KICK ASS KAJSCOMP User manual

®
JUMP STARTER &
AIR COMPRESSOR
KAJSCOMP
USER MANUAL
2 5 0 0
.
V0.4

1
PACKAGING LIST
Jump Starter &
Air Compressor
Smart Clamps DC Cigarette
Lighter Adapter
USB-A to USB-C
Cable
Valve Adapter x 3 User Manual
Carrying Case

2
LAYOUT

3
LCD Power Indicator
DC 12V-16V / 10A Output Port
USB Output Port 1
USB Output Port 2
Air Hose
ON/OFF Button
LED Light
- Button
+ Button
LCD Air Pressure Display
R Button
Power Button
USB Type-C
EC5 Output Port
Battery Clamp Plug
LED Indicator
Red Battery Clamp
Black Battery Clamp
1
12
11
10
9
8
7
6
5
4
3
2
13
14
15
16
17
18
Show the charging process and remaining power
• Press the Power Button to turn ON/OFF the
device and show the remaining capacity. (The
device will automatically switch off after stopping
operation or output for 10 minutes.)
• Long press the button to turn on / off the LED
Light.
• Activate the LCD Air Pressure Indicator.
• Change display unit of measure.
• Display the air pressure of the connected tire.
• Display the output air pressure.
Increase Pressure
Decrease Pressure
Turn ON / Turn OFF the air compressor
(Use after setting the output air pressure)
Connect car tires
Charge your phone, tablet, camera, etc.
Charge your phone, tablet, camera, etc. 75% faster
than a standard charge
Charge your devices
For Charging the Jump Starter
Insert the battery clamp plug into the jump starting
port
Insert the plug completely into the EC5 Output Port
Show the work status of the battery clamp
Connect to positive terminal of the car battery
Connect to negative terminal of the car battery
FUNCTION OPERATION

4
SPECIFICATIONS
Jump Start Output
DC Output Port
Type-C Input
USB1 Output
USB2 Output
LED Light Power
Charging Time
Unit Size (L * W * H)
Air Compressor Pump
Conversion Efficiency
12V
12V-16V/10A
5V/3A, 9V/2A, 12V/1.5A
5V/3A, 9V/2A, 12V/1.5A
5V/2.1A
White: 5W
Quick Charging : 4h-4.5h
201mm * 153.5mm * 77mm
Maximum Air Pressure 150PSI
> 85%

5
OPERATION GUIDE
Charging your Jump Starter
At Home
1. Plug the USB Cable into any USB 2A wall adaptor (not included).
2. Connect the Type-C port into the Jump Starter.
In Car
1. Plug the car adaptor (not included) into the socket.
2. Connect the USB-A to USB-C cable from the car adaptor to the USB-C port on the Jump Starter.
NOTE: It is recommended to recharge the Jump Starter every 3-4 months to maintain the efficiency
and prolong the service life of the internal battery even if the unit has not been used.

6
Charging your Smart Phones or any other Devices
Your Jump Starter comes with two USB charging ports and one Type-C charging ports located at
the front of the unit:
• Plug the USB cable or Type-C cable into the USB output ports or Type-C output port on your
Jump Starter.
• Connect it to your phone, tablet or other devices you want to charge. You can charge 3 devices at
the same time.
• Power on your Jump Starter to start charging!
LED Light
Please press & hold Power Button for 3 seconds to turn on / off the LED light.
Safety Precautions
By owning a Jump Starter, you have everything you need to jump start a vehicle
—no need to wait for help, KickAss to the rescue!
We know you’re excited, but before jumping your vehicle, please be sure to take some
precautionary steps:
• Read your vehicle owner’s manual first as the manufacturer may have specific steps and
precautions that pertain to your vehicle.
• Be sure to turn off all electronics in your car (radio, lights, etc.) before jump starting.
• Make sure you are in a dry, well-ventilated area. Never jump start a vehicle in an enclosed area.
• Remove any moisture from your jump starter unit, accessories, and your vehicle’s battery. Never
attempt to jump start a vehicle when moisture is present.
• Check that the vehicle’s battery terminals are clean to ensure the best conductivity.
• Properly identify the vehicle battery’s positive (+, red) and negative (-, black) terminals before
connecting the clamps.
• When using the clamps, do not allow the metal teeth of the black clamp to touch the metal teeth of
the red clamp.
• When using the clamps, DO NOT connect the RED clamp to the vehicle battery’s negative (-)
terminal, or the BLACK clamp to the vehicle battery’s positive (+) terminal.
• When connecting smart clamps to the battery terminals, ensure the copper teeth on each side of
the clamp make good contact with the terminal. The better the connection, the easier it will be to
start your vehicle.
NOTE: When adjusting the clamps please be sure to disconnect your Jump Starter first. This will
prevent the occurrence of minor sparks.

7
Jump Starting a Vehicle
Step 1: Insert the plug of the battery clamps completely into the jump starter, the red and
green lights flashing alternately.
Step 2: Connect the red clamp to the positive electrode (+) of the car battery and the
black clamp to negative one (-).
Step 3: Start the vehicle.
If the engine does not start on the first try, disconnect it from the car battery and wait for
at least 20 seconds before reconnecting.

8
Step 4: When the vehicle is started, remove the battery clamp from the car battery and
the jump starter within 30 seconds.
NOTE: After the green light of the smart clip is always on (work status), do not
disconnect or change the connection between the clip and the car battery to avoid short
circuit or reverse connection.
Inflating the Vehicle Tire
Please read safety instructions carefully before use:
• For safety reasons, the device should be KEPT OUT OF REACH OF CHILDREN.
• Inspect the Jump Starter before each inflates, ensuring the valve and the air hose are
not damaged.
• Do not bend or restrict the air hose while the compressor is in use.
• Avoid using in rainy or wet conditions as water entering the unit can cause internal
damage and premature failure.
• In case of an electrical or mechanical fault, immediately switch off and unplug the
compressor.
• Only use on tires and inflatable items.
• Take extra care not to over-inflate when inflating other inflatable items such as sports
ball, bike tires, air bed, etc.
• Please refer to your vehicle handbook for the correct tire pressure required for your
vehicle.

9
Step 1: Press the Power Button to activate the device. Then press the R Button to
activate the LCD Air Pressure Display and choose your preferred pressure type in psi,
bar, kPa or kg/cm².
Step 2: Press the + Button/- Button to increase/decrease the air pressure value on the
LCD Air Pressure Display until your desired pressure is reached.
NOTE: Check your car’s standard tire pressure before you set your desired pressure.
The standard tire pressure is usually displayed in the vehicle user manual, the label next
to the cab door (near the B pillar), the drawer next to the driver's seat, the fuel door, etc.
Step 3: Remove the dust cap from the tire valve. Carefully remove the air hose from
Jump Starter and connect it securely onto the tire valve, then press down the handle to
fix the air hose. Once attached, your tire pressure will be displayed on the LCD Air
Pressure Display.
NOTE: The high temperature will increase the pressure of the tire, so please inflate
when the tire is cold.

10
Step 4: Turn the ON/OFF Button on to start the air compressor and inflate the tire. Once
the pre-set pressure has been met the device will automatically shut itself off. Then
please turn the ON/OFF Button off to shut the device completely, disconnect the air hose
and replace the dust cap you have taken off.
NOTE: To extend the service life, do not inflate for more than 8 minutes at any one time.
If using for extended periods, after inflating for 8 minutes, please let the device rest for 5
minutes allowing for it to cool down.

11
LED Indicator Troubleshooting when Starting Vehicle
Insert the plug of the
smart clamps completely
into the jump starter
The red light flashing and
sound an long alarm
The red / green light
flashing alternately
Low power of the jump
starter
Ready to work
Please check the
emergency power supply
or fully charge it
Connect the smart clamp
to the dead battery
The red light is always on
and sound an long alarm
The green light is always
on
The smart clamp is
reversely connected
Please check whether the
clamp is reversely
connected
The smart clamp is short-
circuited Please check
whether the red and black
clamps together connect
or connect both cable
clamps to the same piece
of metal
Please disconnect it from
the car battery and jump
starter, then wait for at
least 20 seconds before
reconnecting
Work status Continue to the next step
The green light is always
on
The red light flashing and
sound an long alarm
Fail to start the vehicle in
30s
Please disconnect it from
the car battery and jump
starter, then wait for at
least 20 seconds before
reconnecting
Start the vehicle
The red light is always on
and sound a short alarm
The red light is always on
and sound an long alarm
Starting current of the
vehicle is too large
Start the dead battery
successfully, enter
anti-recharge protection
state
Please disconnect it from
the car battery and jump
starter, then wait for at
least 20 seconds before
reconnecting
Please remove the
battery clamp from the
car battery and the jump
starter within 30 seconds
STEP LED INDICATOR SITUATIONS SUGGESTION

12
IMPORTANT SAFETY INFORMATION
WARNING: Read all instructions and warnings prior to using this product.
Improper use of this product may result in product damage, excess heat, toxic
fumes, fire or explosion, for which Corporation is not responsible.
• Always read all instructions carefully before using your Jump Starter.
• Do not submerge your Jump Starter in water, or expose it to rain or moisture.
• Never open or disassemble your Jump Starter as it will void your warranty.
• Do not expose your Jump Starter to fire, intense heat, or flammable liquids.
• Only charge the product at temperatures between -20℃~+75℃
• Keep away from and out of reach of children.
• Do not insert foreign objects into ANY inputs or outputs.
• Do not allow the metal teeth of the red clamp to touch the metal teeth of the black
clamp when connected to your Jump Starter.
• Do not connect the black clamp to the vehicle battery’s positive(+) terminal when
connected to your Jump Starter. Do not connect the red clamp to the vehicle battery’s
negative(-) terminal when connected to your Jump Starter.
• Do not open your Jump Starter to replace the internal battery. No user-replace- able
parts are inside your Jump Starter.
• Always disconnect the jump start cables from your Jump Starter after use and store
separately.
• For protecting this unit, make sure the battery capacity of jump starter is above 75%
before jumping start your car.
• Check the power of the product at least every three months, and charge the product in
time.

13
KickAss constantly updates
frequently asked questions,
troubleshooting, videos and
specifications, please visit:
kickassproducts.com.au
for the most up to date
information.
NEED HELP?
