Service Manual
Technical Information 1
1. Summary
Part Ⅰ:Technical Information
Models
KPE07B2D KPA07B2D KPE09B2D KPA09B2D KPE12B2D KPA12B2D KPE15B2D KPA15B2D KPE07B2P KPA07B2P
KPE09B2P KPA09B2P KPE12B2P KPA12B2P KPE15B2P KPA15B2P

Service Manual
Technical Information
2
2. Specications
Parameter Unit Value
Model KPA07B2D KPE15B2D
Product Code CC060038000_X11438 CC060038200_X11438
Power Supply
Rated Voltage V~ 230/208 230/208
Rated Frequency Hz 60 60
Phases 1 1
Cooling Capacity Btu/h 7200/7000 14500/14200
Heating Capacity Btu/h 6000/5800 /
Cooling Power Input W 550/535 1390/1365
Heating Power Input W 485/470 /
Cooling Power Current A 2.9/2.7 6.2/6.7
Heating Power Current A 2.6/2.4 /
Electric Heating Power Input W 3450/2820 3450/2820
Electric Heating Power Current A 15.0/13.6 15.0/13.6
Rated Input W 774 1860
Rated Current A 3.8 10.2
Air Flow Volume(H/M/L) CFM 312/-/282 341/-/306
Dehumidifying Volume Pint/h 1.69 3.17
EER (Btu/h)/W 13.0/13.0 10.4/10.4
COP W/W 3.6/3.6 /
Application Area yd212-19.1 25.1-37.1
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Permissible Excessive Operating Pressure for the
Discharge Side MPa 4.3 4.3
Permissible Excessive Operating Pressure for the
Suction Side MPa 2.5 2.5
Dimension (WXHXD) inch 42X16X21 1/2 42X16X21 1/2
Dimension of Carton Box (LXWXH) inch 45X25 5/16X17 7/8 45X25 9/32X17 7/8
Dimension of Package (LXWXH) inch 45 3/64X25 13/32X18 1/2 45 3/64X25 13/32X18 1/2
Net Weight lb 108 118
Gross Weight lb 132.3 142.2
Refrigerant R410A R410A
Refrigerant Charge oz 33.9 35.27
Indoor Side
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) inch Φ4 3/4X27 51/64 Φ4 3/4X27 51/64
Fan Motor Speed(H/M/L) r/min 990/-/880 1130/-/970
Output of Fan Motor W 18 23
Fan Motor RLA A 0.10 0.2
Fan Motor Capacitor μF 1 1
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32 Φ9/32
Row-n Gap inch 3-1/16 3-1/16
Coil Length (LXDXW) inch 27 1/2X9 1/2X1 1/2 27 1/2X9 1/2X1 1/2
Swing Motor Model / /
Output of Swing Motor W / /
Fuse A 3.15 3.15
Sound Pressure Level (H/M/L) dB (A) 50/-/48 54/-/51
Sound Power Level (H/M/L) dB (A) 60/-/58 64/-/61

Service Manual
Technical Information 3
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Outdoor
Side
Compressor Manufacturer/Trademark RECHI PRECISION CO.,LTD RECHI PRECISION CO.,LTD
Compressor Model 39B142GD&5DKZ 44B342UL-FEKD
Compressor Oil NMOC Ze-Gles RB68EP NMOC Ze-Gles RB68EP or
equivalent
Compressor Type Rotary Rotary
L.R.A. A 13 28.9
Compressor RLA A 2.5 5.9
Compressor Power Input W 470 1330
Overload Protector Internal Internal
Throttling Method Capillary Capillary
Operation Temp ºF 61-86 61-86
Ambient Temp (Cooling) ºF 55-83 55-83
Ambient Temp (Heating) ºF ≤75 ≤75
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32 Φ9/32
Rows-n Gap inch 3-3/64 3-3/64
Coil Length (LXDXW) inch 30 21/32X13 1/2X1 1/2 30 21/32X13 1/2X1 1/2
Fan Motor Speed rpm 990/-/880 1130/-/970
Output of Fan Motor W 18 23
Fan Motor RLA A 0.1 0.2
Fan Motor Capacitor μF 2 2.5
Air Flow Volume of Outdoor Side CFM 471 565
Fan Type Axial-ow Axial-ow
Fan Diameter inch Φ13 47/64 Φ13 47/64
Sound Pressure Level (H/M/L) dB (A) 63/-/61 66/-/63
Sound Power Level (H/M/L) dB (A) 73/-/71 76/-/73
Defrosting Method / /
Note: The connection pipe applies metric diameter.

Service Manual
Technical Information
4
Parameter Unit Value
Model KPA07B2P KPE07B2P
Product Code CC060040000_X11438 CC060039900_X11438
Power Supply
Rated Voltage V~ 265 265
Rated Frequency Hz 60 60
Phases 1 1
Cooling Capacity Btu/h 7200 7200
Heating Capacity Btu/h 6000 /
Cooling Power Input W 550 550
Heating Power Input W 485 /
Cooling Power Current A 2.4 2.4
Heating Power Current A 2.2 /
Electric Heating Power Input W 3450 3450
Electric Heating Power Current A 13.1 13.1
Rated Input W 774 774
Rated Current A 2.9 2.9
Air Flow Volume(H/M/L) CFM 530/-/480 312/-/282
Dehumidifying Volume Pint/h 1.69 1.69
EER (Btu/h)/W 13 13
COP W/W 3.6 /
Application Area yd212-19.1 12-19.1
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Permissible Excessive Operating Pressure for the
Discharge Side MPa 4.3 4.3
Permissible Excessive Operating Pressure for the
Suction Side MPa 2.5 2.5
Dimension (WXHXD) inch 42X16X21 1/2 42X16X21 1/2
Dimension of Carton Box (LXWXH) inch 45X25 9/32X17 7/8 45X25 9/32X17 7/8
Dimension of Package (LXWXH) inch 45 3/64X25 13/32X18 1/2 45 3/64X25 13/32X18 1/2
Net Weight lb 108.0 103.6
Gross Weight lb 132.3 127.9
Refrigerant R410A R410A
Refrigerant Charge oz 33.9 22.9
Indoor Side
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) inch Φ4 3/4X27 51/64 Φ4 3/4X27 51/64
Fan Motor Speed(H/M/L) r/min 1000/-/890 1000/-/890
Output of Fan Motor W 10 10
Fan Motor RLA A 0.11 0.11
Fan Motor Capacitor μF 1 1
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32 Φ9/32
Row-n Gap inch 3-1/16 3-1/16
Coil Length (LXDXW) inch 27 1/2X9 1/2X1 1/2 27 1/2X9 1/2X1 1/2
Swing Motor Model / /
Output of Swing Motor W / /
Fuse A 3.15 3.15
Sound Pressure Level (H/M/L) dB (A) 50/-/48 50/-/48
Sound Power Level (H/M/L) dB (A) 60/-/58 60/-/58

Service Manual
Technical Information 5
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Outdoor
Side
Compressor Manufacturer/Trademark RECHI PRECISION CO.,LTD RECHI PRECISION CO.,LTD
Compressor Model 39B147GD&5DKZ 39B147GD&5DKZ
Compressor Oil NMOC Ze-Gles RB68EP NMOC Ze-Gles RB68EP
Compressor Type Rotary Rotary
L.R.A. A 12.5 12.5
Compressor RLA A 2.2 2.2
Compressor Power Input W 475 475
Overload Protector Internal UP3-LCB
Throttling Method Capillary Capillary
Operation Temp ºF 61-86 61-86
Ambient Temp (Cooling) ºF 55-83 55-83
Ambient Temp (Heating) ºF ≤75 ≤75
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32 Φ3/16
Rows-n Gap inch 3-3/64 3-1/16
Coil Length (LXDXW) inch 27 33/64X9 3/4X1 1/2 30 45/64X13 1/2X1 11/32
Fan Motor Speed rpm 1000/-/890 1000/-/890
Output of Fan Motor W 10 10
Fan Motor RLA A 0.11 0.11
Fan Motor Capacitor μF 1.5 1.5
Air Flow Volume of Outdoor Side CFM 471 471
Fan Type Axial-ow Axial-ow
Fan Diameter inch Φ13 47/64 Φ13 47/64
Sound Pressure Level (H/M/L) dB (A) 63/-/61 63/-/61
Sound Power Level (H/M/L) dB (A) 73/-/71 73/-/71
Defrosting Method / /
Note: The connection pipe applies metric diameter.

Service Manual
Technical Information
6
Parameter Unit Value
Model KPE09B2D KPE09B2P
Product Code CC060039000_X11438 CC060040300_X11438
Power Supply
Rated Voltage V~ 230/208 265
Rated Frequency Hz 60 60
Phases 1 1
Cooling Capacity Btu/h 9400/9200 9400
Heating Capacity Btu/h / /
Cooling Power Input W 775/760 775
Heating Power Input W / /
Cooling Power Current A 3.7/3.9 3.3
Heating Power Current A / /
Electric Heating Power Input W 3450/2820 3450
Electric Heating Power Current A 15.0/13.6 13.1
Rated Input W 951 951
Rated Current A 5.9 4.2
Air Flow Volume(H/M/L) CFM 330/-/294 330/-/294
Dehumidifying Volume Pint/h 2.11 2.11
EER (Btu/h)/W 12.1/12.1 12.1
COP W/W / /
Application Area yd214.4-21.5 14.4-21.5
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Permissible Excessive Operating Pressure for the
Discharge Side MPa 4.3 4.3
Permissible Excessive Operating Pressure for the
Suction Side MPa 2.5 2.5
Dimension (WXHXD) inch 42X16X21 1/2 42X16X21 1/2
Dimension of Carton Box (LXWXH) inch 45X25 9/32X17 7/8 45X25 9/32X17 7/8
Dimension of Package (LXWXH) inch 45 3/64X25 13/32X18 1/2 45 3/64X25 13/32X18 1/2
Net Weight lb 112.5 113.6
Gross Weight lb 136.7 137.8
Refrigerant R410A R410A
Refrigerant Charge oz 23.6 23.6
Indoor Side
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) inch Φ4 3/4X27 51/64 Φ4 3/4X27 51/64
Fan Motor Speed(H/M/L) r/min 1060/-/940 1060/-/940
Output of Fan Motor W 21 21
Fan Motor RLA A 0.2 0.18
Fan Motor Capacitor μF 1.5 1.5
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32 Φ9/32
Row-n Gap inch 3-1/16 3-1/16
Coil Length (LXDXW) inch 27 1/2X9 1/2X1 1/2 27 1/2X9 1/2X1 1/2
Swing Motor Model / /
Output of Swing Motor W / /
Fuse A 3.15 3.15
Sound Pressure Level (H/M/L) dB (A) 52/-/50 52/-/50
Sound Power Level (H/M/L) dB (A) 62/-/60 62/-/60

Service Manual
Technical Information 7
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Outdoor
Side
Compressor Manufacturer/Trademark RECHI PRECISION CO.,LTD RECHI PRECISION CO.,LTD
Compressor Model 44B202GK&FEKD 44B207GK&FEKD
Compressor Oil NMOC Ze-Gles RB68EP NMOC Ze-Gles RB68EP
Compressor Type Rotary Rotary
L.R.A. A 19.5 13.5
Compressor RLA A 3.5 3
Compressor Power Input W 655 645
Overload Protector Internal Internal
Throttling Method Capillary Capillary
Operation Temp ºF 61-86 61-86
Ambient Temp (Cooling) ºF 55-83 55-83
Ambient Temp (Heating) ºF ≤75 ≤75
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32 Φ3/16
Rows-n Gap inch 3-3/64 3-1/16
Coil Length (LXDXW) inch 30 21/32X13 1/2X1 1/2 27 33/64X9 3/4X1 1/2
Fan Motor Speed rpm 1060/-/940 1060/-/940
Output of Fan Motor W 21 21
Fan Motor RLA A 0.2 0.18
Fan Motor Capacitor μF 2 1.5
Air Flow Volume of Outdoor Side CFM 471 471
Fan Type Axial-ow Axial-ow
Fan Diameter inch Φ13 47/64 Φ13 47/64
Sound Pressure Level (H/M/L) dB (A) 63/-/61 63/-/61
Sound Power Level (H/M/L) dB (A) 73/-/71 73/-/71
Defrosting Method / /
Note: The connection pipe applies metric diameter.

Service Manual
Technical Information
8
Parameter Unit Value
Model KPA09B2P KPA09B2D
Product Code CC060040400_X11438 CC060037700_X11438
Power Supply
Rated Voltage V~ 265 230/208
Rated Frequency Hz 60 60
Phases 1 1
Cooling Capacity Btu/h 9400 9400/9200
Heating Capacity Btu/h 8300 8300/8100
Cooling Power Input W 775 775/760
Heating Power Input W 695 695/675
Cooling Power Current A 3.3 3.7/3.9
Heating Power Current A / 3.4/3.2
Electric Heating Power Input W 3450 3450/2820
Electric Heating Power Current A 13.1 15.0/13.6
Rated Input W 951 951
Rated Current A 4.2 5.9
Air Flow Volume(H/M/L) CFM 330/-/294 330/-/294
Dehumidifying Volume Pint/h 2.11 2.11
EER (Btu/h)/W 12.1 12.1/12.1
COP W/W 3.5 3.5/3.5
Application Area yd214.4-21.5 14.4-21.5
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Permissible Excessive Operating Pressure for the
Discharge Side MPa 4.3 4.3
Permissible Excessive Operating Pressure for the
Suction Side MPa 2.5 2.5
Dimension (WXHXD) inch 42X16X21 1/2 42X16X21 1/2
Dimension of Carton Box (LXWXH) inch 45X25 9/32X17 7/8 45X25 9/32X17 7/8
Dimension of Package (LXWXH) inch 45 3/64X25 13/32X18 1/2 45 3/64X25 13/32X18 1/2
Net Weight lb 116.9 116.9
Gross Weight lb 141.1 141.1
Refrigerant R410A R410A
Refrigerant Charge oz 33.9 33.9
Indoor Side
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) inch Φ4 3/4X27 51/64 Φ4 3/4X27 51/64
Fan Motor Speed(H/M/L) r/min 1060/-/940 1060/-/940
Output of Fan Motor W 21 21
Fan Motor RLA A 0.18 0.2
Fan Motor Capacitor μF 1.5 1.5
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32 Φ9/32
Row-n Gap inch 3-1/16 3-1/16
Coil Length (LXDXW) inch 27 1/2X9 1/2X1 1/2 27 1/2X9 1/2X1 1/2
Swing Motor Model / /
Output of Swing Motor W / /
Fuse A 3.15 3.15
Sound Pressure Level (H/M/L) dB (A) 52/-/50 52/-/50
Sound Power Level (H/M/L) dB (A) 62/-/60 62/-/60

Service Manual
Technical Information 9
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Outdoor
Side
Compressor Manufacturer/Trademark RECHI PRECISION CO.,LTD RECHI PRECISION CO.,LTD
Compressor Model 44B207GK&FEKD 44B202GK&FEKD
Compressor Oil NMOC Ze-Gles RB68EP NMOC Ze-Gles RB68EP
Compressor Type Rotary Rotary
L.R.A. A 13.5 19.5
Compressor RLA A 3 3.5
Compressor Power Input W 645 655
Overload Protector Internal Internal
Throttling Method Capillary Capillary
Operation Temp ºF 61-86 61-86
Ambient Temp (Cooling) ºF 55-83 55-83
Ambient Temp (Heating) ºF ≤75 ≤75
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32 Φ9/32
Rows-n Gap inch 3-3/64 3-3/64
Coil Length (LXDXW) inch 27 33/64X9 3/4X1 1/2 30 21/32X13 1/2X1 1/2
Fan Motor Speed rpm 1060/-/940 1060/-/940
Output of Fan Motor W 21 21
Fan Motor RLA A 0.18 0.2
Fan Motor Capacitor μF 1.5 2
Air Flow Volume of Outdoor Side CFM 471 471
Fan Type Axial-ow Axial-ow
Fan Diameter inch Φ13 47/64 Φ13 47/64
Sound Pressure Level (H/M/L) dB (A) 63/-/61 63/-/61
Sound Power Level (H/M/L) dB (A) 73/-/71 73/-/71
Defrosting Method / /
Note: The connection pipe applies metric diameter.

Service Manual
Technical Information
10
Parameter Unit Value
Model KPA12B2D KPE12B2D
Product Code CC060037800_X11438 CC060038100_X11438
Power Supply
Rated Voltage V~ 230/208 230/208
Rated Frequency Hz 60 60
Phases 1 1
Cooling Capacity Btu/h 11800/11600 11800/11600
Heating Capacity Btu/h 10600/10400 /
Cooling Power Input W 1015/1000 1015/1000
Heating Power Input W 910/895 /
Cooling Power Current A 4.9/5.1 5.1/4.9
Heating Power Current A 4.2/4.7 /
Electric Heating Power Input W 3450/2820 3450/2820
Electric Heating Power Current A 15.0/13.6 15.0/13.6
Rated Input W 1306 1306
Rated Current A 7.1 7.1
Air Flow Volume(H/M/L) CFM 341/-/306 341/-/306
Dehumidifying Volume Pint/h 2.75 2.75
EER (Btu/h)/W 11.6/11.6 11.6/11.6
COP W/W 3.4/3.4 /
Application Area yd219.1-28.7 19.13-28.7
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Permissible Excessive Operating Pressure for the
Discharge Side MPa 4.3 4.3
Permissible Excessive Operating Pressure for the
Suction Side MPa 2.5 2.5
Dimension (WXHXD) inch 42X16X21 1/2 42X16X21 1/2
Dimension of Carton Box (LXWXH) inch 45X25 9/32X17 7/8 45X25 9/32X17 7/8
Dimension of Package (LXWXH) inch 45 3/64X25 13/32X18 1/2 45 3/64X25 13/32X18 1/2
Net Weight lb 118 115.8
Gross Weight lb 142.2 140
Refrigerant R410A R410A
Refrigerant Charge oz 35.3 35.27
Indoor Side
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) inch Φ4 3/4X27 51/64 Φ4 3/4X27 51/64
Fan Motor Speed(H/M/L) r/min 1130/-/970 1130/-/970
Output of Fan Motor W 23 23
Fan Motor RLA A 0.2 0.2
Fan Motor Capacitor μF 1 1
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32 Φ9/32
Row-n Gap inch 3-1/16 3-1/16
Coil Length (LXDXW) inch 27 1/2X9 1/2X1 1/2 27 1/2X9 1/2X1 1/2
Swing Motor Model / /
Output of Swing Motor W / /
Fuse A 3.15 3.15
Sound Pressure Level (H/M/L) dB (A) 53/-/50 53/-/50
Sound Power Level (H/M/L) dB (A) 63/-/60 63/-/60

Service Manual
Technical Information 11
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Outdoor
Side
Compressor Manufacturer/Trademark RECHI PRECISION CO.,LTD RECHI PRECISION CO.,LTD
Compressor Model 44B262UK&FEKD 44B262UK&FEKD
Compressor Oil NMOC Ze-Gles RB68EP or
equivalent
NMOC Ze-Gles RB68EP or
equivalent
Compressor Type Rotary Rotary
L.R.A. A 21.5 21.5
Compressor RLA A 4.7 4.7
Compressor Power Input W 1005 1005
Overload Protector Internal Internal
Throttling Method Capillary Capillary
Operation Temp ºF 61-86 61-86
Ambient Temp (Cooling) ºF 55-83 55-83
Ambient Temp (Heating) ºF ≤75 ≤75
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32 Φ9/32
Rows-n Gap inch 3-3/64 3-3/64
Coil Length (LXDXW) inch 30 21/32X13 1/2X1 1/2 30 21/32X13 1/2X1 1/2
Fan Motor Speed rpm 1130/-/970 1130/-/970
Output of Fan Motor W 23 23
Fan Motor RLA A 0.2 0.2
Fan Motor Capacitor μF 2.5 2.5
Air Flow Volume of Outdoor Side CFM 565 565
Fan Type Axial-ow Axial-ow
Fan Diameter inch Φ13 47/64 Φ13 47/64
Sound Pressure Level (H/M/L) dB (A) 66/-/63 66/-/63
Sound Power Level (H/M/L) dB (A) 76/-/73 76/-/73
Defrosting Method / /
Note: The connection pipe applies metric diameter.

Service Manual
Technical Information
12
Parameter Unit Value
Model KPE12B2P KPA12B2P
Product Code CC060040700_X11438 CC060040800_X11438
Power Supply
Rated Voltage V~ 265 265
Rated Frequency Hz 60 60
Phases 1 1
Cooling Capacity Btu/h 11800 11800
Heating Capacity Btu/h / 10600
Cooling Power Input W 1015 1015
Heating Power Input W / 910
Cooling Power Current A 4.2 4.2
Heating Power Current A / 3.7
Electric Heating Power Input W 3450 3450
Electric Heating Power Current A 13.1 13.1
Rated Input W 1264 1264
Rated Current A 5.17 5.17
Air Flow Volume(H/M/L) CFM 341/-/306 341/-/306
Dehumidifying Volume Pint/h 2.75 2.75
EER (Btu/h)/W 11.6 11.6
COP W/W / 3.4
Application Area yd219.1-28.7 19.1-28.7
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Permissible Excessive Operating Pressure for the
Discharge Side MPa 4.3 4.3
Permissible Excessive Operating Pressure for the
Suction Side MPa 2.5 2.5
Dimension (WXHXD) inch 42X16X21 1/2 42X16X21 1/2
Dimension of Carton Box (LXWXH) inch 45X25 9/32X17 7/8 45X25 9/32X17 7/8
Dimension of Package (LXWXH) inch 45 3/64X25 13/32X18 1/2 45 3/64X25 13/32X18 1/2
Net Weight lb 115.8 119.1
Gross Weight lb 140.0 143.3
Refrigerant R410A R410A
Refrigerant Charge oz 35.27 35.27
Indoor Side
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) inch Φ4 3/4X27 51/64 Φ4 3/4X27 51/64
Fan Motor Speed(H/M/L) r/min 1130/-/950 1130/-/950
Output of Fan Motor W 20 20
Fan Motor RLA A 0.2 0.2
Fan Motor Capacitor μF 1.5 1.5
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32 Φ9/32
Row-n Gap inch 3-1/16 3-1/16
Coil Length (LXDXW) inch 27 33/64X9 1/2X1 1/2 27 33/64X9 1/2X1 1/2
Swing Motor Model / /
Output of Swing Motor W / /
Fuse A 3.15 3.15
Sound Pressure Level (H/M/L) dB (A) 53/-/50 53/-/50
Sound Power Level (H/M/L) dB (A) 63/-/60 63/-/60

Service Manual
Technical Information 13
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Outdoor
Side
Compressor Manufacturer/Trademark RECHI PRECISION CO.,LTD RECHI PRECISION CO.,LTD
Compressor Model 44B267HK&FEKD 44B267HK&FEKD
Compressor Oil NMOC Ze-Gles RB68EP or
equivalent
NMOC Ze-Gles RB68EP or
equivalent
Compressor Type Rotary Rotary
L.R.A. A 19 19
Compressor RLA A 3.9 3.9
Compressor Power Input W 1010 1010
Overload Protector Internal Internal
Throttling Method Capillary Capillary
Operation Temp ºF 61-86 61-86
Ambient Temp (Cooling) ºF 55-83 55-83
Ambient Temp (Heating) ºF ≤75 ≤75
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32 Φ9/32
Rows-n Gap inch 3-3/64 3-3/64
Coil Length (LXDXW) inch 27 33/64X9 3/4X1 1/2 27 33/64X9 3/4X1 1/2
Fan Motor Speed rpm 1130/-/950 1130/-/950
Output of Fan Motor W 20 20
Fan Motor RLA A 0.2 0.2
Fan Motor Capacitor μF 2.5 2.5
Air Flow Volume of Outdoor Side CFM 565 565
Fan Type Axial-ow Axial-ow
Fan Diameter inch Φ13 47/64 Φ13 47/64
Sound Pressure Level (H/M/L) dB (A) 66/-/63 66/-/63
Sound Power Level (H/M/L) dB (A) 76/-/73 76/-/73
Defrosting Method / /
Note: The connection pipe applies metric diameter.

Service Manual
Technical Information
14
Parameter Unit Value
Model KPE15B2P KPA15B2P
Product Code CC060041100_X11438 CC060041200_X11438
Power Supply
Rated Voltage V~ 265 265
Rated Frequency Hz 60 60
Phases 1 1
Cooling Capacity Btu/h 14500 14500
Heating Capacity Btu/h / 13300
Cooling Power Input W 1390 1390
Heating Power Input W / 1255
Cooling Power Current A 5.4 5.4
Heating Power Current A / 5.0
Electric Heating Power Input W 3450 3450
Electric Heating Power Current A 13.1 13.1
Rated Input W 1684 1684
Rated Current A 7.1 7.1
Air Flow Volume(H/M/L) CFM 341/-/306 341/-/306
Dehumidifying Volume Pint/h 3.17 3.17
EER (Btu/h)/W 10.4 10.4
COP W/W / 3.1
Application Area yd221-31 21-31
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Permissible Excessive Operating Pressure for the
Discharge Side MPa 4.3 4.3
Permissible Excessive Operating Pressure for the
Suction Side MPa 2.5 2.5
Dimension (WXHXD) inch 42X16X21 1/2 42X16X21 1/2
Dimension of Carton Box (LXWXH) inch 45X25 9/32X17 7/8 45X25 9/32X17 7/8
Dimension of Package (LXWXH) inch 45 3/64X25 13/32X18 1/2 45 3/64X25 13/32X18 1/2
Net Weight lb 116.9 119.1
Gross Weight lb 141.1 143.3
Refrigerant R410A R410A
Refrigerant Charge oz 35.27 38.80
Indoor Side
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) inch Φ4 3/4X27 51/64 Φ4 3/4X27 51/64
Fan Motor Speed(H/M/L) r/min 1130/-/950 1130/-/950
Output of Fan Motor W 20 20
Fan Motor RLA A 0.2 0.2
Fan Motor Capacitor μF 1.5 1.5
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32 Φ9/32
Row-n Gap inch 3-1/16 3-1/16
Coil Length (LXDXW) inch 27 33/64X9 1/2X1 1/2 27 33/64X9 1/2X1 1/2
Swing Motor Model / /
Output of Swing Motor W / /
Fuse A 3.15 3.15
Sound Pressure Level (H/M/L) dB (A) 54/-/51 54/-/51
Sound Power Level (H/M/L) dB (A) 64/-/61 64/-/61

Service Manual
Technical Information 15
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Outdoor
Side
Compressor Manufacturer/Trademark
Panasonic Wanbao
Appliances Compressor
(Guangzhou) Co.,Ltd
Panasonic Wanbao
Appliances Compressor
(Guangzhou) Co.,Ltd
Compressor Model 5PS136LCA21 5PS136LCA21
Compressor Oil FV50S or equivalent FV50S or equivalent
Compressor Type Rotary Rotary
L.R.A. A 26 26
Compressor RLA A 5.05 5.05
Compressor Power Input W 1320 1320
Overload Protector Internal Internal
Throttling Method Capillary Capillary
Operation Temp ºF 61-86 61-86
Ambient Temp (Cooling) ºF 55-83 55-83
Ambient Temp (Heating) ºF ≤75 ≤75
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32 Φ9/32
Rows-n Gap inch 3-3/64 3-3/64
Coil Length (LXDXW) inch 27 33/64X9 3/4X1 1/2 27 33/64X9 3/4X1 1/2
Fan Motor Speed rpm 1130/-/950 1130/-/950
Output of Fan Motor W 20 20
Fan Motor RLA A 0.2 0.2
Fan Motor Capacitor μF 2.5 2.5
Air Flow Volume of Outdoor Side CFM 565 565
Fan Type Axial-ow Axial-ow
Fan Diameter inch Φ13 47/64 Φ13 47/64
Sound Pressure Level (H/M/L) dB (A) 66/-/63 66/-/63
Sound Power Level (H/M/L) dB (A) 76/-/73 76/-/73
Defrosting Method / /
Note: The connection pipe applies metric diameter.

Service Manual
Technical Information
16
Parameter Unit Value
Model KPE07B2D KPA15B2D
Product Code CC060038700_X11438 CC060039500_X11438
Power Supply
Rated Voltage V~ 230/208 230/208
Rated Frequency Hz 60 60
Phases 1 1
Cooling Capacity Btu/h 7200/7000 14500/14200
Heating Capacity Btu/h / 13300/13000
Cooling Power Input W 550/535 1390/1365
Heating Power Input W / 1255/1225
Cooling Power Current A 2.7/2.9 6.2/6.7
Heating Power Current A / 6.2/6.7
Electric Heating Power Input W 3450/2820 3450/2820
Electric Heating Power Current A 15.0/13.6 15.0/13.6
Rated Input W 774 2162
Rated Current A 3.8 12
Air Flow Volume(H/M/L) CFM 530/-/480 341/-/306
Dehumidifying Volume Pint/h 1.69 3.17
EER (Btu/h)/W 13 10.4/10.4
COP W/W / 3.1/3.1
Application Area yd211.95-19.13 21-31
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Permissible Excessive Operating Pressure for the
Discharge Side MPa 4.3 4.3
Permissible Excessive Operating Pressure for the
Suction Side MPa 2.5 2.5
Dimension (WXHXD) inch 42X16X21 1/2 42X16X21 1/2
Dimension of Carton Box (LXWXH) inch 45X25 9/32X17 7/8 45X25 9/32X17 7/8
Dimension of Package (LXWXH) inch 45 3/64X25 13/32X18 1/2 45 3/64X25 13/32X18 1/2
Net Weight lb 103.6 120.2
Gross Weight lb 127.9 144.4
Refrigerant R410A R410A
Refrigerant Charge oz 22.9 38.80
Indoor Side
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) inch Φ4 3/4X27 13/16 Φ4 3/4X27 51/64
Fan Motor Speed(H/M/L) r/min 990/880/- 1130/-/970
Output of Fan Motor W 18 23
Fan Motor RLA A 0.1 0.2
Fan Motor Capacitor μF 1 1
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32 Φ9/32
Row-n Gap inch 3-1/16 3-1/16
Coil Length (LXDXW) inch 27 33/64X9 1/2X1 1/2 27 33/64X9 1/2X1 1/2
Swing Motor Model / /
Output of Swing Motor W / /
Fuse A 3.15 3.15
Sound Pressure Level (H/M/L) dB (A) 50/-/48 54/-/51
Sound Power Level (H/M/L) dB (A) 60/-/58 64/-/61

Service Manual
Technical Information 17
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Outdoor
Side
Compressor Manufacturer/Trademark RECHI PRECISION CO.,LTD RECHI PRECISION CO.,LTD
Compressor Model 39B142GD&5DKZ 44B342UL-FEKD
Compressor Oil NMOC Ze-Gles RB68EP NMOC Ze-Gles RB68EP or
equivalent
Compressor Type Rotary Rotary
L.R.A. A 13 28.9
Compressor RLA A 2.5 5.9
Compressor Power Input W 470 1330
Overload Protector UP3-NCB Internal
Throttling Method Capillary Capillary
Operation Temp ºF 61-86 61-86
Ambient Temp (Cooling) ºF 55-83 55-83
Ambient Temp (Heating) ºF ≤75 ≤75
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ29/32 Φ9/32
Rows-n Gap inch 3-1/16 3-3/64
Coil Length (LXDXW) inch 30 11/16X13 1/2X1 1/2 27 33/64X9 3/4X1 1/2
Fan Motor Speed rpm 990/880 1130/-/970
Output of Fan Motor W 18 23
Fan Motor RLA A 0.1 0.2
Fan Motor Capacitor μF 2 2.5
Air Flow Volume of Outdoor Side CFM 800 589
Fan Type Axial-ow Axial-ow
Fan Diameter inch Φ13 47/64 Φ13 47/64
Sound Pressure Level (H/M/L) dB (A) 63/-/61 66/-/63
Sound Power Level (H/M/L) dB (A) 73/-/71 76/-/73
Defrosting Method / /
Note: The connection pipe applies metric diameter.

Service Manual
Technical Information
18
3. Outline Dimension Diagram
Unit:inch
21 1/242
16
