Kidde VM-REMICA Assembly instructions

P/N 3101795-EN • REV 02 • ISS 11JAN16 1 / 4
VM-REMICA Remote Paging
Microphone Installation Sheet
Description
The VM-REMICA provides remote paging capability throughout a
building or campus. Each VM-REMICA has two inputs for connecting
other remote microphone units. The paging circuit supports up to
63 interconnected remote paging stations.
Installation
WARNING: Electrocution hazard. To avoid personal injury or death
from electrocution, remove all sources of power and allow stored
energy to discharge before installing or removing equipment.
Caution: Circuit boards are sensitive to electrostatic discharge (ESD).
To avoid damage, follow ESD handling procedures.
To install the VM-REMICA:
1.Remove the top retainer bracket on the back of the inner door on
the VM-RLCM remote annunciator cabinet. See Figure 1.
2.Loosen the nuts on the bottom retainer bracket.
3.Insert the VM-REMICA behind the bottom retainer bracket, and
then tighten the nuts on the bracket.
4.Reattach the top retainer bracket to the inner door to secure the
top of the VM-REMICA.
5.Set jumpers JP1 and JP2 as follows:
•Position A if AUDIO_OUT is connected to an EAEC
•Position B if AUDIO_OUT is connected to another
VM-REMICA
Wiring
Wire the VM-REMICA as shown in Figure 2.
Notes
•All wiring is supervised and power-limited.
•Test EOL resistors are installed on the remote microphone key
inputs to prevent trouble signals during installation. When
connecting field wiring to a next VM-REMICA, remove the resistors
from pins 12 and 13, and 16 and 17 on TB1.
•Remote microphones cannot be cascaded more than six deep on
a single circuit path.
•Install a 1.8 kΩ EOLR when key in is not used.
Testing
Note: Additional hardware may be required to adjust the microphone.
To adjust the microphone:
1.After the system amplifiers are properly balanced, press the push-
to-talk switch on the microphone. If you get feedback through the
system speakers, adjust the gain on the VM-REMICA until the
feedback is eliminated. See Figure 1 for the location of the gain
adjustment potentiometer.
Specifications
Voltage
21 to 27 VDC
Current
52 mA
Wiring
Type
Audio out
Key out
Resistance
Capacitance
14 to 18 AWG (1.0 to 2.5 mm²) max.,
shielded twisted-pair, in conduit
14 to 18 AWG (1.0 to 2.5 mm²) max.,
twisted-pair, in conduit
210 Ω max.
1 µF
Audio Output
1 VRMS at 400 to 4,000 Hz (4 kHz)
Trouble relay
Current
UL rating
1 A at 30 VDC resistive
Common
Operating environment
Temperature
Relative humidity
32 to 120°F (0 to 49°C)
0 to 93% noncondensing
Regulatory information
Environmental
class
UL: Indoor dry

2 / 4 P/N 3101795-EN • REV 02 • ISS 11JAN16
Figure 1: Installing the VM-REMICA
1.Remote annunciator cabinet inner door
2.Top retainer bracket
3.Bottom retainer bracket
4.Gain adjustment potentiometer
JP2
JP1
J1
P3 P4
B
A
B
A
1
2
3
4
B
A
B
A
VM-REMICA
JP2
TB1
JP1

P/N 3101795-EN • REV 02 • ISS 11JAN16 3 / 4
Figure 2: Wiring the VM-REMICA
Legend 1. Aux power 2 4. SLC out
2. Aux power 1 5. REMICA key in
3. SLC in 6. REMICA audio in
Contact information
For contact information, see www.kiddelifesafety.com.
© 2016 Walter Kidde Portable Equipment, Inc. All rights reserved.
+ + - -
8 7
4 3 2 1
47 kΩ
CT1
VM-REMICA
AUDIO
DATA
KEY AUDIO
REMOTE MIC
AUX OUT AUX IN
VM-CPU
NETWORK AUDIO AUDIO AUDIO AUDIO
OUTIN
+ -
B B
A INA OUTBINBOUT
+ - + - + - + -
AB
RS-485
+- +-
RS-485R
X
1
A A
+ -
T
X
1
T S
1
R
O
M
1
C
BUS BUS
+ + - -
8 7
4 3 2 1
47 kΩ
CT1
VM-REMICA
1.8 kΩ
+ + - -
8 7
4 3 2 1
47 kΩ
CT1
VM-REMICA
1.8 kΩ
N.C.
EAEC
JP2
JP1
J1
P3 P4
B A
B A
TB1
JP2
JP1
J1
P3 P4
B A
B A
TB1
JP2
JP1
J1
P3 P4
B A
B A
TB1
1 1
1
22
2
3 3
3
4 4
4
5
5
6
6
+ +
+
+ +
+
- -
-
- -
-

4 / 4 P/N 3101795-EN • REV 02 • ISS 11JAN16
