Kenwood FDM30 User manual

HEAD OFFICE: Kenwood Limited, 1-3 Kenwood Business Park, New Lane, Havant, Hampshire PO9 2NH
134699/1
instructions
TYPE FDM30
English 2 - 12
´¸∂w
31 - 22
134699 Iss 1 FDM30 Eng_Arabic.B5.indd 1-4 21/03/2017 15:59

2
safety
lRead these instructions carefully and retain for future reference.
lRemove all packaging and any labels.
lIf the cord is damaged it must, for safety reasons, be replaced by KENWOOD
or an authorised KENWOOD repairer.
lThe blades and discs are very sharp, handle with care. Always hold by the
finger grip at the top, away from the cutting edge, both when
handling and cleaning.
lDO NOT process hot ingredients.
lDo not lift or carry the processor by the handle - or the handle may break
resulting in injury.
lAlways remove the knife blade before pouring contents from the bowl.
lKeep hands and utensils out of the processor bowl and blender goblet whilst
connected to the power supply.
lSwitch off and unplug:
before fitting or removing parts;
when not in use;
before cleaning.
lNever use your fingers to push food down the feed tube. Always use the
pusher supplied.
lNever fit the blade assembly to the power unit without the
blender goblet or mill jar fitted.
lBefore removing the lid from the bowl, blender or multi mill from the power unit:
switch off;
wait until the attachment/blades have completely stopped;
be careful not to unscrew the blender goblet or mill jar from the blade
assembly.
lDo not use the lid to operate the processor, always use the on/off speed
control.
lThis appliance will be damaged and may cause injury if the
interlock mechanism is subjected to excessive force.
lAlways unplug your food processor when not in use.
lNever use an unauthorised attachment.
lNever leave the appliance unattended when it is operating.
lNever use a damaged appliance. Get it checked or repaired: see “service and
customer care”.
lNever let the power unit, cord or plug get wet.
lDo not let excess cord hang over the edge of a table or worktop or touch hot
surfaces.
D - optional attachments
C - standard attachments
A - Plastic blender
B - Glass blender
1
2
3
4
5
6
7


cr
cm
c
co
cp
p
q
r
s
t
c
cq

o
m
m


o

2
1
4
5
9
7
5
4
6
68
bk
3
8
c
b
b
b
b
b
p – q c – cp
cq – cr
s – c
r
cm
c
a
u
a
u
b
u
c
u
d
u
e
u
f
u
b
u
9
cp
co
c
cq
cr
134699 Iss 1 FDM30 Eng_Arabic.B5.indd 5-3 21/03/2017 15:59

3
4
lDo not exceed the maximum capacities stated in the recommended speed
chart.
lChildren should be supervised to ensure that they do not play with the
appliance.
lThis appliance shall not be used by children. Keep the appliance and its cord
out of reach of children.
lAppliances can be used by persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and if
they understand the hazards involved.
lOnly use the appliance for its intended domestic use. Kenwood will not accept
any liability if the appliance is subject to improper use, or failure to comply with
these instructions.
lMisuse of your processor, blender or mill can result in injury.
lThe maximum rating is based on the attachment that draws the greatest load.
Other attachments may draw less power.
blender
l DO NOT process hot ingredients.
l SCALD RISK: Hot ingredients must be allowed to cool to room temperature
before placing in the goblet or before blending.
l Always take care when handling the blade assembly and avoid touching the
cutting edge of the blades when cleaning.
l Only operate the blender with the lid in place.
l Only use the goblet with the blade assembly supplied.
l Never run the blender empty.
l To ensure the long life of your blender, do not run it for longer than 60 seconds.
l Smoothie recipes - never blend frozen ingredients that have formed a solid
mass during freezing, break it up before adding to the goblet.
mill attachments
l Never fit the blade assembly to the power unit without the jar/lid fitted.
l Never unscrew the jar/lid while the mill is fitted to your appliance.
l Do not touch the sharp blades – Keep the blade assembly away from children.
l Never remove the mill until the blades have completely stopped.
l The appliance will not work if the mill is incorrectly fitted.
l Do not process hot ingredients in the mill allow to cool down to room
temperature before processing.
multi mill
l To ensure the long life of your multi mill, never run for longer than 30 seconds.
Switch off as soon as you have got the right consistency.
l The processing of spices is not recommended as they may damage the plastic
parts.
134699 Iss 1 FDM30 Eng_Arabic.B5.indd 3 21/03/2017 16:05

4
before plugging in
l Make sure your electricity supply is the same as the one shown
on the underside of your appliance.
Important – UK only
l The wires in the cord are coloured as follows:
Blue = Neutral, Brown = Live.
l The appliance must be protected by a 13A approved (BS1362)
fuse.
Note:
l For non-rewireable plugs the fuse cover MUST be refitted when
replacing the fuse. If the fuse cover is lost then the plug must not
be used until a replacement can be obtained. The correct fuse
cover is identified by colour and a replacement may be obtained
from your Kenwood Authorised Repairer (see Service).
l If a non-rewireable plug is cut off it must be DESTROYED
IMMEDIATELY. An electric shock hazard may arise if an
unwanted non-rewireable plug is inadvertently inserted into a 13A
socket outlet.
l This appliance conforms to EC Regulation 1935/2004 on
materials and articles intended to come into contact with food.
before using for the first time
1 Remove the plastic blade covers from the knife blade. Take
care the blades are very sharp. These covers should be
discarded as they are to protect the blade during manufacture
and transit only.
2 Wash the parts see “care and cleaning”.
key
processor
1 pusher
2 feed tube
3 lid
4 bowl
5 detachable drive shaft
6 power unit
7 speed/pulse control
8 safety interlocks
9 cord storage (at back)
A plastic blender (if supplied)
 blade assembly
 sealing ring
m goblet
 filler cap
o lid
B glass blender (if supplied)
 blade assembly
 sealing ring
m goblet
 filler cap
o lid
C - standard attachments
p knife blade
q dough tool
r dual whisk
s 4mm slicing/grating disc
t 2mm slicing/grating disc
c extra fine grating disc
attachments
Not all of the attachments listed below may be included with
your food processor. Attachments are dependent upon the
model variant. Refer to “service and customer care” section for
information on how to buy an attachment not included in pack.
D - optional attachments
c citrus juicer (if supplied)
cm centrifugal juicer (if supplied)
multi mill (if supplied)
c jar
co sealing ring
cp blade assembly
grinding mill (if supplied)
cq mill lid
cr grinding mill blade assembly
grinding mill
l To ensure the long life of your grinding mill, never run for longer than 60
seconds. Switch off as soon as you have got the right consistency.
l Do not process turmeric root as it is too hard and may damage the blades.
slicing/grating disc
l Never remove the lid until the cutting disc has completely stopped.
l Handle the cutting discs with care - they are extremely sharp.
centrifugal juicer
lDo not use the juicer if the filter is damaged.
lThe cutting blades on the base of the filter drum are very sharp, take care
when handling and cleaning the drum.
lOnly use the pusher supplied. Never put your fingers in the feed tube. Unplug
before unblocking the feed tube.
lBefore removing the lid, switch off and wait for the filter to stop.
134699 Iss 1 FDM30 Eng_Arabic.B5.indd 4 21/03/2017 16:05

6
5
to use your food processor
1 Fit the detachable drive shaft onto the power unit 1.
2 Then fit the bowl by aligning the on the bowl with the on the
power unit, turn clockwise 2 until it locks .
3 Fit an attachment over the bowl drive
shaft.
l Always fit the bowl and attachment onto the processor before
adding ingredients.
4 Fit the lid 3 - ensuring the top of the drive shaft/tool locates into
the centre of the lid.
l Do not use the lid to operate the processor, always
use the on/off speed control.
5 Plug in, switch on and select a speed. (Refer to the
recommended speed chart).
l The processor will not operate if the bowl or lid are
not fitted correctly into the interlock. Check that the
feed tube and bowl handle are situated to the right
front hand corner.
l Use the pulse (P) for short bursts. The pulse will operate for as
long as the control is held in position.
6 Reverse the above procedure to remove the lid, attachments and
bowl.
l Always switch off and unplug before removing the lid.
important
l Your processor is not suitable for crushing or grinding coffee
beans, or converting granulated sugar to caster sugar.
l When adding almond essence or flavouring to mixtures avoid
contact with the plastic as this may result in permanent marking.
Aplastic blender (if supplied)
to use your blender
1 Fit the sealing ring  into the blade assembly  - ensuring the
seal is located correctly in the grooved area.
lLeaking will occur if the seal is damaged or
incorrectly fitted.
2 Hold the underside of the blade assembly  and insert the
blades into the goblet - turn anti-clockwise until it is secure 4.
Refer to the graphics on the underside of the blade assembly as
follows:
- unlocked position
- locked position
The blender will not operate if incorrectly assembled.
3 Put your ingredients into the goblet.
4 Fit the lid onto the goblet and turn clockwise 5until it clicks. Fit
the filler cap.
5 Place the blender onto the power unit, align the on the blender
with the on the power unit and turn clockwise 6to lock .
l The appliance will not operate if the blender is
incorrectly fitted to the interlock.
6 Select a speed (refer to the recommended speed chart) or use
the pulse control.
Bglass blender (if supplied)
to use your blender
1 Fit the sealing ring  into the blade unit  - ensuring the seal is
located correctly in the grooved area.
lLeaking will occur if the seal is damaged or
incorrectly fitted.
2 Screw the goblet onto the blade assembly 4. Refer to the
graphics on the underside of the blade unit as follows:
- unlocked position
- locked position
The blender will not operate if incorrectly assembled.
3 Put your ingredients into the goblet.
4 Fit the lid to the goblet and push down to secure 5. Fit the
filler cap.
5 Place the blender onto the power unit, align the on the blender
with the on the power unit and turn clockwise 6to lock .
l The appliance will not operate if the blender is
incorrectly fitted to the interlock.
6 Select a speed (refer to the recommended speed chart) or use
the pulse control.
multi mill (if supplied)
Use the multi mill for processing nuts, coffee beans and purées.
1Put the ingredients into the jar c.
2Fit the sealing ring co into the blade assembly cp.
3Turn the blade assembly upside down. Lower it into the jar,
blades down.
4Screw the blade assembly onto the jar until finger tight 7.
Refer to the graphics on the underside of the blade assembly as
follows:
- unlocked position
- locked position
5Place the multi mill onto the power unit, align the on the mini
multi mill with the on the power unit and turn clockwise 8to
lock .
6Switch onto maximum speed or use the pulse control.
grinding mill (If supplied)
Use the grinding mill for processing dry ingredients such as
coffee beans and for grinding spices such as:-
Black peppercorns, cardamom seeds, cumin seeds, coriander
seeds, fennel seeds, fresh ginger root, garlic cloves and fresh
chillies.
to use your grinding mill.
1 Place your ingredients into the blade assembly cr.
2 Fit the lid cq and turn clockwise to lock 9.
3 Place the mill onto the power unit and turn clockwise to lock bk.
4 Select a speed or use the pulse (P).
134699 Iss 1 FDM30 Eng_Arabic.B5.indd 5 21/03/2017 16:05

6
recommended speed chart tool/ attachment
function recommended
speed
processing
time (secs)
maximum capacities hints and tips
Knife blade All in one cake mixes 2 10 1.2kg/2lb 11oz total weight •For coarser textures use the pulse control.
•Cut food such as meat, bread, vegetables into cubes
approximately 2cm.
•Biscuits should be broken into pieces and added down
the feed tube whilst the appliance is running.
•Take care not to over-process. •When making pastry use fat straight from the fridge cut
into 2cm/¾in.cubes.
Pastry - rubbing fat into flour (use fat straight from the fridge and cut into 2cm cubes) Adding water to combine pastry ingredients
2
1 – 2
10
10-20
300g/11oz flour weight
Chopping fish and lean meat Pâtés and terrines
2 10-30 400g/14oz max lean beef
Chopping vegetables Pulse 5-10 100g/4oz
Chopping nuts 2 30-60 100g/4oz
Pureeing soft fruit, cooked fruit and vegetables
2 10-30 500g/1lb 2oz
Cold soups Start at low speed
and increase to
maximum
30-60 1 litre/35 fl oz
Milkshakes/batters 15-30 500ml
Whisk Egg whites 2 60 6 (200g) important
•The whisk is not suitable for making all in one
cake mixes as these mixes are too heavy and will damage it. Always use the knife blade.
•Best results are obtained when the eggs are at room
temperature.
•Ensure the bowl and whisks are clean and free from
grease before whisking.
Whipping cream 2 30 500ml/1pt
Dough tool Yeasted mixes 2 60 340g/ 12oz flour weight •Do not process for longer than 60 seconds.
•Place the dry ingredients in the bowl and add the liquid
down the feed tube whilst the appliance is running. Process until a smooth elastic ball of dough is formed.
•Re-knead by hand only. Re-kneading in the bowl is not
recommended as it may cause the processor to become unstable.
Discs – grating Use for cheese, carrots, potatoes and foods
of a similar texture.
2 –
Do not fill above the
maximum 1.2L marked on
the bowl
•Use fresh ingredients
•Do not cut food too small. Fill the width of the feed tube
fairly full.This prevents the food from slipping sideways during processing.
•When slicing or grating: food placed upright comes out
shorter than food placed horizontally.
•There will always be a small amount of waste on the disc
or in the bowl after processing.
Discs – slicing Use for cheese, carrots, potatoes, cabbage,
cucumber, courgette, beetroot and onions.
2–
Discs – extra fine grating
Grates Parmesan cheese 2 –
Citrus Juicer (if supplied)
Use to squeeze the juice from citrus fruits e.g.oranges, lemons, limes and grapefruits).
1 – – • For best results store and juice the fruit at room
temperature and hand roll on a worktop before juicing.
• To help with juice extraction move the fruit from side to
side when juicing.
• When juicing large quantities, empty the strainer regularly
to prevent the build up of pulp and seeds.
134699 Iss 1 FDM30 Eng_Arabic.B5.indd 6 21/03/2017 16:05

7
recommended speed chart tool/ attachment
function recommended
speed
processing
time (secs)
maximum
capacities
hints and tips
Blender Cold liquids and drinks 2 60 1.2 litre • When making mayonnaise, put all the ingredients, except the oil,
into the blender. Remove the filler cap. Then, with the appliance running, add the oil slowly through the hole in the lid.
• Thick mixtures, e.g. pâtés and dips, may need scraping down. If
the mixture is difficult to process, add more liquid.
• The processing of spices is not recommended as they may
damage the plastic parts.
• To blend dry ingredients - cut into pieces, remove the filler cap,
then with the appliance running, drop the pieces down one by one. Keep your hand over the opening. For best results empty regularly.
•Do not use the blender as a storage container. Keep it empty
before and after use.
•Never blend more than 1.2 litres - less for frothy liquids like
milkshakes.
Do not process hot ingredients Milkshake/Cold milk based mixtures 2 15 1 litre
Multi mill (if supplied)
Herbs 2 10 10g/½ oz •Herbs are best milled when clean and dry.
•Baby food/purée - allow cooked food to cool down to room
temperature before processing in the mill.
•For best results the main bowl is recommended when chopping
herbs.
Nuts 2 10 – 30 50g/2oz Coffee beans 2 30 50g/2oz Uncooked meat (beef steak) cut into 2cm cubes
2 5 50g/2oz
Grinding mill (if supplied)
Processing spices 2 30 – 60 50g/2oz •For optimum performance when processing spices we
recommend that you do not process more than 50g at a time in the mill.
•Whole spices retain their flavour for a much longer time than
ground spices so it is best to grind a small quantity fresh at a time to retain the flavour.
•To release the maximum flavour and essential oils whole spices
are best roasted prior to milling.
•Do not process turmeric root in the mill as it is too hard and may
damage the blades.
•Cut ginger up into small pieces before processing. •For best results the main bowl is recommended when chopping
herbs.
Grinding coffee beans 2 50g/2oz Chopping nuts Pulse – 50g/2oz Processing garlic cloves, fresh chillies and root ginger
Pulse – 30g/1oz
Centrifugal juicer (if supplied)
Hard fruit and vegetables ie carrots and apples
2800g/1lb 12oz •Before processing remove stones and pips (eg pepper, melon,
plum) and tough skins (e.g. melon, pineapple). You do not need to peel or core apples and pears.
•Use firm, fresh fruit and vegetables. •Citrus fruit - peel and remove the white pith, otherwise the juice
may taste bitter. For best results use the citrus juicer.
Soft fruit ie tomatoes and grapes 1500g/1lb 2oz
134699 Iss 1 FDM30 Eng_Arabic.B5.indd 7 21/03/2017 16:05

8
recommended speed chart tool/ attachment
function recommended
speed
processing
time (secs)
maximum
capacities
hints and tips
Blender Cold liquids and drinks 2 60 1.2 litre • When making mayonnaise, put all the ingredients, except the oil,
into the blender. Remove the filler cap. Then, with the appliance running, add the oil slowly through the hole in the lid.
• Thick mixtures, e.g. pâtés and dips, may need scraping down. If
the mixture is difficult to process, add more liquid.
• The processing of spices is not recommended as they may
damage the plastic parts.
• To blend dry ingredients - cut into pieces, remove the filler cap,
then with the appliance running, drop the pieces down one by one. Keep your hand over the opening. For best results empty regularly.
•Do not use the blender as a storage container. Keep it empty
before and after use.
•Never blend more than 1.2 litres - less for frothy liquids like
milkshakes.
Do not process hot ingredients Milkshake/Cold milk based mixtures 2 15 1 litre
Multi mill (if supplied)
Herbs 2 10 10g/½ oz •Herbs are best milled when clean and dry.
•Baby food/purée - allow cooked food to cool down to room
temperature before processing in the mill.
•For best results the main bowl is recommended when chopping
herbs.
Nuts 2 10 – 30 50g/2oz Coffee beans 2 30 50g/2oz Uncooked meat (beef steak) cut into 2cm cubes
2 5 50g/2oz
Grinding mill (if supplied)
Processing spices 2 30 – 60 50g/2oz •For optimum performance when processing spices we
recommend that you do not process more than 50g at a time in the mill.
•Whole spices retain their flavour for a much longer time than
ground spices so it is best to grind a small quantity fresh at a time to retain the flavour.
•To release the maximum flavour and essential oils whole spices
are best roasted prior to milling.
•Do not process turmeric root in the mill as it is too hard and may
damage the blades.
•Cut ginger up into small pieces before processing. •For best results the main bowl is recommended when chopping
herbs.
Grinding coffee beans 2 50g/2oz Chopping nuts Pulse – 50g/2oz Processing garlic cloves, fresh chillies and root ginger
Pulse – 30g/1oz
Centrifugal juicer (if supplied)
Hard fruit and vegetables ie carrots and apples
2800g/1lb 12oz •Before processing remove stones and pips (eg pepper, melon,
plum) and tough skins (e.g. melon, pineapple). You do not need to peel or core apples and pears.
•Use firm, fresh fruit and vegetables. •Citrus fruit - peel and remove the white pith, otherwise the juice
may taste bitter. For best results use the citrus juicer.
Soft fruit ie tomatoes and grapes 1500g/1lb 2oz
using the attachments
Refer to recommended speed chart for each attachment.
p knife blade
Follow the instructions under "to use your food processor".
q dough tool
Use for yeasted dough mixes.
Follow the instructions under "to use your food processor".
r dual whisk
Use for light mixtures only eg egg whites, cream, evaporated
milk and for whisking eggs and sugar for fatless sponges.
Heavier mixtures such as fat and flour will damage it.
using the whisk
1 Fit the bowl onto the power unit, add the detachable drive shaft.
2 Push each beater securely into the drive head.
3 Fit the whisk by carefully turning until it drops over the drive
shaft.
4 Add the ingredients.
5 Fit the lid - ensuring the end of the shaft locates into the centre
of the lid.
6 Switch on.
discs s-c
To use the discs.
Follow the instructions under "to use your food processor".
to use the cutting discs
1 Fit the bowl onto the power unit, add the detachable drive shaft.
2 Holding by the centre grip , place the disc onto the drive shaft
with the appropriate side uppermost.
3 Fit the lid.
4 Put the food in the feed tube.
5 Switch on and push down evenly with the pusher - never put
your fingers in the feed tube.
c citrus juicer (if supplied)
Use the citrus juicer to squeeze the juice from citrus fruits (e.g.
oranges, lemons, limes and grapefruits).
cone
sieve
to use the citrus juicer
1 Fit the drive shaft and bowl onto the power unit.
2 Fit the sieve into the bowl - ensuring the sieve handle is locked
into position directly over the bowl handle.
3 Place the cone over the drive shaft turning until it drops all the
way down.
4 Cut the fruit in half. Then switch on and press the fruit onto the
cone.
l The citrus juicer will not operate if the sieve is not
locked correctly.
cm centrifugal juicer (if supplied)
Use the centrifugal juicer for making juice from firm fruit and
vegetables.
pusher
centrifugal lid
pulp remover
filter drum
bowl
juicing spout
to use the centrifugal juicer
1 Place the juicer bowl with the spout onto the power unit,
align the on the bowl with the on the power unit and turn
clockwise  until it locks .
2 Place the pulp remover into the filter drum - ensuring the
tabs locate with the slots in the bottom of the drum .
3 Fit the filter drum N.
4 Place the attachment lid onto the bowl and turn until it
locks . Your juicer will not operate if the bowl or lid
are not fitted correctly into the interlock h.
5 Place a suitable glass or jug under the juice outlet.
6 Cut the food to fit the feed tube.
7 Switch on and push down evenly with the pusher - never put
your fingers in the feed tube. Process fully before adding
more.
lAfter adding the last piece, let the juicer run for a further 30
seconds to extract all the juice from the filter drum.
important
lIf the juicer starts to vibrate, switch off and empty the pulp from
the drum. (The juicer vibrates if the pulp becomes unevenly
distributed).
lMaximum capacity that can be processed at one time is 800g of
fruit or vegetables.
lSome very hard foods may make your juicer slow down or stop.
If this happens switch off and unblock the filter.
lSwitch off and clear the pulp collector regularly during use.
134699 Iss 1 FDM30 Eng_Arabic.B5.indd 8 21/03/2017 16:05

9
care and cleaning
l Always switch off and unplug before cleaning.
l Handle the blade and cutting discs with care - they
are extremely sharp.
l Some foods may discolour the plastic. This is perfectly normal
and will not harm the plastic or affect the flavour of your
food. Rub with a cloth dipped in vegetable oil to remove the
discolouration.
power unit
l Wipe with a damp cloth, then dry. Ensure that the interlock area
is clear of food debris.
lDo not immerse the power unit in water.
lStore excess cord in the storage area at the back of the power
unit 9.
blender and multi mill
1 Empty the goblet/jar, unscrew the blender blade assembly by
turning to the unlock position to release.
2 Wash the goblet/jar by hand.
3 Remove and wash the sealing ring.
4 Do not touch the sharp blades – brush them clean using hot
soapy water, then rinse thoroughly under the tap. Do not
immerse the blade assembly in water.
5 Leave to dry upside down.
grinding mill
lRemove the lid from the blade assembly by turning in an
anticlockwise direction.
lWash the lid by hand.
lDo not touch the sharp blades – brush them clean using hot
soapy water, then rinse thoroughly under the tap. Do not
immerse the blade assembly in water.
lLeave to dry upside down.
dual whisk
l Detach the beaters from the drive head by gently pulling them
free. Wash in warm soapy water.
l Wipe the drive head with a damp cloth, then dry.
Do not immerse the drive head in water.
all other parts
l Wash by hand, then dry.
l Alternatively they can be washed in your dishwasher.
item suitable for
dishwashing
main bowl, lid, pusher 4
knife blade, dough tool 4
detachable drive shaft 4
discs 4
whisk beaters
Do not immerse the drive head in water 4
citrus juicer 4
centrifugal juicer 4
blender goblet, lid, filler cap 4
grinding mill lid 4
blade assembly and seal for blender and
multi mill 8
grinding mill blade assembly 8
spatula 4
service and customer care
l If you experience any problems with the operation of
the processor, before calling for assistance refer to
the troubleshooting guide or visit
www.kenwoodworld.com.
UK
If you need help with:
lusing your appliance or
lservicing, spare parts or repairs (in or out of guarantee)
Zcall Kenwood customer care on 023 9239 2333. Have your
model number (e.g. TYPE FDM30) and date code (5
digit code e.g. 13L35) ready. They are on the underside of
the power unit.
lspares and attachments
Z call 0844 557 3653.
lother countries
lIf you experience any problems with the operation of
your appliance, before requesting assistance refer to the
“troubleshooting guide” section in the manual or visit
www.kenwoodworld.com.
lPlease note that your product is covered by a warranty, which
complies with all legal provisions concerning any existing
warranty and consumer rights in the country where the product
was purchased.
lIf your Kenwood product malfunctions or you find any defects,
please send it or bring it to an authorised KENWOOD Service
Centre. To find up to date details of your nearest authorised
KENWOOD Service centre visit www.kenwoodworld.com or the
website specific to your Country.
lDesigned and engineered by Kenwood in the UK.
lMade in China.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL
OF THE PRODUCT IN ACCORDANCE WITH THE
EUROPEAN DIRECTIVE ON WASTE ELECTRICAL AND
ELECTRONIC EQUIPMENT (WEEE)
At the end of its working life, the product must not be disposed of
as urban waste.
It must be taken to a special local authority differentiated waste
collection centre or to a dealer providing this service.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health deriving
from inappropriate disposal and enables the constituent materials
to be recovered to obtain significant savings in energy and
resources. As a reminder of the need to dispose of household
appliances separately, the product is marked with a crossed-out
wheeled dustbin.
134699 Iss 1 FDM30 Eng_Arabic.B5.indd 9 21/03/2017 16:05

10
troubleshooting guide
Problem Cause Solution
The processor will not operate. No Power. Check processor is plugged in.
Bowl not fitted to power unit correctly. Check bowl is located correctly and
the handle is situated towards the
right front hand corner.
Bowl lid not locked on correctly. Check that the lid interlock is
located correctly into the handle
area.
The processor will not work
if the bowl and lid are fitted
incorrectly.
If none of the above check the
fuse/circuit breaker in your home.
Blender or mill will not operate Blender or mill not locked on correctly. The blender or mill will not operate
if fitted incorrectly to the interlock.
Blender or mill not assembled correctly. Check blade assembly is fully
tightened into the goblet/jar.
Processor stops during Processor overloaded/maximum capacities Check maximum capacities stated
processing exceeded. in the recommended speed chart.
Lid unlocked. Check lid is locked correctly.
Blender or multi mill leaking from blade Seal missing Check seal is fitted correctly and not
assembly base. Seal incorrectly fitted damaged. To obtain a replacement
Seal damaged. seal see “service and customer care”.
Poor performance of tools/attachments Refer to hints in relevant “using the attachment” section. Check attachments are
assembled correctly.
guarantee UK only
If your food processor goes wrong within one year from the date
you bought it, we will repair it (or replace it if necessary) free of
charge provided:
l it has been used in accordance with these instructions.
l you have not misused, neglected, or damaged it;
l it has not been modified (unless by KENWOOD);
l it is not second hand;
l it has not been used commercially;
l you have not fitted a plug incorrectly; and
l you supply your receipt to show when you bought it.
This guarantee does not affect your statutory rights.
134699 Iss 1 FDM30 Eng_Arabic.B5.indd 10 21/03/2017 16:05

11
recipes
Refer to the recommended speed chart for speeds.
carrot and coriander soup
25g (1oz) butter
1 onion chopped
1 clove garlic crushed
590g carrot cut into 1 cm cubes
cold chicken stock
10-15ml (2-3tsp) ground coriander
salt and pepper
1 Melt the butter in a pan, add the onion and garlic and fry until
soft.
2 Place the carrot into the blender, add the onion and garlic. Add
sufficient stock to reach the 1.2L level marked on the goblet. Fit
the lid and filler cap.
3 Blend on maximum speed for 5 seconds for a coarse soup or
longer for a finer result.
4 Transfer the mixture to a saucepan, add the coriander and
seasoning and simmer the soup for 30 to 35 minutes or until
cooked.
5 Adjust the seasoning as necessary and add extra liquid if
required.
shortcrust pastry
300g (12oz) plain flour
150g (6oz) mixture of lard and margarine cut into small pieces
2.5ml (1⁄2tsp) salt
45ml (3tbsp) cold water
1 Fit the knife blade and add the flour, salt and fat. Process for
approximately 10 seconds or until the mixture looks like coarse
breadcrumbs.
2 Then add the water down the feed tube on low speed until the
mixture looks like it is about to stick together.
3 Turn out the mixture onto a worksurface and shape by hand.
Use as required.
l For best results allow the pastry to rest before use. Place in
a plastic bag or wrap in cling film and chill in the fridge for 20
minutes.
lasagne
300g (12oz) braising steak, cubed.
400g can of tomatoes
30ml (2tbsp) tomato puree
1 onion
5ml (1tsp) basil
100g (4oz) lasagne
200g (8oz) mozzarella cheese
15ml (1tbsp) oil
salt and pepper
1 Grate the cheese using the grating disc.
2 Then separately chop the meat and onions with the knife blade.
3 Pre-heat the oil and fry the onions until softened, add the meat
and fry until brown.
4 Then add the tomatoes, tomato puree and seasonings.
5 Stir well, cover and simmer gently for about 40 minutes.
6 Cook the lasagne in plenty of salted boiling water until tender.
Then drain well.
7 Place layers of meat, lasagne and cheese in a 1 litre/2 pint oven
proof dish. Finish with a layer of cheese.
8 Bake at 190°C/375°F/Gas Mark 5 for 30 minutes or until golden
and bubbling.
victoria sandwich
150g (6oz) soft margarine
150g (6oz) caster sugar
150g (6oz) self raising flour
5ml (1tsp) baking powder
3 eggs
15ml (1tbsp) warm water
filling & decoration
3tbsp strawberry jam
150ml (1⁄4pt) double cream whipped (optional)
1tbsp icing sugar or caster sugar
1 Pre-heat the oven to 180°C/350°F/Gas mark 4 and grease two
18cm (7") shallow cake tins.
2 Fit the knife blade. Place all the ingredients for the sponge in the
bowl and process for 5 seconds. Using a spatula, scrape the
mixture into the centre of the bowl and process for a further
5 seconds.
3 Pour the mixture into the prepared tins and bake for 20 - 25
minutes or until firm to a light touch and coming away from the
edges slightly. If you are unsure whether the cake is cooked
insert a thin skewer in the centre and it should come out clean.
Turn out onto a wire cooling rack.
4 When cool spread the jam and cream over one of the cakes, top
with the other cake and sprinkle with the sugar.
134699 Iss 1 FDM30 Eng_Arabic.B5.indd 11 21/03/2017 16:05

12
white bread
300g(10oz) strong white bread flour
5ml (1tsp) salt
6g(1⁄4oz) lard
15g (1⁄2oz) fresh yeast or 10ml(2tsp) dried yeast + 5ml (1tsp)
caster sugar.
175ml (6 fl oz) warm water
1 Dried yeast (the type that needs reconstituting): Add
the yeast and sugar to the warm water. Leave to stand for 5 - 10
minutes until frothy.
Fresh yeast: crumble into the flour
Other types of yeast: follow the manufacturer’s instructions.
2 Fit the dough tool or knife blade and add the flour (with fresh
yeast if used), salt and lard. Process for a few seconds to evenly
distribute the ingredients.
3 Then with the motor running quickly pour the liquid in a steady
stream down the feed tube until the mixture forms an elastic soft
dough. This will take about 60 seconds.
4 Remove the dough, place in a bowl, cover with an oiled piece of
cling film or a plastic bag, and leave in a warm place for 45 - 60
minutes or until doubled in size.
5 Re-knead by hand for 2 - 3 minute. Re-kneading in the
bowl is not recommended as it may cause the
processor to become unstable. Shape into a loaf or 15
rolls and place on greased baking trays and leave until double in
size.
6 Then bake in a pre-heated oven at 230°C/450°F/Gas mark 8
for 20 - 25 minutes for the loaf or 10 - 15 minutes for bread
rolls. When ready they should sound hollow when tapped on the
base.
134699 Iss 1 FDM30 Eng_Arabic.B5.indd 12 21/03/2017 16:05

13
«∞LAJKW «∞º∂V «∞∫qÒ
§NU“ ¢∫COd «∞DFU ô ¥FLq. «∞πNU“ ¨Od ±uÅq °LBb¸ ¢OU¸ ØNd°Uzw. ¢∫IIw ±s «∞ºKp «∞JNd°Uzw Ë√≤t ±uÅq °LMHc «∞∑OU¸ «∞JNd°Uzw.
¢QØbÍ ±s ¢FAOo «∞GDU¡ «∞FKuÍ °AJq Å∫O` ≠w ±MDIW
«∞LI∂i.
∞s ¥FLq §NU“ ¢∫COd «∞DFUÂ ≠w •U∞W ¢dØOV
Ë«∞GDU¡ «∞FKuÍ °AJq ¨Od Å∫O`.
≠w •U∞W ´b •q «∞LAJKW °U∞∫Ku‰ √´öÁ, ¢∫IIw ±s «∞LMBNd/
ÆU©l «∞b«zd… «∞JNd°UzOW ≠w «∞LMe‰.
¢uÆn §NU“ ¢∫COd «∞DFUÂ √£MU¡ «∞∑AGOq. ¢πUË“ •b «∞∑∫LOq ∞πNU“ ¢∫COd
«∞DFUÂ/¢πUË“ «∞ºFU‹ «∞IBuÈ
¢r ≠∑` «∞GDU¡ «∞FKuÍ.
¢∫IIw ±s «∞ºFU‹ «∞IBuÈ «∞LuÅv °NU Ë«∞L∫bœ… ≠w §bˉ
«∞ºd´U‹.
¢QØbÍ ±s ÆHq «∞GDU¡ «∞FKuÍ °AJq Å∫O`.
•KIW «ù•JU ¨Od ±dØ∂W.
•KIW «ù•JU ¨Od ±dØ∂W ≠w
±u{FNU §Ob«.
•KIW «ù•JUÂ ¢U∞HW.
¢∫IIw ±s ¢dØOV •KIW «ù•JUÂ ≠w ±u{FNU «∞B∫O` Ë°Dd¥IW
Å∫O∫W Ë√≤NU ¨Od ¢U∞HW. ∞K∫Bu‰ ´Kv •KIW ≈•JU ôß∑∂b«‰
«∞∫KIW «∞∑U∞HW. ¸«§Fw ƺr «∞BOU≤W ˸´U¥W «∞FLö¡
ô ¢FLq «_œË«‹/«∞LK∫IU‹ °AJq §Ob. ¸«§Fw «∞∑KLO∫U‹ «∞L∑FKIW °Jq √œ«… √Ë ±K∫o ≠w ƺr («ß∑ªb«Â «∞LK∫o). ¢QØbÍ ±s ¢dØOV «∞LK∫IU‹ °AJq
Å∫O`.







/




22

)(


134699 Iss 1 FDM30 Eng_Arabic.B5.indd 13 21/03/2017 16:05

14
«∞FMU¥W Ë«∞∑MEOn
l √ËÆHw œ«zLUÎ ¢AGOq «∞πNU“ Ë«≠BKOt ´s ±Bb¸ «∞∑OU¸ «∞JNd°w Æ∂q «∞∑MEOn.
l Æb ¢R£d °Fi «ô¨c¥W ´Kv ∞uÊ «∞∂öß∑p. ≥c« «±d ©∂OFw ¢LU±U Ëô ¥Cd
°U∞∂öß∑p «Ë ¥R£d ´Kv ≤JNW «∞DFUÂ. «±º∫w «∞∂öß∑Op °ILU‘ ±GLu”
≠w “¥X ≤∂U¢w ù“«∞W ¢GOOd «∞KuÊ.
l ¢Lº` °IDFW ÆLU‘ ¸©∂W, £r ¢πHn. ±s îKu ±MDIW «∞∑d«°j ±s
°IU¥U «∞DFUÂ.
lô ¢Iu±w °GLd Ë•b… «∞DUÆW ≠w «∞LU¡.
lÆu±w °Kn «∞ºKp «∞e«zb ≠w ±JUÊ ¢ªe¥s «∞ºKp √ßHq Ë•b… «∞DUÆW
9
.
– l

()


/ 
 
/ 
 
– 


 

 l

 l
– l


 l
 
l «≠BKw –¸«´w «∞ªHo ±s ¸√” «∞L∫d„ °Ab≥LU °d≠o ≤∫u «∞ªU¸Ã.
«¨ºKONLU °U∞LU¡ «∞b«≠T Ë«∞BU°uÊ.
l «±º∫w ¸√” «∞L∫d„ °IDFW ÆLU‘ ¸©∂W, £r ¢πHOHNU. ô ¢GLdÍ ¸√”
«∞L∫d„ ≠w «∞LU¡.
§LOl «ô§e«¡ «ôîdÈ
l ¢Gºq °U∞Ob £r ¢πHn.
 l
«∞FMBd
«∞ºKDU≤OW «∞dzOºOW, «∞GDU¡ «∞FKuÍ, ´BU œ≠l «∞LJu≤U‹
ßJOs «∞∑IDOl, √œ«… «∞FπOs
±∫u¸ «∞b˸«Ê
«_Æd«’
«∞ªHUÆW
ô ¢GLdÍ ¸√” «∞L∫d„ ≠w «∞LU¡
´BU¸… ±u«∞`
œË¸‚ Ë«∞GDU¡ «∞FKuÍ Ë≠∑∫W «∞∑F∂µW
±IADW
4
4
4
4
4
4
4
4
4
8
8
4










«∞BOU≤W Ë«∞FMU¥W °U∞FLö¡
l¢BLOr Ë¢Du¥d doowneK ≠w «∞LLKJW «∞L∑∫b….
lÅMl ≠w «∞BOs.
≠w ≤NU¥W «∞FLd «∞∑AGOKw ∞KπNU“, ¥πV ´b «∞∑ªKh ±s «∞πNU“ ≠w ≤HU¥U‹
«∞LMU©o «∞∫Cd¥W.
°q ¥πV √îcÁ ≈∞v ±dØe ¢πLOl îU’ °πNW ±∫KOW ±∑ªBBW ≠w «∞∑ªKh ±s
≥cÁ «∞MHU¥U‹ √Ë ≈∞v ¢U§d ¥Ib ≥cÁ «∞ªb±W.
«∞∑ªKh ±s «_§Ne… «∞LMe∞OW ´Kv ≤∫u ±MHBq, ¥πMV «ü£U¸ «∞ºK∂OW «∞L∫∑LKW
´Kv «∞∂OµW Ë«∞B∫W Ë«∞∑w ¢M∑Z ´s «∞∑ªKh ±s ≥cÁ «∞MHU¥U‹ °Dd¥IW ¨Od
±MUß∂W, ØLU √Ê ≥cÁ «∞FLKOW ¢ºL` °Uß∑dœ«œ «∞Lu«œ «∞LJu≤W «_±d «∞cÍ ¥∑O`
«∞∫Bu‰ ´Kv Ë≠u¸«‹ Ø∂Od… ≠w ±πU‰ «∞DUÆW Ë«∞Lu«¸œ. ∞K∑cØOd °Cd˸…
«∞∑ªKh ±s «_§Ne… «∞LMe∞OW ´Kv ≤∫u ±MHBq, ¥u§b ´Kv «∞πNU“ Åu¸…
±ADu°W ∞ºKW ÆLU±W –«‹ ´πö‹.
 l
»«

.www.kenwoodworld.com
 l


Kenwood l
.KENWOOD

 KENWOOD
www.kenwoodworld.com



)WEEE(
12
134699 Iss 1 FDM30 Eng_Arabic.B5.indd 14 21/03/2017 16:05

15
«ß∑ªb«Â «∞LK∫IU‹
¸«§Fw §bˉ ßd´U‹ «∞∑AGOq «∞LuÅv °NU ∞Jq ±K∫o.
p
ßJOs «∞∑IDOl
.”“ 
q
√œ«… «∞FπOs
¢º∑ªb ±l îKDU‹ «∞FπOs «∞LªLd….
.”“ 
r
«∞ªHOHW ≠Ij ±∏q °OU÷ «∞∂Oi √Ë «∞IAb… √Ë «∞∫KOV
«∞LπHn Ë√¥CUÎ ∞ªHo «∞∂Oi Ë«∞ºJd ∞∑∫COd «∞JOp «ùßHMπw «∞ªU∞w
±s «∞bßr. ¢∑º∂V «∞ªKDU‹ «∞J∏OHW ±∏q «∞b≥uÊ Ë«∞bÆOo ≠w ¢Kn
«ß∑ªb«Â
1 ¸Ø∂w «∞ºKDU≤OW ´Kv Ë•b… «∞DUÆW («∞Lu¢u¸) £r ¸Ø∂w ±∫u¸ «∞b˸«Ê
«∞IU°q ∞KHp Ë«∞∑dØOV.
2 «œ≠Fw Øq ±Cd» °S•JU œ«îq ¸√” «∞b˸«Ê.
3 ¸Ø∂w ±s îö‰ °∫c¸ •∑v ´Kv ±∫u¸ «∞b˸«Ê.
4 √{OHw «∞LJu≤U‹.
5 ¸Ø∂w «∞GDU¡ «∞FKuÍ - ±l «∞∑QØb ±s «ß∑Id«¸ ©d· ±∫u¸ «∞b˸«Ê ≠w
±dØe «∞GDU¡ «∞FKuÍ.
6 ®GKw «∞πNU“.
c –s
 
.»« 

1 ¸Ø∂w «∞ºKDU≤OW ´Kv Ë•b… «∞DUÆW («∞Lu¢u¸) £r ¸Ø∂w ±∫u¸ «∞b˸«Ê
«∞IU°q ∞KHp Ë«∞∑dØOV.
2 «±ºJw «∞∑IDOl ±s «∞LI∂i
b
«∞LdØeÍ £r {Fw ´Kv
±∫u¸ «∞b˸«Ê ±l ¢u§Ot «∞ºD` «∞Lözr _´Kv.
3 ¸Ø∂w «∞GDU¡ «∞FKuÍ.
4 √œîKw «∞DFU ±s îö‰ √≤∂u» .
5 ®GKw «∞πNU“ ±l œ≠l «∞DFU °U∞∑ºUËÍ °u«ßDW ´BU œ≠l «∞LJu≤U‹ -
«•c¸Í Ë{l √ÅU°Fp œ«îq ≠∑∫W
.
c
(≠w •U∞W «∞∑eË¥b œ«îq ÅMbË‚ «∞∂Ol)
«ß∑ªb±w «∞FBU¸… ∞∑∫COd «∞FBOd ±s «∞Lu«∞` (±∏q «∞∂d¢IU‰
Ë«∞KOLuÊ Ë«∞KOLuÊ «∞∫LCw Ë«∞πd¥V ≠dË‹).
±ªdË◊ «∞FBd
«∞LBHU…
«ß∑ªb«Â
2 ¸Ø∂w «∞LBHU… ≠w «∞ºKDU≤OW - ¢QØbÍ ±s «ß∑Id«¸ ±I∂i «∞LBHU… ≠w
±u«{Ft ±∂U®d… ´Kv ±I∂i «∞ºKDU≤OW.
3 ¸Ø∂w ±ªdË◊ «∞FBd ´Kv ±∫u¸ «∞b˸«Ê Ë√œ¥d¥t •∑v ¥º∑Id ¢LU±UÎ ≠w
4 ÆDFw £LU¸ «∞Hu«Øt ≈∞v ≤BHOs. £r ®GKw «∞πNU“ Ë«{GDw «∞HUØNW ´Kv
±ªdË◊ «∞FBd.
l ∞s ¢FLq «∞FBU¸… ≠w •U∞W ¢dØOV «∞LBHU… °AJq ¨Od Å∫O`.
cm
´BU¸… «∞Ddœ «∞LdØeÍ (≠w •U∞W «∞∑eË¥b œ«îq ÅMbË‚
«∞∂Ol)
«ß∑ªb±w ´BU¸… «∞Ddœ «∞LdØeÍ ∞∑∫COd «∞FBOd ±s «∞HUØNW
Ë«∞ªCd«Ë«‹ «∞BK∂W.
´BU œ≠l «∞LJu≤U‹
¨DU¡ «∞Ddœ «∞LdØeÍ
±e¥q «∞KV
«ßDu«≤W «∞∑d®O`
«∞ºKDU≤OW
≠∑∫W ¢b≠o «∞FBOd
«ß∑ªb«Â ´BU¸… «∞Ddœ «∞LdØeÍ
1 {Fw ßKDU≤OW «∞FBU¸… ±l ≠∑∫W ¢b≠o «∞FBOd ´Kv Ë•b… «∞DUÆW
(«∞Lu¢u¸) £r •U–Í «∞Fö±W «∞Lu§uœ… ´Kv «∞ºKDU≤OW ±l «∞Fö±W
«∞Lu§uœ… ´Kv Ë•b… «∞DUÆW («∞Lu¢u¸) £r ∞Hw «∞ºKDU≤OW ≠w «¢πUÁ ´IU¸»
«∞ºU´W
b
•∑v ¢º∑Id ≠w ±u{l «∞IHq .
2 {Fw ±e¥q «∞KV °b«îq «ßDu«≤W «∞∑d®O` - ¢QØbÍ ±s «ß∑Id«¸
«_©d«· ≠w «∞H∑∫U‹ «∞Lu§uœ… ≠w √ßHq «ôßDu«≤W
b
.
3 ¸Ø∂w «ßDu«≤W «∞∑d®O`
b
.
4 {Fw «∞GDU¡ «∞FKuÍ ´Kv «∞ºKDU≤OW Ë∞HOt •∑v ¥º∑Id ≠w ±u{l
«∞IHq
b
. ∞s ¢FLq «∞FBU¸… ≠w •U∞W ¢dØOV «∞ºKDU≤OW √Ë
«∞GDU¡ «∞FKuÍ °Dd¥IW ¨Od Å∫O∫W ≠w ±u{l ¢FAOo «∞IHq
8
.
5 {Fw Øu°UÎ √Ë Ë´U¡Î ±MUß∂UÎ ¢∫X ≠∑∫W ¢b≠o «∞FBOd.
6 ÆDFw «∞LJu≤U‹ •∑v ¥LJs ≈œîU∞NU ´∂d √≤∂u» ≈œîU‰ «∞LJu≤U‹.
7 ®GKw «∞πNU“ ±l œ≠l «∞DFU °U∞∑ºUËÍ °u«ßDW ´BU œ≠l «∞LJu≤U‹ -
«•c¸Í Ë{l √ÅU°Fp œ«îq ≠∑∫W ≈œîU‰ «∞LJu≤U‹. «≤∑Nw ±s
¢∫COd «∞JLOW «∞Lu{u´W °AJq ¢U Æ∂q ≈{U≠W ØLOW √îdÈ.
l °Fb ≈{U≠W ¬îd ÆDFW, «¢dØw «∞FBU¸… ¢FLq ∞Lb… 03 £U≤OW ≈{U≠OW
ôß∑ªö’ Øq «∞FBOd ±s «ßDu«≤W «∞∑d®O`.
≥UÂ
l ≠w •U∞W °b¡ «∞FBU¸… ≠w «ô≥∑e«“, √ËÆHw ¢AGOq «∞πNU“ Ë√≠d¨w «∞KV
±s «ßDu«≤W «∞∑d®O`. (¢N∑e «∞FBU¸… ≠w •U∞W «∞∑u“¥l ¨Od «∞L∑ºUËÍ
∞KV).
l «∞ºFW «∞IBuÈ ∞K∑∫COd ≠w «∞Ld… «∞u«•b… ≥w 008 ¨d«Â ±s «∞HUØNW
√Ë «∞ªCd«Ë«‹.
l °Fi √≤u«Ÿ «_©FLW «∞BK∂W Æb ¢º∂V °j¡ √Ë ¢uÆn «∞FBU¸….
≈–« •bÀ –∞p, √ËÆHw «∞∑AGOq Ë√“¥Kw «∞Ld®`.
l √ËÆHw «∞∑AGOq Ë√≠d¨w ±πLl «∞KV °AJq œË¸Í √£MU¡ «ôß∑ªb«Â.
.)( 


02











134699 Iss 1 FDM30 Eng_Arabic.B5.indd 15 21/03/2017 16:05

16
91
«_œ«…/«∞LK∫o «∞u™OHW «∞ºd´W «∞LuÅv
°NU «∞ºFU‹ «∞IBuÈ
206 – 03
©∫s •∂u» «∞INu… 2 ≠d «∞LJºd«‹ – ≠d ≠Bu’ «∞∏u ˫∞HKHq «_•Ld «∞DU“à ˫∞e≤π∂Oq
–
«∞Hu«Øt Ë«∞ªCdË«‹ «∞BK∂W ±∏q «∞πe¸ Ë«∞∑HUÕ
2–008 ¨d«Â • Æ∂q «∞∑∫COd √“¥Kw «∞MuÈ Ë«∞∂c˸ ±s «∞LJu≤U‹ (±∏q «∞HKHq Ë«∞∂DOa Ë«∞∂dÆu‚)
Ë«∞IAd… «∞ªU¸§OW «∞BK∂W («∞∂DOa Ë«_≤U≤U”). ô ¢∫∑U§w ≈∞v ¢IAOd √Ë ≈“«∞W «∞∂c˸ ±s «∞∑HUÕ √Ë «∞JL∏dÈ.
• «ß∑ªb±w ≠UØNW ËîCd«Ë«‹ ÅK∂W Ë©U“§W. • ≠w •U∞W «∞Lu«∞` - ÆAdÍ «∞Hu«Øt Ë√“¥Kw «∞KV Ë≈ô ßOB∂` ±c«‚ «∞FBOd ±d«Î.
«ß∑ªb±w ´BU¸… «∞Lu«∞` ∞K∫Bu‰ ´Kv √≠Cq «∞M∑UzZ.
«∞Hu«Øt «∞KOMW ±∏q «∞DLU©r Ë«∞FMV 1–005 ¨d«Â
   
 
)(


 




 
•

 
•


 
•

 
•

 
•
 
•


(

)




134699 Iss 1 FDM30 Eng_Arabic.B5.indd 16 21/03/2017 16:05

17
«_œ«…/«∞LK∫o «∞u™OHW «∞ºd´W
«∞LuÅv °NU «∞ºFU‹ «∞IBuÈ
2–• «ß∑ªb±w ±Ju≤U‹ ©U“§W.
• «∞DFU «∞Lu{uŸ °AJq ¸√ßw ¥ªdà ÆBOd«Î ´s «∞DFU «∞Lu{uŸ °AJq √≠Iw.
2–
2–
´BU¸… ±u«∞` (≠w •U∞W «∞∑eË¥b œ«îq ÅMbË‚ «∞∂Ol)
1– – • ∞K∫Bu‰ ´Kv √≠Cq «∞M∑UzZ, îe≤w «∞HUØNW Ë«´Bd¥NU ≠w œ¸§W •d«¸… «∞Gd≠W, √¥CUÎ
∞OMw «∞HUØNW Æ∂q ´Bd≥U ´s ©d¥o œ•d§∑NU ´Kv ßD` ±MCb… «∞FLq ±l «∞CGj ´KONU °d«•W ØHp.
• ∞KLºU´b… ≠w «ß∑ªö’ «∞FBOd, •dØw «∞HUØNW ±s §U≤V üîd √£MU¡ «∞FBd. • ´Mb ´Bd ØLOW Ø∂Od… ±s «∞HUØNW, √≠d¨w «∞LBHU… °U≤∑EU ∞∑πMV ¢d«Ør ∞V Ë°c˸
«∞HUØNW.
«∞ºu«zq Ë«∞LAdË°U‹ «∞∂U¸œ… 06 •´Mb ¢∫COd «∞LU¥u≤Oe, {Fw Øq «∞LJu≤U‹ ≠w «∞LºOq ´b« «∞e¥X. √“¥Kw ¨DU¡ ≠∑∫W
«∞∑F∂µW. £r Å∂Òw «∞e¥X °Dd¥IW °DOµW ±s îö‰ «∞H∑∫W «∞Lu§uœ… ≠w «∞GDU¡ «∞FKuÍ √£MU¡ ¢AGOq «∞πNU“.
•Æb ¢∫∑Uà «∞ªKDU‹ «∞ºLOJW ±∏q «∞LFπMU‹ «∞NAW Ë«∞LGLußU‹ ≈∞v ¢IDOl. ≈–« ˧b‹
ÅFu°W ≠w ¢∫COd≥U, √{OHw «∞Le¥b ±s «∞ºu«zq.
•¨Od ±MBuÕ °D∫s «∞∑u«°q ≠Ib ¢RœÍ ≈∞v ≈•b«À √{d«¸ °U_§e«¡ «∞∂öß∑OJOW. • ±Ju≤U‹ §U≠W - ÆDÓFONU ≈∞v √§e«¡ ÅGOd… £r √“¥Kw ¨DU¡ ≠∑∫W «∞∑F∂µW Ë√ßIDONU
ÆDFW ¢Ku «_îdÈ √£MU¡ ¢AGOq «∞πNU“. √°o ¥b¥p ≠u‚ «∞H∑∫W. ∞K∫Bu‰ ´Kv √≠Cq «∞M∑UzZ √≠d¨w «∞L∫∑u¥U‹ °AJq ±M∑Er.
•ô ¢º∑ªb±w Ø∫UË¥W ¢ªe¥s .•U≠Ew ´Kv «∞b˸‚ ≠U¸¨UÎ Æ∂q Ë°Fb «ôß∑ªb«Â. •ô ¢ªKDw ßFW √Ø∂d ±s 2.1 ∞∑d - «ß∑ªb±w ßFW √Æq ±l «∞ºu«zq «∞d¨u¥W ±∏q «∞∫KOV
«∞LªHu‚.
51
206 •¥LJs «∞∫Bu‰ ´Kv √≠Cq «∞M∑UzZ ´Mb±U ¢JuÊ «_´AU» ≤EOHW ˧U≠W.
203 – 01
203 2 5
   
 
)(

-
-

-














,
)(  
•
 

 
•





/




(

)



)(

–/ 
•

 
•

   
81


134699 Iss 1 FDM30 Eng_Arabic.B5.indd 17 21/03/2017 16:05

18
71
«_œ«…/«∞LK∫o «∞u™OHW «∞ºd´W
«∞LuÅv °NU «∞ºFU‹ «∞IBuÈ
ßJOs «∞∑IDOl îKDU‹ «∞JFJU‹ «∞πU≥e… 201
• ¥πV ¢JºOd «∞∂ºJu¥X ≈∞v ÆDl ÅGOd… Ë≈{U≠∑t ´s ©d¥o ¨DU¡ √≤∂u»
√£MU¡ ¢AGOq «∞πNU“.
• ¢uîw «∞∫c¸ •∑v ô ¢∑πUË“Í «∞H∑d… «∞LDKu°W ∞∑∫COd «∞DFUÂ. • ´Mb ¢∫COd «∞LFπMU‹ «ß∑ªb±w «∞b≥uÊ ±∂U®d… ±s «∞LπLb ±l ¢IDOFNU ≠w Åu¸…
±JF∂U‹ °∫πr ¢Id¥∂w 2ßr.
≈{U≠W «∞LU¡ ∞b±Z ±Ju≤U‹ «∞LFπMU‹
2
1– 2
01
02 – 01
≠d «_ßLU„ Ë«∞K∫u 203 – 01 ∞∫r °IdÍ
©dÍ
≠d «∞ªCd«Ë«‹ 01 – 5 ≠d «∞LJºd«‹ 206 – 03 ≥d” «∞Hu«Øt «∞KOMW Ë«∞Hu«Øt Ë«∞ªCdË«‹ «∞LDNOW 203 – 01
06 – 03 03 – 51 005
206 2 ≥UÂ
•±Cd» «∞∂Oi ¨Od ±MUßV ∞öß∑ªb«Â ±l îKDU‹ «∞JFJU‹ «∞πU≥e… •OY √Ê
Æu«Â ≥cÁ «∞JFJU‹ £ªOs Ëßu· ¥∑º∂V ≠w ¢Kn «∞LCd». «ß∑ªb±w œ«zLUÎ ≤Bq «∞ºJOs.
• ¥LJMp «∞∫Bu‰ ´Kv √≠Cq «∞M∑UzZ ´Mb±U ¢JuÊ œ¸§W •d«¸… «∞∂Oi ≥w ≤Hf œ¸§W
•d«¸… «∞Gd≠W.
• ¢QØbÍ ±s ≤EU≠W «∞ºKDU≤OW ˱Cd» «∞∂Oi Ë´b ˧uœ √Í œ≥uÊ Æ∂q «∞ªHo.
203 005
√œ«… «∞FπOs «∞ªKDU‹ «∞LªLd… 206
• √´ObÍ «∞Fπs °Ob¥p ≠Ij. ¨Od ±MBuÕ °S´Uœ… «∞Fπs ≠w «∞ºKDU≤OW •OY Æb ¥RœÍ –∞p
≈∞v ´b «ß∑Id«¸ §NU“ ¢∫COd «∞DFUÂ.
   
–
(

)



/



 
)(
,





 


()




 
•
 
•
 
•
 
•
 





134699 Iss 1 FDM30 Eng_Arabic.B5.indd 18 21/03/2017 16:05

61
.1)( 
  
)( 
2
.
 l
.On/Off

3 ¸Ø∂w «∞LK∫o ´Kv ±∫u¸ «∞b˸«Ê «∞Lu§uœ ≠w «∞ºKDU≤OW.
l¸Ø∂w œ«zLUÎ Ë«∞LK∫o ≠w §NU“ ¢∫COd «∞DFU Æ∂q ≈{U≠W
«∞LJu≤U‹.
4 ¸Ø∂w «∞GDU¡ «∞FKuÍ
3
- ±l «∞∑QØb ±s «ß∑Id«¸ «∞πe¡ «∞FKuÍ ±s
±∫u¸ «∞b˸«Ê/«_œ«… ≠w ±dØe «∞GDU¡ «∞FKuÍ.
5 ËÅKw «∞πNU“ ±l ±Bb¸ «∞∑OU¸ «∞JNd°w £r ®GKw «∞πNU“ Ë•bœÍ «∞ºd´W
«∞LDKu°W. (¸«§Fw §bˉ «∞ºd´U‹ «∞LuÅv °NU).
l ∞s ¥FLq §NU“ ¢∫COd «∞DFU ≠w •U∞W ¢dØOV «∞ºKDU≤OW √Ë
«∞GDU¡ «∞FKuÍ °Dd¥IW ¨Od Å∫O∫W ≠w ±u{l ¢FAOo «∞IHq.
¢QØbÍ ±s ¢u§Ot √≤∂u» ˱I∂i «∞ºKDU≤OW ≈∞v
«∞πU≤V «_¥Ls ∞KπNU“.
l «ß∑ªb±w ±H∑UÕ Ë{l «∞∑AGOq «∞M∂Cw (P) ∞K∑AGOq ∞H∑d«‹ ÆBOd….
¥FLq Ë{l «∞∑AGOq «∞M∂Cw ©u«‰ ≠∑d… «∞CGj ´Kv ±H∑UÕ «∞∑∫Jr.
6
«¢∂Fw «∞ªDu«‹ «∞ºU°IW °∑d¢OV ±FJu” ù“«∞W «∞GDU¡ «∞FKuÍ, «∞LK∫IU‹
l√ËÆHw œ«zLUÎ ¢AGOq «∞πNU“ Æ∂q ≈“«∞W «∞GDU¡ «∞FKuÍ.
±ö•EW ≥U±W
l §NU“ ¢∫COd «∞DFU ¨Od ±özr ∞D∫s •∂u» «∞INu… √Ë ¢∫u¥q •∂O∂U‹
«∞ºJd ≈∞v ßJd °uœ¸….
l ´Mb ≈{U≠W ¸ËÕ √Ë ≤JNW «∞Ku“ ∞KªKDU‹, ¢πM∂w ±ö±º∑t ±l «∞∂öß∑Op •OY
Æb ¥RœÍ –∞p ≈∞v ¢d„ ´ö±U‹ ±º∑b¥LW ´Kv «∞∂öß∑Op. 1 {Fw «∞LJu≤U‹ ≠w Ë´U¡ «∞D∫s
c
.
= ±u{l «∞H∑`
= ±u{l «∞IHq
6 ®GKw «∞LD∫MW ´Kv «∞ºd´W «∞IBuÈ √Ë «ß∑ªb±w Ë™OHW «∞∑AGOq
«∞M∂Cw.

(≠w •U∞W «∞∑eË¥b œ«îq
ÅMbË‚ «∞∂Ol)
 

.cpco 
 

.7 

:
)( 
 
)( 
8
.
)(
 
-:
 



.cr 
.9cq 
)( 
.bk
.)P( 



–  

 
–
4
:

l≈–« ØU≤X •KIW «ù•JU ¢U∞HW √Ë ¨Od ±∫JLW °AJq Å∫O`
≠ºu· ¥∫bÀ ¢ºd¥∂UÎ.
= ±u{l «∞H∑`
= ±u{l «∞IHq
∞s ¥FLq ≠w •U∞W ¢dØO∂t °AJq ¨Od Å∫O`.
3 {Fw «∞b˸‚.
4 ¸Ø∂w «∞GDU¡ «∞FKuÍ ´Kv «∞b˸‚ Ë∞HOt ≠w «¢πUÁ ´IU¸» «∞ºU´W
5
.
•∑v ≈•JU «∞IHq. ¸Ø∂w ¨DU¡ ≠∑∫W «∞∑F∂µW.
5 {Fw ´Kv Ë•b… «∞DUÆW («∞Lu¢u¸) £r •U–Í «∞Fö±W «∞Lu§uœ…
´Kv ±l «∞Fö±W
«∞Lu§uœ… ´Kv Ë•b… «∞DUÆW («∞Lu¢u¸) £r
∞Hw ≠w «¢πUÁ ´IU¸» «∞ºU´W
6
•∑v ¥º∑Id ≠w ±u{l «∞IHq
.
l ∞s ¥FLq «∞πNU“ ≠w •U∞W ¢dØOV °AJq ¨Od Å∫O` ±l
¢FAOo «∞IHq.
6 •bœÍ «∞ºd´W «∞LDKu°W (¸«§Fw §bˉ «∞ºd´U‹ «∞LuÅv °NU) √Ë
«ß∑ªb±w ¢∫Jr «∞∑AGOq «∞M∂Cw.







A
Plastic liquidiser

)(
«∞e§U§w
l≈–« ØU≤X •KIW «ù•JU ¢U∞HW √Ë ¨Od ±∫JLW °AJq Å∫O`
≠ºu· ¥∫bÀ ¢ºd¥∂UÎ.
2 «¸°Dw «∞b˸‚ ´Kv Ë•b… «∞AHd«‹
4
. ¸«§Fw «∞dßu «∞∑u{O∫OW
«∞Lu§uœ… ´Kv «∞πU≤V «∞ºHKw ∞u•b… «∞AHd«‹ Ë≥w ØU∞∑U∞w:
= ±u{l «∞H∑`
= ±u{l «∞IHq
∞s ¥FLq ≠w •U∞W ¢dØO∂t °AJq ¨Od Å∫O`.
3 {Fw «∞b˸‚.
4 ¸Ø∂w «∞GDU¡ «∞FKuÍ ´Kv «∞b˸‚ Ë«œ≠FOt _ßHq •∑v ¥º∑Id ≠w ±u{Ft
5
. ¸Ø∂w ¨DU¡ ≠∑∫W «∞∑F∂µW.
5 {Fw ´Kv Ë•b… «∞DUÆW («∞Lu¢u¸) £r •U–Í «∞Fö±W «∞Lu§uœ…
´Kv ±l «∞Fö±W «∞Lu§uœ… ´Kv Ë•b… «∞DUÆW («∞Lu¢u¸) £r
∞Hw ≠w «¢πUÁ ´IU¸» «∞ºU´W
6
•∑v ¥º∑Id ≠w ±u{l «∞IHq
.
l ∞s ¥FLq «∞πNU“ ≠w •U∞W ¢dØOV °AJq ¨Od Å∫O` ±l
¢FAOo «∞IHq.
6 •bœÍ «∞ºd´W «∞LDKu°W (¸«§Fw §bˉ «∞ºd´U‹ «∞LuÅv °NU) √Ë
«ß∑ªb±w ¢∫Jr «∞∑AGOq «∞M∂Cw.
B
)(
–  








134699 Iss 1 FDM30 Eng_Arabic.B5.indd 19 21/03/2017 16:05

51
 
 l

1935/2004 l

√Æd«’ «∞∑IDOl/«∞∑IDOl «∞Du∞w («∞∂Ad)
l ¥∫c¸ ≈“«∞W «∞GDU¡ «∞FKuÍ Æ∂q ¢uÆn «∞∑IDOl ¢LU±UÎ.
l ¢uîw «∞∫c¸ √£MU¡ «∞∑FU±q ±l «∞∑IDOl - «∞∑IDOl •Uœ… §b«Î.
´BU¸… «∞Ddœ «∞LdØeÍ
lô ¢º∑ªb±w «∞FBU¸… ≠w •U∞W ¢Kn «∞Ld®`.
l ®Hd«‹ «∞∑IDOl «∞Lu§uœ… ≠w ÆU´b… «ßDu«≤W «∞∑d®O` •Uœ… §b«Î, ¢uîw «∞∫c¸ ´Mb
«∞∑FU±q ±l «ßDu«≤W «∞∑d®O` Ë¢MEOHNU.
l «ß∑ªb±w ≠Ij ´BU œ≠l «∞LJu≤U‹ «∞LeËœ… œ«îq ÅMbË‚ «∞∂Ol. ¥∫c¸ Ë{l √ÅU°Fp
œ«îq √≤∂u» . «≠BKw «∞πNU“ ´s ±Bb¸ «∞∑OU¸ «∞JNd°w Æ∂q ≠p
l Æ∂q ≈“«∞W «∞GDU¡ «∞FKuÍ, √ËÆHw ¢AGOq «∞πNU“ Ë«≤∑EdÍ •∑v ¥∑uÆn «∞Ld®`.

l
 

l


l
Æ∂q «ôß∑FLU‰ ∞KLd… «ôË∞v
1 √“¥Kw √¨DOW «∞MBq «∞∂öß∑OJOW ´s ßJOs «∞∑IDOl. ¢uîw «∞∫c¸ ≠ºJOs
«∞∑IDOl •Uœ §b«Î. ¥πV «∞∑ªKh ±s ≥cÁ «_¨DOW •OY √≤NU ±eËœ… ∞∫LU¥W
ßJOs «∞∑IDOl √£MU¡ «∞∑BMOl Ë«∞MIq.
2 «¨ºKw «_§e«¡ ”¸«§Fw ƺr «∞d´U¥W Ë«∞∑MEOn“.
±H∑UÕ «∞d±u“
§NU“ ¢∫COd «∞DFUÂ
´BU œ≠l «∞DFUÂ
«≤∂u» «∞∑Gc¥W
±H∑UÕ «∞∑∫Jr ≠w «∞ºd´W/«∞∑AGOq «∞M∂Cw
√ÆHU‰ «_±UÊ
±ªeÊ «∞ºKp (≠w «∞ªKn)
•KIW ≈•JU «ù¨ö‚
«∞b˸‚
≠∑∫W «∞∑F∂µW
– «∞e§U§w
•KIW ≈•JU «ù¨ö‚
«∞b˸‚
≠∑∫W «∞∑F∂µW
B


m

o


1
2
3
4
5
6
7
8
9



m

o

 –A

)(


Plastic liquidiser

)(
)(
–C

®Hd… «∞ºJOs
«œ«… «∞Fπs

 )(/
 )(/
)(
p
q
r
s
t
c
 

»«



–D
´BU¸… ±u«∞` (≠w •U∞W «∞∑eË¥b œ«îq ÅMbË‚ «∞∂Ol)
)(
c
cm

(≠w •U∞W «∞∑eË¥b œ«îq
ÅMbË‚ «∞∂Ol)
c
co
cp
Ë´U¡ «∞D∫s
•KIW ≈•JU «ù¨ö‚
)(


cq
cr

 
 


134699 Iss 1 FDM30 Eng_Arabic.B5.indd 20 21/03/2017 16:05
