Kenwood KDC-U559BT User manual

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
GET0997-001A (MN)© 2013 JVC KENWOOD Corporation
KDC-U559BT
CD-RECEIVER
INSTRUCTION MANUAL
JS_KWD_KDC_U559BT_MN_01_EN.indd 1JS_KWD_KDC_U559BT_MN_01_EN.indd 1 19/11/2013 12:10:47 PM19/11/2013 12:10:47 PM

2
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
CONTENTS BEFORE USE
Warning
Do not operate any function that takes your attention away from safe driving.
Caution
Volume setting:
• Adjust the volume so that you can hear sounds outside the car to prevent accidents.
• Lower the volume before playing digital sources to avoid damaging the speakers by the sudden increase of
the output level.
General:
• Avoid using the USB device or iPod/iPhone if it might hinder safe driving.
• Make sure all important data has been backed up. We shall bear no responsibility for any loss of recorded
data.
•
Never put or leave any metallic objects (such as coins or metal tools) inside the unit, to prevent a short circuit.
• If a disc error occurs due to condensation on the laser lens, eject the disc and wait for the moisture to
evaporate.
• USB rating is indicated on the main unit. To view, detach the faceplate.
( 3)
Remote control (RC-406):
• Do not leave the remote control in hot places such as on the dashboard.
• The Lithium battery is in danger of explosion if replaced incorrectly. Replace it only with the same or
equivalent type.
• The battery pack or batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
• Keep the battery out of reach of children and in its original packaging when not in used. Dispose of used
batteries promptly. If swallowed, contact a physician immediately.
BEFORE USE 2
BASICS 3
GETTING STARTED 4
RADIO 5
CD / USB / iPod 6
AUX 8
BLUETOOTH® 9
AUDIO SETTINGS 14
DISPLAY SETTINGS 15
MORE INFORMATION 15
TROUBLESHOOTING 16
INSTALLATION /
CONNECTION 18
SPECIFICATIONS 20
How to read this manual
• Operations are explained mainly
using buttons on the faceplate.
•
[XX] indicates the selected items.
•
( XX) indicates references are
available on the stated page.
Maintenance
Cleaning the unit: Wipe off dirt on the faceplate with a dry silicone or soft cloth.
Cleaning the connector: Detach the faceplate and clean the connector
gently with a cotton swab, being careful not to damage the connector.
Handling discs:
• Do not touch the recording surface of the disc.
• Do not stick tape etc. on the disc, or use a disc with tape stuck on it.
• Do not use any accessories for the disc.
• Clean from the center of the disc and move outward.
• Clean the disc with a dry silicone or soft cloth. Do not use any solvents.
• When removing discs from this unit, pull them out horizontally.
• Remove burrs from the center hole and disc edge before inserting a disc.
Connector (on the reverse
side of the faceplate)
JS_KWD_KDC_U559BT_MN_01_EN.indd 2JS_KWD_KDC_U559BT_MN_01_EN.indd 2 19/11/2013 12:10:49 PM19/11/2013 12:10:49 PM

3
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
BASICS
To Do this (on the faceplate) Do this (on the remote control)
Turn on the power Press BSRC.
• Press and hold to turn off the power.
Press and hold SRC to turn off the power.
( Pressing SRC does not turn on the power. )
Adjust the volume Turn the volume knob. Press VOLor VOL .
Press ATT during playback to attenuate the sound.
• Press again to cancel.
Select a source Press BSRC repeatedly. Press SRC repeatedly.
Change the display
information
Press DISPSCRL repeatedly.
• Press and hold to scroll the current display information. ( not available )
Faceplate
How to reset
Attach
Detach
Remote control (RC-406)
Volume knob
(turn/press)
Detach button
Display windowLoading slot
ENGLISH |
Pull out the insulation sheet
when using for the first time.
Your preset adjustments
will also be erased.
How to replace the battery
Remote sensor (Do
not expose to bright
sunlight.)
JS_KWD_KDC_U559BT_MN_01_EN.indd 3JS_KWD_KDC_U559BT_MN_01_EN.indd 3 19/11/2013 12:10:49 PM19/11/2013 12:10:49 PM

4
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
GETTING STARTED
Set the initial settings
1 Press BSRC to enter STANDBY.
2 Press the volume knob to enter [FUNCTION] .
3 Turn the volume knob to make a selection (see the following table), then press the knob.
4 Press and hold to exit.
To return to the previous setting item or hierarchy, press .
Default: XX
AUDIO CONTROL
SWITCH
PREOUT
REAR / SUB-W : Selects whether rear speakers or a subwoofer are connected to the line out
terminals on the rear (through an external amplifier).
SP SELECT OFF / 5/4 / 6 × 9/6 / OEM : Selects according to the speaker size (5inches or 4inches, 6×9inches
or 6inches) or OEM speakers for optimum performance.
DISPLAY
EASY MENU ON
:Both display and button illumination change to white color when entering [FUNCTION] .;
OFF :Both display and button illumination remain as [COLOR SELECT] color. ( 15)
TUNER SETTING
PRESET TYPE NORMAL
: Memorizes one station for each preset button in each band (FM1/ FM2/ FM3/ MW/ SW1/
SW2).
; MIX : Memorizes one station for each preset button, regardless of the selected band.
SYSTEM
KEY BEEP ON
:Activates the keypress tone.; OFF :Deactivates.
TDF ALARM ON :Activates the alarm if you forget to detach the faceplate when ACC is set to OFF.;
OFF :Deactivates.
SOURCE SELECT
BUILT-IN AUX ON :Enables AUX in source selection.; OFF :Disables. ( 8)
CD READ 1
:Automatically distinguishes between audio file disc and music CD.; 2 : Forces to play as an
music CD. No sound can be heard if an audio file disc is played.
F/W UPDATE
UPDATE SYSTEM/ UPDATE BT
F/W UP
xx.xx
YES :Starts upgrading the firmware.; NO :Cancels (upgrading is not activated).
For details on how to update the firmware, see: www.kenwood.com/cs/ce/
3
Cancel the demonstration
When you turn on the power (or after you reset the
unit), the display shows: “CANCELDEMO” “PRESS”
“VOLUMEKNOB”
1 Press the volume knob.
[YES] is selected for the initial setup.
2 Press the volume knob again.
“DEMOOFF” appears.
Set the clock
1
Press the volume knob to enter [FUNCTION] .
2 Turn the volume knob to select [CLOCK] , then press the knob.
3 Turn the volume knob to select [CLOCK ADJUST] , then press
the knob.
4 Turn the volume knob to make the settings, then press the knob.
Day Hour Minute
5 Turn the volume knob to select [CLOCK FORMAT] , then press
the knob.
6 Turn the volume knob to select [12H] or [24H] , then press
the knob.
7 Press and hold to exit.
To return to the previous setting item or hierarchy, press
.
While in clock display screen...
Press and hold DISP SCRL to enter clock adjustment
mode directly.
Then, perform step 4to set the clock.
1
2
JS_KWD_KDC_U559BT_MN_02_EN.indd 4JS_KWD_KDC_U559BT_MN_02_EN.indd 4 28/11/2013 9:36:22 AM28/11/2013 9:36:22 AM

5
ENGLISH |
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
RADIO
Search for a station
1 Press BSRC to select TUNER.
2 Press JBAND repeatedly (or press *AM–/#FM+ on RC-406) to
select FM1/ FM2/ FM3/ MW/ SW1/ SW2.
3 Press S/ T(or press S/ T(+) on RC-406) to search for a
station.
• To change the searching method for S/ T:Press KSEEK
repeatedly.
AUTO1: Automatically search for a station.
AUTO2: Search for a preset station.
MANUAL: Manually search for a station.
• To store a station: Press and hold one of the number buttons (1to6).
• To select a stored station: Press one of the number buttons (1to6) (or
press one of the number buttons (1to6) on RC-406).
Change the frequency steps
You can change the frequency step of:
FM: 50 kHz to 200 kHz
MW: 9 kHz to 10 kHz
1 Press and hold BSRC to turn off the power.
2 While pressing number buttons 1and 5, press BSRC.
Release your fingers from the buttons after the display appears.
• To restore the initial setting, repeat the same procedure.
• When the frequency step is changed, the previously stored stations in
the memory are deleted.
Direct Access Tuning (using RC-406)
1 Press DIRECT to enter Direct Access Tuning.
2 Press the number buttons to enter a frequency.
3 Press ENT IW to search for a station.
• To cancel, press or DIRECT.
• If no operation is done for 10seconds after step2, Direct Access Tuning
is automatically canceled.
Other settings
1 Press the volume knob to enter
[FUNCTION] .
2 Turn the volume knob to make a selection (see the following table),
then press the knob.
3 Press and hold to exit.
To return to the previous setting item or hierarchy, press .
Default: XX
TUNER SETTING
LOCAL SEEK ON
:Searches only MW/ SW1/ SW2 stations with good reception.;
OFF :Cancels.
AUTO MEMORY YES :Automatically starts memorizing 6 stations with good reception.;
NO :Cancels. (Selectable only if [NORMAL] is selected for [PRESET  TYPE] .)
( 4)
MONO SET ON
:Improves the FM reception, but the stereo effect may be lost.;
OFF :Cancels.
NEWS SET ON :The unit will temporarily switch to News Programme if available.;
OFF :Cancels.
REGIONAL ON :Switches to another station only in the specific region using the “AF”
control.;
OFF :Cancels.
AF SET ON :Automatically searches for another station broadcasting the same
program in the same Radio Data System network with better reception
when the current reception is poor.;
OFF :Cancels.
JS_KWD_KDC_U559BT_MN_01_EN.indd 5JS_KWD_KDC_U559BT_MN_01_EN.indd 5 19/11/2013 12:10:50 PM19/11/2013 12:10:50 PM

6
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
CD / USB / iPod
Start playback
The source changes automatically and playback starts.
CD
USB
iPod/iPhone
Press 5 iPod to select the control mode while in iPod source.
MODE ON: From the iPod*2.
MODE OFF: From the unit.
If you connect the iPod/iPhone to the USB input terminal of the unit
(while listening to TuneIn Radio, TuneIn Radio Pro or Aupeo), the unit
will output the sound from these apps.
Label sideEject disc
USB input terminal
USB input terminal
CA-U1EX (max.: 500mA)
(optional accessory)
KCA-iP102 (optional accessory) or
accessory cable of the iPod/iPhone
*1
TI ON :Allows the unit to temporarily switch to Traffic Information.;
OFF :Cancels.
PTY SEARCH Press the volume knob to enter PTY language selection. Turn the volume
knob to select the PTY language (
ENGLISH / FRENCH / GERMAN ), then
press the knob.
Selects the available Program Type (see the following), then, press
S/ T to start.
CLOCK
TIME SYNC ON
:Synchronizes the unit’s time to the Radio Data System station time.;
OFF :Cancels.
• [MONO SET] / [NEWS SET] / [ REGIONAL] / [AF SET] / [TI] / [PTY SEARCH] is selectable
only when the band is FM1/ FM2/ FM3.
• Available Program Type:
SPEECH : NEWS , AFFAIRS , INFO (information), SPORT , EDUCATE , DRAMA , CULTURE ,
SCIENCE , VARIED , WEATHER , FINANCE , CHILDREN , SOCIAL , RELIGION , PHONE
IN , TRAVEL , LEISURE , DOCUMENT
MUSIC : POP M (music), ROCK M (music), EASY M (music), LIGHT M (music),
CLASSICS , OTHER M (music), JAZZ , COUNTRY , NATION M (music), OLDIES ,
FOLK M (music)
The unit will search for the Program Type categorized under
[SPEECH] or
[MUSIC] if selected.
• If the volume is adjusted during reception of traffic information, alarm
or news bulletin the adjusted volume is memorized automatically. It
will be applied the next time traffic information, alarm or news bulletin
function is turned on.
RADIO
JS_KWD_KDC_U559BT_MN_02_EN.indd 6JS_KWD_KDC_U559BT_MN_02_EN.indd 6 28/11/2013 9:36:31 AM28/11/2013 9:36:31 AM

7
ENGLISH |
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Select a track/file from a list
For iPod: Applicable only when [MODE OFF] is
selected.
( 6)
1 Press .
2 Turn the volume knob to make a selection,
then press the knob.
• MP3/WMA/WAV file: Select the desired
folder, then a file.
• iPod or KME Light/ KMC file: Select the
desired file from the list (PLAYLISTS,
ARTISTS, ALBUMS, SONGS, PODCASTS*,
GENRES, COMPOSERS*).
*
Only for iPod.
• To return to the root folder (or first file), press
number button 5 iPod.
• To return to the previous setting item or
hierarchy, press .
• To cancel, press and hold .
If you have many files....
You can search through them quickly (on step 2
above) at a preset skip search ratio by pressing
S/ T.
• See also “Set the skip search ratio.”
( 8)
• Pressing and holding S/ Tskip songs at
the maximum ratio (10
% ) regardless of the
setting made.
• For USB: Only for files registered in the
database created with KME Light/ KMC.
• Not applicable for audio CD.
To Do this
Pause or resume
playback
Press 6 IW (or press ENT IW on RC-406).
Select a track/file Press S/ T(or press S/ T(+) on RC-406).
Select a folder *3Press J/ K(or press *AM– /#FM+ on RC-406).
Reverse/
Fast-forward
Press and hold S/ T(or press and hold S/ T(+) on RC-406).
Repeat play *4Press 4 repeatedly.
• Audio CD: TRACKREPEAT, REPEATOFF
• MP3/WMA/WAV file or iPod: FILEREPEAT, FOLDERREPEAT, REPEATOFF
• KENWOOD Music Editor Light (KME Light)/ KENWOOD Music Control (KMC)
file
( 16) : FILEREPEAT, REPEATOFF
Random play *4Press 3 repeatedly.
• Audio CD: DISCRANDOM, RANDOMOFF
• MP3/WMA/WAV file or iPod or KME Light/ KMC file: FOLDERRANDOM,
RANDOMOFF
Press and hold 3 to select “ALLRANDOM”. *5
*1Do not leave the cable inside the car when not using.
*2You can still play/pause, file skip, fast-forward or reverse files from the unit.
*3Only for MP3/WMA/WAV files. This does not work for iPod.
*4For iPod: Applicable only when
[MODE OFF] is selected.
*5For CD: Only for MP3/WMA files.
CD / USB / iPod
JS_KWD_KDC_U559BT_MN_01_EN.indd 7JS_KWD_KDC_U559BT_MN_01_EN.indd 7 19/11/2013 12:10:50 PM19/11/2013 12:10:50 PM

8
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
AUX
Preparation:
Select
[ON] for [BUILT-IN AUX] . ( 4)
Start listening
1 Connect a portable audio player
(commercially available).
2 Press BSRC to select AUX.
3 Turn on the portable audio player and
start playback.
Set the AUX name
While listening to a portable audio player
connected to the unit...
1 Press the volume knob to enter [FUNCTION] .
2 Turn the volume knob to select [SYSTEM] ,
then press the knob.
3 Turn the volume knob to select [AUX NAME
SET]
, then press the knob.
4 Turn the volume knob to make a selection,
then press the knob.
AUX (default)/ DVD / PORTABLE / GAME / VIDEO / TV
5 Press and hold to exit.
Auxiliary input jack
Portable audio
player
3.5mm stereo mini plug with “L”
shaped connector (commercially
available)
CD / USB / iPod
Set the skip search ratio
While listening to iPod or KME Light/ KMC file...
1 Press the volume knob to enter [FUNCTION] .
2 Turn the volume knob to select [USB] , then
press the knob.
3 Turn the volume knob to select
[SKIP SEARCH] , then press the knob.
4 Turn the volume knob to make a selection,
then press the knob.
0.5% (default)/ 1% / 5% / 10% : Skip search ratio
over the total files.
5 Press and hold to exit.
Change the USB drive
When a smartphone (Mass Storage Class) is
connected to the USB input terminal, you can
select its internal memory or external memory
(such as an SD card) to playback the stored songs.
You can also select the desired drive to playback
when a multiple drives device is connected.
Press 5 iPod repeatedly to select the desired
drive.
(or)
1 Press the volume knob to enter [FUNCTION] .
2 Turn the volume knob to select [USB] , then
press the knob.
3 Turn the volume knob to select
[MUSIC DRIVE] , then press the knob.
4 Press the volume knob to select
[DRIVE CHANGE] .
The next drive is selected automatically.
Repeat steps 1to 4to select the following drives.
Selectable items: [DRIVE  1] to [DRIVE  5]
Direct Music Search (using RC-406)
1 Press DIRECT.
2 Press the number buttons to enter a track/
file number.
3 Press ENT IW to search for music.
• To cancel, press .
• Not available if Random Play is selected.
• Not applicable for iPod, KME Light/ KMC file.
Select a song by name
While listening to iPod...
1 Press .
2 Turn the volume knob to select a category,
then press the knob.
3 Turn the volume knob quickly to enter
character search.
4 Turn the volume knob to select the
character to be searched for.
5 Press S/ Tto move to the entry
position.
You can enter up to 3characters.
6 Press the volume knob to start searching.
7 Turn the volume knob to make a selection,
then press the knob.
Repeat step7until the desired item is
selected.
• To search for a character other than A to Z
and 0 to 9, enter only “
*”.
• To return to the previous hierarchy, press
.
• To return to the top menu, press number
button 5 iPod.
• To cancel, press and hold .
JS_KWD_KDC_U559BT_MN_01_EN.indd 8JS_KWD_KDC_U559BT_MN_01_EN.indd 8 19/11/2013 12:10:50 PM19/11/2013 12:10:50 PM

9
ENGLISH |
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
BLUETOOTH®
You can operate Bluetooth devices using this unit.
Connect the microphone
If you turn off the unit or detach the control panel
during a phone call conversation, the Bluetooth
connection is disconnected. Continue the
conversation using your mobile phone.
Supported Bluetooth profiles
– Hands-Free Profile (HFP)
– Serial Port Profile (SPP)
– Phonebook Access Profile (PBAP)
– Object Push Profile (OPP)
– Advanced Audio Distribution Profile (A2DP)
– Audio/Video Remote Control Profile (AVRCP)
Adjust the
microphone angle Secure using cord clamps (not
supplied) if necessary.
Microphone input jack
Microphone
(supplied)
Rear panel
Pair a Bluetooth device
When connecting a Bluetooth device to the unit for the first time, perform pairing between the
unit and the device. Once the pairing is completed, the Bluetooth device will remain registered
in the unit even if you reset the unit.
• Up to five devices can be registered (paired) in total.
• A maximum of two Bluetooth phones and one Bluetooth audio device can be connected at
any time.
• This unit supports Secure Simple Pairing (SSP).
• Some Bluetooth devices may not automatically connect to the unit after pairing. Connect the
device to the unit manually. Refer to the instruction manual of the Bluetooth device for more
information.
1 Press BSRC to turn on the unit.
2 Search and select this unit model name (KDC-U5**BT) on the Bluetooth device.
“PAIRING” “PASS XXXXXX” Device name “PRESS” “VOLUME KNOB” scrolls on the
display.
3 Press the volume knob to start pairing.
“PAIRING OK” appears when pairing is completed and “BT” will light up when the Bluetooth
connection is established.
• For some Bluetooth devices, you may need to enter the Personal Identification Number (PIN)
code immediately after searching.
• Pairing request (via Bluetooth) is automatically activated if an iPhone/iPod touch is connected
through the USB input terminal. (Applicable only if
[AUTO PAIRING] is set to [ON] .) ( 13)
Press the volume knob to pair once you have confirm the device name.
Bluetooth test mode
You can check the connectivity of the supported profile between the Bluetooth device and the
unit.
• Make sure there is no Bluetooth device connected.
1 Press and hold .
“PLEASE PAIR YOUR PHONE” appears.
2 Search and select this unit model name (KDC-U5**BT) on the Bluetooth device.
3 Operate the Bluetooth device to confirm pairing.
“TESTING” flashes on the display.
JS_KWD_KDC_U559BT_MN_01_EN.indd 9JS_KWD_KDC_U559BT_MN_01_EN.indd 9 19/11/2013 12:10:51 PM19/11/2013 12:10:51 PM

10
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
The connectivity result (OK or NG) appears after the test.
PAIRING: Pairing status
HF CNT: Hands-Free Profile (HFP) compatibility
AUD CNT: Advanced Audio Distribution Profile (A2DP) compatibility
PB DL: Phonebook Access profile (PBAP) compatibility
• To cancel check mode, press and hold BSRC to turn off the unit.
Bluetooth mobile phone
To Do this
Receive a call Press or the volume knob or one of
the number buttons (1to 6) (or press
on RC-406).
• All the button illumination flash when
there is an incoming call.
• When
[AUTO ANSWER] is set to the
selected time, the unit answers
incoming call automatically.
(  11)
Reject an incoming
call
Press BSRC (or press on RC-406).
End a call Press or BSRC (or press on
RC-406).
Switch between
hands-free and
private talk modes
Press 6IW during a call.
• Operations may vary according to the
connected Bluetooth device.
Adjust the phone
volume
Turn the volume knob during a call.
Phone volume:
[00] to [35] (Default: [15] )
• This adjustment will not affect the
volume of the other sources.
Switch between two
connected phones
Press repeatedly.
• Not applicable during a call.
Improve the sound quality during a call
While talking on the phone...
1 Press the volume knob to enter [FUNCTION] .
2 Turn the volume knob to make a selection (see the following table),
then press the knob.
3 Press and hold to exit.
To return to the previous setting item or hierarchy, press .
Default: XX
MIC GAIN –20 —+ 8 ( 0 ):The sensitivity of the microphone increases as the number
increased.
NR LEVEL –5 — –20 ( –10 ):Adjust the noise reduction level until the least noise is
being heard during a phone conversation.
ECHO CANCEL 1 — 10 ( 4 ):Adjust the echo cancellation delay time until the least echo is
being heard during a phone conversation.
Text message notification
When the phone receives a text message, the unit rings and “SMS RECEIVED”
appears.
• You cannot read, edit, or send a message through the unit.
• To clear the message, press any button.
Use Voice Recognition
1 Press and hold to activate Voice Recognition.
The connected phone (which has been paired the earliest) is activated.
However, if priority device is connected, pressing and holding activate
the priority device.
( 12, DVC PRIORITY)
2 Speak the name of the contact you want to call or the voice command
to control the phone functions.
• Supported Voice Recognition features vary for each phone. Refer to the
instruction manual of the connected phone for details.
• This unit also supports the intelligent personal assistant function of iPhone.
BLUETOOTH®
JS_KWD_KDC_U559BT_MN_01_EN.indd 10JS_KWD_KDC_U559BT_MN_01_EN.indd 10 19/11/2013 12:10:51 PM19/11/2013 12:10:51 PM

11
ENGLISH |
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
BLUETOOTH®
Bluetooth mode operations
1 Press to enter Bluetooth mode.
2 Turn the volume knob to make a selection (see the following table),
then press the knob.
3 Press and hold to exit.
To return to the previous setting item or hierarchy, press .
CALL
HISTORY
1 Press the volume knob to select a name or a phone number.
• “I” indicates call received, “O” indicates call made, “M” indicates call
missed.
• Press
DISP SCRL to change the display category (NUMBER or NAME).
• “NO DATA” appears if there is no recorded call history.
2 Press the volume knob to call.
PHONE
BOOK
1 Turn the volume knob to select a name, then press the knob.
2 Turn the volume knob to select a phone number, then press the knob to call.
• If the phone supports PBAP, the phonebook of the connected phone is
automatically transferred to the unit when pairing. If the phone does not
support PBAP, “TRANSFER PB” appears. Transfer the phonebook manually.
(  13, TRANSFER PB)
• Contacts are categorized as: MO(mobile), HM(home), OF(office),
OT(others), GE(general)
• This unit can display only non-accent letters. (Accent letters such as “Ú” is
showns as “U”.)
• If the phonebook contains many contacts,
(  Select a contact by name).
NUMBER
DIAL
1 Turn the volume knob to select a number (0 to 9) or character ( , #, +).
2 Press S/ T to move the entry position.
Repeat steps
1 and 2 until you finish entering the phone number.
3 Press the volume knob to call.
(or using RC-406)
1 Press the number buttons ( 0 to 9 ) to enter the phone number.
2 Press to call.
VOICE Speak the name of the contact you want to call or use the voice command
to control the phone functions.
(  10, Use Voice Recognition)
BATT* LOW
/ MID / FULL :Shows the strength of the battery.
SIGNAL* NO SIGNAL / LOW / MID / MAX :Shows the strength of the current
received signal.
SETTINGS Default: XX
AUTO ANSWER 1
— 30 :The unit answer incoming call automatically in the selected
time.;
OFF :Cancels.
RING MODE SYSTEM: The unit rings to notify you when a call/text message comes in.
(Default ring tone is different according to the paired device.)
•
CALL: Selects your preferred ring tone ( TONE 1 — 5 ) for incoming
calls.
•
MESSAGE: Selects your preferred ring tone ( TONE 1 — 5 ) for
incoming text messages.
PHONE: The unit uses the connected phones’ ring tone to notify you
when a call/text message comes in. (The connected phone will ring if it
does not support this feature.)
SMS NOTIFY* ON: The unit rings and “SMS RECEIVED” appears to notify you of an
incoming text message.;
OFF :Cancels.
* Functionality depends on the type of the phone used.
Select a contact by name
• You can search through the contacts quickly according to the first letter
(A to Z), number (0 to 9), or symbol.
• The second alphabet of the contact will be searched if the first alphabet
does not exist.
1 Press to enter Bluetooth mode.
2 Turn the volume knob to select [PHONE BOOK] , then press the knob.
3 Turn the volume knob quickly to enter alphabet search mode.
The first menu (ABCDEFGHIJK) appears. To go to the other menu
(LMNOPQRSTUV or WXYZ1 ), press J/ K.
JS_KWD_KDC_U559BT_MN_04_EN.indd 11JS_KWD_KDC_U559BT_MN_04_EN.indd 11 12/17/2013 12:26:21 PM12/17/2013 12:26:21 PM

12
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
BLUETOOTH®
4 Turn the volume knob or press S/ Tto select the desired first
letter, then press the knob.
• To search with numbers, select “1”.
• To search with symbols, select “ ”.
5 Turn the volume knob to select a name, then press the knob.
6 Turn the volume knob to select a phone number, then press the
knob to call.
To return to the previous hierarchy, press .
Store a contact in memory
You can store up to 6 contacts.
1 Press to enter Bluetooth mode.
2 Turn the volume knob to select [CALL HISTORY] , [PHONE BOOK] , or
[NUMBER DIAL] , then press the knob.
3 Turn the volume knob to select a contact or enter a phone number.
If a contact is selected, press the volume knob to show the phone
number.
4 Press and hold one of the number buttons
(1to 6).
“STORED” appears when the contact is stored.
To erase a contact from the preset memory, select [NUMBER DIAL] in
step
2 and store a blank number.
Make a call from memory
1 Press to enter Bluetooth mode.
2 Press one of the number buttons (1to 6).
3 Press the volume knob to call.
“NO MEMORY” appears if there is no contacts stored.
Delete a contact
Not applicable for mobile phone that supports PBAP.
1 Press to enter Bluetooth mode.
2 Turn the volume knob to select [CALL HISTORY] or [PHONE BOOK] , then
press the knob.
3 Turn the volume knob to select a contact.
If a contact is selected, press the volume knob to show the phone
number.
4 Press and hold the volume knob to enter delete mode.
5 Turn the volume knob to select [DELETE ONE] or [DELETE ALL] , then
press the knob.
DELETE ONE : Selected name or phone number in step 3is deleted.
DELETE ALL : All names or phone numbers from the selected menu in
step 2is deleted.
6 Turn the volume knob to select [YES] or [NO] , then press the knob.
Bluetooth mode settings
1 Press the volume knob to enter
[FUNCTION] .
2 Turn the volume knob to select [BT MODE] , then press the knob.
3 Turn the volume knob to make a selection (see the following table),
then press the knob.
4 Press and hold to exit.
To return to the previous setting item or hierarchy, press .
Default: XX
PHONE SELECT
Selects the phone or audio device to connect or disconnect.
AUDIO SELECT
DEVICE DELETE
1 Turn the volume knob to select a device to delete, then press the knob.
2 Turn the volume knob to select [YES] or [NO] , then press the knob.
DVC PRIORITY Selects a device to be connected as priority device.
“” appears in front of the device name set as priority.
JS_KWD_KDC_U559BT_MN_02_EN.indd 12JS_KWD_KDC_U559BT_MN_02_EN.indd 12 28/11/2013 9:36:47 AM28/11/2013 9:36:47 AM

13
ENGLISH |
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
BLUETOOTH®
TRANSFER PB *
“DL PB ” appears and transfer the phonebook of the connected
phone to this unit manually.
* Selectable only when the connected phone supports OPP.
PIN CODE EDIT
(0000)
Changes the PIN code (up to 6 digits).
1 Turn the volume knob to select a number.
2 Press S/ T to move the entry position.
Repeat steps
1 and 2 until you finish entering the PIN code.
3 Press the volume knob to confirm.
RECONNECT ON :The unit automatically reconnect when the Bluetooth device is
within range.;
OFF :Cancels.
AUTO PAIRING ON :The unit automatically pair supported Bluetooth device (iPhone/
iPod touch) when it is connected through USB input terminal.Depending
on the iOS version of the connected iPhone/iPod touch, this function may
not work. ;
OFF :Cancels.
BT HF/AUDIO FRONT :Ouputs audio from the front left and right speakers.;
ALL :Outputs audio from all the speakers.
INITIALIZE YES :Updates all the Bluetooth settings (including stored pairing,
phonebook, and etc.).;
NO :Cancels.
Bluetooth audio player
Operations and display indications may differ according to their
availability on the connected device.
To Do this
Playback 1 Press BSRC (or press SRC on RC-406) to
select BTAUDIO.
2 Operate the Bluetooth audio player to start
playback.
Pause or resume
playback
Press 6IW (or press ENT IW on RC-406)
Select group or folder Press J/ K(or press *AM– /#FM+ on
RC-406).
Reverse/forward skip Press S/ T(or press S/ T(+) on
RC-406)
Reverse/fast-forward Press and hold S/ T(or press and hold
S/ T(+) on RC-406).
Repeat play Press 4 repeatedly to make a selection.
ALLREPEAT, FILEREPEAT, REPEATOFF
Random play Press 3 repeatedly to make a selection.
FOLDERRANDOM, RANDOMOFF
Press and hold 3to select “ALLRANDOM.”
JS_KWD_KDC_U559BT_MN_02_EN.indd 13JS_KWD_KDC_U559BT_MN_02_EN.indd 13 28/11/2013 9:36:48 AM28/11/2013 9:36:48 AM

14
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
AUDIO SETTINGS
While listening to any source...
1 Press the volume knob to enter [FUNCTION] .
2 Turn the volume knob to select [AUDIO CONTROL] , then press the
knob.
3 Turn the volume knob to make a selection (see the following table),
then press the knob.
Repeat step
3until the desired item is selected or activated.
4 Press and hold to exit.
(or using RC-406)
1 Press AUD to enter [AUDIO CONTROL] .
2 Press J/ Kto make a selection, then press ENT IW.
To return to the previous setting item or hierarchy, press .
Default: XX
SUB-W LEVEL –15 to +15 (0) Adjusts the subwoofer output level.
BASS LEVEL –8 to +8 (+6)
Adjusts the level to memorize for each source. (Before
making an adjustment, select the source you want to
adjust.)
MID LEVEL –8 to +8 (+5)
TRE LEVEL –8
to +8 (0)
EQ PRO
BASS ADJUST BASS CTR FRQ 60/ 80/ 100/ 200
: Selects the center frequency.
BASS LEVEL –8
to +8 (+6) : Adjusts the level.
BASS Q FACTOR 1.00/ 1.25/ 1.50/ 2.00 :Adjusts the quality factor.
BASS EXTEND ON
: Turns on the extended bass. ; OFF : Cancels.
MID ADJUST MID CTR FRQ 0.5/ 1.0/ 1.5/ 2.5K
: Selects the center frequency.
MID LEVEL –8
to +8 (+5) : Adjusts the level.
MID Q FACTOR 0.75/ 1.00/ 1.25
: Adjusts the quality factor.
TRE ADJUST
TRE CTR FRQ 10.0/ 12.5/ 15.0/ 17.5K : Selects the center frequency.
TRE LEVEL –8 to +8 (0) : Adjusts the level.
PRESET EQ DRIVE EQ / TOP40 / POWERFUL / ROCK / POPS / EASY / JAZZ /
NATURAL / USER :Selects a preset equalizer suitable to the music genre.
(Select
[USER] to use the customized bass, middle, and treble settings.)
[DRIVE EQ] is a preset equalizer that reduces noise from the road.
BASS BOOST LV1
/ LV2 / LV3 : Selects your preferred bass boost level. ; OFF : Cancels.
LOUDNESS LV1 / LV2 :Selects your preferred low and high frequencies boost to
produce a well-balanced sound at a low volume level.;
OFF :Cancels.
SUBWOOFER  SET ON :Turns on the subwoofer output.; OFF :Cancels.
LPF  SUBWOOFER THROUGH :All signals are sent to the subwoofer.; 85HZ / 120HZ /
160HZ :Audio signals with frequencies lower than 85Hz/ 120Hz/
160Hz are sent to the subwoofer.
SUB-W  PHASE REVERSE (180°)/ NORMAL (0°):Selects the phase of the subwoofer
output to be in line with the speaker output for optimum performance.
(Selectable only if a setting other than
[THROUGH] is selected for
[LPF SUBWOOFER] .)
FADER R15 to F15 ( 0 ):Adjusts the rear and front speaker output balance.
BALANCE L15 to R15 ( 0 ):Adjusts the left and right speaker output balance.
VOLUME  OFFSET
(Default: 0 )
–8 to +8 (for AUX) ; –8 to 0 (for other sources):Presets the volume
adjustment level of each source. (Before adjustment, select the source
you want to adjust.)
SOUND  RECNSTR
(Sound
reconstruction)
ON :Creates realistic sound by compensating the high-frequency
components and restoring the rise-time of the waveform that are lost in
audio data compression.;
OFF :Cancels.
• [SUB-W LEVEL] / [SUBWOOFER SET] / [LPF SUBWOOFER] / [SUB-W PHASE] is
selectable only if
[SWITCH PREOUT] is set to [SUB-W] . ( 4)
• [SUB-W LEVEL]
/ [LPF SUBWOOFER] / [SUB-W PHASE] is selectable only if
[SUBWOOFER SET] is set to [ON] .
JS_KWD_KDC_U559BT_MN_01_EN.indd 14JS_KWD_KDC_U559BT_MN_01_EN.indd 14 19/11/2013 12:10:51 PM19/11/2013 12:10:51 PM

15
ENGLISH |
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
MORE INFORMATION
General
• This unit can only play the following CDs:
• Detailed information and notes about the playable audio files are stated in an online manual
on the following web site: www.kenwood.com/cs/ce/audiofile/
Playable files
• Playable audio file: MP3 (.mp3), WMA (.wma)
• Playable disc media: CD-R/CD-RW/CD-ROM
• Playable disc file format: ISO 9660 Level 1/2, Joliet, Long file name.
• Playable USB device file system: FAT12, FAT16, FAT32
Even when audio files comply with the standards listed above, playback may be impossible
depending on the types or conditions of media or device.
Unplayable discs
• Discs that are not round.
• Discs with coloring on the recording surface or discs that are dirty.
• Recordable/ReWritable discs that have not been finalized.
• 8cm CD. Attempting to insert using an adapter may cause malfunction.
About USB devices
• This unit can play MP3/WMA/WAV files stored on a USB mass storage class device.
• You cannot connect a USB device via a USB hub.
• Connecting a cable whose total length is longer than 5m may result in abnormal playback.
• This unit cannot recognize a USB device whose rating is other than 5V and exceeds 1A.
DISPLAY SETTINGS
1 Press the volume knob to enter [FUNCTION] .
2 Turn the volume knob to select [DISPLAY] , then press the knob.
3 Turn the volume knob to make a selection (see the following table),
then press the knob.
Repeat step
3until the desired item is selected or activated.
4 Press and hold to exit.
To return to the previous setting item or hierarchy, press .
Default:
XX
COLOR SELECT VARIABLE SCAN / COLOR 01 — COLOR 24 / USER : Selects your
preferred button illumination color.
You can create your own color (when
[COLOR 01] — [COLOR 24] or
[USER] is selected). The color you have created can be selected when
you select
[USER] .
1 Press and hold the volume knob to enter the detailed color
adjustment.
2 Press S/ T to select the color ( R / G / B ) to adjust.
3 Turn the volume knob to adjust the level ( 0 — 9 ), then press the
knob.
DIMMER ON : Dims the display illumination (and button illumination). ;
OFF : Illuminates according to the [BRIGHTNESS] settings.
BRIGHTNESS LVL 0 — LVL 31 : Selects your preferred brightness level for display
illumination (and button illumination).
TEXT SCROLL AUTO / ONCE : Selects whether to scroll the display information
automatically, or scroll only once.
; OFF : Cancels.
JS_KWD_KDC_U559BT_MN_01_EN.indd 15JS_KWD_KDC_U559BT_MN_01_EN.indd 15 19/11/2013 12:10:52 PM19/11/2013 12:10:52 PM

16
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
TROUBLESHOOTING
Symptom Remedy
Sound cannot be heard. • Adjust the volume to the optimum level.
• Check the cords and connections.
“PROTECT” appears and
no operations can be
done.
Check to be sure the terminals of the speaker wires are
insulated properly, then reset the unit. If this does not solve
the problem, consult your nearest service center.
• Sound cannot be heard.
• The unit does not turn on.
• Information shown on
the display is incorrect.
Clean the connectors.
( 2)
The unit does not work at
all.
Reset the unit. ( 3)
• Radio reception is poor.
• Static noise while
listening to the radio.
• Connect the antenna firmly.
• Pull the antenna out all the way.
“NA FILE” appears. Make sure the disc contains supported audio files.
( 15)
“NO DISC” appears. Insert a playable disc into the loading slot.
“TOC ERROR” appears. Make sure the disc is clean and inserted properly.
“PLEASE EJECT” appears. Reset the unit. If this does not solve the problem, consult your
nearest service center.
Disc cannot be ejected. Press and hold
M to forcibly eject the disc. Be careful not
to drop the disc when it is ejected. If this does not solve the
problem, reset the unit.
( 3)
“READ ERROR” appears. Copy the files and folders onto the USB device again. If this
does not solve the problem, reset the USB device or use
another USB device.
“NO DEVICE” appears. Connect a USB device, and change the source to USB again.
“COPY PRO” appears. A copy-protected file is played.
MORE INFORMATION
About KENWOOD Music Editor Light and KENWOOD Music
Control
• This unit supports the PC application KENWOOD Music Editor Light and Android™ application
KENWOOD Music Control.
• When you play audio files with song data added using the KENWOOD Music Editor Light or
KENWOOD Music Control, you can search for audio files by Genres, Artists, Albums, Playlists, and
Songs.
• KENWOOD Music Editor Light and KENWOOD Music Control are available on the following web
site: www.kenwood.com/cs/ce/
About iPod/iPhone
Made for
- iPod touch (1st, 2nd, 3rd, 4th, and 5th generation)
- iPod classic
- iPod nano (3rd, 4th, 5th, 6th, and 7th generation)
- iPhone, iPhone 3G, 3GS, 4, 4S, 5
• For the latest compatible list and software versions of iPhone/iPod, see:
www.kenwood.com/cs/ce/ipod
• You cannot operate iPod if “KENWOOD” or “ ” is displayed on iPod.
About Bluetooth
• Depending on the Bluetooth version of the device, some Bluetooth devices may not be able
to connect to this unit.
• This unit may not work with some Bluetooth devices.
• Signal conditions vary, depending on the surroundings.
• For more information about Bluetooth, visit the following website:
www.kenwood.com/cs/ce/
JS_KWD_KDC_U559BT_MN_01_EN.indd 16JS_KWD_KDC_U559BT_MN_01_EN.indd 16 19/11/2013 12:10:52 PM19/11/2013 12:10:52 PM

17
ENGLISH |
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Symptom Remedy
“NA DEVICE” appears. Connect a supported USB device, and check the connections.
“NO MUSIC” appears. Connect a USB device that contains playable audio files.
“iPod ERROR” appears. • Reconnect the iPod.
• Reset the iPod.
Noise is generated. Skip to another track or change the disc.
Tracks do not play back as
you intended them to play.
Playback order is determined when files are recorded.
“READING” keeps flashing. Do not use too many hierarchical levels or folders.
Elapsed playing time is not
correct.
This is caused by how the tracks are recorded.
Correct characters are not
displayed (e.g. album
name).
This unit can only display uppercase letters, numbers, and a
limited number of symbols.
Bluetooth®
No Bluetooth
device is detected.
• Search from the Bluetooth device again.
• Reset the unit.
( 3)
Pairing cannot be
made.
• Make sure you have entered the same PIN code to both the
unit and Bluetooth device.
• Delete pairing information from both the unit and the
Bluetooth device, then perform pairing again.
( 9)
“DEVICE FULL”
appears.
The number of registered devices has reached its limit.
Retry after deleting an unnecessary device.
( 12, DEVICE
DELETE)
Echo or noise
occurs.
• Adjust the microphone unit’s position. ( 9)
• Check the [ECHO CANCEL] setting. ( 10)
Phone sound
quality is poor.
• Reduce the distance between the unit and the Bluetooth
device.
• Move the car to a place where you can get a better signal
reception.
TROUBLESHOOTING
Symptom Remedy
Bluetooth®
• Voice calling method is
not successful.
• “N/A VOICE TAG”
appears.
• Use voice calling method in a more quiet environment.
• Reduce the distance from the microphone when you
speak the name.
• Make sure the same voice as the registered voice tag is
used.
“NOT SUPPORT” appears. The connected phone does not support Voice
Recognition feature.
• “NO ENTRY” appears.
• “NO PAIR” appears.
There is no registered device connected/found via
Bluetooth.
“ERROR” appears. Try the operation again. If “ERROR” appears again,
check if the device supports the function you have
tried.
“NO INFO” appears. Bluetooth device cannot get the contact information.
Sound is being interrupted
or skipped during playback
of a Bluetooth audio
player.
• Reduce the distance between the unit and the
Bluetooth audio player.
• Turn off, then turn on the unit and try to connect again.
• Other Bluetooth devices might be trying to connect to
the unit.
The connected Bluetooth
audio player cannot be
controlled.
• Check whether the connected Bluetooth audio player
supports Audio/Video Remote Control Profile (AVRCP).
(Refer to the instructions of your audio player.)
• Disconnect and connect the Bluetooth player again.
• “HF ERROR XX” appears.
• “BT ERROR” appears.
Reset the unit and try the operation again. If this does
not solve the problem, consult your nearest service
center.
JS_KWD_KDC_U559BT_MN_03_EN.indd 17JS_KWD_KDC_U559BT_MN_03_EN.indd 17 12/12/2013 9:41:40 AM12/12/2013 9:41:40 AM

18
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
INSTALLATION / CONNECTION
Warning
• The unit can only be used with a 12V DC power supply, negative
ground.
• Disconnect the battery’s negative terminal before wiring and
mounting.
• Do not connect Battery wire (yellow) and Ignition wire (red) to the
car chassis or Ground wire (black) to prevent a short circuit.
• Insulate unconnected wires with vinyl tape to prevent a short circuit.
• Be sure to ground this unit to the car’s chassis again after
installation.
Caution
• For safety’s sake, leave wiring and mounting to professionals.
Consult the car audio dealer.
• Install this unit in the console of your vehicle. Do not touch the metal
parts of this unit during and shortly after use of the unit. Metal parts
such as the heat sink and enclosure become hot.
• Do not connect the
· wires of speakers to the car chassis or Ground
wire (black), or connect them in parallel.
• Mount the unit at an angle of less than 30º.
• If your vehicle wiring harness does not have the ignition terminal,
connect Ignition wire (red) to the terminal on the vehicle’s fuse box
which provides 12 V DC power supply and is turned on and off by the
ignition key.
• After the unit is installed, check whether the brake lamps, blinkers,
wipers, etc. on the car are working properly.
• If the fuse blows, first make sure the wires are not touching car’s
chassis, then replace the old fuse with one that has the same rating.
Basic procedure
1 Remove the key from the ignition switch, then
disconnect the
· terminal of the car battery.
2 Connect the wires properly.
See Wiring connection.
( 19)
3 Install the unit to your car.
See Installing the unit (in-dash mounting).
4 Connect the · terminal of the car battery.
5 Reset the unit. ( 3)
Do the required wiring.
( 19)
Dashboard of
your car
Bend the appropriate tabs to hold the
mounting sleeve firmly in place.
How to remove the unit
1 Detach the faceplate.
2 Fit the catch pin on the extraction keys
into the holes on both sides of the trim
plate, then pull it out.
3 Insert the extraction keys deeply into the
slots on each side, then follow the arrows
as shown on the right.
Installing the unit (in-dash mounting)
When installing without the mounting sleeve
1 Remove the mounting sleeve and trim plate from
the unit.
2 Align the holes in the unit (on both sides) with the
vehicle mounting bracket and secure the unit with
screws (commercially available).
Use only the specified screws. Using wrong screws might damage the unit.
Hook on the top side
Orientate the trim plate as
illustrated before fitting.
JS_KWD_KDC_U559BT_MN_01_EN.indd 18JS_KWD_KDC_U559BT_MN_01_EN.indd 18 19/11/2013 12:10:52 PM19/11/2013 12:10:52 PM

19
ENGLISH |
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Part list for installation
(A) Faceplate
(C) Mounting sleeve
(B) Trim plate
(D) Wiring harness
(E) Extraction key
Wiring connection
Fuse (10A)
Front output, Rear/ subwoofer output
Antenna terminal
Car fuse box
Car fuse box
Battery
Ignition switch
Blue/White
(Power control wire/
Antenna control wire)
Light blue/yellow
(Steering remote
control wire)
Red
(Ignition wire)
Yellow
(Battery wire)
Black (Ground wire)
To the metallic body or chassis
of the car
To the power control terminal when using
the optional power amplifier, or to the
antenna control terminal in the vehicle.
Brown
(Mute control wire)
White
Gray
Green
Purple
White/Black
Gray/Black
Green/Black
Purple/Black
To connect the Kenwood navigation system,
refer your navigations manual.
To front speaker (left)
To rear speaker (left)
To front speaker (right)
To rear speaker (right)
To the steering wheel remote control
adapter
Microphone input jack
( 9)
If no connections are made, do not let the wire
come out from the tab.
JS_KWD_KDC_U559BT_MN_04_EN.indd 19JS_KWD_KDC_U559BT_MN_04_EN.indd 19 12/17/2013 12:27:17 PM12/17/2013 12:27:17 PM

20
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
SPECIFICATIONS
Tuner
FM Frequency Range 87.5MHz — 108.0MHz (50kHz space)
87.9MHz — 107.9MHz (200kHz space)
Channel Space Selection 50kHz/ 200kHz
Usable Sensitivity (S/N=26dB) 8.2dBf (0.71μV/75Ω)
Quieting Sensitivity
(DINS/N=46dB)
17.2dBf (2.0μV/75Ω)
Frequency Response (±3dB) 30Hz — 15kHz
Signal-to-Noise Ratio (MONO) 64dB
Stereo Separation (1kHz) 40dB
MW/
SW1/
SW2
Frequency Range Band 1 (MW) 531 kHz to 1 611 kHz (9 kHz space)
530 kHz to 1 700 kHz (10 kHz space)
Band 2 (SW1) 2 940 kHz to 7 735 kHz (5 kHz space)
Band 3 (SW2) 9 500 kHz to 10 135 kHz/
11 580 kHz to 18 135 kHz (5 kHz space)
Channel Space
Selection
Band 1 9 kHz/10 kHz
Band 2/ 3 5 kHz
Usable Sensitivity
(S/N=20dB)
MW 29.0 dBμ (28.2 μV)
SW 30 dBμ (32μV)
CD player
Laser Diode GaAIAs
Digital Filter (D/A) 8 times over sampling
Spindle Speed 500rpm — 200rpm (CLV)
Wow & Flutter Below measurable limit
Frequency Response (±1dB) 20Hz — 20kHz
Total Harmonic Distortion (1kHz) 0.01%
Signal-to-Noise Ratio (1kHz) 105 dB
CD player
Dynamic Range 90dB
Channel Separation 85dB
MP3 Decode Compliant with MPEG-1/2 Audio Layer-3
WMA Decode Compliant with Windows Media Audio
USB
USB Standard USB1.1, USB2.0 (Full speed)
File System FAT12/16/32
Maximum Supply Current DC5V 1A
MP3 Decode Compliant with MPEG-1/2 Audio Layer-3
WMA Decode Compliant with Windows Media Audio
WAV Decode Linear-PCM
Bluetooth
Version Bluetooth Ver.2.1+EDR Certified
Frequency Range 2.402GHz — 2.480GHz
Output Power +4dBm (MAX), 0dBm (AVE) Power Class 2
Maximum Communication
Range
Line of sight approx. 10m
Profile HFP (Hands-Free Profile)
SPP (Serial Port Profile)
PBAP (Phonebook Access Profile)
OPP (Object Push Profile)
A2DP (Advanced Audio Distribution Profile)
AVRCP (Audio/Video Remote Control Profile)
JS_KWD_KDC_U559BT_MN_04_EN.indd 20JS_KWD_KDC_U559BT_MN_04_EN.indd 20 12/18/2013 12:19:23 PM12/18/2013 12:19:23 PM
