Kimball Footprint Radius ProfileUndersurface Storage User manual

Ass mbly Instructions
Footprint®
Proper product installation, in accordance with these instructions, is the responsibilit of the installing agent.
If ou have an questions concerning these instructions, please call Kimball Office Customer Service.
Part No. 1741536 Revisio C-08
Page 1 of 6
Square and Radius Profile
Undersurface Storage
Tools R quir d
■evel ■Electric Drill with Phillips Bit
■Tape Measure or Ruler ■3⁄16" Nut Driver or Socket
Packag Cont nts
■Undersurface Unit ■Plastic Glide Hole Plugs
■#8 x 3⁄4" Panhead (hinged door and open
Phillips Wood Screws bookcase units only)
Installation
Note: These instructions rovide the basic information
for installing Foot rint radius and square rofile
undersurface storage units. (Figure A). The to s of the
undersurface units are re-drilled. Worksurfaces are NOT
re-drilled. Installation of radius rofile and square rofile
units is similar exce t for the amount of recess from the edge
of the worksurface outlined in Ste 2.
Figur A
Square Profile
(File/File shown)
Radius Profile
(File/File shown)
Figure B:
Box Drawer
Suspension
“A”
“B”
1. Remove all drawers from undersurface storage unit.
Kimball Office utilizes three types of drawer suspension
systems: box drawer suspension, file drawer suspension
and lateral file drawer suspension. Follow the steps below
to properly remove both types of drawers.
Box Draw r R moval (Figur B)
■Pull the drawer to fully opened position.
■Remove the shipping screw “A” from both left and right
metal suspensions.
■Simultaneously press the nylon release tabs “B” inward
towards the drawer and lift the drawer off slides.
Fil Draw r R moval (Figur C)
■Extend the file drawer to its full extension.
■ocate the drawer slide release tab, in the approximate
location shown, on each side of the drawer.
■Press tabs in and pull drawer straight out until slide
drawer members disengage from cabinet members.
Figure C:
File Drawer
Suspension Release Tab
Lat ral Fil Draw r R moval (Figur D)
■Pull the drawer to fully opened position.
■Remove the shipping screw “A” from both left and right
metal suspensions.
■Simultaneously press the nylon release tabs “B” inward
towards the drawer and lift the drawer off slides.
“B”
“A”
Figure D:
Lateral File Drawer
Suspension
Ass mbly Instructions
Footprint
Proper product installation, in accordance with these instructions, is the responsibilit of the installing agent.
If ou have an questions concerning these instructions, please call Kimball Office Customer Service.
Part No. 1741536 Revisio C-08
Page 2 of 6
Installation (continu d)
2. Slide unit into position under worksurface. Using a 3⁄16" nut
driver or socket, adjust glides in base of cabinet to snug the
unit against the worksurface. For RADIUS profile units,
recess the face of the lock rail 1⁄8" from the front edge of the
worksurface. (Figure E). For SQUARE profile units, recess
the front of the storage chassis ⁷⁄₈" from the front edge of
the worksurface. (Figure E).
3. Attach unit to worksurface using #8 x 3⁄4" wood screws (pro-
vided) inserted through 3⁄16" diameter holes in metal stretch-
er rails. (Figure F). evel the installed unit either by placing
the level on top of the worksurface or inside the bottom of
the installed unit. evel front to back, then side to side using
a3⁄16" nut driver or socket to adjust glides. (Figure F). When
unit is level make sure all glides are snug to the floor.
Note: In cases of uneven floors, glides may not be able to
adjust enough to level the unit and be snug against the floor.
A longer glide must be used (not rovided). Contact Customer
Service for service art model number.
Figur E
Figur F
Front of Square
profile end panel
(drawers removed)
#8 x 3⁄4"
Wood Screws
WorksurfaceWorksurface
Front of Radius
profile lock panel
(drawers removed)
1⁄8"7⁄8"
Glides
Worksurface
Ass mbly Instructions
Footprint
Proper product installation, in accordance with these instructions, is the responsibilit of the installing agent.
If ou have an questions concerning these instructions, please call Kimball Office Customer Service.
Part No. 1741536 Revisio C-08
Page 3 of 6
Installation (continu d)
4. When unit is level, follow the steps below to properly replace
box drawer suspension, file drawer suspension, and lateral
file drawer suspension.
Box Draw r R plac m nt (Figur G)
■Extend drawer slides.
■Engage rear of rail “C” and begin lowering the
drawer.
■ower the drawer until nylon tabs “B” enter holes in rail.
isten for a click as the drawer locks into slides.
Fil Draw r R plac m nt (Figur H)
■Extend slide cabinet members.
■Make sure chrome ball bearing member is also forward.
■Carefully align slide drawer members with cabinet
members and gently push drawer closed. Check for
proper alignment by inspecting drawer front margins
for spacing and squareness.
Figure H:
File Drawer
Suspension
Figure G:
Box Drawer
Suspension
“C”
“B”
Release Tab
Lat ral Fil Draw r R plac m nt (Figur I)
■Extend drawer slides half way.
■Place the drawer on slides and hook drawer rails
beneath rear rail hooks “C”.
■Click release tabs into place. “C”
Figure I:
Lateral File Drawer
Suspension
5. If necessary, adjust drawer fronts. oosen, do not remove,
screws on drawer slides or screws inside drawer front to
achieve proper alignment. Re-tighten all screws. (Figure J).
6. Install lock core in unit. Reference Footprint Storage and
Metal Filing assembly instruction included with the lock
core.
oosen screws
for adjustment
oosen screws
for adjustment
Figur J
Ass mbly Instructions
Footprint
Proper product installation, in accordance with these instructions, is the responsibilit of the installing agent.
If ou have an questions concerning these instructions, please call Kimball Office Customer Service.
Part No. 1741536 Revisio C-08
Page 4 of 6
Installation (continu d)
7. To install hinged door unit, slide unit into position under
the worksurface. Follow recess guidelines as described in
Step 2. Attach unit to worksurface using #8 x 3⁄4" wood
screws provided. Use pre-drilled holes as a guide. evel unit
as described in Step 3. Make sure all glides are snug to the
floor. Install plastic glide hole plugs and lock core in unit.
When installation is complete, it may be necessary to adjust
the doors for proper alignment and consistent reveal.
(Figure K).
8. Figure shows door hinge detail.
9. Figure M shows the doors out of alignment vertically
(no gap between doors). To correctly align, turn screw “A”
(see hinge detail) clockwise to decrease margin or
counter-clockwise to increase margin. There should be a
slight gap (approximately 1⁄4") between doors.
10. Figure N shows the doors out of alignment horizontally.
To correctly align, slightly loosen screw “B” (see hinge
detail). Reposition door up or down to properly align,
then re-tighten screw “B”.
Note: Horizontal misalignment can also occur if unit is
not level.
11. Figure O shows the doors out of alignment with side of
unit. To correctly align, slightly loosen screw “C” (see hinge
detail). Reposition door to properly align, then re-tighten
screw “C”.
Figur L
Figur s M, N, and O
Figur K
Door in open
position Screw “A”
Inside panel
Hinged Door Unit
(Square profile shown)
Door
End
Panel
Dislodge Tab
Screw “B”
Screw “C”
Screw “B”
Door
Door
Door
Door
Hinge Detail
Figure M
No gap between doors. Gap
should be approximately 1⁄4".
Figure N
Out of alignment
horizontally
Figure O
Out of alignment
to chassis
Ass mbly Instructions
Footprint
Proper product installation, in accordance with these instructions, is the responsibilit of the installing agent.
If ou have an questions concerning these instructions, please call Kimball Office Customer Service.
Part No. 1741536 Revisio C-08
Page 5 of 6
Installation (continu d)
12. To install open bookcase, slide unit into position under
worksurface. Adjust the glides to snug the unit against the
worksurface. Follow recess guidelines for square profile
units as described in Step 2. Attach unit to worksurface
using #8 x 3⁄4" wood screws provided. Use pre-drilled holes
as a guide. evel unit as described in Step 3. Make sure all
glides are snug to the floor. Install plastic glide hole plugs.
(Figure P).
13. All drawers ship standard with filing hardware. Hardware
is changeable to accommodate different filing needs.
(Figure Q).
■oosen or remove screws in drawer side file bar.
■Reposition file bar(s) into desired notch(es).
■Re-insert or tighten screws.
Figur P
Figur Q
Open Bookcase
(Square profile shown)
16" Wide
Radius Pedestal
30" Wide
ateral File
18" Wide
Square Pedestal
36" Wide
ateral File
Ass mbly Instructions
Footprint
Pri ted i U.S.A. © 2008 Kimball I ter atio al, I c. T 800.482.1818 F 812.482.8300
Proper product installation, in accordance with these instructions, is the responsibilit of the installing agent.
If ou have an questions concerning these instructions, please call Kimball Office Customer Service.
Part No. 1741536 Revisio C-08
Page 6 of 6
Installation (continu d)
14. Note: Due to defacing of the units, ganging is NOT
recommended if future reconfigurations of the units are
antici ated.
When ganging, install and level first unit. Then slide next
unit into position. Use C-clamp(s) to help align the units.
Make sure side panels are flush with no gaps. Attach
pedestals to worksurface with #8 x 3⁄4" wood screws
provided. Pre-bore through the side panel of one unit and
attach it to the other with two (2) #8 x 11⁄4" wood screws
(not provided). evel both units and snug all glides.
(Figure R).
Wh n sid of p d stal will b xpos d:
■Specify pedestal reveal strip separately to fill in the space
between top of pedestal and bottom of worksurface.
■The reveal strip must be attached to the pedestal before
the pedestal is installed under the worksurface.
■To mount the pedestal reveal strip, the horizontal
spacers on top of the pedestal will need to be modified
on the exposed end of the pedestal.
■The pedestal reveal strip is shipped with pre-attached
double-sided adhesive tape. Remove the protective
backing from the adhesive and attach the reveal strip
to the prepared space on top of the pedestal.
■Make sure the reveal strip is centered front to back
and flush with the edge of the pedestal. Press firmly
to ensure good adhesion. (Figure S).
Figur R
Figur S
No gap
#8 x 11⁄4"
Wood Screws
C-clamp
Attach
Reveal Strip
#8 x 3⁄4"
Wood Screws

This manual suits for next models

1

Popular Storage manuals by other brands

LaCie LaCie Ethernet Big Disk manual

LaCie

LaCie LaCie Ethernet Big Disk manual

Alice's Home TOBIAS IKSCANDIOUL6 manual

Alice's Home

Alice's Home TOBIAS IKSCANDIOUL6 manual

PEP Modular Computers VMEM-F1 user manual

PEP Modular Computers

PEP Modular Computers VMEM-F1 user manual

HP StorageWorks DAT320 USB Start here

HP

HP StorageWorks DAT320 USB Start here

storXtreme Network Adapter SX-18D user manual

storXtreme

storXtreme Network Adapter SX-18D user manual

Omron ZS-DSU user manual

Omron

Omron ZS-DSU user manual

Broadcom BroadNAS quick start guide

Broadcom

Broadcom BroadNAS quick start guide

Synology RS1221+ Hardware installation guide

Synology

Synology RS1221+ Hardware installation guide

UGREEN CM352 instruction manual

UGREEN

UGREEN CM352 instruction manual

SanDisk Connect quick start guide

SanDisk

SanDisk Connect quick start guide

CEMO FMplus US operating instructions

CEMO

CEMO FMplus US operating instructions

Fujitsu ETERNUS LT140 user guide

Fujitsu

Fujitsu ETERNUS LT140 user guide

Tandberg Data StorageLoader DLT VS160 Quick installation guide

Tandberg Data

Tandberg Data StorageLoader DLT VS160 Quick installation guide

Huawei LUNA2000-200KWH-2H1 Smart String ESS Maintenance manual

Huawei

Huawei LUNA2000-200KWH-2H1 Smart String ESS Maintenance manual

Medion E89617 quick start guide

Medion

Medion E89617 quick start guide

Cavalry CACE Series user manual

Cavalry

Cavalry CACE Series user manual

Seagate Momentus 7200.1 SATA product manual

Seagate

Seagate Momentus 7200.1 SATA product manual

LaCie rugged XL datasheet

LaCie

LaCie rugged XL datasheet

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
