIN3 AVIN
HHMUTE
Pin No. Pin Name Module I/O Application Processing Operation Active Truth
Description (H/L) Value
141,142 NC I Pull down
143 ADCVDD µCOM -
144 ADCGND µCOM -
MICROCOMPUTER’STERMINAL DESCRIPTION
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

19
DDX7015/7025/7035
DDX7045/7065
●How to enter the test mode
While pressing and holding the Eject key and SRC key, reset
the unit.
●How to exit from the test mode
While holding the Reset key, reset the unit.
Note : Turning ACC off, power off, momentary powers down
are does not exit for the test mode.
●Test mode operation
•Source selector :VIDEO
Each press of the V SEL key in TEST mode should switch
from VIDEO→NAVIGATION→DVD→VIDEO
•Volume : STEP 30
•Switching for Video detector or Test mode main menu (for
FNC key on)
• Microprocessor information
• Information for service menu / Serial code writing *
•Chroma adjustment *
•Writing value for LCD panels touch position adjustment *
•Panel mechanism position adjustment *
• Display position adjustment *
•Security code writing (E,M,X,C type only) *
TEST MODE
You must adjustment for * mark function when you repaired
for IC200 (X14-939 :Video control unit).
●Simple way to clear the security code
(without E,M,X,C type)
1)How to enter the security code entry
While pressing the Reset key when unit is security on mode.
2)Enter, “KCAR” with the remote controller as described be-
low.
•Press the remote controller 5 key twice. (Enters a “K”)
•Press the remote controller 2 key three times. (Enters a
“C”)
•Press the remote controller 2 key once. (Enters an “A”)
• Press the remote controller 7 key twice. (Enters an “R”)
Code request mode appears if a mistake was made in en-
tering the numbers.
3)Security function is canceled and unit sets to Menu display
mode.
●Specification of test mode on-screen
Default display is Test mode Main when selected graphic dis-
play mode that in the test mode.
Test Mode Main screen
Information Touch
adjustment
Touch
adjustment
(1~3)
Writing data
for EEPROM
Chroma
adjustment
Chroma
adjustment
(1~13)
Writing data
for EEPROM
Writing NG
Writing NG
Writing NG Writing OK
Writing OK
Adjustment
OK Adjustment
NG
Writing OK
Graphic
position
adjustment
Graphic 1
position
adjustment
Mechanism
position
adjustment
Graphic 2
position
adjustment
DVD
position
adjustment
TV
position
adjustment
VIDEO
position
adjustment
NAVI
position
adjustment
Service
information
Writing for
Serial
number
Operate
similarly to
normal mode
Operate
similarly to
normal mode
Operate
similarly to
normal mode
Source
Mechanism
adjustment Set up Audio
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

20
DDX7015/7025/7035
DDX7045/7065
●Test mode Main
Information Hposi
Service Source
Chroma Set Up
Touch
MECHA ADJ
Audio
• Key specification
Information : Change to Information screen
Service : Change to service information screen
Chroma : Change to Chroma adjustment screen
Touch : Change to Panel Touch adjustment screen
MECHA ADJ : Change to Mechanims adjustment screen
Hposi : Change to horizontal position adjustment screen
Source : Change to source screen
Setup : Change to setup screen
Audio :Change to audio screen
●Information screen
Display for microprocessor, serial number and DVD region code
information.
Return
Serial : x x x x x x x x
System u-com
Ver : 4. XXX ROM :R – – – Type :
*
OSD ROM Ver : 1. 03
Region :
*
B/E Ver : 2. 09 F/E Ver : 4. 02
Box u-com
Ver : 4. XXX ROM :R – – – Type :
*
Span : –
• Key specification
Return : Change toTest Mode Main screen
Return
Serial
Clear
Start
Init
Init
Init
Init
Init
Power On
***
hour
DVD Play
***
hour
DVD Eject
***
time
Mon. Open
***
time
Mon. Close
***
time
Chroma
DCOffset
Ready
None
●Service information screen
Display of service information data and initialization for the
unit.
Initialized Chroma adjustment data.
Display of DC offset voltage detect information.(for audio power
amp)
• Key specification
Init : Select for initialization item
START : Initialization data when while pressing and holding
about 2 second any more.
SERIAL : Change to Serial number input screen
CLEAR : EEPROM data cleared.
RTN : Change toTest Mode Main screen
• Adjustments procedure
1)Select for Init key when you wont initialized data.
2)While pressing and holding START key about 1 second any
more.
3)DC offset information
DC offset detect information for the display
None : Not detected (normal), Detect : Detected
4)Initialized DC offset information
While pressing and holding the Eject key and Volume down
key, reset the unit.
TEST MODE
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
