KERN KET-A05 User manual

KERN & Sohn GmbH
Ziegelei 1
D-72336 Balingen
E-Mail: [e-mail]
Phone: +49-[0]7433- 9933-0
Fax: +49-[0]7433-9933-149
Internet: www.kern-sohn.com
Operating manual
Transponder card reader
KERN KET-A05
Version 1.1
02/2015
GB
KET-A05-BA-e-1511

GB
KERN KET-A05
Version 1.1 02/2015
Operating manual
Transponder card reader
Contents
1Technical data................................................................................................ 3
2Basic Information (General).......................................................................... 3
2.1 Proper use................................................................................................................. 3
2.2 Improper Use............................................................................................................. 4
2.3 Warranty.................................................................................................................... 4
3Basic Safety Precautions.............................................................................. 4
3.1 Pay attention to the instructions in the Operation Manual .......................................... 4
3.2 Personnel training...................................................................................................... 4
4Transport and storage................................................................................... 5
4.1 Testing upon acceptance........................................................................................... 5
4.2 Packaging/return transport......................................................................................... 5
5Unpacking, Setup and Commissioning ....................................................... 5
5.1 Installation Site, Location of Use................................................................................ 5
5.2 Unpacking.................................................................................................................. 6
5.2.1 Scope of delivery........................................................................................................................ 6
5.3 Electric Supply........................................................................................................... 6
5.4 Connection to the balance ......................................................................................... 6
5.5 Initial Commissioning................................................................................................. 6
5.6 Overview of display.................................................................................................... 7
6Operation........................................................................................................ 8
7Servicing, maintenance, disposal ................................................................ 9
7.1 Cleaning .................................................................................................................... 9
7.2 Servicing, maintenance.............................................................................................. 9
7.3 Disposal..................................................................................................................... 9
8Instant help..................................................................................................... 9
2 KET-A05-BA-e-1511

1 Technical data
KERN
KET-A05
Dimensions
133 x 98 x 30 mm
Net weight
400 g
Wall bracket
Stainlees steel
Voltage is supplied to the balance via the connecting cable.
2 Basic Information (General)
2.1 Proper use
The transponder card reader purchased by you is used to login the respective user to
the connected balance.
The transponder card reader is designed exclusively for
connection to the KERN balance mentioned below:
Industrial balances:
KET-TM KEN-TM ILT 6K-4BM BBN 600K-1SM BBB 6T-3M
ILT 6K-3GM BBN 3T-3M BBB 600K-1SM
ILT 60K-3BM BBN 1T-4SM BBB 600K-1M
ILT 60K-2LGM BBN 1T-4M BBB 3T-3M
ILT 60K-2GM BBB 3T-3LM
ILT 30K-2GM BBB 1T-4SM
ILT 300K 2GM BBB 1T-4M
ILT 10K-3LGM
ILT 10K-3GM
ILT 100K-2LGM
ILT 100K-2GM
Laboratory
balances:
PET 600-3M
AET 500-4
ILT 35K-4NM
PET 6000-2M
AET 200-5DM
ILT 50K-4C
PET 2500-2M
AET 200-4NM
PET 1000-3M
AET 100-5M
KET-A05-BA-e-1511 3

2.2 Improper Use
Never operate the transponder card reader in an explosive environment. The serial
version is not explosion protected.
Changes to the transponder card reader's design are not permitted. This may result
in incorrect display results, safety-related defects as well as destruction.
The transponder card reader may only be operated in accordance with the described
default settings. Other areas of use must be released by KERN in writing.
2.3 Warranty
Warranty claims shall be voided in case
•Our conditions in the operation manual are ignored
•The appliance is used outside the described uses
•The appliance is modified or opened
•Mechanical damage and damage caused by media, liquids,
natural wear and tear
•The appliance is improperly set up or incorrectly electrically connected
3 Basic Safety Precautions
3.1 Pay attention to the instructions in the Operation Manual
Carefully read this operation manual before setup and
commissioning, even if you are already familiar with KERN balances.
All language versions contain a non-binding translation.
The original German document is binding.
3.2 Personnel training
The appliance may only be operated and maintained by trained personnel.
4 KET-A05-BA-e-1511

4 Transport and storage
4.1 Testing upon acceptance
When receiving the appliance, please check packaging immediately, and the
appliance itself when unpacking for possible visible damage.
4.2 Packaging/return transport
Keep all parts of the original packaging for a possibly
required return.
Only use original packaging for returning.
Prior to dispatch disconnect all cables and remove
loose/mobile parts.
Reattach possibly supplied transport securing devices.
5 Unpacking, Setup and Commissioning
5.1 Installation Site, Location of Use
The unit is designed to achieve reliable display results under normal conditions of
use.
Therefore, observe the following for the installation site:
•Protect the appliance against high humidity, vapours and dust;
•Do not expose the device to extreme dampness for longer periods of time.
Non-permitted condensation (condensation of air humidity on the appliance)
may occur if a cold appliance is taken to a considerably warmer environment.
In this case, acclimatize the disconnected appliance for ca. 2 hours at room
temperature.
•Avoid static charge.
Major display deviations (incorrect weighing results) may be experienced should
electromagnetic fields (e.g. due to mobile phones or radio equipment), static
electricity accumulations or instable power supply occur. Change location or remove
source of interference.
KET-A05-BA-e-1511 5

5.2 Unpacking
Remove the reader carefully from the packaging, take off the plastic sleeve and put
the transponder card reader together with the balance in the designated space or
attach it to the wall.
(installation of the balance according to the operating instructions of the balance)
5.2.1 Scope of delivery
Serial accessories:
•Transponder card reader
•Connecting cable to balance
•Operating manual
5.3 Electric Supply
Power is supplied via the connected balance.
5.4 Connection to the balance
Disconnect the balance from the mains before connecting the transponder card
reader or disconnecting the transponder card reader to or from the balance.
This transponder card reader is exclusively suitable for the connection to KERN
balances.
5.5 Initial Commissioning
Plug the enclosed connecting cable into the I/O terminal on the balance.
Power is supplied via the balance. The transponder card reader does not have
a power supply unit.
Switch on balance
The balance will launch a self-test and afterwards change to “0.0“ display.
The LED under the - symbol on the transponder card reader will be lit up
red.
The transponder card reader is now ready for operation.
6 KET-A05-BA-e-1511

5.6 Overview of display
Display Designation Description
1 Info Info display The LED under the i- symbol will be on when
data is transferred from the transponder card
reader to the balance.
2 On / Off Power display The LED under the - symbol will be on
when the connection between the transponder
card reader and the balance is correctly
installed.
KET-A05-BA-e-1511 7

6 Operation
First adjust on the balance the following:
Select Port:
In the display select „Devices“
Select Transponder card reader
Select Port RS 232(2)
Select baud rate:
In the display select „Communication“
Select Port RS 232(2)
Adjust the following:
oSpeed: 9600
oData bit: 8
oStop bit: 1
oParity none
Install card-reader:
Plug the enclosed connecting cable into the I/O terminal on the balance.
Switch on balance
Go to the balance and login as “admin”.
Select menu item “data bases“
Select “user“, then select “admin“ and “card number“
Swipe the card across the reader and confirm on the balance
This card is now allocated to “admin“ user only
Login by card:
Switch on balance
Go to weighing mode and swipe the card across the reader;
the LED under the i-symbol will light up briefly and you will hear a beep
The user is now logged-in as “admin“
Repeat these steps for each user you have created
8 KET-A05-BA-e-1511

7 Servicing, maintenance, disposal
7.1 Cleaning
Before cleaning, please disconnect the appliance from the operating voltage.
Please do not use aggressive cleaning agents (solvents or similar agents), but a
cloth dampened with mild soap suds. Ensure that no liquid penetrates into the device
and wipe with a dry soft cloth.
7.2 Servicing, maintenance
The appliance may only be opened by trained service technicians who are authorized
by KERN.
Before opening, disconnect from power supply.
7.3 Disposal
Disposal of packaging and appliance must be carried out by operator according to
valid national or regional law of the location where the appliance is used.
8 Instant help
In case of an error in the program process, briefly turn off the appliance and
disconnect from power supply. The process must then be restarted from the
beginning.
Help:
Fault Possible cause
The - symbol is off •The connection to the balance is
interrupted
•The power supply to the balance has
been interrupted.
