Keydous NJ80-AP User manual

Product: Zhuhai Qiannuo Technology Co., LTD
Website: www.keydous.com
Email address: k[email protected]
Keydous
NJ80-AP
User's manual
Start a New Journey in 2022
Tips:
1.WIFI signal interferes with Bluetooth signal to some
extent, so bluetooth receiver cannot be too close to WIFI
signal source.
2. It is not necessary to insert and remove the shaft body
with great force. When you find that the shaft body needs
great force, it may be misaligned, please stop the operation,
otherwise the hot plug base will be damaged, or the solder
pad will fall off and the PCB will be directly discarded.
Matters needing attention:
· Lithium battery is built into the product. It is strictly
forbidden to place the product in high temperature, high
pressure and direct sunlight. If not used for a long time,
please store the keyboard in a cool and dry environment,
and turn off the power switch.
· The original charging cable must be used to connect the
USB port of the computer for charging, and the charging
current should be less than 1A.

Operation method of bluetooth pairing :(first turn on the power
switch at the bottom of the keyboard)
① Hold down the FN+1 key for 3 seconds. The keyboard enters
the pairing state, and the digit 1 indicator blinks at short intervals.
② Open mobile device Bluetooth (such as mobile phone), select
BT5.0KB (Win7 system select BT3.0KB)
③ The mobile device is connected, and the pairing is complete.
④ Connect to the second device (e.g. computer). If the mobile
phone is connected to 1, hold down FN+2 for 3 seconds, and the
indicator light of number 2 blinks quickly. Then repeat steps ②
and ③.
⑤ Connect the third device (for example, a laptop), and hold
down the FN+3 combination key for three seconds until the
indicator 3 blinks quickly. Then repeat steps② and ③.
⑥ Now turn on the bluetooth of the three connected devices at
the same time, and switch the device connection by pressing
FN+1/2/3.
Lighting operation instructions :(there is no hibernation setting
in wired mode)
FN+ESC= Switch to light/backlight mode.
FN+ENTER= Switch the backlight color
FN+Backspace= Turn lights off/on（Turn off the light and enter
power saving mode）
FN + \ | = switch lamp effect mode (light waves, ripples,
raindrops, serpentine, follow, aggregation, sine wave,Colorful
springs, flowers, laser, peaks and turns, colorful vertical and
horizontal, breathing, neon)
FN+~= Enter custom light mode (FN+ ESC exit)
The Caps indicator is a case-sensitive indicator. You can use the
FN+ Caps command to change the color of the indicator, but it
does not participate in the indicator effect.
FN key operation instructions:
FN+1/2/3= Switch to Bluetooth mode
Fn+4= Switch to 2.4g mode. Fn+ 5= Switch to wired mode
Fn+F10= mute Fn+F11= volume - Fn+F12= volume +
Fn+Pgup=Home Fn+Pgdn=End FN+I=Insert
Fn+L= browse the web Fn+ C= my computer Fn+P=Print
FN+Win= Lock/unlock the Win key
Restore factory Settings: Simultaneously press the four corner
keys of the keyboard for 3 seconds (ESC, Left CTRL, F12, right
arrow)
2.4g pairing operation method :(first turn on the power switch
at the bottom of the keyboard)
Open the keyboard power switch, short press FN+ 4
4 key light flashing, the receiver into the computer USB port can
be used.
FN+Tab= Switch the sleep time of lights. If the Caps light
blinks once, it will start to sleep if it is not used for 2 minutes.
If the Caps indicator blinks twice, the system starts to sleep if it
is not used for 30 minutes.
FN+ direction up = increase brightness.
FN+ direction down = decrease brightness
FN+ direction left = Slow speed.
FN+ direction right = fast speed
F12 button for battery indicator: low battery for red
breath.When charged, it breathes green; when full, it turns to
its original color.
MAC:
FN+M (hold down for 2 seconds, and blink for 2 to enter, and
blink for 1 to exit) = Enter MAC mode (switch Alt and Win, right
Alt to win, right CTRL to Alt)
FN+F=MAC Switch between the multimedia key and standard
key in zone F (the keyboard must enter MAC mode first)
Knob operation instructions:
Turn left = turn down the volume,
turn right = turn up the volume
Press down to mute and press again to restore volume
Driver mode of use: driver programming software can be used
in plug-in mode or wireless 2.4g mode

FCC Requirement
Any changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy, and if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
– Consult the dealer or an experienced radio/TV technician for help.
