Kenwood KDC-M7024 User manual

CD mechanism extension cord : W05-0935-00
CD mechanism operation description is
not in this service manual.
Please, refer to service manual X92-
4030-0x (B51-7867-00).
Mounting hardware assy
(J21-9823-03) DC cord (ISO)
(E30-4942-05)
: KDC-M7024
Remote controller assy
(RC-505)
(A70-2040-05)
: KDC-MP822
DC cord
(E30-6106-05)
: KDC-MP822
Lever
(D10-4674-04) x 2
Plastic cabinet assy
(A02-2731-03)
Screw set
(N99-1723-05)
: KDC-MP822
Screw set
(N99-1734-05) Antenna adaptor
(T90-0552-05)
: KDC-M7024
Size AA battery
(Not supplied)
Escutcheon
(B07-3078-01)
50 4W
DIGITAL AUDIO
COMPACT
50 4W
DIGITAL AUDIO
COMPACT
Panel assy
(A64-2978-01): KDC-MP822
Escutcheon
(B07-3078-01)
Panel assy
(A64-2995-02):
KDC-MP822
Panel assy
(A64-2986-01): KDC-M7024
Panel assy
(A64-3003-02):
KDC-M7024
Escutcheon
(B07-3078-01)
© 2003-2 PRINTED IN JAPAN
B53-0035-00 (N)3114
CD RECEIVER
KDC-M7024
KDC-MP822
SERVICE MANUAL

3
HOWTOTHE PANEL MECHANISM ASSEMBLY
1. Fixed the position of operation side
(Fixed the horizontal position when the panel opened)
qThe mounting hardware (281) of operation side is rota-
tion (A) into the stop position with close side.
wAs figure (B) line is just above and the gear (230) at-
tached to pin.
B
A
Rotary to the
stop position
281
230
This line attached just above
Fig. B
(This figure from look at B arrow)
C
284
702
SW
D
E
F
702
SW
284
2. The slider assembly insert to bottom chassis
qThe bracket for display panel (284) is leave down, in-
sert to the chassis (702). (C)
wThe slider assembly insert to the chassis (702) after
that shift (D) direction.
eThe bracket for display panel (284) is raised (E) direc-
tion.
rKeep the raising conditions, the slider assembly is shift
(F) direction.
(Note) Do not bend the knob of chassis detection switch
when the slider assembly insert.
KDC-M7024/MP822

KDC-M7024/MP822
3
BLOCK DIAGRAM
RESET SW
KEY MATRIX KEY ILL
ROTARY
ENCODER
LCD DRIVER
IC2
SW5V
Q6
PANEL
IC3
REMOCON
WITH
LCD DRIVER
IC1
KEY MATRIX
LCD
BUFFER
RDS
DECODER
BUFFER
u-COM
MPX
E-VOL
&
ACC DET
TEL MUTE
B.U DET
DRIVER
MUTE
POWER
IC
ACC
TEL MUTE
BACK UP
SP OUT (FL)
RESET
IC12
IC2
IC1
IC4
IC7
Q102,103
AM+B
PRE MUTE
PRE MUTE
PRE MUTE
PRE OUT
(FRONT)
PRE OUT
(REAR)
(NF)
PRE OUT
SP OUT (FR)
SP OUT (RL)
SP OUT (RR)
EXT AMP
DIMMER DIMMER
EXT.AMP.CON
ANT-CON ANT CON
P-CON P CON
WIRED REMO/
OPEL DISP I/F
IC8
Q59,60
Q55,56
Q57,58
BU5V
SW 5V
SW 14V
SERVO
ILL+B
SW REG
A8V
Q1,2
Q3
Q4,5
Q6-8
Q9,34
BU5V
SW5V
SW14V
A8V
SERVO
CD5.0V
IC14
MOTOR
DRDR
MOTOR
IC13
EEPROM
EEP5V
Q501
IC1
Q23,24
Q30
Q29
Q25,26
Q32
Q33
Q11-14
IC5
Q104
Q53
KEY
BU5V
BU5V BU5V BU5V
S-METER
AUDIO OUT
SERVO
8V
BU5V
CD4.7V
BACK UP
FM
AM
CD
QUAL
CH
BU5V
8V
SW5V
8V 8V
SW5V
8V
SW5V
BU5V
BU5V
BU5V
SERVO
(X16-214)
(X16-219)
SWITCH UNIT
DISPLAY UNIT
TUNER
CD
CH
MECHA
PANEL
TDF UNIT (X16-208)
(X25-966)

KDC-M7024/MP822
4
● SUB-CIRCUIT UNIT (X16-2080-10)
Ref. No. Application/Function Operation/Condition/Compatibility
IC1 E2PROM For security
● SUB-CIRCUIT UNIT (X16-2140-10)
Ref. No. Application/Function Operation/Condition/Compatibility
IC1 LCD driver KEY Input
IC2 LCD driver
IC3 Remote control sensor
Q1 KEY scan start SW ON when the base goes “L”.
Q5, D26 VLCD AVR
Q6 Remote control sensor power supply SW ON when the base goes “L”.
Q11 Dimmer control LCD back light control. OFF when the base goes “L”, ON when the base goes“H”.
● SWITCH UNIT (X16-2190-10)
Ref. No. Application/Function Operation/Condition/Compatibility
Q1 DSI (Disabled System Indicator) DSI blinks when the base goes “H/L”
Q2 KEY illumination SW (GREEN) ON (KEY illumination green) when the base goes “H”
Q3 KEY illumination SW (RED) ON (KEY illumination red) when the base goes “H”
● ELECTRIC UNIT (X25-966x-xx)
Ref. No. Application/Function Operation/Condition/Compatibility
IC1 System µ-com
IC2 E-vol & N.C. & MPX
IC3 Regulator IC for A8V
IC4 Power IC
IC5 Swiching regulator IC for CD5V
IC7 Reset IC
IC8 Logic IC for muting
IC12 RDS decoder IC
IC13, 14 Motor driver IC for panel mechanism
IC15 ROM IC For ROM correction.
Q1, 2 B.U.5V AVR While BU is applied, BU5V AVR outputs +5V.
Q3 SW5V When Q3’base goes Lo, SW5V outputs +5V.
Q4, 5 SW14V When Q5’base goes Hi, SW14V outputs 14V.
Q6~8 AUDIO 8V AVR When Q6’base goes Hi, A8V AVR outputs 8.4V.
Q9, 34 SERVO+B AVR When Q34’base goes Hi, S+B AVR outputs 7.4V.
Q10 SW for IC5 When Q10’base gose Hi, Q10 is turned on.
Q11~14 ILL+B AVR When Q11’base goes Hi, AVR outputs 10.5V.
Q23, 24 P-ANT SW When Q23’base goes Hi, P-ANT SW outputs 14V.
Q25, 26 P-CON SW When Q26’base goes Hi, P-CON SW outputs 14V.
Q27, 28 P-CON protection Protect Q27 by turning on when P-CON output is grounded.
Q29 Ex Amp control buffer
Q30 Small lamp det SW When Q30’base goes Hi, Q30 is turned on.
Q32 BU det When Q32’base gose Hi, Q32 is turned on.
Q33 ACC det When Q33’base gose Hi, Q33 is turned on.
Q51, 52 Mute driver When a base gose Lo, mute driver is turned on.
COMPONENTS DESCRIPTION

KDC-M7024/MP822
5
Ref. No. Application/Function Operation/Condition/Compatibility
Q53 Noise buffer
Q54 E-vol mute SW When a base gose Hi, mute SW is turned on.
Q55~60 Pre-out mute SW When a base gose Hi, Pre-out is muted.
Q63 E2P 5V SW When Q63’base gose Lo, E2P 5V is out.
Q102, 103 AM+B SW When Q102’base gose Hi, AM+B is out.
Q104 Composite signal buffer for RDS
COMPONENTS DESCRIPTION
MICROCOMPUTER’STERMINAL DESCRIPTION
● SYSTEM MICROCOMPUTER : UPD703030GC014 (X25-966 : IC1)
Pin No. Pin Name I/O Module Purpose / Description Truth table Processing Operation
1 PLL_DATA I/O Tuner Data output/input with F/E.
2 AM+B I/O Power supply AM+B. AM operation : H
3 (FM+B) O Power supply FM+B (S01 F/E only). FM operation :H,
Last FM : H (With RDS, RBDS model)
4 V_ILL PAN_E2P DATA I/O To panel V-ILL D/A converter (V-ILL, LCD), E2PROM data.
5 V_ILL PAN_E2P CLK I/O To panel V-ILL D/A converter (V-ILL, LCD), E2PROM clock.
6 EVDD -
7 EVSS -
8 AFS O Tuner Noise detection time constant switching. FM seek, AF search :L, Receiving : H, Auto 0 : L
9 BEEP O Audio Beep output.
10 REMO I Extra Remote control input (Panel, External display).
11 P_MUTE O Audio Power IC MUTE output. Power OFF : L, All OFF : L, TEL mute :L
12 (SVR) O Audio Power IC SVR discharge circuit control. Power OFF momentary power dropped
: H (5 second) and then L
CD CD mechanism data line.
13 IC2_SDA I/O Audio IC2 data line.
Extra ROM correction data line.
CD CD mechanism clock line.
14 IC2_CLK I/O Audio IC2 clock line.
Extra ROM correction clock line.
15 P_STBY O Audio Power IC STBY output. Power IC ON : H, Power IC OFF : L, All OFF : H
16 P_CON I/O Extra Power control. Power ON : H, Power OFF : Hi-Z, All OFF :Hi-Z
17 DIMMER_CONT O To panel Dimmer control (W-LED only). Dimmer : Pulse control,
Frequency : 1kHz, Normally : H
18 TEST - Connect to GND.
19 NC O Extra NC (MP3 mechanism model). wOutput : L
20 MUTE O Audio Mute output. ON : OPEN, OFF : L
21 PRE_MUTEL O Audio PREOUT (L ch) mute.
M MUTE L is L : L (CD), Momentary power
dropped : L, 2 zone, NAVI interrupt : Fixed H
22 PRE_MUTER O Audio PREOUT (R ch) mute.
M MUTE R is L : L (CD), Momentary power
dropped : L, 2 zone, NAVI interrupt : Fixed H

KDC-M7024/MP822
6
Pin No. Pin Name I/O Module Purpose / Description Truth table Processing Operation
23 BU_DET I Extra Momentary power dropped detection. Backup : L,
No backup, momentary power dropped : H
24 ACC_DET I Extra ACC detection. With ACC : L,Without ACC : H
25 SW5V I/O Power supply 5V power supply. ON : L, OFF : Hi-Z
26
EXT_AMP_CONT O Extra External amplifier control. Refer to external amplifier control.
NC O NC (Without EXT_AMP_CONT model) Output : L
27 DIMMER I Extra Small lamp detection. ON : L, OFF : H
28 ANT_CON O Extra Antenna control. w
Tuner ON : H, Other source With RDS last FM
:H, Other source with RDBS TI ON last FM :H
29 P_ON I/O Power supply
SW 14V, SW 5V control, AD reference Power ON : H, Power OFF : Hi-Z
voltage control output.
30 ILL_ON I/O Power supply FL, illumination output. ON : H, OFF : Hi-Z
31 RESET -
32 XT1 - Sub clock. 32.768kHz
33 XT2 - Sub clock. 32.768kHz
34 REGC - Connect to 1µF capacitor.
35 X2 - Main clock. 20MHz
36 X1 - Main clock. 20MHz
37 VSS -
38 VDD -
39 CLKOUT -
40 LX_REQ_M O LX Communication request to external slave. Request : L
41 LX_MUTE I LX Mute request from external slave. Mute ON : H
42 LX_CON O LX External slave select. ON : H, OFF : L
43 LX_RST O LX Reset output to external slave µ-com. Normally : L, After system reset : H (400ms
or more) and then L
CD source : H, Except CD source : L,
44 CD_MECHA+B I/O Power supply DC 5.0V output. ON : Fast 50ms than M_STOP,
OFF : Slow 50ms than M_STOP
45 TYPE0 I Extra Destination select. w
46 TYPE1 I Extra Destination select. w
47 IC2_TYPE0 I Extra IC2 destination. w
48 IC2_TYPE1 I Extra IC2 destination. w
49 NC O NC Output : L
50 E2P5V I/O Power supply E2PROM, DA converter power supply control. ON : L, OFF : Hi-Z
51 DSI I/O To panel DSI control. ON : L, OFF : Hi-Z
52 L_CE O To panel Chip enable output to LCD driver.
53 L_INH O To panel Inhibit signal output to LCD driver. Normally : H, Reset, momentary power dropped : L
54 VOL A I To panel VOL input.
55 BVDD -
56 BVSS -
57 VOL B I To panel VOL input.
58 M_RST O CD Reset output to CD mechanism. Normally : H, Reset : L (Per mechanism control)
59 M_STOP O CD Stop request to CD mechanism. Stop : L, CD : H
60 CD_SW3 I CD DC down switch detection. Chucking :H
61 LO/EJ I/O CD CD mechanism loading/eject switch. Stop, brake : Hi-Z, Loading :L, Eject : H
62 MOSW O CD CD mechanism motor driver switch. Loading, eject, brake : H
MICROCOMPUTER’S TERMINAL DESCRIPTION

KDC-M7024/MP822
7
Pin No. Pin Name I/O Module Purpose / Description Truth table Processing Operation
63 FPM MOTOR B O P-mecha FPM mechanism (Slider) control. e
64 FPM MOTOR F O P-mecha FPM mechanism (Slider) control. e
65 FPM MOTOR O O P-mecha FPM mechanism (Angle) control. e
66 FPM MOTOR C O P-mecha FPM mechanism (Angle) control. e
67 O_DATA I/O Extra External display data input/output. External display
NC O NC (Without external display model) Output : L
68 O_CLK I/O Extra External display clock input/output. External display
NC O NC (Without external display model) Output : L
69 O_CE I/O Extra External display chip enable input/output. External display
NC O NC (Without external display model) Output : L
70 M_MUTER I CD Mute request form CD mechanism.(R ch). ON : L (CD)
71 AVDD -
72 AVSS -
73 AVREF - Connect to P_ON (29 pin).
74 M_MUTEL I CD Mute request form CD mechanism.(L ch). ON : L (CD)
75 PAN_DET I To panel Panel E2PROM detection. With : L, Without :H
PHONE I Extra PHONE detection.
TEL mute :1V or less, NAVI mute : 2.5V or more,
76 J type 1V or less, 2.5V or more : NAVI mute
NC I NC (Without TEL-MUTE model) Connect to GND.
77 FPM SW4 I P-mecha FPM mechanism position detection, e3.75V or more : No mechanism,
mechanism detection. 1.25V or more : H, Less than 1.25V : L
78 FPM SW1 I P-mecha FPM mechanism position detection. e
79 FPM SW2 I P-mecha FPM mechanism position detection. e
80 FPM SW3 I P-mecha FPM mechanism position detection. e
81 FPM PHOUT I P-mecha FPM mechanism position detection. eH : 2.2V or more
82 S_METER I Tuner S-meter detection. Refer to S03 F/E control.
83 NOISE I Tuner FM noise detection. Refer to S03 F/E control.
84 IFC_OUT I Tuner F/E IFC OUT input. With station : 2.5V or more, refer to S03 F/E control.
85 NC (POWER_DET) I Extra Power IC DC offset detection. 03 model not used. Connect to GND.
86 NC O NC (Except J type) Output : L
87 R_CLK I Tuner RDS decoder clock input.
NC I NC (Without RDS, RBDS model) Connecto to GND.
88 LX_REQ_S I LX Receive request from external slave. Request : L
89 KEY_REQ I To panel Communication request from LCD driver
90 CD_SW1 I CD Loading switch detection. Loading start power off :L
91 CD_SW2 I CD 12cm disc detection switch. 12cm disc power off :L
92 R_QUAL I Tuner RDS decoder QUAL input.
NC I NC (Without RDS, RBDS model) Connecto to GND.
93 R_DATA I Tuner RDS decoder data input.
NC I NC (Without RDS, RBDS model) Connecto to GND.
94 LX_DATA_S I LX Data input from external slave.
95 LX_DATA_M O LX Data output to external slave.
96 LX_CLK I/O LX Clock input/output with external slave.
97 L_DATAL I To panel Data input from LCD driver.
98 L_DATAS O To panel Data output to LCD driver.
99 L_CLK O To panel Clock output to LCD driver.
100 PLL_CLK I/O Tuner Clock input/output with F/E.
MICROCOMPUTER’STERMINAL DESCRIPTION

KDC-M7024/MP822
8
Truth table
w Destination port
MODEL Destination DISPLAY TYPE2 TYPE1 TYPE0
KDC-X969 K FL 0 0 0
KDC-MP922 K FL 0 0 1
FX-9000 J FL 0 1 0
KDC-PSW9524 E FL 1 0 0
KDC-9023R M (E) FL 1 0 1
KDC-X869 K FL 0 1 1
KDC-8024 E FL - - -
KDC-MP822 K LCD - 0 0
KDC-M7024 E LCD - 0 1
FX-5000 J LCD - 1 0
KDC-V7022 K LCD 0 0 0
KDC-X769 K LCD 0 0 1
KDC-722 K LCD 0 1 0
KDC-7024 E LCD 0 1 1
KDC-7024Y
KDC-8023 M (K) LCD 1 0 0
Note :When FL model usingTYPE2, K & J type (with ANT_CON model) : L, E type (without ANT_CON model) :H
Destination(IC2)
TYPE0 TYPE1
Market model L L
Market model CRSC modiification L H
OEM model CRSC modification H L
OEM model CRSC and de-emphasis modification H H
eFPM MOTOR
Slide FPM mechanism operation
FPM MOTOR B FPM MOTOR F
0 0 Standby
1 0 Backward operation
0 1 Forward operation
1 1 Brake
Angle FPM mechanism operation
FPM MOTOR O FPM MOTOR C
0 0 Standby
1 0 Angle open direction
0 1 Angle close direction
1 1 Brake
MICROCOMPUTER’S TERMINAL DESCRIPTION

KDC-M7024/MP822
9
● MECHANISM MICROCOMPUTER : 703033BYGC-J02 (X32-541 : IC7)
Pin No. Pin Name I/O Use Processing Operation STBY
Processing
1 NC O Not used. Fixed Low Low
2 E2P_SCL O ROM correction E2P IC2 clock. Hi-Z
3~5 NC O Not used. Fixed Low Low
6 VDD - 5V
7 GND - GND
8, 9 NC O Not used. Fixed Low Low
10 PON O Power ON/OFF control. H : ON, L : OFF Low
11 /PON O Power ON/OFF control. H : OFF, L :ON High
12 LOE/LIM_SW I Down limit switch detection. L : Most Inner position detection Hi-Z
13 8EjE_SW I Not used. Fixed Low Hi-Z
14 LOS_SW I Not used. Fixed Low Hi-Z
15 12EjE_SW I Not used. Fixed Low Hi-Z
16, 17 NC O Not used. Fixed Low Low
18 IC/Vpp - Write voltage (Flash). -
19 MUTE_L O L ch audio mute control. L : Mute ON, H : Mute OFF Low
20 MUTE_R O R ch audio mute conrol. L : Mute ON, H : Mute OFF Low
21~25 NC O Not used. Fixed Low Low
26 EFLG I WMA error detection. H : Error, L : No error Hi-Z
27 WAIT I Wait control signal detection. Hi-Z
28 FOK I Focus condition detection. H : Focus OK, L : Focus NG Hi-Z
29, 30 NC O Not used. Fixed Low Low
31 RESET I Reset detection. H : Normal, L :Reset Hi-Z
32 XT1 I Not used. Hi-Z
33 XT2 - Not used. -
34 REGC -
35 X2 -
36 X1 I Hi-Z
37 Vss - GND
38 VDD - 5V
39 NC O NC Output stop. Low
40 WRL O Multiplex WRITE signal. _LBEN : 61002 (Not used), _WRL : 63760 Out-Low
41 NC O Not used. Fixed Low Low
42 R/W O Multiplex _R/W signal _R/W : 61002, _WRH : 63760 (Not used) Out-Low
43 DSTB,RD O Multiplex DSTB or RD signal _DSTB : 61002, _RD : 63760 Out-Low
44 ASTB O Multiplex ASTB signal Out-Low
45, 46 NC O Not used. Fixed Low Low
47~54 AD0~AD7 I/O Multiplex address/data Out-Low
55 BVdd - Bus interface power supply.
MICROCOMPUTER’STERMINAL DESCRIPTION

KDC-M7024/MP822
10
Pin No. Pin Name I/O Use Processing Operation STBY
Processing
56 BVss - Bus interface GND.
57~64 AD8~AD15 I/O Multiplex data/address Out-Low
65 /HCSB O Chip select control. H : OFF, L : ON Low
66 /CS O Chip select control. H : OFF, L : ON Low
67 DSP RESET O DSP reset control. H : Normal. L :Reset Low
68 REQ I Data transfer request input. Hi-Z
69 DBBWRDY0 I DBB00 register write permission input. Hi-Z
70 DBBRRDY0 I DBB00 register read permission input. Hi-Z
71 Avdd -
72 Avss -
73 Avref I A/D port reference voltage input.
74 WTS I WMA table select. H : WMA8 table, L :WMA9 table Hi-Z
75 MDL_SEL I Model port changeover. H : 03 model, L : 02 model Hi-Z
76, 77 NC I Not used. Fixed Low Hi-Z
78 HOT I Temperature rise detection. Detection voltage :4V, Reset voltage 3.9V Hi-Z
79 NC I Not used. Fixed Low Hi-Z
80 WMA I WMA correspond changeover. H : DXM6500 (WithWMA), L :DXM6400 (Without WMA) Hi-Z
81 NC I Not used. Hi-Z
82 ASEL I Audio output pole changeover. H : Invert output, L : Normal output Hi-Z
83 DASC I Shock proof changeover. H : Shock proof OFF, L : Shock proof ON Hi-Z
84 E2P_WR I E2PROM write changeover. H : E2PROM write, L : Normal Hi-Z
85 PIC_SEL I PICK UP changeover. H : KPC6C, L : KSS710 Hi-Z
86 NC O Not used. Fixed Low Low
87 MSTOP I Standby restart interrupt. H : Standby, L:Stop Hi-Z (Low input)
88 INTSV I Servo IC interrupt. H : Interrupt Hi-Z
89 FOGUP I Focus gain up interrupt. H : Focus gain up, L : Normal Hi-Z
90 ZMUTE_R I 0 bit mute detection. H : Mute ON, L : Mute OFF Hi-Z
91 ZMUTE_L I 0 bit mute detection. H : Mute ON, L : Mute OFF Hi-Z
92 NC O Not used. Fixed Low Low
93 D-MUTE O Driver mute. H : OFF, L : ON Low
94 SYS_SDA I/O System µ-com I2C data. Hi-Z
95 NC O Not used. Fixed Low Low
96 SYS_SCL I/O System µ-com I2C clock. Hi-Z
97~99 NC O Not used. Fixed Low Low
100 E2P_SDA O ROM correction E2P I2C data. Hi-Z
MICROCOMPUTER’S TERMINAL DESCRIPTION

KDC-M7024/MP822
11
TEST MODE
●How to enter the test mode
While pressing and holding the Preset 1 and Preset 3 keys,
reset the unit.
●How to exit from the test mode
While holding the Preset 6 key, reset the unit.
(Note) The test mode cannot be terminated by reset the
unit, ACC OFF, power OFF and Panel detached, momen-
tary power down.
●Initial status in the test mode
• Sources : ALL OFF
• Display : All segments are lit.
• Volume : -10 dB (displayed as “30” )
• Loudness : OFF
• CRSC : OFF regardless of the presence of switching func-
tion.
• SYSTEM Q : Flat
• WOW : All OFF
• BEEP :When pressing any keys, the buzzer generates a
beep at any time.
• AUX : ON
• MENU SYSTEM Q : OFF
• Variable model : Default is white
• Multifunction : Source dependency (Preset, SCAN, etc.)
●Special display inTuner mode
When any of the following messages is displayed inTuner
mode, the F/E may be abnormal.
• “TNE2P NG” :The EEPROM is set to the default (unstable
values) because the F/E was shipped without passing
through the adjustment process, etc.
• “TNCON NG” :Communication with the F/E is not possible.
●Forced switching of K3I
Each press of the Preset 6 key inTuner mode should switch
K3I from AUTO→Forced Wide →Forced Middle →Forced
Narrow →AUTO.
The initial status is AUTO and the display shows these
modes as follows.
• AUTO : FMA
• Forced Wide : FMW
• Forced Middle : FMM
• Forced Narrow : FMN
●Test mode specifications of the CD receiver
• Forcedejection isinhibited inthe resetstart operation. When
the unit is reset while a CD is loaded in it, the CD is not
recognized by resetting.
• Each press of theTrack Up key jumps to the following track
numbers:
No. 9 →No. 15 →No. 10 →No. 11 →No. 12 →No. 13 →
No. 22 → No. 14 →No. 9 (The cycle restarts from here.)
• Each press of the Track Down key jumps to the previous
track number to the track being played.
• When the number of total trucks of the MP3 disc or the
WMA disc is less than 9, 1st truck is played.
• When the disc media is CD, A short press of the Preset 1
key jumps to the track number 28.
• When the model is equipped the CD mechanism assembly
adapted for MP3 or MP3/WMA disc, the mechanism name
and version number are displayed during the FL model is
lower stand and Display mode of LCD model is DNPS.
●Audio-related specifications
• Pressing the ✽key on the remote initiates the audio adjust-
ment mode.
• BL/F key on the Fader initials.
• Continuous holding of a remote control key is inhibited, and
workings are short press of any keys.
• Bass, Middle andTreble are adjusted in 3 steps of -8 / 0 /
+8 with theTrack Up/Down keys (Default value at 0).
• Balance is adjusted in 3 steps of L15 / 0 / R15 with the
Track Up/Down keys (Default value at 0).
• Fader is adjusted in 3 steps of R15 / 0 / F15 with the Track
Up/Down keys (Default value at 0).
• HPF is adjusted in 2 steps of OFF / 170Hz (or 220Hz) with
the Track Up/Down keys (Default value at OFF).
• LPF is adjusted in 2 steps of OFF / 120Hz with the Track
Up/Down keys (Default value at OFF).
• Bass f, Bass Q, Bass EXT, Middle f, Middle Q andTreble f
are not dealt with by the audio adjust.
• The WOW key pass during the audio adjustment as follow-
ing steps.
Order Mod. Display
TruBass FOCUS SRS
qOFF OFF OFF SRSWOW OFF
wON OFF OFF SRSTruBass ON
eOFF LOW OFF FOCUS LOW
rOFF HIGH OFF FOCUS HIGH
tOFF OFF ON SRS ON
yON HIGH ON SRSWOW HIGH

KDC-M7024/MP822
12
TEST MODE
●Menu-related specifications
• A short press of the Q key initiates the menu mode.
• Pressing the DNPP key on the remote initiates the Menu
mode.
• Continuous holding of a remote control key is inhibited, and
workings are short press of any keys.
• Contrast is adjusted in 3 steps of 0 / 5 / 10 with the Track
Up/Down keys (Default value at 5).
●Backup current measurement
When the unit is reset while ACC is OFF (i.e. by turning
Backup ON), the MUTE terminal goes OFF in 2 seconds in
place of 15 second.(The CD mechanism is not activated at
this time.)
●Special display when the display is all on
Pressing the Preset keys while the power is ALL OFF dis-
plays the following information.
[PRESET 1] Version display (8 digits, Month/Day/Hour/Minute)
(Display) SYS xxxxxxxx : System microcomputer
PAN xxxxxxxx : FL model only
MEM xxxxxxxx : 4 contrasts FL model only
[PRESET 2] Serial number display (8 digits)
(Display) SNo xxxxxxxx
[PRESET 3] Short press :View power ON time. (The All OFF
period is not counted.)
2 seconds long press/hold : Clear power ON time
at the power ON time displaying.
(Display) PonTim xxxxx Max. 60000 (hours)
[PRESET 4] Short press : Display CD operation time.
2 seconds long press/hold : Clear CD operation
time at the CD operation time displaying.
(Display) CDTim xxxxx Max. 60000 (hours)
[PRESET 5] Short press : Display CD ejection count.
2 seconds long press/hold : Clear CD ejection
count at the CD ejection count displaying.
(Display) EjeCnt xxxxx Max. 60000 (times)
[PRESET 6] Short press : Display Panel open/close count.
2 seconds long press/hold : Clear Panel open/close
count at the Panel open/close count.
(Display) PnCnt xxxxxx Max. 600000 (times)
FM key Display ROM collection version.
(Display) ROM R xxx Invalid : “R – – –”
AM key Display panel E2PROM condition.
(Display) P–ROM OK (Registered code)
P–ROM NG (Code is write in error)
P–ROM WAIT (Unregistered code)
P-ROM NON (Panel security nonfunctional)
●Panel mechanism
• Auto-panel close inhibition when set-in the CD.
• The panel operation inhibition at power ON/OFF and ACC
ON/OFF.
• The panelposition changingEject ←→ Last witha short press
of the PLAY/PAUSE keys.
●Other specifications
• No displays such as “CODE OFF/ON” during Power-ON.
• The LINE MUTE inhibition time is one second from 10 sec-
onds when start-up the test mode.
• Do not write the security code with the security jig on the
test mode.
• Do not write the serial with the serial writing jig on the test
mode.
• OEM display output is not stop if OEM display not connec-
tion on the test mode.
●Switching the frequency span (K/M type)
While holding the Preset 1 key and Preset 5 key, reset the
unit.
●Response to OEM setting
(Destination of electronic volume setting)
S03F/E models are response to OEM models option at put
in µ-com 2 pin.
Its setting are following steps.
IC2TYPE0 IC2TYPE1
Description
(47 pin) (48 pin)
Low Low qTrade model (Initial quantify)
Low High wTrade model (CRSC change)
High Low eOEM model-ready CRSC change
High High rOEM model-ready CRSC &
de-emphasis change
●Security-related information
1. Forced Power ON mode (All models)
Even when the security (Cord) is approved, resetting the
unit while holding the Q and Preset 4 keys makes it pos-
sible to turn the power ON for 30 minutes.
After 30 minutes have elapsed, it is not possible to return to
the previous condition unless the unit is reset again.(Secu-
rity code is do not clear at this mode. Put the power on fill-
in.)

KDC-M7024/MP822
13
TEST MODE
2. Method of registration of the security code after
EEPROM (F/E) replacement (Code security model)
1) Enter the test mode. (See How to enter the test mode)
2) Press the MENU key to enter the Menu mode.
3) When the message “Security” is displayed, press and hold
the Track Up/Down key for 1 second to enter the security
registration mode.
4) Enter the code using the FM/AM/Track Up/Track Down keys.
FM key : Number up
AM key : Number down
Track Up key : Cursor right shift
Track Down key : Cursor left shift
5) Hold down theTrack Up key for at least 3 seconds and the
message, “RE-ENTER” appears, so once again enter the
code according to Step 4 above.
6) Press and hold the Track Up key for 3 seconds until “AP-
PROVED” is displayed.
7) Exit from the test mode. (See 2.How to exit from the test
mode)
(Note 1) All Clear is not applicable to the security code of
this model.
(Note 2) When the F/E changed, need re-inscription be-
cause the panel security is clear.
3. Simple way to clear the security code (K type only)
1) During code request mode, press the Track UP key for at
least 3 seconds while holding down the AUTO key.(– – – –
will disappear)
2) Enter, “KCAR” with the remote controller as described be-
low.
• Press the remote controller 5 key twice, and press the
Track Up key. (Enters a “K”)
• Press the remote controller 2 key three times, and press
the Track Up key. (Enters a “C”)
• Press the remote controller 2 key once, and press the
Track Up key. (Enters an “A”)
• Press the remote controller 7 key twice, and press the
Track Up key. (Enters an “R”)
3) Security function is canceled and unit sets to All-Off mode.
4) Code request mode appears if a mistake was made in en-
tering the numbers.
4. How to inscription the panel security code
1) Enter the test mode.
2) Pressing theAM keyon alllighting, check the“P-ROMWAIT”
display.
3) The NEXT key is long press 2 seconds, writing the code.
4) Display is “P-ROM OK”.
5) Exit from the test mode.
(Note) E2PROM connection is NG when display is “P-ROM
NG”, so detach the panel and rewrite after the display is “P-
ROM WAIT”.This code can not clear.
●Check the SRAM
Output (Hi) to the SRAM_CHECK terminal on 101 pin when
SRAM is function properly on the panel of 4 gradation FL
models.
●Check the Flash ROM
1) Display to the following effect at ALL OFF by assortment
system computer and panel for cover the customization
model attach the panel with no Flash ROM.
• Customization system computer + Flash ROM panel :All
lighting
• Non customization system computer + Non Flash ROM
panel : All lighting
• Customization system computer + Non Flash ROM panel
: Panel NG
• Non customization system computer + Flash ROM panel
: Panel NG
2) Output (Hi) to the FLASHROM_CHECK terminal on 102
pin when Flash ROM is function properly.
3) Flash ROM data is initialized when pressing the AM key
long hold at all lighting.
Display is “Data Erase ....” in data erasing mode. Do not
touch anything this mode.When the data erase completed,
display is “Erase OK!!”.
If display is “Erase NG!!!!!!”, Flash ROM data unable erase
for some kind or another factors.
When same effect as pressing the AM key long hold and
data erase once again, Flash ROM is defective.

KDC-M7024/MP822
14
ABCDE
1
2
3
4
5
6
7
PC BOARD (COMPONENT SIDEVIEW)
R55
R56
R31 R32
R44
R43
R112
R105
R127
12
11 2 1
9
8
16
1
2
1
W1
R46
R45
R33
R141
R22
R34
R140
C132
R202
X2
X1
R216
R217 R262
R234
R235
R236
R237
R268
L5
R102
R103
R21
R48R47R23R35
R138
C213
R139
R24R36
R283
R265
R207
R282
R204 R203
R210
C208
R218 R219 R220
R228 R230
R260
R259 R257
R275
R256 R253
R251
C254 C253
R300
R252 R250
C207
R215
R214
R200 R201
R211
R206 R205 R209 R208
C8
C7
1
15
1
17
148
1
11
1222
4434
33
23
25
26
50
100
76
7551
4
8
5
D25 D26
BE
BE
BE
BE
BEBEBEBE
Q11
BE
Q4
EB
Q60
BE
Q26
EB
Q59
EB
Q55
EB
Q56
EB
EB
Q58
Q32
EB
Q3
CN6
CN4
EB
Q57
BE
Q5
Q12
IC15
IC1
IC8
IC5
IC2
IC3
C700
DATA
C111
L2 C113
C112
C110
5V
RST
C109
C131
C105
R126
R125
R143
C108
C104
C102
OGI
R128
C6
L1
128
115
124
C41
CLK
L4
C200
C45 C46
TEST
C42
C32
C49 C50
C252
R129
L6
C1 C2
C250
C100
C128 C126
C256 C34 C31
C
2
C33
224
1
16
15
25C
2
D4
D20
Q9
D17
D16
Q1
D3
D15
D14
D6
CN2 CN1
J1
Q24
CN5
P1
D13
Q25
D1
CN3
IC4
Q13
Q8
ELECTRIC UNIT X25-966x-xx (J74-1474-12)
Refer to the schematic diagram for the values of resistors and capacitors.
X25-966x-xx
IC Q Address
14C
24C
33A
42E
55B
84B
15 5C
13A
35B
43B
53B
83A
94A
11 2A
12 2A
13 2A
24 2B
25 3D
26 3C
32 4B
55 4B
56 4B
57 4B
58 4B
59 3B
60 3F
102 3F
104 4F

KDC-M7024/MP822
15
JIHGF
1
2
3
4
5
6
7
1
3
2
4
1
144
72 73
D11 IC3
SUB-CIRCUIT UNIT
X16-2140-10 (J74-1479-02)
D16 D17
D19 D18
TUN
FMAM
RST
SCRLAUTO
MENU
VOLUME
CONTROL
SRC
ATT
654321
D12
SWITCH UNIT
X16-2190-10 (J74-1484-12)
D14
D19
D16
S1
D18
S21
S14
S9
S4
S19
S15
S10 D13
D6
S5
D5
S3
D4
S8
D3
S13
D2
D8 D9
S18
S7 S12 S20
S17
S2
S11
S6
D1
D15
D17
D10
Q3
Q2
D20
D7
D11
BE
BE
Q1
BE
X16-2140-10
IC Address
36H
X16-2190-10
Q Address
15J
25I
35I
R402
R307
R303
R302
R403
L11
L13
L12
R407
R406
C411
R405 R404
BE
Q102
BE
Q104
C5
X3
C410
C258
C255
C33
24
1
21
2
1
24
25C257
L7
W2
C
N3
CN7
D29
D31
D30
A1

KDC-M7024/MP822
16
KLMNO
1
2
3
4
5
6
7
PC BOARD (FOIL SIDEVIEW)
C4
C3
TH1
C251
C101
C204
R
1
C
1
R
1
R
1
R247
R232
R227
R226
R225
R222
R221
R224
R223
R240
R241
C261 C262
C259
C260
R233
R267
R301
C11
C12
C10
R7
C9
R274
R278
R277
R14
2
R133
C130
R317
R316
R314
R313
C71
BE
C408
R61
R315
D66
R306
R305
C403
C409
C405
C407
C413C412
C401
R1
C127 R130
R147
R264 C13 C21
C22 C15 C16
R8
C14 C24 C23
C280 C279
R9
R10
C203 C202
C201
R266
C211
R270 R271
R258
R273 R245 R246 R248
R254
R255
R261
R231
R238
R332
R331
R330
R328
R327
R326
R325 R324
R329
R239
R229
R320
R281
R285
R212 R213
C206
R321 R323 R322 R269
R272
R134
C129
R135 R132
R148
R3
R2
R309
R308
R319 R318 R312
R311
R310
1
1
15
106
5
10 6
8
169
D54 D55
D52
D
2
D65
D64 D63 D60
D62
D23
D50
D51
D53
D37 D38 D39 D40
D36 D35 D34 D33
D12 D11
D9
BE
Q63
BE
Q51
B
Q
2
Q33
EB
Q30
BE
Q52
EB
Q27
EB
BE
Q54
Q53
BE
Q28
Q103
IC12
IC13
IC7
IC14
IF+B
ESD-GND
SERVO-GND
M2-
SERVO+B
M2+
5V
E2P5V PAN5V
D-GND
D-GND
DATA
CLK SW5V
8V
21
34
GND
8V
VDD
PLL+B
M1-
M1+
AM+B
AUDIO-OUT
RLG
RL
AGND
BU
GND
BU
GND
BU
ELECTRIC UNIT X25-966x-xx (J74-1474-12)
1
1
4
8CP1
5
15
14 2
J1
SUB-CIRCUIT UNIT
X16-2080-10 (J74-1476-02)
IC1
X16-2080-10
IC Address
16K
X25-966x-xx
IC Q Address
75O
12 4L
13 5M
14 6N
23Q
63Q
73Q
10 6P
14 2Q
23 2P
27 2N
28 2N
29 3P
30 4P
33 4P
34 4Q
51 4O
IC Q Address
52 4O
53 4N
54 4N
63 6N
103 3L

KDC-M7024/MP822
17
TSRQP
1
2
3
4
5
6
7
SUB-CIRCUIT UNIT
X16-2140-10 (J74-1479-02)
C27 C26
R41
R42
R1
C1
R2
C2
R24
R3
R6
C5
C3
CP4
R14
R7
C28 C13 C29
C21
R52
R51
R54
ILLGND
DIMMER
VLCD1
VLCD1
PAN5V
DGND
ILL+B
RST
DATAS
DATAL
INH
CE
CLK
REMO
ILLGND
KI2
KI3
KI5
KI4 RED
PANDET DSI
KI1
KS3
KS1
VOLB
ESDGND
VOLA
KS2
KS4 E2PDATA
E2PCLK
GREEN
E2P5V
R53
R11
C6
R68
R67 C4
R5
CP5
R23
R10
R36 C15
C16
R31 C11 R33
C12
R32
R9
R15
C7
R35
C14
R34
R13
R8
R4 R12
R26
125
26 50
100
76
7551
CP1
EB
EB
EB
EB
IC1
D1
Q1
Q11
D22
Q5
D21
D26
IC2
D2
D3 D4
D5
Q6
132
CN2
28 1
26 50
100
76
7551
125
CN1
SWITCH UNIT
X16-2190-10 (J74-1484-12)
R7
R1
R2
R5
R4
R8
R18 R19
R16
R17 R3
R9
DSI
ESDGND
KI5
DSI
RST
KI2
KS3
PAN5V
RED
KI3
KI1
KS1
VOLA
ILL+B VOLB
GREEN
ILLGND
KS2
KI4
DGND
KS4 R6
R10
124
R15
D21 LCD
CN1
S16
R146
R144
C103
C106
R100
R108
C135
R111
C114
R109
R110
R142
R133
C130
R101
C69
R131
C134
R107
C107
R106
R145
R134
C129
R135 R132
R104
W100
R124
C67 C68
R5 R4 R6
R60 R70
D24D23
D27 D28
D12
D11
D9
D10
D2
D5
EB
Q10
BE
Q29
EB
Q33
EB
Q30
BE
Q
52
BE
EB
Q6
BE
Q23
Q2
EB
Q34
EB
Q7
EB
Q14
ILL+B
ILL-GND
8V
SW14V
BU
X16-2140-10
IC Q Address
12R
25R
13R
IC Q Address
53R
66R
11 2R
Refer to the schematic diagram for the
values of resistors and capacitors.

KDC-M7024/MP822
18
UVWXY
1
2
3
4
5
6
7
PC BOARD (COMPONENT SIDEVIEW)
R31
R25
R36
R64
R14 C31
R42
C16
C18 R21
R20
R17
C17
R34
C30
R29
C29
R19
R16
R43 R78
R41
R40
R33
R32
R24
L1
C15
C26
C84
C77
C61
C82 C81 C80 C79
C1
C2
BE
C44 R48
C4
CP24
R68
C86
C22
R26
C20 R23
C33
C83
C58
X1
R65
1
13
54
40
20
21
R56
C53C48
R74
R75
R49
CP1
CP14
CP10
CP21
CP20
CP15
CP7
CP13
CP2
CP6
CP12CP11 CP9
Q1
EB
Q2
1
25
75
76100
51
26 50
IC9
S1
S2
IC13
IC10
1
15
30
16
S3
IC4
S4
3
1
4
5
IC1
CD PLAYER UNIT
X32-5410-00 (J74-1487-12)
X32-5410-00
IC Q Address
13V
45W
13 2V
13W
25X Refer to the schematic diagram for the values of resistors and capacitors.

KDC-M7024/MP822
19
ADACABAAZ
1
2
3
4
5
6
7
PC BOARD (FOIL SIDEVIEW)
C87
C78
C47
R52
L5
C28
R76
R27
CP4
R28
SO0
D-MUTE
SGND
S7.5
MD
FD
R22
C21
C27
5
1
5
1
C25
C23
C24
C42
C70
C65
R71
C67
C74
B
C
A
RFI
D
E
F
FE
VR
PD
A8V
TE2
VC
ASY
EFM
ATEST
IOP-
TE VREF
EARF
FRF
IOP+
63
62
61
60 59
58
RFOK
RZM
LZM TBC
AGND
C75
R69
R67C68 C76
R70
C56 R59
R73
R46
C88
R53
R13
X3
R60
R58
C12
C8
C6
C9
C43
C72
C73
L4
C66
C71
C69
R45
2.5V C40
C46C38
R77
R37 R35
R30 R39
R38
C32
C39
W1 R18
C3 EFLG
C54
CP8
C60
C37
R47
L2
R4
SDA
SCL
SD
TD
VPP/PON
uGND
BU5 /RST
C19
R61
R72
CP18
CP19
C85
R66
R50
R51
R2
C63
C59
C57
R57
F-
T+
T-
F+
LD
ADGND
TD
FD
SD MD
SLD+
SLD-
DGND
D4.7
SPD-
SPD+
E2P-WR
R55
C45 C34
C41
C36
C35 R11 R12
C13
R10
R6
R1
R3 C5
C11
C51
C7
R7
R9
R5
R8
C10
C64
C50
C52 C55
R63
R62
1
16
D1
Q4
CN2
CN1
B E
24 12EJE
/CLK
Lch DATA
LOS
Rch
LE/LM
LO/EJ
MOTOR
1
14
8
125
75 51
26
50
100
76
X2
1
7
1 36
108 73
37
72
144
109
14
85
IC2
17
14 8
IC12
IC6
IC8
IC7
IC5
IC11
CP5
CP22
CP17
CP16CP23
Q3
B
E
Q5
B
E
D2
CD PLAYER UNIT
X32-5410-00 (J74-1487-12)
X32-5410-00
IC Q Address
23AC
6 5AA
7 5AB
85AC
IC Q Address
11 2AB
34AC
43Z
55AC Refer to the schematic diagram for the values of resistors and capacitors.

KDC-M7024/MP822
20
ABCDE
1
2
3
4
5
6
7
X32-5410-00 (1/2)
22K
22K
10K
4.7K
4.7K
22K
22K
4.7K
0V
5.0V
0V
5V
0V
5.0V
0V
5.0V
3.3V
5.0V
0V
0V
5.0V
0V
0V
0V
0V
3.3V
3.3V
0V
3.3V
0V
0V
0V
5.0V
0V
5.0V
5.0V
0V
0V
5V
5.0V
0V
5.0V
0V
0V
0V
0V
3.3V
0V
0V
5.0V
0V
0V
5.0V
0V
0V
0V
5.0V
5.0V
5.0V
0V
5.0V
1.65V
1.65V
1.65V
1.65V
0V
7.5V
0V
0V
1.65V
7.5V
7.5V
5.0V
0V
3.3V
0V
0V
0V
5.0V
0V
0V
0V
0V
IC6
IC8
IC7
IC1
IC4
(X32-5410-00)
MECHANISM CONTROL/
MICRO PROCESSOR
Q2
3.3V AVR
LEVEL
SHIFT
(3.3V-5V)
DM1 (X92- )
MOTOR
SPINDLE
M
LOE/LIM SW
S3
8EJE SW
∗S4
D.5V SW
(AUDIO)
3.3V AVR
LOS SW
12EJE SW
S1
S2
CN1 Q5
A.8V SW
Q3
DM2 (X92- )
SLED MOTOR
LOADING &
M
AUDIO L.P.F
IC2 (1/2)
IC2 (2/2)
Q1 DRIVER
4ch BTL
D1
3.3V
SW
AVR
LOE/LIM SW 64
39
S.GND
S7.5V
MOTOR
LO/EJ
D4.7V
D4.7V
D.GND
D.GND
RST
L1
BU5V 4.7
5V
C15
+3.3V
C20
R23
100K
BU5V
GND
R18
28
27
26
4.7K
C19
0.1
0.1
C26
0.1
16.000MHz
R26
100K C22
1
X2
BU5V
D4.7V
+
+
2.2
C23
22u6.3
C27 C28
1000P CN
STB GND VIN
2
1
R25
1K
3
4
BU5V
+3.3V VOUT
5
BU5V
223 S7.5V
1
2
4
5
6
7
8
24
22
30
FOK WAIT EFLG
100
87
31
27
26 29 28
25
24
23
CP1
VDD VSS REGC XT2 XT1 RESET
33
32
31
34
X1 X2
36 35 38
37
W1 18
21
20
19
19
20
CP2
100
MUTE R
MUTE L
VPP
17
16
15
14
13
4.7K
12EJE SW
LOS SW
8EJE SW
AD3
AD2
AD1
AD0
ASTB
READ
WRITE
+3.3V +
3
0.1
+3.3V
C33
89
90
65
91
A1
Y1
1
2
C31
AD8AD8
AD3 AD2 AD1 AD0 ASTB DSTB,/RD R/W WRL
42
41
40 45
44
43 48
47
46 50 49
51
AD4 AD4
AD7
AD5
AD6 52
53
BVDD
BVSS
54
55
56
AD7
AD5
AD6
+3.3V
100K
59
AD9
AD10
57
58
AD11
AD12 60
61
AD9
AD10
AD12
AD11
62
AD13
AD14
AD15 63
CP24
0.1
BU5V
14 13
VCC
A6
R24
D.OUT
BU5V
LOE/LIM
SW
8EJE SW
MSTOP
MRST
MUTE L
MUTE R
A.GND
DATA
LOS SW
12EJE
SW
3113
11
BU5V9
10
12 12 87
S7.5V
12
C16
0.1
Rch 16
14
15 19 20
17
0.1
C88
Lch
A8V 18 19
20 A8V 94
CLK 21
22 96 A8V
BU5V
12
11
10
9
PON
R14 PON
PON
8
7
6
5
4
BU5V
EVSS
EVDD
SCK0
3
2
E2P SDA
E2P SCL
1
CP4
4.7K
99 100 96 97 98
100
CP6
ZMUTE L
D-MUTE
SAD0
MSTOP
FOGUP
ZMUTE R
INTSV
91
SOD
94 95 91 92 93 1K
R27
89 90 87 88
90 89
SW5V
A8V
23
24 SLD+
12
13
S7.5V
SPD-
R4
2.2K
C3
2.2
C2
1
96
BU5V
CLK
SW5V
S7.5V
DATA
94
R28
10K
S7V
NIS GND CTL
C4
1
2
3
0.01 OUT
5 4
IN
10u10
C1
A8V
C12
2200P
A8V
A8V
2200P
C8
R6
330 4
1
C9
0.1
SLD-
18
19
SLD+
R10
330 8
7
A8V
680P
2.7K
2.7K
68P
18K
30K 11K
C5
R1
A3.3V
C6
680P
3
2R3
C11
C7
0.1
R7
7.5K
R5
R2
C10
0.1
R8
7.5K
S7.5V
18K
R13
C13
68P
5
6R12
30K
R11
11K R9
4.7
C21
A3.3V
FO+ SPD+ SPD- VCC1 GND MUTE GND SPIN SPIN- SPIN+ FDIN FDIN- BIAS
R38 100K
100K
100K
SW5V
AVDD
DBBWRDY0
DBBRRDY0
R42 100K
REQ
RESET
HSCB
CS 65
66
67 R43 100K
68
69
70
R41 10K
R40 10K 0.1
78
DASC
E2P WR
PIC SEL
ASEL
WMA
85 86 83 84
E2P
WR
R30
1K
R33
80 81 82 79
WTS
AVSS
AVREF
71
72
73
MDL
SEL
HOT
74
75
C32
R77
1K
76 77
R78
BU5V
BU5V
R39
100K
10K
R32
R35
1K
S7.5V
10K
BU5V
SW5V
9
18K13K
105 R36
16K
108 R31
4.7K
C29
330P
R29
2
1
4
3
C30
1500P
R34
5 8
7
6
S7.5V
15
14
13
12 12
11
10
FO-
14
13
15
SW5V
100
22 26
SLIN+
TDIN
TDIN-
VCC 29
30 27 28
LO/EJ
SLIN
SLIN-
24 25 23
330P
R17
13K
C17
S7.5V
R21
4.3K
R22
R76
13K
R20
12K
24
16
TR-
SLD+
SLD-
VCC2
GND
CNT
19 20 21 17 18
TR+
19 18
17
S7.5V
22
16
4700P
12K
R16 R19
12K
106
107
C18
A3.3V
C42
4.7
A
3
0.1
C35
AD
3
C34
C
22
0.1
10K
R75
10K
R51
R49 100K
RE
A
WR
I
AU3.3V
AD
0
AS
T
AD
1
AD
2
A3.3V
AD
5
AD
4
AD
8
AD
6
AD
7
AD1
2
AD1
0
AD1
AD
9
1K
R50
4.7
IOP2
R46
IOP1
A3.3V
R57
4.7K
Q2
100K
R47
VCC
(X25-)
CN4
to
