Kidzone Lamborghini Huracan Performante Spyder Ride... User manual

Licensed Lamborghini Huracan Performante Spyder Ride On
Owner’s Manual
060-ROT-13L
*Product appearance and colors may vary from the photo.
www.kidzonetoys.com
This product should only be assembled by an adult.
Children can be harmed by small parts, sharp edges
and points or by electrical items. Care should be taken
when unpacking and assembling the vehicle.
WARNING

This owner’s manual contains important safety, performance, and mainte-
nance information.
Read the manual before allowing your child to ride on the product.
Keep this manual for future reference.
Hello !
Welcome to Kidzone’s world of ride-ons where fun and adventure
await! Little ones have a blast riding our toys at home, in the park, or on
the sidewalk.
At Kidzone, our goal is to make playtime more fun for kiddos, while
ensuring comfort and safety. Our ride-ons help create joyful moments
for the entire family that’ll turn into forever memories!
ATTENTION

Table of Contents
04
06
07
08
13
19
20
22
14
16
18
Safety Instruction
Product Specication
Parts and Accessories
Assembly Instruction
User’s Instruction
Care and Maintenance
Troubleshooting
Warrenty Information
User’s Instruction
Control Panel
Remote Control
Charging
User’s Instruction
User’s Instruction

4
Safety Instruction
When using electrical product, basic safety precaution should always be followed including the following:
Failure to follow the safety instructions may result in property damage, serious injury or death.
DISCLAIMER
• Manufacturer and seller expressly disclaim any and all liability for personal injury, property damage or
losses, whether direct, indirect, or incidental, resulting from the incorrect attachment, improper use,
BASIC SAFETY
• This product is only designed to be used by children age 37 - 72 months.
• Do not exceed the maximum weight capacity of 66 lb / 30 kg.
•
Adult and/or supervisors must instruct the user all common safety rules and safe practice.
•
•
•
•
• Never leave children unattended with the ride-on toy. Close supervision is necessary when your
children is using the product.
This product should be operate on a at and smooth surface. Do not use this product in any slippery
conditions including rain, snow, and ice, or at any potential dangerous places.
To reduce the risk of injury, adult supervision is required. Never use in roadways, near motor vehicles,
on or near steep inclines or steps, swimming pools or other bodies of water; always wear shoes, and
never allow more than 1 rider.
RISK OF FIRE. Do not bypass. Replace only with original size and type.
Do not use this product as a trac tool.
• If necessary, adult and/or supervisors should be responsible for setting up gate and barriers to ensure
a safe environment for child rider.
• Be aware and alert children that hands, legs, hair, clothings, and loose items can potentially get
caught in moving parts. Avoid placing body parts on moving parts and do not wear loose clothing
while using the ride-on toy.
• Avoid using this product in tight environment to prevent damage to the product or injury to the user.
• This product does not equip with brakes. Do not use this product in areas that requires active braking
to prevent possible rolls, crashes, or bodily injury.
• Do not use this product in the dark. Only operate this product during daytime or in a well lit area.
• Avoid continuously hitting into obstacle to prevent overheating or damaging the motor. Drive away
or remove obstacle as soon as possible.
• For your child’s safety, make sure the seatbelt is securely fasten and the rider is wearing personal
protective equipment, such as helmet, when operating this product.
W
E
A
R
P
R
O
T
E
C
T
I
V
E
E
Q
U
I
P
M
E
N
T
W
H
E
N
U
S
I
N
G
Correct Fitting
Make sure the helmet
covers your forehead.
Incorrect Fitting
Forhead is exposed and
vulerable to injury.
WARNING

ver. 05312023
5
CELL BATTERY AND RECHARGEABLE BATTERY HANDLING
• Do not mix old and new batteries.
• Do not mix alkaline, standard (carbon-zinc), or re-chargeable batteries.
• Permanent damage to the battery may occur if it is completely drained. Do not let the battery to drain
completely.
• On average, you will need to charge the battery for 8 - 12 hours. Do not charge the battery for more
than 20 hours. Failure to charge the battery as directed could cause permanent damage to the battery
and void the warranty.
• Only an adult who has read and underrstands the safety instruction should handle, charge, and
recharge the battery.
• Disconnect the battery if not used for a long period of time.
Failure to follow these instruction may result in permanent damage to the product or parts.
CHOCKING HAZARD, ASSEMBLY WARNING
• This product contains small parts before assembly. Keep children away when assembling the
ride-on toy. The assembly should only performed by an adult.
• Remove and dispose all protective materials, plastic bag, and packaging before assembly.
• This product should not be used by children under the age of 36 months old.
ELECTRIC SHOCK, FIRE HAZARD, FLAMMABLE AND EXPLOSIVE WARNING
• To protect against electrical shock, do not let cord, charger, transformer, battery or the product
contact with water or other liquid.
• Do not drive the vehicle into any puddle or contact with any liquid to prevent electrical shock.
• Do not change, modify, or add any electrical wiring on the product. Alternations could potentially
• Only use charger and battery provided or recommended by the manufacturer. Using the wrong type
• Check the battery, charger, and connectors for any sign of excessive wear or damage each time you
charge the battery. Do not use the charger or the battery if damages are present. Change and replace
damage part before use.
• Do not lift or carry the battery by the wires or charger. You might damage the wires and case electric
shock or re.
•
CORROSIVE CHEMICAL, PRODUCT MATERIAL WARNING
• Contact or exposure to battery leakage may cause serious injury. If contant or exposure occurs to the
skin or in the eyes, or if the chemical is swallowed, call medical emergency immediately.
• Battery posts, terminals, and related accessories contain lead and lead compounds which are toxic
and corrosive. Never open the battery.
Failure to follow these instruction may result in bodily harm, serious injury, or death.
cause shirt circuit, a re, or irreversible damage to the electrical system.
of battery or charger could cause a re and potentially property damage and serious injury.
Do not charge more than 20 hours. You might over heat the battery and cause damage or a re.
WARNING
CAUTION

6
Model no.
Motor
060-ROT-13L
Battery 12 V*1
12V*5
120V AC, 0.25 A, 60 Hz
Charger output
Charger input
DC 12 V
Battery Charge Time 8 - 12 hours
Dimension 46.7” x 24.8” x 18.9” (118.5 cm x 63 cm x 48 cm)
Speed 0.6-1.9 mph ( 1-3.1km/h )
Suitable Age 37-72 months
Maximum User Weight 66 lb / 30 kg

ver. 05312023
7
Parts and Accessories
1. Ø10 Washer
6x
2. 3. Machine screw & Nut
(Pre-installed on the steering wheel)
1 set
M10 Nut
4x
A. Wheel
4x
D. Mirror
1x Set
G. Rear Spoiler
1x
B. Windshield
1x
E. Seat
1x
H. Remote Control
1x
C. Wheel Cover
4x
F. Steering Wheel
1x
I. Charger
1x

8
Assembly Instruction
• Slide the wheels (A) into the front axle, follow by a Ø10 washer (1) and tighten with a M10 nut (2).
• Put the wheel cover (C) on the wheel.
• Repeat the same step for the other side and the back axle of the vehicle
Tools required (not included)
1
(A) Wheel
(C) Wheel Cover
(1) Ø10 Washer
(2) M10 Nut
This product should only be assembled by an adult.
Children can be harmed by small parts, sharp edges and points or by electrical
items. Care should be taken when unpacking and assembling the vehicle.
WARNING

ver. 05312023
9
Assembly Instruction
• Connect the electrical connectors from the steering wheel (F) to that of the car.
• Insert the steering wheel over the steering column.
• Align the holes on the steering wheel, then screw in the machine screw and tighten with the nut.
(Note: The machine screw and nut pre-installed on the steering wheel)
• Align and install the rear spoler (G) into the slots on the back of the vehicle body.
2(F) Steering Wheel
(G) Rear Spoiler

10
Assembly Instruction
•
• Insert the mirror (D) to the side of the vehicle.
• Repeat the same step for the other side.
3(B) Windshield
(D) Mirror

ver. 05312023
11
Assembly Instruction
This product is packed with the battery disconnected.
Connect the battery before use.
• Connect the electrical wire from the car to the battery.
4
ATTENTION

12
Assembly Instruction
5
• Attach the seat (E) to the vehicle.
• Fit the tabs on the seat into the groove on the vehicle body, and lock the seat in place.
(E) Seat

ver. 05312023
13
User’s Instruction
Do not change direction until the vehicle comes to a complete stop.
Sudden change in direction may result in permanent damage to the motor.
Control the vehicle
Control Panel
Control the functions of the car. (See page 14 for detail instruction)
Shift Lever
Push / Pull the lever to choose the vehicle forward and backward direction.
Horn Button
Press the button to horn.
Foot Pedal
Press the foot pedal to move the vehicle, release the pedal to stop.
Horn Button
Control Panel
Foot Pedal
Shift Lever
CAUTION

14
User’s Instruction (Control Panel)
Power Button
High Speed ButtonNext Track / Volume +
Previous Track / Volume −
Low Speed ButtonPlay Button
Bluetooth Connection
Flash drive port Charging Port
Power Indicator
Control Panel
Power Button
Press and hold the power button for 3 seconds to turn ON or OFF the vehicle.
High Speed Button
Press the high speed button to select high speed mode.
Low Speed Button
Press the low speed button to select low speed mode.
Bluetooth Connection Button
Press the bluetooth connection button to connect your mobile device to the vehicle via bluetooth.
To connect your mobile device to the vehicle, turn on the Bluetooth and select "Kidzone Ride-On".
You can hear a voice message of connected successfully after pairing. Music can be played from the
vehicle speaker according to the user preferences.
Next Track / Volume + Button
Press the button to select the next music track.
Press and hold the button to increase the volume.
Play Button
Press the play button to play or pause the music.
Previous Track / Volume −Button
Press the button to select the previous music track.
Press and hold the button to decrease the volume.
Light Button
Press the button to turn ON or OFF the light.
Light Button Radio Button

ver. 05312023
15
User Instruction (Control Panel)
Radio Button
Press the radio button to choose FM radio.
Press and hold 2 seconds, you can hear beep then it will start search the channels, you can
select the channel by press the next track / previous track button after search completed.
Allow the vehicle to play MP3 format les from your ash drive device.
Flash drive port
Power Indicator
Indicator shows the estimate power level of the battery.
Charging Port
Plug the charging cable to the charging port to charge the battery. (See page 18)

16
User Instruction (Remote Control)
Using the remote control
The remote control should only be used by an adult.
Pairing the remote control
• Insert batteries into the remote control. (see page 17)
•
• Turn on the power of the vehicle, the indicator should change to solid light.
If failed to pair, remove and replace the battery from the remote control and repeat the pairing steps.
Control the Vehicle
• Press the directional buttons to move the vehicle.
• Press the “P” button to enable emergency brake. All running function will be disabled once the button is
pressed. Press the “P” button again to enable other functions.
• Press the “S” button to switch between high and low speed
The remote control will goes into power saving mode if not used after 10 seconds.
Forward
Speed Button Speed Indicator
Pairing Button
Turn Left
Reverse Turn Right
Emergency Brake

ver. 05312023
17
User Instruction (Remote Control)
Changing the remote control battery
The remote control requires 2 AAA 1.5v batteries. (not included)
• Remove the cover on the back side of the remote control.
• Replace old batteries with 2 new AAA 1.5v batteries in correct polarity.
• Put the cover back in place and secure with the screw.
The battery should only be changed by an adult.
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or re-chargeable batteries.
WARNING

18
User Instruction (Charging)
Charging the battery
1. Connect the charger to the charging port.
2. Plug the charger into a wall outlet. The battery will start charging.
•
•
The vehicle must be OFF when charging.
The indicator on charger turn red when charging, and turn green after charging completed.
• Recharge the battery if the vehicle operates slowly.
• DO NOT operate the vehicle when charging.
NOTE:
• Charge the battery for 4 - 6 hours before the initial use.
• Damage to the battery may occur if it is completely drained.
• Charge the battery for about 8 - 12 hours.
• Do not charge the battery for more than 20 hours.
• Charge the battery at least once a month even if not operating the vehicle for a long time to
maximize the battery life.
• Do not charge or store the battery upside down.
•
The battery should only be charged by an adult.
WARNING

ver. 05312023
19
Care and Maintenance
• Check the product regularly and make sure there is no missing or loose parts. Re-tighten any loose parts
if necessary.
• Make sure there is no cracked or broken plastic parts.
• Store the product away from heat source when not using, cover it with a tarp and away from wet
weather.
•
• Clean the vehicle with a cloth. Use a non-wax furniture polish to restore shine to plastic parts. Do not use
abrasive cleaner.
• Do not wash the product with a hose or immerse any parts in water or other liquid.
• Occasionally use lightweight oil to lubricate moving parts.
• Regularly charge the battery to prolong the battery life.
• Do not store the product near heat source, such as stoves and heaters. Plastic parts may melt under high
temperature.

20
Troubleshooting
Problem Possible Reason Solution
Vehicle does not move
Low Battery Fully charge the battery
Fuse Protection Fuse will reset automatically in
about 10 seconds
Disconnected / Badly connected
battery Reconnect the battery
Failed battery / engine Contact Customer Service
Vehicle does not run very long
Low Battery Fully charge the battery
Old / Damaged Battery Replace battery if necessary
Vehicle runs very slow
Low Battery Fully charge the battery
Old Battery Replace battery if necessary
Vehicle is overloaded Make sure user’s weight is under
66 lb / 30 kg
Vehicle is being used in harsh
environment
Avoid using the vehicle in harsh
environment
