CD RECEIVER
KDC-MPV5025/MPV525
/MPV7026/WV6027
SERVICE MANUAL
Plastic cabinet assy
(A02-1486-13) Lever (D10-4589-04) x2
Screw set
(N99-1730-15)
DC cord
(E30-6295-05)
Screw set
(N99-1719-05)
Escutcheon
(B07-3001-02):KDC-WV6027
(B07-3098-02):KDC-MPV525
/MPV7026
(B07-3100-02):KDC-MPV5025
Mounting hardware assy
(J22-0011-03)
Panel assy
(A64-3186-12)
: KDC-MPV525
(A64-3188-12)
: KDC-MPV5025
Remote controller assy (RC-505)
(A70-2040-05)
CD MECHANISM EXTENSION CORD (24P) :W05-0934-00
MODEL TDF PANEL No. TDF NAME
KDC-MPV5025 Y33-1920-62 TDF-45D
KDC-MPV525/MPV7026 Y33-1920-63 TDF-MPV7026
KDC-WV6027 Y33-1920-66 TDF-WV6027
TDF PANEL INFORMATION
KDC-MPV5025
/MPV525
Panel assy
(A64-3193-12)
KDC-MPV7026
Panel assy
(A64-3198-12)
KDC-WV6027
DC cord
(E30-4958-05)
Antenna adaptor
(T90-0523-05)
Depends on the model. Refer to the parts list.
Size AA battery
(Not suplied)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

2
KDC-MPV5025/MPV525 KDC-MPV7026/WV6027
BLOCK DIAGRAM
BUFFER
Q101 RDS
DECODER
IC7
Q201
BUFFER
IC1
(V-ILL ONLY)
DA CONVERTER
IC2
REMOCON
RESET SW
ENCODER
ROTARYS1
WITH
LCD DRIVER
KEY MATRIX
IC1
LCD
PANEL DET
EJECT SW
S1
EJECT ILLUMI
DSI
SYSTEM
MICROPROCESSOR
IC2
MPX
E-VOL
&
EXT AMP
DIMMER
ACC DET
TEL MUTE
B.U DET
PRE MUTE
PRE MUTE
PRE MUTE
DRIVER
MUTE
IC6
POWER
IC
IC4
THERMAL
PROTECT
PRE OUT
(REAR/NF)
EXT.AMP.CON
DIMMER
ACC
TEL MUTE
BACK UP
AUX IN
(REAR) 3PRE
PRE OUT
(FRONT)
PRE OUT
SP OUT
SURGE DET
SW REG
CD MECHA+B
SERVOSERVO+B SW 14V
Q21
IC9
OPEL DISP I/F
WIRED REMO/
SUPPLY
IC
IC3
POWER ANT CON
P CON
RESET
IC8
SW 5V
Q4
PANEL 5V
Q152 SW5V
S-METER
AUDIO OUT
IFC OUT
PLL-DATA
PLL-CLK
SW5V
AM+B
A8V
SW3
SW2
SW1
MS CLK
MS DATA
M MUTE L
SW4
M MUTE R
LO/EJ
M STOP
MOSW
M RST
SERVO+B
A8V
BU5V
CD MECHA+B
DATA C
CH MUTE
CH RST
REQ H
REQ C
CH CLK
CH-CON
DATA H
BACK UP
NOISE
QUAL
S-METER
R DATA
R CLK
FM
AM
MP IN
LEVEL
CD
QUAL
AFS
CH
SW5V
BU5V
PANEL DET
EJECT
DSI
L CLK
L DATAS
L CE
L DATAL
VOL A
VOL B
REMO
V DATA
V CLK
O-CE
O-DATA
O-CLK
PRE MUTE
MUTE
P-MUTE
EXT.AMP.CON
DIMMER
PHONE
ACC DET
B.U DET
BEEP
PS1-0
PS1-1
PS1-2
PS2-0
PS2-2
RST
FREE
REAR
FRONT
BU5V
BACK UP
A8V
AUX
SW5V
BACK UP
AM+B
FM+B
ILLUMI
A8V
BU5V
BU5V
BU5V
MODE
CD,MP3
FM
AM
CH
E-TYPE
3600mV
1372mV
855mV
3600mV
K,M-TYPE
3600mV
1800mV
600mV
3600mV
TUNER
CD
CH
SWITCH UNIT (X16- )
DAUGHTER UNIT
(X89- )
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

3
KDC-MPV5025/MPV525
KDC-MPV7026/WV6027
BB
BB
A
x2
A x2
D
C
E
G
F
H
J
How to Disassemble (PANEL ASSY)
1)Remove four screws (A).
2)While holding the section (B) indicated with arrows, pull and
remove PANEL ASSY.
DISASSEMBLY FOR REPAIR
3)Pull SWITCH UNIT (C) as indicated in the diagram and re-
move knob (D).
(The knob (D) is attached to the rotary with hook (E) and it
is not possible to remove hook (D) only.)
How to install knob (SRC)
1)Place knob (F) and knob (G) in the positions indicated in
the diagram below.
2)While keeping these positions, use a piece of adhesive tape
(H) to hold knobs in position, as shown in the diagarma.
3)Set the rotary (J) position as shown in the diagram.
4)While keeping the letters “SRC” horizontally in position, set
it to the rotary on the panel.
5)Remove the adhesive tape (H).
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

4
KDC-MPV5025/MPV525
KDC-MPV7026/WV6027
●SWITCH UNIT (X16-2480-20)
Ref. No. Application / Function Operation / Condition / Compatibility
IC1 LCD Driver Drives LCD
IC2 Remote Control IC Controls the unit
IC3 D/A Convert IC
Q2 REMO ON SW The power supply of IC2 is turned on when base level goes “L”
Q3 Key Illumination SW (Green) Lights Green key-illumination when base level goes “H”
Q4 Key Illumination SW (Red) Lights Red key-illumination when base level goes “H”
Q31,34,37 Variable Illumination SW (Blue) Lights Blue Variable illumination when base level goes 0V~5V
Q32,35,38 Variable Illumination SW (Green) Lights Green Variable illumination when base level goes 0V~5V
Q33,36,39
Variable Illumination SW (Red) Lights Red Variable illumination when base level goes 0V~5V
●ELECTRIC UNIT (X34-308x-xx)
Ref. No. Application / Function Operation / Condition / Compatibility
IC1 System µ-COM Controls FM/AM tuner, the changer, CD mechanism, Panel, volume and tone.
IC2 E.Vol & N.C.MPX Controls the source, volume, tone and FM multiplex detector.
Bu5V (5V), Audio8V (8V), FM+B (8V), AM+B (8V), P-CON, ANT-CON
IC3 Power Supply IC
IC4 Power IC Amplifies the front L/R and the rear L/R to 50W maximum.
IC6 Muting logic IC Controls logic for muting.
IC7 RDS decoder
IC8 Reset IC “L” when detection voltage goes below 3.6V or less.
IC9 SW Regulator Power Supply for MP3
Q1 Serge Detection “L” when the back-up voltage becomes more than 24V (momentary power down).
“H” when the back-up voltage becomes less than 24V.
Q2 BACK-UP Detection “L” when B.u is present.
“H” when B.u is absent or momentary power down is detected.
Q3 ACC Detection “L” when Acc is present.
Q4 SW 5V ON when the base is “L”.
Q21 Servo Regulator
Q22 Servo SW
Q23 Control Power Supply IC
Q31 Dimmer Control Dimmer ON when the base is “H”.
COMPONENTS DESCRIPTION
SW1 OUT
1.5~3.0 Audio ON
3.5~5.0 Audio P-CON ON
7.0~ Audio P-CON, P-ANT ON
SW2 OUT
2.0~3.0 ILL FM ON
4.0~ ILL AM ON
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

5
KDC-MPV5025/MPV525
KDC-MPV7026/WV6027
Ref. No. Application / Function Operation / Condition / Compatibility
Q41 SW Regulator Control
Q101 Composite signal buffer
DSI lights when the base is “L”.
Q151 DSI Driver DSI turns off when the base is “H”.
DSI turns on and off when panel is taken off.
Q152 Panel 5V SW When the panel is attached, the base goes “L”, turning the Tr ON to supply 5V to the panel.
When panel is taken off, panel 5V cut off.
Q153,154 ILL Control ILL lights when the base of Q153 is “H”.
Q201 Noise buffer
Q350 Pre and NF Mute SW Drives the Pre and NF Mute sw (Q351,355) when the base is “L”.
(not always Pre and NF)
Q351 Pre / NF Mute SW Mutes the Pre Rear Lch or NF Lch when the base is “H”.
Q352 Pre / NF Mute SW Mutes the Pre Rear Rch or NF Rch when the base is “H”.
Q354 Pre and NF Mute SW Drives the Pre and NF Mute sw (Q352,356) when the base is “L”.
(not always Pre and NF)
Q355 Pre Mute SW Mutes the Front Lch when the base is “H”.
Q356 Pre Mute SW Mutes the Front Rch when the base is “H”.
COMPONENTS DESCRIPTION
●SYSTEM MICROCOMPUTER : UPD703030GC044 (X34 : IC1)
Pin No. Pin Name I/O Application Truth Processing Operation Description
value table
1PLL CLK I/O CLK output terminal to F/E
2Not used O
3PANEL-DET I Panel DET terminal No panel DET : L, Panel DET : H
4IC2 SDA I/O DATA input/output terminal with E-VOL
5IC2 SCL I/O CLK output terminal to E-VOL
6VDD -
7VSS -
8 FLIP-DET I Flip DET terminal L : Panel DET, H : Panel flippable
9BEEP O BEEP output terminal
10 REMO I Remote control input
11 R QUAL I RDS decoder QUAL input terminal
Not used O Destination other than E and E2
MICROCOMPUTER’STERMINAL DESCRIPTION
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

6
KDC-MPV5025/MPV525
KDC-MPV7026/WV6027
Pin No. Pin Name I/O Application Truth Processing Operation Description
value table
12 R DATA I RDS decoder DATA input terminal
Not used O Destination other than E and E2
13 L CE O CE output terminal for LCD driver
14 VILL DATA I/O D/A converter DATA output terminal for V-ILL When panel flippable and when momentary power
down, output L
15 VILL CLK I/O D/A converter CLK output terminal forV-ILL When panel flippable and when momentary power
down, output L
16 DSI I/O EJECT KEY ILL, GUIDE ILL, FLIP-DET “H” and PANEL-DET is “L” :“H” / “L”
DSI control terminal FLIP-DET “H”and PANEL-DET is “H” : “L”
17 Not used O Non dimmer destination
18 TEST -
19 ILL CON O During FLIP DET ILL+B OFF During FLIP DET “L” : H
20 VOL A I Volume key input When looking at VOL, also look at FLIPDET
21 VOL B I Volume key input When looking at VOL, also look at FLIPDET
22 MOSW O CD mechanism MOTOR IC SW Loading, Eject, Brake :H
23 LO/EJ I/O CD mechanism LOADING, EJECT switching STOP, Brake : Hi-Z, Loading : L, Eject : H
24 M STOP O STOP request to CD mechanism
25 M RST O Reset output terminal to CD mechanism Normal : H, Reset :L
26 MUTE I/O MUTE terminal Hi-Z : Mute ON, L : Mute OFF
27 LOE/LIM SW I CD DOWN SW DET terminal H :Chucking
28 M-MUTE L I MUTE request terminal from CD mechanism L : Mute request
29 M-MUTE R I MUTE request terminal from CD mechanism L : Mute request
30 PANEL 5V I/O Panel 5V control terminal Panel DET : L, Detached, Momentary power down : H
31 RESET I Normal : H, Reset :L
32 XT1 I 32kHz
33 XT2 I 32kHz
34 REGC - Connect 1µF condenser to GND
35 X2 I 20MHz
36 X1 I 20MHz
37 VSS -
38 VDD -
39 CLKOUT -
40 IC2 TYPE1 I E-VOL setting switching terminal
41 IC2 TYPE0 I E-VOL setting switching terminal
42~44 TYPE2~TYPE0 IDestination switching terminal e
45 CD MECHA+B I/O Power supply control terminal for MP3 ON : L, OFF : Hi-Z
46 SW5V I/O Control terminal for SW5V ON : L, OFF : Hi-Z
47,48 PS2-0, PS2-1 OControl terminal for power supply IC w
49~51 PS1-0~PS1-2 OControl terminal for power supply IC q
MICROCOMPUTER’STERMINAL DESCRIPTION
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

7
KDC-MPV5025/MPV525
KDC-MPV7026/WV6027
Pin No. Pin Name I/O Application Truth Processing Operation Description
value table
52 B.U-DET I Momentary power down DET terminal BU DET : L, BU no DET (momentary power down) : H
53 ACC-DET I ACC DET terminal ACC DET :L, ACC no DET : H
54 DIMMER I Small DET terminal ON : L, OFF : H
55 BVDD -
56 BVSS -
57 Not used O Non Ext AMP CON destination Output “L”
58 (SVR) O POWER IC SVR control terminal Momentary power down : H
59 P-MUTE O POWER IC MUTE output terminal During POWER OFF : L, During ALL OFF : L, When TEL MUTE : L
60 P-STBY O POWER IC STBY output terminal When POWER IC ON :H, OFF : L
61 Not used O
62 PRE MUTE R ORch PRE MUTE output When momentary power down :L,
M-MUTE R : L (during CD), 2 zone : H fixed
63 PRE MUTE L OLch PRE MUTE output When momentary power down :L,
M-MUTE L : L (during CD), 2 zone : H fixed
64 AFS O Constant switching terminal at noise DET During FM seek and AF search :L, During reception : H
65 O-DATA I/O External display DATA terminal
Not used O Non external display destination No OPEL DISP : L
66 O-CLK I/O External display CLK terminal
Not used O Non external display destination No OPEL DISP : L
67 O-CE I/O External display CE terminal
Not used O Non external display destination No OPEL DISP : L
68 LX_RST O Reset output to external devices Normally : L,
System RST return, then after 400msec or more :H then L
69 LX_CON O Control output to external devices ON : H, OFF : L
70 AVCONT O AD reference voltage control output While in operation : H
71 AVDD -
72 AVSS -
73 AVREF - AD reference voltage control input Connect to 70 pin
74 PHONE I PHONE DET terminal TEL MUTE : 1V or lower,
NAVI MUTE : 2.5V or higher
75 TYPE3 I Destination switching terminal
76~81 Not used I
82 S-METER I S-meter DET terminal
83 NOISE I FM noise DET terminal
84 IFC-OUT I F/E IFC OUT input terminal
85 LX_MUTE I MUTE request from external devices H : MUTE ON, L : MUTE OFF
86 LX_REQ_M O Request output to external devices Request DET : L
87 R-CLK I RDS decoder CLK input terminal
Not used O Non RDS destination Output L fixed
MICROCOMPUTER’STERMINAL DESCRIPTION
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

8
KDC-MPV5025/MPV525
KDC-MPV7026/WV6027
Pin No. Pin Name I/O Application Truth Processing Operation Description
value table
88 LX_REQ_S I Request input from external devices Request DET : L
89 KEY-REQ I Communication request from LCD driver L : KEY input
90 LO.S SW I Loading start SW DET terminal Loading start : L
91 12EJE SW I 12cm DISC EJECT position DET SW terminal 12cm DISC : L
12 or 8cm DET
92 EJECT I EJECT DET terminal L : KEY input
93 Not used O Output L fixed
94 LX_DATA_S I DATA input terminal from external devices
95 LX_DATA_M O DATA output terminal for external devices Last retention
96 LX_CLK I/O CLK input/output terminal with external devices
97 L DATAL I Data input from LCD driver
98 L DATAS O DATA output terminal to LCD driver
99 L CLK O CLK output terminal to LCD driver
100 PLL DATA I/O DATA input/output terminal with F/E
Truth value table
q
PS1-0 PS1-1 PS1-2 AUDIO P-CON P-ANT
LLLOFF OFF OFF
H (L) L (H) L ON OFF OFF
HHLONONOFF
HHHONONON
w
PS2-0 PS2-1 ILLUMI FM+B AM+B
LLOFF OFF OFF
H (L) L (H) ON ON OFF
HHONOFF ON
e
TYPE
MODEL DESTINATION
012
KDC-X579 K L L L
KDC-MP425 K H L L
KDC-MPV525 K L H L
KDC-MPV5025 K L L L
KDC-WV6027 E H L H
KDC-W6027 E L L H
KDC-W6027Y E L L H
KDC-MPV7026 M H H L
KDC-MP6026 M L H H
MICROCOMPUTER’STERMINAL DESCRIPTION
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

9
KDC-MPV5025/MPV525
KDC-MPV7026/WV6027
1. How to enter the test mode
• While holding the Preset 1 and Preset 3 keys, reset the unit.
2. How to exit from the test mode
•Reset the unit, momentary power down, ACC OFF, power
OFF, and Panel detached.
•(Note) The test mode cannot terminated by Panel is fall
down.
3. Initial status in the test mode
•Sources : All OFF.
•Display :All segments are lit.
•Volume :-10 dB (displayed as 30)
•Loudness :OFF
•CRSC :OFF regardless of the presence of
switching function.
•SYSTEM Q : Flat.
•BEEP :When pressing any keys, the buzzer
generates a beep at any time.
•DISPLAY TYPE: TYPE A
4. RDS automatic measurement
•An addition to disposal of substitute for visual check PS
display as usual production lines.
•P-CON terminal is OFF by force, when received the PS
data and in case of corrobaration PS display is
“RDS_TEST”. (“_” is mean blank.)
•This disposal is test mode only.
•P-CON is switching the source or return with power on→off.
5. Special display inTuner mode
When any of the following messages is displayed in Tuner
mode, the front end may be abnormal.
• “TNE 2P NG”:The EEPROM is set to the default (unstable
values) because the F/E was shipped without passing
through the adjustment process, etc.
• “TNCON NG”: Communication with the F/E is not possible.
6. Forced switching of K3I
•Each press of the Preset 6 key inTuner mode should switch
K3I from AUTO →ForcedWide →Forced Middle → Forced
Narrow → AUTO. The initial status is AUTO and the dis-
play shows these modes as follows.
•AUTO:FMA
•Forced Wide :FMW
•Forced Middle : FMM
•Forced Narrow: FMN
TEST MODE
7. CD ReceiverTest Mode Specification
•When resetting to start, forced ejection of CD is prohib-
ited.When a CD is in place, the CD is not recognized when
reset.
•When this key is pressed, the mechanism jumps to
the following track.
No9 →No15 →No10 →No11 →No12 →No13 →
No22 →No14 →No9 (Return to the first track.)
• When this key is pressed, the track goes down by one
from the currently played track.
•When a CD being played, by pressing [1] key intermittently,
the mechanism can be made to jump to Track No.28.
8. Audio-related specifications
•Ashort press of the Q key initiates the audio adjustment
mode.
•Pressing the ✽key on the remote initiates the audio
adjustment mode.
•Fader is selected to the initial item.
• Continuous holding of a remote control key is inhibited.
•Bass, Middle andTreble are adjusted in 3 steps of -8/0/+8
with the Track Up/Down keys.
•Balance is adjusted in 3 steps of L15/0/R15 with theTrack
Up/Down keys.
•Fader is adjusted in 3 steps of F15/0/R15 with the Track
Up/Down keys.
•Volume Offset is adjusted in 2 steps of -8/0 with theTrack
Up/Down keys.
9. Menu-related specifications
•Ashort press of the MENU key initiates the Menu mode.
Except, tape source is usually press and hold 1 second to
enter the menu mode and short press initiates turn over.
•Pressing the DNPP/SBF key on the remote initiates the
Menu mode.
• Continuous holding of a remote control key is inhibited.
•Contrast is adjusted in 3 steps of 0/5/10 (5x7dot), 0/4/7
(14seg) with the Track Up/Down keys.
10. Backup current measurement
•When the unit is reset while ACC is OFF (i.e. by turning
Back-Up ON), the MUTE terminal goes OFF in 2 seconds
in place of 15 second.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

10
KDC-MPV5025/MPV525
KDC-MPV7026/WV6027
11. Special display when the display is All ON
Pressing the Preset keys while the power is All OFF dis-
plays the following information.
[14seg 8 digits]
1key Version display (8 digits, Month/Day/Hour/Minute)
(Display) xxxxxxxx
2key
3key Short press:View power ON time. (The All OFF
period is not counted.)
Long press/hold: Clear power ON time.
(Display) PONxxxxx Max. 65535 (hours)
4key Short press: DisplayTAPE operation time.
Long press/hold: Clear TAPE operation time.
(Display) TPTxxxxx Max. 65535 (hours)
5key Short press: Display TAPE ejection count.
Long press/hold: Clear TAPE ejection count.
(Display) EJCxxxxx Max. 65535 (times)
6key Short press: Display Panel open/close count.
Long press/hold: Clear Panel open/close count.
(Display) PCxxxxx Max. 655359 (times)
FM key Display ROM colection version
(Display) ROM Rxxx Invalid :ROM R–
[15x7dot 12 digits]
1key Version display (8 digits, Month/Day/Hour/Minute)
(Display) SYS_xxxxxxxx
2key
3key Short press:View power ON time. (The All OFF
period is not counted.)
Long press/hold: Clear power ON time.
(Display) PonTim_xxxxx Max. 65535 (hours)
4key Short press: DisplayTAPE operation time.
Long press/hold: Clear TAPE operation time.
(Display) TPTim_xxxxx Max. 65535 (hours)
5key Short press: Display TAPE ejection count.
Long press/hold: Clear TAPE ejection count.
(Display) EjeCnt_xxxxx Max. 65535(times)
6key Short press: Display Panel open/close count.
Long press/hold: Clear Panel open/close count.
(Display) PnCnt_xxxxxx Max. 655359 (times)
FM key Display ROM colection version
(Display) ROM Rxxx Invalid: ROM R–
12. Other specifications
•The line mute against times are 1 second from 10 sec-
onds when starting the test mode.
■Security
•Forced Power ON mode (All models)
Even when the security is approved, resetting the unit while
holding the Q and 4 keys makes it possible to turn the
power ON for 30 minutes.After 30 minutes have elapsed, it
is not possible to return to the previous condition unless
the unit is reset again.
•Method of registration of the security code after
EEPROM (F/E) replacement (Code security model)
1. Enter the test mode.(See How to enter the test mode)
2. Press the MENU key to enter the MENU.
3. When the message “Security” is displayed, press and
hold the Track Up/Down key for 1second to enter the
Security registration mode.
4. Enter the code using the FM/AM/Track Down keys.
• FM key : Number up
•AM key : Number down
•Track Up key : Cursor right shift
•Track Down key : Cursor left shift
5. Hold down theTrack Up key for at least 3 seconds and
the message,“RE-ENTER” appears, so once again en-
ter the code according to Step 4 above.
6. Press and hold theTrack Up key for 3 seconds until“AP-
PROVED” is displayed.
7. Exit from the test mode.(See 2 How to exit from the test
mode)
(Note) All Clear is not applicable to the security code of
this model.
• Simplified method of clearing the security code
1. While the code entry is requested, press and hold the
Track Up key for 3 seconds while holding the AUTO key
pressed. (----will dissappear.)
2. Enter “KCAR” from the remote.
•Press the 5 key on the remote twice, then press the
Track Up key. (This enters “K”)
•Press the 2 key on the remote 3 times, then press the
Track Up key. (This enters “C”)
•Press the 2 key on the remote once, then press the
Track Up key. (This enters “A”)
•Press the 7 key on the remote twice, then press the
Track Up key. (This enters “R”)
3. Security function is canceled and the unit enters the All
OFF mode.
4. If you commit a mistake in the code entry, the unit en-
ters the code request mode.
TEST MODE
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

11
KDC-MPV5025/MPV525
KDC-MPV7026/WV6027
EDCBA
1
2
3
4
5
6
7
PC BOARD
(COMPONENT SIDEVIEW) (FOIL SIDEVIEW)
X16-2480-20
Ref. No. Address
IC1 5D
IC3 6E
Q2 6D
Q3 4D
Q4 4D
Q31 6D
Q32 6D
Q33 7D
Q34 6D
Q35 6D
Q36 7D
Q37 6D
Q38 6D
Q39 7D
X16-2480-20
Ref.No. Address
IC2 3B
Refer to the schematic diagram for the values
of resistors and capacitors.
2569
GND
EQ
VCC
VO
2410
KI2 KI3
91
KI1
KI4
123456CLK AUTO
KI5
KS5
KS4 VOL
SRC
RESET
KI3
AM
FM
C41
C39
IC2
D31
D32
D5
D6
D4
ED1
D7 D8 D9 D10 D13 D12 D11
D1
S1
S2
D3
D2
SWITCH UNIT
X16-2480-20 A/2 (J74-1565-02)
X16 B/2
EBEB
EB
BEBEBE
BEBEBE
BEBEBE
C40 C43
R9
R21
R22
R23 FLIPDET
R24
R25
KS3
KI1
REMO KS5 KI2
DI
ILL+B
VOL-A
KS4
VOL-B ESD-GND
RESET
CL
CE
DO
KI5
C6
R8
CP1
R10
R31
R32
R33
C31
R6
R7
C7
C1
C2 C3 C4
C8
C10
C11
C35
C36
C37
CP32
R1
R2
R40
R41
R42
R43
R44
R45
CP2
CP31
V-ILLCLK KI3
V-ILLDATA
D+ILLGND
KI4
R3
R4
R5
R11
R12
R14
R34R35
R36
R37
R38
R39
C38 C42
2
115
16
1001
76
25
26
50
75
51
1
4
8
5
J1
Q2
Q31
Q32
Q33
D21
Q3
Q4
Q34
Q35
Q36
Q37
Q38Q39
IC1
IC3
X16 B/2
SWITCH UNIT
X16-2480-20 A/2 (J74-1565-02)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

12
KDC-MPV5025/MPV525
KDC-MPV7026/WV6027
FGHIJ
1
2
3
4
5
6
7
PC BOARD (COMPONENT SIDE VIEW)
R358 91067 51 125
224
13 11 12 8 4 3 2
R363
1
1
24
1
117
2
2
24 2
23 1
18
1
3
3
4
6
R361R359
R360
R377
R376
C360
R373
W104
W103
W106
C210
C213 R204
R211
R212
W105
W101
C212
R402
R407
C7 SCL
SDA
R2
8
R409
R422
R56
R59
R60
R151
R163
R210
R208
R207
R209
R105
R103
R152
R102
R154
R153
R104
R113
C502
R213
C226
C227
R215
C223C225R214R216C222C224
R112
R114
C116
C118
R155 R156 R169
R158 R157
R55 R58
R54
C32
C4
R253 R254
R260/W202
/W205
R261/W203
TH1
R37
R31
R262/W204 R259/W201
C257 R257 R32
R33
C31
R35 R34
C304
R372
R36
C403
R408
R370
R371
R315
R403
R404
R406
R401
R405
R203
R362
R364
R357
R355 R356
R352
R351
EB
BE
Q351
EB
Q31
Q352
BE
Q350
BE
Q356
D203
D161
D162
D154 D153 D158
BE
Q201
BE
Q354 D205 D204
EB
D352
D351
Q357
EB
Q358
BE
Q355
L3
W1
W2
W4
W7 W8
R8
R9
BU
R
W5
C256
C33
C258
C
4
C301
C352
C351
C354
C353
C359
C358 C211
C216
C117 C115
X3
C221
C220 C208
C207
C209 C202 C201
C217
C219
C218
C355
C255
C254
C302
C303 C251 C252 C253
W3 W6
J1
J3
ELECTRIC UNIT X34-308x-xx (J74-1447-42)
J2
J4
CN3
CN4
A1
CN5
P1
S1
CN1
CN2
IC4
85
41
IC10
8
7
IC6
251
75
76
100
50
26
51
IC1
44
18
169
34
22
23
33
11
1
12
IC2
IC7
D156D155D160D159D152
D157D151
D308
D307
D301
D303
D304
D311
D310
CN6
D270 D269 D271
D32
D4
D31
L9
D2
D163 D
D254
D252
D25
5
D256
D257
D
2
D309
D357
D356
D358
L8
L7
L6
L10
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

13
KDC-MPV5025/MPV525
KDC-MPV7026/WV6027
ONMLK
1
2
3
4
5
6
7
R2 C1
1
15 16
2
R1
R3
R4
R11
R6
R13
R7
R5
R12
R9
R10
R8
D1
J1
DAUGHTER UNIT
X89-2570-10 (J74-1450-02)
S1
9
8
16
1
R24
R25
R26
R27
S
CL
R28
R417R416
R412R411
R421R420
R44R43
R409
C405
R63
R42
5
1
R41
C45
R422
R56
R59
R157
R55 R58 R54
R166
R413
R419 R415R418
C4
R31
R21
R32
33
C31
R1
R2
R408
D41
Q22
BE
Q41
W11
W26
W28
1
12
W10
8
R9
R22
R23
L1
W29
IC3
W24
W21
W23
W27
W18
W17
W13
W12
W14
W9
BU5V
RST
W19
W22
R166
W25
W15
W20
W30
W33
W31
W34
W32
C22
C20
C21
E
B
B
E
E
C
C
C1
C23
C29
C24
C26
C409
C28
C27
C41C42
C44
C43
C25
D1
J1
14
8
7
1
IC6
25
50
26
51
IC9
X2
X1
D4
D31
D21
Q21
D2 D3
D401
D163 D164 D165
D25
D253 D23
D22
D251D255
D24
D256
2
57
D258
L11
W35/L2
L12
Refer to the schematic diagram for
the values of resistors and capaci-
tors.
X34-308x-xx
Ref. No. Address
IC1 5J
IC2 5H
IC3 3L
IC4 2I
IC6 4K
IC7 6G
IC9 6L
Q21 2M
Q22 3M
Q31 3J
Q41 5M
Q201 4I
Q350 3G
Q351 3G
Q352 3G
Q354 3H
Q355 3G
Q356 3G
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

14
KDC-MPV5025/MPV525
KDC-MPV7026/WV6027
PQRST
1
2
3
4
5
6
7
PC BOARD (FOIL SIDEVIEW)
C2
R303 R305 R304 R307 R302
R306
R
R
R
R67
C501
C500
W109
R165
R187
R188
C51
R64
C214
R51
R52
R57
R159
R314
R206
R423
C111C401
R7
C3 R6 R4
R5
R11
C5
R10
R38
R313
R256 R252
R251
C6
R255
R3
R106
R205
R68
R162
R65
C52
R66
R312 R167
C402
C404
R13 R12
R164
C53 R69
R168
R160
R161
R185 R186
R62 R61
C406
R410
R53
C408
C407
C206 R202
R201
C204
C203
C205
C215
D26
D166
EB
E
BEE
CC
B
Q151
EB
Q152
D201 D202
EB
Q153
EB
Q154
BE
Q1
BE
Q3
BE
Q32
EB
Q2
Q23
Q4
12
43
IC8
ELECTRIC UNIT X34-308x-xx (J74-1447-42)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

15
KDC-MPV5025/MPV525
KDC-MPV7026/WV6027
YXWVU
1
2
3
4
5
6
7
R307 R302 R306 R301 R309 R310 R308 R311
C503
C357
C356
R379
W107/R375
W108/R374 R378
R368
R367
R366
C119
R369
R111
C114
C113
C112
C163
R115
R101
C504
W102/R365
BE
Q101
D359
17
12
18
CN1
DAUGHTER UNIT
X89-2570-10 (J74-1450-02)
Refer to the schematic diagram for
the values of resistors and capaci-
tors.
X34-308x-xx
Ref. No. Address
IC8 5R
Q1 4R
Q2 4R
Q3 3R
Q4 5Q
Q23 5Q
Q101 5V
Q151 7R
Q152 7R
Q153 7Q
Q154 7Q
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

16
KDC-MPV5025/MPV525
KDC-MPV7026/WV6027
ZAA AB AC AD
1
2
3
4
5
6
7
PC BOARD (COMPONENT SIDE VIEW)
S
D
G
EB
C52
C44
C25 C29
C50
RFOK
R12
C3
C8
C10
C11
C13
C15
C27
C35
C37
/RESET
MIDIO
MIACK
C41
C46
C32
CP6
R27
R47
C18
CP2
CP3
CP5
CP7
CP11
R6
R13
L1
R42 R46
R48
R49
R50
R63
R38
CP12
CP15
CP13
R68
CP14
R65
R67 C69
C67
C66
R66
R69
C72
1
34
5
1
1633
48
32 17
6449
BEC
CBE
Q5
Q4
Q7
S1 S2
S3
S4
IC3
IC6
CD PLAYER UNIT X32-5500-00 (J74-1552-12)
X32-5500-00
Ref. No. Address
IC3 4AA
IC6 5AB
Q4 5AA
Q5 5AC
Q7 5AB Refer to the schematic diagram for the values of resistors and capacitors.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

17
KDC-MPV5025/MPV525
KDC-MPV7026/WV6027
AIAHAGAFAE
1
2
3
4
5
6
7
PC BOARD (FOIL SIDE VIEW)
C54
L2
R21
C24
C71
R54
R56
R53
R58
C57
C56
R57
C63
C58
R60
R62
R59
R61
R52
R5
CP1
R10
C12
C5
R70
R2
C7
R9
R34
C28
R36
R35
C6
C34
R22
R37
C30
C31
R43
C26
C21
R29
R64
C38
R45
R44
C53
R40
C51
C48
C49
R51
C36 C47
CP4
R23
C16
X2
C14
R18
CP16
R14
R11
R7
R8
R17
R15
R16
C9
C19
C4
R1
C70
C42
C20
R31
R33
R32
C22 C23
R24
R25
C17
X1
R3
R4
C1 C2
C68
C64
C43
C33
R28
C45
CP9
CP8
C59
C55
R55
CP10
C60
R39
C61
C62
C39
1
16
1
100 25
51
75
76 50
26
1
34
5
3
1
4
5
241
45
31
25
15
26 1
50
100
76
7551
16
130
BEC
CEBBEC
ECB
13
45
S
D
G
EB
EB
EB
BU5V
S.7.5V
FCS
TRK
/MUTEL
/MUTER
SLED
SD
TD
S.GND
MOTOR
SPDL MD
FD
/MSTOP
LIM-SW T2
INT
T1 /RST
T3 T4
FLAGIN
SEARCH
/RESET
BU3.3V /STB
TXD1
/MICK
CLK
A0
/BOOT
/MILP
RXD1
LZM
RZM /MIRST
/MICS
POND3.3
XI
FOGUP
/MRST
SLED IN
LD
LO/EJ
DGND
/EJECT
/LOAD DATA
SLED OUT
/MUTER
D5V
8EJE
LOE/LIM
D.GND
FCS UP
D3.3V
TRK IN
TRK OUT
FCS DOWN
LOS Lch
/MUTEL
Rch
/MSTOP
PON
T
ADCIN
/CLK
FE
D.OUT
Vref
VR
IOP-
PD
C+D
VCC
TE
RF
ARF
F
E
F
A
B
SDO
SPDL+
SPDL-
A.GND
DAVdd3.3V
12EJE
A.+8V
BU2.5V
LRCKIA
D.GND
SDIO
MIRR LOCK HOLD
TZD
BCKIA
TXO
FZD
IOP+ GND
ATEST
FLAG
TX
Vref
REQ
STBY
Q6
Q3
Q10
CN1
D3
Q8
Q9
D2
CN2
Q1
IC2
IC4
IC5
IC1
IC9
IC7
IC8
CD PLAYER UNIT X32-5500-00 (J74-1552-12)
Refer to the schematic diagram for the values of resistors and capacitors.
X32-5500-00
Ref.No. Address
IC1 5AH
IC2 2AG
IC4 5AF
IC5 3AF
IC7 4AG
IC8 3AH
IC9 3AG
Ref.No. Address
Q1 5AH
Q3 5AF
Q6 5AG
Q8 2AF
Q9 3AF
Q10 3AF
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

18
KDC-MPV5025/MPV525
KDC-MPV7026/WV6027
ABCDE
1
2
3
4
5
6
7
D22-25
D2-4,309-311,357,358
Q21
HD74HC27FP-E:IC6
IC9
IC8
IC7
SI-8050JD
PST3436UL
SAA6581T
:
:
:
D21
Q22
IC2
IC4
IC3
IC1 TDA7411
TB2903H
BA4911-V4
:
:
:
:UPD703030GC044
DTC144EUA:Q31,153
Q101,201,351,352,
Q151 :
355-358
Q32
:
:
DTA114YUA
DTC143TUA
DTA123JK
D41
D32
D31
D26
Q350,354
Q154
Q152
2SD2375
2SA1036K
2SC4081
Q4
Q22,23
Q21 : :
:
Q1-3,41 :
UMC2N DTA124EUA
2SA1577
2SA1576A
:
:
:
D21
D1
SW14
SERVO
RESET
IC
D401
DAM01ZNF:
D
2
D
2
SFPB-54V
MA4056-M
HZS5B1
DAN202U
:
:
:
:
D
3
D
3
D
D
MA4082(N)-L
MA4068(N)-M
1N5393G-M6
:
:
:
OPEL
REMO
CD MECHA
UNIT
to
WIRED
REMO/OEM
DISP OUT
CN2
∗
D351
CN6
∗
D352
CN5
∗
C
∗
E
ANT. J4
TUNER
FM/AM
∗
A1
∗
D359
Q101
∗
D RDS
DEMODULATOR
MICROPROCESSOR
SYSYTEM
X2
BU5V
DGND
DGND
D4.5V
D4.5V
LO/EJ
MOSW
SERVO+B
SERVO
M-STOP
100u10
C21
1.5K
R21
R60 2.2K
1
GND
3
222
R59 100
2.2K
R58 2.2K
65
4
7
8
SW3 10
9
11SW4
12
R63
23
27
24
VSS
4VOUT 1
NC
3VDD 2
100K
R410
0.1
C406
C408 27P C407 22P
C405 1
R422 10K
32.768kHz
X2
X1
MUTE
26
R408 100K
26
25
21
23
22
24
23
25
24
22
21
LO/EJ
M RST
M STOP
VOL B
MOSW
XT2 XT1
29 28
27
RST
30
28
27
29 30
31
33
32
35
34
RESET PANEL 5V M-MUTE L LOE/LIM SW M-MUTE R REGC
20.000MHz
0.01
C404
∗
R420 22K
∗
R416 22K
∗
R411 22K
15K
VDD X1 VSS CLKOUT
R409
37
36 38 39
40
90
C118
680P
98
1SCL
MS-CLK
M-RST
MUTE-L
MUTE-R
AUDIO+B
MS-DA
D-OUT
O DATA
O CLK
5
4
GND
REMO
O CE3
2
1
3
52
4
1
L DATAS
PLL DATA
LX-CLK
LX-DATA-M
LX-DATA-S
L DATAL
EJECT
8EJE SW
12EJE SW
1
R52 2.2K
R56 1K
R55 1K
R54 1K
R53 1K
GND 17
13
14
15
Rch 16 43
100K 100K
R61
R62
1820 19
Lch 18
21
SW1 22 19
25
28
29
90
R51 2.2K
C52
0.01
23
24
SW2
R68
470
R64 100K R65 100K
C51
0.01 R67
470
91 10
VILL CLK15
17
20
19
18
16
19
20
16
17
ILL CON
VOL A
TEST
DIM CON
DSI
14
15
12
11
13
12
13
14
10 11 R DATA
VILL DATA
L CE
REMO
R QUAL
VDD
8
9
7
9
8
C402
0.01
FLIP-DET
BEEP
VSS
4
6
5
2
3
5
4
3
1
IC2 SDA
IC2 SCL
PANEL DET
PLL CLK
N.C
R370 100
R371 100
R372 100
R366 470
R367 470
R368 470
2
1
3
R369 470
2
1
66
67
65
L8 4.7uH
L7 4.7uH
AUDIO
IF GND
S-METER 23
IF+B 24
N.C 22
21
VDD5V
D-GND
18
N.C
N.C
20
19
17
16
C111
1000P
C503
4700P
R106
2.2K
82
13
R103 R105
4.7K 4.7K
4
L CLK
100 97 99 98 93 95 96 94 92 91
97
99 98
100
95 96
94
91
92
4.7uH
L9 SCOUT MODE
N.C
R104 470
R102 470
11
IFCOUT
SDA 15
14
PLL+B
VT
13
12
OSCGND
OSCGND
OSCGND 8
N.C 10
9
AM+B 7
6
84
100
L6 4.7uH
R101 1K
OSCGND
RFGND
FMIN
AMIN
5
4
3
2
1
L3
C119 0.01
∗
C360
∗
R373 1K
C356 0.01
QUAL
2.2u50
R112 2.2K
R111
4.7K
12
330P 4
VDDA
MPX
CIN
VSSA
7
6
5
VDDD
SYNC
VSSD 11
10
OSCI 12
13
VREF
RDDA
3
C116
C117
2
OSCO
TCON 14
15
R113 2.2K
87
11 1RDCL 16
C357 0.01
C115 10u16
C114 0.01
LX-REQ-M
R-CLK
KEY-REQ
LX-REQ-S
LX-MUTE
IFC-OUT
S-METER
LO.S SW
88 89 87 86 84 85
NOISE
C
81 82 83
87
88 89 90 86
84
85
100K
R404
82
83
X3
4.332MHz
C113
27P
R115
2.2K C112 27P
R114
2.2K
0.01
+
+
+
IC8
IC7
ELECTRIC UNIT (X34-308x-xx)
IC1
4.7K
4.6V
5.0V
0V
5V
0V
0V
5V
5V
0V
3.3V
0V
5V
5.0V
0V
0V
0V
0V
0V
5.0V
2.5V
5V
0V 5V
0V
0V
5V
0V
5V
0V or 0V
5V
0V
5V
0V
5.0V
0V
0V
5V
0V
5V
5V
0V
0V
5V
5V
5V
0V
0V
5V
0V
2.5V
2.5V
0V
5.0V
2.5V
5V
0V
5V
0V
0V
5V
0V
5V
0V
0V
5V
5V
0
0V
5V
5
or
0-2.2V
0-4.9V
0V
5V
0V
X34-308x-xx (1/4)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

19
KDC-MPV5025/MPV525
KDC-MPV7026/WV6027
JIHGF
X34-308x-xx (2/4)
DA204U:D166,352,359
D269,271,401
D203-205
M
D351 MA3062WA
1SS133
DAP202U
:
:
:
D164
307,308,356
D163,165,301,303,304,
D151-162
)-L
)-M
M
6
MA4120-L
MA4062-L
DA204K
:
:
:
B LINE
B LINE
GND LINE
SIGNAL LINE
D166
P1 CN1
D165
D162
Q151
Q15
3
Q154
∗
D156 D161 D155 D154D160 D159 D158D153
S
SOR
D41
Q41
CD MECHA+B
DIMMER
Q31
Q201 D203
ELECTRONIC
VOLUME
& FM MPX DETECTOR
D301
D310
D311
D303
D307
D309
D304
D308
J2 LX-CN
∗
B
+
C409
47u6.3
C403
213L CE
ESD GND
C502
0.01
1
2
B.U-DET
ACC-DET
DIMMER
∗
R420 22K
∗
R416 22K
∗
R411 22K
R415 22K
R419 22K
∗
R417 22K
∗
R421 22K
∗
R412 22K
43 TYPE2
VDD
CLKOUT
39 40
41
42 IC2 TYPE0
IC2 TYPE1 CD MECHA+B TYPE0 TYPE1
50
46 49
47
48
46 45
44
49
47
48
50
SW5V PS2-0 PS2-1 PS1-0 PS1-1
51
51
52
PS1-2
53
55
54
BVDD
53
52
54
14
(DIM-COM)
RESET
EJECT
VOL A
VOL B
EJECT ILL
V CLK
FLIP DET
L DATAS
L DATAL
L CLK
V DATA
∗
R169
3254
4 3 5
687
7 6 8
R153
470
R152
1K
∗
R151
470 14
99
97
∗
R156
470
R155
2.2K
R154
1K
89 98
8
15
9
10
1110 1312
12
11
13
470
R157
1K 17
16
R160 R159
1K
R158
470
21
20
92
RST
REMO
14
R187
2.2K
2.2K
R188
47K
10 19
R162
100K
4 3 5
6
R163
100K
7 8
R185
470K
10
11
86 69 85 68
94
95 96 88
8CDCHR+
C214 0.01
C215 0.01
C203 0.022
C205 0.47
IFC-OUT
S-METER
74
EXT AMP CON
O-DATA
PRE MUTE R
PRE MUTE L
AVCONT
65
59
56
BVSS
0.01
57
58
N.C
P-MUTE
57
59
62
60
61
P-STBY
N.C
63
64
AFS
60
62
63
64
C44 220u16 C43 220u16
70
67
65
66
O-CE
O-CLK
68
69
LX-CON
LX-RST 67
66
68
69
0.01
71
AVDD
C401
73
72
AVSS
PHONE
AVREF 74
L12
220uH
100K
84
NOISE
N.C N.C
81 82 83 80
84
100K
R404
82
83
R402
R403
100K
N.C N.C N.C N.C
79 78 76 77 R405
R401
100K
R406
100K 100K
C204 0.01
C206 150P
75
TYPE3
∗
R407
22K
R201 10K
R202 4.7K
43
54
100u25 100u25
47K
R42
C45
0.22
R41
47K
R43
47K
C41
C42
SWOUT
ON/OFF
2 3 4 5
VIIN 1
GND1
VOS
6
R44
47K
C32
0.022
C33
1u50
2.2K 100K
R
1
0
R36 R35
C213 0.1
C212
0.1
13
R203
4.7K
R204 4.7K R205 2.2K
R207 1K
83
64
17 17
18
4
18
1K
R210
10K
NV+
MPX
AM
NV-
11
10
9
MPOUT MPIN LEVEL
12
14
13
CDCHL+
CDCHL-
CDCHR-
8
7
66
5
QUAL
15
AFS
16
SDA MUTE
17
18
R208 1K
19
19
5
21
20
R209
10K
22 FREEL
FREER SCL
19
21
20
OUT LR
O
U
O
U
O
U
A
C
915 7RST
REQ H
1
R310 100
R301 10 R302 10
R307 4.7K
R306 4.7
R305 4.7K R304 4.7K
R303 100
C304 0.01
R315 100K
z
1
13
7
P
1
12
7
P
6 8
C303
47u10
C301
0.47u50
C302
0.47u50
4812
13
3711
2610
R311 100
R309 4.7K R308 4.7K
R312 100K
R314 100K
R313 100K
CHCON
A GND
4
5
6
3
2
10 DATA C
13
12
11MUTE DATA H
CLK
Lch
9
8GND
B.U REQ C
Rch
ACIN0L
C227
1
AUXR
AUXC
AUXL
3
4
2
1
3
2
44
CDL
ACOUT R
ACOUT L
SUBL 39
40 41 42 43
MDR
CDR
CREF
MDL
35 36 37 38
SUBR
1
C201
0.47u50
C225
0.1
∗
C209 2.2u50
∗
C208 1u50
∗
C207 1u50
C202
0.47u50
C223
0.1
C226
ACIN0R
A
C
A
C
A
C
A
C
34 1
A
C
R216R215
C224
0.1
R214
33K
R213
33K
C222
0.1
33K
33K
∗
R423
22K
∗
R206
+
+ +
+ +
+
+ + +
+
+
+
+
+
IC2
IC9
47K
10K
47K
47K
47K
47K
4.7K
0V or 5.0V
0V or 5.0V
0V
0V
0V or 5.0V
0V or 5.0V
0V
5V
0V 0V or5.0V
0.6V-4.2V
5V
5V
0V
5V
0V
0V
0V
5V
5V
0V
5V
0V
5V
V
V
0V
0V
5V
5V
or
0V
5V
5V
0V
5V
0V
5.0V
0V
5.0V
0V
0-2.2V
0-4.9V
0V
0V
0V
0V
0V
0V
13.4V
0V 14.3V
5.0V
0V
0V
2.4V
4.0V
0V
4.0V
3.6V
4.0V
4.0V
4.0V
4.0V
0V
380mV
5V
4.0V
4.0V
4.0V
0V
5V
4.0V
4.0V
4.0V
4.0V
4.0V
4.0V
4.0V
4.0V
4.0V
4.0V
4.0V
4.0V4.0V
0V or 5.0V
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

20
KDC-MPV5025/MPV525
KDC-MPV7026/WV6027
KLMNO
X34-308x-xx (3/4)
EXT AMP
D164
Q153
Q
154
Q152
D158 D152 D151D157
D31
DIMMER
Q31 Q32
∗
A
CONT
TEL MUTE
∗
B
D22
DET.SW
S1
PANEL
POWER
SUPPLY
CONTROL D26
∗
Q23
D25
D24
D23
SW5V
Q4
D1
D32
ACC DET
Q3 D4
SERGE DET
D2
Q1
B.U. DET
Q2 D3
D271
POWER IC
D269 AUDIO
Q352
Q350
D205
MUTE SW
Q351
Q356
MUTE
DRIVE
Q354
D204
∗
D358
Q355
∗
Q358
∗
D357
∗
D356
∗
Q357
MUTE SW
∗
C
POWER
SUPPLY IC
EEPROM
(NOT USED)
D163
L11
R167C163
R168 1K
D GND
PAN 5V
ILL GND
ILL +B
C501
0.01
2
.
2K
19
C500
2.2
18171615
4.7K
R166
R186
470K 470K
11
R161
2.2M
R164
47K
12
13
14
74 57
C32
15
0.022
100K
R34
10K
R31 10K
C31 0.01
R38 560
R32 22K
14
47K
R33
R35
21
20
FR
RR
GND
22 FREEL
FREER
21
20
OUT LR
OUT RR
OUT FR
OUT LF
23
24
25
VS
26
ACIN3L 27
28
FR
L10 4.7uH
C211
C210
0.01
+
47u10
C217 1u50
ACIN0R
ACIN2L
ACIN2R
ACIN3R 29
30
ACIN1L 31
32
ACIN1R 33
R212 33K
C221 0.1u50
C216 1u50
0.1u50
C219
C220 0.1u50
R211 33K
0.1u50
C218
R216
R214
33K
33K
R22
4.7K
C22
10u25
∗
C1
0.01
ILM
SW2
SW1
VCC
VBU
VDD
AUDIO
AM
PANT
FM
PCON
R13
5.6K
470K
Q23
R25
10K
R26
10K
R27
10K
R28
10K
12 11 10
10u50
C27
47
51
48 49
50
4.7uH
53
46
∗
R24 10K
8 9 7
C26 10u25
C28 220u16
∗
C23
10u25
4 6 5
∗
W10
3 2
C29 10u16 C24 10u16
C25 10u16
4.7K
R23
R12
47K
GND C2
0.01
1
L1
140uH
+
PC
O
14
2
15
13
A
R361
22K
RL-
RL+
FR-
FR+
C254 0.22u50
C253 0.22u50
22K
R9
33K
3.3K
C5
22K
0.01
R8
13
R37
1K
R11
1/2W
2
C3 1000P
R6 10K
100K
R3
R7
22K
R5
10K R4
20K
82K
R1
36K
R2
59
9
47K
60
R251
C255
+
1u50
4
2PWGND2
STBY
+
C256 22u16 RIP
6
8
VCC2
PWGND1
10
12 IN2
TAB 1
OUT2+
OUT2- 3
OUT1-
OUT1+
5
7RR+
RR-
VCC1
C257
1R253 4.3K
9
R254 10
16
14 IN4
AUX IN
18 PWGND3
R257
15K
TH1
C258 0.22u50
+
20
22 MUTE
24 PWGND4
C251
PREGND
IN1 11
IN3 13
15
C252
0.22u50 RR
0.22u50 FR
OUT4+
OUT3+
OUT3- 17
19
OUT4-
CLIP OUT
21
23
25
62
63
R355
22K
R255 330
R256 330K
360
C352
10u16
R356
22K
R352
FR 360
10u16
C351 360 R351
C354
10u16
R362
22K
R360
RL-
FR-
RR-
FR+
RR+
PA
RL+ F
L
F
L
R358
180
180
R357
R364
180
Q351,352,355-358
C6 0.01
1
2
3
4
5
VDD 14
12 13 10 9 11
GND
6
78
26
RST
17
4
22K
∗
W104
∗
W106
17
21
RR
3
C353
10u16 R359 360
∗
C358
∗
R374
360
∗
W108
∗
W105
∗
W103
1
2
∗
C359
22K
360
∗
C355
47u10
∗
R375
∗
W107
180
R363
1
2
3
∗
R378
∗
R379
∗
R36
5
∗
W101 4.7
∗
W10
2
W204
W202
W201
W203
C4
R10
0.01
∗
W20
52
C7
54 GND SDA
2
3
1A0 VCC
A1
A2
7
6
TEST
SCL
8
18
19
0.01
R165
47K
30
3
W109
∗
R376
∗
R377
20
+
+ +
+
+
+ +
+
+
+
+
+
+
+
+
+
++
+
+
+
KDC-MPV525/MPV5025/WV6027/MPV702
6
IC3
IC4
IC6
IC10
47K
47K
4
7K
47K
2.2K
47K
4.7K
22K
22K
22K
22K
4.7K
4.7K
4.7K
4.7K
4.7K
4.0V
4.0V
4.0V
4.0V
8.0V
0V
0V
4.0V
4.0V
4.0V
4.0V
4.0V
4.0V
4.0V
4.0V
VDD
7
5
13
14.0V
10.3V
14.3V
5.0V
13.1V
8.1V
7.9V
8.1V
0V
7.2V
3.3V
4.6V
0V
14.2V
0V
8.0V
3.4V
0V
7.1V
7.1V
7.1V
3.5V
0V
14.2V
0.2V
0V
3.5V
0V
3.5V
7.1V
7.1V
7.1V
7.1V
0V
5.0V
5.0V
5.0V
5.0V
5.0V
0V
0V
0V
0V
0V
0V
0V
5.0V
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
