CD RECEIVER
KDC-719/X559/Z737,Z638
SERVICE MANUAL
•This service manual does not include information on the CD mechanism assembly (exploded view, parts list,
schematic diagram or mechanism operation description).
For such information, please refer to the CD mechanism assembly service manual (X92-4450-0X: B51-7889-00).
Front glass
(B10-4209-01)
Panel assy
(A64-2646-11)
KDC-719
Front glass
(B10-4213-01)
Panel assy
(A64-2650-11)
KDC-X559
Front glass
(B10-4211-01)
Panel assy
(A64-2648-11)
KDC-Z737
Front glass
(B10-4210-01)
Panel assy
(A64-2647-11)
Z638
Screw set
(N99-1723-05)
: except Z638
Screw set
(N99-1656-05)
Lever
(D10-4674-04)x2
Mounting
hardware assy
(J21-9823-03)
Plastic
cabinet assy
(A02-2712-13)
Remote controller assy
(A70-2026-05)
: KDC-Z737,Z638
Remote controller assy
(A70-2025-05)
: KDC-719/X559
Escutcheon
(B07-3050-02)
: KDC-719/Z737,Z638
(B07-3057-02)
: KDC-X559
DC cord
(E30-6062-05)
: KDC-X559/Z737
DC cord
(E30-6106-05)
: KDC-719
DC cord
(E30-6063-05)
: Z638
Antenna adaptor
(T90-0523/0534/0552-05): Z638

KDC-719/X559 /Z737,Z638
2
BLOCK DIAGRAM
CH
F/E FM+B
PLL+B
AM+B
BUFF E-VOL
DECODER
RDS
ISO
AMP
OEM
EJECT LED
DSI
DISP
4.5V PRE
DC/DC
2WAY MUTE
ACC DET
DIMMER
TEL-MUTE
ACC
DIMMER
POWER IC
PRE AMP PRE OUT
SP OUT
MUTE
DRIVER
NOISE
BUFFER
ANT-CON ANT-CON
P-CON P-CON
IF+B
CD
MECHA
AUX SW
OP AMP
E'S
SPEANA
AGC OP AMP
MUTE 4.5V
BU DET
BACK UP
EX AMP CONT
EX AMP CONT
NAVI MUTE
RESET
DET
PANEL
KEY ILL
MATRIX
KEY
FL
SW
MI-COM
PANEL
SPEANA
BPF
REMO
RESET
REG
SW
BUFFER
3.3V
SW
SERVO
AVR
BOX
DC/DC
A8V
SW14V
DC/DC
REG
BU5V
SW5V
PANEL5V
Q43,44
Q45,46
Q52
IC14
IC1
IC2
Q36 IC8,Q34
IC5
Q37-42 IC10-12
IC4
Q32,
IC7 33,35
Q15
Q31
Q30
Q14
Q111,112
Q26-29
Q3
Q9
IC3,Q4-6
IC6,Q16-23
Q1
A1 Q10-13
Q7,8
Q201,473-476
IC16305,306
IC1
IC5
IC2
ED1Q1,2
Q7-10
IC3
IC4
IC20
IC21
EEP ROM
IC25
Q101, P-CON
ANT-CON
Z638 ONLY
EXCEPT KDC-X559/Z737
KDC-X559/Z737 ONLY
Z638 ONLY
Q3
EXCEPT KDC-719
Z638
ONLY
Z638 ONLY
Z638
EXCEPT
EXCEPT KDC-X559 EXCEPT KDC-X559
KDC-X559 ONLY KDC-X559 ONLY
MI-COM
SDA
SCL
S-METER SW5V
RDCK
FM
AM
SW5V
AUDIO OUT
BACK UP
DATA H
DATA C
MUTE
CH
SDA
RDDA BU5V
BU5V
DSI
EJECT G
EJECT R/G
Z638 (E)
CD/MD
FM
AM 1512mV
866mV
3795mV
BU5V
PRE MUTE
PMUTE
PSTBY
MUTE
BEEP
AUX SW
CD-AUX
E-VOL OUT LEVEL
A8V
IFC OUT
SW5V
A8V
SCL
QUAL
AFS
SERVO
BU5V
Rch
Lch
A8V
A8V
A8V
REQ H
RST
REQ C
CH CON
CLK
A8V
A8V +B
-B
BACK UP
BU5VBU5V
MC REQ
SC CON
FL+B
RED
SI2
SI1
CLK
GREEN
KS1-KS4
KR1-KR5
F01-F06
WAVE
P5V
MC CLK
SC REQ
P RST
MC DATA
GCP
LAT
P5V
REMO
FL+B
FAC
BK
P5V
A8V
+B
-B
SERVO
FAC
FL+B MI-COM
SW5V MI-COM
BU5V
P5V MI-COM
REMO
O-DATA
O-CE
O-CLK
1.8V PRE
613mV274mV 2005mV
3795mV
1.8V PRE
896mV
1695mV
KDC-719 (K)
4.5V PRE
AUX
CHANGER
4.5V PRE 1.8V PRE
3795mV
1512mV
866mV
896mV
274mV
1695mV
2005mV
613mV
3795mV
1.8V PRE
QUAL
E'S OUT LEVEL PRE OUT LEVEL
M RST
SW1
SW2
SW4
SW3
LO/EJ
M STOP
M SW
MUTE R
MUTE L
KDC-X559 (K) KDC-Z737 (M) KDC-X559 (K) KDC-Z737 (M) Z638 (E)
CHANGER
FM
AM
CD/MD
AUX
KDC-719 (K) KDC-X559 (K) KDC-Z737 (M) Z638 (E)
AM
FM
CHANGER
AUX
CD/MD
2361mV
722mV
4.5V PRE
4469mV
848mV
1.8V PRE
1481mV
3717mV
600mV
1964mV
3717mV
1.8V PRE
KDC-719 (K)
251mV (E,M)TYPE
470mV (K)TYPE
215mV
1200mV
1200mV

KDC-719/X559
/Z737,Z638
3
COMPONENTS DESCRIPTION
Ref.No. Component Name Application/Function Operation/Condition/Compatibility
IC1 TAR5S33 FL AVR +3.3V Output
IC2 TC74HC4050AFT Buffer For FL control lines, 5V→3.3V logic level shifting
IC3 RS-171 Remote sensor IC
IC4 BA3830F BPF IC BPF for the spectrum analyser indicator
IC5 UPD703032GFA04 Panel MI-COM.
Q1 DTA144EUA or UN5113 FL+B SW FL & Illumination +B ON/OFF control.When Q2's base goes Hi, Q1 is turned on,
Q2 DTC114YUA or UN5214 and FL+B (45V) line is supplied to FL indicator and the key illumination circuit.
Q3 DTA114EUA or UN5111 REMO SW When a base goes Lo, Q3 is turned on, and PAN5V line is supplied to
IC3 and IC4.
Q4 DTC114EUA or UN5211 FL blanking SW When a base goes Hi, Q4 is turned on, and FL indicator is lit.
Q6 DTC114YK or UN2214 SRC key illumination SW When a base goes Hi, Q6 is turned on, and SRC illumination is lit.
Q7 2SC4081 V-I converter Current driver for green LEDs
Q8 2SC4081 V-I converter Current driver for red LEDs
Q9 DTA114EUA or UN5111 Key illumination Red SW When a base goes Lo, Q9 is turned on, and key illumination Red is lit.
Q10 DTA114EUA or UN5111 Key illumination Green SW When a base goes Lo, Q10 is turned on, and key illumination Green is lit.
ELECTRIC UNIT (X25-924x-xx)
Ref.No. Component Name Application/Function Operation/Condition/Compatibility
IC1 UPD703033GFA18 System MI-COM.
IC2 TDA7407 E-VOL.& N.C. MPX
IC3 M5237ML AVR IC IC is combined with Q4, and it works as the error detection, the Q4's driver.
IC4 TDA7560 Power IC
IC5 TDA7401 High pass filter & Non-Fader HPF (Front/Rear output), LPF, Non-Fader switching and volume function
volume
IC6 ICL7660SIBA DC/DC converter -9V AVR for pre-output amplifier
IC7 TC74HC02AF Mute logic 2-input NOR x 4
IC8 NJM4565M-TE2 Op. amp. Amplifier for the spectrum analyser and generation of Vref.(1/2Vcc) voltage
IC10 NJM4565M-TE2 Op. amp. Amplifier for the front pre-outputs
IC11 NJM4565M-TE2 Op. amp. Amplifier for the non-fader pre-outputs
IC12 NJM4565M-TE2 Op. amp. Amplifier for the rear pre-outputs
IC14 TDA7479D RDS decoder
IC16 S-80837ANNP Reset IC When BU 5V voltage is less than 3.7V, IC outputs Lo.
IC20 BA3121F Isolation amplifier AUX inputs isolation amplifier
IC21 BA3129F Switched op.amp. Input switching with AUX inputs and CD inputs
IC25 BR24C02F-W EEPROM
Q1 2SD2375 CD servo AVR AVR for CD mechanism servo operation, +7.5V output.
Q3 2SA1037K SW 5V While a base goes Lo, SW 5V is supplied to the microprocessor
peripheral circuits.
Q4 2SA2057 A.+8V AVR Q4 is combined with IC3, and it works as the power supply of +8.0V output.
Q5 DTC144EUA or UN5213 A.+8V AVR SW When Q5's base goes Hi, Q6 is turned on, and A.+8V AVR is working.
Q6 DTA124EUA or UN5112
Q7 DTA124EUA or UN5112 SW14V When Q8's base goes Hi, Q7 is turned on, and A.+8V AVR, CD servo
Q8 DTC124EUA or UN5212 AVR and A+10V AVR are working.
Q9 2SB1427 PAN5V SW For PAN5V on/off switching.When a base goes Lo with panel attached
to the set, Q9 is turned on, and PAN5V is supplied to the panel.
Q10 2SA2057 FL/Illumination AVR When Q11's base goes Hi, AVR outputs +9V.
Q11 2SC4081
SWITCH UNIT (X16-168x-xx)

KDC-719/X559
/Z737,Z638
4
Ref.No. Component Name Application/Function Operation/Condition/Compatibility
Q12 DTC124EUA or UN5212 FL/Illumination AVR SW
When Q12' base goes Hi, Q13 is turned on, and FL/Illumination AVR is working.
Q13 DTA124EUA or UN5112
Q14 DTA123JK or KRA105S EXT.AMP CON. SW When a base goes Lo, Q14 is turned on, and control pulse signal is outputted.
Q15 DTC144EUA or UN5213 Dimmer detection SW When vehicle small lamps turn on, Q15's base goes Hi, and it is turned on .
Q16 2SB1443 A.+10V AVR When Q17's base goes Hi, AVR outputs +10V.
Q17 2SC4081
Q18 2SA1576A Q18 and Q20 work as a differential amplifier, Q19 works as a driver, and
Q19 2SC4081 PRE-AMP -9V AVR -9.3V is supplied to OP AMP.
Q20 2SA1576A
Q21 2SC4081 Q21and Q22 work as a differential amplifier, Q23 works as a driver, and
Q22 2SC4081 PRE-AMP +9V AVR +9.7V is supplied to OP AMP.
Q23 2SA1576A
Q26 2SB1277(Q,R) P-CON SW When Q29's base goes Hi, Q26 is turned on, and P-CON signal is outputted.
Q29 DTC114YUA or UN5214 Works during POWER ON mode.
Q27 2SA1576A P-CON. protection SW Protect Q26 by turning ON when P-CON output is grounded.
Q28 DTA124EUA or UN5112 P-CON. protection inhibit SW Prevents Q27 tuning ON during start-up after power ON.
While BACKUP is applied, a base goes Hi, and Q30 is turned on.
Q30 2SC4081 BU detection SW When momentary power down has detected, a base goes Lo, and Q30
is turned off.
Q31 2SC4081 ACC detection SW While ACC is applied, a base goes Hi, and Q31 is turned on.
Q32 DTA124EUA or UN5112 Mute driver for R Ch. When BU detection SW or System RESET or MI-COM.'s MUTE is
Q33 DTA124EUA or UN5112 Mute driver for L Ch. working, a base goes Lo, and Q32 and Q33 are turned on.
Q34 2SC4081 AGC for spectrum analyser
Q35 DTC124EUA or UN5212 E.VOL. mute SW When BU detection SW or MI-COM.'s mute is working, a base goes Hi,
and Q35 is turned on.
Q36 DTC143TUA or UN5216 Noise buffer
Q37 DTC143TUA or UN5216 Audio mute SW (Front L) When Q37's base goes Hi, Pre-output is muting.
Q38 DTC143TUA or UN5216 Audio mute SW (Front R) When Q38's base goes Hi, Pre-output is muting.
Q39 DTC143TUA or UN5216 Audio mute SW (Non Fader R) When Q39's base goes Hi, Pre-output is muting.
Q40 DTC143TUA or UN5216 Audio mute SW (Non Fader L) When Q40's base goes Hi, Pre-output is muting.
Q41 DTC143TUA or UN5216 Audio mute SW (Rear L) When Q41's base goes Hi, Pre-output is muting.
Q42 DTC143TUA or UN5216 Audio mute SW (Rear R) When Q42's base goes Hi, Pre-output is muting.
Q43 DTC124EUA or UN5212 FM+B SW When Q43's base goes Hi, Q44 is turned on, and A.+8V is supplied to
Q44 CPH3105 the F/E.Works during FM reception mode or RDS reception mode.
Q45 DTC124EUA or UN5212 AM+B SW When Q45's base goes Hi, Q46 is turned on, and A.+8V is supplied to
Q46 CPH3105 the F/E.Works during AM reception mode.
Q52 DTC143TUA or UN5216 Composite signal buffer
Q101 DTA114YUA or UN5114 DSI LED SW When a base goes Lo, Q101 is turned on, and DSI illumination LED is lit.
Q103 DTC124EUA or UN5212 AUX/CD selector SW When a base goes Hi, AUX inputs are selected.
When a base goes Lo, CD inputs are selected.
Q111 2SB1277(Q,R) P-ANT SW When Q112's base goes Hi, Q111 is turned on, and P-ANT signal is outputted.
Q112 DTC114YUA or UN5214 Works during FM/AM reception mode or RDS reception mode.
Q201 2SC4081 BU5V discharge SW When BU OFF is detected, Q201 is turned on during the base Hi condition.
Q305 DTA114YUA or UN5114 EJECT LED Red SW When a base goes Lo, Q305 is turned on, and EJECT illumination LED is lit.
Q306 DTA114YUA or UN5114 EJECT LED Green SW When a base goes Lo, Q306 is turned on, and EJECT illumination LED is lit.
Q473 2SC4081 BU 5V AVR While BACKUP is applied, AVR outputs +5V.
Q474 2SB1548(P) Q473 and Q474 are inverted Darlington connection.
Q475 2SC4081 Voltage converter
Q475 and Q476 work as voltage coverter for BU 5V AVR, and it output +9V.
Q476 2SB1548(P)
COMPONENTS DESCRIPTION

KDC-719/X559
/Z737,Z638
5
MICROCOMPUTER’STERMINAL DESCRIPTION
Pin No. Pin Name I/O Description Processing Operation
1 SC DATA I/O Data input/output with the system MI-COM.
2 MC CLK I Clock input from the system MI-COM.
3 NC O Not used (N.C.)
4 DATA 1 O Data output 1 to the FL driver IC
5 CLK O Clock output to the FL driver IC (Data shift by the rise edge of the pulse)
6 NC O Not used (N.C.)
7 DATA 2 O Data output 2 to the FL driver IC
8 CLK IN I Clock input from the FL driver IC (Data shift by the rise edge of the pulse)
9 EVDD - Positive power supply connection terminal Connected to P5V lines.
10 EVSS - Ground connection terminal Connected to GND lines.
11 RED LED O
Illumination red ON/OFF output in case of two colours
Lo: ON, Hi: OFF
/Illumination ON/OFF output in case of one colour
Illumination green ON/OFF output in case of two Lo: ON, Hi:OFF in case of two colours
12 GREEN LED O colours /Not used (N.C.) in case of one colour
/Not used in case of one colour
13 REMO I Data input from the remote control light sensor
14 LATCH O Latch output to the FL driver IC Lo: Latch, Hi:Through
15 GCP O Control pulse output to the FL brightness
16 REMO ON I/O Power supply ON/OFF output to the remote control Lo: ON, Hi-Z: OFF
light sensor IC and BPF IC
17-19 NC O Not used (N.C.)
20 BLK O Display ON/OFF control output Lo: Display OFF, Hi: Display ON
21 TEST I Test terminal Not used (Connected to GND lines)
22-33 NC O Not used (N.C.)
34 RESET I Reset terminal Lo: Reset, Hi: Reset release
35 XT1 - Sub clock resonator connection terminal Not used (Pull down to GND lines)
36 XT2 - Sub clock resonator connection terminal Not used (N.C.)
37 REGC - Capacitor connection terminal for regulator inside
microprocessor
38 X2 - Main clock resonator connection terminal
39 X1 - Main clock resonator connection terminal
40 VSS - Ground connection terminal Connected to GND lines.
41 VDD - Positive power supply connection terminal Connected to P5V lines.
42-47 NC O Not used (N.C.)
48 FL +3.3V O FL VDD ON/OFF output Lo: OFF, Hi: ON
49 FL+B I/O FL+B ON/OFF output Hi-Z: OFF, Hi: ON
50-55 NC O Not used (N.C.)
56 BLUE LED I/O Source key LED ON/OFF output Hi-Z: OFF, Hi: ON
57 NC O Not used (N.C.)
58 BVDD - Positive power supply connection terminal Connected to P5V lines.
59 BVSS - Ground connection terminal Connected to GND lines.
60-71 NC O Not used (N.C.)
IC5 (SWITCH UNIT: X16-168x-xx)

KDC-719/X559
/Z737,Z638
6
MICROCOMPUTER’S TERMINAL DESCRIPTION
Pin No. Pin Name I/O Description Processing Operation
72 SA RESET O Reset output to the BPF IC Hi: Reset
73 NC O Not used (N.C.)
74 AVDD - A/D converter positive power supply connection terminal Connected to P5V lines.
75 AVSS - A/D converter ground connection terminal Connected to GND lines.
76 AVREF - A/D converter reference voltage input terminal
77 F01 I BPF (63Hz) input
78 F02 I BPF (150Hz) input
79 F03 I BPF (330Hz) input
80 F04 I BPF (1kHz) input
81 F05 I BPF (3.3kHz) input
82 F06 I BPF (10kHz) input
83 WAVE IN I Audio input
84 KR5 I Key return 5 input
85 KR4 I Key return 4 input
86 KR3 I Key return 3 input
87 KR2 I Key return 2 input
88 KR1 I Key return 1 input
89 SC REQ O Communication request output to the system MI-COM. Lo: Standby, Hi: Request
90 NC O Not used (N.C.)
91 SC CON I Control input from the system MI-COM. Hi: Operation mode
92 NC O Not used (N.C.)
93 SOURCE I Source key input Lo: Key OFF, Hi: Key ON
94 VREF CON O A/D converter reference voltage control output Hi: Active, Connected to AVREF terminal
95 MC REQ I Communication request input from the system MI-COM. Hi: Request
96 KS4 I/O Key scan output 4
97 KS3 I/O Key scan output 3
98 KS2 I/O Key scan output 2
99 KS1 I/O Key scan output 1
100 MC DATA I Data input from the system MI-COM.
IC5 (ELECTRIC UNIY: X25-9240-xx)
Pin No. Pin Name I/O Description Processing Operation
1 MC DATA I/O Data input/output with the panel MI-COM.
2 MC CLK O Clock output to the panel MI-COM.
Lo: DSI ON, Hi-Z: DSI OFF
3 DSI GUIDE I/O DSI control output Lights on at the panel tilted during POWER ON mode.
Flashing at the panel detached during POWER ON mode.
Lo: ON, Hi-Z: OFF
4 EJECT KEY G O Eject key illumination green control output Lights on at the panel tilted during POWER ON
mode in case of the key illumination green.

7
KDC-719/X559
/Z737,Z638
Pin No. Pin Name I/O Description Processing Operation
5 EJECT KEY R/G O Eject key illumination red/green control output Lo: ON, H-Z: OFF
Lights on at the panel tilted during POWER ON mode.
6 MC REQ/FLIP DET I/O
Communication request output to the panel MI-COM. Hi: Request
/Flip detection input /Lo:Panel detected, Hi: Panel attached
7 IC2 SDA I/O Data input/output with IC2, IC5, and IC25
8 IC2 SCL I/O Clock input/output with IC2, IC5, and IC25
9 EVDD - Positive power supply connection terminal Connected to BU 5V lines.
10 EVSS - Ground connection terminal Connected to GND lines.
11 PAN RESET O Reset output to the panel MI-COM. Lo: Reset or Momentary power down detected
12 BEEP O BEEP output
13 REMO I Data input from the wired remote control
14 SVR O SVR output Not used (N.C.)
15 DIMMER I Small lights detection input Lo: During vehicle small lamps turn on
16 PLL DATA I/O Data input/output with F/E
17 PLL CLK I/O Clock input/output with F/E
18 P-STBY O POWER IC STBY output Lo: Power IC OFF, Hi: Power IC ON or ALL OFF
mode
19 P-CON I/O P-CON output Hi-Z: POWER OFF mode or ALL OFF mode,
Hi: POWER ON mode
20 ANT-CON O ANT-CON output Hi: During TUNER mode or last FM mode with
RDS/RBDS model
21 TEST - Test terminal Not used (Connected to GND lines)
22 P MUTE O POWER IC mute output Lo: Muting during POWER OFF mode, ALL OFF
mode and TEL MUTE ON
23 PAN5V I/O Panel 5V control output Lo: Panel attached normally, Hi-Z: Panel detached
or tilted
Bass boost OFF__Hi: 160msec, Lo: 40msec
24 EXT-AMP-CON O External amp. control output (in 200msec) Bass boost LOW__Hi: 130msec, Lo: 70msec
Bass boost HI__ Hi: 100msec, Lo:100msec
25 CD MECHA+B I/O CD4.7V ON/OFF output Not used (N.C.)
26 EMUTE O Not used (N.C.)
27 BU DET I Momentary power down detection input Lo: BU ON, Hi:When momentary power down
detected or BU OFF
28 ACC DET I ACC detection terminal Lo: ACC ON, Hi: ACC OFF
29 SW5V I/O SW5V control terminal Lo: SW5V ON, Hi-Z: SW5V OFF
30 MUTE I/O MUTE output Lo: Muting OFF, Hi-Z: Muting ON
31 O CE I/O External display CE terminal
32 O CLK I/O External display clock terminal
33 O DATA I/O External display data terminal
34 RESET I Reset input Lo: System reset , Hi: Normal operation
35 XT1 I Sub clock resonator connection terminal Clock count during POWER OFF mode
36 XT2 - Sub clock resonator connection terminal
MICROCOMPUTER’STERMINAL DESCRIPTION

8
KDC-719/X559
/Z737,Z638
Pin No. Pin Name I/O Description Processing Operation
37 REGC - Capacitor connection terminal for regulator inside
microprocessor
38 X2 - Main clock resonator connection terminal Oscillation: POWER ON mode, Oscillation stop:
POWER OFF mode or momentary power down detected
39 X1 I Main clock resonator connection terminal
40 VSS - Ground connection terminal Connected to GND lines.
41 VDD - Positive power supply connection terminal Connected to BU 5V lines.
42 CLKOUT O Internal system clock output Not used (N.C.)
43 NC O Not used (N.C.)
44 E2PDET I EEPROM detection input Lo: No EEPROM, Hi:With EEPROM
Lo:When M MUTE L input is Lo during CD source
45 PRE MUTE L O Pre-out muting L Ch. control output selected or Momentary power down detected, Hi:
Fix in the case of 2 zone mode
Lo:When M MUTE R input is Lo during CD source
46 PRE MUTE R O Pre-out muting R Ch. control output selected or Momentary power down detected, Hi:
Fix in the case of 2 zone mode
47 DSP DATA O Data output to DSP IC Not used (N.C.)
48 DSP LATCH O Latch output to DSP IC Not used (N.C.)
49 DSP CLK O Clock output to DSP IC Not used (N.C.)
Lo: During FM seek or AF search, Hi: During
50 AFS O Noise detection time constant switching terminal FM reception, Hi: During last FM mode with
RDS/RDBS model
51 AM+B I/O AM+B control Hi: During AM reception
52 FM+B I/O FM+B control Hi: During FM reception, Hi: During last FM mode
with RDS/RDBS model
53 R QUAL I Quality input from the RDS decoder IC Except RDS, RBDS model: Not used (pull down to
GND lines)
54 R DATA I Data input from the RDS decoder IC Except RDS, RBDS model: Not used (pull down to
GND lines)
55 IC2TYPE0 I IC2 setting terminal Lo: Initial value (default)
56 IC2TYPE1 I IC2 setting terminal Lo: Initial value (default)
57 P ON I/O SW 14V control output Hi-Z: POWER OFF mode, Hi: POWER ON mode
58 BVDD - Positive power supply connection terminal Connected to BU 5V lines.
59 BVSS - Ground connection terminal Connected to GND lines.
60 TYPE0 I Destination type selection terminal 0
61 TYPE1 I Destination type selection terminal 1
62 TYPE2 I Destination type selection terminal 2
63 TYPE3 I Destination type selection terminal 3
64 AUX SW O CD/AUX input switching output Lo: Except AUX input, Hi:AUX input
65 ILL ON I/O FL/Illumination AVR ON/OFF control output Hi-Z: AVR OFF, Hi: AVR ON
66 MOSW O CD mechanism loading motor control output Hi: CD loading/eject action or Break, Lo: Other
67 LO/EJ I/O CD mechanism loading/Eject switching output Lo: Loading, Hi: Eject, Hi-Z: Stop or Break
MICROCOMPUTER’S TERMINAL DESCRIPTION

9
KDC-719/X559
/Z737,Z638
Pin No. Pin Name I/O Description Processing Operation
68 M STOP O Stop request to CD mechanism MI-COM. Lo: Stop mode, Hi: Operation mode
69 M RST O Reset output to CD mechanism MI-COM. Lo: Reset
70 CH CON O Changer control Lo: Standby mode, Hi: Operation mode
71 CH RST O Reset output to changers : Reset
72 CH REQH O Request output to changers Lo: Request
73 AVCONT O A/D converter reference voltage control output Hi: Active, Connected to AVREF terminal
74 AVDD - A/D converter positive power supply connection Connected to BU 5V lines.
terminal
75 AVSS - A/D converter ground connection terminal Connected to GND lines.
76 AVREF I A/D converter reference voltage input terminal
77 IFC OUT I F/E IFC OUT input terminal Hi: Station detected (Vth=2.5V)
78 S METER I S-meter input from F/E
79 NOISE I FM noise detection input
80,81 NC I Not used (Pull down to GND lines)
82 CD SW2 I 12cm disc detection SW input Lo: 12cm disc detected
83 M MUTE R I Mute request (R Ch.) from CD mechanism MI-COM. Lo: Mute request
84 M MUTE L I Mute request (L Ch.) from CD mechanism MI-COM. Lo: Mute request
85 CD SW3 I Down & limit switch detection input Hi: Chucking, Hi→Lo:Pickup most inner position
86 PANEL DET I Panel detection input Lo: Panel attached, Hi: Panel detached
87 CH MUTE I Mute request from changers Hi: Mute request
88 PHONE I PHONE detection input 1V or less: TEL MUTE, 2.5V or greater: NAVI
MUTE
89 SC CON O Control output to the panel MI-COM. Hi: Operation mode
90 SOURCE I/O SOURCE key detection input Not used (N.C.)
91 CD SW1 I Loading SW detection input Lo: Loading start
92 CD SW4 I/O 8cm disc detection SW input Not used (N.C.)
93 R CLK I Clock input from the RDS decoder IC Except RDS, RBDS model: Not used (pull down to
GND lines)
94 CH REQC I Communication request input from changers Lo: Request
95 EJECT I EJECT key detection input Lo:When EJECT key is pressed
96 SC REQ I Communication request input from the panel MI-COM. Hi: Request
97 CH DATAC I Data input from changers
98 CH DATAH O Data output to changers
99 CH CLK I/O Clock input/output with changers
100 SC DATA I Data input from the panel MI-COM.
MICROCOMPUTER’STERMINAL DESCRIPTION

10
KDC-719/X559
/Z737,Z638
TEST MODE
1. How to enter the test mode
While pressing and holding the Preset 1 and Preset 3 keys, re-
set the unit.
2. How to exit from the test mode
Reset the unit, ACC OFF, power OFF and Panel detached.
(Note) The test mode cannot be terminated by momentary
power down.
3. Initial status in the test mode
• Sources : ALL OFF
• Display : All segments are lit.
• Volume : -10 dB (displayed as “30” )
• Loudness : OFF
• CRSC : OFF regardless of the presence of switching
function.
• SYSTEM Q : Flat
• BEEP : When pressing any keys, the buzzer generates
a beep at any time.
4. Special display in Tuner mode
When any of the following messages is displayed in Tuner mode,
the F/E may be abnormal.
• “TNE2P NG” : The EEPROM is set to the default (unstable
values) because the F/E was shipped without passing through
the adjustment process, etc.
• “TNCON NG” : Communication with the F/E is not possible.
5. Forced switching of K3I
Each press of the Preset 6 key inTuner mode should switch K3I
from AUTO →Forced Wide →Forced Middle →Forced Narrow
→AUTO.
The initial status is AUTO and the display shows these modes
as follows.
• AUTO : FMA
• ForcedWide : FMW
• Forced Middle :FMM
• Forced Narrow : FMN
6.Test mode specifications of the CD receiver
• Forced ejection is inhibited in the reset start operation.When
the unit is reset while a CD is loaded in it, the CD is not recog-
nized by resetting.
• Each press of the Track Up key jumps to the following track
numbers:
No.9 →No. 15 →No.10 →No.11 →No. 12 →No. 13 →No.
14 →No.9 (The cycle restarts from here.)
• Each press of the Track Down key jumps to the previous track
number to the track being played.
• When the number of total trucks of the MP3 disc or the WMA
disc is less than 9, 1st truck is played.
• When the model is equipped the CD mechanism assembly
adapted for MP3 or MP3/WMA disc, the mechanism name and
version number are displayed during the CD source selecting.
• When the disc media is CD, A short press of the Preset 1 key
jumps to the track number 28.
7. Audio-related specifications
• A short press of the Q key initiates the audio adjustment mode.
• Pressing the * key on the remote initiates the audio adjustment
mode.
• Fader is selected to the initial item.
• Continuous holding of a remote control key is inhibited.
• Bass, Middle andTreble are adjusted in 3 steps of Min / Center
/ Max with the Track Up/Down keys.
• Balance is adjusted in 3 steps of Left Max / Center / Right Max
with the Track Up/Down keys.
• Fader is adjusted in 3 steps of Rear Max / Center / Front Max
with the Track Up/Down keys.
• HPF is adjusted in 2 steps of Through / 220Hz with the Track
Up/Down keys.
• LPF is adjusted in 2 steps of Through / 120Hz with the Track
Up/Down keys.
• Bass f, Bass Q, Bass EXT, Middle f, Middle Q and Treble f are
not dealt with by the audio adjust.
8. Menu-related specifications
• Pressing the DNPP/SBF key on the remote initiates the Menu
mode.
• Continuous holding of a remote control key is inhibited.
• In the case of the CD receiver model, A short press of the
PLAY/PAUSE key initiates the Menu mode.
9. Backup current measurement
When the unit is reset while ACC is OFF (i.e.by turning Backup
ON), the MUTE terminal goes OFF in 2 seconds in place of 15
second.(The CD mechanism is not activated at this time.)
10.Special display when the display is all on
Pressing the Preset keys while the power is ALL OFF displays
the following information.
[PRESET 1] Version display (8 digits, Month/Day/Hour/Minute)
(Display)SYS xxxxxxxx : System microcomputer
PAN xxxxxxxx : Panel microcomputer
[PRESET 2] Sireal number display (8 digits)
(Display) SNo xxxxxxxx
[PRESET 3] Short press :View power ON time. (The All OFF
period is not counted.)
Long press/hold : Clear power ON time at the
power ON time displaying.
(Display) PonTim xxxxx Max. 65535 (hours)
[PRESET 4] Short press : Display CD operation time.
Long press/hold : Clear CD operation time at the
CD operation time displaying.
(Display) CDTime xxxxx Max.65535 (hours)
[PRESET 5] Short press : Display CD ejection count.
Long press/hold : Clear CD ejection count at the
CD ejection count displaying.
(Display) EjeCnt xxxxx Max. 65535 (times)
[PRESET 6] Short press : Display Panel open/close count.
Long press/hold : Clear Panel open/close count
at the Panel open/close count.
(Display) PnCnt xxxxxx Max.655350 (times)

11
TEST MODE
KDC-719/X559
/Z737,Z638
11. Method of the span switching (K and M type only)
While holding the Preset 1 and Preset 5 keys, reset the unit.
12. Other specifications
• No displays such as “CODE OFF” during Power-ON.
• Pressing theTI (AUTO) key during changer operation turns on
2zone. Cancel by pressing the TI (AUTO) key again.The P/S
dot is lit during 2zone.
• In the case of 2 PREOUT model with Non Fader output, Each
pressing and holding the ATT key for 1 second or more during
All OFF, Non Fader output is switching Rear output or Non
Fader output.
• In the case of 2 colors key illumination model, Each press the
ATT key during All OFF, the key illumination is switching Green
or Red.
• Security-related information
1. Forced Power ON mode (All models)
Even when the security (Cord) is approved, resetting the unit
while holding the ATT and Preset 4 keys makes it possible to
turn the power ON for 30 minutes.
After 30 minutes have elapsed, it is not possible to return to the
previous condition unless the unit is reset again.
2. Method of registration of the security code after EEPROM
(Tuner Unit Ass'y) replacement (Code security model)
1.Enter the test mode.(See 1. How to enter the test mode)
2.Press the PLAY/PAUSE key to enter the Menu mode.
3.When the message “Security” is displayed, press and hold
theTrack Up/Down key for 1 second to enter the security reg-
istration mode.
4. Enter the code using the FM/AM/Track Up/Track Down keys.
• FM key: Number up
• AM key: Number down
• Track Up key: Cursor right shift
• Track Down key: Cursor left shift
5.Hold down the Track Up key for at least 3 seconds and the
message, “RE-ENTER” appears, so once again enter the
code according to Step 4 above.
6.Press and hold the Track Up key for 3 seconds until “AP-
PROVED” is displayed.
7.Exit from the test mode.(See 2.How to exit from the test mode)
(Note) All Clear is not applicable to the security code of this
model.
3. Simple way to clear the security code (K type only)
1.During code request mode, press the VOL UP key for at least
3 seconds while holding down the DISP key. (---- will disap-
pear)
2.Enter, “KCAR” with the remote controller as described below.
(Same as on 01 model.)
• Press the remote controller 5 key twice, and press theTrack
Up key. (Enters a “K” )
• Press the remote controller 2 key three times, and press the
Track Up key. (Enters a “C” )
• Press the remote controller 2 key once, and press the Track
Up key. (Enters an “A” )
• Press the remote controller 7 key twice, and press theTrack
Up key. (Enters an “R” )
3. Security function is canceled and unit sets to All-Off mode.
4.Code request mode appears if a mistake was made in enter-
ing the numbers.

12
ABCDE
1
2
3
4
5
6
7
C6
C16
C17
1334454850
C18
C19
12
43
EQ
SA
46
5
RST
ATT
SRC
FM
AM
DISP
TI
3
2
1
IC3
S1
S2 S3
S4
S5 S6
S7
S8 S9
S10
S11
S12 S13
S14
X16-168X-XX (J74-1327-22)
S15
S16
S17
S18
S19
S20
ED1
EB
EBEB
EB
EB
CP8
CP6
CP7
CP5 R35
C1
C2
C3 C4
C5
C7
C8
C9
C10
C12
C13
CP1
CP2
CP3
CP4
L1
L2
L4
L9
L13
R1
R7
R8
R9
R10
R11
R12
R13
R14
R15
R16
R17
R21
R25
R27
R32
R33
R34
R36
R39
R42
R43
X1
R50
R49
R48
R51
W2
CP9
C20
C21
15 1
216
31
30
180
5150
10081
1
16 9
8
45
13
91
1810
EB
BE
EBEB
(VDD)
PAN5V
3.3V
FAC
SCDATA
KR3
SCREQ
SCCON MCCLK RST
MCREQ KR2
KS1(CLK)
KS2(DO)
KS3(DI)
KS4
KR5
FLGND
FL+B
VPP
GND
FAC
VDD2
ESD GND
KR4
AUDIO
PRST SOURCE KR1
Q9
Q10
D15
D16
D1
D2
D3
D4
D5
D9
D10
D11
D12
IC1
IC2
IC4
IC5
Q1 Q2
Q3
Q6
Q7
Q8
Q4
D13
D14
J1
X16-168X-XX (J74-1327-22)
PC BOARD
(COMPONENT SIDEVIEW) (FOIL SIDEVIEW)
Refer to the schematic diagram for the values of resistors and capacitors.
X16-168X-XX
IC Q Address
32B
X16-168X-XX
IC Q Address
15D
25D
46D
54D
16D
26D
35D
44D
66D
76C
86D
96C
10 6D

1413
PC BOARD (COMPONENT SIDEVIEW)
Refer to the schematic diagram for the values of resistors and capacitors.
FGHIJ
1
2
3
4
5
6
7
KLMNO
C3
W115
C14
C20
C27
C28
C37
C40 C41
C42
C43 X4
C111
C144
C258
C260
C261
C262
C265
C355
C472
R7
R11
R16
R28
R37
R38
R43
R103
R140
R143
R204
R242
R251
R301
R303
R306
CP3
CP4
R474
R477
X1
C7
C25
C26
C30
C31
C256
C257
C259
C264
C266
C267
C305
CP1
L2
L14
L351
R2
R6
R8
R10
R12
R13
R15
R17
R19
R21
R23
R24
R27
R30
R31
R32
R41 R42
R44
R46
R115
R127
R144
R152
R167
R168
R177
R178
R187
R188
R203
W19
C130
R305
R358
R360
R366
CP5
CP6
C902
R389
R397
R400
R401
R402
R417
R421
R422
R471
R472 R473
R475 R476
W100
W15
W16
W17
W18
W111
C850
C803
C802
C804
L500
R800
R850
R851
CP2
W902
C903
C860
C855
R201
C854
L472
C9
W116
R905
R815
OG I 81
169
111
12
22
44
34
23 33 28
15
1
14 4
1
5
81
45
8
4
18
5
32 17
116
5
81
4
1
45
8
114
87
8
50 31
1
81 100
54
51
80
30
1
14
8
1
7
5
1
22
11
24
1
34
5
12
43
EB
EB
EB
EB
EB
EB
EB
EB
EB
EB
EB
EB EB
EB EB
EB
E
B
EB
EBEB
EB
EB
EB
EB
RES
GND
S-MTR
CD
NOISE
IFC
MD
SDA
SCL
BU5V
TEST
C1
C4
C8
C11
C13
C15
C704
C22
C23
C24
C29 C32C33
C45
C53
C58
C59
C60
C63
C113
C114
C115
C116
C142
C143
C252 C255
C263
C352
C471
C473
C474
C475
C920
C479 C480
C485
L7
R45
W9
C5
C6
C34 C36
C44
C46
C47
C49
C50
C51
C52 C56
C57
C65
C66
C67
C68
C69
C76
C77
C78C79
C81
C82
C85C86
C93C94
C95
C96
C99C100
C101C102
C105
C106
C107
C108
C117
C118
C119
C120
C129
C253 C254
L1
L471
X3
C702
C849
113 24
10 9
12
2
1
9
81
16
12
25 24
B
E
1
315
21
19
20
8
1
E
E
B
B
6
1
B
E
BEBE
B
E
B
E
C64
D5
D8
D13
D21
D33
D34
D35
D36
D39
D40
D112
D472
IC1
IC2
IC3
IC5
IC6
IC7
IC8
IC14
IC16
IC20
IC21
IC22
IC23
Q5
Q8
Q12
Q29
Q30
Q34
Q35
Q472
D14
D51
D52
D53
D101D102
D111
D475
IC10IC11IC12
Q6
Q7
Q11
Q13
Q17
Q19
Q20 Q22
Q23
Q52
Q101
Q305
Q306
Q473 Q475
IC24
D476
CN10 CN8
A1
D1
D6
D9
D10
D22
D23 D24
D50
D121
D122
D123
D124
D471
IC4
J1
D15
D16
D17
P1
Q4
Q10
Q16
Q26
Q111
Q474
Q476
Q1
D31
Q703
S1
CN1
CN2
CN6
CN9
CN3
CN4
CN7
D3
X25-924X-XX (J74-1328-22)
R1
R2
R3
R4
R5
R6
R7
R8
R9
R10
R11
15
1
2
16
S1
J1
X89-253X-XX (J74-1332-12)
IC Q Address
15I
23H
33G
44L
53I
64J
75K
85H
10 3J
11 3J
12 3J
14 3G
IC Q Address
16 6J
20 4H
21 4H
13F
42F
53G
63G
73G
83G
10 4F
11 4G
12 3G
X25-924X-XX
IC Q Address
13 3G
16 4K
17 3K
19 4J
20 4J
22 4J
23 4J
26 5L
29 5L
30 5L
34 4H
35 3H
IC Q Address
52 2G
101 7I
111 5K
305 6K
306 6K
473 6M
474 5L
475 5M
476 5L

1615
PQRST
1
2
3
4
5
6
7
UVWXY
E
B
EB
BE
BE
BE
BE
BE
BE
BE
BE
EB
EB
BE EB
EB
EB
EBEBEBEBEBEB
EB
BE
BE
EB
BE
C251
R48 C35
C481
C121
C863
C484
R205
W14
R206
R207
R14
C21
R20
R40
R202
TH1
R363
L251
L352
R230
R231
R18
R803
R135
R134 R133
R132
R131
R1
R375
R370
R367
R904
CP16
R364 R359
CP12
CP13
R352
R121
C38
R47
C861
C39
R112
C48
R39
R200
R111
W901
R29
C862
R124
R123
R122
C354
CP14
CP10
R3
R4
R384
R382
CP8
CP7
R392
R393
R390
CP9
C353
C852
C204
CP17
R25
R26
R137
R136
R130
R35
C351
C900
C19
R902
R36
R903
R33 R901
L501
C904
C55
R900
R361
R362
R357
R355
R353
R403
R407
R405
R58
R409
R412
R414
R406
R404
R147
R59
R410
R408
CP11
R148
C853
R49
C18
R34 R57
C205
C54
R50
C201
R146
R145
R141
R149
R142
C206
R53
C202
R54
W7
W8
R52
C17
R55
R702
C703
C12
R56
W121
W117/C857
W120
C2
L3
R161 R162
R175
R173
R166
R164
R165
R163
R170
R169
C98
C97
C83
R172R171 R182 R181
C88
C91
C92
W5
C90
C89
W6
W3
W2
W1
C87 C84
R190
R185
R183
R179
R180
C104
C103
C110
C109
R176
R174
R189
W4
R186
R184
R157 R155
R156
C858
C203
W114
L9
CP15
R151
C72
R98
C75
C73
W11
W12
R154
L5
R153
R150
C70
C74
C71
C856
C139
L13
C137
L12
C134 W113
C133
C135
L11
L10
R213
R212
C16
C864
C146
C145 C141
C10
R5
C851
R211
R210
W112
C131
C136
C859
C132
41
85
D32
D30
D473 D474
Q201
Q15
D7
Q14
D38
D41
Q28
Q3
D54
Q9
Q31
D19
Q33
Q27 Q112
D20
Q32
Q21
Q471
Q18
D42
IC25
Q36
Q103
D702
Q704
D45
D46 D44
D29
Q38
Q37 Q39 Q40 Q41 Q42
D27
D28
Q45
D25 D26
Q46 Q43
Q44
D43
X25-924X-XX (J74-1328-22)
119
20 2
CN1
X89-253X-XX (J74-1332-12)
PC BOARD (FOIL SIDEVIEW)
Refer to the schematic diagram for the values of resistors and capacitors.
IC Q Address
25 5T
36S
96R
14 5Q
15 5Q
18 4S
21 4S
27 5R
28 5Q
IC Q Address
31 5R
32 4S
33 5S
36 3U
37 3S
38 3S
39 3S
40 3S
41 3S
X25-924X-XX
IC Q Address
42 3S
43 2V
44 2V
45 2U
46 2U
103 4U
112 5R
201 5Q

ABCDE
1
2
3
4
5
6
7
FGHIJ
10K
47K
10K
47K
22K
22K
47k
2.2k
47K
47K
47K
47K
22K
22K
22K 47K
22K 47K
22K
22K
22K
22K
22K
22K
22K
22K 22K
22K
14V
0V
14.4V
/5.0V
0V
2.2V
0V
3.0V
10V
0V
-10V
0V
0V
10.6V
-10.0V
10.6V
5.0V
0V
0V
0V
0V
5.0V
0V0V
0V
5.0V
5.0V
0V
7.7V
0V
7.7V
4.1V
0V
14.4V 7.7V
7.7V
1.4V
1.4V
1.3V
5.0V
0V
0V
14.4V
9.0V
1.4V
7.7V
7.7V
7.7V
1.4V
0V
7.7V
0V 5V
0V
5.0V
5.0V
5V
0V
0V
3.5V
0V
5.0V
0V
0V
5V
0V
5V
5V
0V
0V
5V
0V
5V
0V
5V 5.0V
0V
0V
5V
0V
5V
5V
0V
5V
0V
0V
5V
0V
5V
0V
0V
5V
0V
5V
0V
5V
0V
5V
0V
5V
0V
5V
0V
5V
0V
5V
0V
0V
0V
5V
5.0V
0V
0/5.0V
0/5.0V
0/5.0V
0/5.0V
5V
0V
0V
5V
0V
5V
5V
0V
5V
0V
0V
5V
5V
0V
5V
0V
5.0V
0V 5V
0V
4.2V
0V
5V
0V
0V
0V
0V
5V
0V
5V
4.1V
1.5V
0.6V
0V
5V
5V
0V
5V
0V
0V
5V
5V
0V
5V
0V 0V
5V
0V
5V
9.1V
9.2V 45.3V
5.0V 5.0V
4.7V
13.6V 1.25V
8.2V
7.5V
-9.3V
-5.5V
0.1V
9.7V
5.0V
0V
0V
5V
0V
4.7V
∗
IC23
IC3
A1
IC4
IC7
IC6
∗
IC1
IC16
ELECTRIC UNIT (X25-924X-XX)
DC CORD
DC CORD
DC CORD
KDC-Z838/719
KDC-MP819/X659/X559/Z737
Z638
IC25
Q26
∗
I
Q112
D112
Q111
D111
D14
Q27
Q29
Q28
D15
J1
D16
Q30
D1
D17
Q31
D13
Q14
D7
D8
∗
K
∗
JQ15
D474
D475
Q475
Q476
Q3
Q472
D473
Q474
Q473
Q201
∗
L
∗
N
D472
Q11
Q10
Q4
Q7
Q6
Q8
Q5
D3
Q1
Q12
Q13
D6
D5
D30
D38 D40 D39
D36 D35
D34
D33
D41
D32
CN8
D19
Q33 Q32
Q16
Q17
D9
D10
Q19
Q18 Q20
∗
C
D20
Q21
Q22
Q23
(X25-924X-XX)
CBEFIJKLNAO
to CD MECHA
P-ANT
SW
EXT. AMP
CON. SW DIMMER
BU DETECTION
SW 5V
CD4.7V
A. +8V AVR
CD SERVO AVR
FL ILL
DC/DC CONVERTER
SYSTEM MI-COM.
RESET IC
POWER IC
P-CON SW
P-CON.
PROTECTION SW
PROTECTION
P-CON.
INHIBIT SW
DETECTION
SW
MUTE DRIVER
for Rch
MUTE DRIVER
for Lch
SW SW
ACC DETECTION
MUTE
LOGIC
FL/ILLUMINATION
AVR
FL/ILLUMINATION
AVR SW
MECHA.
AVR
AVR SW
MECHA.
AVR
A. +10V PRE-AMP
+9V AVR
PRE-AMP
-9V AVR
SW 14V
AVR
IC
A. +8V
SW
AVR
EEP ROM
VOLTAGE CONVERTER
BU 5V
AVR
BU 5V
DISCHARGE
SW
(BOTTOM VIEW)
R38 1K 1/2W
R103 4.7K
9
11
22K
R111
R112 560
1W
R37 4.7K
∗
W111
19
20
R40
1K 1/2W
R39
22K
C36
0.1u50
+
3.3u50
0.068
+
C34
C35
REAR Lch+
9
FRONT Lch+
FL+
815 16 FUSE
11 12 1310 14
R41
12K
C37
1000P
R43
15K
R42
22K
C1 3900u16
FRONT Rch+
FRONT Rch-
FRONT Lch-
9
RR-
FR+
FR-
RR+
RL+
FL-
RL-
12
14
11
13
4
REAR Rch+
REAR Rch-
REAR Lch-
ANT
675
ACC
GND
P CON
321
+
C2 0.01
R44 22K
B.U.
L1
3.3K 1/2W
R45
47K
R46
C39
0.01 R48
100K
TEL MUTE
ILLMI
140uH
10 EXT CONT
BU
1K
R13
560
R14
10
R15
10K
C20 0.01
14
10K
R19
0.022
C21
100K
R20
24
88
BU
27
28
12
13
47K
∗
R16
C484
0.01
C485
220u16
22K
R3 22K
C479 100u6.3
2.2K
R4
BU
R476
C481
0.01
10u16
C480
R475 22K
2.2K
R205
100K
R206 R207
100K
∗
W14
SW5V
100K
R1
VOS
C474 100u25 C475 100u25
SW OUT
VIN
GND1
+B
2 1 3 4
BU
100uH
OFF
ON/ 5
220u10
C473
∗
C130
1K
0.33 R477
∗
W902
BU
VIN VREF
GND
R5
220
BU
A8V
SW14V
BU
R6
15K
24K
R8R7
4.3K
+
C8
220u10
SW14V
BU
R2 1.5K
C3 0.1
+
C4 100u10
GND
VO1
VIN
VO3-1
CT
4 2 1 3 5 6
VO3-2
4
6
C14 2.2
C17 0.01
+
C15 100u50
C13 100u16
+
C11 100u16
+
1
3
5
13
11
9
7
19
17
15
23
21
25
R115 33K
33u10
+
C116 1u50
R200 220
+
0.22u50
C117
0.22u50
C118
RL
0.22u50
C119
0.22u50
C120
FL
RR
FR
RL+
RL-
FL+
FL-
RR+
FR-
FR+
RR-
470
TH1
R202 10K
C115 1u50
C129 1u50
+
+
SVR OUT1+
OUT1-
OUT2+
TAB
OUT2-
PGND1
STBY
PGND2
VCC1
SGND
IN1
OUT3+
IN3
HSD
OUT3-
OUT4+
OUT4-
IN2
ACGND
IN4
PGND4
PGND3
MUTE
VCC2
2
6
4
10
8
BU
18
14
12
16
24
22
20
BU
23
MOTOR
S7.5V
22 21
LO/EJ
20
D4.7V
19
D4.7V
18
D.GND
17
D.GND
16
BU5V
15
LOE/
14
EJECT
13
MSTOP
12
MRST
11
MUTE L
10
MUTE R
9
Rch
8
A.GND
7
Lch
6
A8V
5
DATA
4
CLK
3
LOS SW
2
12EJE
D.OUT
1
S.GND
24
67
66 83
84
69 68 85
82
91
8 7
C853 0.1
LIM SW
SW
R33 4.7K
S7.5V
+4.7V
+4.7V
BUBU
A8V
A8V
123
CIN2BIN2 CIN1
7GND 8
DIN2
COUT
5 6
4AIN2
BIN1 BOUT 10
9
DIN1 11
2
1
AIN1 AOUT 13
DOUT
VCC 14
45 46
34
30
25
29
BU
BST
GND 3
1
LV
V+
OSC
6
8
72
CAP+
4
VOUT CAP-
5
BU
R23
75
+
C23 4.7u25
C27 2.2 C28 2.2
C26 2.2 C25 2.2
+
C24
100u16
C29 22u16
+
7.5K
R26
47
R25
2.7K
R24
91K
R28
56K
R27
R29 47
10K
91K C31 0.01
R32 91K
C30 0.022
+
C32
4.7u25
+
C33
4.7u25
+5V
+5V
+5V
1u50
+
C22
1
12
22
18
A8V
C19
0.01
R36 100K
R35
470
+5V+5V
+5V
R31
R30
B
L3 22uH
31
2
+5V
SW5V
+5V
+5V
10K
R12
1K
R21
90
64
63
62
61
59
58
56
55
57
60
54
53
52
51
0.01 CP17
1Kx2
∗
R410 100K
R414 100K
R412 100K
∗
R406 100K
∗
R408 100K
∗
R407 100K
∗
R409 100K
∗
R403 100K
∗
R404 100K
∗
R405 100K
PRE MUTE L
46
AFS
AM+B
50
FM+B
PRE MUTE R
DSP LATCH
DSP CLK
DSP DATA
49 48 47
R58
100K
45
42
CLK OUT
E2P DET 43
45 44
NC
VDD
VSS
X1 39
41 40
R QUAL
R DATA
IC2TYPE0
BVSS
BVDD
P ON
IC2TYPE1
TYPE3
TYPE2
TYPE1
TYPE0
R361 2.2K
80
79
78
77
76
75
74
73
72
71
70
68
67
66
69
65
CP5
R401 1K
R400 100
1Kx2
1000P
R397
1K
C351
CP6
2.2Kx2
CP12
100Kx2
M MUTE R M MUTE L CD SW3 PANEL DET SOURCE(OEL ONLY)
M RST
M STOP
LO/EJ
MOSW
AUX SW
ILL ON
CH RST
CH CON
AVREF
AVSS
AVDD
CH REQH
AVCONT
S METER
IFC OUT
R357 2.2K 85
82 CD SW2
NC
81
NOISE
NC
83
84
R353 1K R355 1K
CP13 100Kx2
87
86
CH MUTE
88 89 PHONE
SC CON
R359 100K
R360 470
14
16
17
15
18
19
20
21
22
23
24
26
27
28
29
30
25
BU DET
35 22P
X4
32.768kHz
27P
20MHz
X1
C42
C43
36
XT2
REGC 37
X2 38
XT1
32
33
31
100x4
∗
CP14
O CE
O CLK
RESET
O DATA 32
34 33 31
ACC DET
MUTE
SW5V
CD MECHA+B
EXT-AMP-CON
EMUTE
PAN5V
ANT-CON
P MUTE
TEST
P-CON
PLL DATA
PLL CLK
P-STBY
SVR
DIMMER
34
34
OUT
2
VDD
1
VSS
3NC
4
100K
R393
R422 22K
∗
R392 47K
R390 47K
CP10
470x2 CP9
∗
R382
R127 2.2K
4.7Kx2
1
2
3
4
5
6
7
8
9
10
11
13
12
CD SW1 CD SW4 R CLK CH DATAC CH DATAH
IC2 SDA
PAN RESET
REMO
BEEP
IC2 SCL
EVSS
EVDD
EJECT KEY G
EJECT KEY R/G
MC REQ/FLIP DET
MC CLK
DSI GUIDE
91
92
93
94
95 CH REQC
EJECT
R362 2.2K
R366
R364 100K
1K
R367 47K
99 98 96
97 SC REQ
CH CLK
100 SC
DATA
MC DATA
L351
CP4
∗
R384 2.2K
CP8
100x2
CP2
470x4
27
28
29
30
SW5V
BU
BU
SW5V SW5V
SW5V
SW5V SW5V
SW5VSW5V
88
25
23
24
22
20
19
18
15
12
10
11
17
16
8
7
5
14
3
97
98 99
95 96
94
93
91
89 86
87
85
82
83 84
51
52
53
54
46
66
67
68
69
70
71
72
77
78
13
SW5V
+5V
C204
1K
R201
C354
1
R417
22K
0.01
C852
CP11
100Kx2
∗
R402 470
R358 1K
R370 100K
100Kx4
CP16
CP3
470x2
600
CP7 4.7Kx2
R375 1M
2
1
0.1
C355
47K
R421
8
7
BU
4.7uH
L352
0.01
C353
47u16
C352
+
2
FL+B
22
21
A8V
SW5V
SW5V
+5V BU +5V
A8V BU
A+9V
A8V
+5V BU
A+9V
FL+B SW5V
+5V
A8V
BU
15
0.01
C48
0-12
0-13
0-14
0-11
No.
KDC-X559
KDC-X659
KDC-719
KDC-MP819
MODEL NAME
NO
NO
NO
YES
YES
YESNO
NO NO YES YES NO
YES
NO
YES NO
YES
YES
NO
C56,57,
76,77,802 IC1 IC23
100K
100K
100K
100K 2.2K 22K
22K
2.2K
NONO YES
NO
NO
YES
YES
NO YES YES
R163,164,
173,174 W7,
W1-6, 8W121
KDC-Z838
Z638
KDC-Z737 2-71 0-22
0-21 NO
YES NO
YESNO
NO
NO YES
NO
NO NO
YES
YES
YES
NO
YES
YES
YES
YES
YES
NO
YES
YES
NO
NO
YES
YES
YES
YES
NO
NO
YES
YES
NO
YES
YES
YES
YES
NO
NO
YES
NO
NO
C46,
47
YES
YES
YES
YES
YES
NO
NO
YES
NO
NO
C93,94
22u16
99,100
10u16
10u16
22u16
22u16
10u16
10u16
C130
YES
YES
NO
NO
YES
NO
NO
CP14
YES
NO
NO
NO
NO
NO
NO UPD703033GFA17
UPD703033GFA17
UPD703033GFA18
UPD703033GFA18
UPD703033GFA17
UPD703033GFA18
UPD703033GFA18
YES
NO
NO
Q306
YES
NO
R16
100K
100K
22K YES
R17,
NO
NO
NO
NO
NO
NO
22K
2.2K
22K
R382
2.2M
100K
100K
100K
100K
100K
100K
R392 R402 R403 R404 R405 R406 R407 R409R408 R410
YES
YES
NO
NO
YES
NO
NO
YES
YES
NO
YES
YES
YES
NO
YES
NO
YES
YES
YES
YES
NO
NO
YES
YES
NO
NO
NO
NO
NO
NO
NO
YES
YES
YES
YES YES
NO
NO
YES
NO
NO
YES
NO
YES
NO
YES
YES
YES
YES
YES
NO
YES
NO
NO
NO
NO
YES
YES
YES
YES
YES
YES
NO
NO
NO
NO
NO
YES
NO
NO NO
YES
YES NO
NO
YES
YES
NO
NO
NO
NO
YES
YES
W11,
12
YES
NO
NO
YES
NO
NO
YES
W14,
NO
NO
YES
NO
NO
NO
NO
W111,
YES
YES
YES
YES
NO
+5V +5V
+5V
+5V
+5V +5V
+5V+5V
+5V
+5V
+5V
C114
470x2
1K
R389
R203 4.3K
1
14
1
14
B.U.GND
PNK/BLK
FRONT R
ANT CONT
P. CON
ACC
FRONT L
ILLUMI
EXT.CONT
REAR R
REAR L
513 7
FR-
FR+
RR-
RR+
RL+
FL-
FL+
RL-
B42
31
P.CON
6
5
8
7
ILLUMI
A42
BU
68
ACC
GND
BRN
ORG/WHT
YELBLK 116
BLU/WHT
BLU/WHT
ANT CON
314
2
RED 15
413
TEL MUTE
GRN
VIOL
VIOL/BLK
GRN/BLKWHT/BLK
GRY/BLK
P CON
FR+
FL-
FR- GRY 512
7
610 11
FL+ 8
WHT 9
RR+
RL-
RR-
RL+
PNK/BLK EXT.
CONT
ACC
GND
WHT
WHT/BLK
GRY/BLK
GRY
BLU/WHT
BLU
RED
BLK
FRONT L
ANT CONT
FRONT R
P. CON
GRN VIOL/BLK GRN/BLK VIOL YEL
ORG/WHT
B.U.
REAR L
REAR R
ILLUMI
BRN TEL MUTE
WHT
WHT/BLK
GRY/BLK
GRY
BLU
BLU/WHT
RED
BLK
GRN VIOL/BLK GRN/BLK VIOL YEL
ORG/WHT
A8V
IC16
11109
876 141312 54 315 21
16
109
811 612 572
15
3
1413
41
16
R11 100K
C9 0.22
C10 0.01 C12 0.01
∗
C857 1000P
10uH
L2
5.6K
R10
∗
W117
∗
W121
C38 0.01
R47 18K
C861 0.1
L471
C16 0.1
1
C7
R815 2.2K
A1 WP
5
6
GND SDA
A2
4
3SCL
7
8
2
1A0 VCC
7
8
FL+B FL+B
FL+B
A+9V
A+9V
9VA
A9V A9V
A9V 9VA
SW5V
Q26,29
Q27
Q28
Q32
Q33 Q10,11
Q12,13
Q472
Q16,17 Q21-23
Q18-20
Q4
Q5,6
Q475,476
Q201
C857
YES
YES
YES
YES
YES
YES
NO
K1
∗
R17
UNIT 902 11715-18384
K3
K2
K4
M1
M2
E1
+ +
+
+
+
+

KLMNOPQRST
1
2
3
4
5
6
7
22K
22K
22K
22K
4.7K
22K
22K
22K
4.7K
22K
4.7K
4.7K
4.7K
4.7K
4.7K
4.7K
10K
47K 47K
10K
47K
10K
0V
4.1V
0V
4.1V
0V
4.1V
0V
4.1V
4.1V
4.1V
4.1V
4.1V
4.1V
4.1V
8.2V
5V
0V
5V
0V
4.1V
0V 4.1V
4.1V
4.1V
4.1V
4.1V
4.1V
8.2V
4.1V 4.1V
4.1V
4.1V
4.1V
0V
4.1V
5.0V
0V
0V
5.0V
5V
0V
2.4V
2.4V
8V
0V
8V
0V
8.2V
8.2V
4.1V
4.1V
4.1V
4.1V
4.1V4.1V
4.1V
4.1V
4.1V
4.1V
4.1V
4.1V
4.1V
0V 4.1V
4.1V
4.1V
0V
5V
4.1V
4.1V
4.1V
4.1V
4.1V
4.1V
4.1V
4.1V
4.1V
4.1V
5.0V
9.7V
0V
0V 0V
0V
0V
0V
-9.3V
-9.3V
0V
0V
0V
-9.3V
9.7V
0V
0V
0V
9.7V
0V
0V
0V
0V
0V
0V
4.3V
4.1V
4.1V
4.1V
4.1V
4.1V
4.1V
4.3V
4.8V
4.1V
4.1V
0V
1.4V
4.1V
8.2V
0V
IC14
IC5
IC8
IC21
IC20
IC2
IC12
IC11
IC10
KDC-MP819/X659/Z838 (1/2)
Z638/KDC-719/X559/Z737 (1/2)
DAUGHTER UNIT (X89-253X-XX)
A
KDC-719
KDC-Z737
Z638
KDC-MP819
KDC-X659
KDC-Z838
KDC-X559
DIN CONNECTOR
CORD with
CORD with
DIN CONNECTOR
CN2
Q18,20,23,27
D22-24,31,121-124
D25,26
D27,28,44,46
D17
D21,42,54
D15
D16
D6
D13,14,33-36,39,40,111,112
D9
D10,50
D7,473
D8
D1
D3
D5,474
Q26,111
IC1
Q1
Q8,12,35,43,45,103
Q14
Q16
Q11,17,19,21,22,30,
Q9
Q6,7,13,28,32,33
Q4,10
Q3
IC14
IC7
IC6
IC8,10,11,12
IC3
IC4
IC2
Q45
Q46
Q44
Q43
FE1
ANT.
W9
D43
B LINE
B LINE
SIGNAL LINE
GND LINE
∗A
Q52
CN4
∗E
CN7
D50
D21
CN6
CN3
D28 D29
D27
D22
D23
D31
D24
∗F
Q34
D45
D44
D46
Q103
D26 D25
Q36 Q35
∗B
Q42
Q41
Q40
Q39
Q38
Q37
CN1
D54 D51 D52 D53
∗Q306Q305
Q9
D101
Q101
S1
CN9
D124
D123
D122
D121
∗O
IC5
IC16
IC21
IC20
IC23
Q5,15,472
31,34,201,473,475
Q29,112
Q36-42,52
Q101,305,306
Q44,46
Q474,476
D19,20,30
D29,45
D32
D51-53
D38,41
D472,475
D101
P1
:∗
TDA7407:
: TDA7560
: TDA7401
: ICL7660SIBA
: TC74HC02AF
: NJM4565M-TE2
: TDA7479D
: S-80837ANNP
: BA3121F
: BA3129F
: SI-8050JD
: M5237ML
: 2SD2375
: 2SA1037K
: 2SA2057
: DTC144EUA or
: DTA124EUA or
: DTC124EUA or
: 2SB1427
: 2SC4081
: DTA123JK or
: 2SB1443
: 2SA1576A
: 2SB1277(Q,R)
: DTC114YUA or
: DTC143TUA or
: CPH3105
: DTA114YUA or
: 2SB1548(P)
: RM10ZLF
: MA8082-L
: MA8100-L
: MA4051(N)-M
: MA8056-M
: MA8047-M
: MA4110(N)-M
: MA4056(N)-M
: 1SR154-400 or
: 1SS133
: MA4068(N)-M
: MA4062(N)-M
: DAP202U or
: DA204U
: MA4062-L
: RD6.8M(B2)
: MA8068-M
: MA8062-L
: DAN202U or
: 1SR154-400
: FTZ6.8E
: B30-1566-05
: SS14
CN1 J1
2/2
J1
X16-
(X89-253X-XX)
E-VOL. &
SWITCHED OP. AMP.
SPEANAAMP
PAN 5V
PANEL
DET SW
RDS
D42
F/E
UN5213
UN5112
UN5212
KRA105S
UN5114
UN5216
UN5214
IC25 BR24C02F-W:
MA142WK
MA142WA
S1J
D43 : IMSA-6801
N.C. MPX
NOISE
BUFFER
E. VOL.
SW
MUTE
AUX/CD
SW
SELECTOR
ISOLATION
AMPLIFIER
OP.
AMP. AGC for
ANALYSER
SPECTRUM
HIGH PASS FILTER &
NON-FADER VOLUME
AMP.
OP.
OP.
AMP.
OP.
AMP.
AUDIO
MUTE SW
(FRONT L)
(FRONT R)
MUTE SW
AUDIO
(NON-FADER R)
MUTE SW
AUDIO
(NON-FADER L)
AUDIO
MUTE SW
(REAR L)
MUTE SW
AUDIO
(REAR R)
AUDIO
MUTE SW
SW
DSI LED SW EJECT LED RED SW
FM+B
SW
SW
AM+B
DECODER
COMPOSITE
BUFFER
SIGNAL
EJECT LED
GREEN SW
1
2B.U. GND
BU
1
20
78
0.01
4.7uH
L13
C139
24
23
22
21
+B
S-METER
IF1 +B
IF1 GND
AUDIO OUT
AMIF OUT
51
4.7uH
L12
22K
52
1K
R213
R212
R211
22K
R210
1K 4.7uH
L9
0.01
9
16 SDA
17
19
18
16
15
SW5V
17
NOISE OUT
VDD 5V
RDS OUT
DIG GND
SCL
12
14
13
11
10
77
PLL +B
IFC OUT
VT
W/N
OSC GND
AM ANT
7
6
5
4
8
+B
+B AM +B
OSC GND
OSC GND
FM +B
OSC GND
1
2
3
+B
FM ANT
RF GND
C131
L7 52mH
2
+B
B
A8V
10P
C134
A8V A8V
L11
4.7uH C135
0.01
L10
4.7uH
A8V
+B
W112
0.01
C133
SW5V
C144
C142
10u16
0.01
330P
2.2Kx4
CP15
SW5V
OIN
RDDA
1
2QUAL
4
3VREF
MPX
T57
RDCL
OOUT
SW5V
6
7GND
ARI
5
8FOUT
OSEL
FSEL
VS
EXTR
TM
16
15
13
14 C146
10P
X3
4.332MHz
C145
11
10
12
9
10P
C141
54
53
93
SW5V
4.7uH
L14
C143
10u16
C856
0.01
C137
0.01
10P
C136
10P
C132
0.1
C859
+B+B
3
1
CD Lch
CD Rch
CD GND2
R156 10C68 0.47u50
+
R155 10C67 0.47u50
+
+
C69 47u6.3 R157 4.7
C79
27
C85 0.33u50
C87 0.33
C83 0.33
C84 0.33
C88 0.33
C81 0.33u50
+
+
C86 0.33u50
+
C82 0.33u50
C60 2.2u50
HRRO
HRLO
20
HFR2
HRR1
HRR2
HRL2
HRL1
16
17
15
19
18
DGND
SCL
HFL1
CREF
HFL2
AGND
HFR1
22
21
25
26
23
24
7
8
12
10
11
9
14
13
HFRO
OREF
AXOR
HFLO
AXOL
6
CR2
CL2
CL1
AXIR
CR1
MUTE
5
2
3
4
0.1
C89
C91
0.1
C90
0.1
4.7u16
0.1
C92
C78
SDA
VCC
28 AXIL 14.7u16
V- AIN+ AOUT AIN-
1
4
2
3
BOUT
BIN-
BIN+
V+
6 7 5 8
2
AUX
Rch
3
AUX
1
R141
15K
R146 820
R147 1KR148 9.1KR149
+
10u16
C55 1
C54 0.01
R145 47K
+
C58 10u16
4.7u25
+
C50
R140 47K
4.7u25
+
C49
+
C53
4.7u25
1K
R142
+
C52
4.7u2547K
R143
C51 4.7u25
+
R154 330K R153 330K
10 9 18 17 20 19 12 1115 16 13 14 4 3 876521
R137 4.7K
R130 4.7K 2 CH MUTE
CH RST
CH CON
3
1
1
5
3
R136 4.7K
R135 4.7K
R134 100 4
5
R132 100
R133 100
R131 4.7K
8
7
6CLK
REQ C
REQ H
DATA H
DATA C
98
97
99
94
72
70
87
71
24
23
9
8
14
11
10
13
35
34
32
31
29
30 ∗W4
∗W3
∗W1
∗W2 FL
FR
RR
RL
24K
C59
FAC FAC
FL+B
FLGND
RST
AUDIO
P RST
SC DATA
MC CLK
SC REQ
MC REQ
SC CON
PAN 5V
D GND
SRC
N.C.
(R/G)
EJECT EJECT
ESD GND
ILL(G)
KEY
10u16
0.1
C205
R50
100K
R56
R57
3300P
C202
10
C201
4.7
3300P
10
C45
+
C6
4.7u25
+
22u10
+
C44
4.7u25
0.01
C40
+
47K
R53 0.1 C206
∗W8
∗W7
6
3
R55 C5
5
BINGND
4
AIN1+ BIN1+
BOUT
8
7
VM2
VCC
VM1
AIN
AOUT
BIN2+
BIN1-
BOUT
BSW
BIN2- 10
8
9
VCC
14
13
11
12
VEE
ASW
AIN2+
AIN1-
AOUT
AIN2-
1
2
5
7
6
1
2
4
3
R54
47K
47K
R52
SCL
GND
NC25
VS
NC28
OUTRF
OUTLF
NC33
OUTLR
OUTRR
SDA
QUAL NC20 SMUTE MUXR MUXL MP IN MP OUT NC17 MPX NC13 LEVEL
PHONE+
CDLOUT
PHONE-
CDROUT
TAPER
CDGND
∗W12
43
∗W11
44
NC6
CDR
1
CDL
4
6
5
3
2
0.033
R151 10K
C72 10
AFS
9
7
8
AM
11 NC11
43 44
4.7u25
C63
40 42 41 38 39 34 36 37 35
TAPEL
AC INLF
VREF
CREF
AC INLR
AC INRF
AC INRR
AC OUTR
NC36
AC OUTL
12
R150
4.7K 0.47
C70
C71
150P
14
19 15
14
13
12
C75 0.1
R152
18 16
17
4.7K
19 18
C74 0.1
20
R98
21
22
8 7
32
33
29
28
27
30
31
26
23
24
25
1000P
+
47u16
3
5
1
23
24
30
29
31
32
35
34
R183 2.2K
R185 10K
R181C105
R190
82
47022u16
1
2
R182C106
54
R184 2.2K
V-
R186 10K
BIN+
R188
22K 10u16
C108
81
AOUT
AIN+
AIN-
3 2
7BOUT
V+
6BIN-
+
2200P
C110
A+9V
R169
82
82
R170
82
R179
R180
82
R189
82
∗W6 ∗W5
470
+
22u16
R172
470
∗C100
+
R171
470
∗C99
R162
470
∗C94
R161
470
+
∗C93
22K
∗W18
54
∗R174
R176 10K
∗W17
∗R173
R175 10K
BIN+ V-
1
R187
22K
3
R178
22K
2
+
C107
10u16
C102
10u16
+
8BOUT
V+ BIN-
AOUT
AIN-
AIN+
7
6
R177 10u16
+
C101
54
R166 10K
∗W16
∗R164
V-
∗R163
∗W15
R165 10K
BIN+
AOUT
AIN+
AIN-
1
22K
R168
3 2
10u16
C96
+
8
7
6BIN-
BOUT V+
R167
22K +
C95
10u16
2200P
C109
C103
2200P
C104
2200P
2200P
C98
2200P
C97
14
13
9
8
11
10
RR
RL
NL
NR
FR
FL
RR
RL
10
98 7
FL
NL
NR
FR
4
3
6
52 1
470
R905
95 89
10
96
2
1
11
34
14
5
C860 0.1
22K
4.7K
23
100K
R301 R303
240
3
390K
R305
4.7
C305
100
R306
86
W19
P5VP5V
+B +B+B
+B
BU
+5V
SW5V SW5V
21
22
FL+B
43
44
12
14
A8V
L5 4.7uH A8VA8V
A8V
SW5V
18 19
A8V
A8V
A8V
A8V
C113
C111
SW5V
+5V
A8V BU
SW5V
A8V BU
+5V
+5V+5V
BU
6
4
1
2
O-CE
O-CLK
O-DATA3
GND5REMO4
C854 0.1
R122 470
R124 470
R123 470
R121 1K
31
32
33
13
33K
R144
BU
0.1
∗C802
0.1
C803
0.1
C804
RR R-GND RL NL FL N-GND F-GND NR FR
Lch
GND
AUX
R231
R230
4.7K
C73 0.01
10
R204
+
+
+
0.01
C855
C203 0.1
C851 0.01
C858 0.1
R242 4.7K
1
14
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
ESD GND
EJECT
EJECT
EJECT
N.C.
SRC
D GND
P5V
SC CON
MC REQ
SC REQ
MC CLK
SC DATA
P RST
AUDIO
RST
FL GND
FL +B
FAC
FAC
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
ESD GND
SRC
D GND
P5V
SC CON
MC REQ
SC REQ
MC CLK
SC DATA
P RST
AUDIO
RST
FL GND
FL +B
FAC
FAC
R8 510
R7 470
R6 240
R5 240
R4 240
R3 470
R2 240
R1 470
P5V
FL+B
R9 470
∗R10 220
R11 220
ILL(G)
ILL(R/G)
MODEL NAME No.
0-00
2-71
UNIT
NO
YES
R10
S70-0873-05
S70-0856-05
S1
(YG)
(SR/PG)
KDC-X659 (K)
KDC-MP819 (K)
KDC-719 (K)
KDC-X559 (K)
Z638 (E)
KDC-Z737 (M)
KDC-Z838 (M)
KRC-Z965 (M)
X838 (E)
123
4
2
3
1
5
8
4
12
7
3
11
6
2
10
5
1
9
13
9
10 7 85 63 41 2
FR
F GND
FL RL
R GND RR
FL
F GND N GND
NL
8
7
10
94 3
6
5
FR NR
1
2
RL R GND RL
0.01
C41
W113
C66
1u50
∗C46
∗C47 1
2
3
1
2
8
7
4
5
6
2
3
1
5
4
2
3
1
FL+B
FL+B
FL+B
A+9V A+9V
A+9V
A+9V
A+9V
A+9V
9VA
9VA
9VA
9VA
A9V
A9V
Q103
IC20
Q39Q40
Q41Q42
Q52
EJECT ILL
Q305
∗C76 4.7u16 ∗C77 4.7u16 ∗C57 4.7u16 ∗C56 4.7u16
C65
1u50
1u50
1u50
GND5
O CE2
REMO4
3 O DATA
O CLK1
92 D GND
CH RST
A GND
CH MUTE5
6
713
12
CH CON
B.U.3
411
10
REQ H18
REQ C
CH CLK
Lch
DATA H
DATA C
Rch
+
+
∗S1
CAUTION : For continued safety, replace safety critical components only with manufacturer's recommended parts (refer to parts list).
!Indicates safety critical components. To reduce the risk of electric shock, leakage-current or resistance measurements shall be
carried out (exposed parts are acceptably insulated from the supply circuit) before the appliance is returned to the customer.
•DC voltages are as measured with a high impedance voltmeter. Values may vary slightly due to variations between individual
instruments or/and units.
KDC-719/X559/Z737,Z638

UVWXYZAA AB AC AD
1
2
3
4
5
6
7
IC5
IC4
IC3
ED1
IC1
SWITCH UNIT (X16-168X-XX)
Z638/KDC-719/X559/Z737 (2/2)
IC2
KDC-X659/MP819/Z838 (2/2)
X838/KRC-Z965 (2/2)
A
1.3V
1.3V
2.5V
2.5V
0V
0V
5V
5.0V
0V
5V
5V
0V
5V
0V
5.0V
0V
0V
5V
5V
0V
5V
0V
0V
5V
5V
0V
0V
5.0V
0V
5.0V
5V
0V
5.0V
0V
5.0V
0V
0V
5V
5.0V
5V
0V
5V
0V
5V
0V
0V
5V 5V
0V
0V
0V
5V
1.3V
5.0V
3.3V
5.0V
0V
0V
3.3V
0V
3.3V
0V
5V
0V
5V
5.0V
0V
0V
0V
5V
45.3V
10K
10K
47K
10K
47K
47K
10K
10K
10K
10K
10K
10K
47K
10K
∗S9
∗S18
∗S7
∗S10 ∗S8
∗S17
∗S12
∗S2
∗S13
∗S16
∗S5
∗S19
∗S6
∗S3
∗S15
CP2
1Kx4
CP4
470x2
CP5
1Kx4
CP6
100x2
CP3
CP9
100Kx2
CP1
470x4
L4
W2
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
FAC
FAC
FL+B
FL GND
RST
AUDIO
PRST
SC DATA
MC CLK
SC REQ
MC REQ
SC CON
PAN5V
D GND
SRC
ESD GND
30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
100
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
51
52
53
54
55 56
57
58 59 60
61
62
63
64
65 66
67
68 69 70
71
72
73
74
75 76
77
78 79 80
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
NC NC NC NC NC NC NC NC NC
TEST
BLK
NC NC NC
REMO ON
GCP
LATCH
REMO
GREEN
RED
EVSS
EVDD
CLK IN
DATA2
NC
CLK
DATA1
NC
MC CLK
SC DATA
KS1
KS2
KS3
KS4
MC REQ
VREF CON
SOURCE
NC
SC CON
NC
SC REQ
KR1
KR2
KR3
KR4
KR5
WAVE IN
F06
F05
NC NC NC NC NC BLUE LED NC BVDD BVSS NC NC NC NC NC NC NC NC NC NC NC NC SA RST NC AVDD AVSS AVREF F01 F02 F03 F04
NC
NC
NC
RESET
XT1
XT2
REGC
X2
X1
VSS
VDD
NC
NC
NC
NC
NC
NC
FL VDD
FL +B
NC
1
2
3
4
5
6
7
8
9
R02
R01
LNNF
LNIN
RENF
REIN
RSTC
BISC
GND
18
17
16
15
14
13
12
11
10
RST
F01
F02
F03
F04
F05
F06
RELV
VCC
4.7uH
L1
C1 1
2.2
C6
100P
C7
15K
R16
10uH
L2
1
C10
0.01
C21
0.1
C20
1K
R25
0.1
C13
100
R43
100K
R21
2.2
C9
0.01
C17
0.01
C18
0.01
C19
3.9K
R50
3.9K
R48
2.2K
R49
100
R39
2.2K
R51
100
R42
100K
R12
15K
R27
0.01
C16
100Kx4
20.000MHz
X1
29
28 27
30
19
25
22
20 21
24 23
26
11
43
10
7
8
5
6
9
17
14
12 13
16 15
18
2
ab
2a
30a
G1
dc
G2G26 G25
fhg e
G24 G23
cdab
G47 G46
ghef
G44G45
fhg eg
G48
30g
2g
G3G4
cdba
G5
abcaddbcegfh
KR1
KR2
KR3
KR4
KR5
KS1
KS2
KS3
KS4
C12 1
R32 1K
R33 22K
R34 100K R35 100K
C8 10
F01
72
F02
F03
F05
F04
F06
91
95
2
89
1
34
KS4
KS3
KS2
KS1
F05
F06
83
KR5
KR4
KR3
KR2
KR1
91
89
95
100K
R36
10K
R1
CTL
GND
NIS
1
20.01
C2
3
IN
5
OUT
4
L9
270K
R14
270K
R13
83
R17 10
R15 15K
L13
39
40 45
44
43
BOUT
COUT
AOUT
7
C3 0.1
AIN15
2
1VCC
3
14 BIN
4
5
6
CIN
8GND
10
13
12
11
16
15
14
FIN
NC16
FOUT
EOUT
NC13
EIN
7
4
9
DOUT
DIN 5
100x2
CP7 100x4 CP8
2
GND
GND 4
VCC
OUT 1
3
F04
F03
F01
F02
72
1K
R10
16
13
R11 100
16 14 13
7
4 5
1
2
15
93
7 8
93
7
8
P5V
34
MODEL NAME
KDC-X659
KDC-MP819
KDC-X559
KDC-719
Z638
KDC-Z737
KDC-Z838
KRC-Z965
X838
K
E
M
UNIT
No.
2-71
0-00
12,13,15-19
S2,3,5-10,
S70-0873-05
(YG)
S70-0856-05
(SR/PG)
NO
YES
P5V
P5V
P5V
P5V
P5V
P5V P5V
P5V P5V
P5V
P5V
P5V
P5V
P5V
P5V P5V
P5V +3.3V
+B +B
+5V
+B
+5V
P5V
+5V
ef
+B
IC3
Q3
Q1,2
Q6
Q10
Q7,8
Q9
3
1
2F1
F1 F1
48 49 50 F2
F2 F2
2.2K
R9 56K R8
0.01
C5
34
35 36
37
38 39 40
41
42
43
44
45
SI2 SI1 CLK SO1 SO2 GCP LAT BK VDD1 VSS VSS VDD2
2.2
C4
22
R7
45
44
43 40
39
P5V
+3.3V+3.3V
S20
S11
S4
S14
Q6
Q3
Q4
Q2
Q1
Q8 Q7
Q9Q10
D10
D11
S1
TAR5S33
RS-171
IC4
IC1
IC2 TC74HC4050AFT
BA3830F
IC3
DA204UD1,2,15,16
IC5
D10,11 MA8056-M
UPD703032GFA04
D3-5,9,13,14 FTZ6.8E
DTA144EUA orQ1
D12
Q3,9,10
DTC114YUA or
MA8062-L
Q2
DTA114EUA or
DTC114YK orQ6
Q4
2SC4081
DTC114EUA or
Q7,8
J1
D2
D12
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
36 FM
25
14 SA
EQ TI AM
ATT DISP
SRC
RESET
D1
(X16-168X-XX)
A
1/2
X89-
J1
B LINE
GND LINE
SIGNAL LINE
3.3V AVR
BUFFER
REMOTE
SENSOR IC
SW
REMO
BPF IC
FL+B SW
KEY
ILLUMINATION
SW
BLANKING
FL
SW
KEY ILLUMINATION
PANEL MI-COM.
UN2214
UN5211
UN5111
UN5214
UN5113
V-I CONVERTER
GREEN SW KEY ILLUMINATION RED SW
∗ A
D3 D5
D14
D13
D4
D9
D15D16
KDC-719/X559/Z737,Z638
DTA123JK
DTA144EUA
DTC114YK
DTC114YUA
DTC143TUA
UN5111
UN5114
UN5211
UN5213
UN5214
UN5216
2SA1576A
2SB1548 2SB1277
2SB1443
2SA1037K
2SC4081 DTA114EUA DTA124EUA
DTC114EUA
DTC124EUA
DTC144EUA
NJM4565M-TE2
DAN202U DAP202U
DA204U
DTA114YUA
MA142WA
MA142WK
UN5212
RD6.8M TC74HC02AF BA3129F
BA3830F BA3121F M5237ML
BR24C02F-W TC74HC4050AFT
TDA7479D
CAUTION : For continued safety, replace safety critical components only
with manufacturer's recommended parts (refer to parts list).
!Indicates safety critical components. To reduce the risk of electric shock,
leakage-current or resistance measurements shall be carried out (exposed
parts are acceptably insulated from the supply circuit) before the appliance
is returned to the customer.
• DC voltages are as measured with a high impedance voltmeter. Values
may vary slightly due to variations between individual instruments or/and
units.

23
KDC-719/X559
/Z737,Z638
Parts with the exploded numbers larger than 700 are not supplied.
AB
3
2
1
281
RC2
DC1
A
B
C
D
E
F
G
H
J
K
L
N
:
:
:
:
:
:
:
:
:
:
:
:
N09-6006-05
N09-6053-05
N19-2168-05
N24-3020-46
N30-2003-46
N30-3006-45
N30-3010-46
N80-2006-46
N80-2008-45
N83-3005-46
N84-2606-46
N80-3008-46
φ2x3.5
M2.6x5
WASHER
RETAINING RING
M2x3
M3x6(BLK)
M3x10
φ2x6
φ2x8(BLK)
φ3x5
φ2.6x6
φ3x8
Depends on the model.
Refer to the parts list.
(X16-168X-XX)
(X89-253X-XX)
(X25-924X-XX)
200 213 260
RC1
280
282 DC2
DC3
220x2
F
F
x3
Kx2
J
J
K
K
K
KK
N
F1
Gx2
F
G
G
F
K
F
D
Bx2
B
C
LE
H
HH
Fx3
Fx2
K
J
J
K
A
A
202
746
759
DME1
FC1
235
233
232 234
754
740
739
739
743
253
251
223
226
222
221
786
762
225
755
227
224
227
261 229 252
203
215
214
204
708
273
270
272
275
274
271 277
276
741
784
207
250
268
205
701
763
738
785
245 x2
245 x2
245 x2
245 x2
K
793
(X25-)
W9
(X25-)
A1
(X25-)
794
(X25-)
797
(X25-)
795
(X25-)
796
(X25-)
792
(X25-)
798
(X25-)
PA1
EXPLODEDVIEW

24
KDC-719/X559
/Z737,Z638
!
Indicates safety critical components.
✽New parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No. A d
d
N
e
wParts No. Description Desti-
nation Ref. No. A
d
d
N
e
wParts No. Description Desti-
nation
K2 : KDC-719 K4 : KDC-X559 M2 : KDC-Z737 E1 : Z638
!
200 1A ✽ A02-2712-13 PLASTIC CABINET ASSY
202 1B ✽ A52-0811-12 TOP PLATE
203 2A ✽ A21-4175-04 DRESSING PANEL
204 2A ✽ A21-4209-02 DRESSING PANEL K2E1M2
204 2A ✽ A21-4210-02 DRESSING PANEL K4
205 3A ✽ A22-2946-12 SUB PANEL ASSY
207 1B ✽ A46-1756-11 REAR COVER
PA1 2A ✽ A64-2646-11 PANEL ASSY K2
PA1 2A ✽ A64-2647-11 PANEL ASSY E1
PA1 2A ✽ A64-2648-11 PANEL ASSY M2
PA1 2A ✽ A64-2650-11 PANEL ASSY K4
RC1 1A A70-2025-05 REMOTE CONTROLLER ASSY (RC-410) K2K4
RC2 1A ✽ A70-2026-05 REMOTE CONTROLLER ASSY (RC-420) E1M2
213 1A ✽ B07-3050-02 ESCUTCHEON K2E1M2
213 1A ✽ B07-3057-02 ESCUTCHEON K4
214 2A ✽ B10-4209-01 FRONT GLASS K2
214 2A ✽ B10-4210-01 FRONT GLASS E1
214 2A ✽ B10-4211-01 FRONT GLASS M2
214 2A ✽ B10-4213-01 FRONT GLASS K4
215 2A ✽ B10-4217-04 FRONT GLASS
- B46-0100-50 WARRANTY CARD
- B46-0606-04 ID CARD K2K4
- B46-0612-14 ID CARD E1M2
- B46-0645-03 USER CARD K2K4
- B46-0648-03 USER CARD K4
- B58-1365-04 CAUTION CARD
- ✽ B64-2176-00 INST. MANUAL (ENGLISH) K2K4
- ✽ B64-2177-00 INST. MANUAL (FRE,SPA) K2K4
- ✽ B64-2178-00 INST. MANUAL (ENG,T-CHI) M2
- ✽ B64-2180-00 INST. MANUAL (ENGLISH) E1
- ✽ B64-2181-00 INST. MANUAL (FRE,GER) E1
- ✽ B64-2182-00 INST. MANUAL (DUT,ITA) E1
- ✽ B64-2183-00 INST. MANUAL (SPA,POR) E1
220 1A ✽ D10-4674-04 LEVER
221 3A ✽ D10-4675-04 LEVER
222 3A ✽ D10-4676-04 LEVER
223 3A ✽ D10-4677-04 LEVER
224 3A ✽ D10-4678-03 LEVER
225 3A ✽ D13-2242-04 GEAR
226 3A ✽ D21-2406-04 SHAFT
227 3A ✽ D21-2407-04 SHAFT
229 3A D39-0237-05 DAMPER
232 2B ✽ E30-6064-05 CORD WITH PINPLUG (6P) K4
232 2B ✽ E30-6065-05 CORD WITH PINPLUG (4P) K2E1M2
233 2B ✽ E30-6067-15 CORD WITH PINPLUG (AUX 2P) K4M2
234 2B ✽ E30-6068-05 CORD WITH DIN CONNECTOR (13P)
235 2B ✽ E30-6069-05 CORD WITH DIN CONNECTOR (4P) E1
DC1 1A ✽ E30-6062-05 DC CORD K4M2
DC2 1A ✽ E30-6106-05 DC CORD K2
DC3 1A ✽ E30-6063-05 DC CORD E1
FC1 2B ✽ E39-0447-05 FLAT CABLE (24P)
245 2B F29-0049-05 INSULATING COVER
F1 2B F52-0006-05 FUSE (MINI BLADE TYPE) (10A)
F1 2B F52-0011-05 FUSE (MINI BLADE TYPE) (10A)
250 2A ✽ G01-3135-04 COMPRESSION SPRING
251 3A ✽ G01-3136-14 EXTENSION SPRING
252 3A ✽ G02-1428-04 FLAT SPRING
253 3B ✽ G02-1429-04 FLAT SPRING
- ✽ H10-4802-12 POLYSTYRENE FOAMED FIXTURE
- H25-0329-04 PROTECTION BAG (280X450X0.03) K2K4M2
- H25-0337-04 PROTECTION BAG (180X300X0.03)
- H25-1111-04 PROTECTION BAG (280X450X0.03) E1
- ✽ H54-2320-03 ITEM CARTON CASE K2
- ✽ H54-2321-03 ITEM CARTON CASE E1
- ✽ H54-2322-03 ITEM CARTON CASE M2
- ✽ H54-2324-03 ITEM CARTON CASE K4
260 1A ✽ J21-9823-03 MOUNTING HARDWARE ASSY
261 3A ✽ J21-9831-04 MOUNTING HARDWARE ASSY
268 2A ✽ K24-3837-04 KNOB (OPEN)
270 2A ✽ K24-3850-04 KNOB (SKIP UP) K2E1M2
270 2A ✽ K24-3852-04 KNOB (SKIP UP) K4
271 2A ✽ K24-3851-04 KNOB (SKIP DOWN) K2E1M2
271 2A ✽ K24-3853-04 KNOB (SKIP DOWN) K4
272 2A ✽ K25-1417-13 KNOB (EQ,SRC)
273 2A ✽ K25-1418-03 KNOB (PAUSE)
274 2A ✽ K25-1423-03 KNOB (VOL)
275 2A ✽ K25-1428-03 KNOB (PRE1-3,ATT,Q) K4
275 2A ✽ K25-1456-03 KNOB (PRE1-3) K2E1M2
276 2A ✽ K25-1420-03 KNOB (PRE4-6,TI,DISP) E1
276 2A ✽ K25-1429-03 KNOB (PRE4-6,AUTO,DISP) K4
276 2A ✽ K25-1457-03 KNOB (PRE4-6) K2M2
277 2A ✽ K25-1458-13 KNOB (FM,AM) K4
277 2A ✽ K25-1459-13 KNOB (FM,AM) K2E1M2
280 1A N99-1656-05 SCREW SET
281 1A N99-1723-05 SCREW SET K2K4M2
A 1B N09-6006-05 TAPTITE SCREW (PAN ST 2X3.5T)
B3A ✽ N09-6053-05 MACHINE SCREW (M2.6X5)
C3A ✽ N19-2168-05 FLAT WASHER (1.4X3.0X0.25)
D 3A N24-3020-46 E TYPE RETAINING RING (2X5X1.7)
E 3A N30-2003-46 PAN HEAD MACHINE SCREW
F 1B N30-3006-45 PAN HEAD MACHINE SCREW
G 3B N30-3010-46 PAN HEAD MACHINE SCREW
H 2A N80-2006-46 PAN HEAD TAPTITE SCREW
J 1A N80-2008-45 PAN HEAD TAPTITE SCREW
K 1B N83-3005-46 PAN HEAD TAPTITE SCREW
L 3A N84-2606-46 PAN HEAD TAPTITE SCREW
282 1A T90-0523-05 ANTENNA ADAPTOR E1
282 1A T90-0534-05 ANTENNA ADAPTOR E1
282 1A ✽ T90-0552-05 ANTENNA ADAPTOR E1
DME1 1B ✽ X92-4450-01 MECHANISM ASSY (DXM-6111W)
C1 CK73FB1A105K CHIP C 1.0UF K
C2 CK73GB1H103K CHIP C 0.010UF K
C3 CK73GB1C104K CHIP C 0.10UF K
!
!
!
!
KDC-719/X559/Z737,Z638
SWITCH UNIT (X16-168x-xx)
PARTS LIST

✽New parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
PARTS LIST
25
KDC-719/X559
/Z737,Z638
SWITCH UNIT (X16-168x-xx)
Ref. No. A d
d
N
e
wParts No. Description Desti-
nation Ref. No. A
d
d
N
e
wParts No. Description Desti-
nation
C4 CK73FB1A225K CHIP C 2.2UF K
C5 CK73GB1H103K CHIP C 0.010UF K
C6 CK73FB1A225K CHIP C 2.2UF K
C7 CC73GCH1H101J CHIP C 100PF J
C8 CK73EB0J106K CHIP C 10UF K
C9 CK73FB1A225K CHIP C 2.2UF K
C10 CK73FB1A105K CHIP C 1.0UF K
C12 CK73FB1A105K CHIP C 1.0UF K
C13 CK73GB1C104K CHIP C 0.10UF K
C16-19 CK73GB1H103K CHIP C 0.010UF K
C20 CK73GB1H104K CHIP C 0.10UF K
C21 CK73GB1H103K CHIP C 0.010UF K
J1 E59-0829-05 RECTANGULAR PLUG (16P)
L1 L40-4795-68 SMALL FIXED INDUCTOR (4.7UH)
L2 ✽ L40-1005-68 SMALL FIXED INDUCTOR (10UH)
L4 L92-0332-05 CHIP FERRITE
L9 L92-0332-05 CHIP FERRITE
L13 L92-0332-05 CHIP FERRITE
X1 L78-0821-05 RESONATOR (20.0MHZ)
CP1 R90-1016-05 MULTI-COMP 470 X4
CP2 R90-0724-05 MULTI-COMP 1K X4
CP3 R90-0720-05 MULTI-COMP 100K X4
CP4 R90-1022-05 MULTI-COMP 470 X2
CP5 R90-0724-05 MULTI-COMP 1K X4
CP6,7 R90-1019-05 MULTI-COMP 100 X2
CP8 R90-1014-05 MULTI-COMP 100 X4
CP9 R90-0737-05 MULTI-COMP 100K X2
R1 RK73GB2A103J CHIP R 10K J 1/10W
R7 ✽ RK73GB2A220J CHIP R 22 J 1/10W
R8 RK73GB2A563J CHIP R 56K J 1/10W
R9 RK73GB2A222J CHIP R 2.2K J 1/10W
R10 RK73GB2A102J CHIP R 1.0K J 1/10W
R11 RK73GB2A101J CHIP R 100 J 1/10W
R12 RK73GB2A104J CHIP R 100K J 1/10W
R13,14 ✽ RK73GB2A274J CHIP R 270K J 1/10W
R15,16 RK73GB2A153J CHIP R 15K J 1/10W
R17 RK73GB2A100J CHIP R 10 J 1/10W
R21 RK73GB2A104J CHIP R 100K J 1/10W
R25 RK73GB2A102J CHIP R 1.0K J 1/10W
R27 RK73GB2A153J CHIP R 15K J 1/10W
R32 RK73GB2A102J CHIP R 1.0K J 1/10W
R33 RK73GB2A223J CHIP R 22K J 1/10W
R34-36 RK73GB2A104J CHIP R 100K J 1/10W
R39 RK73GB2A101J CHIP R 100 J 1/10W
R42 RK73GB2A101J CHIP R 100 J 1/10W E1M2
R43 RK73GB2A101J CHIP R 100 J 1/10W
R48 RK73GB2A392J CHIP R 3.9K J 1/10W
R49 RK73GB2A222J CHIP R 2.2K J 1/10W
R50 RK73GB2A392J CHIP R 3.9K J 1/10W E1M2
R51 RK73GB2A222J CHIP R 2.2K J 1/10W E1M2
W2 R92-1252-05 CHIP R 0 OHM J 1/16W
S1 S70-0863-05 TACT SWITCH
S2,3 S70-0856-05 TACT SWITCH E1M2
S2,3 S70-0873-05 TACT SWITCH K2K4
S4 S70-0857-05 TACT SWITCH
S5-10 S70-0856-05 TACT SWITCH E1M2
S5-10 S70-0873-05 TACT SWITCH K2K4
S11 S70-0857-05 TACT SWITCH
S12,13 S70-0856-05 TACT SWITCH E1M2
S12,13 S70-0873-05 TACT SWITCH K2K4
S14 S70-0857-05 TACT SWITCH
S15-19 S70-0856-05 TACT SWITCH E1M2
S15-19 S70-0873-05 TACT SWITCH K2K4
S20 S70-0857-05 TACT SWITCH
D1,2 DA204U DIODE
D3-5 MA8056-M ZENER DIODE
D9 MA8056-M ZENER DIODE
D10,11 FTZ6.8E ZENER DIODE
D12 MA8062-L ZENER DIODE
D13,14 MA8056-M ZENER DIODE
D15,16 DA204U DIODE
ED1 ✽ CN2034M FLUORESCENT INDICATOR TUBE
IC1 ✽ TAR5S33 ANALOGUE IC
IC2 TC74HC4050AFT MOS-IC
IC3 RS-171 ANALOGUE IC
IC4 BA3830F ANALOGUE IC
IC5 ✽ UPD703032GFA04 MI-COM IC
Q1 DTA144EUA DIGITAL TRANSISTOR
Q1 UN5113 DIGITAL TRANSISTOR
Q2 DTC114YUA DIGITAL TRANSISTOR
Q2 UN5214 DIGITAL TRANSISTOR
Q3 DTA114EUA DIGITAL TRANSISTOR
Q3 UN5111 DIGITAL TRANSISTOR
Q4 DTC114EUA DIGITAL TRANSISTOR
Q4 UN5211 DIGITAL TRANSISTOR
Q6 DTC114YK DIGITAL TRANSISTOR
Q6 UN2214 DIGITAL TRANSISTOR
Q7 2SC4081 TRANSISTOR
Q8 2SC4081 TRANSISTOR E1M2
Q9 DTA114EUA DIGITAL TRANSISTOR K2K4
Q9 UN5111 DIGITAL TRANSISTOR K2K4
Q9,10 DTA114EUA DIGITAL TRANSISTOR E1M2
Q9,10 UN5111 DIGITAL TRANSISTOR E1M2
D101 B30-1566-05 LED (1608,RED)
C1 C90-2822-05 ELECTRO 3900UF 16WV K2E1M2
C1 C90-5377-05 ELECTRO 3900UF 16WV K4
C2 CK73GB1H103K CHIP C 0.010UF K
C3 CK73GB1C104K CHIP C 0.10UF K
C4 ✽ C90-5442-05 ELECTRO 100UF 10WV
C5,6 CE04NW1E4R7M ELECTRO 4.7UF 25WV K4M2
C7 CK73FB1C105K CHIP C 1.0UF K
C8 CE04DW1A221M ELECTRO 220UF 10WV
C9 CK73FB1C224K CHIP C 0.22UF K
C10 CK73GB1H103K CHIP C 0.010UF K
!
Indicates safety critical components.K2 : KDC-719 K4 : KDC-X559 M2 : KDC-Z737 E1 : Z638
ELECTRIC UNIT (X25-924x-xx)
