SERVICEMANUAL
CD RECEIVER
KDC-X917/X817/9017
●KDC-X817
PTY
4.5V
PREOUT
AUD
OFF
SRC
DISC
DAB
AME AUTO
KDC-X817 System E's+
EX
COMPACT
TEXT
DIGITAL AUDIO
50Wx 4
CLK
LOUD SCANMENU RDM REP M. RDM
DISC
NF
ANG
NAME
DISP
Knob(EJECT)
(K24-3653-04)
Front glass
(B10-3252-01:X917)
(B10-3253-01:X817)
(B10-3254-01:9017)
Panel assy
(A64-2149-02:X917)
(A64-2150-02:X817)
(A64-2151-02:9017)
Knob(VOL)
(K25-1216-03) Knob(1-6)
(K25-1221-03)
Knob(FM/AM)
(K25-1218-03)
Screw set
(N99-1704-05)
Escutcheon
(B07-3010-02)
Stay
(J54-0606-04)
Remote controller assy
(A70-0883-05:9017)
(A70-0894-05:X917/X817)
Bracket
(J19-5051-03:L)
(J19-5052-03:R)
Mounting hardware assy
(J21-9716-03)
Plastic cabinet assy
(A02-1497-03)
DC cord
(E30-4939-05:X917/X817)
(E30-4940-05:9017) Screw set
(N99-1652-05) Lever
(D10-4562-04)
Torsion coil spring
(G01-2924-04)

KDC-X917/X817/9017
2
BLOCK DIAGRAM
PLL+B
FM+B
AM+B
DIMMER
MUTE
2WAY
DET. ACC
SRM
BU DET.
SRM DRIVER
A8V
SERVO
DC/DC
SW5V BU5V
P CON
ANT-CON
MUTE
DRIVER
4.5V PRE
MUTE
E's
POWER IC
IC4
u-COM
IC1
CD
CH
IC7
IC10-12
Q37-42
IC5
IC2
F/E
MECHA
E-VOL
PRE OUT SP-OUT
DIMMER TEL-MUTE ACC ANT-CONT P-CON BACK UP
DECORDER
RDS
IC14
IC8
Q14 Q15
Q31
Q26-29
Q1,2Q3
Q51
Q9
Q30
IC15
IC2
IC1
IC3
EX.AMP CONTROL
AVR
DC/DC BOX
PANEL u-COM
RESET
SW
RESET IC
VFD
(GRADATED)
REMO G/R SW
SPEANA
IC16
BUFFER
Q36
NOISE
PRE OUT OUTPUT VOLTAGE
SPEANA AGC OPAMP
CONTROL EX.AMP
NAVI-MUTE
PANEL 5V
4.5VPRE
Q4-6
Q7,8
IC6
DC/DC REG
KEY MATRIX
BFP
IF+B
SW14V
IC4
IC5
ROM
REG 3.3V
CH S-METER
QUAL
SERVO+B
MUTE R
M STOP
SW2
LO/EJ
MUTE L
M RST
SW3
SW1
MS DATA
MS CLK
A8V BU5V
SW5V
RST
REQ C
CLK
CH-CON
DATA H
REQ H
CD AM FM
MUTE
PRE MUTE
MC REQ
PANEL RST
SC REQ
MC CLK
SC DATA
MC DATA
RESET
SRM SW2
SRM SW3
SRM DET
SRM SW1
RDCK
RDDA
QUAL
SDA
SCL
AFS
AFS
S-METER
A8V
+B -B
+B -B
SCL
SDA
S-METER SW5V
DATA C
BACK UP
PANEL 5V
PANEL 5V
FAC
FL+B
750mV
4500mV
CHANGER
AM
4.5V PRE
2250mVFM
230mV
1200mV
1200mV
251mV (E TYPE) 470mV (K TYPE)
IFC OUT
AUDIO OUT
SW5V
NOISE
IFC OUT
4500mVCD K TYPEMODE 4500mV
4500mV
1069mV 1715mV
E TYPE 3600mV
600mV
1800mV
3600mV
K TYPE E TYPE
3600mV
1372mV
855mV
3600mV
1.8V PRE
SRM SUB-
SRM SUB+
DRIVER
MUTE
BU5V
MO SW
Q52
BUFF
FL(GRADATED) TYPE (X13-994)

KDC-X917/X817/9017
3
MICROCOMPUTER'S TERMINAL DESCRIPTION
●Terminal description
Pin Function I/O Description Processing Operation
1 AM+B O AM power terminal H: During AM radio operation
2 FM+B O FM power terminal H: During FM radio operation
H: During FM radio operation if with RDS, RBDS
3AFS O Switching terminal for noise detection L: During AF search, FM seek
H: During receive
4 PLL-DATA I/O Data I/O terminal to F/E
5 PLL-CLK I/O CLK terminal to F/E
6 Evdd - Positive power terminal
7 Evss - GND terminal
8 N.C O Open (not used)
9 BEEP O BEEP output terminal
10 N.C O Open (not used)
11 PRE-MUTE L O L (during CD): when M MUTE L is L (low)
L during momentary power down
Fixed at H only during 2 zone
12 PRE-MUTE R O L (during CD): when M MUTE R is L (low)
L during momentary power down
Fixed at H only during 2 zone
13 IC2-SDA I/O IC2, IC5, CD mechanism, DATA line
14 IC2-SCL O IC2, IC5, CD mechanism, CLK line
15 N.C O Open (not used)
16 N.C O Open (not used)
17 N.C O Open (not used)
18 TEST - Test terminal
19 P-MUTE O Power IC MUTE terminal L: During Power-OFF L: During All-OFF
L: During Tell-mute
20 P-STBY O Power IC STBY terminal Power IC ON: H. Power IC OFF: L. During All-OFF: H
21 MUTE O MUTE termianl ON: Open OFF: L
22 N.C O Open (not used)
23 N.C O Open (not used)
24 ACC-DET I ACC detection terminal L: ACC H: No ACC
25 DIMMER I Small detection terminal ON: L OFF: H
26 SW5V O 5 volt power terminal ON: L OFF: H
27 EXT-AMP-CO O External AMP control terminal (200ms) L 40ms: Bus boost OFF
L 70ms: Bus boost LOW
L 100ms: Bus boost HI
28 P-CON O Power control terminal Power ON: H Power OFF: L
29 ANT-CON O Antenna control terminal TUNER, TI ON: H Open if no ANT-CON
30 P-ON O SW14V control terminal Power ON: H Power OFF: L
31 RESET I Reset IN terminal H: Normally H: During reset
32 XT1 I Subclock terminal Time count Operation during Power-OFF
33 XT2 - Subclock terminal
34 REGC - Capacitor output terminal for regulator inside microprocessor
35 X2 - Main clock terminal Oscillates: During Power-ON
Oscillates stop: During Power-OFF, during
momentary power down
36 X1 I Main clock terminal
37 Vss - GND terminal
38 Vdd - +B terminal
39 CLKOUT O Internal system clock output
40 N.C O Open (not used)
41 N.C O Open (not used)
42 TYPE0 I Destination selector port
43 TYPE1 I Destination selector port
44 TYPE2 I Destination selector port
45 N.C O Open (not used)
46 IC2TYPE0 I IC2 destination terminal L: During default
System µ-com: UPD703033GC051

KDC-X917/X817/9017
4
MICROCOMPUTER'S TERMINAL DESCRIPTION
Pin Function I/O Description Processing Operation
47 IC2TYPE1 I IC2 destination terminal L: During default
48 CH-REQH O Request output to changer
49 CH-RST O Reset output to changer Normally L, after system RST reset is ”H” for
400ms and then ”L”
50 CH-MUTE I Mute request from changer ON: H OFF: L
51 CH-CON O Changer control output ON: H OFF: L
52 ILL-ON O FL, illumination output ON: H OFF: L
53 M-MUTE L I Mute request from CD mechanism ON: L
54 M-MUTE R I Mute request from CD mechanism ON: L
55 BVdd - +B terminal
56 BVss - GND terminal
57 M-RST O Reset output to CD mechanism Normally H, L:During reset
Per mechanical control specs.
58 M-STOP O Stop request to CD mechanism Stop: L H: During CD
59 N.C O Open (not used)
60 LO/EJ I/O CD mechanism, LODING, EJECT selector Stop, Brake: Hi-z, LOADING: L, EJECT: H
61 MOSW O CD mechanism, MOTOR, SW LOADING, EJECT, Brake: H
62 N.C O Open (not used)
63 CD-SW3 I CD down SW detection terminal Chucking: H
64 PAN-RESET O Reset output to panel microprocessor Normally H, L: During reset, momentary power down
65 MC-REQ/PAN I/O REQ terminal/panel detection for panel microprocessor L: During panel use
66 N.C O Open (not used)
67 N.C O Open (not used)
68 N.C O Open (not used)
69 N.C O Open (not used)
70 AVCONT O AD reference voltage control output Same timing as P ON H: During operation
71 Avdd - +B terminal
72 Avss - GND terminal
73 Avref I Reference voltage supply terminal for A/D converter
74 PHONE I PHONE detection terminal Tel mute: Min 1 volt, Navi mute: Max.2.5 volt
75 SRM-SW3 I Mask mechanism position detection input See 01mask mechanical position detection chart
76 SRM-SW1 I Mask mechanism position detection input See 01mask mechanical position detection chart
77 SRM-SW2 I Mask mechanism position detection input See 01mask mechanical position detection chart
78 SRM-DET I Mask mechanism detection input L: Mechanism H: No mechanism
79 NOISE I FM noise detection terminal
80 S-METER I S meter detection terminal
81 R-DATA I RDS DECODER DATA input terminal Connect to GND: On models without RDS,
RBDS
82 R-QUAL I RDS DECODER QUAL input terminal Connect to GND: On models without RDS,
RBDS
83 IFC-OUT I F/E IFC OUT input terminal L: When station present
84 N.C I Open (not used) Connect to GND
85 N.C I Open (not used) Connect to GND
86 SRM-B O SRM mechanical submotor output terminal
87 R-CLK I RDS DECODER CLK input terminal Connect to GHD: On models without RDS,
RBDS
88 CH-REQC I Input request from changer ON: L
89 SC-REQ I Communication request from panel microprocessor
90 CD-SW1 I LOADING SW detection terminal LOADING start: L
91 CD-SW2 I 12cm disk detection switch terminal 12cm DISC: L
92 SRM+B O SRM mechanical submotor output terminal
93 BU-DET I Momentary power down detection terminal L: B.U H:NoB.U(momentary power down)
94 CH-DATAC I Data input terminal from changer
95 CH-DATAH O Data input terminal to changer
96 CH-CLK I/O CLK I/O terminal used with changer
97 SC-DATA I Data line from panel microprocessor
98 MC-DATA I/O Data line to panel microprocessor
99 MC-CLK O CLK terminal to panel microprocessor
100 PAN5V O Panel 5 volt control terminal L: Panel H: No panel

KDC-X917/X817/9017
5
ADJUSTMENT
Test Mode
1. How to enter test mode
While holding the FM key and the Preset 6 key, reset the
unit.
2. How to exit from test mode.
While holding down the Preset 6 key, reset the unit.
Note: Does not exit from test mode ACC-OFF, Power-OFF
or Momentary power down
3. Test mode reset status
•Sources are all OFF
•All display segment lit up
•Volume at -10dB (shows 30 on display)
•LOUD is OFF.
•CRSC is OFF regardless of whether switching function is
provided.
•SYSTEM Q is in FLAT
•Blank skip is OFF. (C/R model)
•LEDs are white, no scanning. (VLCD model)
4. Special displays in Tuner
When the following displays appear in tuner mode it shows
a problem with the front end.
•“TNE2P NG” ..... F/E is not aligned and EEPROM is in
reset (no settings) such as when shipped.
•“TNCON NG” .... Cannot communicate with F/E (front
end).
5. K3I switching
Each time the Preset 6 key is pressed in Tuner mode,
switches one at a time through the following sequence:
AUTO →Forced Wide →Forced Middle →Forced Narrow
→AUTO. When reset, displays the following in AUTO.
•AUTO ................ FMA
•Forced Wide ..... FMW
•Forced Middle ... FMM
•Forced Narrow .. FMN
6. CD receiver test mode specifications
•No automatic ejection during reset-start. Does not make a
CD check in reset with a CD loaded.
•Using the Track up key jumps to the following tracks.
No.9→No.15→No.10→No.11→No.12→No.13→No.14→and
back to No. 9
•Using the Track down key moves 1 track downwards from
the track being played.
7. Audio items
•Momentarily pressing the Q key calls up audio adjustment
mode.
•Pressing the ∗key on the remote control calls up audio
alignment mode.
•Continuous forward is disabled on the remote control.
•Bass/Middle/Treble are settable in 3 steps of MIN/
CENTER/MAX with the Track up/down keys.
•Balance is settable in 3 steps of Left MAX/CENTER/Right
MAX with the Track up/down keys.
•Fader is settable in 3 steps of Rear MAX/CENTER/Front
MAX with the Track up/down keys.
•HPF is settable in 2 steps of THRU/220Hz with the Track
up/down keys.
•LPF is settable in 2 steps of THRU/120Hz with the Track
up/down keys.
•Bass f/Bass Q/Bass EXT/Middle f/Middle Q/Treble f do
not appear in the audio alignment.
8. Menu items
•Momentarilypressing theCLK keycalls upthe Menumode.
•The DNPP/SBF keys on the remote control calls up Menu
mode.
•Continuous forward is disabled on the remote control.
•Calendar adjust, calendar display switching and calendar
memo are eliminated from forward (FL model)
•In color alignment mode, Preset 1 is red, 2 is blue, 3 is
green and 4 is white. (VLCD model).
•Contrast is set in 3 steps of 0, 5, 10 and the reset value is
5. (VLCD/LCD models)
•Brightness adjustment is set in 3 steps of 0, 5, 10 and the
reset value is 10. (Normal FL model)
9. Backup current measurement
The MUTE terminal turns off 2 seconds (not 15 seconds)
after being reset in ACC off (backup on). (The panel, CD
and tape mechanisms are disabled during this time.)
10. Special displays during All-Off with all lamps on
The following displays appear when the preset keys are
pressed with all display segment lit up.
PRESET1 Version display (8 digits; Mo. Dy. Hr. Mn.)
(Display) SYS XXXXXXXX system microprocessor
PAN XXXXXXXX panel microprocessor
PRESET2 Serial No. display (8 digits) Note: CD/RK type eXcelon model
(Display) SNo XXXXXXXX
PRESET3 Press once: Power-on time display (Does not count during All-Off)
Press long: Clears the time display during power-on.
(Display) PonTim XXXXX (C/R) MAX 65535(time)
PRESET4 Press once: TAPE/CD/MD operating time display.
Press long: Clears TAPE/CD/MD operating time.
(Display) CDTime XXXXX (CD/R)
TapTim XXXXX (C/R) MAX 65535(time)
PRESET5 Press once: TAPE/CD/MD eject count display.
Press long: Clears TAPE/CD/MD eject count display.
(Display) EjeTim XXXXX MAX 65535(count)
PRESET6 Press once: PANEL open/shut count display.
Press long: Clears PANEL open/shut count display.
(Display) PnCnt XXXXX MAX655350(count)

KDC-X917/X817/9017
6
ADJUSTMENT
11. Others
•Automatic panel close is disabled when tape or CD is
inserted. (M&T model)
•Panel operation is disabled at Power-ON or Power-OFF.
(M&T model)
•Panel open and closes with the ATT key. (M&T model)
•No displays such as “CODE OFF” during Power-ON.
•Pressing the TI (AUTO) key during changer operation turns
on 2zone. Cancel by pressing the TI (AUTO) key again.
The P/S dot is lit during 2zone.
•Pressing the CLK key for 1 second or more during All OFF,
calls up the Mask Key (security) write mode.
Security items
•Forced power-ON mode (all models)
Even when writing is permitted by the security function (mask
key), Power-on can be set for a 30 minute period each time
the reset key is pressed while holding down the ATT key
and Preset 4 keys. After 30 minutes elapses, can only be
restored by using reset.
•How to register the security code for EEPROM (F/E)
replacement (coded security models)
1. While holding the FM key and the preset 6 key, reset the
unit.
2. Call up security register mode by pressing the CLK key.
3. Enter the code with the Preset 1/2/3/4 keys.
For example, to enter the number, “3510”....
- Press the Preset 1 key 4 times.
- Press the Preset 2 key 6 times.
- Press the Preset 3 key 2 times.
- Press the Preset 4 key 1 time.
4. Hold down the DISP key for at least 3 seconds and the
message, “RE-ENTER” appears, so once again enter
the code according to Step 3 above.
5. Hold down the DISP key for at least 3 seconds, and the
message, “APPROVED” appears.
6. Cancel test mode. (See, 2. How to cancel the test mode.)
Note: All clear cannot be performed on the security code
for this model.
•Simple way to clear the security code (K type only)
1. During code request mode, press the VOL UP key for at
least 3 seconds while holding down the DISP key.
(---- will disappear)
2. Enter, “KCAR” with the remote controller as described
below. (Same as on 00 model.)
Press the remote controller 5 key twice, and press the
Track Up key. (Enters a “K”)
Press the remote controller 2 key three times, and press
the Track Up key. (Enters a “C”)
Press the remote controller 2 key once, and press the
Track Up key. (Enters an “A”)
Press the remote controller 7 key twice, and press the
Track Up key. (Enters an “R”)
3. Security function is canceled and unit sets to All-Off mode.
4. Code request mode appears if a mistake was made in
entering the numbers.

78
IHGE FDCA B
1
2
3
4
5
6
7
PC BOARD (Component Side View)
R45
C34
/MUTER
D.OUT
R125
RW
LDON
FBAL
R233
RF GND
ARF IOP-
IOP+
F
TE
TR
TBAL
TE
FE
+
-
-+
GCTL
A
R234
C
D
B
1
Vref E
R54
R38
R37
C26
C85
R36
R34
R32
R218
C35
C25
C28
C24
LDCNT
X1
R46
R76
R82
R73
EJECT/SLED-
22 FCS+
LD
R3
16
VR PD
FCS-
Vc
Vcc
F
R6
TRK-
TRK+
CP3
A.+B
S.+B
SW3
Rch
S.GND
1
SLED+
LOAD
+
-ECS
+
FOD
R107
R47
B
CP1
E
CP2
BU.5V
C21
SPDL+
SPDL-
A.GND
Lch
TVD-
-
+
R75
/MSTOP
/MRST
C45
R83
R72
R71
C43
R81
BBEE
R77
R108
SW1
/CLK
DATA
R104
SW2
D.GND
/RST
C71
R121
R117
5
C72
C68
4
R122
R102
R118 R126
C77
8
C79
C80
1
C78
A.5V LO/EJ
/MUTEL
MOTOR
R78
C41
R44C51
C67
R103
C63
+
EB
GO I
D4
CN2
CN1
Q4
Q2
D2
Q5
IC6
D3
Q3
IC5
R213
C6
VDET
OFT
R19
C15 C19
/RFDET
C7
C11
C10
R11
R10
C12
16
C8
1
C89
BDO
TRCRS
R202
C2
C16
17
32
R17
C18
IPFLAG C23
R16 C14
R15
25
C17
R18
C13
TOFS
C29
26
C33
C20
R21
R20
1001
51
STLD
FLAG
FCLK
50
ST-O
SMCK
75
DQSY
76
R5
R8
C5
B
E
R12 R9
C4
W17
C1
C3
CLVS C55
C46
R52
R49
14
1
15
28
IC1
IC2
S2
Q1
D1
S3
X32-5030-00 (J74-1161-02)
S1
IC4
.ON.feR sserddA
CIQ
1B4
2C4
4D2
5D3
6D3
1B4
2D4
3D3
4C4
5D4
.ON.feR sserddA
CIQ
1H4
2G4
4F2
5F3
6F3
1H4
2F4
3F3
4G4
5F4
PC BOARD (Foil Side View)
CD PLAYER UNIT CD PLAYER UNIT
CD PLAYER UNIT
(X32-5030-00) CD PLAYER UNIT
(X32-5030-00)
Refer to the schematic diagram for the values of resistors and capacitors.
C85
R45
R44 C51
C34
C41
CP1
R117
X1
R121
C72
C77
R125
R104 C78
R122
R118 R126
R102
R107
R108
C79 C80
R32
C68
C67
R103
C63
C71
C24
R36
C26
R34
R77
R37
C28
R38 C25
R46
R73
C21
R75
CP2
CP3
R54
C43
R72
R71
R81
R83
C45
R82
R47
R78
R76
R6
R3
R233
C35
R234
R218
GCTL
TBAL
FBAL
+
LDON
-
+
FE+
RW
LDCNT
ECS
-
+FOD
CB
D
1
F
Vcc
Vc
EJECT/SLED-
DATA
/CLK
D.GND
D.OUT
BU.5V
PD
1
1
/MRST
SPDL+
-
+TVD MOTOR
Rch
TRK-
LD VR
FCS+ TRK+
FCS-
A.+B
/MUTEL
/MUTER
LOAD
SLED+
A.GND
/MSTOP
SPDL-
S.GND
S.+B
SW3
IOP-
GND
ARF
Vref
FE
Lch
LO/EJ A.5V
SW2
+
/RST
RF
TE
TR
SW1
IOP+
A
TE
-
-
4
8
5
22
16
EBEB
EB
BE
D4
IC6
Q3 GO
I
IC5
Q4
D2
CN1
Q2
Q5
D3
CN2
W17
C89
R5
C29
C46
R52
C23
R49
C33
R9
C20
C19
R20
R8
C1
C8
C12
C10
C11
R18
C3
C2
C17
C18
R17
C16
R15 C15
C14 R16C13
R12
R10
C7
C6
R11
C5
R19
R213
R202
C55
R21
C4
CLVS
VDET
TRCRS
BDO
/RFDET OFT
1
STLD
SMCK
ST-O
FLAG
TOFS FCLK
DQSY
IPFLAG
1
1
16
32
17
25 51
75
76100
50
26
14 15
28
B
E
IC1
IC4
D1
S3
S2
Q1
IC2
S1
X32-5030-00 (J74-1161-02)

JKLMNOP RQ
1
2
3
4
5
6
7
910
Refer to the schematic diagram for the values of resistors and capacitors.
SWITCH UNIT
R25
C8
C11
C9
R18
R17
R2
R1
R7
C15
C10
R22
R27
R28
R33
R26
L1
R23
R24
R8
R6
R5
R12
R11
R9
R14
R19
R20
R4
R3
R13
C7
C5
C6
C17
C18
R40
C14
C16
R39
C1
R36
R34
R35
C4
C3
C2
CP1
CP18 CP19
CP15
CP17
CP16
CP3 CP2
CP13
CP20
CP14
L11
L10
L9
CP21
CP4
CP22
X1
C12
R21
L8
L12
R29
C19
R30
R31
BBE E
E
B
EB
EB
B
E
EB
9
16 1
8
9
118
10
76 75 51 50
26
25
1
100
25
48
124
1
214
15
DO
CLK
KS1
KS2
KS3
KS4
3.3V
P RESET
FAC
FAC
SC DATA
SCREQ
RST
MC
REQ
MC CLK
FL GND
ANA
DGND
VDD
S.GND
S.GND
KR1
KR2
KR3
KR4
KR5
DI
FL+B
1
3
4
5
J1
S22
IC6
IC5
Q3
Q4
Q2
Q7
Q8
Q5
Q6
IC1
IC2
D3
D4
D5
D1
D2
D6
IC4
D7
12
3
4
DISP
ATT
EJECT
CLK 1 2 3 4 5 6 TI RST
FM
AM
dB
118
S10S9
S12S11
S6
S5
S8
S7
S18
S17
S20
S19
S14
S13
S16
S15
S2
S1
S4
S3
IC3
S21
ED1
X13-9940-10 (J74-1134-02)
PC BOARD (Component Side View)
D2
D35
D36
Q10
D39
D38
D41
D40
D33
D13
D34
D47
D50
D49
D21
Q6
Q34
Q19
Q20
Q35
Q18
Q45
Q43
Q21
Q22
Q29
Q28
Q23
Q27
Q24
Q14
Q52
Q36
D11
BE
L5
R173
R174
R177
R178
R175
R176
R186
R183
R165
R184
R185
R188
R187
R164
W4
W3 W6
W5
W2
R41
R39
W1
TH1
W10
W15
W9
R168
W7
R8
R163
R9
R7
C14
R1
C7
R167
W8
R37
R33
R12
R166
R136
R13
R132
R131
R155
R157
R156
R130
R137
R134
R133
R135
R237
R239
R236
R234
R235
R232
R233
R92
R93
R90
R99
R97 R101
R100
R95
R62
R60
R67
R81
R89
R79
R83
R144
R143
R147
R220
R142
R141
R140
R148
R204
R202
R151
R150
R152
R121
R104
R107
R109
R225
R221
R223
R224
R119
R126
R125
R124
R55
C38
C37
C42
C43
C41
C149
C144
C145
C30
C31
C146
C70
C73
C62
C75
C72
C71
C46
C54
R30
R29
R31
C131
R32
R25
R26
R28
R27
R50
R53
R51
C2
R36
C141
C135
C4
C137
C10
C139
R22
C133
R34
C110
C113
C109
C103
C111
C104
C98
C112
C97
R241
R242
C48
C35
R205
R207
R208
R206
R158
R98
C90
C92
C91
C89
R61
R59
R56
R54
R52
C17
C12 C18
C55
R127
C150
BE
BE
BE
BE
EB EB
EB
BE
EB
EB
BE
BE
BE
BE
BE
BE
BE
BE
R179
R180
R181
R161
R182
R172
R170
R171
C88
C87
C83
C84
R190
R162
R189
R169
R10
6
1
R14
C27 C26
C28
R15
R19
C25
R91
R94
R72
R71
R73
R74
R66
R70
R69
R80
R84
R86 R88
R78
R75
R82
R85
R102
R146
R214
R145
R215
R216
R203
R211
R200
R201 R213
R154
R153
R116 R115
R114
R118 R117
R110
R108
R120
R230
R122
C39
R47
C20
C148
C147
C74
C44
C45
R24
R48
C21
R42
R44
R43
R23
R2
R3
R20
R17
R21
R6
R4
R16
X2
R11
X1
R231
R49
C129
R113
R77
W100
TEST
DATA
CLK
RST
81
C3
R46
R45
X3
C1
C101C102C96C95
C143
C108
C115 C107
C142
C53
C60
C51
C52
C65
C68
C63
C66 C23
C32
C5
C22
C49 C50
C36
C34
C67
C77
C76
C114
C40
C105
C69
C106
C94C93
C29
C100
C99
C9
C24
C15
C6
C8
C61
C118C119 C120
C78
C117
C79
L2
L1
C116
R38
R40
R5
C200
L7
L9
L12
L13
L10
L11
R212
R210
C86
C82
C85
C81
L6
L3
L14
C13
C11
C33
L4
B
E
B
E
B
EB
E
B
E
B
E
BE
B
E
B
E
BEBE
B
EB
E
BE
B
E
B
E
B
E
BE
B
E
1
14
15
28
8
1
4
5
13
12
1
2
6
9
16
1
9
81
1
1
2
25
13
24
1
2
24
4
1
5
8
2
3
1
4
1
7
14
8
1
8
5
4
1
4
58
I
G
O
44 34
33
23
22
12
11
1
18
5
4
1
8
16
9
1
5
610
222
121
E
B
125
26
50
51
75
76
100
E
B
17
1
BE
BEE
B
BE
BE
E
B
E
B
E
B
SMTR IFC-OUT
NOISE
IC7
IC5
IC15
IC14
IC3
D44D46 D45
D48
D19
D20
Q8 Q7
Q11
Q39
Q2
Q5
Q3
Q12
Q37
Q38
Q15
Q13
Q17
Q33
Q42
Q30
Q32
Q31
Q40
Q41
Q46
Q44
IC10
IC11
IC8
IC12
IC6
IC16
IC2
IC1
Q51
D25
D26
CN3
CN6
CN5
WH1
CN7
CN2
A1
Q4
Q1
Q9
J1
Q16
Q26
Q25
D1
D9
D3
D4
D17
D10
D16
D5
D6
D14
D12
IC4 CN1
D15
D8
D7
E1
D32
D30
D31
D27
D28
D29
D24 D23 D22
D18
X25-8730-10 (J74-1142-02)
CN4
F/E
ELECTRIC UNIT
ELECTRIC UNIT
(X25-8730-10)
.ON.feR sserddA
CIQ
1Q3
2Q2
3Q2
4Q4
5Q4
6Q2
2Q2
3Q5
4R2
5Q5
6Q2
7Q2
8Q6
.ON.feR sserddA
CIQ
1N3
2L4
3O5
4L6
5M4
6O3
7N4
8M4
01N5
11N4
21N4
41L3
51L2
61O3
1P5
2O4
3N3
4P4
5P5
6P5
7O5
8O5
9L2
01O2
11O2
21O2
31O2
41N4
51O5
61O4
71O4
81O3
91O3
02O3
12O3
22O3
32O3
42O5
52O5
62N5
72M5
82M5
92N5
03O4
13O5
23M4
33N4
43L3
53L4
63L4
73N5
83N5
93N4
04N4
14N4
24N4
34L5
44L5
54L4
64L4
15L3
25K3
SWITCH UNIT
(X13-9940-10)

STU WV X YAAZ
1
2
3
4
5
6
7
12
11
Refer to the schematic diagram for the values of resistors and capacitors.
SWITCH UNIT
EB
R21
R8
S.GND
B
KS1
KR5
KR4
E
KR3
KR2
R9
KS2
ANA
RST
MC CLK
MC
REQ
FL+B
C7
R7
C6
15
14
FL GND
R13
R40
CP21
CP4
FAC
1
2
C15
L9
E
B
SCREQ
SC DATA
P RESET
3.3V
BE
C17
15
4
3
DO
L11
CP17
R22
R14
R12
DGND
CP13
CP14 25
R23
FAC
CP18
CP15
CP16
CP19
CP20
24
C18
C16
48
CLK
1
L12
R26
C12
L8
C5
R11
C3
VDD
R30
R31
L10
CP22
S.GND
R29 L1
C2
50 51
C4
75
C11
26
X1
25 C1 1
18 R4
1
KS3
KR1
BE
R5
R17
R18
R36
C9
DI
R24
76
R25
10
R3
9
R28
R39
R27
100
CP3
CP2
C10
R34 8
C14
R33 1
KS4
R1
C19
R2
R20
EB
R35
CP1
9
16
R6
EB
C8
R19
Q8
D3
J1
Q3
Q5
IC5
D2
D7
IC4
IC1
D6
IC2
Q2
D5
D1
D4
IC6 Q4
S22
Q6
Q7
EJECT
DISP
AM
RST
18
dB
FM
6
TI 5 4 3 2 1 CLK
ED1 1
ATT 2
3
1
4
S1
S14
S15
S16
S21
S19
S20
S17
S18
S13 S12 S11
S9S10 S8 S7
S6
S5
S4
IC3
S3
S2
X13-9940-10 (J74-1134-02)
PC BOARD (Foil Side View)
D41
D40
D39
D38
Q43
Q45
Q52
D49
D50
D36
D34
D35
D33
Q6
Q29
Q28
Q27
Q35
Q24
D11
D13
Q14
D2
Q36
Q34
D21
D47
Q18
Q19
Q23 Q21 Q22
Q20
Q10
EB
R98
C146
C145
R150
C139
C133
C131
R156
R157
R155
EB
C137
C135
B
E
R242
R241
EB
C144
C141
R235
R239
R237
C103
TH1
R208
R207
R205
R206
C2
C38
R13
C98
C97
C112
C104
C111
C109
C113
C110
R12
C54
R148
R147
R184
R186
R202
C150
R204
C62
BE
BE
C35
R39
EB
C70
C72
C75
C73
C71 R158
R152
B
R151
E
C90
C89
C91
C92
W5
W6
W1
W2
W3
W4
R7
R168
R164
R34
R165
W7
R163
R167
W15
R36
EB
R33
R37
C7
R8
R175
R173
R176
R166
W8
W10
R174
R178
R177
BE
R187
R183
R185
W9
R188
C48
R41
C4
R22
C37
R121
L5
C46
C149
BE
R144
BE
R140
R143 R83
R79
R81
R97
R142
C55
R141
R119
R104
R109
R99
R89
R95
R90
R93
R92
R100
R101
R233
R234
R236
R232
R223
R224
R225
R50
R126
R124
R125
R127 C41
R107
R59
R61
C43
C42
R67
R51
R53
R55
B
R32
C31
C10
E
ER30
R31
EB
E
EB
B
B
EB
R29
C30
R27
R28
R26
R135
R133
R131
R132
R60
R62
R221
R220
R52
R54
R56
R134
R137
R130
R136
R25
C14
EB
R1
C17
C12 C18
R9
6
1
L14
C76
C74
EB
C129
24
R210
L9
R200
L7
1
C115
R201 R211
BE
L11
R212
BE
L10
R213
L12
L13
1
87
C143
C142
1
R45
C102
25
24
C116
2
1
C1
L1
C95C96
R169
6
R170 99
8
16
1
R180
C101
1
1
R179
E
R5
C108
4
5
C81
R153
R203
C119C117C118 C120
C114
C67
C61
L6
R40
C34
C36
C60
R38
B
28
C78
C84
C83
C87
C88
11
23 12
C69
22 C68
C85
R154
C82
C63
1
44
33
34
C77
C66
C79 C65
C86
C99
C93 1 C94
C100
C105
C106
15
14
C53
E
E
BB
I
B
C8
E
R19
R15
B
R46
E
R161
EB
5
8
C39
R17
R20
R48
C107
R189
R190
R16
C20
R47
R14
E
BE
B
C21
R6
O
G
14
4
1
B
E
R162
E
R172
5
4
1
E
B
8
B
R181
E
R171
85
EB
R182
4
1
7
8
1
B
R2
E
R43
R42
C22
EB
B
R44
B
W100
C5
E
C6 R21
C23
E
B
C13
76 R230
C50 9
R145
R146
1
X3
16
R214
NOISE
SMTR
C49
R110
DATA 8
C52
CLK
R116
R120
R118
R113
R114
R115
1
R117
IFC-OUT
C51
R102
R94
100 R108
R91
E
12
R216
R215
6C147
C148
10
B
ER231
EBB
2
5
1
C9
13
R86
R84 EB EB
R82
R80
R88
75
R77
R85
R75
R78
1
222
121
C32
R4
R3
R122
TEST
25
E
C40
B
L4
R49
26
50
C44
X2
43
X1
12
EB
R23
L3
C24
C45
C33
8
5
C28
C27
1
4
C11
C26
C25
RST
R66
R69
R70
R74
R73
R71
R72
51
R10
C29
R11
R24
18
B
E
B
E
BE
E
2
1
B
E
E
B
B
C3
L2
C15
C200
X25-8730-10 (J74-1142-02)
IC14
D31
D30
WH1
CN4
31
D32
Q44
Q46
F/E
CN7
Q9
IC4
J1
CN1
D6
Q12
Q2
D25
Q41
Q40
Q38
Q37
D19
D29
D28
D27
D1
D15
IC2
IC5
Q32
Q33
D20
Q31
Q15
Q25
IC10
Q26
D12
D14
Q7
D17
Q8
IC3
Q39
D8
IC11
D7
Q42
IC12
IC7
D16
D3
Q30
D9
Q16
IC1
D48
D26
IC8
D46
Q51
CN6
IC15
D44 D45
CN5
Q3
IC16
D18
Q17
E1
IC6
D10
D5
CN3
Q13
Q11
CN2
Q1
Q5
Q4
D4
D24
D23
D22
A1
ELECTRIC UNIT
.ON.feR sserddA
CIQ
1T3
2T2
3T2
4T4
5T4
6T2
2T2
3T5
4T2
5T5
6T2
7T2
8T6
.ON.feR sserddA
CIQ
1W3
2Y4
3V5
4Y6
5X4
6V3
7W4
8X4
01W5
11W4
21W4
41Y3
51Y2
61V3
1U5
2V4
3W3
4U4
5U5
6U5
7V5
8V5
9Y2
01V2
11V2
21V2
31V2
41W4
51V5
61V4
71V4
81V3
91V3
02V3
12V3
22V3
32V3
42V5
52V5
62W5
72X5
82X5
92W5
03V4
13V5
23X4
33W4
43Y3
53Y4
63Y4
73W5
83W5
93W4
04W4
14W4
24W4
34Y5
44Y5
54Y4
64Y4
15Y3
25Z3
SWITCH UNIT
(X13-9940-10) ELECTRIC UNIT
(X25-8730-10)

ABCDEFG IH
1
2
3
4
5
6
7
22K
22K
22K
22K
47K
47K
22K
22K
22K
22K
22K
22K
47K
47K
47K
10K
47K
10K
22K
22K
22K 22K
47K
2.2K
4.7K 4.7K 4.7K 4.7K 4.7K 4.7K
22K
22K
IC3
∗ IC6
IC7
IC4
IC11
IC5
IC10 IC12
(X25-8730-1X)
(E30-4939-05)
KDC-X917/X817/X717
DC CORD
(E30-4940-05)
KDC-9017
DC CORD
123456
D3
Q5
SW5V
A8V
A.V.R
Q8
SERVO +B
SW14V
D4
Q13
Q1
∗ D2
D1
B.U.5V Q2
Q4 Q3
DETECT SW
SMALL LAMP
Q6
Q9
Q7
Q11
Q10
Q15
D9
4V PRE DC/DC
CONVERTER
Q17
Q16
VOLTAGE
REGULATOR
Q19
Q24
P-ANT SW
Q21
Q18 Q20
D10
Q22
Q23
D11
Q25
D12
D14 Q26
CN6
ILL +B
D48D50 D49
Q12
PAN 5V
Q51
SW
DETECT
ACC
DETECT
SW
Q29
P-CON SW
B.U.
Q30 CIRCUIT Q31
MUTE
LOGIC
Q27
Q28
D16
D17
MUTE
AUDIO
CONVERTER A.V.R
4V PRE DC/DC
PRE MUTE
D36 D35
D34
D33
POWER AMP
D41
D40 D39 D38
Q39 Q40
4V PRE
OP AMP
∗ Q14
EXT.AMP
CON.SW
J1
CN2
CN1 CN1
D20
Q32 Q33 D19
NONFAD SW
HPF & LPF &
Q37Q38 Q42 Q41
4V PRE
OP AMP
4V PRE
OP AMP
(X25-8730-1X)
GND LINE
SIGNAL LINE
∗
D7
D5
CORD
RCA CORD
RCA
REAR N-FADER FRONT
SP OUT/DC IN
PRE
OUT
D15
∗ C
∗ A1
D6
D32
D30
D31
∗ B
FL & ILLUM
MASK u-COM ONLY FLASH u-COM ONLY
∗ F ∗ EREAR
N-FADER FRONT
PRE
OUT
R45
R39
22K
R10
+
R9
C9 100u10
VOUTVIN
R4
C2 0.022
R3 22K
C4 0.01
10u10
220u16
C6 100u6.3
+
C3
+
C5
22K
R1 100 R2
+
IC3
GND
4.3K
R7
220u10
C8
+
Q9
Q7,8
1.5K
1.5K
100K
R20
Q15
∗
C1 3900u16
+
Q1,2
220
R5
C21
0.022
24K
15K
R6
R8
1
C7
27
C22
+
1u50
54
C25 2.2
R22 100K
C23 4.7u16
R21 1K
+
C26 2.2
C27 2.2
VOUTCAP-
BOOST V+
75
100u16
R23
C24
+
C29 22u16
LV
3GND 6
+
OSC
2CAP+ 7
L3
22uH
18
560 1W
1K
R38
1/2W
C30 0.022
Q18-23
C28 2.2
4.7u16
C33
+
Q24,25
C31 0.01
R32 91K
R27 56K
R26
7.5K
R24 2.7K
47
R29 47
R28 91K
R31 91K
R30
10K
R25
R37 4.7K
3.3u25
C34
R33 4.7K
R34
R36
4
3
C15 33u63
FAC
MC CLK
FLGND
ANA
MC REQ
DATA I/O
SC REQ
RST
R233
R234
R236 R235
R237
124 53 67
470
1K 1K
470
1K
FAC
P RST
FL+B
DGND
VDD
R239
108911 12 13
1K
+
99 65
97
89
R232
4.7K
8
64
22K
R231
93
11
R43
5.6K
R47
18K
22K
R44
Q26-29
1/2W
28
29
C39
0.01
1
2
3
4
100K
R48
0.068
C36
+
0.1u50
R40 1K
R42
12K
1000P
C37
+
C35
R41
12K
0.01
C48
14 13 12
R46
C38
47K
0.01
3.3K
1/2W
12
11
5 6
7
10 9 8
31
N-FR
C102
1u50
C115
+
R204
R203
47K
Q16,17
0.47u50
C116
+
FR
RR
9
19
2
9
Q37-42
12K
R202
R201 10K
R200 100
FL
RL
1.5K
TH1
22u50
C99
+360
R171
13
FRA
RRA
FRB
RRB
C120
0.22u50
C118
0.22u50 +
22K
R206
22K
R208
22u16
C114
8
TAB GND 2 OUT2- ST-BY OUT2+ VCC2 OUT1-
1
2
3 5 6
7 4
IN1 IN2 OUT1+ RIP GND1
9
10
11
12
R178
22K
R177
C119
0.22u50 0.22u50
C117
RLA
22K
R205
22K
R207
FLA
RLB
FLB
R174 2.2K
R175 10K R176 10K
4VSS 5
2
3
22K
6
OUT4+ IN4 IN3 AUX IN OUT3+ GND3 OUT3- VCC1 PRE-GND
14
15 16
17
18 19 20
21
DIAGNOSIS MUTE OUT4- GND4
22
23
24
25
81 VDD 7
82
R179 R180
10u16
+
C101
Lch Lch Rch GND
B.U. GND
RRA
FRA
RRB
FRB
RLB
FLA
FLB
RLA
560
∗
R13
10K
R19
1K
Q14
10
REAR Lch-
FRONT Lch+
REAR Lch+
FRONT Lch-
87
9
FRONT Rch-
REAR Rch-
FRONT Rch+
REAR Rch+
ACC
PHONE
P-CON
EXT CONT
P-ANT
GND
ILLUM
3
4
2
32654
1311 12 14 15
1
16
2
N-FL
N-FL
RR
RL
1
C103
∗
C109
∗
C110
∗
C113
C111
2134
C107
C95
14
13
12
11
10
CR1
DGND
11
8
10
14
13
+
22u50
C94
22u50
C100
+ +
22u50
C93
360
R172
360
R162
360
R161
22u16
C106
+
22u16
C105
360
R182
360
R181
Q32,33
SDA
SCL
AUX1 INR SDA 28
VCC
1AUX1 INL
26
SCL 27
3MUTE
2
R187
R167
R188
22K
22K
R168
R166 10K
R163 2.2KR164 2.2K
R165 10K
5
VSS
463
2
22K
R185 10K
R183 2.2KR184 2.2K
R186 10K
4VSS
2
35
22K
6
82 82
R170
18
7
VDD
82
R169
10u16
+
+
C96
+
1VDD
82
R190
8
7
82
R189
C108
10u16
+
+
AUX2
HP FR1
6
23
+
1u50
C60
AGND 25
CR2
4
CREF 24
CL1
5
7
22
HP FL1
CL2
21
HP FL2
8AUX2
19
HP FR2 20
HP
9
18
HP RL1 0.33
C83
HP
0.33
C87
0.33
C88
16 C84
17
HP RR1 0.33
HP RL2
HP
OUT
HP RR2 15 HP
34
35
C89 0.1
C90 0.1
C92 0.1
C91 0.1
FL
10
FR
11
13
RL
14
RR
Lch Rch Rch GND GND
C112
C97
2200P
0.1
FR
FL
N-FR
FR
FL
RR
RL
C98
C104
2200P
0.1
2200P
56789
9
8
CE D F
0-12
0-11
0-10
0-13
MODEL
NAME UNIT No.
KDC-X917
KDC-X817
KDC-9017
KDC-X717
13
2
RROUT
RLOUT
REF
FROUT
FLOUT
OUTL
OUTR
∗
R14
+
10u16 10u16
10u16
BU
YEL
GND BLK
ACC
P. CON
RED
BLU/WHT
5
6
7
89
10
12
11
1
4
2
314
13
16
15 ILLUMI
ORG/WHT
512
P. CON
ACC
GND
215
161
BLK YEL
14
13
BLU/WHT
RED 3
4
FRONT L
FRONT R
GRN
WHT 9
10
11
GRY/BLK 6
GRY
WHT/BLK 8
7VIOL/BLK
VIOL REAR R
GRN/BLK REAR L
EXT.
PNK/BLK CONT
ANT CONT BLU
ANT CONT BLU
F1 10A
L1
24
VDD
GND
2200P
2200P
0.1
2200P
22K
R173 2.2K
C32 4.7u16
+
∗ W100
∗
C200 0.047F5.5
+
22uH
L2
C11 100u16
+
C10 0.01
C13 100u16
C12 0.01
+
1 2 3 4 5 6
FAC
GND
VIN
C.T
FAC
VO
0.015
C17C18
0.015
10K
R12
10
8
2.2
C14
30
0.1
C129
21
31
4.7K
R230
100
0.33u50
C86
0.33u50
C85
∗ W4
∗ W3
∗ W2
∗ W1
∗
W5
∗
W6
3
YES
YES
B
YES
NO NO
YES
YES
YES NO
YES
NO
YES W02-3271
W02-3271
W02-3271
W02-3272
A1
NO
YES
YES
YES
MODEL
KDC-X717
KDC-9017
KDC-X817
KDC-X917
NAME
C90-2822
C90-5377
C90-5377
E40-3241
E40-5066
E40-5066
CN1C1
C90-5377
79
C78,
E40-5066
TC7662BEOAYES
YES
NO
YES
D7 IC6
TC7662BEOA
ICL7660SIBA
TC7662BEOA
NO
14
YES
YES
YES
R13,
KDC-X717 YES NO
MODEL
NAME
KDC-9017
KDC-X817
KDC-X917 NO YES
NO NO
YES
YES
R53 R54
YES
YES
YES
NO
Q14 Q52
NO
YES
YES
NO
NO
YES
YES
NO
R51
YES
NO
YES
NO
R52
NO YES
NO
NOYES
YES
YES
R56
NO
R55
NO
YES
YES
90
R89,
YES
NO
YES
242
R241,
NO
NO YES NO
NO
W1-4
NO
NO
YES
NO
NO
6
W5,
REAR R
REAR L
GRN
VIOL/BLK
VIOL
GRN/BLK
WHT
WHT/BLK
GRY
GRY/BLK
FRONT R
FRONT L
20
ILLUMI
ORG/WHT
BU
25
2.2 1W
R11
52
C82 +
0.33u50
C81 +
0.33u50
YES
YES
YES
NO
110,113
C109,
KDC-X717
KDC-9017
KDC-X817 YES
NO
NO
NO
MODEL
NAME
KDC-X917
D2
YES
C200
NO
W100
IC16
YES
YES NO
NO
NO
NO
S-80837ANNP
S-80837ANNP
S-80837ANNP
S-80837ANNP
S-80842ANNP
S-80842ANNP
S-80842ANNP
S-80842ANNPYES NO
YES
D2
YES
YES NO
C200
NO
NO
IC16 W100
YES
YES
YES
YES
26 2.2K
10
C16 0.01
Lch Lch Rch Rch GND GND
YES
NO
YES
NO
7.7V
5.1V
7.7V
14.4V
7.7V
0V
7.7V
9.0V
1.4V 0V
1.4V 0V
7.7V
14.4V
7.7V 0V
0V
0V
-9.3V
0V
9.7V 9.7V
0V
0V
-9.3V 0V
0V 0V
0V
-9.3V
0V
9.7V
0V
0V
0V
0V
0V
0V
0V
0V
5.1V
13.6V
1.24V
0V
0V
10.4V
0V
10.6V
0V
-10.0V
-10.0V
10.6V
5.1V
0V
4.1V
4.1V
4.1V
4.1V
4.1V
4.1V
4.1V
4.1V 0V
4.1V
0V
4.1V
0V
0V
4.1V
4.1V 4.1V
0V
8.2V
4.1V
7.7V 1.3V 4.1V 7.7V
5.1V
0V
5.1V
5.1V
0V
B LINE
B LINE
2SB1188
BCE
2SB1548
E
C
B
2SB1277
2SB1443
CE
B
DTA123JK
DTA144EUA
DTC114YUA
DTC143TUA
UN5213
UN5214
2SA1362
2SB1218A
2SD1819A
B
C
E
2SC4081
B
C
E
DTA124EUA
DTC114EUA
DTC124EUA
DTC144EUA
IN
GND
OUT
BA3830F TA78L05F NJM4565M-TE2
NJM4565MD
DAN202U
DAP202U
DA204K
DA204U
UN5212
RD6.8M
A
C
N
DA227 TC74HC02AF
BA5917AFP M5237ML LB1930M
TC74HC4050AFT
TDA7479D

JKLMNOP RQ
1
2
3
4
5
6
7
1/2
KDC-X917/X817/9017
22K
22K
22K
47K
47K
22K
22K
22K
∗ IC16
IC8
IC2
IC1
IC14
IC15
(X16-1180-10)
A
CN5
D47 D46
CN3
OP AMP
SPEANA
RST IC
Q34
AGC
SPEANA
D21
MUTE
Q35
E-VOL
E-VOL
u-COM
CN4
CN7
DRIVER
MOTOR
RDS
DECODER
Q44
AM+B Q45
Q46
FM+B Q43
WH1
D25 D26
F/E
MASK
MECHA
CH CORD
(E30-4945)
2/2
X13-
CN1
to CD MECHA. (X32- )
CH-IN
ANT.
TUNER
J1
D29
D27
D28
D44D45
Q36
∗ D
D22
D23
D24
∗ Q52
Q53
IC1 : UPD703033GC051
IC2 : TDA7407
IC3 : M5237ML
IC4 : TA8273H
IC5 : TDA7401
IC6 :
IC7 : HD74HC02FP or
TC74HC02AF
IC8,10-12 : NJM4565M-TE2
IC14 : TDA7479D
IC15 : LB1930M
IC16 :
Q1,4 : 2SB1548(P)
Q2,11,17,19,21,22,30,
31,34,36,52 : 2SC4081 or
2SD1819A
Q3,18,20,23,27 : 2SA1576A or
2SB1218A
Q5,15,53 : DTC144EUA or
UN5213
Q6,7,13,28,32,33 : DTA124EUA or
KRA303
Q8,12,35,43,45 : DTC124EUA or
UN5212
Q9 : 2SD2375
Q10 : 2SA1648-Z
Q14 : DTA123JK or
KRA105S
Q16 : 2SB1443
Q24,29 : DTC114YUA or
UN5214
Q25,26 : 2SB1277(Q,R)
Q37-42 : DTC143TUA or
KRC410
Q44,46 : 2SB1188(Q,R)
Q51 : 2SB1427
D1 : RM10ZLF
D2 : RB160L-40
D3,10,16 : MA4056(N)-M
D4 : MA4082(N)-M or
HZS9A2L
D5 : MA4100(N)-M
D6 : MA4051(N)-M
D7 : MA4056-M
D9 : MA4110(N)-M
D11,33-36,38-41 : 1SR154-400
D12,14 : AM01Z or
DSM1SD2 or
ERA15-02
D15,30-32 : 1SS133
D17 : MA4062(N)-M
D19,20 : DAP202U
D21,44-50 : DA204K or
KDS226
D22-24,29 : MA4062-L or
HZS6C1
D25,26 : RD6.8M(B2)
D27,28 : MA4068(N)-M
D43
SA-C2012-101TB
D43 IMSA-6801 or:
∗
∗
29
96
R145 47K
100K
R16
R225 2.2K
SW2
D OUT
22 21
R223 2.2K R224 2.2K
R67
MOSW
MUTE L
MS CLK
MECH
MUTE R
SW1
MS DA
NC
BU 5V
D GND
M STOP
AUDIO +B
M RST
GND
Rch
Lch
LO/EJ
SERVO SERVO
SW3
4
R220 100K R221 100K
1220 19 18 17 15 14 13 16 11 10 97 65 8
44
43
1
321
2
3
4
10
C45
CLK REQ H REQ C CH RST DATA C DATA H CH CON CH MUTE
R132 100
R131 4.7K R135 4.7K
R133 100
R130 4.7K
R134 100
R137 4.7K
4.7K
54321876
91
R147 10K
0.01
C54
R148
1
2
3
VDD 8
7 6
15KR146 820
R141
61
47u6.3
53
14
90
13
54
58
57 60
L4 4.7uH
+
0.01
C41
C40
63
1
2
4
R113 1K
R117 470
9
100
R140
47K
4.7u16
C49
10K
+
33K
R144
4.7u16
C53
4GND
+
AM+B FM+B AFS PLL-DATA EVDD EVSS
1
2
3
4
5 6
7
8
4.7u16
5
4.7u16
C50
+
C52
+
47K
+
CH-CLK
99
98 MC-DATA
SC-DATA
97
BU-DET
P-MUTE P-STBY IC2-CLK PRE-MUTER IC2-SDA BEEP NC NC NC TEST
10
12
13
14
NC PRE-MUTEL
11
15 16
17
18 19 20
22
23
21 MUTE
DIMMER
25
24
26
SW5V
27
EXT-AMP-CONT
28
P-CON
ANT-CON 29
33
ACIN RR
ACIN LR
ACOUT L
ACOUT R
ACIN RF
R154 330K R153 330K
C74 0.1
0.01
C73
R71
0.033
C72
SCL
4.7K
R150
150P
12
80
0.47
R70
R152
4.7K
4.7uH
SDA
L6
1
3
2
5
7
8
6
9
10
11
44
2
1000P
C62
47u10
GND
QUAL MP IN LEVEL MP OUT SPANA L SPANA R SMUTE
18
14
12
13 15 16
17
MPX NC NC
19 20
21
22
NC
NC
AFS
AM
24
23 SDA
SCL
25 NC
SCL
SDA
29 CDL OUT
NC
NC
NC
CDL
NC
27 VDD
26
OUT RR
28
CDR OUT
CDGND
CDR
31
30 OUT FR
OUT RL
32 NC
OUT FL
+
C51 4.7u16
95
SRM SUB+
94
92
93
CD-SW1
CD-SW2
SC-REQ
NC
90
91
89
R-CLK
CH-REQC
SRM SUB-
87
88
NC
XT2
31
30
P-ON
33
32
XT1
RESET
X2 35
REGC 34
36
CLKLOT
VSS 37
X1
39
VDD 38
40
79
83
86
84
85
R-QUAL
IFC-OUT
R-DATA
81
82
80 S-METER
SRM DET
NOISE
77
78
76
SRM SW2
SRM SW1
SRM SW3
PHONE
AVREF
AVSS
46
NC
NC
43
41
42
TYPE0
44
TYPE1
45
NC
TYPE2
ILL-ON
M-MUTER
M-MUTEL
NC
CD-SW3
NC
MOSW
LO/EJ
MC-REQ/PANEL
M-RST
BVSS
BVDD
CH-RST
IC2TYPE1 47
IC2TYPE0
48
CH-CON
50
CH-MUTE
49
Rch Lch A GND
+ + +
0.47u50
C67
0.47u50
C68
47u6.3
C69 4.7
10
R157
R155
10
R156
231
35
34
C63 2.2u50
CREF
VREF
TAPE R
TAPE L
ACIN LF
44 43 42 41 40 39
NC
34 37 36 35 38
+
C76 10u10 C77 10u10
∗
C79 10u10
∗
C78 10u10
44
43
+
+
0.47u50
4
2
0.47u50
72 75 74 73 71 70 69 68 67 66 65 64 63 62 61 60 59 58 57 56 55 54 53 52 51
GND EXTRES
+
C143
C144
10u10
0.01
7
8FILOUT FSEL
ARI TM 10
9
SRM SUB-
SRM SW2
SRM DET
GND
SRM SW3
0.22
S-GND
P-GND
OSCO
C142
C141
330P
L14
4.7uH
5
6
3
10u10 4
+MPX OSCI
OSEL VCC 12
11
VREF C146
X3
13 10P
1
2
82
81
16
QUAL
RDDA
RDCK
T57 C145
15
14 10P
87
4
78
101
3
4
5
92
86 IN1
IN2
NC
OUT2
2VCC NC
NC OUT1
8
7
6
9
5
277 3
1
0.01
C137
IF1 +B
24 IF1 GND
L13
4.7uH
AMIF OUT
22 S-METER
23
20 AUDIO OUT
21
SDA
5
4.7uH
L12
18
RDS OUT
19 NOISE OUT
VDD 5V
17
15 SCL
DIG GND
16
4
PLL +B
13 IPC OUT
14
12
10 OSC GND
11 VT
OSC GND
8
9W/N
1
4.7uH
Q43,44
L10
2
Q45,46
1K R213
22K
R212 4.7uH
1R211
22K
R210
1K
4
0.01
C133
AM +B
OSC GND
7
5
OSC GND
FM +B
6
0.01
C131
52mH
3AM ANT
2RF GND
FM ANT
L9
2
1
4.332MHz
2
4
3
1
5
2
4
3
1
5
3
P RST
SC REQ
DATA I/O
MC REQ
FLGND
MC CLK
ANA 13
11
12
RST 9
10
7
8
FAC
FL+B
FAC 5
6
4
DGND
VDD 2 1
5
DGND
VDD
FL+B
3
2
4
MC REQ
FAC
P RST
FAC
6
7
DATA I/O
SC REQ
RST
8
9
10
11
ANA
MC CLK
FLGND
12
13
14
15
1
S.GND
S.GND
GND
+B
DET
94
95
51
88
48
49
50
96
NC NC NC ACC-DET
CH-REQH
PAN-RST
M-STOP
AVDD
AVCONT
CH-DATAH
CH-DATAC
MC-CLK
PAN5V
27
28
24
25
26
52
R115 470
PLL-CLK5
R118 4.7K R116 4.7K
30
1K
R50
20 R125 47K
9
19
12
11
14
13 R119 1K
R121 1K
R122 10K R120 10K
21 R126 100K
22P
C42
27P
C43
1
C44
32.768kHz
X2
20.0MHz
X1
10K
R49
∗ R51 100K
∗ R52 100K
∗ R53 100K
∗ R54 100K
∗ R56 100K
∗ R55 100K
R60 100K
R62 100K
L5
50
48
49
51
470
R110
R108
470
100K
R109
93
97
100
99
96
95
94
R102 1K
R101 2.2K
R100 2.2K
R94 1K
R93 100K
R92 100K
R91 1K
100K
R107
100K
R104
R99 100K
R97 100K
R95 100K
∗ R90 100K
∗ R89 100K
R88 2.2K
C46 1000P
R86 2.2K
R84 1K
R85
100K
R83
2.2K
R82 1K
R81
R80 1K
2.2K
R79
R77 1K
2.2K
NC NC NC NC
R75 2.2K
R74 1K R73 1K R72 1K R71 1K
R78 1M
R69 1K R70 1K
89
64
65 57 60
58
61
63
53
54
90
91
C66
C65
C149 0.1 C55
1
1K
R142
R151
10K
4.7K
R98
1K
R158
C61
77 6SRM SW1
SRM SUB+
67 6
C148
0.22
C147
75
76
76
77
75
79
78
86
88
87
83
82
81
80
92
2.2K
R214
R216 2.2K
R215 2.2K
4.7uH
L11
0.01
C135
0.01
C139
47K
R243
83
10K
31
1K
∗
R241
4.7K
∗
R242
79
80
SDA
SCL
80
R66
100K
R127 2.2K
R124 10K
L7
12
3R114 1K
R136
R143
RDS
RDS
220
R65
0.1
C75
C64 0.015
0V
4.1V
4.1V
4.1V
4.1V
8.2V
0V
0V
5.1V
5V
0V
7.6V
5.0V
0V
0V
7.6V
7.6V
0V
5V
5V
0V
2.5V
2.4V
5.1V 0V 0V 5.1V
4.1V
4.1V
4.1V
4.3V
4.1V
5V
0V
0V
8.2V 4.1V
4.1V 4.1V
4.1V
5.1V
4.8V
0V
3.6V
0V
5.1V 5.1V
5.1V
0V
0V
0V
5.1V 0V
5.1V
0V
5.1V
0V
5.1V
0V
0V
5.1V
5.1V
0V
0V
5.1V
5.1V
0V
0V
5.1V
0V
5.1V 0V
5.1V
3.5V
0V
5.1V
0V or 5.0V
0V
5.1V
0V
5.1V
5.1V
0V
5.1V
0V
5.1V
0V
5.1V
0V
0V or 5.0V
0.2V or 5.5V
5.1V
0V
5.1V
0V
1.6V
0V
0-5.0V 0-4.2V
5.1V
0V
0V or 5.0V
5.1V
0V
0V
5.1V
0V
5.1V
5.1V
0V
0V
5.1V
5.1V
0V
5.1V
0V
0V
5.1V
5.1V
0V
5.1V
0V
CAUTION:For continued safety, replace safety critical components only with manufacturer’s recommended parts (refer
to, parts list). Indicates safety critical components.To reduce the risk of electric shock, leakage-current or resistance
measurements shall be carried out (exposed parts are acceptably insulated from the supply circuit) before the appliance
is returned to the customer.
DC voltages are as measured with a high impedance voltmeter.Values may vary slightly due to variations between individual
instruments or/and units.

AAZYW XVUS T
1
2
3
4
5
6
7
J1
SRC
S20
Q5
Q3
D4 D5
VOL+
S2
dB
S19 4 S11
FM
S18
AM
S15 5 S12 1 S8
S17
S16 6 S13 2 S9
TI
S14 S10
S6
S5
S3 ATT S4 EJECT S1
S21
RESET
ED1
IC1 : UPD703033GC058
IC2 : BA3830F
IC3 : RS-171
Q2 : KRA304 or
Q3 : KRA303 or
Q4-8 : KRC402 or
D6
D1,2
D4,5,7
D3
DA204U
: MA3056-M
MA3062WA:
:
DA227:
1/2
-J1
SPE-ANA
BPF
REMOTE
X13
S22
OPEN
D3
3 VOL-
DISP
S7 CLK
Q6Q7
Q2
DTA144EUA
DTA124EUA
DTC114EUA
D7
D2 D1
SIGNAL LINE
D6
Q4
MSM531622F90TSIC4
IC6
IC5 TC74HC4050AFT LP2982-3.3
:
:
:
Q8
IC4
IC6
IC2
(X13-9940-10)
A
IC5
IC1
IC3
10K
10K
22K
22K
10K
10K
47K
47K
10K
10K
10K
10K10K
10K
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
D11
D3
D10
D2
D9
D1
D8
D0
OE
VSS
CE
A0
A1
A2
A3
A4
A5
A6
A7
A17
A18
NC
NC
NC
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
VCC
D4
D12
D5
D13
D6
D14
D7
A-1
VSS
BYTE
A16
A15
A14
A13
A12
A11
A10
A9
A8
A19
NC
NC
NC
1
2
3
4
5
6
7
8
VCC
1Y
1A
2Y
2A
3Y
3A
GND
16
15
14
13
12
11
10
9
NC
6Y
6A
NC
5Y
5A
4Y
4A
9 8
7
6 5
4
3
2
1
GND
BIAS-C
NC
REC IN
REC NF
LINE IN
LINE NF
RO1 RO2
10 11 12 13 14 15 16 17 18
VDD
NC
FO6 FO5
FO4
FO3
FO2
FO1
NC
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
S GND
ANA
FL GND
MC CLK
MC REQ
RST
DATA I/O
SC REQ
FAC
P RST
FAC
FL+B
D GND
VDD
S GND
2.2
C9
R3 15K
270K 270K
10
C10
0.01
C7
47K
F1
1
2F1
3F1
VDD2(+B) VSS
4
VSS
5 6
BK LATCH
8 9
11 NP
7VDD1
14 DATA1
F2
17 F2
18 F2
C11
2.2
22
R25
10K
CP1
KR5
KR4
KR3
KR2
KS1
KS2
KS3
KS4
2.2K
10K
R6
2.2M
R21
100
R7
C19 100P
0.1
5.1K
R13
98
1K
R14
99 86
KR1
86
46
0.01
C6
8
R1
R2
9
1K
R19
R18
100
10
10
R17
R22
NC
AD4 51
BLUE
49 AD2 50
AD0 AD1
48
47
OE CE NC
45 46
44
NC NC
42
43
41
34
0.01
VDD NC
39 40 38
VSS
37
R29
10K
X1
C2
1
35
X1
36
X2
29
R12
100K
R11
100K
R41
1K
TX1 TX2 REGC
33
32
A3 RESET
31
30 26 A12
A1 A2
28
27
C4
0.01 C5
0.01
BVDD
24
A6
A5
25
REMO10 LATCH
GCP
REMO ON
A15
A14
A13
BLK
TEST
A11
A10
A9
A8
A7
17
22
23
21
19
20
18
13
15
16
14
12
11
13
DATA1
CLK
NC
CLK IN
EVDD
EVSS
RED
GREEN
DATA2
9
89
10
8
0.01
7
C1
5
6
1
L8
3
4
2
100
CP2
100
F04
F03 76
77
F06 F05 78
79
WAVE IN
KR5 80
81
KR4 82
83 91 88
SC REQ
KR1
KR2
KR3
84 85
NC 87
86
SOURCE
SC CON
OPEN 89
90
MC REQ
VREF CON
KS4
92 93
KS3 94
MC DATA
SC DATA 97
KS1
KS2
96 95 98 99
R24
1K
KR5
KR4
KR2
KR3
KR1
R23 10K
R8 10K
R9 1K
92
KS4
KS3
98 99
KS2
KS1
NC
100K
R27
79 78
77
76
CP3
1K
77
76 79 78
46
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
AD5
AD6
AD7
BVSS
AD8
AD9
AD10
AD11
AD12
AD13
AD14
AD15
A16
A17
A18
A19
NC
A20
AVDD
AVSS
AVREF
F01
F02
C3
75
74
75
74
R4
R5
80
80
470
CP4
AD3
R28
100K
11
1
2
4
12 R39
100
14
15
16
19
20
21
22
23
24
25
28
27
26 29 A4
30
L1
44
43
100
CP22
CP24 100K
100K
CP23
L10
10uH
R31 22K
R30 22K
47
48 49
50
54
53
52
70
51
66
65
67
68
69
65
68
70
69
68
67
66
65
67
66
64
63
62
61
60
59
58
57
70
R20 10K
R40 1K
22K
CP21
92
13
4
2VCC
1
OUT 5
CTL
3GND
C
L9
C16 1
90
90
C17 0.01
C12
R26
DATA2
15
GCP
10
NP
12
CLK
13
17
100
R33
100
R34
L12 13
16
9
10
13 10
9
100
R36
R35
100 11
12
2
15
14
1
4
C15 4.7
14
15
C8 2.2
L11
10uH
0.1
100
CP17
47K
CP13
47K
CP14
100
CP18
C18
CP19
100
47K
CP15
47K
100
CP20
CP16
14
64 26
25
24
23
70
52
51
53
61
63
62
54
65
66
16
15 19
68
67
22
21
20
30
29
28
27
43
44
60
59
58
57
50
49
48
47
D15/
17
20MHz
C14 0.1
1/2W
1/2W
4
VDD
1
OUT
2
GND1
GND2 3
89
91
91
89
1.2K
1K
31
31
MC CLK
0-5.0V 0-5.0V 0-5.0V 0-5.0V 0-5.0V 0-5.0V
0-5.0V
1.6V 4.5V
0V
0V
5.1V
0V
0V
0V
4.9V 5V
0V
0V
0-5.0V
0V
4.9V
5V
0V
4.9V
0V
0V
4.9V
0V
4.9V
0V
5.1V
5.1V
0V
0V
0V
4.7V
0V
4.7V
5.1V
4.9V
0V
0V
4.9V
5V
0V
5.1V 0V
4.9V
5.1V
0-5.0V
0-5.0V
5.1V
5.1V
2.6V
2.6V
4.9V
0V
0V
0V
4.9V 0-5.0V
0-5.0V
0-5.0V
0-5.0V
0-5.0V
0-5.0V
0-5.0V 0-5.0V5.2V
0-5.0V
0-5.0V
0-5.0V
0-5.0V
0-5.0V
0-5.0V
0-5.0V
5.2V
5.2V 5.0V
3.4V
0V
1.4V
3.4V
0V
0V
5.0V
0V
4.9V
0V
0V
3.4V
0V
4.9V
0V
4.9V
4.9V
0V
3.4V
0V
0V
3.4V
0-5.0V
0-5.0V
0-5.0V
0-5.0V
0-5.0V
0-5.0V
0-5.0V
0-5.0V
0-5.0V
0-5.0V
0-5.0V
0-5.0V
0-5.0V
4.9V
B LINE
CAUTION:For continued safety, replace safety critical components only with manufacturer’s recommended parts (refer
to, parts list). Indicates safety critical components.To reduce the risk of electric shock, leakage-current or resistance
measurements shall be carried out (exposed parts are acceptably insulated from the supply circuit) before the appliance
is returned to the customer.
DC voltages are as measured with a high impedance voltmeter.Values may vary slightly due to variations between individual
instruments or/and units. 2/2
KDC-X917/X817/9017

AJAIAHAF AGAEADAB AC
1
2
3
4
5
6
7
50 49 48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
76
77
78 79 80
81
82
83
84
85 86
87
88 89 90
91
92
93
94
95 96
97
98 99
100
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
STOUT
TRCRS
FLAG
IPFLAG
FCLK
CLDCK
EFM or CK384
DVSS2
AVSS2
AVDD2
TOFS
FOD
TRD
KICK
ECS
ECM
PC
TVD
TRV
VCOF2
VCOF
PLLF2
PLLF
IREF
DSLF
DRF
ARF
VREF
RFENV
NC
NC
NC
TE
NC
NC
FE
TBAL
FBAL
AVDD3
AVSS3
NC
NC
LDON
VDET
RFDET
OFT
BDO
73/74SEL TES ICRST CLVS TEST ASEL PON SEARCH VER/HOR SW3 AMUTE L AMUTE R CD-RW RST MECHASEL MSTOP LDCNT DATA CLK HOT AVREF OUT R AVDD1 OUT L AVSS1
CSEL
TEST1
TEST2
IOSEL
NRST
BCLK
LRCK
SRDATA
SUBC
SBCK
DQSY
DEMPH
TX
PSEL
MSEL
SSEL
DVDD1
X1
X2
DVSS
XSUB1
XSUB2
DVDD2
NC
NC
SMCK
STLD
PCK or DSLB
14 13 12 11 10 9 8 7 6 5 4 3 2 1
OP.OUT
GND
SLED+
SLED-
NC
SL.IN
GND
MUTE
NC NC
TR.IN
NC
TRK+
TRK-
15 16
17
18 19 20
21
22
23
24
25 26
27
28
OP.IN- OP.IN+ SPDL+ SPDL- NC SP.IN VCC VCC VREF FC.IN NC FCS- FCS+ GND
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
D
B
C
A
GND
LD
PD
VR
VC
VCC
F
E
FCS+
TRK+
TRK-
FCS-
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
D.OUT
SW2
SW1
CLK
DATA
MECHA
NC
BU+5V
D.GND
MUTE R
MUTE L
MRST
MSTOP
A.+8V
Lch
A.GND
Rch
LO/EJ
MOTOR
S.7.5V
S.GND
SW3
16.93MHz
X1
100K
R213
100K
C85
0.1
100K
R54
0.1
C35
220K
R38
0.015
C25 0.1 C29
R37
470 C28
1
1
C26
150
R36
68K
R32
100K
47K R5 360
28
27
FCS+
TRK-
TRK+
FCS-
47K
R73
R71
10K
1K
R72 0.015 C43
24K
R78
56K
R77
R76 6.2K
33K
R75
27
26
1
2
CP1 100
4.7K
R49
76
85
4
12
3
C79C80
330
R108
330
R107 20K
R121 R117
20K
68P
C77
20K
R125
R118
20K
R122
20K
68P
C78
R126
20K
10K
0.1
R47
10K
OUT
GND
IN
3.3
C51
2200P
CP3 100
CP2 100 26
1
2
47
30
29
34
35
93
94
86
89
91
87
11
12
11
12
17
18
86
87
89
94
93
91
10
2
1
4
3
11
12
15
19
29
30
32
33
34
35 36
27
TVD
ECS
18
17
LOAD
SLED+
SLED-
EJECT
SPDL-
SPDL+
R44
5.1K 1K
R46
0.1
C33
FE
1
C1
2.2
C41
C72
470P
2200P
470P
C71
FIN
FIN
16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
GND
NRFDET
OFTR
C.OFTR
BDO
C.BDO
3TOUT
C.EA
ARF
C.AGC
RFIN
RFOUT
RFN
VCC
LD
PD
17
18 19 20
21
22
23
24
25 26
27
28 29 30
31
32
VREF VDET TEBPF TEOUT TEN FEN FEOUT GCTL TBAL F E C A D B FBAL
1
3
23300P
6800P
19 0.033
C10 4700P
1000P
C23 ARF
C8 1
10K
R10
10K
R11 9.1K R12
15P
C5
2P
C6
RF
0.1
C7
R15
820K
43K
C16
150P
R17
3.9K
R18
TE
22K
R16
4700P
C14
0.047
C15
C17
4700P
12
51K
R19
220P
C18
92
C19 0.1
R20 100K
10
11 R21 240K
R6 2.7K R3 2.7K
27
28
30
29
31
32
0.047
C46R52
33K
R81
32
33
R83
1K12K
R82
C45
0.015
36
4.7
IOP+
R8 10
R9
IOP-
+
10u6.3
C4
W17
6
1
31
32
29
30
6
1
0.022
C24
3.3K
R102 3.3K
R101
1
C67
5.6K
R103
1
C68
5.6K
R104
C34
R45
R218
10u16
C63
+
0.1
C55
C13
C11
C12
1
C2
4.7
C3
R34
4
15
C20 0.1
R202 100K 2200P
C89
47
4.7
C21
92
R234 10K
R233 6.2K
IC2
IC4
IC5
(X32-5030-00)
IC1
CN1
CN2
D3
D4
S2
S1
IC6
(2/2)
(1/2)
IC6
Q3
Q4
D2
Q5 Q2
S3 DOWN & LIMIT
SWITCH
M
M
LOADING & SLED
MOTOR
SPINDLE
MOTOR
MAIN
UNIT
CN1
to
PICKUP
OPTICAL
IC1 : AN22000AA
IC2 : MN662773KF1
IC4 : BA5917AFP
IC5 : TA78L05F
IC6 : NJM4565MD
Q1 : MCH6101
Q2,5 : DTC124EUA
Q3,4 : 2SA1362(Y)
D1,2,4 : DAN202U
D3 : DA204U
SIGNAL LINE
CD SIGNAL
PROCESSOR
BTL
DRIVER
ACTIVE
PON SW
MOTOR SW
D.5V SW
A.8V SW
GAIN
CONTROL SW
FILTER
PU1
(T25-0215-05)
(X92- )
DM2
(X92- )
DM1
(X92- )
DET.SWITCH
SWITCH
S1 : LOAD DET.
S2 : 12cm DISC
bult in u-COM.
5V AVR
AMP
RF
D1
Q1
APC
22K
22K
22K
22K
0V
0V
0V
0V
0V
5.0V
2.5V
3.0V
2.5V
2.5V
2.5V
2.5V
2.5V
1.4V
2.5V 2.5V 2.5V 2.5V 2.5V
1.8V
0V
5.0V 0V 0V
5V
0V
0V
4.8V
5.0V
5.0V
4.8V
5.0V 5.0V 5.0V 0V 5.0V
5.0V
0V
5.0V
0V
5V
5.0V 5.0V
0V
8.0V
2.5V
2.5V
2.5V
0V
5.0V
4.0V
4.0V
4.0V
4.0V
2.5V
5.0V
4.0V 4.0V 2.5V
2.0V
2.0V 2.0V 4.0V 4.0V
2.5V 2.5V
8.0V
TE
2.4V 2.4V
3.4V
0.1V
5.0V
2.5V
0.8Vp-p
0.8Vpp
1.2Vp-p
3.5V
FE
0V or 5.0V 2.5V
0V
5.0V
0V
B LINE
KDC-X917/X817/9017
CD MECHANISM
CAUTION:For continued safety, replace safety critical components only with manufacturer’s recommended parts (refer to,
parts list). Indicates safety critical components.To reduce the risk of electric shock, leakage-current or resistance
measurements shall be carried out(exposed parts are acceptably insulated from the supply circuit) before the appliance is
returned to the customer.
DC voltages are as measured with a high impedance voltmeter.Values may vary slightly due to variations between individual
instruments or/and units.

CD
1
2
3
2221
KDC-X917/X817/9017 KDC-X917/X817/9017
S 1 S 2
S 3
A
B
C
D
E
F
G
H
J
M1.7x2.5
φ2x3.5
M1.7x4
M2x2
φ2x6
WASHERφ1.2
WASHERφ1.6
WASHERφ1.6
M2x2
: N09-4249-05
: N09-4172-05
: N09-4202-05
: N38-2020-46
: N09-4294-05
: N19-2023-04
: N19-2058-04
: N19-2093-04
: N39-2020-46
18
14
54
2
13
83
51
46
50
46 51 40
26
25
72
70
873
52
75 52
DJ
G
B
B
HE
E
H
E
E
E
885
E
H
Ex2
E
F
E
B
F
GB
Cx2
B
B
B
Ax2
53
37
38
39
65
45 80
17
66
16
12
71
18
11
54
54
79
77
19
43
60
60
20
DPU1
44
41
3
9
1047
x2
35
58
67 78
DM2
DM1
24
55
34
32
31
27 29
49
36
30
21
63
64
82 22
61
61
76
33
71
875
62
8
660
60
69
EXPLODED VIEW (CD MECHANISM)
Parts with exploded numbers larger than 700 are not suppied.
AB
1
2
3
M2.5x2
M2x2 (BLK)
φ2x4
M2x2.5
M2x1.8 (BLK)
FLAT WASHER
FLAT WASHER
FLAT WASHER
RETAINING RING
RETAINING RING
φ2x2.5
φ2x5
φ2x8 (BLK)
φ3x5
M2x4
φ3x8
φ3x12
φ2.6x6
A
B
C
D
E
F
G
H
J
K
L
M
N
P
Q
R
S
T
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
N09-4400-05
N09-4401-05
N09-4427-05
N09-4448-05
N09-4449-05
N19-2154-04
N19-2155-04
N19-2156-04
N29-0522-05
N29-0523-05
N38-2025-46
N80-2005-46
N09-4473-05
N83-3005-46
N86-2004-45
N80-3008-46
N83-3012-46
N86-2606-46
P
P
PP
P
P
NN
N
N
M
M
D
P
P
P
P
R
S
SS
S
A
A
G
H
A
F
F
J
C
J
P
Q
Q
Q
B
B
B
B
B
B
D
L
L
E
K
X25-8370-1X
X13-9940-10
ED1
J1
F/EA1 IC4
201 DC1
265
ST1
260
261
RM1
227
280 LV1
LV1
281
222
221
237
235
236
257 267
272
276
270
271
275
220
220
228
273
274
251
238
239
214
212
264
211
210
232
254
225
240
242
230
250
202
213
253
263
243
252
277
269
226
ME1
DN1
AC1
WH1
248 x6
771
770
784
772
751
722
782
701
F1
801
802
PA1
FC1
BB
FPC1
PM1
FPC2
249
EXPLODED VIEW (UNIT)
Parts with exploded numbers larger than 700 are not suppied.

KDC-X917/X817/9017
PARTS LIST
23
Ref.No. Parts No. Description
A
d
d
A
d
d
N
e
w
Dest
inati
on
Ref.No. Parts No. Description
A
d
d
A
d
d
N
e
w
Dest
inati
on
∗New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohane Parts No. werden nicht geliefert.
K: KDC-X917 K1: KDC-X817 K2: KDC-9017 indicates safety critical components.
KDC-X917/X817/9017
KDC-X917/X817/9017
201 1C A02-1497-03 PLASTIC CABINET ASSY
202 2C * A10-4803-02 CHASSIS ASSY
210 2C A22-2865-03 SUB PANEL ASSY
211 2C A10-4805-02 CHASSIS
212 2C A10-4807-03 CHASSIS CALKING ASSY
213 2C A10-4812-03 CHASSIS
214 2C A10-4810-03 CHASSIS CALKING ASSY
220 3C A21-4069-03 DRESSING PANEL
221 3C A46-1690-01 REAR COVER
222 1D A52-0779-02 TOP PLATE
PA1 3C * A64-2149-02 PANEL ASSY K
PA1 3C * A64-2150-02 PANEL ASSY K1
PA1 3C * A64-2151-02 PANEL ASSY K2
RM1 1C A70-0883-05 REMOTE CONTROLLER ASSY K2
RM1 1C A70-0894-05 REMOTE CONTROLLER ASSY K,K1
225 2C B03-3072-02 DRESSING PLATE K,K1
225 2C B03-3073-02 DRESSING PLATE K2
226 3D B07-3006-03 ESCUTCHEON ASSY K,K1
226 3D B07-3007-03 ESCUTCHEON ASSY K2
227 1C B07-3010-02 ESCUTCHEON
228 3C * B10-3252-01 FRONT GLASS K
228 3C * B10-3253-01 FRONT GLASS K1
228 3C * B10-3254-01 FRONT GLASS K2
- B46-0100-50 WARRANTY CARD
- B46-0606-04 ID CARD
- B46-0631-13 USER CARD K,K1
- B58-1366-04 CAUTION CARD
- * B64-1891-00 INSTRUCTION MANUAL E
- * B64-1892-00 INSTRUCTION MANUAL F,S
230 2C D10-4563-04 ARM ASSY
232 2C D10-4590-04 ARM
235 2D D13-2135-04 GEAR ASSY
236 2D D13-2138-04 GEAR
237 2D D13-2139-04 GEAR
238 2C D13-2140-04 GEAR
239 2C D13-2141-04 GEAR ASSY
240 2C D13-2165-03 GEAR ASSY
242 2C D14-0754-04 ROLLER
243 2C D14-0760-03 ROLLER
LV1 1D D10-4562-04 LEVER
AC1 2D E30-4934-05 CORD WITH PINPLUG K,K1
AC1 2D E30-4935-05 CORD WITH PINPLUG K2
DC1 1C E30-4939-05 DC CORD K,K1
DC1 1C E30-4940-05 DC CORD K2
DN1 2D E30-4945-05 CORD WITH DIN CONNECTOR
FC1 2D E39-0375-05 FLAT CABLE
J1 3C E58-0903-05 RECTANGULAR REC
248 2D F29-0049-05 INSULATING COVER
F1 2D F52-0006-05 FUSE(MINI BLADE TYPE)
F1 2D F52-0011-05 FUSE(MINI BLADE TYPE)
249 1D G01-2924-04 TORSION COIL SPRING
250 2C G01-3065-04 EXTENSION SPRING
251 3C G01-3066-04 TORSION COIL SPRING
252 3C G01-3069-04 EXTENSION SPRING
253 2C G01-3080-04 TORSION COIL SPRING
254 2C G09-2038-04 FORMED WIRE
257 3C G16-1177-04 SHEET
- H10-4764-02 POLYSTYRENE FOAMED FIXTURE
- H25-0329-04 PROTECTION BAG (280X450X0.03)
- H25-0337-04 PROTECTION BAG (180X300X0.03)
- H25-1108-04 PROTECTION BAG (100X300X0.03)
- H30-0544-04 ADHESIVE DOUBLE-COATED TAPE
- * H54-2020-03 ITEM CARTON CASE K
- * H54-2021-03 ITEM CARTON CASE K1
- * H54-2022-03 ITEM CARTON CASE K2
260 1C J19-5051-03 BRACKET L
261 1C J19-5052-03 BRACKET R
263 2C J21-9651-03 MOUNTING HARDWARE ASSY
264 2C J21-9699-04 MOUNTING HARDWARE
265 1C J21-9716-03 MOUNTING HARDWARE ASSY
267 3C J90-0999-04 GUIDE
FPC1 3C J84-0121-12 FLEXIBLE PRINTED WIRING BOARD
FPC2 1C J84-0122-04 FLEXIBLE PRINTED WIRING BOARD
ST1 1C J54-0606-04 STAY
269 3C K24-3646-04 KNOB OPEN
270 3C K25-1215-03 KNOB EJECT
271 3C K25-1216-03 KNOB VOL
272 3C K25-1217-03 KNOB ATT
273 3C K25-1218-03 KNOB FM,AM
274 3C K25-1219-03 KNOB UP,DOWN
275 3C K25-1220-03 KNOB SRC
276 3C K25-1221-03 KNOB 1-6
277 3C K29-7017-03 KNOB LOCK
280 1C N99-1652-05 SCREW SET
281 1D N99-1704-05 SCREW SET
A 2C N09-4400-05 MACHINE SCREW
B 2C N09-4401-05 MACHINE SCREW
C 1C N09-4427-05 TAPTITE SCREW
D 2C N09-4448-05 MACHINE SCREW
E 3C N09-4449-05 MACHINE SCREW
F 2D N19-2154-04 FLAT WASHER
G 2C N19-2155-04 FLAT WASHER
H 2C N19-2156-04 FLAT WASHER
J 2C N29-0522-05 RETAINING RING
K 3C N29-0523-05 RETAINING RING
L 3C N38-2025-46 PAN HEAD MACHIN SCREW
M 3C N80-2005-46 PAN HEAD TAPTITE SCREW
N 3D N09-4473-05 MACHINE SCREW
P 1D N83-3005-46 PAN HEAD TAPTITE SCREW
Q 2C N86-2004-45 BINDING HEAD TAPTITE SCREW
PM1 1C T42-1034-04 MOTOR ASSY
ME1 1D X92-4100-00 MECHANISM ASSY

KDC-X917/X817/9017
PARTS LIST
24 indicates safety critical components.
Ref.No. Parts No. Description
A
d
d
A
d
d
N
e
w
Dest
inati
on
Ref.No. Parts No. Description
A
d
d
A
d
d
N
e
w
Dest
inati
on
∗New Parts
Parts without Parts No.are not supplied.
Les articles non mentionnes dans le Parts No.ne sont pas fournis.
Teile ohane Parts No.werden nicht geliefert.
K: KDC-X917 K1: KDC-X817 K2: KDC-9017
SWITCH UNIT(X13-9940-10)
SUB CIRCUIT UNIT(X16-1180-10)
ELECTRIC UNIT(X25-8730-1X)
SWITCH UNIT (X13-9940-10)
C1 CK73GB1H103K CHIP C 0.010UF K
C2 CK73GB0J105K CHIP C 1.0UF K
C3-7 CK73GB1H103K CHIP C 0.010UF K
C8,9 CK73FB1A225K CHIP C 2.2UF K
C10 CK73EB0J106K CHIP C 10UF K
C11 CK73FB1A225K CHIP C 2.2UF K
C12 C93-1174-05 CERAMIC CAPACITOR (TYPE 2)
C14 CK73GB1C104K CHIP C 0.10UF K
C14 CK73GB1H104K CHIP C 0.10UF K
C15 CK73EB1A475K CHIP C 4.7UF K
C16 CK73GB0J105K CHIP C 1.0UF K
C17 CK73GB1H103K CHIP C 0.010UF K
C18 CK73GB1C104K CHIP C 0.10UF K
C18 CK73GB1H104K CHIP C 0.10UF K
C19 CC73GCH1H101J CHIP C 100PF J
J1 E59-0835-05 RECTANGULAR PLUG
L1 L92-0332-05 CHIP FERRITE
L8 L92-0332-05 CHIP FERRITE
L9-11 L40-1015-34 SMALL FIXED INDUCTOR
L12 L92-0332-05 CHIP FERRITE
X1 L78-0821-05 RESONATOR
CP1 R90-0714-05 MULTI-COMP 10K X4
CP2 R90-1014-05 MULTI-COMP 100 X4
CP3 R90-0724-05 MULTI-COMP 1K X4
CP4 R90-1022-05 MULTI-COMP 470 X2
CP13-16 R90-0748-05 MULTI-COMP 47K X4
CP17-20 R90-1014-05 MULTI-COMP 100 X4
CP21 R90-1020-05 MULTI-COMP 22K X2
CP22 R90-1019-05 MULTI-COMP 100 X2
R1 R92-2565-05 METAL GLAZE RESISTOR
R2 R92-0365-05 CHIP R 1.0K J 1/2W
R3 RK73GB1J153J CHIP R 15K J 1/16W
R4,5 RK73GB1J274J CHIP R 270K J 1/16W
R6 RK73GB1J103J CHIP R 10K J 1/16W
R7 RK73EB2B101J CHIP R 100 J 1/8W
R8 RK73GB1J103J CHIP R 10K J 1/16W
R9 RK73GB1J102J CHIP R 1.0K J 1/16W
R11 RK73GB1J104J CHIP R 100K J 1/16W
R12 RK73GB1J102J CHIP R 1.0K J 1/16W
R13 RK73GB1J512J CHIP R 5.1K J 1/16W
R14 RK73GB1J102J CHIP R 1.0K J 1/16W
R17 RK73FB2A100J CHIP R 10 J 1/10W
R18 RK73FB2A101J CHIP R 100 J 1/10W
R19 RK73GB1J102J CHIP R 1.0K J 1/16W
R20 RK73GB1J103J CHIP R 10K J 1/16W
R21 RK73GB1J225J CHIP R 2.2M J 1/16W
R22 RK73GB1J473J CHIP R 47K J 1/16W
R23 RK73GB1J103J CHIP R 10K J 1/16W
R24 RK73GB1J102J CHIP R 1.0K J 1/16W
R25 RK73FB2A220J CHIP R 22 J 1/10W
R26 RK73GB1J222J CHIP R 2.2K J 1/16W
R27,28 RK73GB1J104J CHIP R 100K J 1/16W
R29 RK73GB1J103J CHIP R 10K J 1/16W
R30,31 RK73GB1J223J CHIP R 22K J 1/16W
R33-36 RK73GB1J101J CHIP R 100 J 1/16W
R39 RK73GB1J101J CHIP R 100 J 1/16W
R40 RK73GB1J102J CHIP R 1.0K J 1/16W
S1-18 S70-0856-05 TACT SWITCH
S19,20 S70-0857-05 TACT SWITCH
S21 S70-0851-05 TACT SWITCH
S22 S70-0864-05 TACT SWITCH
D1,2 DA227 DIODE
D3 HZM5.6N(B2) ZENER DIODE
D3 MA3056-M ZENER DIODE
D3 02CZ5.6-Y ZENER DIODE
D4,5 MA3062WA ZENER DIODE
D6 DA204U DIODE
D7 MA3062WA ZENER DIODE
ED1 MN14424A FLUORESCENT INDICATOR TUBE
IC1 UPD703033GC058 MI-COM IC
IC2 BA3830F ANALOGUE IC
IC3 RS-171 ANALOGUE IC
IC4 MSM531622F90TS MEMORY IC
IC5 LP2982-3.3 ANALOGUE IC
IC6 TC74HC4050AFT MOS-IC
Q2 DTA144EUA DIGITAL TRANSISTOR
Q2 KRA304 DIGITAL TRANSISTOR
Q3 DTA124EUA DIGITAL TRANSISTOR
Q3 KRA303 DIGITAL TRANSISTOR
Q4-8 DTC114EUA DIGITAL TRANSISTOR
Q4-8 KRC402 DIGITAL TRANSISTOR
X16-118
J1 3C E58-0903-05 RECTANGULAR RECEPTACLE
FPC1 3C * J84-0121-12 FLEXIBLE PRINTED WIRING BOARD
X25-873
C1 C90-2822-05 ELECTRO 3900UF 16WV K2
C1 C90-5377-05 ALMINIUM ELECTROLYTIC C. K,K1
C2 CK73GB1H222K CHIP C 2200PF K
C3 C90-2866-05 ELECTRO 220UF 16WV
C4 CK73GB1H103K CHIP C 0.010UF K
C5 C90-2594-05 ELECTRO 10UF 10WV
C6 CE04CW0J101M ELECTRO 100UF 6.3WV
C7 CK73FB1C105K CHIP C 1.0UF K
C8 CE04CW1A221M ELECTRO 220UF 10WV
C9 CE04CW1A101M ELECTRO 100UF 10WV
C10 CK73GB1H103K CHIP C 0.010UF K
C11 C90-2962-05 ELECTRO 100UF 16WV
C12 CK73GB1H103K CHIP C 0.010UF K
C13 C90-2962-05 ELECTRO 100UF 16WV
C14 CK73FB1A225K CHIP C 2.2UF K
C15 C90-5375-05 ALMINIUM ELECTROLYTIC C.
C17,18 CK73GB1H153K CHIP C 0.015UF K
C21 CK73GB1E223K CHIP C 0.022UF K
C21 CK73GB1H223K CHIP C 0.022UF K
C22 C90-2608-05 ELECTRO 1.0UF 50WV
ELECTRIC UNIT (X25-8730-1X)
SUB CIRCUIT UNIT (X16-1180-10)

KDC-X917/X817/9017
PARTS LIST
25
Ref.No. Parts No. Description
A
d
d
A
d
d
N
e
w
Dest
inati
on
Ref.No. Parts No. Description
A
d
d
A
d
d
N
e
w
Dest
inati
on
∗New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohane Parts No. werden nicht geliefert.
K: KDC-X917 K1: KDC-X817 K2: KDC-9017 indicates safety critical components.
ELECTRIC UNIT(X25-8730-1X)
C23 C90-2595-05 ELECTRO 4.7UF 16WV
C24 C90-2962-05 ELECTRO 100UF 16WV
C25-28 CK73EB1C225K CHIP C 2.2UF K
C29 CE04CW1C220M ELECTRO 22UF 16WV
C30 CK73GB1E223K CHIP C 0.022UF K
C30 CK73GB1H223K CHIP C 0.022UF K
C31 CK73GB1H103K CHIP C 0.010UF K
C32,33 C90-2595-05 ELECTRO 4.7UF 16WV
C34 C90-2598-05 ELECTRO 3.3UF 25WV
C35 CK73GB1C683K CHIP C 0.068UF K
C36 C90-2602-05 ELECTRO 0.10UF 50WV
C37 CK73GB1H102K CHIP C 1000PF K
C38,39 CK73GB1H103K CHIP C 0.010UF K
C40 CE04CW0J470M ELECTRO 47UF 6.3WV
C41 CK73GB1H103K CHIP C 0.010UF K
C42 CC73GCH1H220J CHIP C 22PF J
C43 CC73GCH1H270J CHIP C 27PF J
C44,45 CK73GB0J105K CHIP C 1.0UF K
C46 CK73GB1H102K CHIP C 1000PF K
C48 CK73GB1H103K CHIP C 0.010UF K
C49-53 C90-2595-05 ELECTRO 4.7UF 16WV
C54 CK73GB1H103K CHIP C 0.010UF K
C55 CK73FB1C105K CHIP C 1.0UF K
C60 C90-2608-05 ELECTRO 1.0UF 50WV K,K1
C61 CE04CW1C470M ELECTRO 47UF 16WV
C62 CK73GB1H103K CHIP C 0.010UF K
C63 C90-2610-05 ELECTRO 2.2UF 50WV
C65-68 C90-2606-05 ELECTRO 0.47UF 50WV
C69 CE04CW0J470M ELECTRO 47UF 6.3WV
C70 CK73GB1A474K CHIP C 0.47UF K
C71 CC73GCH1H151J CHIP C 150PF J
C72 CK73GB1E333K CHIP C 0.033UF K
C72 CK73GB1H333K CHIP C 0.033UF K
C73 CK73GB1H103K CHIP C 0.010UF K
C74,75 CK73GB1C104K CHIP C 0.10UF K
C74,75 CK73GB1H104K CHIP C 0.10UF K
C76-79 C90-2850-05 ELECTRO 10UF 10WV K,K1
C76,77 C90-2850-05 ELECTRO 10UF 10WV K2
C81,82 C90-2605-05 ELECTRO 0.33UF 50WV K,K1
C83,84 CK73FB1C334K CHIP C 0.33UF K K,K1
C85,86 C90-5356-05 ALMINIUM ELECTROLYTIC C. K,K1
C87,88 CK73FB1C334K CHIP C 0.33UF K K,K1
C89-92 CK73GB1C104K CHIP C 0.10UF K K,K1
C89-92 CK73GB1H104K CHIP C 0.10UF K K,K1
C93,94 CE04CW1C220M ELECTRO 22UF 16WV
C95,96 C90-2597-05 ELECTRO 10UF 16WV
C97,98 CK73GB1H222K CHIP C 2200PF K
C99,100 CE04CW1C220M ELECTRO 22UF 16WV
C101,102 C90-2597-05 ELECTRO 10UF 16WV
C103,104 CK73GB1H222K CHIP C 2200PF K
C105,106 CE04CW1C220M ELECTRO 22UF 16WV K,K1
C107,108 C90-2597-05 ELECTRO 10UF 16WV K,K1
C109,110 CK73GB1H222K CHIP C 2200PF K K,K1
C111-113 CK73FB1H104K CHIP C 0.10UF K K,K1
C111,112 CK73FB1H104K CHIP C 0.10UF K K2
C114 CE04CW1C220M ELECTRO 22UF 16WV
C115 C90-2608-05 ELECTRO 1.0UF 50WV
C116 C90-2606-05 ELECTRO 0.47UF 50WV
C117-120 C90-5296-05 NP-ELECT 0.22UF 50WV
C129 CK73GB1C104K CHIP C 0.10UF K
C129 CK73GB1H104K CHIP C 0.10UF K
C131 CK73GB1H103K CHIP C 0.010UF K
C133 CK73GB1H103K CHIP C 0.010UF K
C135 CK73GB1H103K CHIP C 0.010UF K
C137 CK73GB1H103K CHIP C 0.010UF K
C139 CK73GB1H103K CHIP C 0.010UF K
C141 CC73GCH1H331J CHIP C 330PF J K,K1
C142,143 C90-2594-05 ELECTRO 10UF 10WV K,K1
C144 CK73GB1H103K CHIP C 0.010UF K K,K1
C145,146 CC73GCH1H100D CHIP C 10PF D K,K1
C147,148 CK73GB1A224K CHIP C 0.22UF K
C149 CK73GB1C104K CHIP C 0.10UF K
C149 CK73GB1H104K CHIP C 0.10UF K
C150 CK73GB1H222K CHIP C 2200PF K
CN1 E40-3241-05 PIN ASSY K2
CN1 E40-5066-05 PIN ASSY K,K1
CN2 E40-3237-05 PIN ASSY
CN3 E40-3266-05 PIN ASSY
CN4 E40-3261-05 PIN ASSY
CN5 E40-9550-05 FLAT CABLE CONNECTOR
CN6 E40-9557-05 FLAT CABLE CONNECTOR
CN7 E40-5031-05 FLAT CABLE CONNECTOR
J1 E58-0863-15 RECTANGULAR RECEPTACLE
WH1 E30-4804-05 CORD WITH PLUG
WH1 E30-4932-05 CORD WITH PLUG
E1 J19-2826-05 HOLDER
L1 L33-1170-05 CHOKE COIL ASSY
L2 L33-1029-05 SMALL FIXED INDUCTOR
L3 L40-2205-91 SMALL FIXED INDUCTOR(22UH,J)
L4 L40-4795-91 SMALL FIXED INDUCTOR(4.7UH,J)
L5 L92-0075-05 CHIP FERRITE
L6 L40-4795-91 SMALL FIXED INDUCTOR(4.7UH,J)
L7 L33-1039-05 LINE FILTER COIL
L9-13 L40-4795-91 SMALL FIXED INDUCTOR(4.7UH,J) K2
L9-14 L40-4795-91 SMALL FIXED INDUCTOR(4.7UH,J) K,K1
X1 L78-0821-05 RESONATOR
X2 L77-2738-05 CRYSTAL RESONATOR
X3 L77-2002-05 CRYSTAL RESONATOR K,K1
P 2D N83-3005-46 PAN HEAD TAPTITE SCREW
R 2D N80-3008-46 PAN HEAD TAPTITE SCREW
S 2D N83-3012-46 PAN HEAD TAPTITE SCREW
T 2D N86-2606-46 BINDING HEAD TAPTITE SCREW
R1 RK73FB2A223J CHIP R 22K J 1/10W
R2 RK73GB1J101J CHIP R 100 J 1/16W
R3 RK73GB1J223J CHIP R 22K J 1/16W
R4 RK73GB1J222J CHIP R 2.2K J 1/16W
R6 RK73GB1J153J CHIP R 15K J 1/16W

KDC-X917/X817/9017
PARTS LIST
26 indicates safety critical components.
Ref.No. Parts No. Description
A
d
d
A
d
d
N
e
w
Dest
inati
on
Ref.No. Parts No. Description
A
d
d
A
d
d
N
e
w
Dest
inati
on
∗New Parts
Parts without Parts No.are not supplied.
Les articles non mentionnes dans le Parts No.ne sont pas fournis.
Teile ohane Parts No.werden nicht geliefert.
K: KDC-X917 K1: KDC-X817 K2: KDC-9017
ELECTRIC UNIT(X25-8730-1X)
R7 R92-3032-05 CHIP R 4.3K D 1/10W
R8 R92-3047-05 CHIP R 24K D 1/10W
R9,10 RK73FB2A152J CHIP R 1.5K J 1/10W
R11 R92-2104-05 CHIP R 2.2 J 1W
R12 RK73FB2A103J CHIP R 10K J 1/10W
R13 RK73EB2B102J CHIP R 1.0K J 1/8W K,K1
R14 RK73FB2A561J CHIP R 560 J 1/10W K,K1
R16 RK73GB1J104J CHIP R 100K J 1/16W
R19 RK73EB2B103J CHIP R 10K J 1/8W
R20 RK73GB1J104J CHIP R 100K J 1/16W
R21 RK73FB2A102J CHIP R 1.0K J 1/10W
R22 RK73GB1J104J CHIP R 100K J 1/16W
R23 RK73GB1J750J CHIP R 75 J 1/16W
R24 RK73GB1J272J CHIP R 2.7K J 1/16W
R25 RK73GB1J470J CHIP R 47 J 1/16W
R26 RK73GB1J752J CHIP R 7.5K J 1/16W
R27 RK73GB1J563J CHIP R 56K J 1/16W
R28 RK73GB1J913J CHIP R 91K J 1/16W
R29 RK73GB1J470J CHIP R 47 J 1/16W
R30 RK73GB1J103J CHIP R 10K J 1/16W
R31,32 RK73GB1J913J CHIP R 91K J 1/16W
R33 RK73FB2A472J CHIP R 4.7K J 1/10W
R34 R92-0366-05 CHIP R 560 J 1W
R36 RK73GB1J223J CHIP R 22K J 1/16W
R37 RK73FB2A472J CHIP R 4.7K J 1/10W
R38 RD14DB2H102J SMALL-RD 1.0K J 1/2W
R39 RK73FB2A223J CHIP R 22K J 1/10W
R40 RD14DB2H102J SMALL-RD 1.0K J 1/2W
R41 RK73FB2A123J CHIP R 12K J 1/10W
R42 RK73GB1J123J CHIP R 12K J 1/16W
R43 RK73GB1J562J CHIP R 5.6K J 1/16W
R44 RK73GB1J223J CHIP R 22K J 1/16W
R45 RD14DB2H332J SMALL-RD 3.3K J 1/2W
R47 RK73GB1J183J CHIP R 18K J 1/16W
R48 RK73GB1J104J CHIP R 100K J 1/16W
R49 RK73GB1J103J CHIP R 10K J 1/16W
R50 RK73GB1J102J CHIP R 1.0K J 1/16W
R51 RK73GB1J104J CHIP R 100K J 1/16W K1,K2
R52 RK73GB1J104J CHIP R 100K J 1/16W K
R53 RK73GB1J104J CHIP R 100K J 1/16W K1
R54 RK73GB1J104J CHIP R 100K J 1/16W K
R54,55 RK73GB1J104J CHIP R 100K J 1/16W K2
R56 RK73GB1J104J CHIP R 100K J 1/16W K,K1
R60 RK73GB1J104J CHIP R 100K J 1/16W
R62 RK73GB1J104J CHIP R 100K J 1/16W
R66,67 RK73GB1J104J CHIP R 100K J 1/16W
R69-74 RK73GB1J102J CHIP R 1.0K J 1/16W
R75 RK73GB1J222J CHIP R 2.2K J 1/16W
R77 RK73GB1J102J CHIP R 1.0K J 1/16W
R78 RK73GB1J105J CHIP R 1.0M J 1/16W
R79 RK73GB1J222J CHIP R 2.2K J 1/16W
R80 RK73GB1J102J CHIP R 1.0K J 1/16W
R81 RK73GB1J222J CHIP R 2.2K J 1/16W
R82 RK73GB1J102J CHIP R 1.0K J 1/16W
R83 RK73GB1J222J CHIP R 2.2K J 1/16W
R84 RK73GB1J102J CHIP R 1.0K J 1/16W
R85 RK73GB1J104J CHIP R 100K J 1/16W
R86 RK73GB1J222J CHIP R 2.2K J 1/16W
R88 RK73GB1J222J CHIP R 2.2K J 1/16W
R89-91 RK73GB1J102J CHIP R 1.0K J 1/16W K2
R91 RK73GB1J102J CHIP R 1.0K J 1/16W K,K1
R92,93 RK73GB1J104J CHIP R 100K J 1/16W
R94 RK73GB1J102J CHIP R 1.0K J 1/16W
R95 RK73GB1J104J CHIP R 100K J 1/16W K2
R97 RK73GB1J104J CHIP R 100K J 1/16W
R98 RK73GB1J472J CHIP R 4.7K J 1/16W
R99 RK73GB1J104J CHIP R 100K J 1/16W
R100,101 RK73GB1J222J CHIP R 2.2K J 1/16W
R102 RK73GB1J102J CHIP R 1.0K J 1/16W
R104 RK73GB1J104J CHIP R 100K J 1/16W
R107 RK73GB1J104J CHIP R 100K J 1/16W
R108 RK73GB1J471J CHIP R 470 J 1/16W
R109 RK73GB1J104J CHIP R 100K J 1/16W
R110 RK73GB1J471J CHIP R 470 J 1/16W
R113,114 RK73GB1J102J CHIP R 1.0K J 1/16W
R115 RK73GB1J471J CHIP R 470 J 1/16W
R116 RK73GB1J472J CHIP R 4.7K J 1/16W
R117 RK73GB1J471J CHIP R 470 J 1/16W
R118 RK73GB1J472J CHIP R 4.7K J 1/16W
R119 RK73GB1J102J CHIP R 1.0K J 1/16W
R120 RK73GB1J103J CHIP R 10K J 1/16W
R121 RK73GB1J102J CHIP R 1.0K J 1/16W
R122 RK73GB1J103J CHIP R 10K J 1/16W
R124 RK73GB1J103J CHIP R 10K J 1/16W
R125 RK73GB1J473J CHIP R 47K J 1/16W
R126 RK73GB1J104J CHIP R 100K J 1/16W
R127 RK73GB1J222J CHIP R 2.2K J 1/16W
R130,131 RK73EB2B472J CHIP R 4.7K J 1/8W
R132-134 RK73EB2B101J CHIP R 100 J 1/8W
R135-137 RK73EB2B472J CHIP R 4.7K J 1/8W
R140 RK73GB1J473J CHIP R 47K J 1/16W
R141 RK73GB1J153J CHIP R 15K J 1/16W
R142 RK73GB1J102J CHIP R 1.0K J 1/16W
R143 RK73GB1J473J CHIP R 47K J 1/16W
R144 RK73GB1J333J CHIP R 33K J 1/16W
R145 RK73GB1J473J CHIP R 47K J 1/16W
R146 RK73GB1J821J CHIP R 820 J 1/16W
R147,148 RK73GB1J103J CHIP R 10K J 1/16W
R150 RK73GB1J472J CHIP R 4.7K J 1/16W
R151 RK73GB1J103J CHIP R 10K J 1/16W
R152 RK73GB1J472J CHIP R 4.7K J 1/16W
R153,154 RK73GB1J334J CHIP R 330K J 1/16W
R155,156 RK73EB2B100J CHIP R 10 J 1/8W
R157 RK73EB2B4R7J CHIP R 4.7 J 1/8W
R158 RK73GB1J102J CHIP R 1.0K J 1/16W
R161,162 RK73FB2A361J CHIP R 360 J 1/10W
R163,164 RK73FB2A222J CHIP R 2.2K J 1/10W
R165,166 RK73FB2A103J CHIP R 10K J 1/10W
R167,168 RK73FB2A223J CHIP R 22K J 1/10W
R169,170 RK73FB2A820J CHIP R 82 J 1/10W

KDC-X917/X817/9017
PARTS LIST
27
Ref.No. Parts No. Description
A
d
d
A
d
d
N
e
w
Dest
inati
on
Ref.No. Parts No. Description
A
d
d
A
d
d
N
e
w
Dest
inati
on
∗New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohane Parts No. werden nicht geliefert.
K: KDC-X917 K1: KDC-X817 K2: KDC-9017 indicates safety critical components.
ELECTRIC UNIT(X25-8730-1X)
R171,172 RK73FB2A361J CHIP R 360 J 1/10W
R173,174 RK73FB2A222J CHIP R 2.2K J 1/10W
R175,176 RK73FB2A103J CHIP R 10K J 1/10W
R177,178 RK73FB2A223J CHIP R 22K J 1/10W
R179,180 RK73FB2A820J CHIP R 82 J 1/10W
R181,182 RK73FB2A361J CHIP R 360 J 1/10W K,K1
R183,184 RK73FB2A222J CHIP R 2.2K J 1/10W K,K1
R185,186 RK73FB2A103J CHIP R 10K J 1/10W K,K1
R187,188 RK73FB2A223J CHIP R 22K J 1/10W K,K1
R189,190 RK73FB2A820J CHIP R 82 J 1/10W K,K1
R200 RK73GB1J101J CHIP R 100 J 1/16W
R201 RK73GB1J103J CHIP R 10K J 1/16W
R202 RK73GB1J183J CHIP R 18K J 1/16W
R203 RK73GB1J473J CHIP R 47K J 1/16W
R204 RK73GB1J152J CHIP R 1.5K J 1/16W
R205-208 RK73GB1J223J CHIP R 22K J 1/16W
R211 RK73GB1J223J CHIP R 22K J 1/16W
R213 RK73GB1J223J CHIP R 22K J 1/16W
R214-216 RK73GB1J222J CHIP R 2.2K J 1/16W K,K1
R220,221 RK73GB1J104J CHIP R 100K J 1/16W
R223-225 RK73GB1J222J CHIP R 2.2K J 1/16W
R230 RK73GB1J472J CHIP R 4.7K J 1/16W
R231 RK73GB1J223J CHIP R 22K J 1/16W
R232 RK73EB2B472J CHIP R 4.7K J 1/8W
R233 RK73EB2B471J CHIP R 470 J 1/8W
R234,235 RK73EB2B102J CHIP R 1.0K J 1/8W
R236 RK73EB2B471J CHIP R 470 J 1/8W
R237 RK73EB2B102J CHIP R 1.0K J 1/8W
R239 RK73EB2B102J CHIP R 1.0K J 1/8W
R241 RK73GB1J102J CHIP R 1.0K J 1/16W K,K1
R242 RK73GB1J472J CHIP R 4.7K J 1/16W K,K1
W1-6 R92-1252-05 CHIP R 0 OHM K2
D1 RM10ZLF DIODE
D2 RB160L-40 DIODE
D3 MA4056(N)-M ZENER DIODE
D4 HZS9A2L ZENER DIODE
D4 MA4082(N)-L ZENER DIODE
D5 MA4100-L ZENER DIODE
D6 MA4051(N)-M ZENER DIODE
D7 MA4056-M ZENER DIODE K,K1
D9 MA4110(N)-M ZENER DIODE
D10 MA4056(N)-M ZENER DIODE
D11 1SR154-400 DIODE
D12 AM01Z DIODE
D12 DSM1SD2 DIODE
D12 ERA15-02 DIODE
D14 AM01Z DIODE
D14 DSM1SD2 DIODE
D14 ERA15-02 DIODE
D15 1SS133 DIODE
D16 MA4056(N)-M ZENER DIODE
D17 MA4062(N)-M ZENER DIODE
D18 1SS133 DIODE
D19,20 DAP202U DIODE
D21 DA204K DIODE
D21 KDS226 DIODE
D22-24 HZS6C1 ZENER DIODE
D22-24 MA4062-L ZENER DIODE
D25,26 RD6.8M(B2) ZENER DIODE
D27,28 MA4068(N)-M ZENER DIODE
D29 HZS6C1 ZENER DIODE
D29 MA4062-L ZENER DIODE
D30-32 1SS133 DIODE
D33-36 1SR154-400 DIODE
D38-41 1SR154-400 DIODE
D44-50 DA204K DIODE
D44-50 KDS226 DIODE
IC1 UPD703033GC051 MI-COM IC
IC2 TDA7407 ANALOGUE IC
IC3 M5237ML IC(VOLTAGE REGULATOR)
IC4 TA8273H ANALOGUE IC
IC5 TDA7401 ANALOGUE IC K,K1
IC6 ICL7660SIBA ANALOGUE IC K2
IC6 TC7662BEOA ANALOGUE IC K,K1
IC7 HD74HC02FP MOS-IC
IC7 TC74HC02AF IC
IC8 NJM4565M-TE2 ANALOGUE IC
IC10-12 NJM4565M-TE2 ANALOGUE IC K,K1
IC10,11 NJM4565M-TE2 ANALOGUE IC K2
IC14 TDA7479D ANALOGUE IC K,K1
IC15 LB1930M ANALOGUE IC
IC16 S-80837ANNP MOS-IC
Q1 2SB1548(P) TRANSISTOR
Q2 2SC4081 TRANSISTOR
Q2 2SD1819A TRANSISTOR
Q3 2SA1576A TRANSISTOR
Q3 2SB1218A TRANSISTOR
Q4 2SB1548(P) TRANSISTOR
Q5 DTC144EUA DIGITAL TRANSISTOR
Q5 UN5213 DIGITAL TRANSISTOR
Q6,7 DTA124EUA DIGITAL TRANSISTOR
Q6,7 KRA303 DIGITAL TRANSISTOR
Q8 DTC124EUA DIGITAL TRANSISTOR
Q8 UN5212 DIGITAL TRANSISTOR
Q9 2SD2375 TRANSISTOR
Q10 2SA1648-Z TRANSISTOR
Q11 2SC4081 TRANSISTOR
Q11 2SD1819A TRANSISTOR
Q12 DTC124EUA DIGITAL TRANSISTOR
Q12 UN5212 DIGITAL TRANSISTOR
Q13 DTA124EUA DIGITAL TRANSISTOR
Q13 KRA303 DIGITAL TRANSISTOR
Q14 DTA123JK DIGITAL TRANSISTOR K,K1
Q14 KRA105S DIGITAL TRANSISTOR K,K1
Q15 DTC144EUA DIGITAL TRANSISTOR
Q15 UN5213 DIGITAL TRANSISTOR
Q16 2SB1443 TRANSISTOR
Q17 2SC4081 TRANSISTOR
Q17 2SD1819A TRANSISTOR

KDC-X917/X817/9017
PARTS LIST
28 indicates safety critical components.
Ref.No. Parts No. Description
A
d
d
A
d
d
N
e
w
Dest
inati
on
Ref.No. Parts No. Description
A
d
d
A
d
d
N
e
w
Dest
inati
on
∗New Parts
Parts without Parts No.are not supplied.
Les articles non mentionnes dans le Parts No.ne sont pas fournis.
Teile ohane Parts No.werden nicht geliefert.
K: KDC-X917 K1: KDC-X817 K2: KDC-9017
Q18 2SA1576A TRANSISTOR
Q18 2SB1218A TRANSISTOR
Q19 2SC4081 TRANSISTOR
Q19 2SD1819A TRANSISTOR
Q20 2SA1576A TRANSISTOR
Q20 2SB1218A TRANSISTOR
Q21,22 2SC4081 TRANSISTOR
Q21,22 2SD1819A TRANSISTOR
Q23 2SA1576A TRANSISTOR
Q23 2SB1218A TRANSISTOR
Q24 DTC114YUA DIGITAL TRANSISTOR
Q24 UN5214 DIGITAL TRANSISTOR
Q25,26 2SB1277(Q,R) TRANSISTOR
Q27 2SA1576A TRANSISTOR
Q27 2SB1218A TRANSISTOR
Q28 DTA124EUA DIGITAL TRANSISTOR
Q28 KRA303 DIGITAL TRANSISTOR
Q29 DTC114YUA DIGITAL TRANSISTOR
Q29 UN5214 DIGITAL TRANSISTOR
Q30,31 2SC4081 TRANSISTOR
Q30,31 2SD1819A TRANSISTOR
Q32,33 DTA124EUA DIGITAL TRANSISTOR
Q32,33 KRA303 DIGITAL TRANSISTOR
Q34 2SC4081 TRANSISTOR
Q34 2SD1819A TRANSISTOR
Q35 DTC124EUA DIGITAL TRANSISTOR
Q35 UN5212 DIGITAL TRANSISTOR
Q36 2SC4081 TRANSISTOR
Q36 2SD1819A TRANSISTOR
Q37-40 DTC143TUA DIGITAL TRANSISTOR K2
Q37-40 KRC410 DIGITAL TRANSISTOR K2
Q37-42 DTC143TUA DIGITAL TRANSISTOR K,K1
Q37-42 KRC410 DIGITAL TRANSISTOR K,K1
Q43 DTC124EUA DIGITAL TRANSISTOR
Q43 UN5212 DIGITAL TRANSISTOR
Q44 2SB1188(Q,R) TRANSISTOR
Q45 DTC124EUA DIGITAL TRANSISTOR
Q45 UN5212 DIGITAL TRANSISTOR
Q46 2SB1188(Q,R) TRANSISTOR
Q51 2SB1427 TRANSISTOR
Q52 2SC4081 TRANSISTOR K,K1
Q52 2SD1819A TRANSISTOR K,K1
TH1 PTH9C42BD471Q POSITIVE RESISTOR
A1 W02-3271-05 ELECTRIC CIRCUIT MODULE
F/E X86-3240-11 TUNER UNIT
C1,2 CK73FB1C105K CHIP C 1.0UF K
C3 CK73FB0J475K CHIP C 4.7UF K
C4 C92-0566-05 CHIP-TAN 10UF 6.3WV
C5 CC73GCH1H150J CHIP C 15PF J
C6 CC73GCH1H020C CHIP C 2.0PF C
C7 CK73GB1C104K CHIP C 0.10UF K
C8 CK73FB1C105K CHIP C 1.0UF K
CD PLAYER UNIT (X32-5030-00)
C10 CK73GB1H472K CHIP C 4700PF K
C11 CK73GB1H682K CHIP C 6800PF K
C12 CK73GB1H332K CHIP C 3300PF K
C13 CK73GB1C333K CHIP C 0.033UF K
C14 CK73GB1H472K CHIP C 4700PF K
C15 CK73GB1C473K CHIP C 0.047UF K
C16 CC73GCH1H151J CHIP C 150PF J
C17 CK73GB1H472K CHIP C 4700PF K
C18 CC73GCH1H221J CHIP C 220PF J
C19,20 CK73GB1C104K CHIP C 0.10UF K
C21 CK73FB0J475K CHIP C 4.7UF K
C23 CK73GB1H102K CHIP C 1000PF K
C24 CK73GB1E223K CHIP C 0.022UF K
C25 CK73GB1H153K CHIP C 0.015UF K
C26 CK73GB0J105K CHIP C 1.0UF K
C28 CK73GB0J105K CHIP C 1.0UF K
C29 CK73GB1C104K CHIP C 0.10UF K
C33-35 CK73GB1C104K CHIP C 0.10UF K
C41 CK73EB1C225K CHIP C 2.2UF K
C43 CK73GB1H153K CHIP C 0.015UF K
C45 CK73GB1H153K CHIP C 0.015UF K
C46 CK73GB1C473K CHIP C 0.047UF K
C51 CK73FB1C105K CHIP C 1.0UF K
C55 CK73GB1C104K CHIP C 0.10UF K
C63 C92-1359-05 CHIP-TAN 10UF 16WV
C67,68 CK73GB0J105K CHIP C 1.0UF K
C71,72 CK73GB1H471K CHIP C 470PF K
C77,78 CC73GCH1H680J CHIP C 68PF J
C79,80 CK73GB1H222K CHIP C 2200PF K
C85 CK73GB1C104K CHIP C 0.10UF K
C89 CK73GB1H222K CHIP C 2200PF K
CN1 E40-9536-05 FLAT CABLE CONNECTOR
CN2 E40-9339-05 FLAT CABLE CONNECTOR
CN2 E41-0036-05 FLAT CABLE CONNECTOR
CN2 E41-0129-05 FLAT CABLE CONNECTOR
X1 L78-0572-05 RESONATOR (16.93MHZ)
CP1-3 R90-1019-05 MULTI-COMP 100 X 2
R3 RK73GB1J272J CHIP R 2.7K J 1/16W
R5 RK73GB1J361J CHIP R 360 J 1/16W
R6 RK73GB1J272J CHIP R 2.7K J 1/16W
R8 RK73EB2B4R7J CHIP R 4.7 J 1/8W
R9 RK73EB2B100J CHIP R 10 J 1/8W
R10,11 RK73GB1J103J CHIP R 10K J 1/16W
R12 RK73GB1J912J CHIP R 9.1K J 1/16W
R15 RK73GB1J824J CHIP R 820K J 1/16W
R16 RK73GB1J223J CHIP R 22K J 1/16W
R17 RK73GB1J513J CHIP R 51K J 1/16W
R18 RK73GB1J392J CHIP R 3.9K J 1/16W
R19 RK73GB1J513J CHIP R 51K J 1/16W
R20 RK73GB1J104J CHIP R 100K J 1/16W
R21 RK73GB1J304J CHIP R 300K J 1/16W
R32 RK73GB1J104J CHIP R 100K J 1/16W
R34 RK73GB1J683J CHIP R 68K J 1/16W
ELECTRIC UNIT(X25-8730-1X)
CD PLAYER UNIT(X32-5030-00)
